Release Notes for Cisco uBR904
Cable Access Router for Cisco IOS Release 12.0 T

August 23, 1999

These release notes for the Cisco uBR904 cable access router support Cisco IOS Release 12.0 T, up to and including Release 12.0(5)T. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.

For a list of software caveats that apply to Release 12.0(5)T, see Caveats for Cisco IOS Release 12.0 T that accompanies these release notes. This caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

•Introduction

•System Requirements

•New and Changed Information

•Important Notes

•Caveats

•Related Documentation

•Service and Support

•Cisco Connection Online

•Documentation CD-ROM

Introduction

The Cisco uBR904 cable access router gives residential or small office/home office (SOHO) subscribers, high-speed Internet or Intranet access via a shared two-way cable system and IP backbone network. The router connects computers and other customer premise devices at a subscriber site to the service provider's hybrid/fiber coax (HFC) and IP backbone network.

The Cisco uBR904 cable access router interoperates with any bidirectional, DOCSIS-qualified Cable Modem Termination System (CMTS). The Cisco uBR904 ships from the Cisco factory with a Cisco Internetwork Operating System (IOS) software image stored in nonvolatile memory (NVRAM) that supports DOCSIS-compliant bridging data operations. The Cisco uBR904 functions as a cable modem-a modulator/demodulator at a subscriber site to convey data communications on the cable television system.

Based on the feature licenses your company purchased, you can download other Cisco IOS images from CCO. You can configure each Cisco uBR904 cable access router in your network to support special operating modes based on your cable plant's service offering and the practices in place for your network. The Cisco uBR904 can function as an advanced router, providing wide area network (WAN) data connectivity in a variety of configurations.

System Requirements

This section describes the system requirements for Release 12.0 T:

•Memory Requirements

•Headend Interoperability

•Hardware Supported

•Determining the Version of Your Software Release

•Upgrading to a New Software Release

•Feature Set Tables

Memory Requirements

Table 1 Memory Requirements for the Cisco uBR904

Feature Set
Image Name
Required
Flash
Memory
Required
DRAM
Memory
Runs
From
Feature
Status
IP Routing Standard Feature Sets

Home Office, DOCSIS Baseline Privacy, Easy IP

ubr900-k1y5-mz

4 MB Flash

8 MB DRAM

RAM

Added in Release 12.0(3)T

Telecommuter, DOCSIS Baseline Privacy, L2TP, Easy IP, IPSec 56

ubr900-k1sy556i-mz

4 MB Flash

8 MB DRAM

RAM

Encryption image added in Release 12.0(3)T

Small Office, DOCSIS Baseline Privacy, Firewall, Easy IP

ubr900-k1oy5-mz

4 MB Flash

8 MB DRAM

RAM

Added in Release 12.0(3)T

Small Office+, DOCSIS Baseline Privacy, Firewall, L2TP, Easy IP, IPSec 56

ubr900-k1osy556i-mz

4 MB Flash

8 MB DRAM

RAM

Encryption image added in Release 12.0(3)T


Headend Interoperability

To support data feature sets that involve encryption/decryption, Cisco IOS images must contain encryption/decryption software at both the CMTS and the Cisco uBR904. Both the CMTS router and the Cisco uBR904 must be enabled and configured per the software feature set. Should you have the Cisco uBR7200 series equipment, also reference applicable release notes for the corresponding images at the headend that support the feature set.

Hardware Supported

There are no new hardware features supported by the Cisco uBR904 for Cisco IOS Release 12.0 T.

Determining the Version of Your Software Release

To determine the version of Cisco IOS software running on your Cisco uBR904 cable access router, log in to the cable access router and enter the show version user EXEC command:

router>show version

Cisco Internetwork Operating System Software

IOS (tm) 904 Software (UBR900-k1y5-mz), Version 12.0(5)T...

Upgrading to a New Software Release

For information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) on CCO at:

Service & Support: Product Bulletins: Software

Under Cisco IOS 12.0, select Cisco IOS Software Release 12.0 T Upgrade (#819: 1/99).

Note   The Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification can also be found at this URL: http://www.cisco.com/warp/public/732/120/819_pp.htm. You must have an account on CCO to access this URL.

Feature Set Tables

Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.

Table 2 Feature Sets Supported by Cisco uBR904

Feature Set
Feature Set Matrix Term
Software Image
Platform

DOCSIS Baseline Privacy, Easy IP

Home Office

ubr900-k1y5-mz

Cisco uBR904

DOCSIS Baseline Privacy, L2TP, Easy IP, IPSec 56

Telecommuter/IP Sec 56

ubr900-k1sy556i-mz

Cisco uBR904

DOCSIS Baseline Privacy, Firewall, Easy IP

Small Office/Firewall

ubr900-k1oy5-mz

Cisco uBR904

DOCSIS Baseline Privacy, Firewall, L2TP, Easy IP, IPSec 56

Small Office+/Firewall/IP Sec 56

ubr900-k1osy556i-mz

Cisco uBR904


The image subset legend for Tables 1, 2 and 3 appears below:

•k1=DOCSIS baseline privacy

•s=Plus set includes L2TP

•o = Firewall

•y5=reduced IP image w/easy IP functionality

•56i=56-bit IPSec

The Cisco uBR904 cable access router IP routing capabilities conserve IP addresses by using port-level multiplexed Network Address Translation (NAT) and Port Address Translation (PAT). Dynamic Host Configuration Protocol (DHCP) is used to distribute these or real IP addresses to the devices the Cisco uBR904 supports. NAT/PAT is bundled with DHCP server into a feature referred to as "Easy IP."
A boot image supporting DOCSIS-compliant bridging or routing operations ships from the Cisco factory.
Caution
Cisco IOS images with strong encryption (including, but not limited to, 56-bit data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to Unites States government regulations. When applicable, you must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.

lists the features and feature sets supported by Cisco IOS Release 12.0 T for the Cisco uBR904 cable access router and uses the following conventions:

•Yes—The feature is supported in the feature set.

