Release Notes for Cisco 3600 Series for Cisco IOS Release 12.1 XM
June 13, 2002
Cisco IOS Release 12.1(5) XM7
78-12049-01 Rev. H1
These release notes for the Cisco 3600 series support Cisco IOS Release 12.1(5) XM7. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.1(5) XM7, see the "Caveats for Cisco IOS Release 12.1 XM" section and Caveats for Cisco IOS Release 12.1T that accompanies these release notes. This caveats document is updated for every maintenance release and is also located on Cisco.com and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 located on Cisco.com and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
MIBs
•
•
Introduction
The Cisco 3600 series includes the Cisco 3620, Cisco 3640, and Cisco 3660 routers. As modular solutions, the Cisco 3600 series routers enable corporations to increase dial-up density and take advantage of current and emerging WAN technologies and networking capabilities. The Cisco 3600 series routers are fully supported by Cisco IOS software, which includes dial-up connectivity, LAN-to-LAN routing, data and access security, WAN optimization, and multimedia features.
For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.1(5) XM7, see the "New and Changed Information" section and the "Related Documentation" section.
System Requirements
This section describes the system requirements for Release 12.1(5)XM4:
•
•
Memory Recommendations
Cisco IOS Release 12.1(5) XM7 supports Cisco 3660 routers only.
Table 1 Memory Recommendations for the Cisco 3660 Router
Memory
Recommended
Memory
Recommended
FromIP
c3660-i-mz
8 MB
32 MB
RAM
IP Plus
c3660-is-mz
16 MB
64 MB
RAM
IP Plus/IPSec 56
c3660-is56i-mz
32 MB
64 MB
RAM
IP/FW/IDS
c3660-io3-mz
8 MB
64 MB
RAM
IP/FW/IDS Plus IPSec 56
c3660-io3s56i-mz
32 MB
64 MB
RAM
IP/H.323 Gtkpr Prxy
c3660-ix-mz
8 MB
64 MB
RAM
IP Plus/IPSec 3DES
c3660-ik2s-mz
32 MB
64 MB
RAM
IP/FW/IDS Plus IPSec 3DES
c3660-ik2o3s-mz
32 MB
64 MB
RAM
IP/IPX/AT/DEC
c3660-d-mz
8 MB
64 MB
RAM
IP/IPX/AT/DEC Plus
c3660-ds-mz
16 MB
64 MB
RAM
IP/IPX/AT/DEC FW IDS Plus
c3660-do3s-mz
16 MB
64 MB
RAM
Enterprise/SNASw Plus
c3660-a3js-mz
32 MB
96 MB
RAM
Enterprise/SNASw Plus/IPSec 56
c3660-a3js56i-mz
32 MB
96 MB
RAM
Enterprise/SNASw Plus IPSec 3DES
c3660-a3jk2s-mz
32 MB
96 MB
RAM
Enterprise Plus
c3660-js-mz
32 MB
96 MB
RAM
Enterprise Plus IPSec 56
c3660-js56i-mz
32 MB
96 MB
RAM
Enterprise Plus/IPSec 3DES
c3660-jk2s-mz
32 MB
96 MB
RAM
Enterprise/FW/IDS Plus IPSec 56
c3660-jo3s56i-mz
32 MB
96 MB
RAM
Enterprise/FW/IDS Plus IPSec 3DES
c3660-jk2o3s-mz
32 MB
96 MB
RAM
Enterprise Plus/H323 MCM
c3660-jsx-mz
32 MB
96 MB
RAM
Telco1
c3660-telco-mz
16 MB
64 MB
RAM
Telco Plus1
c3660-telcoent-mz
32 MB
96 MB
RAM
Telco Plus IPSec 3DES1
c3660-telcoentk2-mz
32 MB
96 MB
RAM
1 The Telco images only run on the 3660-AC-CO and 3660-DC-CO.
Hardware Supported
Cisco IOS Release 12.1(5) XM7 supports the following Cisco 3600 series routers:
•
Note
Table 2 lists the supported interfaces for the Cisco 3600 series routers for Cisco IOS Release 12.1(5) XM7.
