Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 12.1 XM
February 25, 2002
Cisco IOS Release 12.1(5) XM8
78-12051-01 Rev. I0
These release notes for the Cisco AS5300 universal access servers describe the enhancements provided in Cisco IOS Release 12.1(5) XM8. These release notes are updated as needed.
For a list of the software caveats that apply to Release 12.1(5) XM8, see the "Caveats" section and Caveats for Cisco IOS Release 12.1T that accompanies these release notes. This caveats document is updated for every maintenance release and is also located on Cisco.com and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 on Cisco.com and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
MIBs
•
Introduction
The Cisco AS5300 is a versatile data communications platform that performs two functions in a single modular chassis, depending on the installed feature cards and IOS images:
•
•
The remote access server is intended for Internet service providers (ISPs), telecommunications carriers, and other service providers that offer managed Internet connections and medium to large sites that provide both digital and analog access to users on an enterprise network. By terminating both analog and digital calls on the same chassis simultaneously, the access server provides a clear, simple, and easy migration path from analog dial access services to digital dial access services.
The Cisco AS5300 Voice Gateway is a versatile data communications platform that provides the functions of an access server, router, and digital modem(s) in a single modular chassis. The Cisco AS5300 includes three feature card slots: one holds a T1/E1/PRI feature card, and the other two support modem feature cards or voice digital signal processor (DSP) feature cards. When equipped with modem cards, the Cisco AS5300 serves as a remote access concentrator for dial-up (modem or ISDN) Internet access. When equipped with voice feature cards and Voice IOS, the Cisco AS5300/Voice Gateway serves as a Voice over IP (VoIP) gateway. By using one slot for modems and the other for voice DSPs, the Cisco AS5300 can serve in both capacities. Modem, voice, or fax calls are routed to the appropriate cards/resources via Dialed Number Identification Service (DNIS).
For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.1(5) XM8, see the "New and Changed Information" section and the "Related Documentation" section.
System Requirements
This section describes the system requirements for Cisco IOS Release12.1(5) XM8 and includes the following sections:
•
•
•
Memory Recommendations
Supported Hardware
Cisco IOS Release 12.1(5) XM8 supports the Cisco AS5300. Table 2 details the supported interfaces.
For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco AS5300, log in to the Cisco AS5300 and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 12.1 Software c5300-i-mz, Version 12.1(5) XM8, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, refer to Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:
http://www.cisco.com/warp/public/130/upgrade_index.shtml
Microcode and Modem Code Software
Microcode software images are bundled with the system software image with the exception of the Channel Interface Processor (CIP) microcode (all system software images). Bundling eliminates the need to store separate microcode images. When the router starts, the system software unpacks the microcode software bundle and loads the proper software on all the interface processor boards.
You could have received a later version of modem code than the one bundled with the Cisco IOS software. The modem code in Flash memory is mapped to the modems. Unless you fully understand how Cisco IOS software uses modem code, it is important to keep the factory configuration.
To obtain the latest Cisco IOS software release compatible with Cisco MICA portware, refer to the Cisco AS5x00 MICA 6-Port and 12-Port Modem Module Portware/Cisco IOS Software Compatibility Matrixes at http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/5300/sw_conf/sw_ports/compmat/mca12prt.htm.
The modem code release notes are on Cisco.com and the Documentation CD-ROM:
On Cisco.com at:
Technical Documents: Access Servers and Access Routers: Access Servers: Cisco AS5300: Configuration Documents for Cisco AS5300: Port Information
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300: Configuration Documents for Cisco AS5300: Port Information
Note
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Cisco IOS Release 12.1(5) XM8 supports the same feature sets as Cisco IOS Release 12.1(5) T, but Cisco IOS Release 12.1(5) XM8 can include new features supported by the Cisco AS5300.
Caution
Table 3 lists the features and feature sets supported by the Cisco AS5300 in Cisco IOS Release 12.1(5) XM8 and uses the following conventions:
•
•
•
Note
Table 3 Feature List by Feature Set for the Cisco AS5300
Plus
IPSec 56
IPSec 5612.1(5) XM
Yes
Yes
Yes
Yes
12.1(5 )XM
Yes
Yes
Yes
Yes
12.1(5) XM
Yes
Yes
Yes
Yes
Media Gateway Control Protocol Basic CLASS and Operator Services
12.1(5) XM
Yes
Yes
Yes
Yes
SIP Diversion Header Implementation for Redirecting Number (CSCdr72341)
12.1(5) XM1
Yes
Yes
Yes
Yes
SIP Gateway Support for Third Party Call Control (CSCdr32290)
12.1(5) XM1
Yes
Yes
Yes
Yes
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco AS5300 for Cisco IOS Release 12.1(5) XM8.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM8
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM8.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM7
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM7.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM6
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM6.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM5
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM5.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM4
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM4.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM3
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM3.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM2
There are no new hardware and software features in the Cisco AS5300 for Cisco IOS Release 12.1(5) XM2.
