Release Notes for Cisco MC3810 for Cisco IOS Release 12.1 T
July 15, 2002
Note
See the "Important Notes" section for information concerning Cisco IOS Release 12.1(5)T.
Note
These release notes for the Cisco MC3810 multiservice access concentrator describe the enhancements provided in Cisco IOS Release 12.1(5)T. These release notes are updated as necessary.
For a list of software caveats that apply to Cisco IOS Release 12.1(5)T, see Caveats for Cisco IOS Release 12.1 T that accompanies these release notes. The caveats document is updated for every maintenance release and is located on CCO and the Documentation CD-ROM.
Use these release notes with the Cross-Platform Release Notes for Cisco IOS Release 12.1 located on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
•
•
Introduction
The Cisco MC3810 multiservice access concentrator is fully supported by Cisco IOS software for multiprotocol routing, bridging, and Systems Network Architecture (SNA). As part of an enterprise backbone or as customer premises equipment (CPE) to serve provider-managed network services, the Cisco MC3810 reduces operating costs and complexity, and increases network throughput and performance.
The Cisco MC3810 provides a complete file system for software images, message files, and reports. The standard Flash memory size is 8 MB, and a 16-MB upgrade option is available. The 16-MB version can hold two code images simultaneously for fail-safe upgrades.
Management and configuration of the Cisco MC3810 should be familiar to the Cisco IOS user and compatible with existing management systems. As such, it provides a superset of the Cisco command-line interface (CLI). The Cisco MC3810 can be managed by standard Cisco management platforms and facilities such as CiscoView and the native remote log-in facilities provided by Telnet and rlogin. Three types of configuration interfaces are provided:
•
•
•
The HTTP-based interface allows configuration from any web browser such as Netscape Navigator or Microsoft Explorer. The SNMP MIB allows management of the Cisco MC3810 from SNMP managers (for example, HP OpenView).
For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.1(5)T, see the "New and Changed Information" section on page 42 and the "Related Documentation" section on page 56.
System Requirements
This section describes the system requirements for Cisco IOS Release 12.1(5)T:
•
•
•
Memory Recommendations
Table 1 lists the recommended minimum memory for the Cisco MC3810 multiservice access concentrator with Cisco IOS Release 12.1(5)T.
Hardware Supported
Cisco IOS Release 12.1(5)T supports the Cisco MC3810 multiservice access concentrator. The Cisco MC3810 base chassis is a semi fixed configuration router that can be customized for a specific application at the factory or in the field by a qualified technician. The base chassis includes the following components:
•
•
•
•
•
Cisco MC3810 series concentrators are supplied in various standard hardware configurations. These are equipped with different sets of functional modules to provide specific functional capability. Many configurations are possible, but they are all variations of the basic categories described in Table 2. Supported hardware is shown in Table 3. The chassis opening for any mounting area not equipped with a functional module is closed off with a removable cover plate.
Table 2 Cisco MC3810 Series Standard Hardware Categories
Base chassis services1
None
Optional modules can be added to create other chassis variations
Base chassis services1 plus compressed analog voice connections to telephone, fax, central office, analog PBX
AVM (analog voice module) with 1 to 6 APMs (analog personality modules)
VCM3 or VCM6 or
HCM2 or HCM6
(only one voice compression module)MFT2 to support a channelized T1 or E1 trunk
MFT2 and VDM3 to support video codec dialing
Base chassis services1 plus compressed digital voice through digital PBX
DVM
VCM3 or VCM6 or
HCM2 or HCM6
(one or two voice compression modules)MFT2 to support a channelized T1 or E1 trunk
MFT2 and VDM to support video codec dialing
Base chassis services1 plus compressed digital voice through PINX
BVM and MFT1
VCM3 or VCM6 or
HCM2 or HCM6
(only one voice compression module)MFT to support a channelized T1 or E1 trunk
MFT2 and VDM3 to support video codec dialing
Base chassis services1 plus channelized T1 or E1
MFT2
DVM to support digital cross-connect voice (channel bank functionality/
drop-and-insert) through digital PBX or channel bankVDM3 to support video codec dialing
VCM3 and/or VCM6, or HCM2 and/or HCM6, to support voice compression
1 Base chassis services include administrative access, Ethernet, data transport, and video transport.
2 The MFT is available with or without BRI backup.
3 If a VDM is installed, an MFT is required to support ATM for the video dialing network connection.
Table 3 Hardware Supported on the Cisco MC3810 for Cisco IOS Release 12.1 T
6-port AVM1
MC3810-AVM6=
1-port E1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-E1=
1-port T1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-T1=
1-port unbalanced E1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-BNC=
4-port BRI voice module3
MC3810-BVM4=
ModuleSupports an RS-366 Automatic Calling Equipment (ACE) interface to the DTE port of the videoconferencing equipment4
MC3810-VDM=
1-port E & M analog module
MC3810-APM-EM=
1-port FXS analog module
MC3810-APM-FXS=
1-port FXO analog module
MC3810-APM-FXO=
1-port FXO analog module, approved for the U.K.