•No—The feature is not supported in the feature set.

•In—The Cisco IOS release that introduced the feature. For example, (3) means the feature was introduced in 12.0(3)T. If the cell in this column is empty, the feature was included in the initial base release.

Table 3 Feature List by Feature Set


Feature Sets

Feature
In
Home Office, DOCSIS Baseline Privacy, Easy IP
Telecommuter, DOCSIS Baseline Privacy, L2TP, Easy IP, IPSec 56
Small Office, DOCSIS Baseline Privacy, Firewall, Easy IP
Small Office+, DOCSIS Baseline Privacy, Firewall, L2TP,
Easy IP, IPSec 56

Cable Device MIB

(2)XC

Yes

Yes

Yes

Yes

Cisco Standard MIBs

(2)XC

Yes

Yes

Yes

Yes

Radio Frequency Interface (RFI) MIB

(2)XC

Yes

Yes

Yes

Yes

Full and DOCSIS-compliant Bridging

(2)XC

Yes

Yes

Yes

Yes

Routing (RIP V2)

(2)XC

Yes

Yes

Yes

Yes


New and Changed Information

The following section lists the new features supported in Cisco IOS Release 12.0 T.

No New Hardware Features In Release 12.0(5)T

There are no new hardware features supported by the Cisco uBR904 in Cisco IOS Release 12.0(5)T.

New Software Features in Release 12.0(5)T

Enhancements to Bridging Operation

Using previous Cisco IOS images, only 3 PC's can be directly connected to 3 of the 4 Ethernet hub ports at the rear of the Cisco uBR904 and operate correctly in bridging mode. The 3-node directly-connected bridge limit existed due to the MAC chip contained in the unit. The MAC chip reserved 1 filter for the Cisco uBR904's MAC address, leaving 3 available for Ethernet devices.

Cisco IOS 12.0(5)T images contain enhanced software, allowing 1 to 254 PCs to operate in bridging mode. Using Cisco IOS 12.0(5)T images, 4 PCs can be directly connected to 4 Ethernet hub ports or 1 of the 4 ports can be connected to an Ethernet hub, which then connects additional computers or devices at the site. For additional information regarding the bridging operation, see "Bridging Mode" in "Limitations and Restrictions".

No New Hardware Features In Release 12.0(4)T

There are no new hardware features supported by the Cisco uBR904 in Cisco IOS Release 12.0(4)T.

No New Software Features In Release 12.0(4)T

There are no new software features supported by the Cisco uBR904 in Cisco IOS Release 12.0(4)T.

No New Hardware Features In Release 12.0(3)T

There are no new hardware features supported by the Cisco uBR904 in Cisco IOS Release 12.0(3)T.

New Software Features In Release 12.0(3)T

Cisco IOS Firewall Feature Set (Firewall)

The Cisco IOS Firewall feature set, available for a wide range of Cisco router platforms, adds greater depth and flexibility to existing Cisco IOS software security capabilities, enriching features such as authentication, encryption, and failover with robust firewall functionality and intrusion detection. A Cisco IOS software-based, integrated firewall solution scales to meet the bandwidth and performance requirements of any network. It also maximizes a Cisco router investment by combining multiprotocol routing functionality with sophisticated security policy enforcement throughout the network.

The Cisco IOS Firewall feature set delivers cost-effective perimeter security packaged with advanced features like stateful, application-based filtering, dynamic per-user authentication and authorization, defense against network attacks, Java blocking, and real-time alerts. Because it is completely interoperable with Cisco IOS software features including NAT, VPN tunneling protocols, Cisco Express Forwarding (CEF), AAA extensions, Cisco encryption technology, and Cisco IOS IPSec, It is a complete, integrated VPN solution.

New Software Features In Release 12.0(2)XC

Cable Device MIB

The Cable Device MIB is for DOCSIS-compliant cable modems and Cable Modem Termination Systems (CMTS). The Cable Device MIB records statistics related to the configuration and status of the cable modem. Statistics include an events log and device status. The following list details the components of the Cable Device MIB:

•The docsDevBase group extends the MIB-II "system" group with objects needed for cable device system management.

•The docsDevNmAccess group provides a minimum level of SNMP access security.

•The docsDevSoftware group provides information for network downloadable software upgrades.

•The docsDevServer group provides information about the progress of interaction with various provisioning servers.

•The docsDevEvent group provides information about the progress of reporting.

•The docsDevFilter group configures filters at link layer and IP layer for bridge data traffic.

The Cable Device MIB is very similar to the RFI MIB in that both allow access to statistics; they are different in that the Cable Device MIB reports statistics on the Cisco uBR904 cable access router, and the RFI MIB reports statistics on the radio frequency transmissions over the cable television line.

