Release Notes for Cisco 1400 Series for Cisco IOS Release 12.0 T
December 13, 1999
These release notes for Cisco 1400 series support Cisco IOS Release 12.0 T, up to and including Release 12.0(7)T. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(7)T, see the Caveats for Cisco IOS Release 12.0 T document that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
Obtaining Technical Assistance
System Requirements
This section describes the system requirements for Release 12.0 T:
•
•
Memory Requirements
Table 1 Memory Requirements for the Cisco 1400 Series
IP/IPX
c1400-ny-mz
4 MB
16 MB
RAM
IP/IPX Plus
c1400-nsy-mz
4 MB
16 MB
RAM
IP/IPX/FW Plus
c1400-nosy-mz
62 MB
16 MB
RAM
(3)3
IP/FW Plus IPSec 56
c1400-osy56i-mz
6 MB
16 MB
RAM
(7)
1 The number in the "In" column indicates the Cisco IOS release when the image was first introduced. For example, (7) means an image was introduced in Release 12.0(7)T. If a cell in this column is empty, the interface was included in the initial base release.
2 4 MB in Release 12.0(5)T and earlier releases.
3 This feature set was initially introduced in Release 12.0(2)T for the Cisco 1401 router only.
Hardware Supported
Cisco IOS Release 12.0 T supports the Cisco 1400 series:
•
•
For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Following are some of the key features of the Cisco 1400 series:
•
•
•
•
•
•
•
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco 1400 series, log in to the router and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 1400 Software (C1400-NY-MZ), Version 12.0(7)T, RELEASE SOFTWAREUpgrading to a New Software Release
For information on upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) on CCO at:
Technical Documents: Product Bulletins: Software
Under Cisco IOS 12.0, click Cisco IOS Software Release 12.0 T Upgrade (#819: 1/99).
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Release 12.0 T supports the same feature sets as Release 12.0, but Release 12.0 T can include new features supported by the Cisco 1400 series.
Table 2 Feature Sets Supported by the Cisco 1400 Series
IP/IPX
Basic2
c1400-ny-mz
Cisco 1400 series
IP/IPX Plus
Plus3
c1400-nsy-mz
Cisco 1400 series
IP/IPX/FW
Basic
c1400-nosy-mz
Cisco 1400 series
(3)4
IP/FW Plus IPSec 56
Plus, IPSec 565
c1400-osy56i-mz
Cisco 1400 series
(7)
1 The number in the "In" column indicates the Cisco IOS release when the image was first introduced. For example, (3) means an image was introduced in Release 12.0(3)T. If a cell in this column is empty, the interface was included in the initial base release.
2 This feature set is offered in the basic feature set.
3 This feature set is offered in the Plus feature set.
4 This feature set was initially introduced in Release 12.0(2)T for the Cisco 1401 router only.
5 This feature set is offered in the encryption feature sets, which consist of IPSec 56-bit (Plus IPSec 56) data encryption feature sets.
