Release Notes for Cisco MC3810 for Cisco IOS Release 12.0 T
July 2, 2002
These release notes for the Cisco MC3810 multiservice access concentrator support Cisco IOS Release 12.0 T, up to and including Release 12.0(7)T. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to related documents.
For a list of software caveats that apply to Release 12.0(7)T, refer to the document Caveats for Cisco IOS Release 12.0 T that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with the cross-platform Release Notes for Cisco IOS Release 12.0 located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
As part of an enterprise backbone or as customer premises equipment (CPE) to serve provider-managed network services, the Cisco MC3810 multiservice access concentrator reduces operating costs and complexity, and increases network throughput and performance. The Cisco MC3810 is fully supported by Cisco IOS software for multiprotocol routing, bridging, and Systems Network Architecture (SNA).
To make file management easier, the Cisco MC3810 provides a complete file system for software images, message files, and reports. The standard Flash memory size is 8 MB, and a 16-MB upgrade option is available. The 16-MB version can hold two code images simultaneously for fail-safe upgrades.
Management and configuration of the Cisco MC3810 should be familiar to the Cisco IOS user and compatible with existing management systems. As such, it provides a superset of the Cisco command-line interface (CLI). The Cisco MC3810 can be managed by standard Cisco management platforms and facilities such as CiscoView and the native remote log-in facilities provided by Telnet and rlogin. Three types of configuration interfaces are provided:
•
Cisco CLI
•
•
The HTTP-based interface allows configuration from any Web browser such as Netscape Navigator or Microsoft Explorer. The SNMP MIB allows management of the Cisco MC3810 from SNMP managers (for example, HP OpenView).
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0(7)T:
•
•
Memory Requirements
Table 1 Memory Requirements for the Cisco MC3810
IP
mc3810-i-mz
4 MB1
16 MB2
RAM
IP Plus
mc3810-is-mz
8 MB
32 MB
RAM
IP/ATM Plus
mc3810-a2is-mz
8 MB
32 MB
RAM
IP Plus ATM MCM H323
mc3810-a2isx-mz
8 MB
32 MB
RAM
Enterprise Plus
mc3810-js-mz
8 MB
32 MB
RAM
Enterprise/ATM Plus
mc3810-a2js-mz
8 MB
32 MB
RAM
Enterprise Plus ATM MCM H323
mc3810-a2jsx-mz
8 MB
32 MB
RAM
1 Required flash for IP feature set; default configuration includes 8 MB.
2 Required DRAM for IP feature set; default configuration includes 32 MB.
Hardware Supported
Cisco IOS Release 12.0(7)T supports the Cisco MC3810 multiservice access concentrator. The Cisco MC3810 base chassis is a semi-fixed configuration router that can be customized for a specific application at the factory or in the field by a qualified technician. The base chassis includes the following components:
•
•
•
•
•
Cisco MC3810 series concentrators are supplied in various standard hardware configurations. These are equipped with different sets of functional modules to provide specific functional capability. Many configurations are possible, but they are all variations of the basic categories described in . Supported hardware is shown in . The chassis opening for any mounting area not equipped with a functional module is closed off with a removable cover plate.
Table 2 Cisco MC3810 Series Standard Hardware Categories
Base chassis
Base chassis services1
None
Optional modules can be added to create other chassis variations.
Analog voice chassis
Base chassis services1 plus compressed analog voice connections to telephone, fax, central office, analog PBX
AVM (analog voice module) with 1 to 6 APMs (analog personality modules)
VCM3 or VCM6 (voice compression modules
MFT2 to support a channelized T1 or E1 trunk
MFT2 and VDM3 to support video codec dialing
Digital voice chassis
Base chassis services1 plus compressed digital voice through digital PBX
DVM
VCM3 and/or VCM6
(1 or 2 VCMs)MFT2 to support a channelized T1 or E1 trunk
MFT2 and VDM to support video codec dialing
BRI voice chassis
Base chassis services1 plus compressed digital voice through PINX
BVM and MFT1
VCM3 and/or VCM6
(1 VCM required)MFT to support a channelized T1 or E1 trunk
MFT2 and VDM3 to support video codec dialing
T1/E1 trunk chassis
Base chassis services1 plus channelized T1 or E1
MFT1
DVM to support digital cross-connect voice (channel bank functionality/
drop-and-insert) through digital PBX or channel bankVDM3 to support video codec dialing
