Release Notes for Cisco uBR924 Cable Access Router for Cisco IOS Release 12.1 XM


February 13, 2002


Note You can find the most current Cisco IOS documentation on Cisco.com. This set of electronic documents may contain updates and modifications made after this document was published.


These release notes for the Cisco uBR924 cable access router describe the enhancements provided in Cisco IOS Release 12.1(5)XM7. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.

For a list of software caveats that apply to Release 12.1(5)XM7, see the "Caveats" section and Caveats for Cisco IOS Release 12.1 TThe caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.1 Tlocated on Cisco.com and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

Introduction

Early Deployment Releases

System Requirements

New and Changed Information

MIBS

Limitations and Restrictions

Important Notes

Caveats

Troubleshooting

Related Documentation

Obtaining Documentation

Obtaining Technical Assistance

Introduction

For information on new features and Cisco IOS commands supported by Release 12.1 XM, see the "New and Changed Information" section and the "Related Documentation" section.

The DOCSIS-based Cisco uBR924 cable access router gives residential or small office/home office (SOHO) subscribers high-speed Internet or intranet access. The Cisco uBR924 cable access router supports both data traffic and packet voice and fax traffic via a shared two-way cable system and Internet Protocol (IP) backbone network. The Cisco uBR924 cable access router connects computers and other customer premises devices at a subscriber site to the service provider's cable, hybrid-fiber coaxial (HFC), and IP backbone network.

The Cisco uBR924 cable access router is based on Data-over-Cable Service Interface Specifications (DOCSIS) and interoperates with any bidirectional, DOCSIS-qualified cable modem termination system (CMTS). The Cisco uBR924 cable access router ships from the Cisco factory with a Cisco IOS software image stored in nonvolatile Flash memory that supports DOCSIS-compliant bridging data operations. The Cisco uBR924 cable access router functions as a cable modem at the subscriber site to convey data communications on the cable television system.

Special operating modes, based on your service offering and the practices in place for your network, can be supported for the Cisco uBR924 router, based on the available images in Cisco IOS Release 12.1(5)XM7. The Cisco uBR924 cable access router can also function as an advanced router, providing wide-area network (WAN) data connectivity in a variety of configurations.


Note All Cisco uBR924 cable access router images support DOCSIS Baseline Privacy Interface (BPI) encryption. BPI is subject to export restrictions.


Cisco uBR924 Cable Access Router

The Cisco uBR924 cable access router features a single F-connector interface to the cable system, four RJ-45 (10BASE-T Ethernet) hub ports, two RJ-11 Foreign Exchange Station (FXS) voice ports, one RJ-11 port for an optional backup analog telephone line connection, and one RJ-45 console port to connect to a laptop computer/console terminal for local Cisco IOS configuration. The Cisco uBR924 cable access router supports voice and data Cisco IOS software images; available feature sets include Easy IP and voice.

Early Deployment Releases

These release notes describe the Cisco uBR924 cable access router for Cisco IOS Release 12.1(5)XM7, which is an early deployment (ED) release based on Cisco IOS Release 12.1(5)T. Early deployment releases contain fixes for software caveats and support for new Cisco hardware and software features.

In addition to the new features that are introduced in Cisco IOS Release 12.1(5)XM2 for the Cisco uBR924 cable access router, all features that are supported in Release 12.1(5)T are also supported in Release 12.1(5)XM7. Table 3Table 1 shows the new features supported in Release 12.1(5)XM2. Table 3 lists all features supported in Release 12.1(5)XM7.

Table 1 Early Deployment Releases for the Cisco uBR924 Cable Access Router

ED Release
Maintenance Release
New Software Features in Release 12.1(5)XM2 and
Software Features Inherited from Release 12.1(5)T
Availability
Cisco IOS
Release 12.1 XM3

(5)

MGCP1 CAS2 PBX3 and AAL24 PVC5

MGCP Basic CLASS6 and Operator Services

Now

Cisco IOS
Release 12.1 T

(5)

NAT7 - Support for NetMeeting Directory (Internet Locator Service - ILS)

Parser Cache

Support for the ip address docsis command

Now

(3a)

HSRP8 Support for ICMP9 Redirect

Media Gateway Control Protocol Residential Gateway Support

Secure Shell (SSH) Version 1 Client Support

Support for the ip address dhcp command

XGCP10 MIB11  support for both the MGCP and SGCP12 protocols

Now

(2)

Configurable H.225 Timers

Ecosystem Gatekeeper Interoperability Enhancements, Phase 2

H.323 Support for Virtual Interfaces

RFC 2233 support for link up/down traps and for the IF-MIB MIB

Now

(1)

Cable Monitor Web Diagnostics Tool

Cisco Cable Clock Card Support

DOCSIS 1.0+ Extensions—Dynamic Multi-SID13 Assignment and Concatenation

Dynamic Host Configuration Protocol (DHCP) Proxy Support

Ecosystem Gatekeeper Interoperability Enhancements

H.323 Enhancements

Secure Shell Server (SSH) Support

SNMP14 Enhancements

Note Release 12.1 T also includes the features from Release 12.0 T and Release 12.0(7)XR.

