Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 12.0 T
May 8, 2001
These release notes for Cisco AS5300 universal access servers support Cisco IOS Release 12.0 T, up to and including Release 12.0(7)T. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0 T, see the Caveats for Cisco IOS Release 12.0 T document that accompanies these release notes. This caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM. For more information, refer to the "Caveats" section of this document.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
Introduction
This section contains information about the Cisco AS5300 universal access servers and Early Deployment (ED) releases for the Cisco AS5300.
Note
The AS5300/Voice Gateway is primarily supported with voice specific IOS releases, namely 12.0(2)XH and 12.0(4)XH. The first planned General Deployment (GD) release for these key Voice over IP (VoIP) features is 12.0(6)T.
The Cisco AS5300 is a versatile data communications platform that performs two functions in a single modular chassis depending on the installed feature cards and IOS images:
•
•
The remote access server is intended for Internet service providers (ISPs), telecommunications carriers, and other service providers that offer managed Internet connections, as well as medium to large sites that provide both digital and analog access to users on an enterprise network. By terminating both analog and digital calls on the same chassis simultaneously, the access server provides a clear, simple, and easy migration path from analog dial access services to digital dial access services.
The Cisco AS5300/Voice Gateway is a versatile data communications platform that provides the functions of an access server, router, and digital modem(s) in a single modular chassis. The AS5300 includes three feature card slots: one holds a T1/E1/PRI feature card, and the other two support modem feature cards or voice digital signal processor (DSP) feature cards. When equipped with modem cards, the AS5300 serves as a remote access concentrator for dial-up (modem or ISDN) Internet access. When equipped with voice feature cards and Voice IOS, the AS5300/Voice Gateway serves as a voice (VoIP) gateway. By using one slot for modems and the other for voice DSPs, the AS5300 can serve in both capacities. Modem, voice, or fax calls are routed to the appropriate cards/resources via Dialed Number Identification Service (DNIS).
For information on new features and Cisco IOS commands supported by Release 12.0(7)T, refer to the "New and Changed Information" section and the "Related Documentation" section.
System Requirements
This section describes the system requirements for Release 12.0 T and includes the following topics:
•
•
•
Memory Requirements
describes the DRAM and Flash memory requirements for the Cisco AS5300 for Release12.0(7)T.
Hardware Supported
lists the interface and modem cards supported by the Cisco AS5300 using Cisco IOS Release 12.0 T.
For detailed descriptions of new hardware features, see the "New and Changed Information" section.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco AS5300, log in to the Cisco AS5300 and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) AS5300 Software (c5300-i-mz), Version 12.0(7)T, RELEASE SOFTWAREUpgrading to a New Software Release
For information on upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 12.0, click Cisco IOS Software Release 12.0 T Upgrade (#819: 1/99).
Microcode and Modem Code Software
Microcode and modem code software images are bundled with the Cisco IOS software image—with the exception of the Channel Interface Processor (CIP) microcode. Bundling eliminates the need to store separate microcode and modem code images. When the Cisco AS5300 is powered on, the system software unpacks the modem code software bundle and loads the proper software on all the interface processor boards. lists the current versions of modem firmware and portware supported by the Cisco AS5300 for the Microcom 12-port and MICA 6-port and 12-port modem cards.
Note
To understand how Cisco IOS software uses Microcom modem code, see the section "Modem Code" in the Installing 56K 12-Port Modem Modules in Cisco AS5300 Universal Access Servers publication. To understand how Cisco IOS software uses MICA modem code, see the section "Modem Code" in the Installing 6-Port Modules and Carrier Cards in Cisco AS5300 Universal Access Servers publication.The Cisco IOS Software Upgrade Planner on CCO contains information about downloading software. To access this document from CCO, click Login on the CCO home page to access all information. From the CCO home page, go to the Service & Support area menu, click Software Center, then Cisco IOS Software or IOS Upgrade Planner.
The modem code release notes are on CCO and on the Documentation CD-ROM.
On CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers:Firmware and Portware Information
Feature Set Table
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
lists the software features and feature sets available for the Cisco AS5300 in Cisco IOS Release 12.0 T, up to and including Release 12.0(7)T. uses the following conventions:
•
•
•
Note
Table 4 Selected Features Supported by the Cisco AS5300 Feature Sets
40
3DES1
top
top Plus
prise
Plus
prise Plus 40
prise Plus IPSec 56
prise Plus IPSec 56
3DES2APPN High-Performance Routing
No
No
No
No
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
Bisync Enhancements:
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Cisco MultiPath Channel (CMPC)
No
No
No
No
No
No
No
No
No
No
No
No
DLSw+ Enhancements:
–
–
–
–
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
FRAS Enhancements:
–
–
–
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 LU Nailing
No
No
No
No
No
No
No
No
No
No
No
No
TN3270 Server Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
Token Ring LANE
No
No
No
No
No
No
No
No
No
No
No
No
Tunneling of Asynchronous Security Protocols
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Store and Forward Fax
5
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Easy IP (Phase 1)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Easy IP (Phase 2) DHCP Server
1
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
No
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TCP Enhancements:
–
–
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet Accounting
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX Named Access Lists
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX SAP-after-RIP
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NLSP Enhancements
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
NLSP Multicast Support
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Subnetwork Bandwidth Manager
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco Call History MIB Command-Line Interface
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS Internationalization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CNS Client for Cisco IOS Software
4
No
No
No
Yes
Yes
No
No
Yes
Yes
Yes
Yes
Yes
CNS client for IOS 12.05(t) (aka IPSec Policy Agent II)
5
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Process MIB
3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN MIB RFC 2127
1
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
No
OS_IFSS Featurette
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMPv2C
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMPv3
3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Requests
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Time-Based Access Lists
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VPDN MIB
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
VPDN MIB and Syslog Facility
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
No
No
No
No
No
No
No
No
No
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI String Search
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Mulitcast Routing Monitor
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BERT/TDM
3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TDM Hairpinning
4
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Automated Double Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Certificate Authority Interoperability
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
Double Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
No
No
No
No
No
No
No
Yes
Yes
HTTP Security
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
IPSec Network Security
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
IPSec with Triple-DES
2
No
No
No
No
Yes
No
No
No
No
No
No
Yes
MS-CHAP Support
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Named Method Lists for AAA Authentication and Accounting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Parse Bookmarks
1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TCP Intercept
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Vendor-Proprietary RADIUS —Additional Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLNS and DECnet Fast Switching over PPP
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
DECnet/VINES/XNS over ISL:
–
–
–
No
No
No
No
No
No
No
Yes
Yes
No
No
No
Fast-Switched Policy Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
No
No
No
No
No
No
No
No
No
Telnet Extensions for Dialout
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Templates for Protocol Translation
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
SS7/CCS7 Dial Access Solution (DAS)
3
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Large Scale Dialout
3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over IP
3
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
High-Density Voice over IP for Cisco AS5300/Voice Gateway
5
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
ATM MIB Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
PAD Enhancements
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
PAD Subaddressing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Always On/Dynamic ISDN (AO/DI)
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Async over UDP
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 R2 Country Support3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 R1 Support for only Taiwan4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Layer 2 Forwarding—Fast Switching
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
L2TP Dial-Out
5
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Leased-Line ISDN at 128 kbps
No
No
No
No
No
No
No
No
No
No
No
No
ISDN LAPB-TA
4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Microsoft Point-to-Point Compression (MPPC)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS Callback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Modem Management Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple ISDN Switch Types
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
National ISDN Switch Types for BRI and PRI Interfaces (NI2)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP over ATM
No
No
No
No
No
No
No
No
No
No
No
No
SS7
4
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Stackable Home Gateway
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Switched 56K Digital Connections
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet Extensions for Dialout
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Version 2 Support
5
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Resource Pool Manager
5
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Service Provider 1.0 Features
3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco H.323 Multizone Enhancements
7
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Configuring RADIUS for Multiple User Datagram Protocol Ports
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Debit Card Accounting and New RADIUS Attributes for IP Telephony
7
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Dynamic Multiple Encaps for Dial-in over ISDN
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Interactive Voice Response for Cisco Access
7
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Open Settlements Protocol (OSP) for IP Telephony
7
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
Resource Pool Management Server
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Resource Pool Management with Direct Remote Services
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Selecting AAA Server Groups Based on DNIS
7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over IP Q.SIG Network Transparency for Cisco AS5300
7
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
1 This image is not available in Release 12.0(1)T. It is available in Release 12.0(2)T and later 12.0 T releases.
2 This image is not available in Release 12.0(1)T. It is available in Release 12.0(2)T and later 12.0 T releases.
3 E1 R2 country support requires specific versions of Mica portware. For details, see the Mica portware release notes, which are available on CCO in the Software Center. Note that country support varies with the portware release level, and the release notes provide a list of countries.
4 E1 R1 signaling support for Taiwan requires MICA portware version 2.3.1.0.
Encryption Images Added to Cisco IOS Release 12.0(2)T and Later
lists two new Triple-DES encryption images available in Cisco IOS Release 12.0(2)T and later 12.0 T releases; they are not available in Release 12.0(1)T.
CautionCisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco AS5300 universal access servers for Release 12.0 T:
New Hardware Features in Release 12.0(7)T
The following new hardware features are supported by the Cisco AS5300 for Release 12.0(7)T:
High-Density Voice Support with DSPM-549
This release implements high-density voice support on the Cisco AS5300 by using DSPM-549 digital signal processor (DSP) modules. When equipped with Voice Feature Cards (VFCs) and voice-enabled Cisco IOS software, the AS5300/Voice Gateway supports carrier-class VoIP and FAX over IP services.