Table 2 Supported Interfaces for the Cisco 3600 Series
16- and 32-port asynchronous (NM-16A and NM-32A)
All Cisco 3600 series platforms
6- to 30-port integrated digital modems network modules (NM-6DM, NM-12-DM, NM-18DM, NM-24DM, NM-30DM)
All Cisco 3600 series platforms
6 digital modem upgrade (MICA-6MOD)
All Cisco 3600 series platforms
8- or 16-port integrated analog network modules (NM-8AM and NM-16AM)
All Cisco 3600 series platforms
4- and 8-port BRI network module with NT1 (NM-4B-U and NM-8B-U)
All Cisco 3600 series platforms
4- and 8-port BRI network module with S/T interface (NM-4B-S/T and NM-8B-S/T
All Cisco 3600 series platforms
4- and 8-port synchronous/asynchronous (NM-4A/S and NM-8A/S)
All Cisco 3600 series platforms
1- and 4-port Ethernet (AUI and 10BaseT, NM-1E and NM-4E)
All Cisco 3600 series platforms
1-port Fast Ethernet (100BaseTX and 100BaseFX, NM-1FE-TX and NM-1FE-FX)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 1-port channelized/PRI /E1 balanced mode (NM-1FE1CE1B)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 1-port channelized/PRI/E1 unbalanced mode (NM-1FE1CE1U)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 1-port channelized/PRI/T1(NM-1FE1CT1)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 1-port channelized/PRI /T1 with CSU (NM-1FE1CT1-CSU)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 2-port channelized/PRI/ E1 balanced mode (NM-1FE2CE1B)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 2-port channelized/PRI /E1 unbalanced mode (NM-1FE2CE1U)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 2-port channelized/PRI /T1 (NM-1FE2CT1)
All Cisco 3600 series platforms
1-port 10/100BaseTX with 2-port channelized/PRI/ T1 with CSU (NM-1FE2CT1-CSU)
All Cisco 3600 series platforms
1 Ethernet and 2 WAN card slots (NM-1E2W)
All Cisco 3600 series platforms
1 Ethernet, 1 Token Ring, and 2 WAN card slots (NM-1E1R2W)
All Cisco 3600 series platforms
2 Ethernet and 2 WAN card slots (NM-2E2W)
All Cisco 3600 series platforms
1-port fast Ethernet, 1-port Token Ring with 2 WAN card slots (NM-1FE1R2W[=])
All Cisco 3600 series platforms
1-port fast Ethernet with 2 WAN card slots (NM-1FE2W[=])
All Cisco 3600 series platforms
2-port fast Ethernet with 2 WAN card slots (NM-2FE2W[=])
All Cisco 3600 series platforms
2 WAN card slots (NM-2W[=])
All Cisco 3600 series platforms
1-port, 24-channel T1 voice/fax module, supports 24 channels of medium-complexity codecs: G.729a/b, G.726, G.711 and fax or 12 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, two PVDM-12s, and one VWIC-1MFT-T11 . Part number: NM-HDV-1T1-24
All Cisco 3600 series platforms
1-port, enhanced 24-channel T1 voice/fax module, supports 24 channels of high- and medium-complexity codecs: G.729a/b, G.726, G.729, G.728, G.723.1, G.711, and fax. Consists of one NM-HDV, four PVDM-12s, and one VWIC-1MFT-T12. Part number: NM-HDV-1T1-24E
All Cisco 3600 series platforms
2-port, 48-channel T1 voice/fax module, supports add/drop multiplexing (drop and insert); 48 channels of medium-complexity codecs: G.729a/b, G.726,G.711, and fax; or 24 channels of G726, G729, G723.1, G.728, G729a/b, G711, and fax. Consists of one NM-HDV, four PVDM-12, and one VWIC-2MFT-T1-DI2. Part number: NM-HDV-2T1-48
All Cisco 3600 series platforms
1-port, 30-channel E1 voice/fax module, supports 30 channels of G.729a/b, G.726, G.711 and fax or 18 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, three PVDM-12s, and one VWIC-1MFT-E11. (NM-HDV-1E1-30[=])
All Cisco 3600 series platforms
1-port, enhanced 30-channel E1 voice/fax module, supports 30 channels of G.729a/b, G.726, G.729, G.728, G.723.1, G.711, and fax. Consists of one NM-HDV, five PVDM-12s, and one VWIC-1MFT-E11. (NM-HDV-1E1-30E[=])
All Cisco 3600 series platforms
2-port, 60-channel E1 voice/fax module, supports add/drop multiplexing (drop and insert); 60 channels of G.729a/b, G.726, G.711, and fax or 30 channels of G.726, G.729, G.723.1, G.728, G.729a/b, G.711, and fax. Consists of one NM-HDV, five PVDM-12s, and one VWIC-2MFT-E1-D11. (NM-HDV-2E1-60[=])
All Cisco 3600 series platforms
High-density voice/fax network module spare (NM-HDV)
Digital T1 Packet Voice Trunk Network Modules spare component
12-channel packet voice DSP module upgrade spare (PVDM-12=)
Digital T1 Packet Voice Trunk Network Modules spare component
1-port RJ-48 multiflex trunk—T1 (VWIC-1MFT-T1)2
Digital T1 Packet Voice Trunk Network Modules spare component
2-port RJ-48 multiflex trunk—T1 (VWIC-2MFT-T1)2
Digital T1 Packet Voice Trunk Network Modules spare component
2-port RJ-48 multiflex trunk with drop and insert—T1 (VWIC-2MFT-T1-DI(=))2
Digital T1 Packet Voice Trunk Network Modules spare component
1-port T1 multiflex trunk interface (VWIC-1MFT-T1)
All Cisco 3600 series platforms