MC3810-FXO-UK=
1-port FXO analog module, approved for Germany
MC3810-FXO-GER=
1-port FXO analog module, approved for PR26 countries
MC3810-FXO-PR2=
1-port FXO analog module, approved for PR37 countries
MC3810-FXO-PR3=
2-DSP HCM, supports up to 8 channels of compressed voice
MC3810-HCM2=
6-DSP HCM, supports up to 24 channels of compressed voice
MC3810-HCM6=
3-DSP VCM, supports up to 6 channels9 of compressed voice
MC3810-VCM3=
6-DSP VCM, supports up to 12 channels9 of compressed voice
MC3810-VCM6=
1-port MFT with RJ-48 channelized T1 interface
MC3810-MFT-T1=
1-port MFT with RJ-48 channelized E1 interface
MC3810-MFT-E1=
1-port MFT with unbalanced E1-BNC interface
MC3810-MFT-BNC=
1-port MFT with RJ-48 channelized T1 and BRI S/T interfaces
MC3810-MFT-TBS=
1-port MFT with unbalanced E1-BNC and BRI S/T interfaces
MC3810-MFT-EUS=
1 Requires one to six APMs and one voice compression module (VCM3 or VCM6).
2 Requires one or two voice compression modules (VCM6) for processed voice.
3 Requires one voice compression module (VCM3 or VCM6) and Cisco IOS Release 12.0(4)T or a later release.
4 Requires MFT for ATM connectivity and Cisco serial V.35 DCE cable (product order number 72-1721-01) that includes a Ringing Indicator (RI) conductor, and a Cisco RS-366 ACE cable (product order number 72-1722-01) to connect the VDM to the videoconferencing equipment RS-366 dial-up DTE port.
5 For use with analog voice modules; one AVM requires at least one APM and supports up to six APMs.
6 PR2 countries currently include Australia and New Zealand.
7 PR3 countries currently include Japan and Singapore.
8 VCMs and Cisco IOS Plus feature sets are required for voice processing (for example, switching, compression, echo cancellation, and silence suppression) but not for drop-and-insert applications.
9 Cisco MC3810 maximum voice channel support by compression algorithm: G.711 at 64 kbps = 6 channels; G.726 at 32 kbps = 12 channels; G.729 at 8 kbps = 12 channels; G.729a at 8 kbps = 24 channels.
Determining the Software Version
To determine the version of Cisco IOS software running on a Cisco MC3810, log in and enter the show version EXEC command:
MC3810>#show versionCisco Internetwork Operating System SoftwareIOS (tm) MC3810 Software (mc3810-js-mz), Version 12.1(5)T, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see the product bulletin Cisco IOS Upgrade Ordering Instructions on CCO at:
Technical Documents: Product Bulletins: Software: General System Software Bulletins
Feature Set Table
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Cisco IOS Release 12.1(5)T supports the same features as Release 12.1, but Release 12.1(5)T can include new features supported by the Cisco MC3810 multiservice access concentrator.
