Release Notes for the Cisco SOHO 70 Series for Cisco IOS Release 12.1(5)YC
March 25, 2002
These release notes for the Cisco SOHO series routers describe the enhancements provided in Cisco IOS Release 12.1(5)YC3. These release notes are updated as needed. Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 located on Cisco.com and the Documentation CD-ROM.
For a list of the software caveats that apply to Cisco IOS Release 12.1(5)YC3, see the "Caveats" section and Caveats for Cisco IOS Release 12.1 T. The caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.
Contents
These Release Notes describe the following topics:
•
Obtaining Technical Assistance
System Requirements
This section describes the system requirements for Cisco IOS Release 12.1(5)YC3 and includes the following sections:
•
•
Memory Requirements
Table 1 Memory Requirements for the Cisco SOHO Series
SOHO 76 and SOHO 77
soho70-y1-mz
8 MB
16 MB
RAM
Hardware Supported
Cisco IOS Release 12.1(5)YC3 supports the Cisco SOHO series routers:
•
•
The SOHO 76 and SOHO 77 are small office and home office (SOHO) asymmetric digital subscriber line (ADSL) routers each with one Ethernet interface for connection to a service provider networks.
The SOHO routers also provide the following key hardware features:
•
•
•
•
For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Table 2 Supported Interfaces for the Cisco SOHO Series
SOHO 76 and SOHO 77
One 10BaseT (RJ-45)
RJ-11
RJ-45
Determining Your Software Release
To determine the version of Cisco IOS software running on your Cisco 800 series router, log in to the router and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm)800Software (C800-Y6-MW), Version 12.1(5)YC3, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see Cisco IOS Upgrade Ordering Instructions located at:
http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.1(5)YC3 supports the same feature sets as Releases 12.1 and 12.1 T, but Release 12.1(5) can include new features supported by the Cisco SOHO series routers.
Table 3 lists the features and feature sets supported by the Cisco SOHO series routers in Cisco IOS Release 12.1(5)YC3, and uses the following conventions:
•
•
Note
New and Changed Information
The following section lists the new software features supported by the Cisco SOHO series for Release 12.1(5)YC3 and above.
New Software Features in Release 12.1(5)YC1
The following new software features are supported by the Cisco SOHO series for Cisco IOS Release 12.1(5)YC1 and above:
OpenDSL
This feature implements auto-provisioning of the Cisco SOHO 70 Series routers. Auto-provisioning operates at bootup, and includes two procedures: Device Authentication and Image Maintenance. The router will be authenticated at bootup using its vendor ID and serial number. It then requests the Proxy Element to download its configuration file, and configures itself from CLIs in this file. It then polls for configuration changes, and downloads a new image and configuration file, if available, to retrieve the latest changes.
Limitations and Restrictions
The CISCO-DSL-CPE-MIB is partially supported by the Cisco SOHO 70 routers for the OpenDSL feature. Only those objects used in the Device Authentication and Image Maintenance procedures are supported. These objects are:
•
•
•
Important Notes
The following sections contain important notes about Cisco IOS Release 12.1(5)YC3.
OpenDSL Issues for the Cisco SOHO 70 Routers
The Cisco SOHO 70 routers with OpenDSL are preloaded with a CLI configuration such as "autoconfigure" instead of with no configuration. If a router is not loaded with some configuration, it will enter the initial console-user configuration dialog, which requires input from the user to get the router started.
If the image has been deleted by the user, the user needs to clear flash memory to allow the downloading of a new image during auto provisioning.
There is no WarmRestart action available for the routers. Selecting WarmRestart on CDCM will not reload the routers.
Configuration files must conform to the following.
•
•
–
–
–
–
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
For information on caveats in Cisco IOS Release 12.1 T, see Caveats for Cisco IOS Release 12.1 T.
All caveats in Cisco IOS Release 12.1 are also in Cisco IOS Release 12.1 T.
For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1, which lists severity 1 and 2 caveats and is located on Cisco.com and the Documentation CD-ROM.
Note
Resolved Caveats - Releases 12.1(5)YC2 and 12.1(5)YC3
This section describes unexpected behavior that is fixed in Releases 12.1(5)YC2 and 12.1(5)YC3.
Management
CSCdw65903
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Caveats for Release 12.1(5)YC1
This section describes possibly unexpected behavior by Release 12.1(5)YC1, specific to the Cisco SOHO 70 routers. These caveats are all of severity 3 (moderate).
Resolved Caveats - Release 12.1(5)YC1
This section describes possibly unexpected behavior by software releases prior to Release 12.1(5)YC1 that have been resolved in Release 12.1(5)YC1 and above.
CSCdt77246:
When a router is configured for PPPoE and IP NAT, and an incoming packet does not contain an MSS field or its TCP option field is not terminated by 0, the router might stop routing packets. This defect has been fixed in 12.1(5)YC1 release.
CSCdt35967:
When using CODEC g711alaw & g711ulaw, c827-4v fails to make an outgoing call to another Cisco voice gateway. This defect has been fixed in 12.1(5)YC1 release.
CSCds92106:
C827-4v may hang during system bootup. This defect has been fixed in 12.1(5)YC1 release.
Unresolved Caveats - Release 12.1(5)YC1
This section describes possibly unexpected behavior by Release 12.1(5)YC1.
CSCdt47054
When the router is configured to an ATM PVC with PPPoE encapsulation, it unexpectedly resets when the ATM PVC is removed in a subsequent configuration while the PPPoE session is still active.
CSCdt61879
When the configuration file URL in the ImageTable script is changed to point to a different, new configuration file and the router is reloaded, the previous configuration file is downloaded, rather than the new one. The problem has been traced to the cache in the PE, which retains the previous URL of the configuration file and sends that URL to the tftp server. The workaround is to clear the PE cache before reloading the router. This forces the PE to reload its cache with the latest information from the ImageTable script.
CSCdt61928
The router unexpectedly resets when executing cl or de commands in exec mode. The workaround is to expand these commands to at least cle and deb.
CSCdt61929
A zero byte configuration file will cause the router to operate in a loop and repeatedly download the configuration file.
Related Documentation
The following sections describe the documentation available for the Cisco SOHO series routers. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with the documents listed in the following sections:
•
Release-Specific Documents
The following documents are specific to Release 12.1. They are located on Cisco.com and the Documentation CD-ROM.
•
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•
Technical Documents: Product Bulletins
•
As a supplement to the caveats listed in the "Caveats" section section in these release notes, see the Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1 T documents, which contain caveats applicable to all platforms for all maintenance releases of IOS Releases 12.1 and 12.1 T.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco SOHO series routers on Cisco.com and the Documentation CD-ROM:
•
•
•
On Cisco.com at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Fixed Configuration Access Routers: Cisco SOHO Series Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Fixed Configuration Access Routers: Cisco SOHO Series Routers
Feature Modules
Feature modules describe new features supported by Release 12.1(5)YC3 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
To reach the Release 12.1(5)YC3 feature modules:
•
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in 12.1-Based Limited Lifetime Releases: New Features in Release 12.1 YC: New Features in Release 12.1(5)YC
•
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in 12.1-Based Limited Lifetime Releases: New Features in Release 12.1 YC: New Features in Release 12.1(5)YC
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image. Feature Navigator is available 24 hours a day, 7 days a week.
To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to set up an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two types of books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
The Cisco IOS software documentation set is available on Cisco.com and on the Documentation CD-ROM.
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Release 12.1 Documentation Set
Table 4 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is available in both electronic and printed form.
Note
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