High-density voice support increases the voice capacity of a Cisco AS5300 up to 120 channels. This increase in voice support provides the voice density of up to four T1 lines (96 voice or FAX calls) or four E1 lines (120 voice or FAX calls).
A fully configured AS5300/Voice Gateway can support up to two high density (48/60 channel) voice feature cards, and therefore the system supports up to 96/120 simultaneous voice/fax calls (4T1/E1 density).
The benefits of high-density voice features include:
•
•
•
•
•
Single-Density Voice Support with DSPM-542
This feature implements voice support on the Cisco AS5300 using DSPM-542 digital signal processor (DSP) modules.
The benefits of voice features include:
•
•
•
•
•
This release supports a C542 based VCWare that provides codec and feature interoperability between earlier generation, TI-C542 based AS5300/Voice Gateways, and the latest High Density versions. This release supports parallel C542-based VCWare/DSPWare and C549-based VCWare/DSPWare. However, note that the C542-based VCWare does not increase the number of calls supported on those earlier generation voice feature cards. Increasing support to 96/120 channels requires the latest generation (C549-based, AS53-VOXD based) voice feature cards.
New Features in Release 12.0(7)T
The following new hardware features are supported by the Cisco AS5300 universal access servers for Release 12.0(7)T:
Cisco H.233 Accounting and Security Enhancements for Cisco Gateways
The Cisco H.323 gateway now supports the use of CryptoH323Tokens for authentication. The CryptoH323Token is defined in H.225 Version 2 and is used in a "password-with-hashing" security scheme described in section 10.3.3 of the H.235 specification.
A cryptoToken can be included in any RAS message and is used to authenticate the sender of the message. You can use a separate database for user ID and password verification.
With this release, Cisco H.323 gateways support three levels of authentication:
•
•
•
You can configure the level of authentication for the gateway using the Cisco IOS software command line interface.
CryptoTokens for registration requests (RRQ), unregistration request (URQ), disengage request (DRQ) and the terminating side of admission request (ARQ) messages contain information about the gateway that generated the token, including the gateway ID (which is the H.323 ID configured on the gateway) and the gateway password. CryptoTokens for the originating side ARQ messages contain information about the user that is placing the call, including the user ID and personal identification number (PIN).
Cisco H.323 Multizone Enhancements
Cisco H.323 Multizone enhancements allow a Cisco gateway to provide information to the gatekeeper with additional fields in the RAS (registration, admission, and status) messages.
Previously, the source gateway attempted to set up a call to a destination IP address as provided by the gatekeeper in an Admission Confirm (ACF) message. If the gatekeeper was unable to resolve the destination E.164 phone number to an IP address, the incoming call was terminated.
This version of the H.323 software adds support to allow a gatekeeper to provide additional destination information and modify the destinationInfo field in the ACF. The gateway will include the canMapAlias associated destination information in setting up the call to the destination gateway.
In conjunction with the canMapAlias functionality, this version includes support for the gatekeeper to indicate to the gateway that the call should be destined to a new E.164 number. The gatekeeper indicates this by sending an Admission Confirm message with an IP address of 0.0.0.0 in the destCallSignalAddress field and the new destination E.164 phone number in the destinationInfo field.
The gateway receiving such an ACF will fall back to routing the call based on this new E.164 address and performing a new lookup of the gateway's configured dial plan. This may result in the call being routed back to the PSTN or to an H.323 endpoint.
Configuring RADIUS for Multiple User Datagram Protocol Ports
In past Cisco IOS releases, RADIUS hosts were uniquely identified by their IP addresses; therefore, only one definition of a RADIUS server for each IP address was allowed. The Configuring RADIUS for Multiple UDP Ports feature expands RADIUS implementation so that RADIUS security servers are identified by their IP addresses and specific UDP port numbers. The combination of the IP address and UDP port number creates a unique identifier, allowing different ports to be individually defined as RADIUS hosts providing a specific AAA service. In other words, this unique identifier enables RADIUS requests to be sent to different UDP ports on a server at the same IP address. If two different host entries on the same RADIUS server are configured for the same service—for example, accounting—the second host entry configured acts as failover backup to the first one. Using this example, if the first host entry fails to provide accounting services, the network access server tries the second host entry configured on the same device for accounting services. (The RADIUS host entries are tried in the order that they are configured.)
The Configuring RADIUS for Multiple UDP Ports feature also applies to RADIUS server groups—server groups can now include multiple service definitions for host entries for the same server, as long as each entry has a unique identifier.
