Release Notes for Cisco 3600 Series for Cisco IOS Release 12.1 YD

June 17, 2002

Cisco IOS Release 12.1(5) YD6

78-12643-01 Rev. F1

These release notes for the AS5300 universal access servers series describe the enhancements provided in Cisco IOS Release 12.1(5) YD6. These release notes are updated as needed.

For a list of the software caveats that apply to Release 12.1(5) YD6, see Caveats for Cisco IOS Release 12.1(5) YD and Caveats for Cisco IOS Release 12.1 T that accompanies these release notes. This caveats document is updated for every maintenance release and is also located on Cisco.com and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 located on Cisco.com and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

•Introduction

•System Requirements

•New and Changed Information

•Important Notes

•Caveats for Cisco IOS Release 12.1(5) YD

•Related Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

Introduction

The Cisco 3600 series includes the Cisco 3620, Cisco 3640, and Cisco 3660 routers. As modular solutions, the Cisco 3600 series routers enable corporations to increase dial-up density and take advantage of current and emerging WAN technologies and networking capabilities. The Cisco 3600 series routers are fully supported by Cisco IOS software, which includes dial-up connectivity, LAN-to-LAN routing, data and access security, WAN optimization, and multimedia features.

System Requirements

This section describes the system requirements for Release 12.1(5) YD6:

•Memory Recommendations

•Hardware Supported

•Determining the Software Version

•Upgrading to a New Software Release

•Feature Set Tables

Memory Recommendations

Table 1 Minimum Memory Recommendations for the Cisco 3600 Series

Platform
Image Name
Software Image
Flash Memory
Recommended
DRAM Memory
Recommended
Runs
From
Cisco 3620

IP Plus

c3620-is-mz

16 MB

64 MB

RAM

IP Plus IPSec 56

c3620-is56i-mz

16 MB

64 MB

RAM

Enterprise Plus

c3620-js-mz

32 MB

96 MB

RAM

Enterprise Plus IPSec 56

c3620-js56i-mz

32 MB

96 MB

RAM

Enterprise Plus IPSec 3DES

c3620-jk2s-mz

32 MB

96 MB

RAM

Enterprise Plus/H323 MCM

c3620-jsx-mz

32 MB

96 MB

RAM

Cisco 3640

IP Plus

c3640-is-mz

16 MB

64 MB

RAM

IP Plus IPSec 56

c3640-is56i-mz

16 MB

64 MB

RAM

Enterprise Plus

c3640-js-mz

32 MB

96 MB

RAM

Enterprise Plus IPSec 56

c3640-js56i-mz

32 MB

96 MB

RAM

Enterprise Plus IPSec 3DES

c3640-jk2s-mz

32 MB

96 MB

RAM

Enterprise Plus/H323 MCM

c3640-jsx-mz

32 MB

96 MB

RAM

Cisco 36601

IP Plus

c3660-is-mz

16 MB

64 MB

RAM

IP Plus/IPSec 56

c3660-is56i-mz

32 MB

64 MB

RAM

Enterprise Plus

c3660-js-mz

32 MB

96 MB

RAM

Enterprise Plus IPSec 56

c3660-js56i-mz

32 MB

96 MB

RAM

Enterprise Plus/IPSec 3DES

c3660-jk2s-mz

32 MB

96 MB

RAM

Enterprise Plus/H323 MCM

c3660-jsx-mz

32 MB

96 MB

RAM

1 The Cisco 3660 uses SDRAM.


Hardware Supported

Cisco IOS Release 12.1(5) YD6 supports the Cisco 3600 series routers:

•Cisco 3620

•Cisco 3640

•Cisco 3660 (3661 and 3662)

Note For important information about the ATM OC-3 network modules and compatibility with the Cisco 3620 router, please review the field notice on Cisco.com, at http://www.cisco.com/warp/customer/770/51.shtml

Table 2 lists the supported interfaces for the Cisco 3600 series routers for Cisco IOS Release 12.1(5) YD6.