New Hardware Features in Cisco IOS Release 12.1(5)XM1
There are no new hardware features in the Cisco AS5300 for Cisco IOS Release 12.1(5)XM1.
New Software Features in Cisco IOS Release 12.1(5)XM1
The following new software features are supported by the Cisco AS5300 for Cisco IOS Release 12.1(5)XM1.
SIP Diversion Header Implementation for Redirecting Number (CSCdr72341)
The SIP Diversion Header Implementation for Redirecting Number feature provides support for a new SIP header field; Call Control (CC)-Diversion. The CC-Diversion header field enables the SIP gateway to pass call control redirecting information during the call setup. Call control redirection is the redirection of a call based on a subscriber service such as call forwarding. Call redirection information is information is typically used for Unified Messaging and voice mail services to identify the recipient of a message. Call control rediversion information can also be used to support applications such as automatic call distribution and enhanced telephony features such as Do Not Disturb and Caller ID.
For further details, please see: http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/hennigan.htm.
SIP Gateway Support for Third Party Call Control (CSCdr32290)
This feature adds SDP changes for third party call control in SIP for click-to-dial, mid-call announcements, voice mail, and a timed conference bridge initiation.
For further details, please see SIP Gateway Support for Third Party Call Control at:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/caribou.htm#xtocid33510
New Hardware Features in Cisco IOS Release 12.1(5)XM
There are no new hardware features in the Cisco AS5300 for Cisco IOS Release 12.1(5)XM2.
New Software Features in Cisco IOS Release 12.1(5)XM
The following new software features are supported by the Cisco AS5300 for Cisco IOS Release 12.1(5)XM2.
Enhancement to Fax Detection Feature for the Cisco AS5300
Users can now route fax calls to a fax e-mail address based on the redirecting dialed number (RDNIS), the dialed number (DNIS), or on a user-specified string, in addition to previously existing choices. RDNIS is the telephone number that is dialed for a particular subscriber before a call is transferred, on busy or no answer, to a shared voice/fax mail access and deposit number (DNIS).
A new keyword in the session target mailto: command ($m$)specifies use of RDNIS as part of the fax e-mail address if RDNIS is present; otherwise, DNIS is used. Additionally, a string can be entered, which allows the fax e-mail to be sent to an address that is not necessarily based on a telephone number.
Fax Detection for Cisco AS5300 Universal Access Servers
On Cisco AS5300 gateways equipped with voice feature cards (VFCs), the fax detection feature lets service providers deploy unified communication applications where each subscriber has a single E.164 number for both voice mail and fax mail. When configured for fax detection, the gateway automatically listens to incoming calls to discriminate between voice and fax. The gateway then routes the calls to the appropriate application or server.
Note
H.323 Call Redirection Enhancements
The user-to-user information element (UUIE) of the facility message is used primarily for call redirection. The UUIE contains a field, facilityReason, that indicates the nature of the redirection. The H.323 Call Redirection Enhancements feature adds support for two of the reasons: routeCallToGatekeeper and callForwarded. It also provides a nonstandard method for using the facility message to effect call transfer.
Route Call to Gatekeeper
There are two situations in which the Cisco H.323 Gateway might receive or generate a facility message with a routeCallToGatekeeper reason.
•
–
–
•
Upon receiving the message, the intermediate Cisco H.323 Gateway sends a facility message to the originator of the SETUP message. This message indicates that the SETUP message should be sent to another address. (The gateway includes the callSignalAddress from ARJ in the alternativeAddresss field of the facility message.)
Upon receiving the facility message, the calling gateway terminates the initial call and sends a new SETUP message to the specified gatekeeper, using the new IP address specified in the alternativeAddress field of the facility message. If the callSignalAddress is not provided, the gateway will not send the facility message and the call is terminated without any rerouting.
Call Forward
In certain cases, an H.323 endpoint might determine that a call needs to be forwarded. The endpoint then sends a facility message to the gateway with a facilityReason of callForwarded. This message includes the address of the new destination (either an alternativeAddress or alternativeAliasAddress).