Caution
Table 5 lists the features and feature set images supported by the Cisco MC3810 in Cisco IOS Release 12.1(5)T and uses the following conventions:
•
•
Note
Table 5, Part 1 Feature List by IP Feature Set for the Cisco MC3810
Plus
IPSec
56/No ISDN
Plus/
No
ISDN
VoIP and
VoATM
VoIP and VoATM/
IPSec 56
Plus/ IPSec 56Autoinstall Using DHCP for LAN Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CUG Selection Facility Suppress Option
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching Diagnostics and Troubleshooting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Interworking Signaling Enhancements for H.323 and SIP VoIP
No
No
No
No
Yes
Yes
No
No
NAT—Support for Netmeeting Directory (Internet Locator Service—ILS)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NTP MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Parser Cache
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP Support for Frame Relay
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC SNRM Timer and Window Size Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VIC-2BRI-NT/TE, MC3810-BVM4-NT/TE
Yes
Yes
No
No
Yes
Yes
Yes
No
VoIP Call Admission Control Using RSVP
No
No
No
No
Yes
Yes
No
No
ATM LANE FSSR Protocol
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.5) Enhancements
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.8)
No
No
No
No
No
No
No
No
Trunk Conditioning for FRF.11 and Cisco Trunks
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RFC 1483
No
No
No
No
Yes
Yes
No
Yes
rtVBR, nrtVBR, CBR, UBR
No
No
No
No
Yes
Yes
No
Yes
Structured CES1
No
No
No
No
Yes
Yes
No
Yes
Traffic Shaping
No
No
No
No
Yes
Yes
No
Yes
UNI 3.12
No
No
No
No
Yes
Yes
No
Yes
UNI 4.0 (with ILMI)
No
No
No
No
Yes
Yes
No
Yes
APPN
No
No
No
No
No
No
No
No
APPN High-Performance Routing
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
BAN for SNA Frame Relay Support
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bisync
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bridging Code Rework
No
No
No
No
No
No
No
No
Caching and Filtering
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Enhanced Load Balancing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Ethernet Redundancy
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Peer Clusters
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw (RFC 1795)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP Bandwidth Reservation
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw Version 2 (RFC 1266)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Downstream PU Concentration (DSPU)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SNA Support
(RFC 1490)No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NCIA
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NetView Native Service Point
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Polled Async
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QLLC
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Integration
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Transport (STUN)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC-to-LAN Conversion (SDLLC)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNA and NetBIOS WAN Optimization
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRB/RSRB
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRT
No
No
No
No
No
No
No
No
SRTLB
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TG/COS
No
No
No
No
No
No
No
No
TN3270
No
No
No
No
No
No
No
No
TN3270 LU Nailing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 Server Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
EGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP Optimizations
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ES-IS
No
No
No
No
No
No
No
No
GRE VPN
No
No
No
No
No
No
No
No
IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IS-IS
No
No
No
No
No
No
No
No
Named IP Access Control List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NHRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On Demand Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Not-So-Stubby-Areas (NSSA)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF On Demand Circuit (RFC 1793)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Protocol-Independent Multicast (PIM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Policy-Based Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Apollo Domain
No
No
No
No
No
No
No
No
AppleTalk Phase 2
No
No
No
No
No
No
No
No
Banyan VINES
No
No
No
No
No
No
No
No
Concurrent Routing and Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet IV
No
No
No
No
No
No
No
No
DECnet V
No
No
No
No
No
No
No
No
GRE
No
No
No
No
No
No
No
No
Integrated Routing and Bridging (IRB)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LAN Extension Host
No
No
No
No
No
No
No
No
Multiring
No
No
No
No
No
No
No
No
Novell IPX
No
No
No
No
No
No
No
No
OSI
No
No
No
No
No
No
No
No
Source-Route Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent and Translational Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VLANs (ISL & IEEE 802.10)
No
No
No
No
No
No
No
No
XNS
No
No
No
No
No
No
No
No
Event MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AutoInstall
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Automatic Modem Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI String Search
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HTTP Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter (RTR) Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RMON Events and Alarms
No
No
No
No
No
No
No
No
RMON Full
No
No
No
No
No
No
No
No
Service Assurance Agent (formerly RTR) Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco Works Voice Manager
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Request
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP version 3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application Specific Routing
No
No
No
No
No
No
No
No
Gateway Support for Alternate Gatekeeper
No
No
No
No
Yes
Yes
No
No
Generic Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Gatekeeper and Proxy
No
No
No
No
No
No
No
No
H.235 Accounting and Security Enhancements for Cisco Gateways
No
No
No
No
Yes
Yes
No
No
H.323 Version 2
No
No
No
No
Yes
Yes
No
No
H.323 Multizone Enhancements
No
No
No
No
Yes
Yes
No
No
H.323 Hot Standby Routing Protocol (HSRP)
No
No
No
No
Yes
Yes
No
No
Multicast Routing Monitor
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multimedia Conference Manager