1-port E1 multiflex trunk interface (VWIC-1MFT-E1)
All Cisco 3600 series platforms
2-port T1 multiflex trunk interface (VWIC-2MFT-T1)
All Cisco 3600 series platforms
2-port T1 multiflex trunk interface with drop and insert (VWIC-2MFT-T1-DI)2
All Cisco 3600 series platforms
2-port E1 multiflex trunk interface with drop and insert (VWIC-2MFT-E1-DI)
All Cisco 3600 series platforms
1- and 2-port voice/fax network module (NM-1V and NM-2V)
All Cisco 3600 series platforms
2-port E&M voice interface card (VIC-2E/M)
All Cisco 3600 series platforms with Voice/Fax network module
2-port FXO voice interface card (VIC-2FXO, VIC-2FXO-M3, and VIC-2FXO-EU)
All Cisco 3600 series platforms with Voice/Fax network module
2-port FXS voice interface card
All Cisco 3600 series platforms with Voice/Fax network module
2-port BRI voice interface card (VIC-2BRI-S/T-TE)
Cisco 3620 and 3640 platforms with Voice/Fax network module
2-Port analog DID Voice Interface (VIC2-DID)
All Cisco 3600 series platforms
48/56/64 kbps
All Cisco 3600 series platforms
1.544/2.048 Mbps
All Cisco 3600 series platforms
Up to 8 Mbps on 4-port serial network module
All Cisco 3600 series platforms
52 Mbps max using HSSI network module
All Cisco 3600 series platforms
Up to 100 Mbps on ATM OC3 network modules
All Cisco 3600 series platforms
1- and 2-port channelized T1 modules without CSUs (NM-1CT1 and NM-1CT1)
All Cisco 3600 series platforms
1- and 2-port channelized T1 network modules with CSUs (NM-1CT1-CSU and NM-2CT1-CSU)
All Cisco 3600 series platforms
1- and 2-port E1 network modules unbalanced mode NM-1CE1U and NM-2CE1U)
All Cisco 3600 series platforms
1- and 2-port E1 network modules balanced mode (NM-1CE1B and NM-2CE1B)
All Cisco 3600 series platforms
1-port ATM-25 network module (NM-1ATM-25)1
All Cisco 3600 series platforms
1-port ATM T3 network module (NM-1A-T3)3
All Cisco 3600 series platforms
4-port T1 ATM network module with IMA (NM-4T1-IMA)
All Cisco 3600 series platforms
4-port E1 ATM network module with IMA (NM-4E1-IMA)
All Cisco 3600 series platforms
8-port T1 ATM network module with IMA (NM-8T1-IMA)
All Cisco 3600 series platforms
8-port E1 ATM network module with IMA (NM-8E1-IMA)
All Cisco 3600 series platforms
1-port ATM E3 network module (NM-1A-E3)4
All Cisco 3600 series platforms
1-port ATM OC-3 network module with multimode fiber (NM-1A-OC3MM)
All Cisco 3600 series platforms
1-port ATM OC-3 network module with single-mode intermediate reach fiber (NM-1A-OC3SMI)
All Cisco 3600 series platforms
1-port ATM OC-3 network module with single-mode long reach fiber (NM-1A-OC3SML)
All Cisco 3600 series platforms
1-port ATM OC-3 multimode network module and circuit emulation service (NM-1A-OC3MM-1V)5
All Cisco 3600 series platforms
1-port ATM OC-3 single-mode, intermediate reach network module and circuit emulation service (NM-1A-OC3SMI-1V)5
All Cisco 3600 series platforms
1-port ATM OC-3 single-mode, long reach network module and circuit emulation service (NM-1A-OC3SML-1V)5
All Cisco 3600 series platforms
1-port high-speed serial interface (HSSI) network module
All Cisco 3600 series platforms
4-port serial (NM-4T)
All Cisco 3600 series platforms
4- or 8-port asynchronous/synchronous serial low speed (128 kbps max)
Data compression network module (NM-COMPR)
Cisco 3620 and 3640 series platforms
Data encryption network modules (NM-VPN-MP)
Cisco 3620 and 3640 series platforms
Multiservice Interchange (MIX) 3660 module (MIX-3660-64)
Cisco 3660 series platforms
Wireless network module (NM-WMDA)
All Cisco 3600 series platforms
4 E1 Data compression AIM (AIM-COMPR4)
Cisco 3660 series platforms
Data Encryption AIM (AIM-VPM-HP)
Cisco 3660 series platforms
1-port T1/Fractional T1/DSU/CSU WAN interface card (WIC-1DSU-T1)
All Cisco 3600 series platforms
1-port T1/Fractional T1 56/64 kbps DSU/CSU WAN interface card (WIC-1DSU-56K4)
All Cisco 3600 series platforms
1-port ISDN with NT1 WAN interface card (WIC-1B-U)
All Cisco 3600 series platforms
1-port ISDN WAN interface card (WIC-1B-S/T)
All Cisco 3600 series platforms
1-port serial WAN interface card (WIC-1T)
All Cisco 3600 series platforms
2-port serial (WIC-2T[=])6
All Cisco 3600 series platforms
2-port asynchronous/synchronous (WIC-2A/S[=])
All Cisco 3600 series platforms
1 See T1/E1 Multiflex Voice/WAN Interface Cards in this table.
2 For Cisco 3660 series, only supported in T1/E1 digital packet voice trunk network modules and new Fast Ethernet mixed media network modules: NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W. For Cisco 3620 and 3640, supported in T1/E1 digital packet voice trunk network modules or in 1- or 2-port Ethernet and Fast Ethernet network module (NM-1E2W, NM-2E2W, NM-1E1R2W, NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W)