Caution
Table 3 lists the features and feature sets supported by the Cisco 1400 series in Cisco IOS Release 12.0 T and uses the following conventions:
•
•
Note
Table 3 Feature List by Feature Set for the Cisco 1400 Series
EIGRP
Yes
Yes
Yes
Yes
IGRP
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Virtual Private Network (VPN)
No
Yes
Yes
Yes
ATM MIB
Yes
Yes
Yes
Yes
CDP MIB
Yes
Yes
Yes
Yes
Chassis MIB
Yes
Yes
Yes
Yes
Configuration/Management MIB
Yes
Yes
Yes
Yes
Flash MIB
Yes
Yes
Yes
Yes
IP Multicast MIBs
No
Yes
Yes
Yes
Image MIB
Yes
Yes
Yes
Yes
IP MIB
Yes
Yes
Yes
Yes
IP Multicast Route MIB
No
Yes
Yes
Yes
IPX MIB
Yes
Yes
Yes
No
NLSP MIB
No
Yes
Yes
Yes
OSPF MIB
Yes
Yes
Yes
Yes
Queue MIB
Yes
Yes
Yes
Yes
Remote Monitoring
Yes
Yes
Yes
Yes
RSVP MIB
No
Yes
Yes
Yes
Round Trip Time Monitor
Yes
Yes
Yes
Yes
Transparent Bridging MIB
Yes
Yes
Yes
Yes
IP Static Route MIB
Yes
Yes
Yes
Yes
VPN MIB
No
Yes
Yes
Yes
UPD MIB
Yes
Yes
Yes
Yes
SNMP
Yes
Yes
Yes
Yes
Compression
Yes
Yes
Yes
Yes
Multicast Source Discovery Protocol3
No
No
No
No
NetFlow Policy Routing
No
Yes
Yes
Yes
Border Gateway Protocol (BGP)
No
Yes
Yes
Yes
Cisco Discovery Protocol (CDP)
Yes
Yes
Yes
Yes
ConnectionLess Network Services (CLNS)
No
Yes
Yes
Yes
DHCP Relay
Yes
Yes
Yes
Yes
DHCP Server
Yes
Yes
Yes
Yes
HTTP
Yes
Yes
Yes
Yes
IP CDP
Yes
Yes
Yes
Yes
IP Compression
Yes
Yes
Yes
Yes
IP Multicast
No
Yes
Yes
Yes
IP Multicast NAT
No
Yes
Yes
Yes
IP NAT
Yes
Yes
Yes
Yes
IP NHRP
Yes
Yes
Yes
Yes
IPX
Yes
Yes
Yes
No
IPX Compression
Yes
Yes
Yes
No
IPX EIGRP
Yes
Yes
Yes
No
IPX NHRP
No
Yes
Yes
No
IPX NLSP
No
Yes
Yes
No
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Next Hop Reservation Protocol (NHRP)
Yes
Yes
Yes
Yes
Network Time Protocol (NTP)
No
Yes
Yes
Yes
Resource Reserve Protocol (RSVP)
No
Yes
Yes
Yes
Simple Network Time Protocol (SNTP)
Yes
Yes
Yes
Yes
Serial Tunneling (STP)
Yes
Yes
Yes
Yes
Source Route Bridging (SRB)
Yes
Yes
Yes
Yes
Transparent Bridging
Yes
Yes
Yes
Yes
Access Lists
Yes
Yes
Yes
Yes
Cisco IOS Firewall: Context-Based Access Control
No
No
Yes
Yes
IPX Access Lists
Yes
Yes
Yes
No
NETBIOS Access Lists
Yes
Yes
Yes
Yes
Radius
Yes
Yes
Yes
Yes
TACACS
Yes
Yes
Yes
Yes
TACACS+
Yes
Yes
Yes
Yes
Cisco Discovery Protocol over PPP (CCP)
Yes
Yes
Yes
Yes
IPX over WAN
Yes
Yes
Yes
No
Layer 2 Forwarding (L2F)
No
Yes
Yes
Yes
Layer Tunnel Protocol (L2TP)
No
Yes
Yes
Yes
PPP over ATM
Yes
Yes
Yes
Yes
Traffic Shaping
Yes
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
Yes
Virtual Template
Yes
Yes
Yes
Yes
1 This feature set was introduced for the Cisco 1401 in Release 12.0(2)T, and for the Cisco 1400 series in Release 12.0(3)T.
2 This feature set was introduced for the Cisco 1400 series in Release 12.0(7)T.
3 This feature was introduced in Release 12.0(7)T.
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 1400 series for Release 12.0 T:
New Software Features in Release 12.0(7)T
The following new software enhancements are supported by the Cisco 1400 series for Release 12.0(7)T and later releases.