Table 2 Supported Interfaces for the Cisco 3600 Series

Interface, Network Module, or Data Rate
Product Description
Platforms Supported
Mixed Media Network Modules

1-port 10/100BaseTX with 1-port channelized/PRI/E1 balanced mode (NM-1FE1CE1B)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 1-port channelized/PRI/E1 unbalanced mode (NM-1FE1CE1U)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 1-port channelized/PRI/T1(NM-1FE1CT1)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 1-port channelized/PRI/T1 with CSU (NM-1FE1CT1-CSU)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 2-port channelized/PRI/E1 balanced mode (NM-1FE2CE1B)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 2-port channelized/PRI/E1 unbalanced mode (NM-1FE2CE1U)

All Cisco 3600 series platforms

1-port 10/100BaseTX with 2-port channelized/PRI/T1 (NM-1FE2CT1)

All Cisco 3600 series platforms

Mixed Media Network Modules (Continued)

1-port 10/100BaseTX with 2-port channelized/PRI/T1 with CSU (NM-1FE2CT1-CSU)

All Cisco 3600 series platforms

1 Ethernet and 2 WAN card slots (NM-1E2W)

All Cisco 3600 series platforms

1 Ethernet, 1 Token Ring, and 2 WAN card slots (NM-1E1R2W)

All Cisco 3600 series platforms

2 Ethernet and 2 WAN card slots (NM-2E2W)

All Cisco 3600 series platforms

1-port Fast Ethernet, 1-port Token Ring with 2 WAN card slots (NM-1FE1R2W[=])

All Cisco 3600 series platforms

1-port Fast Ethernet with 2 WAN card slots (NM-1FE2W[=])

All Cisco 3600 series platforms

2-port Fast Ethernet with 2 WAN card slots (NM-2FE2W[=])

All Cisco 3600 series platforms

2 WAN card slots (NM-2W[=])

All Cisco 3600 series platforms

Dial Access Network Modules

16- and 32-port asynchronous (NM-16A and NM-32A)

All Cisco 3600 series platforms

6- to 30-port integrated digital modems network modules (NM-16DM, NM-12-DM, NM-18DM, NM-24DM, NM-30DM)

All Cisco 3600 series platforms

6-port digital modem upgrade (MICA-6MOD)

All Cisco 3600 series platforms

8- or 16-port integrated analog network modules (NM-8AM and NM-16AM)

All Cisco 3600 series platforms

LAN Interface Network Modules

1- and 4-port Ethernet (AUI and 10BaseT, NM-1E and NM-4E)

All Cisco 3600 series platforms

1-port Fast Ethernet (100BaseTX and 100BaseFX, NM-1FE-TX and NM-1FE-FX)

All Cisco 3600 series platforms

Digital T1/E1 Packet Voice Trunk Network Modules and Spare Components

1-port, 24-channel T1 voice/fax module, supports 24 channels of medium-complexity codecs: G.729a/b, G.726, G.711 and fax or 12 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, two PVDM-12s, and one VWIC-1MFT-T11 . Part number: NM-HDV-1T1-24

All Cisco 3600 series platforms

1-port, enhanced 24-channel T1 voice/fax module, supports 24 channels of high- and medium-complexity codecs: G.729a/b, G.726, G.729, G.728, G.723.1, G.711, and fax. Consists of one NM-HDV, four PVDM-12s, and one VWIC-1MFT-T12. Part number: NM-HDV-1T1-24E

All Cisco 3600 series platforms

2-port, 48-channel T1 voice/fax module, supports add/drop multiplexing (drop and insert); 48 channels of medium-complexity codecs: G.729a/b, G.726,G.711, and fax; or 24 channels of G726, G729, G723.1, G.728, G729a/b, G711, and fax. Consists of one NM-HDV, four PVDM-12, and one VWIC-2MFT-T1-DI2. Part number: NM-HDV-2T1-48

All Cisco 3600 series platforms

Digital T1/E1 Packet Voice Trunk Network Modules and Spare Components (Continued)

1-port, 30-channel E1 voice/fax module, supports 30 channels of G.729a/b, G.726, G.711 and fax or 18 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, three PVDM-12s, and one VWIC-1MFT-E11. (NM-HDV-1E1-30[=])

All Cisco 3600 series platforms

1-port, enhanced 30-channel E1 voice/fax module, supports 30 channels of G.729a/b, G.726, G.729, G.728, G.723.1, G.711, and fax. Consists of one NM-HDV, five PVDM-12s, and one VWIC-1MFT-E11. (NM-HDV-1E1-30E[=])

All Cisco 3600 series platforms

2-port, 60-channel E1 voice/fax module, supports add/drop multiplexing (drop and insert); 60 channels of G.729a/b, G.726, G.711, and fax or 30 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, five PVDM-12s, and one VWIC-2MFT-E1-D11. (NM-HDV-2E1-60[=])

All Cisco 3600 series platforms

High-density voice/fax network module spare (NM-HDV)

Digital T1 Packet Voice Trunk Network Modules spare component

12-channel packet voice DSP2 module upgrade spare (PVDM-12=)

