debug ip ospf mpls traffic-eng advertisements
debug ip dvmrp
To display information on Distance Vector Multiprotocol Routing Protocol (DVMRP) packets received and sent, use the debug ip dvmrp privileged EXEC command. The no form of this command disables debugging output.
debug ip dvmrp [detail [access-list] [in | out]]
no debug ip dvmrp [detail [access-list] [in | out]]
Syntax Description
Usage Guidelines
Use the debug ip dvmrp detail command with care. This command generates a substantial amount of output and can interrupt other activity on the router when it is invoked.
Examples
The following is sample output from the debug ip dvmrp command:
Router# debug ip dvmrpDVMRP: Received Report on Ethernet0 from 172.19.244.10DVMRP: Received Report on Ethernet0 from 172.19.244.11DVMRP: Building Report for Ethernet0 224.0.0.4DVMRP: Send Report on Ethernet0 to 224.0.0.4DVMRP: Sending IGMP Reports for known groups on Ethernet0DVMRP: Received Report on Ethernet0 from 172.19.244.10DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Building Report for Tunnel0 224.0.0.4DVMRP: Send Report on Tunnel0 to 192.168.199.254DVMRP: Send Report on Tunnel0 to 192.168.199.254DVMRP: Send Report on Tunnel0 to 192.168.199.254DVMRP: Send Report on Tunnel0 to 192.168.199.254DVMRP: Radix tree walk suspensionDVMRP: Send Report on Tunnel0 to 192.168.199.254The following lines show that the router received DVMRP routing information and placed it in the mroute table:
DVMRP: Received Report on Ethernet0 from 172.19.244.10DVMRP: Received Report on Ethernet0 from 172.19.244.11The following lines show that the router is creating a report to send to another DVMRP router:
DVMRP: Building Report for Ethernet0 224.0.0.4DVMRP: Send Report on Ethernet0 to 224.0.0.4Table 71 provides a list of internet multicast addresses supported for host IP implementations.
The following lines show that a protocol update report has been sent to all known multicast groups. Hosts use IGMP reports to communicate with routers and to request to join a multicast group. In this case, the router is sending an IGMP report for every known group to the host, which is running mrouted. The host the responds as though the router was a host on the LAN segment that wants to receive multicast packets for the group.
DVMRP: Sending IGMP Reports for known groups on Ethernet0The following is sample output from the debug ip dvmrp detail command:
Router# debug ip dvmrp detailDVMRP: Sending IGMP Reports for known groups on Ethernet0DVMRP: Advertise group 224.2.224.2 on Ethernet0DVMRP: Advertise group 224.2.193.34 on Ethernet0DVMRP: Advertise group 224.2.231.6 on Ethernet0DVMRP: Received Report on Tunnel0 from 192.168.199.254DVMRP: Origin 150.166.53.0/24, metric 13, distance 0DVMRP: Origin 150.166.54.0/24, metric 13, distance 0DVMRP: Origin 150.166.55.0/24, metric 13, distance 0DVMRP: Origin 150.166.56.0/24, metric 13, distance 0DVMRP: Origin 150.166.92.0/24, metric 12, distance 0DVMRP: Origin 150.166.100.0/24, metric 12, distance 0DVMRP: Origin 150.166.101.0/24, metric 12, distance 0DVMRP: Origin 150.166.142.0/24, metric 8, distance 0DVMRP: Origin 150.166.200.0/24, metric 12, distance 0DVMRP: Origin 150.166.237.0/24, metric 12, distance 0DVMRP: Origin 150.203.5.0/24, metric 8, distance 0The following lines show that this group is available to the DVMRP router. The mrouted process on the host will forward the source and multicast information for this group through the DVMRP cloud to other members.
DVMRP: Advertise group 224.2.224.2 on Ethernet0The following lines show the DVMRP route information:
DVMRP: Origin 150.166.53.0/24, metric 13, distance 0DVMRP: Origin 150.166.54.0/24, metric 13, distance 0The metric is the number of hops the route has covered, and the distance is the administrative distance.
debug ip eigrp
To display information on Enhanced Interior Gateway Routing Protocol (EIGRP) packets, use the debug ip eigrp privileged EXEC command. The no form of this command disables debugging output.
debug ip eigrp
no debug ip eigrp
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
This command helps you analyze the packets that are sent and received on an interface. Because the debug ip eigrp command generates a substantial amount of output, only use it when traffic on the network is light.