Cisco Standard MIBs

The Cisco Standard MIBs consists of the following components:

•CISCO-PRODUCT-MIB

•CISCO-SYSLOG-MIB

•CISCO-FLASH-MIB

•BRIDGE-MIB

•IF-MIB

•CiscoWorks/CiscoView

Note   Cisco Management Information Base (MIB) User Quick Reference is no longer published. For the latest list of MIBs supported by Cisco, see Cisco Network Management Toolkit on CCO at: Service & Support: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB

DOCSIS Baseline Privacy

The DOCSIS Baseline Privacy feature is based on the DOCSIS Baseline Privacy Interface Specification. It provides data privacy across the HFC network by encrypting traffic flows between the Cisco uBR904 and the cable operator's CMTS.

Baseline Privacy security services are defined as a set of extended services within the DOCSIS MAC sublayer. Two new MAC management message types, BPKM-REQ and BPKM-RSP are employed to support the Baseline Privacy Key Management (BPKM) protocol.

The BPKM protocol does not use authentication mechanisms such as passwords or digital signatures; it provides basic protection of service by ensuring that a cable modem, uniquely identified by its 48-bit IEEE MAC address, can only obtain keying material for services it is authorized to access. The Cisco uBR904 is able to obtain two types of keys from the CMTS: the Traffic Exchange Key (TEK), which is used to encrypt and decrypt data packets, and the Key Exchange Key (KEK), which is used to the decrypt the TEK.

For more information on this feature, refer to the DOCSIS Baseline Privacy Interface Specification (SP-BPI-IO1-970922).

Easy IP

Dynamic Host Configuration Protocol (DHCP) Server:

With the introduction of Easy IP, Cisco IOS Release 12.0(3)T supports Intelligent DHCP Relay and DHCP Client functionality. A DHCP Relay Agent is any host that forwards DHCP packets between clients and servers. A DHCP Relay Agent enables the client and server to reside on separate subnets. If the Cisco IOS DHCP server cannot satisfy a DHCP request from its own database, it can forward the DHCP request to one or more secondary DHCP servers defined by the network administrator using standard Cisco IOS IP helper-address functionality.

Network Address Translation and Port Address Translation (NAT/PAT)

•Allows customers to maintain their own private networks while giving them full Internet access through the use of one or more global IP addresses

•Allows several private IP addresses to use the same global IP address by using address overloading

•Facilitates configuration and permits a large network of users to reach the network by using one Cisco uBR904 cable access router and the same DOCSIS cable interface IP address

•Eliminates the need to readdress all hosts with existing private network addresses (one-to-one translation) or by enabling all internal hosts to share a single registered IP address (many-to-one translation, also known as Port Address Translation [PAT])

•Enables packets to be routed correctly to and from the outside world by using the Cisco uBR904 cable access router

•Allows personal computers on the Ethernet interface to have IP addresses to be mapped to the cable interface's IP address

Routing protocols will run on the Ethernet interface instead of the cable interface, and all packets received are translated to the correct private network IP address and routed out the Ethernet interface. This eliminates the need to run RIP on the cable interface.

To implement the Cisco uBR904 cable access router, the Ethernet interface is configured with an "inside" address and the cable interface is configured with an "outside" address. The Cisco uBR904 cable access router also supports configuration of static connections, dynamic connections, and address pools.

Full and DOCSIS-Compliant Bridging

Full and DOCSIS-Compliant Bridging for the Cisco uBR904 cable access router complies with the DOCSIS standards for interoperable cable modems.

IPSec Network Security (IPSec)

IPSec Network Security (IPSec) is an IP security feature that provides robust authentications and encryption of IP packets. IPSec is a framework of open standards developed by the Internet Engineering Task Force (IETF). IPSec provides security for transmission of sensitive information over unprotected networks such as the Internet. IPSec acts at the network layer, protecting and authenticating IP packets between participating IPSec devices ("peers") such as Cisco uBR904s.

IPSec provides the following network security services:

•Privacy—IPSec can encrypt packets before transmitting them across a network.

•Integrity—IPSec authenticates packets at the destination peer to ensure that the data has not been altered during transmission.

•Authentication—Peers authenticate the source of all IPSec-protected packets.

•Anti-replay protection—Prevents capture and replay of packets; helps protect against denial-of-service attacks.

With IPSec, data can be transmitted across a public network without fear of observation, modification, or spoofing. This enables applications such as virtual private networks (VPNs) and remote user access.

IPSec services are similar to those provided by Cisco Encryption Technology, a proprietary security solution introduced in Cisco IOS Software Release 11.2. However, IPSec provides a more robust security solution, and is standards-based.

Layer 2 Tunneling Protocol (L2TP)

Layer 2 Tunneling Protocol (L2TP) is an emerging Internet Engineering Task Force (IETF) standard that combines the best features of two existing tunneling protocols: Cisco's Layer 2 Forwarding (L2F) and Microsoft's Point-to-Point Tunneling Protocol (PPTP). L2TP is an extension to the Point-to-Point Protocol (PPP), which is an important component for Access Virtual Private Networks (VPNs).

Traditional dial-up networking services only supported registered IP addresses, which limited the types of applications that could be implemented over Virtual Private Networks (VPNs). L2TP supports multiple protocols and unregistered and privately administered IP addresses over the Internet. This allows the existing access infrastructure, such as the Internet, modems, access servers, and ISDN terminal adapters (TAs), to be used.