VCM3 and/or VCM6 (1 or 2 VCMs) to support voice compression
1 Base chassis services include administrative access, Ethernet, data transport, and video transport.
2 The MFT is available with or without BRI backup.
3 If a VDM is installed, an MFT is required to support ATM for the video dialing network connection.
Table 3 Hardware Supported on the Cisco MC3810 for Cisco IOS Release 12.0(7)T
6-port AVM1
MC3810-AVM6
1-port E1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-E1
1-port T1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-T1
1-port unbalanced E1 DVM, connects to PBX/channel bank/key system2
MC3810-DVM-BNC
4-port BRI voice module3
MC3810-BVM4
Supports an RS-366 Automatic Calling Equipment (ACE) interface to the DTE port of the videoconferencing equipment4
MC3810-VDM
1-port E & M analog module
MC3810-APM-EM
1-port FXS analog module
MC3810-APM-FXS
1-port FXO analog module
MC3810-APM-FXO
1-port FXO analog module, approved for the U.K.
MC3810-FXO-UK
1-port FXO analog module, approved for Germany
MC3810-FXO-GER
1-port FXO analog module, approved for PR26 countries
MC3810-FXO-PR2
1-port FXO analog module, approved for PR37 countries
MC3810-FXO-PR3
Voice Compression Modules8
3-DSP VCM, supports up to 6 channels9 of compressed voice
MC3810-VCM3
6-DSP VCM, supports up to 12 channels9 of compressed voice
MC3810-VCM6
1-port MFT with RJ-48 channelized T1 interface
MC3810-MFT-T1
1-port MFT with RJ-48 channelized E1 interface
MC3810-MFT-E1
1-port MFT with unbalanced E1-BNC interface
MC3810-MFT-BNC
1-port MFT with RJ-48 channelized T1 and BRI S/T interfaces
MC3810-MFT-TBS
1-port MFT with unbalanced E1-BNC and BRI S/T interfaces
MC3810-MFT-EUS
1 Requires one to six APMs and one voice compression module (VCM3 or VCM6).
2 Requires one or two voice compression modules (VCM6) for processed voice.
3 Requires one voice compression module (VCM3 or VCM6) and Cisco IOS Release 12.0(4)T or a later release.
4 Requires MFT for ATM connectivity and Cisco serial V.35 DCE cable (product order number 72-1721-01) that includes a Ringing Indicator (RI) conductor, and a Cisco RS-366 ACE cable (product order number 72-1722-01) to connect the VDM to the videoconferencing equipment RS-366 dial-up DTE port.
5 For use with analog voice modules; one AVM requires at least one APM and supports up to six APMs.
6 PR2 countries currently include Australia and New Zealand.
7 PR3 countries currently include Japan and Singapore.
8 VCMs and Cisco IOS Plus feature sets are required for voice processing (for example, switching, compression, echo cancellation, and silence suppression) but not for drop-and-insert applications.
9 Cisco MC3810 maximum voice channel support by compression algorithm: G.711 at 64 kbps = 6 channels; G.726 at 32 kbps = 12 channels; G.729 at 8 kbps = 12 channels; G.729a at 8 kbps = 24 channels.
Determining the Software Version
To determine the version of Cisco IOS software running on a Cisco MC3810, log in and enter the show version EXEC command:
MC3810>show versionCisco Internetwork Operating System SoftwareIOS (tm) MC3810 Software (mc3810-js-mz), Version 12.0(7)T, RELEASE SOFTWAREUpgrading to a New Software Release
For information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819 1/99) on CCO at:
Service & Support: Software Center: Cisco IOS Software: Product Bulletins: Software
Feature Set Table
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
lists the features and feature sets supported by the Cisco MC3810 in Cisco IOS Release 12.0(7)T and uses the following conventions:
•
•
•
Note
Table 5 Feature List by Feature Set for the Cisco MC3810
ATM LANE FSSR Protocol
(5)
No
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
Yes
Yes
No
Yes
Yes
Frame Relay-ATM Interworking (FRF.5) Enhancements
(7)
No
No
Yes
Yes
No
Yes
Yes
Frame Relay-ATM Interworking (FRF.8)
(7)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP Over ATM
No
No
Yes
Yes
No
Yes
Yes
RFC 1483
No
No
Yes
Yes
No
Yes
Yes
rtVBR, nrtVBR, CBR, UBR
No
No
Yes
Yes
No
Yes
Yes
Structured CES1
No
No
Yes
Yes
No
Yes
Yes
Traffic Shaping
No
No
Yes
Yes
No
Yes
Yes
UNI 3.12
No
No
Yes
Yes
No
Yes
Yes
UNI 4.0 (with ILMI)
No
No
Yes
Yes
No
Yes
Yes
APPN
No
No
No
No
No
No
No
APPN High-Performance Routing
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
BAN for SNA Frame Relay Support
No
Yes
Yes
Yes
Yes
Yes
Yes
Bisync
No
Yes
Yes
Yes
Yes
Yes
Yes
Bridging Code Rework
No
No
No
No
No
No
No
Caching and Filtering
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Enhanced Load Balancing
(3)
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Ethernet Redundancy