3 Requires the Cisco IOS Plus feature sets.
4 Requires the Cisco IOS Plus feature sets.
5 For the Cisco 3660 series only, online insertion and removal (OIR) is now supported in Cisco IOS Release 12.1(5)T.
6 Supported in Fast Ethernet mixed media network modules: NM-1FE2W, NM-2FE2W, NM-1FE1R2W, NM-2W.
Determining the Software Version
To determine the version of Cisco IOS software running on a Cisco 3600 series router, log in to the router and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) 3660 Software (c3660-js-mz), Version 12.1(5) XM7, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, refer to Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:
http://www.cisco.com/warp/public/130/upgrade_index.shtml
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Cisco IOS Release 12.1(5) XM7 supports the same feature sets as Cisco IOS Release 12.1(5) T, but Cisco IOS Release 12.1(5) XM7 can include new features supported by the Cisco 3600.
Caution
Table 3, Table 4 and Table 5 list the features and feature sets supported by the Cisco 3660 in Cisco IOS Release 12.1(5) XM7 and use the following conventions:
•
•
•
Note
Table 3 Feature Lists by Feature Sets for the Cisco 3661 and 3662 Routers, Part 1 of 3
FW/
IDS
IDS Plus
IPSec 56
H.323
Plus
IPSec 56
IDS Plus
IPSec
3DES
Plus
IPSec
3DES
IPX/
AT/
DEC
AT/
DEC/ FW/
IDS PlusAnalog DID for Cisco 2600 and Cisco 3600 Series Routers
(5) XM
No
Yes
No
Yes
Yes
Yes
Yes
No
Yes
High Performance Gatekeeper
(5) XM
No
No
Yes
No
No
No
No
No
No
MGCP CAS PBX and AAL2 PVC1
(5) XM
No
Yes
No
Yes
Yes
Yes
Yes
No
Yes
MGCP Basic CLASS and Operator Services
(5) XM
No
Yes
No
Yes
Yes
Yes
Yes
No
Yes
Multiservice Interchange (MIX) Functionality on 3600 Series Multiservice Platforms
(5) XM
No
Yes
No
Yes
Yes
Yes
Yes
No
Yes
SIP Diversion Header Implementation for Redirecting Number
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
SIP Gateway Support for Third Party Call Control
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
SIP User Agent MIB
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
WT-2750 Multipoint Broadband Wireless System
(5) XM
No
Yes
No
Yes
Yes
Yes
Yes
No
Yes
1 AAL2 PVC is not implemented in this release.
Table 4 Feature Lists by Feature Sets for the Cisco 3661 and 3662 Routers, Part 2 of 2
IPX/AT/
DEC Plus
Plus
FW/IDS Plus
IPSec 56
FW/ IDS
Plus IPSec
3DES
Plus IPSec
56
Plus IPSec 3DESAnalog DID for Cisco 2600 and Cisco 3600 Series Routers
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
High Performance Gatekeeper
(5) XM
No
Yes
No
No
No
No
MGCP CAS PBX and AAL2 PVC1
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
MGCP Basic CLASS and Operator Services
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
Multiservice Interchange (MIX) Functionality on 3600 Series Multiservice Platforms
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
SIP Diversion Header Implementation for Redirecting Number
(5) XM
No
Yes
Yes
Yes
Yes
Yes
SIP Gateway Support for Third Party Call Control
(5) XM
No
Yes
Yes
Yes
Yes
Yes
SIP User Agent MIB
(5) XM
No
Yes
Yes
Yes
Yes
Yes
WT-2750 Multipoint Broadband Wireless System
(5) XM
Yes
Yes
Yes
Yes
Yes
Yes
1 AAL2 PVC is not implemented in this release.
Table 5 Feature Lists by Feature Sets for the Cisco 3661 and 3662 Routers, Part 3 of 3
SNASw
Plus
SNASw Plus
SNASw Plus
IPSec 3DES
SNASw Plus
IPSec 56
Plus
IPSec
3DESAnalog DID for Cisco 2600 and Cisco 3600 Series Routers
(5) XM
Yes
Yes
Yes
Yes
No
Yes
Yes
High Performance Gatekeeper
(5) XM
No
No
No
No
No
No
No
MGCP CAS PBX and AAL2 PVC1
(5) XM
Yes
Yes
Yes
Yes
No
Yes
Yes
MGCP Basic CLASS and Operator Services
(5) XM
Yes
Yes
Yes
Yes
No
Yes
Yes
Multiservice Interchange (MIX) Functionality on 3600 Series Multiservice Platforms
(5) XM
Yes
Yes
Yes
Yes
No
Yes
Yes
SIP Diversion Header Implementation for Redirecting Number
(5) XM
Yes
Yes
Yes
Yes
No
No
No
SIP Gateway Support for Third Party Call Control
(5) XM
Yes
Yes
Yes
Yes
No
No
No
SIP User Agent MIB
(5) XM
Yes
Yes
Yes
Yes
No
No
No
WT-2750 Multipoint Broadband Wireless System
(5) XM
Yes
Yes
Yes
Yes
No
Yes
Yes
1 AAL2 PVC is not implemented in this release.
New and Changed Information
The following is a list of the new hardware and software features supported by the Cisco 3600 series for Release 12.1(5) XM7.