L2TP can be initiated wherever PPTP or L2F is currently deployed and can be operated as a client initiated tunnel, such as PPTP, or a network access server (NAS) initiated tunnel, such as L2F.

Refer to the "Limitations and Restrictions" section for information regarding the functionality of the Cisco uBR904 cable access router in L2TP applications.

Radio Frequency Interface MIB

The Radio Frequency Interface (RFI) MIB module is for DOCSIS-compliant radio frequency interfaces in cable modems and CMTS. RFI MIB entries provide:

•Upstream and downstream channel characteristics.

•Class of service attributes.

•Physical signal quality of the downstream channels.

•Attributes of cable access router MAC interface.

•Status of several MAC layer counters.

The RFI MIB includes tables describing both the CMTS and the cable modem side of the cable interface. All cable modem tables are implemented.

Routing (RIP V2)

A routing configuration for the Cisco uBR904 cable access router is most likely used when the cable access router is being added to an existing personal computer network. If set to support routing mode, the Cisco uBR904 cable access router will automatically configure the headend's IP address as its IP default gateway. When the IP host-routing is being configured, this automatic configuration of the headend's IP address as its IP default gateway will allow the Cisco uBR904 cable access router to send packets not intended for the Ethernet interface to the headend.

RIP V2 routing is useful for small internetworks in that it enables optimization of NIC-assigned IP addresses by defining VLSMs for network addresses, and it allows CIDR addressing schema.

Limitations and Restrictions

This section describes warnings and cautions about using Cisco IOS Release 12.0 T software.

Bridging Mode

The Cisco uBR904 ships from the Cisco factory with the console port enabled. Based on the standard practices in place for your network, disable the console port as appropriate via the DOCSIS configuration file downloaded to the Cisco uBR904 cable access router. This prohibits network configuration access at the remote site.

Note   Downloading a Cisco IOS image disables the console port by default and erases all previously saved configurations.

For software enhancements when operating in bridging mode, see the "Enhancements to Bridging Operation" section of the New Software Features in Release 12.0(5)T.

The ability of the Cisco uBR904 to grant access to CPE devices is controlled by the "MAX CPE" field in the DOCSIS configuration file. The Cisco uBR904 defaults to one CPE MAC address unless this option is set to a higher number. The valid range using Cisco IOS Release 12.0(5)T or higher images is 1 to 254 for bridging operation; 1 filter is reserved for the broadcast address.

You can install and configure the Cisco uBR904 to operate as a router. In routing mode, no maximum upper limitation exists. For instructions to change from bridging to routing modem, see the "Important Notes" section of this document.

Caution   After you connect a laptop PC to the Cisco uBR904 console port and save configuration changes (provided your network supports remote configuration) power cycle the Cisco uBR904 if you're not using the laptop at the subscriber site. This is important when the Cisco uBR904 is configured to operate in a DOCSIS-compliant bridging mode. Power cycling the Cisco uBR904 ensures the laptop PC does not remain in the list of CPE devices at the subscriber site for the Cisco uBR904 to support. Only reinitialization of the cable interface clears out the bridge table and resets the counter that specifies the number of CPE devices being bridged.

Note   This behavior is in accordance with DOCSIS. For configurations including Cisco series 7200 CMTS equipment, enter the clear cable modem host <mac address> command to clear the laptop PC from the headend security access control tables.

Layer 2 Tunneling Protocol (L2TP)

The current implementation of L2TP in Cisco IOS Release 12.0(5)T is dependent on a PPP connection supported on one of the directly attached interfaces. A dial-up PPP connection is required in order to initiate an L2TP Tunnel connection. This is a requirement of the L2TP Access Concentrator (LAC). In Cisco IOS Release 12.0(5)T, the Cisco uBR904 cable access router cannot function as the LAC; it can only function as the L2TP Network Server (LNS), which terminates a tunnel created elsewhere in the network.

Important Notes

This section contains important information about using your Cisco IOS Release 12.0 T software.

Supplemental and Corrected Text for the Cisco uBR904 Cable Modem Installation and Configuration Guide

Data transmitted to a Cisco uBR904 cable access router from the CMTS shares a 27 or 26 Mbps, 6 MHz data channel in the 88 to 860 MHz range. The Cisco uBR904 shares an upstream data rate of up to 10 Mbps on a 200kHz-wide to 3.2 MHz-wide channel in the 5 to 42 MHz range.

Note   End-to-end throughput varies based on the design and loading of network components, the mix of traffic, the processing speed and interface of the host servers, the processing speed and local Ethernet performance of the subscriber's computer, and other parameters.

The Cisco uBR904 cable access router supports 64 or 256 Quadrature Amplitude Modulation (QAM) downstream, and Quadrature Phase Shift Keying (QPSK) or 16 QAM upstream transmission.