Now

1 MGCP = Media Gateway Control Protocol

2 CAS = Channel Associated Signaling

3 PBX = private branch exchange

4 AAL2 = ATM Adaptation Layer 2

5 PVC = Permanent Virtual Circuit

6 CLASS = Custom Local Area Subscriber Services

7 NAT = Network Address Translation

8 HSRP = Hot Standby Router Protocol

9 ICMP = Internet Control Message Protocol

10 XGCP is meant to represent both Simple Gateway Control Protocol and Media Gateway Control Protocol.

11 MIB = Management Information Base

12 SGCP = Simple Gateway Control Protocol

13 SID = Service ID

14 SNMP = Simple Network Management Protocol


System Requirements

This section describes the system requirements for Cisco IOS Releases 12.1(5)XM7 and includes the following sections:

Memory Recommendations

Headend Interoperability

Supported Hardware

Determining the Software Version

Upgrading to a New Software Release

Feature Set Tables

Memory Recommendations

Table 2 lists the memory recommendations for each of the feature sets available for the Cisco uBR924 cable access router in Cisco IOS Release 12.1(5)XM7. The image subset legend for Table 2Table 2 is as follows:

y5=Reduced IP image with Easy IP functionality (PAT/NAT/DHCP server)

v4=Voice set

k1=DOCSIS baseline privacy

Table 2 Memory Recommendations for the Cisco uBR924 Cable Access Router,
Release 12.1(5)XM7 Feature Sets

Feature Set Matrix Term
Image Name
Minimum
Recommended
Flash
Memory
Minimum
Recommended
DRAM
Memory
Runs
From

Home Office with Voice—Base image with Easy IP and Voice

ubr920-k1v4y5-mz

4 MB Flash

16 MB DRAM

RAM


Headend Interoperability

Cisco Cable Clock Card Support

The Cisco uBR924 cable access router automatically supports the Cisco Cable Clock Card feature for voice traffic when the CMTS is a Cisco uBR7200 series universal broadband router with the Cisco Cable Clock Card feature.

DOCSIS Concatenation

If using DOCSIS concatenation with a 16-QAM (quadrature amplitude modulation) symbol rate, the CMTS must be configured for Unique Word 16 in the preamble for both short and long data burst profiles. On the Cisco uBR7200 series universal broadband routers, use the cable modulation-profile global configuration command and specify "uw16" for both the long and short modulation profiles.

DOCSIS 1.0+ Extensions

Cisco IOS Release 12.1 XM images support the Cisco DOCSIS 1.0+ Extensions, which include dynamic multi-SID assignment and concatenation. To use the dynamic multi-SID and concatenation features, both the Cisco uBR924 router and the CMTS router must support them. If you are using the Cisco uBR7200 series headend equipment as the CMTS router, Cisco IOS Release 12.0(7)XR, Release 12.1(1)T, or greater is required on the CMTS router to ensure that these features are activated.

To configure the Cisco uBR924 cable access router to support multiple classes of service, use either the Cisco Subscriber Registration Center (CSRC) tool or the configuration file editor of your choice. DOCSIS configuration files can contain multiple classes of service (CoS) to support voice. The first CoS is used for data (and voice if no other CoS is defined), and up to three additional classes of service can be defined to give higher priority for voice traffic.

Voice Protocol Support

When using a voice-enabled Cisco IOS Release 12.1 image, the Cisco uBR924 cable access router can packetize and transport voice in compliance with the H.323 protocol. H.323v2 is integrated in Cisco gatekeeper/gateway products, such as the Cisco 2600 series and Cisco 3600 series, using Cisco IOS Release 12.0(5)T. The gatekeeper must be running Cisco IOS Release 12.0(5)T or greater to support registration of the full E.164 address for each Cisco uBR924 cable access router voice port.

To support the MGCP CAS PBX and AAL2 PVC feature and the MGCP Basic CLASS and Operator Services feature, both the Cisco uBR924 cable access router and the Cisco gatekeeper/gateway products must be running Cisco IOS Release 12.1(5)XM7 or greater.

The Cisco uBR924 cable access router also supports the Simple Gateway Control Protocol (SGCP) when using voice-enabled Cisco IOS Release 12.1 images. SGCP is an alternative to the H.323 protocol that provides signaling and feature negotiation via a remote Call Agent. SGCP eliminates the need for a dial plan mapper. It also eliminates the need for static configuration on the router to map IP addresses to telephone numbers because this function is provided by the remote Call Agent.

Supported Hardware

The Cisco uBR924 cable access router contains the following interfaces:

A single F-connector interface to the cable system.

Four RJ-45 (10BASE-T Ethernet) hub ports to connect:

Up to 254 computers directly to the four Ethernet hub ports at the rear of the Cisco uBR924 router when operating in bridging mode. When operating in routing mode, all four Ethernet hub ports can be connected directly to four computers.


Note For releases earlier than Cisco IOS Release 12.0(5)T, the four Ethernet hub ports only support a maximum of three computers when operating in bridging mode. (The maximum of three computers is for all four ports together— not three computers per port).


One of the four Ethernet hub ports at the rear of the Cisco uBR924 router can be connected to an Ethernet hub, which then connects additional computers or devices at the site when operating in routing or bridging mode.

Two RJ-11 Foreign Exchange Station (FXS) ports connect telephones and fax devices to the cable system and IP backbone; the router ships from the Cisco factory with the voice ports enabled. The FXS ports on the Cisco uBR924 router can be connected to analog telephones or fax machines but cannot be used for private branch exchange (PBX) extensions.

One RJ-11 port connects to a standard, analog telephone line (optional) to provide a backup plain old telephone service (POTS) connection to the Public Switched Telephone Network (PSTN). The backup port becomes operational if the Cisco uBR924 router loses power or its connection to the cable network.

One RJ-45 console port (optional) to connect to a laptop computer or console terminal when locally configuring the Cisco uBR924 router; the router ships from the Cisco factory with the console port enabled.

Determining the Software Version

To determine the version of Cisco IOS software running on your Cisco uBR924 cable access router, log into the Cisco uBR924 cable access router and enter the show version EXEC command:

For the Cisco uBR924 cable access router:

Router# show version
Cisco Internetwork Operating System Software
IOS (tm) 920 Software (ubr920-k1v4y5-mz), Version 12.1(5)XM7, RELEASE SOFTWARE

Upgrading to a New Software Release

For technical information about upgrading to a new software release, see Cisco IOS Upgrade Ordering Instructions on Cisco.com at http://www.cisco.com/warp/public/620/6.html.