New Hardware and Software Features in Cisco IOS Release 12.1(5)XM7
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM7.
New Hardware and Software Features in Cisco IOS Release 12.1(5)XM6
Cisco IOS Release 12.1(5) XM6 does not support the Cisco 3600 series .
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM5
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM5.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM4
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM4.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM3
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM3.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM2
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM2.
New Hardware and Software Features in Cisco IOS Release 12.1(5) XM1
There are no new hardware and software features in the Cisco 3600 series for Cisco IOS Release 12.1(5) XM1.
New Hardware Features in Cisco IOS Release 12.1(5) XM
The following new hardware is supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) XM.
2-Port Analog DID Voice Interface (VIC2-DID)
This Direct Inward Dial (DID) voice interface enables a Cisco 3600 series router to provide DID service to extensions on a PBX.
Wireless Network Module
The NM-WMDA wireless network module installs in the network module slot of a Cisco 2600 series router. Installing a wireless network module enables the Cisco 2600 series router to act as a subscriber unit (SU) in a point-to-multipoint wireless network. It is configured through the router's system console or via the CiscoView network management system. The network module provides the control and data interface between the Cisco 3600 series digital motherboard and the radio frequency (RF) subsystem in the wireless transverter. It also provides the up/down conversion from baseband to intermediate frequency (IF). One network module supports one or two wireless transverters (main and diversity).
Microcode software images ship in Flash memory along with the system software image. When the router starts, the system software unpacks the microcode software bundle and loads the proper software on all the interface linecards.
It is possible to use a later version of microcode software than the one shipped with the Cisco IOS software from the factory. The microcode software in Flash memory is mapped to the linecards. Unless you fully understand how Cisco IOS software uses microcode software, it is important to keep the factory configuration.
The multipoint wireless modem card requires external microcode software. Information about this microcode software is available (with a Cisco.com login) at:
http://www.cisco.com/cgi-bin/tablebuild.pl/rsu.
For further information regarding the network module, refer to the Cisco Network Modules Hardware Installation Guide (for Cisco 3600 series routers) for detailed installation instructions, and the Software Configuration Guide (for Cisco 3600 series routers) for an overview of network module configuration procedures and information on configuring specific network modules.
MIX 3660 Module
The Multiservice Interchange (MIX) 3660 module (MIX-3660-64) is used on the Cisco 3660 series to enable the Multiservice Interchange (MIX), which supports switching of DS0 time slots via MIX interconnects across the backplane to each network module slot. This enables the Cisco 3660 series to switch DS0 voice channels on a T1/E1 interface on one network module to and from a separate voice- processing network module.
New Software Features in Cisco IOS Release 12.1(5) XM
The following new software features are supported by the Cisco 3600 series for Cisco IOS Release 12.1(5) XM.
Analog DID for Cisco 2600 and Cisco 3600 Series Routers
Direct Inward Dialing (DID) is a service offered by telephone companies that enables callers to dial directly to an extension on a Private Branch Exchange (PBX) without the assistance of an operator or automated call attendant. This service makes use of DID trunks, which forward only the last three to five digits of a phone number to the PBX. If, for example, a company has a PBX with extensions 555-1000 to 555-1999, and a caller dials 555-1234, the local CO would forward 234 to the PBX. The PBX would then ring extension 234. This entire process is transparent to the caller.
When this feature is configured, a voice-enabled Cisco 2600 and Cisco 3600 series router can receive calls from a DID trunk and connect them to the appropriate extensions.
High Performance Gatekeeper
The High Performance Gatekeeper provides the network administrator the ability to identify H.323 traffic and apply appropriate policies.
The High Performance Gatekeeper is implemented on Cisco IOS software and enables a network manager to:
•
•
•
•
MGCP CAS PBX and AAL2 PVC
The MGCP CAS PBX and AAL2 PVC feature set extends the earlier Simple Gateway Control Protocol (SGCP) CAS and AAL2 support onto the merged SGCP/MGCP software base. These features enable various service provider solutions, including Integrated Access, IP PBX, Residential Cable Access, and Voice over DSL. The added AAL2 PVC features are not implemented in this release.
Multiservice Interchange (MIX) Functionality on the 3600 Series Multiservice Platforms
Multiservice Interchange (MIX) Functionality adds TDM connection capabilities to Cisco 3600 series multiservice platforms. On the Cisco 3660, MIX requires the installation of a multiservice interchange card, also called a "MIX module" (MIX-3660-64). On the Cisco 3620 and Cisco 3640, MIX features are software only. MIX features support applications that are sensitive to time delay, such as voice and video. MIX enables the combination of different types of traffic on a single T1 or E1 connection, giving customers the flexibility to manage traffic through their routers efficiently, as either traditional TDM connections or in packet-based format.
On all Cisco 3600 series multiservice platforms, MIX allows connection of TDM streams between separate voice/WAN interface cards (VWICs) on the same fast Ethernet network module (NM-xFE2W).