Table 4 Cisco uBR904 Cable Access Router Data Specifications

Description
Downstream Values
Upstream Values

Frequency Range

88 to 860 MHz

5 to 42 MHz

Modulation

64 QAM

256 QAM

QPSK

16 QAM

Data Rate

30 Mbps/64 QAM
(27 Mbit/sec after FEC overhead)

42.8 Mbps/256 QAM
(36 Mbit/sec after FEC overhead)

QPSK—320 Kbit/sec to 5 Mbit/sec


16 QAM—640 Kbit/sec to 10 Mbit/sec

Bandwidth

6 MHz

200K, 400K, 800K, 1.6M,

3.2 MHz

FEC

RS (122, 128) Trellis

Reed Solomon

One Channel

Receive level of digital signal
-15 to +15 dBmV

Note   Most field measurements are of nearby or adjacent analog signal, which is normally +6 to +10 dB (system specific) above the digital signal level

QPSK— +8 to +58 dBmV

16 QAM— +8 to +55 dBmV

Signal-to-Noise Ratio (SNR)

64 QAM:
>23.5 dB @ BER<10^8

256 QAM*:
>30 dB @ BER <10^-8
(For input level between +15 and -8 dBmV, SNR must be greater than 30 dB. For input level between -8 and -15 dBmV, SNR must be greater than 33 dB.)

Note   These performance numbers are in laboratory-controlled conditions, against statistically pure noise sources (AWGN). Since such conditions do not exist in practice, a 6 or more dB SNR margin is required for reliable operation. Check with your local system guidelines.

QPSK:
>15 dB @ BER<10^-8
(QPSK will work at 98% successful ping rate for SNR>13 dB. An SNR of 15 dB is needed to get almost optimal packets per minute transition.)


16 QAM:
>22 dB @ BER <10^-8
(For 16 QAM, an SNR>22 dB makes the grade for 98% ping efficiency. To get a good packet rate, you need SNR>25 dB).

Note   These measurements were done for 0 and -10 dBmV input to the CMTS, 1280 ksym/sec and 64 bytes packet size with a Cisco uBR904 and laboratory-controlled conditions.

Security

DES decryption: DOCSIS Baseline Privacy (BPI), 40 bit- and 56 bit-encryption, as controlled by the headend and configuration files.

Note   Cisco IOS images must contain encryption software at both the CMTS and the Cisco uBR904. Enable and configure both routers to support encryption.

DES encryption.


DOCSIS configuration files are created at the headend typically by using a configuration file editor of your choice. Using the FastStep utility at a subscriber site to locally configure the unit is not supported.

The DOCSIS configuration file defines the Cisco uBR904's operating mode, such as the provisioned downstream and upstream service assignments, including assigned frequencies, data rates, modulation schemes, Class of Service (CoS), type of services to support, and other parameters.

Note   An incorrect configuration file can cause the Cisco uBR904 to constantly cycle off-line. Such errors include: wrong downstream frequency, wrong UCD, wrong downstream Channel ID, invalid CoS, and incorrect BPI privacy configurations or shared secret strings.

The Cisco uBR904 cable access router supports the following service classes:

•The first CoS in the DOCSIS configuration file is configured as the "Tiered Best Effort Type Class" used by the Cisco uBR904 as the primary QoS for all regular data traffic. The class has no minimum upstream rate specified for the channel.

This service class assigns a primary SID for the unit. In addition to being used as a data SID, the router uses this SID for all MAC message exchanges with the CMTS. Any SNMP management traffic from the network to the Cisco uBR904 also uses this SID.

While this class is strictly "best effort," you can prioritize data traffic within this class into eight different priority levels.

Note   The CMTS system administrator, however, must define the supported upstream traffic priority levels and include the traffic priority fields in the DOCSIS configuration file downloaded to the Cisco uBR904.

•The CMTS system administrator, when creating a DOCSIS configuration file for the Cisco uBR904, can configure extra classes of service. These secondary classes of service are expected to be high QoS classes and are used by high priority traffic. These classes have a minimum upstream rate specified for the channel.

To change the operating mode of the Cisco uBR904 from its default bridging state, follow the procedure in Table 5.

To configure routing, follow these instructions when in global configuration mode. After you have completed the procedure, enter the show startup-config command to verify that routing is enabled.

Table 5 Configuring Operating Modes for the Cisco uBR904 Cable Access Router

Step
Command
Purpose

1

uBR904(config)#int c 0

Enter the interface configuration mode for the router interface.

2

uBR904(config-if)#no cable-modem compliant bridge

uBR904(config-if)#no bridge group number and remove bridge-group number.

uBR904(config-if)#ip address mask

ip address x.x.x.x (0-255)

subnet mask x.x.x.x (0-255)

uBR904(config-if)#exit

Turn off DOCSIS-compliant bridging.




Enable the IP address and subnet.

Return to the global configuration mode.

3

uBR904(config)#int e 0

uBR904(config-if)#no bridge group number and remove bridge-group number.

uBR904(config-if)#ip address mask

ip address x.x.x.x (0-255)

subnet mask x.x.x.x (0-255)

uBR904(config-if)#exit

Enter the interface configuration mode for Ethernet 0.



Enable the IP address and subnet

Return to the global configuration mode.

4

uBR904(config)#ip routing

Enable IP routing for the router.

5

uBR904(config)#router rip

uBR904(config)#version 2 rip

uBR904(config)#network

network-number

uBR904(config-if)#exit

Enter the router configuration mode and enable RIP version 2 routing.

Specify the network that is connected to the router where RIP will operate. If the router is attached to more than one network, enter each IP address in a separate command.

Return to the global configuration mode.

6

uBR904(config-if)#Ctrl-z

uBR904#copy running-config startup-config
Building configuration...

Return to the privileged EXEC mode.

Save the configuration to nonvolatile RAM, so that it will not be lost in the event of a reset, power cycle, or power outage.