For other information about upgrading to Cisco IOS Release 12.1, see the product bulletin Cisco IOS Software Release 12.1 Upgrade Paths and Packaging Simplification on Cisco.com at:

Service & Support: Software Center: Cisco IOS Software: Product Bulletins: Software

Under Cisco IOS 12.1, click Cisco IOS Software Release 12.1 Ordering Procedures and Platform Support

Feature Set Tables

Cisco IOS software is packaged in feature sets consisting of software images, depending on the platform. Each feature set contains a specific set of Cisco IOS features.


Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit Triple Data Encryption Standard [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay because of United States government regulations. When applicable, purchaser and user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.

Table 3 lists the voice and data software images by feature sets for the Cisco uBR924 cable access router. This table uses the following conventions:

Yes—The feature is supported in the feature set.

No—The feature is not supported in the feature set.


Note These feature set tables might contain a selected list of features. These tables might not be cumulative—nor do they list all the features in each image.



Note This table might not be cumulative or list all the features in each image. You can find the most current Cisco IOS documentation on Cisco.com. This set of electronic documents may contain updates and modifications made after this document was published. If you have a Cisco.com login account, you can find image and release information regarding features prior to Cisco IOS Release 12.1(5)XM7—that is, Release 12.1(5)T, on which Release 12.1(5)XM7 is based— by using the Feature Navigator tool at: http://www.cisco.com/go/fn.


Table 3 Feature List by Feature Set for the Cisco uBR924 Cable Access Router—
Voice and Data

Features
Home Office with Voice
Feature Set

Baseline Privacy Interface (BPI) Encryption

Yes

Baseline Privacy Interface (BPI) MIB

Yes

Cable Device MIB (RFC 2669)

Yes

Cable Monitor

Yes

Firewall (Cisco Secure Integrated Software)

No

Cisco Standard MIBs

Yes

Cisco Voice MIBs

Yes

Configurable H.225 Timers

Yes

DHCP Proxy Support

Yes

DOCSIS 1.0+ Extensions (Dynamic multi-SID assignment and concatenation)

Yes

DOCSIS-Compliant Bridging

Yes

Easy IP

Yes

Ecosystem Gatekeeper Interoperability Enhancements

Yes

HSRP Support for ICMP Redirect

Yes

H.323v2 Protocol

Yes

H.323 Support for Virtual Interfaces

Yes

IPSec Encryption with 56-bit DES

No

IPSec Encryption with Triple DES [3DES]

No

Layer 2 Tunneling Protocol (L2TP)

No

Media Gateway Control Protocol (MGCP) Basic CLASS and Operator Services

Yes

MGCP CAS PBX and AAL2 PVC

Yes

MGCP Residential Gateway Support (RGW)

Yes

NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)

Yes

Parser Cache

Yes

RFC 2233 Support

Yes

Radio Frequency Interface MIB (RFC 2670)

Yes

Routing (RIP V2)

Yes

Secure Shell (SSH)—56-bit encryption

Yes

Secure Shell (SSH)—3DES encryption

No

Simple Gateway Control Protocol (SGCP)

Yes

XGCP MIB

Yes


New and Changed Information

The following sections list the new hardware and software features supported by the Cisco uBR924 cable access router.

New Hardware Features in Release 12.1(5)XM7

There are no new hardware features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM7.

New Software Features in Release 12.1(5)XM7

There are no new software features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM7.

New Hardware Features in Release 12.1(5)XM4

There are no new hardware features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM4.

New Software Features in Release 12.1(5)XM4

There are no new software features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM4.

New Hardware Features in Release 12.1(5)XM3

There are no new hardware features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM3.

New Software Features in Release 12.1(5)XM3

There are no new software features in the Cisco uBR924 for Cisco IOS Release 12.1(5)XM3.

New Hardware Features in Release 12.1(5)XM2

Cisco IOS Release 12.1(5)XM2 does not contain any new hardware features for the Cisco uBR924 cable access router.

New Software Features in Release 12.1(5)XM2

The following new software features are supported by the Cisco uBR924 cable access router for Cisco IOS Release 12.1(5)XM2.

MGCP CAS PBX and AAL2 PVC

The Media Gateway Control Protocol (MGCP) Channel Associated Signaling (CAS) private branch exchange (PBX) and ATM Adaptation Layer 2 (AAL2) Permanent Virtual Circuit (PVC) feature set—referred to as the MGCP CAS PBX and AAL2 PVC feature set— extends the earlier Simple Gateway Control Protocol (SGCP) CAS and AAL2 support onto the merged SGCP/MGCP software base. These features enable various service provider solutions, including Integrated Access, IP PBX, Residential Cable Access, and Voice over DSL.


Note For extensive information on the MGCP CAS PBX and AAL2 PVC feature, refer to the MGCP CAS PBX and AAL2 PVC feature module, on Cisco.com at
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121newft/121limit/121x/121xm/121xm_5/ftmgcpba.htm.


MGCP CAS PBX and AAL2 includes the following features:

CAS Termination and Translation to MGCP on BGWs and TGWs

Channel Associated Signaling termination and translation to MGCP is supported on Business Gateways (BGWs) and Trunking Gateways (TGWs).

Support for CAS PBX and Feature Group D CAS Functions

MGCP 0.1 has been expanded to support CAS packages that handle CAS PBX and Feature Group D CAS functions, including Barge-In/Busy-Line-Verify capabilities on the TGW.

Expanding MGCP 0.1 to Control AAL2 Voice Transport

The earlier version of the merged SGCP/MGCP stack supported only Voice over IP. The merged stack will now support both VoIP and VoAAL2. However, the Cisco uBR924 cable access router does not support this feature in Cisco IOS Release 12.1(5)XM2—only the Cisco MC3810 platform supports this feature in this release.