Debit Card Accounting and New RADIUS Attributes for IP Telephony
The Debit Card feature allows service providers to offer calling service with debit accounting. The Debit Card feature and RADIUS-specific enhancements also support Vendor-Specific Attributes (VSA). The Debit Card for Packet Telephony on Cisco AS5300 works in tandem with the Cisco Interactive Voice Response (IVR) feature. The IVR voice scripts have been modified to use Tool Command Language (TCL) scripts.
The feature components consist of IVR functionality in Cisco IOS software that works in connection with an integrated third-party billing system. This includes the ability to maintain per-user credit balance information through a RADIUS interface to the Cisco IOS software. When these features are implemented, the billing system and IOS software functions enable a carrier to authorize voice calls and to debit individual user accounts in real time at the edges of a voice over IP network, without requiring external service nodes.
Dynamic Multiple Encapsulations for Dial-In over ISDN
The Dynamic Multiple Encapsulations feature allows incoming calls over ISDN to be assigned an encapsulation type such as Frame Relay, PPP, and X.25 based on calling line identification (CLID) or DNIS. It also allows various encapsulation types and per-user configurations on the same ISDN B channel at different times according to the type of incoming call.
The Dynamic Multiple Encapsulations feature allows per-user configuration for each dial-in caller on any ingress ISDN B channel on which encapsulation can be run independently from other B channels on the same ISDN link. The caller is identified by CLID (caller ID) or DNIS to ensure that only incoming calls with authorization and valid user profiles are accepted. When PPP is used, authentication and profile binding can also be done by PPP name.
In addition, a large set of user profiles can be stored in dialer profiles locally or on a remote AAA server. (For large scale dial-in, storing user-specific configurations on a remote server becomes necessary for enhancing expandability and local memory efficiency.) However, whether stored locally or on a remote AAA server, the user-specific encapsulation and configuration can be applied to individual B channels dynamically and independently.
Dynamic multiple encapsulation is especially important in Europe where ISDN is relatively inexpensive and maximum use of all 30 B channels on the same ISDN link is desirable. Further, the feature removes the need to statically dedicate channels to a particular encapsulation and configuration type, and improves channel usage.
Gateway Support for Alternate Gatekeeper (CSCdp04549)
The Alternate Gatekeeper feature provides redundancy for a gatekeeper in a system where gatekeepers are used. This enhancement allows a gateway to use up to two alternate gatekeepers as a backup in the case of a primary gatekeeper failure.
A gatekeeper manages H.323 endpoints in a consistent manner, allowing them to register with the gateway and to locate another gatekeeper. The gatekeeper provides logic variables for proxies or gateways in a call path, to provide connectivity with the public switched telephone network (PSTN), to improve Quality of Service (QoS), and to enforce security policies. Multiple gatekeepers may be configured to communicate with one another, either by integrating their addressing into Domain Naming System (DNS) or using Cisco IOS configuration options.
Interactive Voice Response for Cisco Access
Cisco is building voice gateways to connect more traditional telephone networks to voice over IP (VoIP) networks. Customers who are installing VoIP networks often need a mechanism at the gateway to present a customized interface to the caller. The Interactive Voice Response (IVR) feature was first made available to customers with Cisco IOS Release 11.(3)NA2 with the Service Provider VoIP feature set. IVR, with the addition of scripts using Tool Command Language (TCL), is being introduced with Cisco IOS Release 12.0(4)XH. These TCL IVR scripts are the default scripts that must be used with the IVR application in Cisco IOS Release 12.0(4)XH and future releases.
IVR consists of simple voice prompting and digit collection to gather caller information for authenticating the user and identifying the destination. IVR provides the ability to:
•
•
•
•
Open Settlements Protocol (OSP) for IP Telephony
Internet voice telephony is often used for toll bypass by routing through an existing data network or the Internet instead of PSTN trunks. Calls of this nature require originating and terminating gateways. When the originating and terminating voice gateways are owned by two different carriers, settlement between these carriers is required. The Settlement for Packet Voice feature implements a standardized settlement protocol that can be implemented between different vendors' gateways and voice settlement servers.
The Cisco gateway-based settlement protocol interacts between carriers to create a single authentication at initialization. The authentication is the basis for the establishment of a secure communication channel between the Settlement system and the infrastructure component. This channel then allows the following three types of transactions to be handled:
•
•
•
Redundant Link Manager
Part of the Cisco SS7 Dial Access Solution (DAS), the Cisco Redundant Link Manager (RLM) provides link management over multiple IP networks, so that your Cisco SS7 DAS can tolerate a single point of failure.
By using the RLM functionality, the Q.931 signaling protocol and other proprietary protocols are transported on top of multiple redundant links between a telephony controller and the media gateways (MGWs).
A feature enhancement to RLM for this Cisco SS7 DAS release is redundancy at the link and telephony-controller level. When each RLM group has multiple telephony controllers associated with a MGW, a telephony-controller priority and a link priority are examined by the RLM client during failover, ensuring improved control handling. The RLM client is an MGW running RLM software.