On the Cisco 3660, the MIX module also enables the following features:
•
•
•
In addition, extended availability drop and insert (EADI) capabilities have been enhanced to allow MIX connections across slots to stay up through a router reload if they have been saved in the NVRAM.
MGCP Basic CLASS and Operator Services
The MGCP Basic CLASS and Operator Services are a set of calling features, sometimes called "custom calling" features, that use MGCP to transmit voice, video, and data over the IP network. These features are usually found in circuit-based networks. MGCP BCOS brings them to the Cisco IOS gateways on packet-based networks.
The MGCP BCOS software is built on the MGCP CAS PBX and AAL2 software package, and supports MGCP 0.1 and the earlier protocol versions Simple Gateway Control Protocol (SGCP) 1.1 and 1.5.
The following MGCP BCOS features are available on Residential Gateways (RGWs):
•
•
•
•
•
•
•
•
•
•
The following two features can be run as RGW or trunking gateway (TGW) features:
•
•
SIP Diversion Header Implementation for Redirecting Number
The SIP Diversion Header Implementation for Redirecting Number feature provides support for a new Session Initiation Protocol (SIP) header field; Call Control (CC)-Diversion. The CC-Diversion header field enables the SIP gateway to pass call control redirecting information during the call setup. Call control redirection is the redirection of a call based on a subscriber service such as call forwarding, and is typically used for Unified Messaging and voice mail services to identify the recipient of a message. SIP gateway support has also been enhanced to process a SIP 3xx Redirection response after the receipt of a SIP 18x Information response. More information about this feature is available at:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/hennigan.htm
More information about the Session Initialtion Protocol Gateway Call Flows is available at:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/
SIP Gateway Support for Third Party Call Control
The SIP Gateway Support for Third-Party Call Control feature enables one endpoint (for example, a call controller) to create, modify, or terminate calls between other endpoints via delayed media negotiation. A delayed media negotiation is one where the Session Description Protocol (SDP) information is not completely advertised in the initial call setup. Third-party call control is often used for operator services (creating a call connecting two parties together) and conferencing. SIP gateway support has also been enhanced to allow SIP gateways to route using a Fully Qualified Domain Name (FQDN) in addition to using an IP address. More information about this feature is available at:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/caribou.htm
More information about the Session Initialtion Protocol Gateway Call Flows is available at:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121rel/sipcfs/
SIP User Agent MIB
The SIP User Agent MIB adds the ability to manage a Session Initiation Protocol (SIP) network via an SNMP-based network management platform.
WT-2750 Multipoint Broadband Wireless System
The Cisco broadband fixed wireless point-to-multipoint system is an integrated solution consisting of one headend and multiple subscriber units. The fixed wireless point-to-multipoint subscriber unit is designed to receive radio frequency (RF) signals from the headend. It also transmits a return signal to the headend. This return signal is a point-to-point signal, so a properly installed subscriber antenna must be correctly oriented with the headend antenna to which it is transmitting. For more information about the fixed wireless point-to-multipoint headend feature, see Point-to-Multipoint Support for the Cisco uBR7200 Series Universal Broadband Router.
MIBs
Current MIBs
To obtain lists of supported MIBs by platform and Cisco IOS release, and to download MIB modules, go to the Cisco MIB website on Cisco.com at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.
Deprecated MIBs
Old Cisco MIBs will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs without affecting existing Cisco IOS products or network management system (NMS) applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 6.
Important Notes
Non-Software Caveats - UNII Configuration
•
A shift in frequency-locked loop (FLL) control voltage causes a 24-MHz reference signal drift on the wireless multipoint network module with diversity (NM-WMDA). As a result, a large-frequency offset occurs in unlicensed national information infrastructure (UNII) outdoor unit (ODU) receive (Rx) and transmit (Tx) oscillators, which are locked on to the 24 MHz reference coming from the NM-WMDA. That causes signal-to-noise ratio (SNR) degradations for both upstream and downstream signals.
The SNR degradation is insignificant in multichannel multipoint distribution service (MMDS) links. However, In UNII links the degradation can be significant, since the local oscillator (LO) multiplication ratio is much higher for UNII frequencies.
Workaround for UNII: The shift in the 24 MHz reference must be minimized by imposing a maximum 2 ms continuous burst size. This is achieved by not using the following slow upstream modulation profiles:
–
–
In addition to eliminating slow upstream modulation profiles, it is also necessary to set the maximum packet concatenation size to 1522 bytes for all supported modulation profiles. This is done by setting sub-TLV 6 (Maximum Upstream Channel Transmit Burst Configuration Setting), which is part of TLV 4 (Class of Service Configuration Setting), to 1522, which is the maximal number of bytes that can be concatenated. Note that the "Maximum Upstream Channel Transmit Burst Configuration Setting" has to be set for the customer-premise equipment (CPE) to be operational, so the above-mentioned modification is minimal.
Product Number Change
Beginning with Cisco IOS Release 12.0(7)XK, Cisco changed the product numbers you use to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.
Caveats for Cisco IOS Release 12.1 XM
Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
This section contains only open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Cisco IOS Release 12.1 and Cisco IOS Release 12.1T are also in Cisco IOS Release 12.1(5) XM7.