No
No
No
No
No
No
No
No
PGM Router Assist
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Process MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Random Early Detection (RED)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AURP
No
No
No
No
No
No
No
No
IPX RIP
No
No
No
No
No
No
No
No
NLSP
No
No
No
No
No
No
No
No
RTMP
No
No
No
No
No
No
No
No
SMRP
No
No
No
No
No
No
No
No
SRTP
No
No
No
No
No
No
No
No
LAT
No
No
No
No
No
No
No
No
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
No
No
No
No
No
No
No
No
X.25
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ARAP 1.0/2.0
No
No
No
No
No
No
No
No
Asynchronous Master Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATCP
No
No
No
No
No
No
No
No
CPPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CSLIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DHCP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Pooling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX and ARAP on Virtual Async Interfaces
No
No
No
No
No
No
No
No
IPXCP
No
No
No
No
No
No
No
No
MacIP
No
No
No
No
No
No
No
No
NASI
No
No
No
No
No
No
No
No
NetBEUI over PPP
No
No
No
No
No
No
No
No
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
SLIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Airline Product Set (ALPS)
No
No
No
No
No
No
No
No
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Entity MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Expression MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Point to Multipoint
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Per Port Debugging (Conditionally Triggered Debugging)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Manager
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AAA Server Group Deadtimer
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Security
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Additional Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Authenticating ACLs
No
No
No
No
No
No
No
No
Automated Double Authentication
No
No
No
No
No
No
No
No
Certificate Authority Interoperability
No
No
No
No
No
No
No
No
Context-Based Access Control (CBAC)
No
No
No
No
No
No
No
No
Extended Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
No
Yes
No
No
Yes
Yes
No
IPSec Network Security
No
No
Yes
No
No
Yes
Yes
No
Kerberized Login
No
No
No
No
No
No
No
No
Kerberos V Client Support
No
No
No
No
No
No
No
No
Lock and Key
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Mac Security for Hubs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Md5 Routing Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS-CHAP Support
No
No
No
No
No
No
No
No
Named Method Lists for AAA Authentication & Accounting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Layer Encryption (40-bit or Export Controlled 56-bit DES)
No
No
No
No
No
No
No
No
RADIUS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Router Authentication
No
No
No
No
No
No
No
No
Sublock Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TACACS+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Time-Based Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Tunneling Endpoint Discovery
No
No
No
No
No
No
No
No
Enhanced ATM VC Configuration and Management
No
No
No
No
Yes
Yes
No
Yes
Multiple ISDN Switch Types
Yes
Yes
No
No
Yes
Yes
Yes
Yes
LAT
No
No
No
No
No
No
No
No
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
No
No
No
No
No
No
No
No
X.25 Pad
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Xremote
No
No
No
No
No
No
No
No
Trunk Conditioning for FRF.11 and Cisco Trunks
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP Support for LLQ
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PSTN Fallback
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Caller ID on 2600, 3600 and MC3810
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Analog Signaling
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM Video SVCs
No
No
No
No
No
No
No
No
ATM Voice SVCs
No
No
No
No
No
No
No
No
Call Detail Records (CDR)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial Peer Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 CAS Signaling3
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
No
No
No
No
Yes
Yes
No
Yes
Fancy Queuing on Frame Relay or Cisco HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
G.723.1
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
G.726 (ADPCM)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Gain Control
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Version 2 Phase 2 Enhancements
No
No
No
No
Yes
Yes
No
No
High-Performance Compression Module Support
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN BRI Voice Module1
No
Yes
No
No
Yes
Yes
Yes
Yes
ISDN PRI QSIG Digit Forwarding1
No
Yes
No
No
Yes
Yes
Yes
Yes
ISDN PRI QSIG Voice Signaling1
No
Yes
No
No
Yes
Yes
Yes
Yes
Local Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Local Voice Busy Out
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiflex Trunk
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multi-length Dial Patterns
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple Ring Tones
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Off-Net Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On-Net/Off-Net Call Rerouting
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OPX Ring-Through
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Pass-Through Voice
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Permanent Connection
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PLAR
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Preference-based Hunt Groups
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QSIG Protocol Support
No
Yes
No
No
Yes
Yes
Yes
Yes
Remote Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Simple Gateway Control Protocol Support on the Cisco MC3810 and Cisco 3600 Series Routers
No
No
No
No
Yes
No
No
No
T1 CAS Signaling
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent CCS
No
Yes
No
Yes
Yes
Yes
Yes
Yes
Transparent CCS and Frame Forwarding Enhancements
No
Yes
No
No
Yes
Yes
Yes
Yes
Trunk Conditioning Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Activity Detection
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Busyout Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over ATM
No
No
No
No
Yes
Yes
No
Yes
Voice over ATM with AAL2 Trunking
No
No
No
No
Yes
Yes
No
Yes
Voice over Frame Relay