Digital T1 Packet Voice Trunk Network Modules spare component

1-port RJ-48 multiflex trunk—T1 (VWIC-1MFT-T1)2

Digital T1 Packet Voice Trunk Network Modules spare component

2-port RJ-48 multiflex trunk—T1 (VWIC-2MFT-T1)2

Digital T1 Packet Voice Trunk Network Modules spare component

2-port RJ-48 multiflex trunk with drop and insert—T1 (VWIC-2MFT-T1-DI(=))2

Digital T1 Packet Voice Trunk Network Modules spare component

T1/E1 Multiflex Voice/WAN Interface Cards

1-port T1 multiflex trunk interface (VWIC-1MFT-T1)

All Cisco 3600 series platforms

1-port E1 multiflex trunk interface (VWIC-1MFT-E1)

All Cisco 3600 series platforms

2-port T1 multiflex trunk interface (VWIC-2MFT-T1)

All Cisco 3600 series platforms

2-port T1 multiflex trunk interface with drop and insert (VWIC-2MFT-T1-DI)3

All Cisco 3600 series platforms

2-port E1 multiflex trunk interface with drop and insert (VWIC-2MFT-E1-DI)

All Cisco 3600 series platforms

Voice/Fax Interfaces and Network Modules1

1- and 2-port voice/fax network module (NM-1V and NM-2V)

All Cisco 3600 series platforms

2-port E&M4 voice interface card (VIC-2E/M)

All Cisco 3600 series platforms with voice/fax network module

2-port FXO5 voice interface card (VIC-2FXO, VIC-2FXO-M3, and VIC-2FXO-EU)

All Cisco 3600 series platforms with voice/fax network module

2-port FXS6 voice interface card

All Cisco 3600 series platforms with voice/fax network module

2-port 7 voice interface card (VIC-2BRI-S/T-TE)

Cisco 3620 and 3640 platforms with voice/fax network module

WAN Data Rates

48/56/64 kbps8

All Cisco 3600 series platforms

1.544/2.048 Mbps9

All Cisco 3600 series platforms

Up to 8 Mbps on 4-port serial network module

All Cisco 3600 series platforms

52 Mbps max using high speed serial interface (HSSI) network module

All Cisco 3600 series platforms

Up to 100 Mbps on ATM optical carrier 3 (OC3) network modules

All Cisco 3600 series platforms

Channelized WAN Network Modules

1- and 2-port channelized T1 modules without CSUs (NM-1CT1 and NM-1CT1)

All Cisco 3600 series platforms

1- and 2-port channelized T1 network modules with CSUs (NM-1CT1-CSU and NM-2CT1-CSU)

All Cisco 3600 series platforms

1- and 2-port E1 network modules, unbalanced mode NM-1CE1U and NM-2CE1U)

All Cisco 3600 series platforms

1- and 2-port E1 network modules, balanced mode (NM-1CE1B and NM-2CE1B)

All Cisco 3600 series platforms

Asynchronous Transfer Mode (ATM) Network Modules

1-port ATM-25 network modules (NM-1ATM-25)1

All Cisco 3600 series platforms

1-port ATM T3 network module (NM-1A-T3)

All Cisco 3600 series platforms

1-port ATM E3 network module (NM-1A-E3)

All Cisco 3600 series platforms

1-port high-speed serial interface (HSSI) network module

All Cisco 3600 series platforms

4- and 8-port BRI network module with network termination 1 (NT1) interface (NM-4B-U and NM-8B-U)

All Cisco 3600 series platforms

4- and 8-port BRI network module with S/T interface (NM-4B-S/T and NM-8B-S/T)

All Cisco 3600 series platforms

4- and 8-port synchronous/asynchronous (NM-4A/S and NM-8A/S)

All Cisco 3600 series platforms

16- and 32-port asynchronous (NM-16A and NM-32A)

All Cisco 3600 series platforms

4-port serial (NM-4T)

All Cisco 3600 series platforms

1-port ATM OC-3 network module with multimode fiber (NM-1A-OC3MM)

All Cisco 3600 series platforms

1-port ATM OC-3 network module with single-mode intermediate reach fiber (NM-1A-OC3SMI)

All Cisco 3600 series platforms

1-port ATM OC-3 network module with single-mode long reach fiber (NM-1A-OC3SML)

All Cisco 3600 series platforms

1-port ATM OC-3 multimode network module and circuit emulation service (NM-1A-OC3MM-1V)10

All Cisco 3600 series platforms

1-port ATM OC-3 single-mode, intermediate reach network module and circuit emulation service (NM-1A-OC3SMI-1V)10

All Cisco 3600 series platforms

1-port ATM OC-3 single-mode, long reach network module and circuit emulation service (NM-1A-OC3SML-1V)10