One New Feature Set
One new feature set has been created for the Cisco 1400 series in Release 12.0(7)T:
•
Multicast Source Discovery Protocol
Multicast Source Discovery Protocol (MSDP) connects multiple PIM sparse-mode (SM) domains. MSDP allows multicast sources for a group to be known to all rendezvous points (RPs) in different domains. Each PIM-SM domain uses its own RPs and need not depend on RPs in other domains. An RP runs MSDP over TCP to discover multicast sources in other domains.
An RP in a PIM-SM domain has an MSDP peering relationship with MSDP-enabled routers in another domain. The peering relationship occurs over a TCP connection, where primarily a list of sources sending to multicast groups is exchanged. The TCP connections between RPs are achieved by the underlying routing system. The receiving RP uses the source lists to establish a source path.
The purpose of this topology is to have domains discover multicast sources in other domains. If the multicast sources are of interest to a domain that has receivers, multicast data is delivered over the normal, source-tree building mechanism in PIM-SM.
MSDP is also used to announce sources sending to a group. These announcements must originate at the domain's RP.
MSDP depends heavily on (M)BGP for interdomain operation. You should run MSDP in your domain's RPs that act as sources, sending to global groups for announcement to the Internet.
New Hardware Features in Release 12.0(5)T
The following new hardware enhancements are supported by the Cisco 1400 series for Release 12.0(5)T and later releases.
Cisco 1417 Routers
The Cisco 1417 is one in a family of low-end routers providing Ethernet-based CPE devices with an ADSL link to a telco Central Office. It is designed to provide high speed WAN access over regular copper phone lines for small remote branch offices or home offices; it provides data communications services for one or more Ethernet nodes, while at the same time allowing voice communications to a telephone. The Cisco 1417 is the second of the Cisco 1400 family of CPE routers. It is based on the Cisco 1401 1E1ATM25, and incorporates the ADSL interface using an Alcatel chip set.
No New Features in Release 12.0(4)T
There are no new features supported by the Cisco 1400 series in Cisco IOS Release 12.0(4)T.
New Software Features in Release 12.0(3)T
The following new software enhancement is supported by the Cisco 1400 series for Release 12.0(3)T and later releases.
One New Feature Set
The following feature set is now available for the Cisco 1400 series in Release 12.0(3)T:
•
Note
New Software Features in Release 12.0(2)T
The following new software enhancement is supported by the Cisco 1401 router for Release 12.0(2)T and later releases.
One New Feature Set
One new feature set is now available for the Cisco 1401 router only in Release 12.0(2)T and later releases:
•
No New Features in Release 12.0(1)T
There are no new features supported by the Cisco 1400 series in Cisco IOS Release 12.0(1)T.
Important Notes
The following sections contain important notes about Cisco IOS Release 12.0 that can apply to the Cisco 1400 series.
Last Maintenance Release of Cisco IOS Release 12.0 T
Cisco IOS Release 12.0(6)T has been renamed 12.0(7)T to align this release with the 12.0(7) mainline release. The closed caveats for Release 12.0(7)T are identical to the caveats closed in the 12.0(7) mainline release. There was no change in the feature content of the renamed release—the features in 12.0(6)T are the same as 12.0(7)T. Release 12.0(7)T is the last maintenance release of the 12.0 T release train.
Customers needing closure of caveats for the 12.0 T features should migrate to the 12.1mainline release, which has the complete feature content of Release 12.0 T and will eventually reach General Deployment (GD). Release 12.0 T is a super set of the 12.0 mainline release, so all caveats closed in the 12.0 mainline are also closed in 12.0 T.
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml .
Cisco IOS Syslog Failure
Certain versions of Cisco IOS software may fail or hang when they receive invalid User Datagram Protocol (UDP) packets sent to their syslog ports (port 514). At least one commonly used Internet scanning tool generates packets that cause such problems. This fact has been published on public Internet mailing lists, which are widely read both by security professionals and by security crackers. This information should be considered in the public domain.