Examples
The following is sample output from the debug ip eigrp command:
Router# debug ip eigrpIP-EIGRP: Processing incoming UPDATE packetIP-EIGRP: Ext 192.168.3.0 255.255.255.0 M 386560 - 256000 130560 SM 360960 - 256000 104960IP-EIGRP: Ext 192.168.0.0 255.255.255.0 M 386560 - 256000 130560 SM 360960 - 256000 104960IP-EIGRP: Ext 192.168.3.0 255.255.255.0 M 386560 - 256000 130560 SM 360960 - 256000 104960IP-EIGRP: 172.69.43.0 255.255.255.0, - do advertise out Ethernet0/1IP-EIGRP: Ext 172.69.43.0 255.255.255.0 metric 371200 - 256000 115200IP-EIGRP: 192.135.246.0 255.255.255.0, - do advertise out Ethernet0/1IP-EIGRP: Ext 192.135.246.0 255.255.255.0 metric 46310656 - 45714176 596480IP-EIGRP: 172.69.40.0 255.255.255.0, - do advertise out Ethernet0/1IP-EIGRP: Ext 172.69.40.0 255.255.255.0 metric 2272256 - 1657856 614400IP-EIGRP: 192.135.245.0 255.255.255.0, - do advertise out Ethernet0/1IP-EIGRP: Ext 192.135.245.0 255.255.255.0 metric 40622080 - 40000000 622080IP-EIGRP: 192.135.244.0 255.255.255.0, - do advertise out Ethernet0/1Table 72 describes the significant fields shown in the display.
debug ip error
To display IP errors, use the debug ip error command in privileged EXEC mode. To disable debugging errors, use the no form of this command.
debug ip error access-list-number [detail] [dump]
no debug ip error
Syntax Description
Defaults
No default behavior or values
Command Modes
Privileged EXEC
Usage Guidelines
This command is used for IP error debugging. The output displays IP errors which are locally detected by this router.
CautionEnabling this command will generate output only if IP errors occur. However, if the router starts to receive many packets that contain errors, substantial output may be generated and severely affect system performance. This command should be used with caution in production networks. It should only be enabled when traffic on the IP network is low, so other activity on the system is not adversely affected. Enabling the detail and dump keywords use the highest level of system resources of the available configuration options for this command, so a high level of caution should be applied when enabling either of these keywords.
Caution
Examples
The following is sample output from the debug ip error command:
debug ip errorIP packet errors debugging is on04:04:45:IP:s=10.8.8.1 (Ethernet0/1), d=10.1.1.1, len 28, dispose ip.hopcountThe IP error in the above output was caused when the router attempted to forward a packet with a time-to-live (TTL) value of 0. The "ip.hopcount" traffic counter is incremented when a packet is dropped because of an error. This error is also displayed in the output of the show ip traffic command by the "bad hop count" traffic counter.
Table 73 describes the significant fields shown in the display.
The following is sample output from the debug ip error command enabled with the detail keyword:
debug ip error detailIP packet errors debugging is on (detailed)
1d08h:IP:s=10.0.19.100 (Ethernet0/1), d=10.1.1.1, len 28, dispose udp.noport
1d08h: UDP src=41921, dst=33434
1d08h:IP:s=10.0.19.100 (Ethernet0/1), d=10.2.2.2, len 28, dispose ip.hopcount
1d08h: UDP src=33691, dst=33434The detailed output includes layer 4 information in addition to the standard output. The IP error in the above output was caused when the router received a UDP packet when no application was listening to the UDP port. The "udp.noport" traffic counter is incremented when the router drops a UDP packet because of this error. This error is also displayed in the output of the show ip traffic command by the "no port" traffic counter under "UDP statistics."
Table 74 describes the significant fields shown in the display.