All Cisco 3600 series platforms

4-port T1 ATM network module with IMA11 (NM-4T1-IMA)

All Cisco 3600 series platforms

4-port E1 ATM network module with IMA (NM-4E1-IMA)

All Cisco 3600 series platforms

8-port T1 ATM network module with IMA (NM-8T1-IMA)

All Cisco 3600 series platforms

8-port E1 ATM network module with IMA (NM-8E1-IMA)

All Cisco 3600 series platforms

Advanced Integration Modules (AIM)

4 E1 data compression advanced integration module (AIM-COMPR4)

Cisco 3660 series platforms

Data encryption AIM (NM-VPM-HP)

Cisco 3660 series platforms

Other Network Modules

Data compression network module (NM-COMPR)

Cisco 3620 and 3640 series platforms

Data encryption network module (NM-VPN-MP)

Cisco 3620 and 3640 series platforms

WAN Interface Cards

1-port T1/Fractional T1/DSU/CSU WAN interface card (WIC-1DSU-T1)

All Cisco 3600 series platforms

1-port T1/Fractional T1 56/64 kbps DSU/CSU WAN interface card (WIC-1DSU-56K4)

All Cisco 3600 series platforms

1-port ISDN with NT1 WAN interface card (WIC-1B-U)

All Cisco 3600 series platforms

1-port ISDN WAN interface card (WIC-1B-S/T)

All Cisco 3600 series platforms

1-port serial WAN interface card (WIC-1T)

All Cisco 3600 series platforms

2-port serial (WIC-2T[=])12

All Cisco 3600 series platforms

2-port asynchronous/synchronous (WIC-2A/S[=])

All Cisco 3600 series platforms

1 See T1/E1 Multiflex Voice/WAN Interface Cards in this table.

2 DSP = digital signal processor

3 For Cisco 3660 series, only supported in T1/E1 digital packet voice trunk network modules and new Fast Ethernet mixed media network modules: NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W. For Cisco 3620 and 3640, supported in T1/E1 digital packet voice trunk network modules or in 1- or 2-port Ethernet and Fast Ethernet network module (NM-1E2W, NM-2E2W, NM-1E1R2W, NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W)

4 E&M = recEiver and transMitter (or Ear and Mouth)

5 FXO = Foreign Exchange Office

6 FXS = Foreign Exchange Station

7 BRI = Basic Rate Interface

8 Kbps = Kilobits per second

9 Mbps = Megabits per second

10 For the Cisco 3660 series only, online insertion and removal (OIR) is now supported in Cisco IOS Release 12.1(5)T.

11 IMA =Inverse Multiplexing over ATM

12 Supported in Fast Ethernet mixed media network modules: NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W.


Determining the Software Version

To determine the version of Cisco IOS software running on a Cisco 3600 series router, log in to the router and enter the show version EXEC command:

router>show version

Cisco Internetwork Operating System Software

IOS (tm) 3620 Software (c3620-js-mz), 12.1(5) YD6, RELEASE SOFTWARE

Upgrading to a New Software Release

For general information about upgrading to a new software release, refer to Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:

http://www.cisco.com/warp/public/130/upgrade_index.shtml

Feature Set Tables

Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Table 3 lists the Cisco IOS Release12.1(5) YD6 feature set image for the Cisco IAD2420 series platforms.

Cisco IOS Release 12.1(5) YD6 supports the same feature sets as Cisco IOS Release 12.1(5) T, but Cisco IOS Release 12.1(5) YD6 can include new features supported by the Cisco 3600.

Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit Triple Data Encryption Standard [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay because of United States government regulations. When applicable, purchaser and user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.

Table 3 lists the features and feature sets supported by the Cisco 3600 series in Cisco IOS Release 12.1(5) YD6 and use the following conventions:

•Yes—The feature is supported in the software image.

•No—The feature is not supported in the software image.

Note This table does not list all the features in each image. You can find the most current Cisco IOS documentation on Cisco.com. If you have a Cisco.com login account, you can find image and release information regarding Cisco IOS Release 12.1(5) T by using the Feature Navigator tool at http://www.cisco.com/go/fn.

Table 3 Feature Lists by Feature Sets for the Cisco 3600 Series Routers


Software Images by Feature Sets
IP Plus
IP Plus
IPSec 56
Enterprise Plus
Enterprise Plus IPSec56
Enterprise/
Plus IPSec 3DES
Enterprise Plus H323 MCM

IP Keyswitch

Yes

Yes

Yes

Yes

Yes

Yes

Survivable Remote Site Telephony

Yes

Yes

Yes

Yes

Yes

Yes


New and Changed Information

The following is a list of the new hardware and software features supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) YD6.