Addition of SGCP CAS PBX Support to the Existing Merged SGCP/MGCP Software Stack

The CAS PBX gateway features include CAS PBX trunks, digit maps, CAS events, and quarantine buffer software. These features were available in the existing standalone SGCP software; now they are supported using the SGCP protocol option in the merged stack:

Digital and analog E&M CAS PBX trunks include:

emulated Direct Outward Dial (DOD), PBX originating, multifrequency (MF) or dual tone multifrequency (DTMF), wink start or immediate start

emulated Direct Inward Dial (DID), PBX terminating, MF or DTMF, wink start or immediate start

emulated DOD/DID, bidirectional, MF or DTMF, wink start or immediate start

basic, bidirectional, DTMF, ground start

This feature is supported for both Voice over IP and Voice Transport over ATM.

SGCP CAS events include:

DTMF and MF tones

timer

power ringing

network congestion tone

busy tone

dial tone

FAX tone

modem tone

hookflash

ringback tone (analog, Rapid Transport Protocol [RTP], and Named Service Events [NSE])

The essential difference for current SGCP users is that support for the SGCP application has been replaced with the MGCP application. The MGCP application supports both SGCP commands and MGCP commands, permitting access to a larger feature set than with the SGCP application alone. The MGCP CAS PBX and AAL2 PVC software assumes the MGCP mode as the default environment. This allows the gateway to recognize both MGCP and SGCP messages sent by the Call Agent. However, the user can specify SGCP mode for certain messages that will be sent by the gateway (by using the sgcp option as the service type in the mgcp call-agent command).

MGCP Basic CLASS and Operator Services

The MGCP Basic CLASS (Custom Local Area Subscriber Services) and Operator Services (BCOS) are a set of calling features, sometimes called "custom calling" features, that use MGCP to transmit voice, video, and data over the IP network. These features are usually found in circuit-based networks. MGCP BCOS brings them to the Cisco IOS gateways on packet-based networks.

The MGCP BCOS software is built on the MGCP CAS PBX and AAL2 software package (see the section above), and supports MGCP 0.1 and the earlier protocol versions SGCP 1.1 and 1.5.

The following MGCP BCOS features are available on Residential Gateways (RGWs):

Distinctive Power Ring

Visual Message Waiting Indicator

Caller ID

Caller ID with Call Waiting

Call Forwarding

Ring Splash

Distinctive Call Waiting Tone

Message Waiting Tone

Stutter Dial Tone

Off-Hook Warning Tone

The following two features can be run as RGW or trunking gateway (TGW) features:

911 Calls

This feature is supported in SGCP mode on Cisco uBR924, Cisco 3660, and Cisco AS5300 platforms and in MGCP mode on the Cisco 3660 and Cisco AS5300 TGW platforms and on the Cisco MC3810, Cisco 2600, and Cisco uBR924 RGW platforms.

Three-Way Calling

This feature is supported on the Cisco 3660 and Cisco AS5300 TGW platforms and on the Cisco MC3810, Cisco 2600, and Cisco uBR924 RGW platforms. This feature cannot be supported on the G.728 and G.723 codecs.

Distinctive Power Ring

A telephone rings in a distinctive pattern when a call comes in from a pre-defined telephone number. Five patterns are available:

R1: one long ring

R2: long ring -long ring

R3: short ring-short ring-long ring

R4: short ring - long ring - short ring

R5: one short ring

Visual Message Waiting Indicator

A light will go on when a message is waiting for the line.

Caller ID

The calling party's telephone number, date, and time of the call appear on the receiving telephone's display between the first and second rings. Up to 18 digits are shown. Private and unlisted numbers are displayed. If the called party answers the phone on the first ring, the calling party's number will not appear.

If the called party has an appropriate name display unit, the calling party's name appears on the display along with the telephone number. The name and number appear between the first and second rings.

If the calling party has blocked Caller ID from displaying the telephone number, the called party will see "P" for private or "Anonymous" on the display unit.

Caller ID with Call Waiting

If the called party has Caller ID and has enabled the Call Waiting feature, then the calling party's telephone number and name (if an appropriate display unit is available) appear while the called party is on the line with another call.

If the calling party has blocked Caller ID from displaying the telephone number and name, the called party will see "P" for private or "Anonymous" on the display unit.

Call Forwarding

Several scenarios are available:

The system transfers all incoming calls to a designated telephone number when the called number does not answer after a predetermined interval.

The system transfers all incoming calls to a designated telephone number when the called number is busy.

The system transfers all incoming calls to a specific destination when the user enters a code and a destination telephone number that receives the calls. The user is responsible for all charges between the original called number and the receiving telephone number.

A user can activate Call Forwarding remotely using a touch-tone telephone and a user-defined PIN (default is the last four digits of the user's telephone number). The original destination telephone emits a Ring Splash when a call is forwarded.

911 Calls

The user can make a 911 call to an Emergency Service Bureau (ESB), and the call is maintained as long as the ESB does not hang up. If the user hangs up, the call is maintained. If the user hangs up then picks up the phone again, the call can resume. If the user hangs up and does not pick the phone up again, the ESB can ring the user and resume the call.

This feature is available in SGCP mode on the Cisco uBR924, Cisco 3660, and Cisco 5300 platforms and in MGCP mode on all five supported platforms.

Ring Splash

Also known as Reminder Ring, Ring Splash is activated when the user enables Call Forwarding on the telephone. The user hears Distinctive Power Ring R5 when the line is idle and a call has been forwarded. This serves as a reminder to the user that Call Forwarding is active.