The following is sample output from the debug ip error command enabled with the detail and dump keywords:
debug ip error detail dumpIP packet errors debugging is on (detailed) (dump)1d08h:IP:s=10.0.19.100 (Ethernet0/1), d=10.1.1.1, len 28, dispose udp.noport1d08h: UDP src=37936, dst=3343403D72360: 0001 42AD4242 ..B-BB03D72370:0002FCA5 DC390800 4500001C 30130000 ..|%\9..E...0...03D72380:01116159 0A001364 0A010101 9430829A ..aY...d.....0..03D72390:0008C0AD ..@-1d08h:IP:s=10.0.19.100 (Ethernet0/1), d=10.2.2.2, len 28, dispose ip.hopcount1d08h: UDP src=41352, dst=3343403C01600: 0001 42AD4242 ..B-BB03C01610:0002FCA5 DC390800 4500001C 302A0000 ..|%\9..E...0*..03C01620:01116040 0A001364 0A020202 A188829A ..`@...d....!...03C01630:0008B253 ..2S
Note
The output from the debug ip error command, when the dump keyword is enabled, provides raw packet data in hexadecimal and ASCII forms. This addtional output is displayed in addition to the standard output. The dump keyword can be used with all of the available configuration options of this command.
Table 75 describes the standard output fields shown in the display.
Related Commands
debug ip ftp
To activate the debugging option to track the transactions submitted during an FTP session, use the debug ip ftp privileged EXEC command. To disable debugging output, use the no form of this command.
debug ip ftp
no debug ip ftp
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
The debug ip ftp command is useful for debugging problems associated with FTP.
Examples
The following is an example of the debug ip ftp command:
Router# debug ip ftpFTP transactions debugging is onThe following is sample output from the debug ip ftp command:
FTP: 220 ProFTPD 1.2.0pre8 Server (DFW Nostrum FTP Server) [defiant.dfw.nostrum.com]Dec 27 22:12:09.133: FTP: ---> USER routerDec 27 22:12:09.133: FTP: 331 Password required for router.Dec 27 22:12:09.137: FTP: ---> PASS WQHK5JY2Dec 27 22:12:09.153: FTP: 230 Anonymous access granted, restrictions apply.Dec 27 22:12:09.153: FTP: ---> TYPE IDec 27 22:12:09.157: FTP: 200 Type set to I.Dec 27 22:12:09.157: FTP: ---> PASV..............Dec 27 22:12:09.173: FTP: ---> QUITDec 27 22:12:09.181: FTP: 221 Goodbye.
debug ip http authentication
To troubleshoot HTTP authentication problems, use privileged EXEC command. The no form of this command disables debugging output.
debug ip http authentication
no debug ip http authentication
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
The debug ip http authentication command displays the authentication method the router attempted and authentication-specific status messages.
Examples
The following is sample output from the debug ip http authentication command:
Router# debug ip http authenticationAuthentication for url `/' `/' level 15 privless `/'Authentication username = `local15' priv-level = 15 auth-type = localTable 76 describes the significant fields shown in the display.
debug ip http ezsetup
To display the configuration changes that occur during the EZ Setup process, use the debug ip http ezsetup privileged EXEC command. The no form of this command disables debugging output.
debug ip http ezsetup
no debug ip http ezsetup
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
Use the debug ip http ezsetup command to verify the EZ Setup actions without changing the configuration of the router.
EZ Setup is a form you fill out to perform basic router configuration from most HTML browsers.
Examples
The following is sample output from the debug ip http ezsetup that shows the configuration changes for the router when the EZ Setup form has been submitted:
Router# debug ip http ezsetupservice timestamps debugservice timestamps logservice password-encryption!hostname router-name!enable secret router-pwline vty 0 4password router-pw!interface ethernet 0ip address 172.69.52.9 255.255.255.0no shutdownip helper-address 172.31.2.132ip name-server 172.31.2.132isdn switch-type basic-5essusername Remote-name password Remote-chapinterface bri 0ip unnumbered ethernet 0encapsulation pppno shutdowndialer map ip 192.168.254.254 speed 56 name Remote-name Remote-numberisdn spid1 spid1isdn spid2 spid2ppp authentication chap callindialer-group 1!ip classlessaccess-list 101 deny udp any any eq snmpaccess-list 101 deny udp any any eq ntpaccess-list 101 permit ip any anydialer-list 1 list 101ip route 0.0.0.0 0.0.0.0 192.168.254.254ip route 192.168.254.254 255.255.255.255 bri 0logging bufferedsnmp-server community public ROip http serverip classlessip subnet-zero!endRelated Commands
Displays individual tokens parsed by the HTTP server.