New Hardware and Software Features in Cisco IOS Release 12.1(5) YD6

There are no new hardware and software features supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) YD6.

New Hardware and Software Features from Cisco IOS Release 12.1(5) YD1 to Cisco IOS Release 12.1(5) YD6

There are no new hardware or software features supported by the Cisco 3600 series from Cisco IOS Release 12.1(5) YD1 toCisco IOS Release 12.1(5) YD6.

New Hardware Features in Cisco IOS Release 12.1(5) YD

There are no new hardware features supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) YD.

New Software Features in Cisco IOS Release 12.1(5) YD

The following new software features are supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) YD.

IP Keyswitch

The IP Keyswitch feature provides Cisco IP phone call-handling capabilities in a LAN environment. This feature enables the Cisco 2600 series to provide IP Keyswitch capability integrated in the router for the Cisco IP Phone 7960, Cisco IP Phone 7940, and Cisco IP Phone 7910. It loads phone images, and configures, and manages the Cisco IP phones in your LAN. It also provides a host of features such as call forwarding, call transfer, and hold, for example. The IP Keyswitch feature provides you with integrated call processing capabilities for a small office with up to 48 extensions.

Refer to the following documents for further information:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121limit/121yd/121yd_5/ipkeys.htm

Survivable Remote Site Telephony

The Survivable Remote Site Telephony feature provides the Cisco CallManager with fallback support for the Cisco IP phones attached to the router on your local Ethernet. Cisco IOS Release 12.1(5)YD integrates this feature on the Cisco 2600 series and enables the routers to provide call handling support for the Cisco IP phones when the Cisco IP phones lose connection to the remote primary, secondary, or tertiary Cisco CallManager or when the WAN connection is down.

The Cisco CallManager 3.0 supports Cisco IP phones at remote sites attached to Cisco branch office multi-service routers across the WAN. Prior to Survivable Remote Site Telephony, when the WAN connection between the remote branch office router and the Cisco CallManager failed, or connectivity with the Cisco CallManager was lost for some other reason, the Cisco IP phones at the branch office became unusable for the duration of the failure. To overcome this problem the Survivable Remote Site Telephony feature was developed. The feature provides call-handling support on the branch-office router for its attached Cisco IP phones when a failure occurs. The system automatically detects the failure, and using Simple Network Auto Provisioning (SNAP) technology, auto configures the branch office router to provide call processing service for the local IP phones. When the failure is restored, call-handling capabilities for the Cisco IP phones switch back to the primary Cisco CallManager. During a failure, the Cisco IP phone displays a message to inform the user that the Cisco IP phone is in the Cisco CallManager fallback mode and is able to perform a limited set of functions.

Refer to the following documents for further information:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121limit/121yd/121yd_5/fallback.htm

Important Notes

Product Number Change

Beginning with Cisco IOS Release 12.0(7)XK, Cisco changed the product numbers you use to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.

Old Product Number
New Product Number
Release
Image Description

S364AR1K2-12.1.3=

S364AR1K2-1213=

Cisco IOS Release 12.1(3)

Cisco 3640 Series IOS Enterprise/SNA SW PLUS IPSEC 3DES

S26CP-12.1.3=

S26CP-12103=

Cisco IOS Release 12.1(3)

Cisco 2600 Series IOS IP Plus


Deprecated MIBs

To obtain lists of supported MIBs by platform and Cisco IOS release, and to download MIB modules, go to the Cisco MIB website on Cisco.com at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.

Deprecated and Replacement MIBs

Old Cisco MIBs will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs without affecting existing Cisco IOS products or network management system (NMS) applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 4.

Table 4 Deprecated MIBs

Deprecated MIB
Replacement

OLD-CISCO-APPLETALK-MIB

RFC1243-MIB

OLD-CISCO-CHASSIS-MIB

ENTITY-MIB

OLD-CISCO-CPUK-MIB

In Development

OLD-CISCO-DECNET-MIB

In Development

OLD-CISCO-ENV-MIB

CISCO-ENVMON-MIB

OLD-CISCO-FLASH-MIB

CISCO-FLASH-MIB

OLD-CISCO-INTERFACES-MIB

IF-MIB CISCO-QUEUE-MIB

OLD-CISCO-IP-MIB

In Development

OLD-CISCO-MEMORY-MIB

CISCO-MEMORY-POOL-MIB

OLD-CISCO-NOVELL-MIB

NOVELL-IPX-MIB

OLD-CISCO-SYS-MIB

(Compilation of other OLD* MIBS)

OLD-CISCO-SYSTEM-MIB

CISCO-CONFIG-COPY-MIB

OLD-CISCO-TCP-MIB

CISCO-TCP-MIB

OLD-CISCO-TS-MIB

In Development

OLD-CISCO-VINES-MIB

CISCO-VINES-MIB

OLD-CISCO-XNS-MIB

In Development


Caveats for Cisco IOS Release 12.1(5) YD

Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

This section contains only open and resolved caveats for the current Cisco IOS maintenance release.