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over Frame Relay Configuration Updates
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over Frame Relay Using FRF.11 and FRF.12
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over HDLC
No
No
No
No
No
No
No
No
Voice over IP
No
No
No
No
Yes
Yes
No
Yes
Voice Port Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Port Testing Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bandwidth-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Custom and Priority Queuing4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial Backup
Yes
Yes
No
No
Yes
Yes
Yes
Yes
Dial-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Header, Link and Payload Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Snapshot Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Weighted Fair Queuing4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP over ATM
No
No
No
No
Yes
Yes
No
Yes
Always On/Direct ISDN
No
No
No
No
No
No
No
No
ATM LAN Emulation: Decnet Routing and Banyan Vines Support
No
No
No
No
Yes
Yes
No
Yes
ATM LAN Emulation: (HSRP and SSRP)
No
No
No
No
Yes
Yes
No
Yes
ATM: Rate Queues for SVC per Subinterface
No
No
No
No
Yes
Yes
No
Yes
ATM UNI 3.1 Signaling
No
No
No
No
Yes
Yes
No
Yes
ATM UNI 4.0 (with ILMI)
No
No
No
No
Yes
Yes
No
Yes
Combinet Packet Protocol (CPP)
No
No
No
No
No
No
No
No
Dialer Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Facility Data Link Capabilities on Multiflex Trunk
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Compression (FRF.9)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay End-to-End Keepalive
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SVCs Support (DTE)
No
No
No
No
No
No
No
No
Frame Relay Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay UNI
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.8)
No
No
No
No
No
No
No
No
Half Bridge/Half Router for CPP and PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Integrated BRI Backup1
Yes
Yes
No
No
Yes
Yes
Yes
Yes
IPXwan 2.0
No
No
No
No
No
No
No
No
ISDN
No
No
No
No
No
No
No
No
ISDN Advise of Charge
No
No
No
No
No
No
No
No
ISDN Caller ID Callback
No
No
No
No
No
No
No
No
ISDN NFAS
No
No
No
No
No
No
No
No
Leased Line ISDN at 128 kbps
No
No
No
No
Yes
Yes
Yes
No
MPPC-MS PPP Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS Callback
No
No
No
No
No
No
No
No
Multicast Source Discovery Protocol (MSDP)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multichassis Multilink PPP (MMP)
No
No
No
No
No
No
No
No
National ISDN Switch Type
No
No
No
No
No
No
No
No
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SMDS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stackable Home Gateway
No
No
No
No
No
No
No
No
Switched 56
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Private Dialup Network (VPDN)
No
No
No
No
No
No
No
No
X.25
No
No
No
No
No
No
No
No
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Closed User Groups
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switch Local Acknowledgment
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
No
No
Yes
Yes
Yes
Yes
X.25 over Frame Relay (Annex G)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs
and SVCsYes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1 Voice signaling on CES is not available.
2 ATM PVCs only. SVCs are not supported.
3 Includes T1 CAS protocols, plus UK Standard CAS (Mercury protocol) and CEPT standard E&M.
4 Applicable to data-only interfaces.
Table 5, Part 2 Feature List by IP Feature Set for the Cisco MC3810
No ISDN
IPSec56
IPSec56/ No ISDN
VoATM,
No ISDN
3DES
VoATM,
VoIP,
3DES
VoFR,
3DES
VoFR,
No ISDN,
3DES
VoATM,
3DESAutoinstall using DHCP for LAN Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CUG Selection Facility Suppress Option
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching Diagnostics and Troubleshooting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Interworking Signaling Enhancements for H.323 and SIP VoIP
No
No
No
No
Yes
No
No
No
NAT—Support for Netmeeting Directory (Internet Locator Service—ILS)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NTP MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Parser Cache
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP Support for Frame Relay
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC SNRM Timer and Window Size Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VIC-2BRI-NT/TE, MC3810-BVM4-NT/TE
No
Yes
Yes
No
Yes
Yes
No
Yes
VoIP Call Admission Control using RSVP
No
No
No
No
Yes
No
No
No
ATM LANE FSSR Protocol
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5) Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.8)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP over ATM
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RFC 1483
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
rtVBR, nrtVBR, CBR, UBR
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Structured CES1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
UNI 3.12
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
UNI 4.0 (with ILMI)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
APPN
No
No
No
No
No
No
No
No
APPN High-Performance Routing
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
BAN for SNA Frame Relay Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bisync
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bridging Code Rework
No
No
No
No
No
No
No
No
Caching and Filtering
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Enhanced Load Balancing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Ethernet Redundancy
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Peer Clusters
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw (RFC 1795)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP Bandwidth Reservation
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw Version 2 (RFC 1266)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Downstream PU Concentration (DSPU)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SNA Support
(RFC 1490)Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NCIA
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NetView Native Service Point
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Polled Async