For information on caveats in Cisco IOS Release 12.1T, see Caveats for Cisco IOS Release 12.1T.
For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1, which lists severity 1 and 2 caveats and select severity 3 caveats for Cisco IOS Release 12.1 and is located on Cisco.com and the Documentation CD-ROM.
Caveat numbers and brief descriptions of caveats in Cisco IOS Release 12.1(5) XM7 are listed in Table 7. For details about a particular caveat, go to Bug Toolkit at:
http://www.cisco.com/kobayashi/bugs/bugs.html
To access this location, you must have an account on Cisco.com. For information about how to obtain an account, go to the "Feature Navigator" section.
Note
Open Caveats — Cisco IOS Release 12.1(5) XM7
There are no open caveats specific to Cisco IOS Release 12.1(5) XM7 that require documentation in the release notes.
Resolved Caveats — Cisco IOS Release 12.1(5) XM7
All the caveats listed in Table 7 are open in Cisco IOS Release 12.1(5) XM7. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open and Resolved Caveats for Release 12.1(5) XM6
Cisco IOS Release 12.1(5) XM6 does not support the Cisco 3600 series .
Open Caveats—Cisco IOS Release 12.1(5) XM5
There are no open caveats specific to Cisco IOS Release 12.1(5) XM5 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.1(5) XM5
All the caveats listed in Table 8 are resolved in Cisco IOS Release 12.1(5) XM5. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM4
All the caveats listed in Table 9 are open in Cisco IOS Release 12.1(5) XM4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Table 9 Open Caveats for Release 12.1(5) XM4
CSCdt61467
Need a way to change the default value of VPDN parameters
Resolved Caveats—Cisco IOS Release 12.1(5) XM4
All the caveats listed in Table 10 are resolved in Cisco IOS Release 12.1(5) XM4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM3
All the caveats listed in Table 11 are open in Cisco IOS Release 12.1(5) XM3. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Resolved Caveats—Cisco IOS Release 12.1(5) XM3
All the caveats listed in Table 12 are resolved in Cisco IOS Release 12.1(5) XM3. This table lists only severity 1 and 2 caveats and select severity 3 caveats.
Open Caveats—Cisco IOS Release 12.1(5) XM2
This section documents possible unexpected behavior by Cisco IOS Release 12.1(5) XM2 and describes only severity 1 and 2 caveats and select severity 3 caveats.
•
During brief periods of high-traffic activity on the subscriber-unit router and with the router's CPU overloaded, the radio "link-metrics" (continuous codeword error statistics) might not be collected because network-packet traffic has priority over the radio "link-metrics" on the CPU. This might cause the "link-metrics" tables to show zeros only and/or error messages to be generated. There is no workaround.
•
The system will accept a statistic parameter for a second antenna even though it is a single-antenna system.
Workaround: Disregard data for the second antenna.
•
When the PPP Password Authentication Protocol (PAP)-password validation fails—that is, when the PPP PAP password is configured incorrectly—a slow memory leak occurs. There is no workaround.
•
An endpoint that is controlled by the Media Gateway Control Protocol (MGCP) or the Simple Gateway Control Protocol (SGCP) might go into a state where notification request (RQNT) message receives the following response, even after retrying the RQNT message several times:
400 Endpt in transient state:Workaround: Reboot the Cisco 3600 router to recover the endpoint.
•
The mapping of the ISDN release code does not follow the documentation as stated in the Enhancements to the Session Initiation Protocol for VoIP on Cisco Access Platforms feature module at http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121t/121t3/dtsipgv2.htm. There is no workaround.
•
Hairpinning a call on an HDV module when the call is hung up before being connected causes the "D" channel to go down. There is no workaround.
•
A "B" channel might remain in a "busy" state for an undetermined time after a call is terminated. Eventually the "B" channel is released. There is no workaround.
•
On an outgoing call, the Cisco 3600 router does not map the progress message that it receives. This causes the inband ringback not to be heard. There is no workaround.
•
Using VCON clients, the T120 proxy does not work when a call is established through NetMeeting. There is no workaround.
Resolved Caveats—Cisco IOS Release 12.1(5) XM2
All the caveats listed in this section are resolved in Cisco IOS Release 12.1(5) XM2. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco IOS software contains a flaw that permits the successful prediction of TCP Initial Sequence Numbers.
This vulnerability is present in all released versions of Cisco IOS software running on Cisco routers and switches. It only affects the security of TCP connections that originate or terminate on the affected Cisco device itself; it does not apply to TCP traffic forwarded through the affected device in transit between two other hosts.
To remove the vulnerability, Cisco is offering free software upgrades for all affected platforms. The defect is described in DDTS record CSCds04747.
Workarounds are available that limit or deny successful exploitation of the vulnerability by filtering traffic containing forged IP source addresses at the perimeter of a network or directly on individual devices.
This notice will be posted at http://www.cisco.com/warp/public/707/ios-tcp-isn-random-pub.shtml.
This caveat is resolved in Cisco IOS Release 12.1(5) XM2.
Open Caveats—Cisco IOS Release 12.1(5) XM1
The caveats listed in this section are open in Cisco IOS Release 12.1(5) XM1.
•
This caveat is included because a Cisco 3600 series router can function as a Gatekeeper.