Distinctive Call-Waiting Tone

The called party hears four audible tone patterns (waiting tones, or WTs) when a call is waiting on the called party's line. The tone patterns are heard in sequence as the incoming call continues to wait:

WT1: one short tone

WT2: short tone - short tone

WT3: short tone - short tone - short tone

WT4: short tone - long tone - short tone

Message Waiting Tone

For users with an active voice mail system, a special dial tone is heard when the user goes off-hook and a message is waiting. The dial tone is a sequence of 10 short tones followed by a steady tone. If the user has a telephone with a visual message indicator, the indicator light goes on when a message is waiting.

Stutter Dial Tone

This tone is used in place of the dial tone to indicate that a message is waiting. When the user goes off-hook, a sequence of three short tones followed by a steady tone is heard.

Off-Hook Warning Tone

The user hears this tone when the telephone is off-hook. The tone is repeated bursts of sound of rising pitch.

Three-way Calling

The user can create a 3-way call by pressing the switchhook quickly to put the first call on hold, dialing a third party, and pressing the switchhook again quickly to join all parties to the call. This feature is supported on all five platforms.

Requirements and limitations for Three-way Calling (TWC):

The user who sets up the 3-way call must be connected to a residential gateway, which handles the call setup. TWC is transparent to a trunking gateway.

Only the G.711u codec supports TWC. If any part of a 3-way call is made on a non-G.711u codec, that codec must be switched to G.711u mode before the second switchhook flash in order for the 3-way call to be set up.

TWC supports calls originating as Voice over IP calls, not Voice over ATM or Voice over Frame Relay calls. However, if the network has ATM or Frame Relay as a transport protocol, the VoIP call will be completed.

The user originating the 3-way call is the controller. Each of the two other users on the call can add another person onto the call, which is referred to as call chaining. Those new users can also add another person to the call. However, once five people in total are on the call, adding more users will cause voice quality to degrade.

If the controller of the call hangs up, all the users are disconnected from the call. If one of the noncontroller users hangs up, the remaining users are still connected to the call.

If the controller presses the switchhook quickly for a third time, the last user connected to the call is dropped from the call.

If two users are on a call and a third user calls one of them, that third user cannot be joined (bridged) into the two-party call.


Note Three-way calling services are limited to using only the G.711 codec voice algorithms. Attempts to connect a call using a high-complexity algorithm, such as G.729, will result in blocked calls.


Hardware and Software Features Inherited From Release 12.1(5)T

For information on hardware and software features that have been inherited from Cisco IOS Release 12.1(5)T, see the Release Notes for Cisco uBR924 Cable Access Router for Cisco IOS
Release 12.1(5)T
 on Cisco.com at
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121relnt/ubr900/9001215t.htm.

MIBS

Current MIBs

To obtain lists of supported MIBs by platform and Cisco IOS release, and to download MIB modules, go to the Cisco MIB website on Cisco.com at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.

Supported MIBs

The Cisco uBR924 cable access router supports the following categories of MIBs:

Cable Device MIBs—These MIBs are for DOCSIS-compliant cable modems and CMTS to record statistics related to the configuration and status of the cable modem. These MIBs include support for the MIB attributes defined in RFC 2669.

Cisco's standard MIBs—These MIBs are common across most of Cisco's router platforms. If your network management applications are already configured to support other Cisco routers, such as the Cisco 2600 series or Cisco 7200 series, no further configuration is needed unless the version of Cisco IOS software being used has updated these MIBs.

Cisco Voice MIBs—These MIBs are common across Cisco's router platforms that support Voice over IP (VoIP). These MIBS provide access to voice-related parameters and statistics, including the SGCP protocol.

Radio Frequency Interface MIBs—These MIBs are for DOCSIS-compliant radio frequency interfaces in cable modems and CMTS. This MIB includes support for the MIB attributes defined in RFC 2670.

SNMP standard MIBs—These are the MIBs required by any agent supporting SNMPv1 or SNMPv2 network management.

Cable-specific MIBs—These MIBs provide information about the cable interface and related information on the Cisco uBR924 cable access router. They include both DOCSIS-required MIBs and Cisco-specific enterprise MIBs. If your network management applications have not already been configured for the Cisco uBR924 cable access router, these MIBs must be loaded.

Deprecated MIBs—These MIBs were supported in earlier releases of Cisco IOS software but have been replaced by more standardized, scalable MIBs. Network management applications and scripts should convert to the replacement MIBs as soon as possible.

Cable Device MIBs

The Cisco uBR924 cable access router supports the Cable Device MIB, which is defined by RFC 2669 and describes DOCSIS-compliant cable modems and CMTS. The Cable Device MIB records statistics related to the configuration and status of the cable modem. Statistics include an events log and device status. The following list details the components of the Cable Device MIB:

"docsDevBase" group extends the MIB-II "system" group with objects needed for cable device system management.

"docsDevNmAccess" group provides a minimum level of SNMP access security.

"docsDevSoftware" group provides information for network downloadable software upgrades.

"docsDevServe" group provides information about the progress of interaction with various provisioning servers.

"docsDevEven" group provides information about the progress of reporting.

"docsDevFilter" group configures filters at link layer and IP layer for bridge data traffic.

The Cable Device MIB is very similar to the RFI MIB in that both allow access to statistics; they are different in that the Cable Device MIB reports statistics on the cable modem, and the RFI MIB reports statistics on the radio frequency transmissions over the cable television line.