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QLLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Integration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Transport (STUN)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC-to-LAN Conversion (SDLLC)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNA and NetBIOS WAN Optimization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRB/RSRB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRT
No
No
No
No
No
No
No
No
SRTLB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TG/COS
No
No
No
No
No
No
No
No
TN3270
No
No
No
No
No
No
No
No
TN3270 LU Nailing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 Server Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
EGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP Optimizations
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ES-IS
No
No
No
No
No
No
No
No
GRE VPN
No
No
No
No
No
No
No
No
IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IS-IS
No
No
No
No
No
No
No
No
Named IP Access Control List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NHRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On Demand Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Not-So-Stubby-Areas (NSSA)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF On Demand Circuit (RFC 1793)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Protocol-Independent Multicast (PIM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Policy-Based Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Apollo Domain
No
No
No
No
No
No
No
No
AppleTalk Phase 2
No
No
No
No
No
No
No
No
Banyan VINES
No
No
No
No
No
No
No
No
Concurrent Routing and Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet IV
No
No
No
No
No
No
No
No
DECnet V
No
No
No
No
No
No
No
No
GRE
No
No
No
No
No
No
No
No
Integrated Routing and Bridging (IRB)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LAN Extension Host
No
No
No
No
No
No
No
No
Multiring
No
No
No
No
No
No
No
No
Novell IPX
No
No
No
No
No
No
No
No
OSI
No
No
No
No
No
No
No
No
Source-Route Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent and Translational Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VLANs (ISL & IEEE 802.10)
No
No
No
No
No
No
No
No
XNS
No
No
No
No
No
No
No
No
Event MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AutoInstall
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Automatic Modem Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI String Search
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HTTP Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter (RTR) Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RMON Events and Alarms
No
No
No
No
No
No
No
No
RMON Full
No
No
No
No
No
No
No
No
Service Assurance Agent (formerly RTR) Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco Works Voice Manager
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Request
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP version 3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application Specific Routing
No
No
No
No
No
No
No
No
Gateway Support for Alternate Gatekeeper
No
No
No
No
No
No
No
No
Generic Traffic Shaping
Yes
Yes
Yes
No
No
No
No
No
H.323 Gatekeeper and Proxy
No
No
No
No
No
No
No
No
H.235 Accounting and Security Enhancements for Cisco Gateways
No
No
No
No
No
No
No
No
H.323 Version 2
No
No
No
No
No
No
No
No
H.323 Multizone Enhancements
No
No
No
No
No
No
No
No
H.323 Hot Standby Routing Protocol (HSRP)
No
No
No
No
No
No
No
No
Multicast Routing Monitor
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multimedia Conference Manager
No
No
No
No
No
No
No
No
PGM Router Assist
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Process MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Random Early Detection (RED)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AURP
No
No
No
No
No
No
No
No
IPX RIP
No
No
No
No
No
No
No
No
NLSP
No
No
No
No
No
No
No
No
RTMP
No
No
No
No
No
No
No
No
SMRP
No
No
No
No
No
No
No
No
SRTP
No
No
No
No
No
No
No
No
LAT
No
No
No
No
No
No
No
No
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
No
No
No
No
No
No
No
No
X.25
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ARAP 1.0/2.0
No
No
No
No
No
No
No
No
Asynchronous Master Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATCP
No
No
No
No
No
No
No
No
CPPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CSLIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DHCP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Pooling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX and ARAP on Virtual Async Interfaces
No
No
No
No
No
No
No
No
IPXCP
No
No
No
No
No
No
No
No
MacIP
No
No
No
No
No
No
No
No
NASI
No
No
No
No
No
No
No
No
NetBEUI over PPP
No
No
No
No
No
No
No
No
PPP
No
No
No
No
No
No
No
No
SLIP
No
No
No
No
No
No
No
No
Airline Product Set (ALPS)
No
No
No
No
No
No
No
No
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Entity MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Expression MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Point to Multipoint
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Per Port Debugging (Conditionally Triggered Debugging)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Manager
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AAA Server Group Deadtimer
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Security
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Additional Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Authenticating ACLs
No
No
No
No
No
No
No
No
Automated Double Authentication
No
No
No
No
No
No
No
No
Certificate Authority Interoperability
No
No
No
No
No
No
No
No
Context-Based Access Control (CBAC)
No
No
No
No
No
No
No
No
Extended Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPSec Network Security
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Kerberized Login
No
No
No
No
No
No
No
No
Kerberos V Client Support
No
No
No
No
No
No
No
No
Lock and Key
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Mac Security for Hubs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Md5 Routing Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS-CHAP Support
No
No
No
No
No
No
No
No
Named Method Lists for AAA Authentication & Accounting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Layer Encryption (40-bit or Export Controlled 56-bit DES)
No
No
No
No
No
No
No
No
RADIUS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Router Authentication
No
No
No
No
No
No
No
No
Sublock Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TACACS+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Time-Based Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Tunneling Endpoint Discovery