On a Cisco 7200 series router, the Gatekeeper Transaction Message Protocol (GKTMP) may not be able to re-establish connection to the backend server until five minutes after the connection was terminated.
The Gatekeeper sends all requests to the server. However, if there is a slow link or limited processor capacity, the server is unable to respond to these requests on time. When this happens, the Gatekeeper may mark the server as unreachable and terminate the connection. Once the connection is terminated, it will not be re-established for another five minutes.
Workaround: Match server capacity to process requests with the number and capacities of the gatekeepers it is serving.
•
The system will accept a statistic parameter for a second antenna even though it is a single-antenna system.
Workaround: Disregard data for the second antenna.
•
During brief periods of high-traffic activity on the subscriber-unit router and with the router's CPU overloaded, the radio "link-metrics" (continuous codeword error statistics) might not be collected because network-packet traffic has priority over the radio "link-metrics" on the CPU. This might cause the "link-metrics" tables to show zeros only and/or error messages to be generated. There is no workaround.
•
An endpoint that is controlled by the Media Gateway Control Protocol (MGCP) or the Simple Gateway Control Protocol (SGCP) might go into a state where notification request (RQNT) message receives the following response, even after retrying the RQNT message several times:
400 Endpt in transient state:Workaround: Reboot the Cisco 3600 router to recover the endpoint.
•
FXS VIC and DID VIC fail to recognize on-hook.
•
A Cisco 3600 series router functioning as a gateway might modify the ISDN cause code, which is then passed on to the session initiation protocol (SIP) and might cause service to be unavailable. There is no workaround.
•
When a Cisco 3600 series router functioning as a gateway in an SS7 configuration sets up an MGCP connection successfully, and then receives a "delete connection" (DLCX) message before the ringing tone is stopped, or receives any signal which needs a digital signal processor (DSP) resource, the VoIP call is cleared and the telephony call leg is maintained.
However, if a "notification request" (RQNT) message is sent after a DLCX message, the ringing tone stops but the telephony call leg is not cleared. This causes the endpoint to be unable to accept any more calls.
Workaround: Issue the no mgcp command followed by the mgcp command.
First alternative workaround: Make sure the call appearance (CA) sends a RQNT message before a DLCX message.
Second alternative workaround: Make sure the CA sends a DLCX message with"X:<id>".
•
On a Cisco 3600 series router functioning as a gateway, MGCP calls might cause a memory leak. There is no workaround.
Resolved Caveats—Cisco IOS Release 12.1(5) XM1
All the caveats listed in this section are resolved in Cisco IOS Release 12.1(5) XM1. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
When a call is set up, a large number of lost packets might be reported during the negotiation. Once the call is connected, packets go through properly and counters do not continue to increment.
This caveat has been resolved in Cisco IOS Release 12.1(5) XM1.
•
Connection setup improvements.
This caveat has been resolved in Cisco IOS Release 12.1(5) XM1
Open Caveats—Cisco IOS Release 12.1(5) XM
The caveats listed in this section are open in Cisco IOS Release 12.1(5) XM.
•
During brief periods of high-traffic activity on the subscriber-unit router and with the router's CPU overloaded, the radio "link-metrics" (continuous codeword error statistics) might not be collected because network-packet traffic has priority over the radio "link-metrics" on the CPU. This might cause the "link-metrics" tables to show zeros only and/or error messages to be generated. There is no workaround.
•
The system will accept a statistic parameter for a second antenna even though it is a single-antenna system.
Workaround: Disregard data for the second antenna.
•
An endpoint that is controlled by the Media Gateway Control Protocol (MGCP) or the Simple Gateway Control Protocol (SGCP) might go into a state where notification request (RQNT) message receives the following response, even after retrying the RQNT message several times:
400 Endpt in transient state:Workaround: Reboot the Cisco 3600 router to recover the endpoint.
Resolved Caveats—Cisco IOS Release 12.1(5) XM
There are no resolved caveats specific to Cisco IOS Release 12.1(5) XM that require documentation in the release notes.
Related Documentation
The following sections describe the documentation available for the Cisco 3600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.1 and are located on Cisco.com and the Documentation CD-ROM:
•
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
As a supplement to the caveats listed in "Caveats for Cisco IOS Release 12.1 XM" in these release notes, see Caveats for Cisco IOS Release 12.1 and Caveats for Cisco IOS Release 12.1T, which contains caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.1 and Cisco IOS Release 12.1 T.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Release Notes: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Caveats
Note
Platform-Specific Documents
The documents listed below are available for the Cisco 3600 series routers and are also available on Cisco.com and on the Documentation CD-ROM.
•
•
•
•
On Cisco.com, beginning under the Service & Support heading:
Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers
On the Documentation CD-ROM:
Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.1(5)XM3 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: New Feature Documentation
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.
Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. It contains feature information about mainline-, T-, S-, and P-trains. You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1: Configuration Guides and Command References
Cisco IOS Release 12.1 Documentation Set Contents
Table 13 lists the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form if ordered.
Note
On Cisco.com at:
Technical Documents: Cisco IOS Software: Cisco IOS Release 12.1
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:
Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
Guest