All caveats in Cisco IOS Release 12.1 are also in Cisco IOS Release 12.1 T.

For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1

For information on caveats in Cisco IOS Release 12.1 T, see Caveats for Cisco IOS Release 12.1T,  which lists severity 1 and 2 caveats and select severity 3 caveats and is located on Cisco.com and the Documentation CD-ROM.

Caveat numbers and brief descriptions for Cisco IOS Release 12.1(5) YD6 are listed in Table 5. For details about a particular caveat, go to Bug Toolkit at:

http://www.cisco.com/kobayashi/bugs/bugs.html

To access this location, you must have an account on Cisco.com. For information about how to obtain an account, go to the "Feature Navigator" section.

Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, log in to Cisco.com and click Service and Support: Technical Assistance Center: Select & Download Software: Jump to a software resource: Software Bug Toolkit/Bug Watcher. Another option is to go to http://www.cisco.com/support/bugtools/.

Open Caveats—Cisco IOS Release 12.1(5) YD6

There are no open caveats specific to Cisco IOS Release 12.1(5) YD6 that require documentation in the release notes.

Resolved Caveats—Cisco IOS Release 12.1(5) YD6

All the caveats listed in Table 5 are resolved in Cisco IOS Release 12.1(5) YD6. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 5 Resolved Caveats for Release 12.1(5) YD6

Caveat ID Number
Description

CSCdw65903

An error can occur with management protocol processing. Please use the following URL for further information:

http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903


Open Caveats—Cisco IOS Release 12.1(5) YD5

There are no open caveats specific to Cisco IOS Release 12.1(5) YD5 that require documentation in the release notes.

Resolved Caveats—Cisco IOS Release 12.1(5) YD5

All the caveats listed in Table 6 are resolved in Cisco IOS Release 12.1(5) YD5. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 6 Resolved Caveats for Release 12.1(5) YD5

Caveat ID Number
Description

CSCds26949

Gateway does not set PUSH bit in TCP header for h225-q931 msgs

CSCdu53333

DSP does not respond - seeing%VTSP-3-DSP_TIMEOUT

CSCdv43814

VOIP leg MOH stream not played out to POTS leg

CSCdv68263

No windowing of h245 delays audio cutover in high roundtrip network

CSCdv71043

Transferred call forwarded to Unity does not work

CSCdv87550

Memory allocation failure - mem leak

CSCdw18804

Problem: When a 7960 with attached 7914 fallback to SRST router, the speed-dial assignment is skewed.

Workaround: None.


Open Caveats—Cisco IOS Release 12.1(5) YD4

There are no open caveats specific to Cisco IOS Release 12.1(5) YD4 that require documentation in the release notes.

Resolved Caveats—Cisco IOS Release 12.1(5) YD4

All the caveats listed in Table 7 are resolved in Cisco IOS Release 12.1(5) YD4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 7 Resolved Caveats for Release 12.1(5) YD4

Caveat ID Number
Description

CSCdu82132

Router crashes with bus error at hdsprm_htsp_tsp_map

CSCdv41018

Copland card adds unnecessary overhead when configured for data

CSCdt46360

DSP/Telephony leg dangles after running traffic


Open Caveats—Cisco IOS Release 12.1(5) YD3

There are no open caveats specific to Cisco IOS Release 12.1(5) YD3 that require documentation in the release notes.

Resolved Caveats—Cisco IOS Release 12.1(5) YD3

All the caveats listed in Table 8 are resolved in Cisco IOS Release 12.1(5) YD3. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 8 Resolved Caveats for Release 12.1(5) YD3

Caveat ID Number
Description

CSCds87266

No ringback played to PSTN when IP phones initiates a transfer

CSCdt77514

BRI L2 is not established after reload

CSCdu70532

GW interprets On Hook that is less than 100ms instead of ignoring it

CSCdu74485

Caller ID information is not collected with T1 CAS FXO GroundStart

CSCdu60475

router crashes when mgcp is configured

CSCdt44029

cRTP causes 7200 and 3640 to hang

CSCdt59350

x.25 fails on serial i/fs & traceback @ fecpm_serial_RX_interrupt

CSCdt19563

Spurious memory access and tracebacks reported

CSCdt58453

Output gain (negative output attenuation) too powerful


Open Caveats—Cisco IOS Release 12.1(5) YD2

All the caveats listed in Table 9 are open in Cisco IOS Release 12.1(5) YD2. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 9 Open Caveats for Release 12.1(5) YD2