Upon receiving the facility message, the Cisco H.323 Gateway sends a release complete to the original destination endpoint and initiates a new call using the new destination address supplied in the facility message. The release complete message contains a ReleaseCompleteReason of facilityCallDeflection. If the gateway is registered with a gatekeeper, the gateway sends a DRQ to the gatekeeper and waits for the DCF before sending a setup message to the destination gatekeeper.
The facility message must contain an E.164 address in the alternativeAliasAddress field. If no address is included, the facility message is ignored. The E164 is required because the call forwarding process initiates a new call, which may be subject to authentication processes that can handle only E.164 addresses.
If the facility message contains both and IP address (in the alternativeAddress field) and an E.164 address (in the alternativeAliasAddress field), the gateway first attempts to find a match for the new E.164 and the dial-peer. If there is no match, the gateway uses the same incoming peer to determine if there is a matching peer to reroute the call. If there is no match to the incoming peer, the message is ignored.
Call Transfer
If a facility message with a facilityReason of callForwarded is received after the call has been accepted, it is considered a call transfer. In this case, the Cisco H.323 Gateway will place the call on hold and initiate a new call using the address (alternativeAddress or alternativeAliasAddress) supplied in the facility message.
As with call forwarding, the facility message must contain an E.164 address in the alternativeAliasAddress field. If no address is included, the facility message is ignored. The E164 is required because the call forwarding process initiates a new call, which may be subject to authentication processes that can handle only E.164 addresses.
If the facility message contains both an IP address (in the alternativeAddress field) and an E.164 address (in the alternativeAliasAddress field), the gateway first attempts to find a match for the new E.164 and the dial-peer. If there is no match, the gateway uses the same incoming peer to determine if there is a matching peer to reroute the call. If there is no match to the incoming peer, the message is ignored.
Unlike in the call forwarding case, the facility message is accepted by both the called side and the originating side.
Note
For further details, please see http://www.cisco.com/univercd/cc/td/doc/product/software/ios122/122newft/122t/122t2/ftcallrd.htm.
Media Gateway Control Protocol Basic CLASS and Operator Services
The Media Gateway Control Protocol (MGCP) Basic CLASS and Operator Services (BCOS) are a set of calling features, sometimes called "custom calling" features, that use MGCP to transmit voice, video, and data over the IP network. These features are usually found in circuit-based networks. MGCP BCOS brings them to the Cisco IOS gateways on packet-based networks.
The MGCP BCOS software is built on the MGCP CAS PBX and AAL2 software package, and supports MGCP 0.1 and the earlier protocol versions Simple Gateway Control Protocol (SGCP) 1.1 and 1.5.
The following two features can be run as trunking gateway (TGW) features:
•
This feature is supported in SGCP and MGCP modes on the Cisco AS5300.
•
This feature is supported on the G.711a and G.711u codecs only.
Refer to the following documents for additional information:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios122/122newft/122t/122t2/ftmgcptk.htm
http://www.cisco.com/univercd/cc/td/doc/product/software/ios122/122newft/122t/122t2/ftmgcpgr.htm
Important Notes
Cisco IOS Release 12.1(5) XM8 is compatible with MICA portware 2.7.3.0.
MIBs
Current MIBs
To obtain lists of supported MIBs by platform and Cisco IOS release, and to download MIB modules, go to the Cisco MIB website on Cisco.com at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.
Deprecated and Replacement MIBs
Old Cisco MIBs will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs without affecting existing Cisco IOS products or network management system (NMS) applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 4.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
This section contains only open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Cisco IOS Release 12.1 and Cisco IOS Release 12.1T are also in Cisco IOS Release 12.1(5) XM8.
For information on caveats in Cisco IOS Release 12.1T, see Caveats for Cisco IOS Release 12.1T.
For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1, which lists severity 1 and 2 caveats and select severity 3 caveats for Cisco IOS Release 12.1 and is located on Cisco.com and the Documentation CD-ROM.
Caveat numbers and brief descriptions of caveats in Cisco IOS Release 12.1(5) XM5 are listed in Table 5 and Table 6. For details about a particular caveat, go to Bug Toolkit at:
http://www.cisco.com/kobayashi/bugs/bugs.html
To access this location, you must have an account on Cisco.com. For information about how to obtain an account, go to the "Feature Navigator" section.
Note
Open Caveats — Cisco IOS Release 12.1(5) XM8
All the caveats listed in Table 5 are open in Cisco IOS Release 12.1(5) XM8. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Resolved Caveats — Cisco IOS Release 12.1(5) XM8
All the caveats listed in Table 6 are resolved in Cisco IOS Release 12.1(5) XM8. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats — Cisco IOS Release 12.1(5) XM7
There are no open caveats specific to Cisco IOS Release 12.1(5) XM7 that require documentation in the release notes.