To download an updated Cisco IOS image to a Cisco uBR904 installed in the field, follow the procedure in "Downloading Specific Cisco IOS Images."

Downloading Specific Cisco IOS Images

Normally, the CMTS system administrator uses the provisioning and billing system to set the software upgrade file name, the IP address of the TFTP server where the software upgrade file exists, and the MAC address of the Cisco uBR904 to upgrade in the field. Refer to the procedure that follows.

Option 128 in the DOCSIS configuration file supports a vendor-defined attribute (type = 43) that lets the system administrator define the name of a Cisco IOS image to download to a remote Cisco uBR904. This requires a unique DHCP policy for the Cisco uBR904, a unique DOCSIS configuration file to be sent by the DOCSIS process, and a unique Cisco IOS image file name—such as "ios.cfg" file—located in the same TFTP server directory supported by the DOCSIS process.

When the Cisco uBR904 initializes, Cisco IOS software processes the DOCSIS configuration file. If the software upgrade option is present in the DOCSIS configuration file and if the name of the Cisco IOS image in the DOCSIS configuration file differs from the image that is currently running on the Cisco uBR904, the router downloads the new Cisco IOS image from the TFTP server and automatically reboots.

To download an updated Cisco IOS image via a DOCSIS configuration file:

Step 1 Create a file to send to the remote Cisco uBR904 by using a configuration file editor of your choice. In that file, specify commands such as:

•hostname SUCCEED

•service linenumber

•enable password cisco

•interface ethernet 0

•load 30

•no shut

•line vty 0 4

•password cisco

•end

Step 2 Save the file by using a short name such as "ios.cf".

Step 3 Ensure that file permissions allow the file to be sent by TFTP.

Note   An easy way to do this on UNIX is to make sure the "ios.cfg" file is in /tftpboot; then enter the following command: chmod 777 ios.cfg

Step 4 Start an Internet browser, such as NetScape 4.08 and create a generic DOCSIS configuration file by using the Cisco configuration file editor of your choice. Cisco provides a number of tools to help automate this process.

Step 5 Follow the instructions provided in the specific Cisco tool. Select the starting point for your configuration file, for example, bronze.cm, silver.cm, gold.cm, platinum.cm. This populates the configuration file with default provisioning values.

Correctly populate the following two fields:

•Vendor ID (hexadecimal)—The vendor ID field is typically the first three Octets of the Cisco uBR904's MAC address as found on the label of the unit.

•Vendor Specific Information Field (dotted-decimal)—this is referred to as the VSIF field.

Note   DOCSIS configuration files work on the "TLV" basis—meaning Type, Length, Value. Use the Cisco configuration file editor tool of your choice to help automate the specification. Most Cisco tools include online help.

To download a specific Cisco IOS image to a group of Cisco uBR904s, you can define an Organizationally Unique Identifier (OUI) and use this OUI to make the Cisco uBR904s pay attention to the Vendor ID and VSIF. A global OUI can be used—"0-0-c".

(a) To install a file called "Cisco ios.cf" on ten Cisco uBR904s, (assuming a mixture of OUIs exist on those ten units such as "00-50-7b", "00-10-7d", and so on) use the configuration file editor of your choice and specify "0-0-c" in the Vendor ID field.

(b) Tell the Cisco uBR904s that they must get the file called "ios.cf" through TFTP. You do this with the VSIF field. Calculate the "dotted-decimal" equivalent of the ASCII characters: i o s . c f

Use a Sun workstation or any UNIX box and enter:
unix-workstation%man ascii

This prints out the man page. You can find the ASCII-to-decimal conversion chart needed. See the sample below:

     Decimal - Character

     |  0 NUL|  1 SOH|  2 STX|  3 ETX|  4 EOT|  5 ENQ|  6 ACK|  7 BEL|

     |  8 BS |  9 HT | 10 NL | 11 VT | 12 NP | 13 CR | 14 SO | 15 SI |

     | 16 DLE| 17 DC1| 18 DC2| 19 DC3| 20 DC4| 21 NAK| 22 SYN| 23 ETB|

     | 24 CAN| 25 EM | 26 SUB| 27 ESC| 28 FS | 29 GS | 30 RS | 31 US |

     | 32 SP | 33  ! | 34  " | 35  # | 36  $ | 37  % | 38  & | 39  ' |

     | 40  ( | 41  ) | 42  * | 43  + | 44  , | 45  - | 46  . | 47  / |

     | 48  0 | 49  1 | 50  2 | 51  3 | 52  4 | 53  5 | 54  6 | 55  7 |

     | 56  8 | 57  9 | 58  :| 59  ; | 60  < | 61  = | 62  > | 63  ? |

     | 64  @ | 65  A | 66  B | 67  C | 68  D | 69  E | 70  F | 71  G |

     | 72  H | 73  I | 74  J | 75  K | 76  L | 77  M | 78  N | 79  O |

     | 80  P | 81  Q | 82  R | 83  S | 84  T | 85  U | 86  V | 87  W |

     | 88  X | 89  Y | 90  Z | 91  [ | 92  \ | 93  ] | 94  ^ | 95  _ |

     | 96  ` | 97  a | 98  b | 99  c |100  d |101  e |102  f |103  g |

     |104  h |105  i |106  j |107  k |108  l |109  m |110  n |111  o |

     |112  p |113  q |114  r |115  s |116  t |117  u |118  v |119  w |

     |120  x |121  y |122  z |123  { |124  | |125  } |126  ~ |127 DEL|

(c) By using a similar chart as that above, convert the "ios.cf" string letter-by-letter to a decimal value. Here is what you end up with:

  i        o        s        .        c        f

 105       111     115     46      99       102

(d) Populate the VSIF field of the DOCSIS configuration file by using the editor of your choice.