Displays HTTP server transaction processing.
Displays the URLs accessed from the router.
debug ip http ssi
To display information about the HTML SSI EXEC command or HTML SSI ECHO command, use the debug ip http ssi privileged EXEC command. The no form of this command disables debugging output.
debug ip http ssi
no debug ip http ssi
Syntax Description
This command has no arguments or keywords.
Examples
The following is sample output from the debug ip http ssi command:
Router# debug ip http ssiHTML: filtered command `exec cmd="show users"'HTML: SSI command `exec'HTML: SSI tag `cmd' = "show users"HTML: Executing CLI `show users' in mode `exec' doneThe following line shows the contents of the SSI EXEC command:
HTML: filtered command `exec cmd="show users"'The following line indicates the type of SSI command that was requested:
HTML: SSI command `exec'The following line shows the argument show users assigned to the tag cmd:
HTML: SSI tag 'cmd' = "show users"The following line indicates that the
show users command is being executed in EXEC mode:
HTML: Executing CLI `show users' in mode `exec' donedebug ip http token
To display individual tokens parsed by the HTTP server, use the debug ip http token privileged EXEC command. The no form of this command disables debugging output.
debug ip http token
no debug ip http token
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
Use the debug ip http token command to display low-level HTTP server parsings. To display high-level HTTP server parsings, use the debug ip http transaction command.
Examples
The following is part of a sample output from the debug ip http token command. In this example, the browser accessed the router's home page http://router-name/. The output gives the token parsed by the HTTP server and its length.
Router# debug ip http tokenHTTP: token len 3: 'GET'HTTP: token len 1: ' 'HTTP: token len 1: '/'HTTP: token len 1: ' 'HTTP: token len 4: 'HTTP'HTTP: token len 1: '/'HTTP: token len 1: '1'HTTP: token len 1: '.'HTTP: token len 1: '0'HTTP: token len 2: '\15\12'HTTP: token len 7: 'Referer'HTTP: token len 1: ':'HTTP: token len 1: ' 'HTTP: token len 4: 'http'HTTP: token len 1: ':'HTTP: token len 1: '/'HTTP: token len 1: '/'HTTP: token len 3: 'www'HTTP: token len 1: '.'HTTP: token len 3: 'thesite'HTTP: token len 1: '.'HTTP: token len 3: 'com'HTTP: token len 1: '/'HTTP: token len 2: '\15\12'HTTP: token len 10: 'Connection'HTTP: token len 1: ':'HTTP: token len 1: ' 'HTTP: token len 4: 'Keep'HTTP: token len 1: '-'HTTP: token len 5: 'Alive'HTTP: token len 2: '\15\12'HTTP: token len 4: 'User'HTTP: token len 1: '-'HTTP: token len 5: 'Agent'HTTP: token len 1: ':'HTTP: token len 1: ' 'HTTP: token len 7: 'Mozilla'HTTP: token len 1: '/'HTTP: token len 1: '2'HTTP: token len 1: '.'...Related Commands
Displays the configuration changes that occur during the EZ Setup process.
Displays HTTP server transaction processing.
Displays the URLs accessed from the router.
debug ip http transaction
To display HTTP server transaction processing, use the debug ip http transaction privileged EXEC command. The no form of this command disables debugging output.
debug ip http transaction
no debug ip http transaction
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
Use the debug ip http transaction command to display what the HTTP server is parsing at a high level. To display what the HTTP server is parsing at a low level, use the debug ip http token command.
Examples
The following is sample output from the debug ip http transaction command. In this example, the browser accessed the router's home page http://router-name/.