Caveat ID Number
Description

CSCdu45133

FXO-DSP in busy state after overload, using vespa image


Resolved Caveats—Cisco IOS Release 12.1(5) YD2

All the caveats listed in Table 10 are resolved in Cisco IOS Release 12.1(5) YD2. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 10 Resolved Caveats for Release 12.1(5) YD2

Caveat ID Number
Description

CSCds82435

net3: non-conformance regarding INFORMATION message

CSCdu07504

sh voice dsp causes reload

CSCdt03449

ISDN BRI callout results in VOICE ERROR when ALERTING is received

CSCds42715

4 Octets added to IP Header when Fast Switching to Native VLAN

CSCds78766

DSP Hangs on NM-2V with S_SETUP_IND_NO_DSP

CSCdu45133

FXO-DSP in busy state after overload, using vespa image

CSCdu11853

router crash

CSCdt93862

Access level issue while using Web interface

CSCdt11503

IOS crashes when large OID (>256 fields) is received

CSCdt93862

Redzone corruption in pptp_tcp_readf()


Open Caveats—Cisco IOS Release 12.1(5) YD1

All the caveats listed in Table 11 are open in Cisco IOS Release 12.1(5) YD1. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 11 Open Caveats for Release 12.1(5) YD1

Caveat ID Number
Description

CSCdt77713

CCB list management problem

CSCdt49924

ISDN: isdn map not properly populating calling party number


Resolved Caveats—Cisco IOS Release 12.1(5) YD1

All the caveats listed in Table 12 are resolved in Cisco IOS Release 12.1(5) YD1. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 12 Closed and Resolved Caveats for Release 12.1(5) YD1

Caveat ID Number
Description

CSCdt52094

LLQ: Traffic drop when configuring LLQ in frame-relay interface

CSCdt16296

7206VXR crashes with ip_rtp_add_negative_cache

CSCdt20427

Spurious access @rate_limit_compress_adjust for all compr. pkt

CSCdt30629

Need to speed up RM to TACACS+ accounting processing

CSCds19979

TCP header compression does not work on virtual-access i/f

CSCds37837

MQC: dTS, police, and LLQ need to adjust for post-CRTP packet rate

CSCds43465

MQC: LLQ, Policer, Shaper should take CRTP compression feedback

CSCds47392

Destination phone continues to ring after source phone hangs up

CSCds73763

Router crashes when clear counter command is given

CSCdt71905

Pick up on shared line hangs the phone

CSCdt72099

Please investigate last_bad_payload 13 reported on FB GW

CSCdu05593

Minor scale enhancements

CSCdt98297

12.1.5YD:3660 supports 150 ephones under SRST mode

CSCdu00379

CON PLAR deleted during FB/normal cycle w DEFAULT-DEST. defined

CSCdu04283

Router crashes when assigning a long name under ephone-dn


Open and Resolved Caveats—Cisco IOS Release 12.1(5) YD

There are no open and resolved caveats specific to Cisco IOS Release 12.1(5) YD that require documentation in the release notes.

Related Documentation

The following sections describe the documentation available for the Cisco 3600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.

Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.

Use these release notes with these documents:

•Release-Specific Documents

•Platform-Specific Documents

•Feature Modules

•Feature Navigator

•Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Cisco IOS Release 12.1 and are located on Cisco.com and the Documentation CD-ROM:

•Cross-Platform Release Notes for Cisco IOS Release 12.1

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes

•Product bulletins, field notices, and other release-specific documents on Cisco.com at:

Technical Documents

•The "Caveats for Cisco IOS Release 12.1(5) YD" section

As a supplement to the caveats listed in "Caveats for Cisco IOS Release 12.1(5) YD" in these release notes, see Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1T, which contains caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.1 and Cisco IOS Release 12.1 T.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Caveats

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats

Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, log in to Cisco.com and click Service & Support: Technical Assistance Center: Select & Download Software: Jump to a software resource: Software Bug Toolkit/Bug Watcher. Another option is to go to http://www.cisco.com/support/bugtools/bugtool.shtml.

Platform-Specific Documents

The documents listed below are available for the Cisco 3600 series routers and are also available on Cisco.com and on the Documentation CD-ROM.