Note   You cannot directly enter the decimal of "105.111.115.46.99.102" because this is only the "value" part of the TLV. What you actually enter is the sub-type of "128" then, count the length of the word you have chosen for the Cisco IOS image file name.

The "ios.cf" name is used in this example. Thus, the length is 6. Therefore, this is what you enter in the VSIF field: 128.6.105.111.115.46.99.102

(e) Save your changes by using the configuration file editor of your choice. Change the "File Name" field selected in Step 5: for example, bronze.cm, silver.cm, gold.cm, platinum.cm, to a different value such as:
/tftpboot/gold-ios-config.cm

Note   Do not save this file using the same name as the default that served as your starting point, because this will override the default selected.

(f) Once you have saved the file as "gold-ios-config.cm," then, FTP back to cs and log in. Make sure you use the binary mode of FTP and choose the file you just created.

(g) Put the file in the /tftpboot (or equivalent) directory of the TFTP server you are using for your Cisco uBR904 setup. Enter the following command to ensure you can TFTP the file:
chmod 777 gold-ios-config.cm

(h) Go into your DHCP server by using a Cisco tool such as CNR and change the value for "packet-file-name" to the new file name you just created: "gold-ios-config.cm."

(i) Once you have reloaded the CNR DHCP server or the tool you are using, enter the following command from the CMTS:

clear cable modem x.x.x.x reset

The Cisco uBR904 reregisters with the CMTS. When it gets the new DOCSIS configuration file—"gold-ios-config.cm"—it TFTPs the file "ios.cf" to itself.

The console port of the Cisco uBR904 is completely disabled.

Caution   You must telnet to the unit from the CMTS. If you do not put an enable password and line vty passwords in the ios.cf file you created, then you will not be able to access the unit.

If you entered passwords for enable and vty, you should see something similar to the example shown below when you telnet to the Cisco uBR904:

UBR7246# telnet 10.1.1.255

Trying 10.1.1.255 ... Open

SUCCEED line 1


User Access Verification

Password:

SUCCEED>en

Password:

SUCCEED#

You should see the value of the "hostname" command you put in the ios.cf file now installed on the Cisco uBR904; and all other commands.

If you enter show version on the Cisco uBR904, the Cisco uBR904 indicates a "HOST CONFIGURATION FILE" has been loaded by using TFTP in the middle of the output. Look at the last line of the example below:

System restarted by power-on at 20:23:35 - Tue Jun 15 1999

System image file is "flash:ubr900-y4-mz.113-9.NA", booted via flash

Host configuration file is "ios.cf", booted via tftp from 207.249.162.170

You have successfully loaded the Cisco IOS image and DOCSIS configuration file.

Deprecated MIBs

Older Cisco Management Information Bases (MIBs) will be replaced in a future release. OLD-CISCO-* MIBs are currently migrated into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in .

Table 6 Deprecated and Replacement MIBs

Deprecated MIB
Replacement

OLD-CISCO-APPLETALK-MIB

RFC1243-MIB

OLD-CISCO-CHASSIS-MIB

ENTITY-MIB

OLD-CISCO-CPUK-MIB

In Development

OLD-CISCO-DECNET-MIB



OLD-CISCO-ENV-MIB

CISCO-ENVMON-MIB

OLD-CISCO-FLASH-MIB

CISCO-FLASH-MIB

OLD-CISCO-INTERFACES-MIB

IF-MIB CISCO-QUEUE-MIB

OLD-CISCO-IP-MIB



OLD-CISCO-MEMORY-MIB

CISCO-MEMORY-POOL-MIB

OLD-CISCO-NOVELL-MIB

NOVELL-IPX-MIB

OLD-CISCO-SYS-MIB

(Compilation of other OLD* MIBS)

OLD-CISCO-SYSTEM-MIB

CISCO-CONFIG-COPY-MIB

OLD-CISCO-TCP-MIB

CISCO-TCP-MIB

OLD-CISCO-TS-MIB



OLD-CISCO-VINES-MIB

CISCO-VINES-MIB

OLD-CISCO-XNS-MIB



Note   The Cisco Management Information Base (MIB) User Quick Reference publication is no longer being published. For the latest list of MIBs supported by Cisco, refer to Cisco Network Management Toolkit on Cisco Connection Online (CCO). From the CCO home page, click on the following path: Service & Support: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.

Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.

For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T that accompanies these release notes.

All caveats in Release 12.0 are also in Release 12.0 T.

For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0, which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM.

Note   If you have an account with CCO, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on CCO at: Service & Support: Online Technical Support: Software Bug Toolkit or at http://www.cisco.com/support/bugtools.

Related Documentation

The following sections describe the documentation available for the Cisco uBR900 series cable access routers and related documents. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and feature modules, and other documents.

Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.

