Release Notes for Cisco 2600 Series for Cisco IOS Release 12.1 XQ
February 18, 2002
Cisco IOS Release 12.1(3) XQ4
78-11552-01 Rev. F0
These release notes describe the features provided in Cisco IOS Release 12.1(3) XQ4 for the Cisco 2600 series routers. These release notes are updated as needed.
For a list of the software caveats that apply to Release 12.1(3) XQ4, see Caveats for Cisco IOS Release 12.1T that accompanies these release notes. This caveats document is updated for every maintenance release and is also located on Cisco Connection Online (Cisco.com) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 located on Cisco.com and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
Obtaining Technical Assistance
Introduction
Cisco Systems extends enterprise-class and managed services Customer Premises Equipment (CPE) versatility, integration, and power to branch offices with the Cisco 2600 series modular access router family. The widely deployed Cisco 2600 series modular access routers are designed to enable customers to easily adopt future technologies and scale to accommodate network expansion. The Cisco 2600 series shares modular interfaces with the Cisco 1600, Cisco 1700, and Cisco 3600 series, providing a solution to meet today's branch office needs for applications such as the following:
•
•
•
•
•
•
The Cisco 2600 series modular architecture provides the versatility needed to adapt to changes in network technology as new services and applications become available. Driven by a powerful reduced instruction set computing (RISC) processor, the Cisco 2600 series supports the advanced Quality of Service (QoS), security, and network integration features required in today's evolving enterprise networks.
For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.1(3) XQ4, see the "New and Changed Information" section section and the "Related Documentation" section.
System Requirements
This section describes the system requirements for Release 12.1(3) XQ4.
•
•
Memory Recommendations
Minimum memory recommendations for the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ4 are shown in Table 1.
Hardware Supported
Cisco IOS Release 12.1(3) XQ4 supports the following Cisco 2600 series routers.
•
•
•
•
•
•
For detailed descriptions of the new hardware features, see the "New and Changed Information" section. Table 2 shows the supported interfaces for the Cisco 2600 series routers with Cisco IOS Release 12.1(3) XQ4.
Determining the Software Version
To determine the version of Cisco IOS software running on a Cisco 2600 series router, log in to the router and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 2600 Software (c2600-is-mz), Version 12.1(3) XQ4, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, refer to Software Installation and Upgrade Procedures located at the following URL:
http://www.cisco.com/warp/public/130/upgrade_index.shtml
Microcode Software
Microcode software images ship on the flash along with the system software image. When the router starts, the system software unpacks the microcode software bundle and loads the proper software on all the interface linecards.
It is possible to use a later version of microcode than the one shipped with the Cisco IOS software from the factory. The microcode in Flash memory is mapped to the linecards. Unless you fully understand how Cisco IOS software uses microcode, it is important to keep the factory configuration.
The point-to-multipoint wireless modem card requires external microcode. Information about this microcode will be available on Cisco.com in November.
Other Firmware Code
The latest version of analog modem firmware for the Cisco 2600 series supports the internal analog modems (both NM-16AM and NM-8AM) in a wide range of countries, starting with Cisco IOS Release 11.3(5)T and later releases. The latest firmware (version 1.2.0) also supports dial-out and fax-out.
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers: Analog Modem Firmware
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers: Analog Modem Firmware
Feature Set Tables
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features, as shown in Table 3.
Cisco IOS Release 12.1(3) XQ4 supports the same feature sets as Cisco IOS Release12.1(3a)T1, but Cisco IOS Release 12.1(3) XQ4 can include new features supported by the Cisco 2600 series.
Caution
Table 4 lists the features and feature sets supported by the Cisco 2600 series in Cisco IOS Release12.1(3) XQ4 and uses the following conventions:
•
•
Note
Table 4 Feature List by Feature Set for the Cisco 2600 Series
Plus
IPSec 3DESPoint to Multipoint Wireless
Yes
Yes
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ4.
New Hardware and Software Features in Cisco IOS Release 12.1(3)XQ4
No new hardware and software feature are supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ4.
New Hardware and Software Features in Cisco IOS Release 12.1(3)XQ3
No new hardware and software feature are supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ3.
New Hardware and Software Features in Cisco IOS Release 12.1(3)XQ2
No new hardware and software feature are supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ2.
New Hardware and Software Features in Cisco IOS Release 12.1(3)XQ1
No new hardware and software feature are supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ1.
New Hardware Features in Cisco IOS Release 12.1(3)XQ
The following new hardware feature is supported by the Cisco 2600 series for Cisco IOS Release 12.1(3) XQ.
Wireless Network Module
The NM-WMDA wireless network module installs in the network module slot of a Cisco 2600 series router. Installing a wireless network module enables the Cisco 2600 series router to act as a subscriber unit (SU) in a point-to-multipoint wireless network. It is configured through the router's system console or via the CiscoView network management system. The network module provides the control and data interface between the Cisco 2600 series digital motherboard and the radio frequency (RF) subsystem in the wireless transverter. It also provides the up/down conversion from baseband to intermediate frequency (IF). One network module supports one or two wireless transverters (main and diversity).