Attackers can cause Cisco IOS devices to repeatedly fail and reload, resulting in a completely disabled Cisco IOS device that needs to be reconfigured by its administrator. Some Cisco IOS devices have been observed to hang instead of failing when attacked. These devices do not recover until they are manually restarted by reset or power cycling. An administrator must personally visit an attacked, hung device to restart it, even if the attacker is no longer actively sending any traffic. Some devices have failed without providing stack traces; some devices may indicate that they were "restarted by power-on," even when that is not the case.
Assume that any potential attacker is likely to know that existence of this problem and the ways to exploit it. An attacker can use tools available to the public on the Internet and does not need to write any software to exploit the vulnerability. Minimal skill is required and no special equipment is required.
Despite Cisco specifically inviting such reports, Cisco has received no actual reports of malicious exploitation of this problem.
This vulnerability notice was posted on Cisco's World Wide Web site:
http://www.cisco.com/warp/public/770/iossyslog-pub.shtml
This information was also sent to the following e-mail and USENET news recipients:
•
•
•
•
•
•
•
Affected Devices and Software Versions
Vulnerable devices and software versions are specified in Table 4, Affected and Repaired Software Versions. Affected versions include Releases 11.3 AA, 11.3 DB, and all 12.0 versions (including 12.0 mainline, 12.0 S, 12.0 T, and any other regular released version whose number starts with 12.0), up to the repaired releases listed in Table 4. Cisco is correcting the problem in certain special releases and will correct it in future maintenance and interim releases. See Table 4, Affected and Repaired Software Versions for details. Cisco intends to provide fixes for all affected IOS variants.
No particular configuration is needed to make a Cisco IOS device vulnerable. It is possible to filter out attack traffic by using access lists. See the "Workarounds" section for techniques. However, except at Internet firewalls, the appropriate filters are not common in customer configurations. Carefully evaluate your configuration before assuming that any filtering you have protects you against this attack.
The most commonly used or asked-about products are listed below. If you are unsure whether your device is running Cisco IOS software, log in to the device and issue the show version command. Cisco IOS software will identify itself simply as "IOS" or "Internetwork Operating System Software". Other Cisco devices will not have the show version command, or they will identify themselves differently in their output. The most common Cisco devices that run Cisco IOS software include the following:
•
•
•
•
Affected software versions, which are relatively new, are not necessarily available on every device listed above. If you are not running Cisco IOS software, you are not affected by this problem.
The following Cisco devices are not affected:
•
•
•
•
•
•
•
•
This vulnerability has been assigned Cisco bug ID CSCdk77426.
Solution
Cisco offers free software updates to correct this vulnerability for all affected customers—regardless of their contract status. However, because this vulnerability information has been disseminated by third parties, Cisco has released this notice before updates are available for all software versions. Table 4 gives Cisco's projected fix dates.
Make sure your hardware has adequate RAM to support the new software before installing it. The amount of RAM is seldom a problem when you upgrade within a major release (say, from 11.2[11]P to 11.2[17]P), but it is often a factor when you upgrade between major releases (say, from 11.2 P to 11.3 T).
Because fixes will be available for all affected releases, this vulnerability will rarely, if ever, require an upgrade to a new major release. Cisco recommends very careful planning for any upgrade between major releases. Make certain no known bugs will prevent the new software from working properly in your environment.
Further upgrade planning assistance is available on Cisco's World Wide Web site at:
http://www.cisco.com
If you have service contracts you can obtain new software through your regular update channels (generally through Cisco's World Wide Web site). You can upgrade to any software release, but you must remain within the boundaries of the feature sets you have purchased.
If you do not have service contracts, you can upgrade to obtain only the bug fixes; free upgrades are restricted to the minimum upgrade required to resolve the defects. In general, you will be restricted to upgrading within a single row of Table 4, except when no upgrade within the same row is available in a timely manner. Obtain updates by contacting one of the following Cisco Technical Assistance Centers (TACs):
•
•
•
Give the URL of this notice (http://www.cisco.com/warp/public/770/iossyslog-pub.shtml) as evidence for a free update. Non-contract customers must request free updates through the TAC. Please do not contact either "psirt@cisco.com" or "security-alert@cisco.com" for software updates.