Use these release notes with these documents:

•Release-Specific Documentation

•Platform-Specific Documents

•Feature Modules

•Cisco IOS Software Documentation Set

Release-Specific Documentation

The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:

•Cross-Platform Release Notes for Cisco IOS Release 12.0

On CCO:

Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes for Cisco IOS Release 12.0

On the Documentation CD-ROM:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes for Cisco IOS Release 12.0

•Product bulletins, field notices, and other release-specific documents on CCO at:

Service & Support: Technical Documents

•Caveats for Cisco IOS Release 12.0 T

As a supplement to the caveats listed in the "Caveats" section in these release notes, see Caveats for Cisco IOS Release 12.0 T, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T.

On CCO:

Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T

On the Documentation CD-ROM:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T

Note   If you have an account with CCO, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on CCO at: Service & Support: Online Technical Support: Software Bug Toolkit or at http://www.cisco.com/support/bugtools.

Platform-Specific Documents

The following documents are available for the Cisco uBR904.

•Cisco uBR904 Cable Access Router Installation and Config. Guide

•Update to the uBR904 Cable Access Router Installation and Config. Guide

•Bridging and Routing Features for the Cisco uBR904 Cable Access Router

•Regulatory Compliance and Safety Info. for the Cisco uBR904

•Troubleshooting Tips for the Cisco uBR904 Cable Access Router

•Cisco uBR904 Cable Access Router Subscriber Setup Quick Reference Card

These documents are also available on CCO and the Documentation CD-ROM.

On CCO:

Service & Support: Documentation Home Page: Cisco Product Documentation: Broadband/Cable Solutions: Cisco uBR900 Series Cable Access Routers

On the Documentation CD-ROM:

Cisco Product Documentation: Broadband/Cable Solutions: Cisco uBR900 Series Cable Access Routers

Feature Modules

Feature modules describe new features supported by Release 12.0 T, and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.

On CCO:

Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in Release 12.0 T:

On the Documentation CD-ROM:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in Release 12.0 T

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.

On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.

On CCO:

Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Cisco IOS Interface Configuration Guide or Cisco IOS Interface Command Reference

On the Documentation CD-ROM:

Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Cisco IOS Interface Configuration Guide or Cisco IOS Interface Command Reference

Release 12.0 Documentation Set

details the contents of the Cisco IOS Release 12.0 software documentation set which is available in electronic form and also in printed form upon request.

Note   You can find the most current Cisco IOS documentation on CCO or the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the paper documents were printed.

On CCO:

Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References

On the Documentation CD-ROM:

Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References

Table 7 Cisco IOS Software Release 12.0 Documentation Set

Books
Chapter Topics
· Configuration Fundamentals Configuration Guide
· Configuration Fundamentals Command Reference

Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
System Management

· Bridging and IBM Networking Configuration Guide
· Bridging and IBM Networking Command Reference

Transparent Bridging
Source-Route Bridging
Token Ring Inter-Switch Link
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point
SNA Frame Relay Access Support
APPN
Cisco Database Connection
NCIA Client/Server Topologies
Cisco Mainframe Channel Connection
Airline Product Set

· Dial Solutions Configuration Guide
· Dial Solutions Command Reference

X.25 over ISDN
Appletalk Remote Access
Asynchronous Callback, DDR, PPP, SLIP
Bandwidth Allocation Control Protocol
ISDN Basic Rate Service
ISDN Caller ID Callback
PPP Callback for DDR
Channelized E1 & T1
Dial Backup for Dialer Profiles
Dial Backup Using Dialer Watch
Dial Backup for Serial Lines
Peer-to-Peer DDR with Dialer Profiles
DialOut
Dial-In Terminal Services
Dial-on-Demand Routing (DDR)
Dial Backup
Dial-Out Modem Pooling
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Dialup Networks
Dial Business Solutions and Examples

· Cisco IOS Interface Configuration Guide
· Cisco IOS Interface Command Reference

Interface Configuration Overview
LAN Interfaces
Logical Interfaces
Serial Interfaces

· Network Protocols Configuration Guide, Part 1
· Network Protocols Command Reference, Part 1

IP Overview
IP Addressing and Services
IP Routing Protocols

· Network Protocols Configuration Guide, Part 2
· Network Protocols Command Reference, Part 2

AppleTalk
Novell IPX

· Network Protocols Configuration Guide, Part 3
· Network Protocols Command Reference, Part 3

Network Protocols Overview
Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

· Security Configuration Guide
· Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options

· Cisco IOS Switching Services Configuration Guide
· Cisco IOS Switching Services Command Reference

Switching Services
Switching Paths for IP Networks
Virtual LAN (VLAN) Switching and Routing

· Wide-Area Networking Configuration Guide
· Wide-Area Networking Command Reference

Wide-Area Network Overview
ATM
Frame Relay
SMDS
X.25 and LAPB

· Voice, Video, and Home Applications Configuration Guide

•Voice, Video, and Home Applications Command Reference

Voice over IP
Voice over Frame Relay
Voice over ATM
Voice over HDLC
Frame Relay-ATM Internetworking
Synchronized Clocks
Video Support
Universal Broadband Features

· Quality of Service Solutions Configuration Guide
· Quality of Service Solutions Command Reference

Policy-Based Routing
QoS Policy Propagation via BGP
Committed Access Rate
Weighted Fair Queueing
Custom Queueing
Priority Queueing
Weighted Random
Early Detection
Scheduling
Signaling
RSVP
Packet Drop
Frame Relay Traffic Shaping
Link Fragmentation
RTP Header Compression

· Cisco IOS Software Command Summary
· Dial Solutions Quick Configuration Guide
· System Error Messages