Router# debug ip http transactionHTTP: parsed uri '/'HTTP: client version 1.0HTTP: parsed extension RefererHTTP: parsed line http://www.company.com/HTTP: parsed extension ConnectionHTTP: parsed line Keep-AliveHTTP: parsed extension User-AgentHTTP: parsed line Mozilla/2.01 (X11; I; FreeBSD 2.1.0-RELEASE i386)HTTP: parsed extension HostHTTP: parsed line router-nameHTTP: parsed extension AcceptHTTP: parsed line image/gif, image/x-xbitmap, image/jpeg, image/HTTP: parsed extension AuthorizationHTTP: parsed authorization type BasicHTTP: received GET ''Table 77 lists describes some of the fields in the output.
Related Commands
Displays the configuration changes that occur during the EZ Setup process.
Displays individual tokens parsed by the HTTP server.
Shows the URLs accessed from the router.
debug ip http url
To show the URLs accessed from the router, use the debug ip http url privileged EXEC command. The no form of this command disables debugging output.
debug ip http url
no debug ip http url
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
Use the debug ip http url command to keep track of the URLs that are accessed and to determine from which hosts the URLs are accessed.
Examples
The following output is from the debug ip http url command. In this example, the HTTP server accessed the URLs and /exec. The output shows the URL being requested and the IP address of the host requesting the URL.
Router# debug ip http urlHTTP: processing URL '/' from host 172.31.2.141HTTP: processing URL '/exec' from host 172.31.2.141Related Commands
Displays the configuration changes that occur during the EZ Setup process.
Displays individual tokens parsed by the HTTP server.
Displays HTTP server transaction processing.
debug ip icmp
To display information on Internal Control Message Protocol (ICMP) transactions, use the debug ip icmp privileged EXEC command. The no form of this command disables debugging output.
debug ip icmp
no debug ip icmp
Syntax Description
This command has no arguments or keywords.
Usage Guidelines
This command helps you determine whether the router is sending or receiving ICMP messages. Use it, for example, when you are troubleshooting an end-to-end connection problem.
Note
Examples
The following is sample output from the debug ip icmp command:
Router# debug ip icmpICMP: rcvd type 3, code 1, from 10.95.192.4ICMP: src 10.56.0.202, dst 172.69.16.1, echo replyICMP: dst (10.120.1.0) port unreachable rcv from 10.120.1.15ICMP: src 172.69.12.35, dst 172.69.20.7, echo replyICMP: dst (255.255.255.255) protocol unreachable rcv from 10.31.7.21ICMP: dst (10.120.1.0) port unreachable rcv from 10.120.1.15ICMP: dst (255.255.255.255) protocol unreachable rcv from 10.31.7.21ICMP: dst (10.120.1.0) port unreachable rcv from 10.120.1.15ICMP: src 10.56.0.202, dst 172.69.16.1, echo replyICMP: dst (10.120.1.0) port unreachable rcv from 10.120.1.15ICMP: dst (255.255.255.255) protocol unreachable rcv from 10.31.7.21ICMP: dst (10.120.1.0) port unreachable rcv from 10.120.1.15Table 78 describes the significant fields shown in the display.
Table 79 describes the significant fields in the second line of the display.
Other messages that the debug ip icmp command can generate follow.
When an IP router or host sends out an ICMP mask request, the following message is generated when the router sends a mask reply:
ICMP: sending mask reply (255.255.255.0) to 172.69.80.23 via Ethernet0The following two lines are examples of the two forms of this message. The first form is generated when a mask reply comes in after the router sends out a mask request. The second form occurs when the router receives a mask reply with a nonmatching sequence and ID. Refer to Appendix I of RFC 950, Internet Standard Subnetting Procedures, for details.