Workarounds
You can work around this vulnerability by preventing any affected Cisco IOS device from receiving or processing UDP datagrams addressed to its port 514. This can be done either using packet filtering on surrounding devices, or by using input access list filtering on the affected IOS device itself.
If you use an input access list, apply that list to all interfaces to which attackers may be able to send datagrams. Interfaces include—not only physical LAN and WAN interfaces—but virtual subinterfaces of those physical interfaces, as well as virtual interfaces and interface templates corresponding to GRE, L2TP, L2F, and other tunneling protocols.
The input access list must block traffic destined for UDP port 514 at any of the Cisco IOS device's own IP addresses, as well as at any broadcast or multicast addresses on which the Cisco IOS device may be listening. Be sure to block both old-style "all-zeros" broadcasts and new-style "all-ones" broadcasts. It is not necessary to block traffic being forwarded to other hosts—only traffic actually addressed to the Cisco IOS device is of interest.
No single input access list works in all configurations. Know the effect of your access list in your specific configuration before activating it.
The following example shows a possible access list for a three-interface router, along with the configuration commands needed to apply the list. The example assumes input filtering is not needed, other than as a workaround for this vulnerability:
! Deny all multicasts, and all unspecified-net broadcasts, to port 514access-list 101 deny udp any 224.0.0.0 31.255.255.255 eq 514! Deny old-style unspecified-net broadcastsaccess-list 101 deny udp any host 0.0.0.0 eq 514! Deny network-specific broadcasts. This example assumes that all of! the local interfaces are on the class B network 172.16.0.0, subnetted! everywhere with mask 255.255.255.0. This will differ from network! to network. Note that we block both new-style and old-style broadcasts.access-list 101 deny udp any 172.16.0.255 0.0.255.0 eq 514access-list 101 deny udp any 172.16.0.0 0.0.255.0 eq 514! Deny packets sent to the addresses of our own network interfaces.access-list 101 deny udp any host 172.16.1.1 eq 514access-list 101 deny udp any host 172.16.2.1 eq 514access-list 101 deny udp any host 172.16.3.3 eq 514! Permit all other traffic (default would be to deny)access-list 101 permit ip any any! Apply the access list to the input side of each interfaceinterface ethernet 0ip address 172.16.1.1 255.255.255.0ip access-group 101 ininterface ethernet 2ip address 172.16.2.1 255.255.255.0ip access-group 101 ininterface ethernet 3ip address 172.16.3.3 255.255.255.0ip access-group 101 inListing all possible addresses—especially all possible broadcast addresses—to which attack packets can be sent is complicated. If you do not need to forward any legitimate syslog traffic received on an interface, you can block all syslog traffic arriving on that interface. Remember that blocking will affect traffic routed through the Cisco IOS device as well as traffic destined to the device; if the IOS device is expected to forward syslog packets, you will have to do the detailed filtering. Because input access lists impact system performance, install them with caution—especially on systems running very near their capacity.
Software Versions and Fixes
Many Cisco software images have been or will be specially reissued to correct this vulnerability. For example, regular released version 12.0(2) is vulnerable, as are interim versions 12.0(2.1) through 12.0(2.3). The first fixed interim version of 12.0 mainline software is 12.0(2.4). However, a special release, 12.0(2a), contains only the fix for this vulnerability and does not include any other bug fixes from later 12.0 interim releases.
If you are running 12.0(2) and want to fix this problem without risking possible instability presented by installing the 12.0(2.4) interim release, you can upgrade to 12.0(2a). Release 12.0(2a) is a "code branch" from the 12.0(2) base, which will merge back into the 12.0 mainline at 12.0(2.4).
Special releases, like 12.0(2a), are one-time, spot fixes, and they will not be maintained. Thus, the upgrade path from12.0(2a) is to 12.0(3).
Table 4 specifies information about affected and repaired software versions.