The RLM client on the MGW supports both versions of RLM functionality:
•
•
After installation, the RLM client defaults to Version 2; however, you can choose a different version by using a command line interface (CLI) configuration command. Once an RLM version is selected, all RLM groups on a given MGW use the selected version's functionality.
Note
Resource Pool Management Server
Part of the Cisco SS7 Dial Access Solution (DAS), the Cisco Resource Pool Manager Server (RPMS) communicates with the RPM component of the MGWs to enable telephone companies and ISPs to count, control, bill, and manage resources centrally for wholesale and retail dial network services. RPM is configured across multiple MGW stacks using one or more external RPMS.
The Cisco RPMS provides the following:
•
•
•
•
Cisco RPMS offers three major functions:
•
•
•
Resource Pool Management with Direct Remote Services
Cisco Resource Pool Manager (RPM) enables telephone companies and ISPs to share dial resources for wholesale and retail dial network services in a single network access server (NAS) or across multiple NAS stacks. With Cisco RPM, service providers can count, control, and manage dial resources and provide accounting for shared resources when implementing different service-level agreements.
Cisco RPM can be configured in one or more standalone Cisco NASs, or, optionally, across multiple NAS stacks by using one or more external Cisco Resource Pool Manager Servers (RPMSs).
The Cisco RPM is ideal for combining retail and wholesale dial services using Cisco AS5200, AS5300, and AS5800 network access servers. Call management and call discrimination can be configured to occur before the call is answered. Dial customers are differentiated by the use of configurable customer profiles that are based on the Dialed Number Information Service (DNIS) and the call type determined at the time of an incoming call. When a call arrives at the NAS, the DNIS and call type are matched against a table of disallowed calls. If the DNIS and call type match an entry in this table, the call is rejected. Call discrimination can be used to manage the billing of calls to different types of resources.
When management by virtual private dialup network (VPDN) is configured, a VPDN group includes the information needed to set up or reject a VPDN session. VPDN setup can be based on the DNIS received during call setup, or on the domain name after the call is answered. Load balancing is used to achieve full usage of VPDN tunnels. The VPDN group can also serve as the "customer profile" when all calls are answered and sessions are identified and limited by domain name instead of DNIS.
To support data over voice bearer service (DoVBS), service providers use DNIS to direct calls to the appropriate resource. When a digital call arrives at the NAS through the voice network, it terminates on a High-Level Data Link Control (HDLC) controller rather than on a modem.
Direct remote services is an enhancement to Cisco resource pool management (RPM) implemented in Cisco IOS Release 12.0(7)T that enables service providers to implement wholesale dial services without using VPDN tunnels. A customer profile that has been preconfigured with a PPP template to define the unique PPP services for the wholesale dial customer is selected by the incoming DNIS and call type. At the same time, the DNIS is used to select AAA server groups for authentication/authorization and for accounting for the customer.
Selecting AAA Server Groups Based on DNIS
In past Cisco IOS releases, authentication and accounting services (otherwise referred to as AAA services) have been implemented in one of the following methods:
•
•
•
With Cisco IOS Release 12.0(7)T, you can now select an AAA server group to which authentication and accounting requests will be sent by using DNIS. With this new Selecting AAA Server Groups Based on DNIS feature, you can specify the same server group for AAA services or a separate server group for each AAA service. You can now configure authentication and accounting on different physical devices and provide failover backup support.
This feature obsoletes the previous Cisco IOS Release 12.0(2)T AAA DNIS Map feature.
SPE and Firmware Download Enhancements
The spe configuration command enables you to download firmware into your modems. When the access server is booted, the spe command controls the location from where the firmware image is downloaded to the service processing element (SPE). An SPE unit is defined as the smallest software downloadable unit. For Microcom, an SPE is an individual modem; for MICA an SPE is either 6 or 12 modems, depending on whether the MICA module is single or double density.
TCLWare
The Debit Card for Packet Telephony on Cisco Access Platforms feature requires the use of both Audio Files and TCL Scripts. Unzip and download the files to your TFTP server.
In addition, download the audio files and TCL scripts from the Access Products Service and Support site on CCO at the following "TCLWare" location:
http://www.cisco.com/kobayashi/sw-center/sw-access.shtml
Voice over IP Q.SIG Network Transparency for Cisco AS5300
QSIG Private Network Transparency provides the Cisco AS5300 the capability to relay QSIG messages transparently across H.323 VoIP networks for inter-PBX/KTS signaling. The feature also provides the ability for internetworking between non-QSIG signaling (for example, E&M, R2, Q.931) and QSIG signaling for basic calls.
QSIG Transparency provides support for ISDN supplementary features such as call waiting and caller identification delivery. The feature supports ISDN supplementary services defined ECMA-141, QSIG Data Link Layer and Standard-142, and QSIG Basic Call Control by providing network feature transparency.