ICMP: mask reply 255.255.255.0 from 172.69.80.31ICMP: unexpected mask reply 255.255.255.0 from 172.69.80.32The following output indicates that the router sent a redirect packet to the host at address 172.69.80.31, instructing that host to use the gateway at address 172.69.80.23 in order to reach the host at destination address 172.69.1.111:
ICMP: redirect sent to 172.69.80.31 for dest 172.69.1.111 use gw 172.69.80.23The following message indicates that the router received a redirect packet from the host at address 172.69.80.23, instructing the router to use the gateway at address 172.69.80.28 in order to reach the host at destination address 172.69.81.34:
ICMP: redirect rcvd from 172.69.80.23 -- for 172.69.81.34 use gw 172.69.80.28The following message is displayed when the router sends an ICMP packet to the source address (172.69.94.31 in this case), indicating that the destination address (172.69.13.33 in this case) is unreachable:
ICMP: dst (172.69.13.33) host unreachable sent to 172.69.94.31The following message is displayed when the router receives an ICMP packet from an intermediate address (172.69.98.32 in this case), indicating that the destination address (172.69.13.33 in this case) is unreachable:
ICMP: dst (172.69.13.33) host unreachable rcv from 172.69.98.32Depending on the code received (as Table 78 describes), any of the unreachable messages can have any of the following "strings" instead of the "host" string in the message:
netprotocolportfrag. needed and DF setsource route failedprohibitedThe following message is displayed when the TTL in the IP header reaches zero and a time exceed ICMP message is sent. The fields are self-explanatory.
ICMP: time exceeded (time to live) send to 10.95.1.4 (dest was 172.69.1.111)The following message is generated when parameters in the IP header are corrupted in some way and the parameter problem ICMP message is sent. The fields are self-explanatory.
ICMP: parameter problem sent to 128.121.1.50 (dest was 172.69.1.111)Based on the preceding information, the remaining output can be easily understood:
ICMP: parameter problem rcvd 172.69.80.32ICMP: source quench rcvd 172.69.80.32ICMP: source quench sent to 128.121.1.50 (dest was 172.69.1.111)ICMP: sending time stamp reply to 172.69.80.45ICMP: sending info reply to 172.69.80.12ICMP: rdp advert rcvd type 9, code 0, from 172.69.80.23ICMP: rdp solicit rcvd type 10, code 0, from 172.69.80.43debug ip igmp
To display Internet Group Management Protocol (IGMP) packets received and sent, and IGMP-host related events, use the debug ip igmp privileged EXEC command. To disable debugging output, use the no form of this command.
debug ip igmp
no debug ip igmp
Syntax Description
This command has no arguments or keywords.
Defaults
None
Command History
10.2
This command was introduced.
12.1(3)T
Additional fields were added to the output of this command to support the Source Specific Multicast (SSM) feature.
Usage Guidelines
This command helps discover whether the IGMP processes are functioning. In general, if IGMP is not working, the router process never discovers that another host is on the network that is configured to receive multicast packets. In dense mode, this situation will result in packets being delivered intermittently (a few every 3 minutes). In sparse mode, packets will never be delivered.
Use this command in conjunction with the debug ip pim and debug ip mrouting commands to observe additional multicast activity and to learn the status of the multicast routing process, or why packets are forwarded out of particular interfaces.
Examples
The following is sample output from the debug ip igmp command:
Router# debug ip igmpIGMP: Received Host-Query from 172.69.37.33 (Ethernet1)IGMP: Received Host-Report from 172.69.37.192 (Ethernet1) for 224.0.255.1IGMP: Received Host-Report from 172.69.37.57 (Ethernet1) for 224.2.127.255IGMP: Received Host-Report from 172.69.37.33 (Ethernet1) for 225.2.2.2The messages displayed by the debug ip igmp command show query and report activity received from other routers and multicast group addresses.
The following is sample output from the debug ip igmp command when SSM is enabled. Because IGMP Version 3 lite (IGMP v3lite) requires the host to send IGMP Version 2 (IGMPv2) packets, IGMPv2 host reports also will be displayed in response to the router IGMPv2 queries. If SSM is disabled, the word "ignored" will be displayed in the debug ip igmp command output.