Note
Table 4 Affected and Repaired Software Versions
11.2 and earlier—all variants
Unaffected early releases (no syslog server)
Unaffected
Unaffected
Unaffected
11.3, 11.3T, 11.3DA, 11.3MA, 11.3NA, 11.3WA, 11.3(2)XA
11.3 releases without syslog servers
Unaffected
Unaffected
Unaffected
11.3AA
11.3 early deployment for AS58xx
11.3(7)AA2, 8-JAN-19994
11.3(7.2)AA
11.3(8)AA, 15-FEB-1999
11.3DB
11.3 for Cisco NRP routing blade in Cisco 6400 xDSL DSLAM
11.3(7)DB2, 18-JAN-1999
12.0
12.0 Mainline
12.0(2a), 8-JAN-1999
12.0(2.4)
12.0(3), 1-FEB-1999
12.0T
12.0 new technology early deployment
12.0(2a)T1, 11-JAN-1999
12.0(2.4)T
12.0(3)T, 15-FEB-1999
12.0S
ISP support; 7200, RSP, GSR
12.0(2.3)S, 27-DEC-1998
12.0(2)S5 , 18-JAN-1999
12.0DB
12.0 for Cisco 6400 universal access concentrator node switch processor (lab use)
12.0(2)DB, 18-JAN-1999
12.0(1)W
12.0 for Catalyst 8500 and LS1010
12.0(1)W5(5a) and 12.0(1a)W5(5b) (LS1010 platform only)
12.0(1)W5(5.15)
12.0(1)W5(6) (platform support for Catalyst 8540M will be in 12.0(1)W5(7))
12.0(0.6)W5
One-time early deployment for CH-OC12 module in Catalyst 8500 series switches.
Unaffected; one-time release
Unaffected
Unaffected; general upgrade path is via 12.0(1)W5 releases.
12.0(1)XA3
Short-life release; merged to 12/0T at 12.0(2)T
Obsolete
Merged
Upgrade to 12.0(2a)T1 and/or to 12.0(3)T.
12.0(1)XB
Short-life release for Cisco 800 series; merged to 12.0 T and 12.0 (3)T
12.0(1)XB1
Merged
Upgrade to 12.0(3)T.
12.0(2)XC
Short-life release for new features in Cisco 2600, Cisco 3600, ubr7200, ubr900 series; merged to 12.0 T at 12.0(3)T.
12.0(2)XC1, 7-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(2)XD
Short-life release for ISDN voice features; merged to 12.0 T at 12.0(3)T.
12.0(2)XD1, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(1)XE
Short-life release
12.0(2)XE, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
1 A special fix is a one-time release that provides the most stable immediate upgrade path.
2 Interim releases are tested less rigorously than regular, maintenance releases; interim releases may contain serious bugs.
3 Fixed maintenance releases are on a long-term upgrade path. Other long-term upgrade paths also exist.
4 All dates in this table are estimates and are subject to change.
5 This entry is not a misprint. The 12.0(2.3)S interim release is available before the 12.0(2)S regular release in which the vulnerability is fixed.
Flash defaults to Flash:1 on Multipartition Flash
When using a multipartition flash card, the various flash partitions are referred to as "flash:1:", "flash:2:", etc. If you specify only "flash" in a multipartition flash, the parser assumes "flash:1:." For example, if you enter show flash all the parser defaults to "show flash:1: all" and only the flash information for the first partition displays. To see information for all flash partitions, enter show flash ?. This will list all of the valid partitions. Then enter show flash:xx: all on each valid partition.