The wireless network module requires external microcode. Information about this microcode will be available on Cisco.com in November.
For further information regarding the network module, refer to the Cisco Network Modules Hardware Installation Guide (for Cisco 2600 series routers) for detailed installation instructions, and the Software Configuration Guide (for Cisco 2600 series routers) for an overview of network module configuration procedures and information on configuring specific network modules.
New Software Features in Cisco IOS Release 12.1(3) XQ4
The following new software feature is supported by the Cisco 2600 series for Cisco IOS
Release 12.1(3) XQ4.
Point to Multipoint Wireless
The Cisco broadband fixed wireless point-to-multipoint system is an integrated solution consisting of one headend and multiple subscriber units. The fixed wireless point-to-multipoint subscriber unit is designed to receive radio frequency (RF) signals from the headend. It also transmits a return signal to the headend. This return signal is a point-to-point signal, so a properly installed subscriber antenna must be correctly oriented with the headend antenna to which it is transmitting. For more information about the fixed wireless point-to-multipoint headend feature, see the Point-to-Multipoint Support for the Cisco uBR7200 Series Universal Broadband Router.
Important Notes
The following sections contain important notes about Cisco IOS Release 12.1(3) XQ4 that can apply to the Cisco 2600 series.
Product Number Change
Beginning with Cisco IOS Release 12.0(7) XK, Cisco changed the product numbers used to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.
MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or network management system (NMS) applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 5.
Note
Caveats
Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
For information on caveats in Cisco IOS Release 12.1(3) T, see Caveats for Cisco IOS Release 12.1T that accompanies these release notes. This document lists severity 1 and 2 caveats and selected severity 3 caveats for Cisco IOS Release 12.1T.
All caveats in Cisco IOS Release 12.1(3a)T1 are also in Cisco IOS Release 12.1(3) XQ4.
For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1, which lists severity 1 and 2 caveats and is located on Cisco.com and the Documentation CD-ROM.
Note
http://www.cisco.com/support/bugtools
Open Caveats—Cisco IOS Release 12.1(3) XQ4
There are no open caveats specific to Cisco IOS Release 12.1(3) XQ4 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.1(3) XQ4
All the caveats listed in this section are resolved in Cisco IOS Release 12.1(3) XQ4. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Open Caveats for Release 12.1(3) XQ3
This section documents possible unexpected behavior by Cisco IOS Release 12.1(3) XQ3, and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
During brief periods of high-traffic activity on the subscriber-unit router and with the router's CPU overloaded, the radio "link-metrics" (continuous codeword error statistics) might not be collected because network-packet traffic has priority over the radio "link-metrics" on the CPU. This might cause the "link-metrics" tables to show zeros only and/or error messages to be generated. There is no workaround.
•
The system will accept a statistic parameter for a second antenna even though it is a single-antenna system.
Workaround: Disregard data for the second antenna.
Closed and Resolved Caveats for Release 12.1(3)XQ3
All the caveats listed in this section are resolved in Cisco IOS Release 12.1(3)XQ3. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
When the radio debugging function is enabled via the debug radio command, none of the radio debugging flags appear in the output of the show debug command. This makes it difficult to determine if the radio debugging function is turned on. There is no workaround.
This caveat is resolved in Cisco IOS Release 12.1(3)XQ3.
•
The Cisco vendor-specific DOCSIS TLV 129, which performs a Cisco IOS configuration file download without disabling the console, is not supported.
Workaround: Use DOCSIS TLV 128, which performs a Cisco IOS configuration file download, but does disable the console afterwards.
This caveat is resolved in Cisco IOS Release 12.1(3)XQ3: DOCSIS TLV 129 is now supported.
•
Tag-Length-Value (TLV) option 43.129, which is used to download an Cisco IOS configuration file without disabling the console, is currently not supported on the Cisco 2600 routers functioning as subscriber units.
Workaround: Use TLV option 43.128, which is used to download an Cisco IOS configuration file and requires disabling the console.
This caveat is resolved in Cisco IOS Release 12.1(3)XQ3: TLV option 43.129 is now supported.
•
Connection setup improvements.
This caveat is resolved in Cisco IOS Release 12.1(3)XQ3.
Related Documentation
The following sections describe the documentation available for the Cisco 2600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to or support Cisco IOS Release 12.1 and are located on Cisco.com and the Documentation CD-ROM:
•
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•
To reach these documents, refer to the Service & Support section at this path on Cisco.com:
Technical Documents
•
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Caveats: Caveats for Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.1: Release Notes: Caveats: Caveats for Cisco IOS Release 12.1
Note
http://www.cisco.com/support/bugtools
Platform-Specific Documents
These documents are available for the Cisco 2600 on Cisco.com and the Documentation CD-ROM:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.1 XQ1, and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, and configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in Release 12.1T
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation: New Features in Release 12.1T
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM, unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On Cisco.com and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Release 12.1 Documentation Set
Table 6 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form upon request.
Note
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
You can reach the Cisco IOS documentation set on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Note
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
.