IGMP:Received v3-lite Report from 10.0.119.142 (Ethernet3/3), group count 1IGMP:Received v3 Group Record from 10.0.119.142 (Ethernet3/3) for 232.10.10.10IGMP:Update source 1.1.1.1IGMP:Send v2 Query on Ethernet3/3 to 224.0.0.1IGMP:Received v2 Report from 10.0.119.142 (Ethernet3/3) for 232.10.10.10IGMP:Update source 1.1.1.1Related Commands
debug ip mrm
Displays MRM control packet activity.
debug ip pim
Displays PIM packets received and sent, and PIM-related events.
debug ip igrp events
To display summary information on Interior Gateway Routing Protocol (IGRP) routing messages that indicate the source and destination of each update, and the number of routes in each update, use the debug ip igrp events privileged EXEC command. The no form of this command disables debugging output.
debug ip igrp events [ip-address]
no debug ip igrp events [ip-address]
Syntax Description
Usage Guidelines
If the IP address of an IGRP neighbor is specified, the resulting debug ip igrp events output includes messages describing updates from that neighbor and updates that the router broadcasts toward that neighbor. Messages are not generated for each route.
This command is particularly useful when there are many networks in your routing table. In this case, using debug ip igrp transactions could flood the console and make the router unusable. Use debug ip igrp events instead to display summary routing information.
Examples
The following is sample output from the debug ip igrp events command:
This shows that the router has sent two updates to the broadcast address 255.255.255.255. The router also received two updates. Three lines of output describe each of these updates.
The first line indicates whether the router sent or received the update packet, the source or destination address, and the interface through which the update was sent or received. If the update was sent, the IP address assigned to this interface is shown (in parentheses).
IGRP: sending update to 255.255.255.255 via Ethernet1 (160.89.33.8)The second line summarizes the number and types of routes described in the update:
IGRP: Update contains 26 interior, 40 system, and 3 exterior routes.The third line indicates the total number of routes described in the update:
IGRP: Total routes in update: 69debug ip igrp transactions
To display transaction information on Interior Gateway Routing Protocol (IGRP) routing transactions, use the debug ip igrp transactions privileged EXEC command. The no form of this command disables debugging output.
debug ip igrp transactions [ip-address]
no debug ip igrp transactions [ip-address]
Syntax Description
Usage Guidelines
If the IP address of an IGRP neighbor is specified, the resulting debug ip igrp transactions output includes messages describing updates from that neighbor and updates that the router broadcasts toward that neighbor.
When many networks are in your routing table, the debug ip igrp transactions command can flood the console and make the router unusable. In this case, use the debug ip igrp events command instead to display summary routing information.
Examples
The following is sample output from the debug ip igrp transactions command:
The output shows that the router being debugged has received updates from two other routers on the network. The router at source address 160.89.80.240 sent information about ten destinations in the update; the router at source address 160.89.80.28 sent information about three destinations in its update. The router being debugged also sent updates—in both cases to the broadcast address 255.255.255.255 as the destination address.
On the second line the first field refers to the type of destination information: "subnet" (interior), "network" (system), or "exterior" (exterior). The second field is the Internet address of the destination network. The third field is the metric stored in the routing table and the metric advertised by the neighbor sending the information. "Metric... inaccessible" usually means that the neighbor router has put the destination in a hold down state.
The entries show that the router is sending updates that are similar, except that the numbers in parentheses are the source addresses used in the IP header. A metric of 16777215 is inaccessible.
Other examples of output that the debug ip igrp transactions command can produce follow.
The following entry indicates that the routing table was updated and shows the new edition number (97 in this case) to be used in the next IGRP update:
IGRP: edition is now 97Entries such as the following occur on startup or when some event occurs such as an interface making a transition or a user manually clearing the routing table:
IGRP: broadcasting request on Ethernet0IGRP: broadcasting request on Ethernet1The following type of entry can result when routing updates become corrupted between sending and receiving routers:
IGRP: bad checksum from 172.69.64.43An entry such as the following should never appear. If it does, the receiving router has a bug in the software or a problem with the hardware. In either case, contact your technical support representative.
IGRP: system 45 from 172.69.64.234, should be system 109debug ip inspect
To display messages about Context-Based Access Control (CBAC) events, use the debug ip inspect privileged EXEC command. The no form of this command disables debugging output.
debug ip inspect {function-trace | object-creation | object-deletion | events | timers | protocol | detailed}
no debug ip inspect detailed
Syntax Description