Traffic Shaping
On the ATM25 interface of the Cisco 1400 series there are two types of traffic shaping: hardware-based and software-based. Hardware-based traffic shaping is provided by the ATM SAR chip and is enabled on a per-pvc basis by one of the following IOS PVC configuration commands:
ubr <peak-cell-rate>
ubr+ <peak-cell-rate> <minimum-guaranteed-cell-rate>
vbr-nrt <peak-cell-rate> <sustainable-cell-rate> <maximum-burst-size>
The SAR chip has "rate counters" that control the rate at which the current buffer up for segmentation is going to be transmitted. Ideally, the SAR chip could be programmed with values for all of the above command parameters. Unfortunately, it only has the rate counters, which specify a divisor of the basic line rate of 25 Mbps and which really sets the maximum transmission rate (peak-cell-rate) for the channel. Note that with the ubr and ubr+ commands, the rate counter for the PVC is obtained from the <peak-cell-rate> parameter. With the vbr-nrt command, the rate counter is obtained from the <sustainable-cell-rate> parameter. While the <minimum-guaranteed-cell-rate> parameter in the ubr+ command and the <peak-cell-rate> parameter in the vbr-nrt command can be specified by the user, they are ignored by the ATM25 driver.
Software-based traffic shaping is enabled on a per-interface basis via the traffic-shape interface configuration command. For performance reasons, and since for ATM interfaces you most likely want to do shaping on a per-pvc basis, the ATM driver does not support software-based traffic shaping while fastswitching. However, if fast-switching is disabled and the traffic-shape interface configuration command is enabled, then software traffic shaping will occur. (See CSCdk28377 for more information.)
Image Deferral, Cisco IOS Release 12.0(4)XI
Cisco IOS Release 12.0(4)XI was deferred to Release 12.0(4)XI1 on all software images for the Cisco 1417, uBR7200, and uBR924.
For the Cisco 1417 router, the IP/IPX/FW Plus feature set, c1400-nosy-mz, was deferred due to the firewall not working. This image is now available in Release 12.0(5)T.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 T are also in Release 12.0.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0.
For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T, which lists severity 1 and 2 caveats and is located on CCO and the Documentation CD-ROM.
Note
Related Documentation
The following sections describe the documentation available for the Cisco 1400 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Service & Support: Technical Documents
•
This document contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco 1400 series on CCO and the Documentation CD-ROM:
•
•
•
•
•
•
On CCO at:
Technical Documents: Documentation Home Page: DSL Products: Cisco 1400 Series Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: DSL Products: Cisco 1400 Series Routers
Feature Modules
Feature modules describe new features supported by Release 12.0 T and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0:Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
Table 5 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Obtaining Documentation
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly. Therefore, it is probably more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Registered Cisco.com users can order the Documentation CD-ROM and other Cisco Product documentation through our online Subscription Services at http://www.cisco.com/cgi-bin/subcat/kaojump.cgi.
Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco's corporate headquarters (California, USA) at 408 526-4000 or, in North America, call 800 553-NETS (6387).
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Warranty or maintenance contract customers can use the Technical Assistance Center. All customers can submit technical feedback on Cisco documentation using the web, e-mail, a self-addressed stamped response card included in many printed documents, or by sending mail to Cisco.
Cisco.com
Cisco continues to revolutionize how business is done on the Internet. Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com's broad range of features and services helps customers and partners to streamline business processes and improve productivity. Through Cisco.com, you will find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online support services, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users may order products, check on the status of an order and view benefits specific to their relationships with Cisco.
You can access Cisco.com in the following ways:
•
•
•
–
–
You can e-mail questions about using Cisco.com to cco-team@cisco.com.
Technical Assistance Center
The Cisco Technical Assistance Center (TAC) is available to warranty or maintenance contract customers who need technical assistance with a Cisco product that is under warranty or covered by a maintenance contract.
To display the TAC web site that includes links to technical support information and software upgrades and for requesting TAC support, use www.cisco.com/techsupport.
To contact by e-mail, use one of the following:
In North America, TAC can be reached at 800 553-2447 or 408 526-7209. For other telephone numbers and TAC e-mail addresses worldwide, consult the following web site: http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a Cisco.com log-in account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/public/technotes/tech_sw.html
This URL is subject to change without notice. If it changes, point your Web browser to Cisco.com, press Login, and click on this path: Technical Assistance Center: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate and value your comments.
Guest