(5)
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Peer Clusters
(3)
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw (RFC 1795)
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP
(5)
No
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP Bandwidth Reservation
(3)
No
Yes
Yes
Yes
Yes
Yes
No
DLSw Version 2 (RFC 1266)
No
Yes
Yes
Yes
Yes
Yes
Yes
Downstream PU Concentration (DSPU)
No
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SNA Support
(RFC 1490)No
Yes
Yes
Yes
Yes
Yes
Yes
NCIA
No
Yes
Yes
Yes
Yes
Yes
Yes
NetView Native Service Point
No
Yes
Yes
Yes
Yes
Yes
Yes
Polled Async
No
Yes
Yes
Yes
Yes
Yes
Yes
QLLC
No
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter
No
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Integration
No
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Transport (STUN)
No
Yes
Yes
Yes
Yes
Yes
Yes
SDLC-to-LAN Conversion (SDLLC)
No
Yes
Yes
Yes
Yes
Yes
Yes
SNA and NetBIOS WAN Optimization
No
Yes
Yes
Yes
Yes
Yes
Yes
SRB/RSRB
No
Yes
Yes
Yes
Yes
Yes
Yes
SRT
No
No
No
No
No
No
No
SRTLB
No
Yes
Yes
Yes
Yes
Yes
Yes
TG/COS
No
No
No
No
No
No
No
TN3270
No
No
No
No
Yes
Yes
Yes
TN3270 LU Nailing
No
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 Server Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
BGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
EGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP Optimizations
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ES-IS
No
No
No
No
Yes
Yes
Yes
GRE VPN
No
No
No
No
Yes
Yes
Yes
IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IS-IS
No
No
No
No
Yes
Yes
Yes
Named IP Access Control List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NHRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On Demand Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Not-So-Stubby-Areas (NSSA)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF On Demand Circuit (RFC 1793)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Protocol-Independent Multicast (PIM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Policy-Based Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Apollo Domain
No
No
No
No
Yes
Yes
Yes
AppleTalk Phase 2
No
No
No
No
Yes
Yes
Yes
Banyan VINES
No
No
No
No
Yes
Yes
Yes
Concurrent Routing and Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet IV
No
No
No
No
Yes
Yes
Yes
DECnet V
No
No
No
No
Yes
Yes
Yes
GRE
No
No
No
No
Yes
Yes
Yes
Integrated Routing and Bridging (IRB)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LAN Extension Host
No
No
No
No
No
No
No
Multiring
No
No
No
No
No
No
No
Novell IPX
No
No
No
No
Yes
Yes
Yes
OSI
No
No
No
No
Yes
Yes
Yes
Source-Route Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent and Translational Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VLANs (ISL & IEEE 802.10)
No
No
No
No
No
No
No
XNS
No
No
No
No
Yes
Yes
Yes
AutoInstall
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Automatic Modem Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI String Search
(5)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HTTP Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter (RTR) Enhancements
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RMON Events and Alarms
No
No
No
No
No
No
No
RMON Full
No
No
No
No
No
No
No
Service Assurance Agent (formerly RTR) Enhancements
(5)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Request
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP version 3
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application Specific Routing
(3)
No
No
No
No
No
No
No
Gateway Support for Alternate Gatekeeper
(7)
No
No
No
Yes
No
No
Yes
Generic Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Gatekeeper and Proxy
(3)
No
No
No
Yes
No
No
Yes
H.235 Accounting and Security Enhancements for Cisco Gateways
(7)
No
No
No
Yes
No
No
Yes
H.323 Version 2
(5)
No
No
No
Yes
No
No
Yes
H.323 Multizone Enhancements
(7)
No
No
No
Yes
No
No
Yes
H.323 Hot Standby Routing Protocol (HSRP)
(3)
No
No
No
Yes
No
No
Yes
Multicast Routing Monitor
(5)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multimedia Conference Manager
(3)
No
No
No
Yes
No
No
Yes
PGM Router Assist
(5)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Process MIB
(3)
Yes
Yes
Yes
No
Yes
Yes
No
Random Early Detection (RED)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter Enhancements
(3)
Yes
Yes
Yes
No
Yes
Yes
No
RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AURP
No
No
No
No
Yes
Yes
Yes
IPX RIP
No
No
No
No
Yes
Yes
Yes
NLSP
No
No
No
No
Yes
Yes
Yes
RTMP
No
No
No
No
Yes
Yes
Yes
SMRP
No
No
No
No
Yes
Yes
Yes
SRTP
No
No
No
No