Resolved Caveats — Cisco IOS Release 12.1(5) XM7
All the caveats listed in Table 7 are resolved in Cisco IOS Release 12.1(5) XM7. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM6
There are no open caveats specific to Cisco IOS Release 12.1(5) XM6 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.1(5) XM6
All the caveats listed in Table 8 are resolved in Cisco IOS Release 12.1(5) XM6. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM5
There are no open caveats specific to Cisco IOS Release 12.1(5) XM5 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.1(5) XM5
All the caveats listed in Table 9 are resolved in Cisco IOS Release 12.1(5) XM5. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM4
All the caveats listed in Table 10 are open in Cisco IOS Release 12.1(5) XM4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Resolved Caveats—Cisco IOS Release 12.1(5) XM4
All the caveats listed in Table 11 are resolved in Cisco IOS Release 12.1(5) XM4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM3
All the caveats listed in Table 12 are open in Cisco IOS Release 12.1(5) XM3. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Resolved Caveats—Cisco IOS Release 12.1(5) XM3
All the caveats listed in Table 13 are resolved in Cisco IOS Release 12.1(5) XM3. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM2
This section documents possible unexpected behavior by Cisco IOS Release 12.1(5) XM2 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
When the PPP Password Authentication Protocol (PAP)-password validation fails—that is, when the PPP PAP password is configured incorrectly—a slow memory leak occurs. There is no workaround.
•
The CLI command isdn negotiate-bchan resend-setup does not show up when using the CLI help feature. This command allows Cisco IOS software to try a different B channel when a call setup on an initial B channel fails—for example, due to a Continuity Testing (COT) test failure. Turning on this option is recommended when using the isdn switch-type primary ni command in order to increase the call success rate.
Workaround: Configure the isdn negotiate-bchan resend-setup command, even though it is not yet documented as a command.
Resolved Caveats—Cisco IOS Release 12.1(5) XM2
All the caveats listed in this section are resolved in Cisco IOS Release 12.1(5) XM2. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
If a Class-3 switch that is connected to an ISDN PRI interface of a Cisco AS5300 initiates a call, the call uses a SIP proxy, reaches a gateway, and is terminated at another switch. Most of the calls are completed properly (that is, a tone is generated and the phone is answered), but randomly some of the calls do not complete and no error message is produced in the Cisco AS5300 log. There is no workaround.
This caveat is resolved in Cisco IOS Release 12.1(5)XM2.
•
Cisco IOS software contains a flaw that permits the successful prediction of TCP Initial Sequence Numbers.
This vulnerability is present in all released versions of Cisco IOS software running on Cisco routers and switches. It only affects the security of TCP connections that originate or terminate on the affected Cisco device itself; it does not apply to TCP traffic forwarded through the affected device in transit between two other hosts.
To remove the vulnerability, Cisco is offering free software upgrades for all affected platforms. The defect is described in DDTS record CSCds04747.
Workarounds are available that limit or deny successful exploitation of the vulnerability by filtering traffic containing forged IP source addresses at the perimeter of a network or directly on individual devices.
This notice will be posted at http://www.cisco.com/warp/public/707/ios-tcp-isn-random-pub.shtml.
This caveat is resolved in Cisco IOS Release 12.1(5) XM2.
Open and Resolved Caveats—Cisco IOS Release 12.1(5) XM1
There are no open and resolved caveats specific to Cisco IOS Release 12.1(5) XM1 that require documentation in the release notes.
Open and Resolved Caveats—Cisco IOS Release 12.1(5) XM
There are no open and resolved caveats specific to Cisco IOS Release 12.1(5) XM that require documentation in the release notes.
Related Documentation
The following sections describe the documentation available for Cisco IOS Release 12.2. These documents consist of software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.1 and are located on Cisco.com and the Documentation CD-ROM:
•
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 12.1and Caveats for Cisco IOS Release 12.1 T, which contain caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.1 and Cisco IOS Release 12.1 T.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
Platform-Specific Documents
These documents are available for the Cisco AS5300 on Cisco.com and the Documentation CD-ROM:
•
•
•
•
On Cisco.com at:
Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.1(5) XM8 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.
Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to set up an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Release 12.1 Documentation Set
Table 14 lists the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form if ordered.
Note
On Cisco.com at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:
Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
.