Cisco Standard MIBs

The Cisco uBR924 cable access router supports the Cisco Standard MIBs, which consist of the following components:

CISCO-PRODUCT-MIB

CISCO-SYSLOG-MIB

CISCO-FLASH-MIB

BRIDGE-MIB

IF-MIB (RFC 2233)

CiscoWorks/CiscoView support


Note The Cisco Management Information Base (MIB) User Quick Reference publication is no longer published. For the latest list of MIBs supported by Cisco, see the Cisco Network Management Toolkit on Cisco.com. From the Cisco.com home page, click on this path: Service & Support: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB


Cisco Voice MIBs

The Cisco uBR924 cable access router supports the Cisco Voice MIBs are supported, which consist of the following components:

CISCO-VOICE-IF-MIB

CISCO-VOICE-DIAL-CONTROL-MIB

CISCO-VOICE-ANALOG-MIB

CISCO-DIAL-CONTROL-MIB

DIAL-CONTROL-MIB

SGCP-MIB

XGCP-MIB

Radio Frequency Interface MIBs

The Cisco uBR924 cable access router supports the Radio Frequency Interface (RFI) MIB. The RFI MIB module is defined in RFC 2670 and describes DOCSIS-compliant radio frequency interfaces in cable modems and CMTS. On the cable modem, RFI MIB entries provide:

Upstream and downstream channel characteristics

Class-of-service attributes

Physical signal quality of the downstream channels

Attributes of cable access router MAC interface

Status of several MAC layer counters

The RFI MIB includes tables describing both the CMTS and the cable modem side of the cable interface. All cable modem tables are implemented.

With IPSec, data can be transmitted across a public network without fear of observation, modification, or spoofing. This enables applications such as VPNs, extranets, and remote user access.

IPSec services are similar to those provided by Cisco Encryption Technology, a proprietary Cisco security solution. However, IPSec provides a more robust security solution, and is standards based.

SGCP and MGCP MIBs

The Cisco uBR924 cable access router supports the Simple Gateway Control Protocol (SGCP) and Media Gateway Control Protocol (MGCP) through a single MIB (XGCP-MIB). This MIB supports configuration, performance, and fault management of the SGCP and MGCP interfaces.

The key attributes of this MIB are as follows:

xgcplnBadVersions—Number of incoming messages delivered to the protocol entity and that are for an unsupported protocol version

xgcpRequestTimeOut—Timeout value used for retransmitting an unacknowledged message

xgcpRequestRetries—Number of retries for a request that exceeds timeout

xgcpAdminStatus—Desired state of the protocol entity

xgcpOperStatus—Current operational status of the protocol entity

xgcpUnRecognizedPackets—Number of unrecognized packets since reset

xgcpMsgStatTable—Table that contains SGCP statistics information since reset

xgcpMsgStatEntry—Row in the "xgcpMsgStatTable" that contains information about SGCP message statistics per IP address of the Media Gateway Controller (MGC)

xgcpIPAddress—IP address of the MGC

xgcpSuccessMessages—Number of successful messages that communicate with the MGC on that IP address

xgcpFailMessages—Number of failed messages that communicate with the MGC on that IP address

xgcpUpDownNotification—Notification sent when the protocol status changes between up and down


Note For complete details on the SGCP and MGCP MIB, see the XGCP-MIB.my file on the Cisco.com MIB website.


Cable-Specific MIBs

Table 4 shows the cable-specific MIBs that are supported on the Cisco uBR924 cable access router. This table also provides a brief description of each MIB's contents. Because of interdependencies, the MIBs must be loaded in the order given in the table.


Note The names given in Table 4 are the filenames for the MIBs as they exist on Cisco's FTP site (ftp://ftp.cisco.com/pub/mibs/ or http://www.cisco.com/public/mibs). Most MIBs are available in both SNMPv1 and SNMPv2 versions; the SNMPv1 versions have V1SMI as part of their filenames. Also see the Cisco MIBs home page at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.


Table 4 Supported MIBs for the Cisco uBR924 Cable Access Router

MIB Filename
Description

SNMPv2-SMI.my

SNMPv2-SMI-V1SMI.my

This module specifies the Structure of Management Information (SMI) for SNMPv2, as defined in RFC 1902.

SNMPv2-TC.my

SNMPv2-TC-V1SMI.my

This module defines the textual conventions as specified in pages 4 and 10-11 of RFC 854.

CISCO-SMI.my

CISCO-SMI-V1SMI.my

This module specifies the SMI for Cisco's enterprise MIBs.

CISCO-TC.my

CISCO-TC-V1SMI.my

This module defines the textual conventions used in Cisco's enterprise MIBs.

IF-MIB.my

IF-MIB-V1SMI.my

This module describes generic objects for the Layer 3 network interface sublayers. This MIB is an updated version of MIB-II's if table, and incorporates the extensions defined in RFC 2233.

CISCO-CABLE-SPECTRUM-MIB.my

CISCO-CABLE-SPECTRUM-MIB-V1SMI.my

This module describes the spectrum management flap list attributes.

DOCS-IF-MIB.my

DOCS-IF-MIB-V1SMI.my

This module describes the DOCSIS-compliant Radio Frequency (RF) interfaces in cable modems and cable modem termination systems, as described in RFC 2670.

DOCS-BPI-MIB.my

DOCS-BPI-MIB-V1SMI.my

This module describes the attributes for the DOCSIS-specified Baseline Privacy Interface (BPI) on cable modems and the CMTS.

DOCS-CABLE-DEVICE-MIB.my

DOCS-CABLE-DEVICE-MIB-V1SMI.my

This module was previously known as the CABLE-DEVICE-MIB and contains cable-related objects for DOCSIS-compliant cable modems, as specified in RFC 2669.



Note Because of interdependencies, the MIBs must be loaded in the order given in the table.


Deprecated and Replacement MIBs

A number of Cisco-provided MIBs have been replaced with more scalable, standardized MIBs; these MIBs have filenames that start with "OLD" and first appeared in Cisco IOS Release 10.2. The functionality of these MIBs has already been incorporated into replacement MIBs, but the old MIBs are still present to support existing Cisco IOS products or network management system (NMS) applications. However, because the deprecated MIBs will be removed from support in the future, you should update your network management applications and scripts to refer to the table names and attributes that are found in the replacement MIBs.