No
No
No
No
No
No
No
No
Enhanced ATM VC Configuration and Management
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple ISDN Switch Types
No
Yes
No
No
No
No
No
No
LAT
No
No
No
No
No
No
No
No
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
No
No
No
No
No
No
No
No
X.25 Pad
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Xremote
No
No
No
No
No
No
No
No
Trunk Conditioning for FRF.11 and Cisco Trunks
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PSTN Fallback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP over ATM SVC
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Caller ID on 2600, 3600 and MC3810
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Analog Signaling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM Video SVCs
No
No
No
No
No
No
No
No
ATM Voice SVCs
No
No
No
No
No
No
No
No
Call Detail Records (CDR)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial Peer Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 CAS Signaling3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
No
Yes
No
No
Yes
No
No
Yes
Fancy Queuing on Frame Relay or Cisco HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
G.723.1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
G.726 (ADPCM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Gain Control
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Version 2 Phase 2 Enhancements
No
No
No
No
Yes
No
No
No
High-Performance Compression Module Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN BRI Voice Module1
No
Yes
No
No
Yes
Yes
No
Yes
ISDN PRI QSIG Digit Forwarding1
No
Yes
No
No
Yes
Yes
No
Yes
ISDN PRI QSIG Voice Signaling1
No
Yes
No
No
Yes
Yes
No
Yes
Local Dialing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Local Voice Busy Out
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiflex Trunk
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multi-length Dial Patterns
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple Ring Tones
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Off-Net Dialing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On-Net/Off-Net Call Rerouting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OPX Ring-Through
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Pass-Through Voice
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Permanent Connection
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PLAR
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Preference-based Hunt Groups
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QSIG Protocol Support
No
Yes
No
Yes
Yes
Yes
Yes
Yes
Remote Dialing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Simple Gateway Control Protocol Support on the Cisco MC3810 and Cisco 3600 Series Routers
No
No
No
No
Yes
No
No
No
T1 CAS Signaling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent CCS
No
Yes
No
Yes
Yes
Yes
Yes
Yes
Transparent CCS and Frame Forwarding Enhancements
No
Yes
No
No
Yes
Yes
No
Yes
Trunk Conditioning Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Activity Detection
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Busyout Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over ATM
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Voice over ATM with AAL2 Trunking
Yes
Yes
Yes
Yes
Yes
No
No
Yes
Voice over Frame Relay Configuration Updates
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over Frame Relay Using FRF.11 and FRF.12
Yes
Yes
Yes
No
No
Yes
Yes
No
Voice over HDLC
No
No
No
No
No
No
No
No
Voice over IP
No
No
No
Yes
No
No
No
No
Voice Port Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Port Testing Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bandwidth-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Custom and Priority Queuing4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Header, Link and Payload Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Snapshot Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Weighted Fair Queuing5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Always On/Direct ISDN
No
No
No
No
No
No
No
No
ATM LAN Emulation: Decnet Routing and Banyan Vines Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM LAN Emulation: (HSRP and SSRP)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM: Rate Queues for SVC per Subinterface
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM UNI 3.1 Signaling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM UNI 4.0 (with ILMI)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Combinet Packet Protocol (CPP)
No
No
No
No
No
No
No
No
Dialer Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Facility Data Link Capabilities on Multiflex Trunk
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Compression (FRF.9)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay End-to-End Keepalive
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SVCs Support (DTE)
No
No
No
No
No
No
No
No
Frame Relay Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay UNI
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.8)
No
No
No
No
No
No
No
No
Half Bridge/Half Router for CPP and PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Integrated BRI Backup1
No
Yes
No
No
Yes
Yes
No
Yes
ISDN
No
No
No
No
Yes
Yes
No
Yes
ISDN Advise of Charge
No
No
No
No
Yes
Yes
No
Yes
ISDN Caller ID Callback
No
No
No
No
Yes
Yes
No
Yes
ISDN NFAS
No
No
No
No
Yes
Yes
No
Yes
Leased Line ISDN at 128 kbps
No
Yes
No
No
Yes
Yes
No
Yes
MPPC-MS PPP Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS Callback
No
No
No
Multicast Source Discovery Protocol (MSDP)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multichassis Multilink PPP (MMP)
No
No
No
No
No
No
No
No
National ISDN Switch Type
No
No
No
No
No
No
No
No
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SMDS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stackable Home Gateway
No
No
No
Switched 56
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Private Dialup Network (VPDN)
No
No
No
No
No
No
No
No
X.25
No
No
No
No
No
No
No
No
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Closed User Groups
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switch Local Acknowledgment
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
No
Yes
No
No
Yes
Yes
No
Yes
X.25 over Frame Relay (Annex G)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs
and SVCsYes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1 Voice signaling on CES is not available.