New Features in Release 12.0(5)T
The following new hardware features are supported by the Cisco AS5300 universal access servers for Release 12.0(5)T:
Asynchronous Serial Traffic over UDP
The Asynchronous Serial Traffic over UDP feature provides the ability to encapsulate asynchronous data into UDP packets, and then unreliably send this data without needing to establish a connection with a receiving device.
You load the data you want to send through an asynchronous port, and then send it, optionally, as a multicast or a broadcast. The receiving device(s) can then receive the data whenever it wants. If the receiver ends reception, the transmission is unaffected.
This process is referred to as UDP Telnet (UDPTN), although it does not (and cannot) use the Telnet protocol. UDPTN is similar to Telnet in that both are used to send data, but UDPTN is unique in that it does not require that a connection be established with a receiving device.
Cisco Resource Pool Manager
The Cisco Resource Pool Manager (RPM) feature enables telephone companies and Internet service providers (ISPs) to share dial resources for wholesale and retail dial network services. With RPM, telcos and ISPs can count, control, and manage dial resources and provide accounting for shared resources when implementing different service-level agreements. Resource pool management can be configured in a single, standalone Cisco network access server using RPM or, optionally, across multiple network access server stacks using one or more external Cisco Resource Pool Manager Servers.
Cisco Store and Forward Fax
Cisco Store and Forward Fax enables Cisco AS5300 access servers to transmit and receive faxes across packet-based networks. This feature is an implementation of the RFC 2305 proposed standard from the Internet Engineering Task Force (IETF), which is the same as the T.37 recommendation from the International Telegraph Union (ITU). With this feature, your access server becomes a multiservice platform, supplying both data and fax communication. With Store and Forward Fax, you can:
•
•
•
Store and Forward Fax functionality is facilitated through Simple Mail Transfer Protocol (SMTP). Additional functionality is provided in this product to provide confirmed delivery using existing SMTP mechanisms (such as Extended Simple Mail Transfer Protocol (ESMTP)) for those features.
CNS Client for Cisco IOS Software
Cisco Networking Services (CNS) Client feature for Cisco IOS software enables authenticated directory access. CNS Client for Cisco IOS software includes the following components:
•
•
•
•
•
•
•
LDAP V.3 client functionality enables Cisco IOS software-based applications to securely authenticate to a CNS for Active Directory (CNS/AD) server using Kerberos V.5 as security protocol to retrieve or store information such as policy and configuration data. Cisco IOS software-based applications publish or subscribe to events using CNS event services client, enabling external applications using the application programming interface (API) features of CNS to receive events or publish events to the Cisco IOS device. This Cisco IOS software-based device will use CNS locator services client to locate the nearest directory server using Domain Name System. The administrator need not configure the device to locate the nearest directory server.
All the above-mentioned functionality is intended for use by internal Cisco IOS application developers. CNS IPSec VPN provisioning agent enables the router to retrieve IPSec policies stored in the CNS/AD server and configure itself, automating the provisioning of customer premises equipment devices for IPSec VPN. CNS provisioning agent enables Cisco IOS device to be provisioned using CNS event services.
H.323 Version 2 Support
The H.323 Version 2 Support feature upgrades Cisco IOS software to comply with the mandatory requirements in the version 2 specification. This upgrade enhances the existing Voice over IP (VoIP) GateWay, the Multimedia Conference Manager (GateKeeper and Proxy), and the DTMF digital relay using H.245.
DTMF is the tone generated on a touch-tone phone when you press keypad digits. The tones are compressed into a single stream at one end of a call and decompressed at the other end by using H.245 messages. However, this compression and decompression can lead to distortion, depending upon the codec used. Thus, the DTMF-relay is used to configure one of three methods to transport DTMF tones generated after the call is established out-of-band. The three methods are:
•
•
•
H.323 Version 2 defines a lightweight registration procedure that requires full registration for initial registration, but uses an abbreviated renewal procedure to update the gatekeeper and minimize overhead. Lightweight registration requires each endpoint to specify a Time To Live (TTL) value in its Registration Request (RRQ) message.
The H.323 Version 2 gateway supports the registration of fully qualified E.164 numbers with the GateKeeper for phones connected directly to the gateway. Tunneling through H.225 User-to-User Information Element (UUIE) facilitates transparent handling of supplementary services between two endpoints through a VoIP network. This tunneling eliminates the need to interpret various supplementary signalling messages in the VoIP gateways.
H.323 Version 2 GateKeeper selects a destination gateway by choosing from among all gateways registered in a zone by allowing you to assign selection priorities to these gateways based on the dialed prefix. Gateway resource reporting allows the gateway to notify the gatekeeper when H.323 resources are getting low. The gatekeeper uses this information to determine which gateway it will use to complete a call. The gatekeeper maintains a separate gateway list, ordered by priority, for each of its zone-prefixes.