Table 5 shows the deprecated MIBs and their replacements. In most cases, SNMPv1 and SNMPv2 replacements are available, but some MIBs are available only in one version. A few of the deprecated MIBs do not have replacement MIBs; support for these MIBs will be discontinued in a future release of Cisco IOS software.

Table 5 Replacements for Deprecated MIBs

Deprecated MIB
Replacement MIBs
SNMPv1 MIB
SNMPv2 MIB

OLD-CISCO-APPLETALK-MIB

RFC1243-MIB

OLD-CISCO-CHASSIS-MIB

ENTITY-MIB-V1SMI

ENTITY-MIB

OLD-CISCO-CPU-MIB

CISCO-PROCESS-MIB

OLD-CISCO-DECNET-MIB

OLD-CISCO-ENV-MIB

CISCO-ENVMON-MIB-V1SMI

CISCO-ENVMON-MIB

OLD-CISCO-FLASH-MIB

CISCO-FLASH-MIB-V1SMI

CISCO-FLASH-MIB

OLD-CISCO-INTERFACES-MIB

IF-MIB-V1SMI
CISCO-QUEUE-MIB-V1SMI

IF-MIB
CISCO-QUEUE-MIB

OLD-CISCO-IP-MIB

OLD-CISCO-MEMORY-MIB

CISCO-MEMORY-POOL-MIB-V1SMI

CISCO-MEMORY-POOL-MIB

OLD-CISCO-NOVELL-MIB

NOVELL-IPX-MIB

OLD-CISCO-SYS-MIB

(Compilation of other OLD* MIBS)

OLD-CISCO-SYSTEM-MIB

CISCO-CONFIG-COPY-MIB-V1SMI

CISCO-CONFIG-COPY-MIB

OLD-CISCO-TCP-MIB

CISCO-TCP-MIB-V1SMI

CISCO-TCP-MIB

OLD-CISCO-TS-MIB

OLD-CISCO-VINES-MIB

CISCO-VINES-MIB-V1SMI

CISCO-VINES-MIB

OLD-CISCO-XNS-MIB



Note Some of the MIBs listed in Table 5 Table 5represent feature sets that are not supported on the Cisco uBR924 cable access router.


Limitations and Restrictions

This section describes warnings and cautions about using Cisco IOS Release 12.1(5)XM7 software.

Bridging Support

The Cisco uBR924 cable access router interoperates with DOCSIS cable networks. Cisco IOS Release 12.1 XM does not support bridging traffic across a non-DOCSIS cable network.

GRE IP Tunnels Are Not Supported

Generic routing encapsulation (GRE) IP tunnels cannot be built between two Cisco uBR924 cable access routers because GRE IP tunnels are not supported in any Cisco IOS image for the Cisco uBR924 cable access routers. IPSec tunnels, however, are supported when using Cisco IOS images that support IPSec encryption.

IP Address Negotiation

The DOCSIS specifications require that a cable modem obtain its IP address at power-on or reset from a DHCP server that is available through the cable interface. For this reason, the Cisco uBR924 cable access router defaults to a configuration that uses the ip address docsis command for the cable interface. It is not possible to override this setting by specifying a specific static IP address; to assign a static IP address to the Cisco uBR924 router, configure the DHCP server so that it assigns the desired IP address on the basis of the unit's Media Access Controller (MAC) address. However, service providers should warn subscribers that changes in the cable network's topology—due to traffic levels, growth, or changes to the cable plant and other hardware—might still require changing the subnets and IP addresses assigned to a particular cable modem.


Note The ip address negotiated and ip address dhcp commands cannot be used on the cable interface.


Upgrading Software Images Using BPI

To enable BPI encryption, the Cisco uBR924 cable access router must use a Cisco IOS image that supports BPI encryption. If the router's current software image does not support BPI encryption (or if the current software image is corrupted), you must disable BPI encryption in the DOCSIS configuration file and reset the router before you will be able to download a new software image.

Using Access Lists

Avoid manually configuring access lists 100, 101, and 102 on the Cisco uBR924 cable access router. Configuring these access lists, either by using the CLI or an Cisco IOS configuration file, can cause the router to reload. Use access lists 103 through 109 instead for those configurations that require access lists.

This situation occurs when the DOCSIS "docsDevNmAccessEntry" table is filled at initial provisioning with the network management stations that are allowed SNMP access. The router automatically uses access lists 100, 101, and 102 for the cable, Ethernet, and USB interfaces to control this access.

Using Multiple PCs with the Cisco uBR924 Cable Access Router

The "MAX CPE" parameter in a Cisco uBR924 cable access router's DOCSIS configuration file determines how many PCs (or other customer premises equipment [CPE] devices) are supported by the Cisco uBR924 cable access router. The default value for the "MAX CPE" parameter is 1, which means only one PC can be connected to the Cisco uBR924 cable access router.

The DOCSIS 1.0 specification states that a CMTS cannot age out MAC addresses for CPE devices, so the first PC that is connected to the Cisco uBR924 cable access router is normally the only one that the CMTS recognizes as valid. If a subscriber replaces an existing PC or changes its network interface card (NIC) to one that has a different MAC address, the CMTS will refuse to let the PC come online because this would exceed the maximum number of CPE devices specified by the "MAX CPE" parameter. A similar thing would happen if a user decides to move a PC from one Cisco uBR924 router to another.

To allow a subscriber to replace an existing PC or NIC, the following workarounds are possible:

If using a Cisco uBR7200 series router as the CMTS, enter the clear cable host MAC address command on the Cisco uBR7200 series router to remove the PC's MAC address from the router's internal address tables. The new PC will be rediscovered and associated with the correct Cisco uBR924 cable access router during the next DHCP lease cycle.