2 ATM PVCs only. SVCs are not supported.
3 Includes T1 CAS protocols, plus UK Standard CAS (Mercury protocol) and CEPT standard E&M.
4 Applicable to data-only interfaces.
Table 6 Feature List by Enterprise Feature Set for the Cisco MC3810
prise
Plus
prise
Plus/ IP
Sec56
Plus/VoIP
and VoATM
IPSec56
prise
Plus VoATM
prise Plus VoFR, 3DES
prise Plus VoATM3DES
Plus VoATM,
VoIP, 3DESAutoinstall using DHCP for LAN Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CUG Selection Facility Suppress Option
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching Diagnostics and Troubleshooting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Interworking Signaling Enhancements for H.323 and SIP VoIP
No
No
Yes
Yes
No
No
No
Yes
Yes
NAT—Support for Netmeeting Directory (Internet Locator Service—ILS)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NTP MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Parser Cache
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP Support for Frame Relay
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC SNRM Timer and Window Size Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VIC-2BRI-NT/TE, MC3810-BVM4-NT/TE
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VoIP Call Admission Control using RSVP
No
No
Yes
Yes
No
No
No
Yes
Yes
ATM LANE FSSR Protocol
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.5) Enhancements
No
No
No
No
No
No
No
No
Frame Relay-ATM Interworking (FRF.8)
No
No
No
No
No
No
No
No
PPP Over ATM
No
No
Yes
Yes
Yes
Yes
Yes
Yes
RFC 1483
No
No
Yes
Yes
Yes
Yes
Yes
Yes
rtVBR, nrtVBR, CBR, UBR
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Structured CES1
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Traffic Shaping
No
No
Yes
Yes
Yes
Yes
Yes
Yes
UNI 3.12
No
No
Yes
Yes
Yes
Yes
Yes
Yes
UNI 4.0 (with ILMI)
No
No
Yes
Yes
Yes
Yes
Yes
Yes
APPN
No
No
No
No
No
No
No
No
APPN High-Performance Routing
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
BAN for SNA Frame Relay Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bisync
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bridging Code Rework
No
No
No
No
No
No
No
No
Caching and Filtering
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Enhanced Load Balancing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Ethernet Redundancy
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Peer Clusters
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw (RFC 1795)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP Bandwidth Reservation
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw Version 2 (RFC 1266)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Downstream PU Concentration (DSPU)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SNA Support
(RFC 1490)Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NCIA
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NetView Native Service Point
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Polled Async
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QLLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Integration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Transport (STUN)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC-to-LAN Conversion (SDLLC)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNA and NetBIOS WAN Optimization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRB/RSRB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRT
No
No
No
No
No
No
No
No
SRTLB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TG/COS
No
No
No
No
No
No
No
No
TN3270
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 LU Nailing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 Server Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
EGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP Optimizations
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ES-IS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
GRE VPN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IS-IS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Named IP Access Control List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NHRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On Demand Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Not-So-Stubby-Areas (NSSA)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF On Demand Circuit (RFC 1793)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Protocol-Independent Multicast (PIM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Policy-Based Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Apollo Domain
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Phase 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Banyan VINES
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Concurrent Routing and Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet IV
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet V
Yes
Yes
Yes
Yes
Yes
Yes