•Quick Start Guides for Cisco 3600 Series Routers

•Hardware Installation Documents for Cisco 3600 Series

•Software Configuration Documents for Cisco 3600 Series

•Regulatory Compliance and Safety Info for the Cisco 3600 Series

On Cisco.com, beginning under the Service & Support heading:

Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers

On the Documentation CD-ROM:

Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers

Feature Modules

Feature modules describe new features supported by Cisco IOS Release 12.1(5) YD6 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: New Feature Documentation

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation

Feature Navigator

Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.

Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.

To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.

Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:

http://www.cisco.com/go/fn

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Configuration Guides and Command References

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References

Release 12.1 Documentation Set

Table 13 lists the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form if ordered.

Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration

Table 13 Cisco IOS Software Release 12.1 Documentation Set

Books
Chapter Topics

•Cisco IOS Configuration Fundamentals Configuration Guide

•Cisco IOS Configuration Fundamentals Command Reference

Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
System Management

•Cisco IOS Bridging and IBM Networking Configuration Guide

•Cisco IOS Bridging and IBM Networking Command Reference, Volume I

•Cisco IOS Bridging and IBM Networking Command Reference, Volume II

Transparent Bridging
Source-Route Bridging
Token Ring Inter-Switch Link
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point
SNA Frame Relay Access Support
APPN
Cisco Database Connection
NCIA Client/Server Topologies
Cisco Mainframe Channel Connection
Airline Product Set

•Cisco IOS Dial Services Configuration Guide: Terminal Services

•Cisco IOS Dial Services Configuration Guide: Network Services

•Cisco IOS Dial Services Command Reference

X.25 over ISDN
AppleTalk Remote Access
Asynchronous Callback, DDR, PPP, SLIP
Bandwidth Allocation Control Protocol
ISDN Basic Rate Service
ISDN Caller ID Callback
PPP Callback for DDR
Channelized E1 & T1
Dial Backup for Dialer Profiles
Dial Backup Using Dialer Watch
Dial Backup for Serial Lines
Peer-to-Peer DDR with Dialer Profiles
DialOut
Dial-In Terminal Services
Dial-on-Demand Routing (DDR)
Dial Backup
Dial-Out Modem Pooling
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Dialup Networks
Dial Business Solutions and Examples

•Cisco IOS Interface Configuration Guide

•Cisco IOS Interface Command Reference

Interface Configuration Overview
LAN Interfaces
Logical Interfaces
Serial Interfaces

•Cisco IOS IP and IP Routing Configuration Guide

•Cisco IOS IP and IP Routing Command Reference

IP Overview
IP Addressing and Services
IP Routing Protocols

•Cisco IOS AppleTalk and Novell IPX Configuration Guide

•Cisco IOS AppleTalk and Novell IPX Command Reference

AppleTalk
Novell IPX

•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide

•Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference

Network Protocols Overview
Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

•Cisco IOS Security Configuration Guide

•Cisco IOS Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options

•Cisco IOS Switching Services Configuration Guide

•Cisco IOS Switching Services Command Reference

Switching Services
Switching Paths for IP Networks
Virtual LAN (VLAN) Switching and Routing

•Cisco IOS Wide-Area Networking Configuration Guide

•Cisco IOS Wide-Area Networking Command Reference

Wide-Area Network Overview
ATM
Frame Relay
SMDS
X.25 and LAPB

•Cisco IOS Multiservice Applications Configuration Guide

•Cisco IOS Multiservice Applications Command Reference

Voice over IP
Voice over Frame Relay
Voice over ATM
Voice over HDLC
Frame Relay-ATM Internetworking
Synchronized Clocks
Video Support
Universal Broadband Features

•Cisco IOS Quality of Service Solutions Configuration Guide

•Cisco IOS Quality of Service Solutions Command Reference

Policy-Based Routing
QoS Policy Propagation via BGP
Committed Access Rate
Weighted Fair Queueing
Custom Queueing
Priority Queueing
Weighted Random Early Detection
Scheduling
Signaling
RSVP
Packet Drop
Frame Relay Traffic Shaping
Link Fragmentation
RTP Header Compression

•Cisco IOS Command Summary

•Cisco IOS Command Reference Master Index

•Cisco IOS Configuration Guide Master Index

•Cisco IOS Dial Services Quick Configuration Guide

•Cisco IOS New Feature Index

•Cisco IOS System Error Messages

•Cisco IOS Debug Command Reference



Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at the following sites:

•http://www.cisco.com

•http://www-china.cisco.com

•http://www-europe.cisco.com

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

•Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:

Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

•P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.

.