Increase the value of the "MAX CPE" parameter in the Cisco uBR924 cable access router's DOCSIS configuration file so that it can accommodate the desired number of PCs. Reset the Cisco uBR924 cable access router to force it to load the new configuration file.

Using the Reset Switch

The reset switch on the back panel of the Cisco uBR924 cable access router is recessed to prevent accidental resets of the router. To depress the switch, use a blunt object, such as a pen or pencil point; do not use a sharp object, such as a knife or awl, because this could damage the switch and the router's circuitry.

Important Notes

This section contains important information about using Cisco IOS Release 12.1(5)XM7 software.

CPE Device Filtering

In Cisco IOS Release 12.1(5)XM7, the "docsDevCpeIpMax" attribute defaults to -1 instead of a default of 1, which was used in the past. This attribute controls the maximum number of CPE devices that can pass traffic through the router from its Ethernet interface as follows:

When "docsDevCpeIpMax" is set to -1, the Cisco uBR924 cable access router does not filter any IP packets on the basis of their IP addresses, and CPE IP addresses are not added to the "docsDevFilterCpeTable" table.

When "docsDevCpeIpMax" is set to 0, the Cisco uBR924 cable access router does not filter IP packets on the basis of the IP addresses. However, the source IP addresses are still entered into the "docsDevFilterCpeTable" table.

When "docsDevCpeIpMax" is set to a positive integer, it specifies the maximum number of IP addresses that can be entered into the "docsDevFilterCpeTable" table. The Cisco uBR924 cable access router compares the source IP address for packets it receives from CPE devices to the addresses in this table. If a match is found, the packet is processed; otherwise, the packet is dropped.

CPE IP address filtering is done as part of the following process:

1. MAC address filtering—Packets are filtered on the basis of the CPE device's MAC address. This is controlled by the value of the "MAX CPE" parameter, which is set in the DOCSIS configuration file.

2. Link Level Control (LLC) filtering—Packets are filtered on the basis of the packet's protocol. This is controlled by the "docsDevFilterLLCTable" table.

3. CPE IP address filtering—Packets are filtered on the basis of the CPE device's IP address, as controlled by the "docsDevCpeIpMax" attribute and the "docsDevFilterCpeTable" table.

4. Access list filtering—Packets are filtered on the basis of access lists. IP filtering is controlled by the "docsDevFilterIpTable" table, and SNMP access filters are controlled by the "docsDevNmAccessTable" table.

See the DOCS-CABLE-DEVICE-MIB.my MIB for more information on the attributes and tables listed above.

Disabling the Finger Server

By default, the Cisco uBR900 series cable access router enables its onboard TCP/IP "finger" server to allow remote users to query the number and identities of any users who are logged in to the router. Unless your network operations center (NOC) requires this service, it should be disabled to prevent denial-of-service attacks that access the finger server's well-known port (TCP port 79). To disable the finger server, include the no service finger command in the Cisco IOS configuration file that the router downloads at initial power-on.

Supplemental and Corrected Text for the Online Feature Module

Troubleshooting Tips for the uBR924 Cable Access Router, page 15, indicates:

"Some CATV systems use alternative frequency plans such as the IRC (Incrementally Related Carrier) and HRC (Harmonically Related Carrier) plans. Most of the IRC channel slots overlap the EIA plan. The HRC plan is not supported by Cisco's cable access routers since so few cable plants are using this plan."

The correction should read:

"For the Cisco uBR924 cable access router, both the IRC (Incrementally Related Carrier) and HRC (Harmonically Related Carrier) plans are supported. Most of the IRC channel slots overlap the EIA plan. For the Cisco uBR924 cable access router, both the IRC and HRC plans are supported.

"The list of downstream search bands added for HRC have appropriate center frequencies and step values for an HRC channel plan. The expanded search band list may increase the amount of time required by the Cisco uBR924 cable access router to acquire the downstream signal on the HRC channel plan, which can add to the total time for complete registration of the modem the very first time it is added to the cable system."

Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

All caveats in Cisco IOS Release 12.1(5)T and earlier 12.1 T releases are also in Cisco IOS Release 12.1(5)XM7. For information on caveats in Cisco IOS Release 12.1 T, see the Caveats for Cisco IOS Release 12.1 T document.

All caveats in Cisco IOS Release 12.1 are also in Cisco IOS Release 12.1 T.

For information on caveats in Cisco IOS Release 12.1, see Caveats for Cisco IOS Release 12.1, which lists severity 1 and 2 caveats and select severity 3 caveats and is located on Cisco.com and the Documentation CD-ROM.

Caveat numbers and brief descriptions are listed in Table 7 and Table 8. For details about a particular caveat, go to Bug Toolkit at:

http://www.cisco.com/kobayashi/bugs/bugs.html

To access this location, you must have an account on Cisco.com. For information about how to obtain an account, go to the "Feature Navigator" section.


Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, go to Cisco.com and press Login. Then go to Software Center: Cisco IOS Software: Cisco Bugtool Navigator II. Another option is to go to http://www.cisco.com/support/bugtools/.


Open Caveats in Release 12.1(5)XM7

There are no open caveats specific to Cisco IOS Release 12.1(5)XM7 that require documentation in the release notes.

Closed or Resolved Caveats—Release 12.1(5)XM7

All the caveats listed in Table 6 are resolved in Cisco IOS Release 12.1(5)XM7. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 6 Closed and Resolved Caveats for Release 12.1(5) XM7

Caveat ID Number
Description

CSCdw65903

An error can occur with management protocol processing. Please use the following URL for further information:

http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903


Open Caveats in Release 12.1(5)XM4

All the caveats listed in Table 7 are open in Cisco IOS Release 12.1(5)XM4. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 7 Open Caveats for Release 12.1(5) XM4

Caveat ID Number
Description

CSCdt61467

Need a way to change the default value of VPDN param