High-Density Voice over IP Support for the Cisco AS5300 Gateway
The High-Density Voice over IP Support for the Cisco AS5300 Gateway feature implements high-density voice support on the Cisco AS5300 by using DSPM-549 digital signal processor modules. When equipped with Voice Feature Cards and voice-enabled Cisco IOS software, the AS5300/Voice Gateway supports carrier-class VoIP and fax over IP services.
High-density voice support increases the voice capacity of a Cisco AS5300 up to 120 channels. This increase in voice support provides the voice density of up to four T1 lines (96 voice or fax calls) or four E1 lines (120 voice or fax calls).
A fully configured voice-capable Cisco AS5300 router includes two voice carrier cards, each capable of supporting 60 concurrent sessions.
Layer 2 Tunneling Protocol Dial-out
The Layer 2 Tunneling Protocol (L2TP) Dial-Out feature enables L2TP Network Servers (LNSs) to tunnel dial-out VPDN calls using L2TP as the tunneling protocol. This feature enables a centralized network to efficiently and inexpensively establish a virtual point-to-point connection with any number of remote offices.
Using the L2TP Dial-Out feature, Cisco routers can carry both dial-in and dial-out calls in the same L2TP tunnels.
Previously, only dial-in VPDN calls were supported.
L2TP dial-out involves two devices: an LNS and an L2TP Access Concentrator (LAC). When the LNS wants to perform L2TP dial-out, it negotiates an L2TP tunnel with the LAC. The LAC then places a PPP call to the client(s) the LNS wants to dial-out to.
Service Assurance Agent
The Service Assurance (SA) Agent is both an enhancement to and a new name for the Response Time Reporter (RTR) feature that was introduced in Cisco IOS Release 11.2. The feature allows you to monitor network performance by measuring key Service Level Agreement metrics such as response time, network resources, availability, jitter, connect time, packet loss, and application performance.
With Cisco IOS Release 12.0(5)T, the SA Agent provides new capabilities that enable you to:
•
•
•
Subnetwork Bandwidth Manager
Resource Reservation Protocol (RSVP) is a signalling mechanism that supports request of specific levels of service such as reserved bandwidth from the network. RSVP and its service class definitions are largely independent of the underlying network technologies. This independence requires that a user define the mapping of RSVP onto subnetwork technologies.
The Subnetwork Bandwidth Manager (SBM) feature answers this requirement for RSVP in relation to IEEE 802-based networks. SBM specifies a signalling method and protocol for LAN-based admission control for RSVP flows. SBM allows RSVP-enabled routers and Layer 2 and Layer 3 devices to support reservation of LAN resources for RSVP-enabled data flows. The SBM signalling method is similar to that of RSVP itself. SBM protocol entities have the following features:
•
•
•
Voice over IP Enhancements for the Cisco AS5300/Gateway
The Voice over IP Enhancements for the Cisco AS5300/Gateway feature implements voice support on the Cisco AS5300 using DSPM-542 digital signal processor modules.
New Software Features in Release 12.0(4)T
The following new software features are supported by the Cisco AS5300 in Cisco IOS Release 12.0(4)T:
ISDN LAPB-TA
To carry asynchronous traffic over ISDN, you need a terminal adapter to convert that traffic and forward it over synchronous connections. This is normally implemented by the V.120 protocol, which carries asynchronous traffic over ISDN. However, several countries in Europe (Germany, Switzerland, and some Eastern European countries) use Link Access Procedure, Balanced (LAPB) as the protocol to forward their asynchronous traffic over synchronous connections.
The Cisco AS5300 access server therefore needs to be able to recognize and accept calls from these asynchronous/synchronous conversion devices. The Link Access Procedure, Balanced-Terminal Adapter (LAPB-TA) feature makes this possible. (LAPB is sometimes referred to as "X.75," because LAPB is the link layer specified in the ITU-T X.75 recommendation for carrying asynchronous traffic over ISDN.)
ISDN LAPB-TA allows a user with an ISDN terminal adapter that supports asynchronous traffic over LAPB to call into the router and establish an asynchronous Point-to-Point Protocol (PPP) session. LAPB supports both local Challenge Handshake Authentication Protocol (CHAP) authentication and external RADIUS authorization on the authentication, authorization, and accounting (AAA) server.
Dynamic Multiple Encapsulations for Dial-In over ISDN
This feature allows incoming calls over Integrated Services Digital Network (ISDN) to be assigned an encapsulation type such as PPP, X.25, and ISDN LAPB-TA based on calling line identification (CLID) or Dialed Number Identification Service (DNIS). It also allows various encapsulation types as well as per-user configurations on the same ISDN B channel at different times according to the type of incoming call.
The Dynamic Multiple Encapsulations feature allows per-user configuration for each dial-in caller on any ingress ISDN B channel on which encapsulation can be run independently from other B channels on the same ISDN link. The caller is identified by CLID or DNIS to make sure that only incoming calls with authorization and valid user profiles are accepted. If the protocol is PPP, authentication and profile binding can also be done by PPP name.
Dynamic multiple encapsulations are especially important in Europe where ISDN is relatively inexpensive and where it is desirable to allow maximum use of all B channels on the same ISDN link, especially for large scale dial-in. This feature removes the need to statically dedicate channels to a particular encapsulation and configuration type, and improves channel usage.
In addition to enhancing large scale dial-in functionality, dynamic multiple encapsulations also work well in smaller scale dial-in situations and for modem calls.
Time-Division Multiplex Hairpinning
Time-division multiplex (TDM) hairpinning is supported for voice calls on the Cisco AS5300. TDM hairpinning is the connection of an incoming and an outgoing voice call on the same Cisco AS5300 via the TDM bus. The current hairpinning functionality requires converting calls to and from packet form with a pair of digital signal processors (DSPs).
The advantages of TDM hairpinning over conventional DSP-based hairpinning are:
•
•
•
This new capability is transparent to users because the TDM code handles the hairpinning process. As a result of this internal processing, there are no new or changed CLI commands.
New Features in Release 12.0(3)T
The following new features are supported by the Cisco AS5300 in Cisco IOS Release12.0(3)T. To locate the online documentation about these features, refer to the "Platform-Specific Documents" section.
BERT/TDM
Cisco's bit-error-rate-testing (BERT) solution and time-division multiplexing (TDM) command enhancements have been implemented for the Cisco AS5300 in Cisco IOS Release 12.0(2)XD1 and 12.0(3)T1. This enhancement applies to T1 and E1 facilities. The BERT solution can be managed from remote command-line interface (CLI) and SNMP management platforms for any Cisco AS5300 in the network. A loopback LED on the Cisco AS5300 chassis blinks slowly to indicate that BERT is in progress; it blinks rapidly if the test fails. You can use bit error rate testing and loopbacks to aid in problem resolution as well as to test the quality of T1/E1 links. Early detection of poor quality links and fast problem isolation can result in improved quality of service and higher revenues.
The TDM subsystem troubleshooting commands are not used during normal system operation. Instead, the Cisco IOS commands show the current status and settings of the TDM backplane, enable debug output for display to a console when TDM programming occurs, and provide a set of test commands to test the functionality of the TDM path.
Voice over IP
Voice over IP (VoIP) support for the Cisco AS5300 was added in Cisco IOS Release 11.3(2)NA. VoIP enables a Cisco AS5300 to carry live voice traffic (for example, telephone calls and faxes) over an IP network. VoIP on the Cisco AS5300 supports two primary applications:
•
•
Used as a PSTN gateway, the VoIP feature leverages the standardized use of H.323-based Internet telephone client applications, such as:
•
•
•
Voice over IP is primarily a software feature. However, to use this feature on the Cisco AS5300, you must install the VoIP feature card (VFC). The VFC contains multiple digital signal processor (DSP) modules. The VFC uses the Cisco AS5300 quad T1/E1 PSTN interface and LAN or WAN routing capabilities to provide up to a 48- or 60-channel gateway for VoIP packetized voice traffic to/from T1/E1 time-division multiplexing (TDM) traffic.
Service Provider Features for Voice over IP
The Cisco voice service provider features include enhancements to the functionality and configuration of both the gateway and the VoIP gatekeeper. The architecture of these features provides the quality of service (QoS), stability, and functionality necessary for carrier class, real-time IP communications services.
The service provider features offer security, billing, scaling, and reliability for the Cisco VoIP gateway. Supporting up to two T1/E1 digital channels, the gateway connects to existing telephones and fax machines through the PSTN, key systems, and PBXs, making the process of placing calls over the IP network transparent to users. The gateway capability allows the Cisco AS5300 to function as an H.323 endpoint, providing admission control, address lookup and translation, and accounting services.
The gatekeeper manages H.323 endpoints in a consistent manner, allowing them to register with the gatekeeper and to locate another gatekeeper. The gatekeeper provides logic variables for proxies or gateways in a call path to provide connectivity with the PSTN, to improve QoS, and to enforce security policies. Multiple gatekeepers can be configured to communicate with one another, either by integrating their addressing into Domain Naming System (DNS), or via Cisco IOS configuration options.
SS7/CCS7 Dial Access Solution
The Cisco SS7/CCS7 Dial Access Solution (DAS) provides centralized functions for adding Signaling System 7 (SS7) interfaces to large dial points of presence (POPs). This Non-Facility Associated Signaling (NFAS) functionality provides a full integration of dial access capabilities within the circuit-switched network infrastructure and provides significant savings on switching interface costs while simultaneously reducing trunking costs. Using the NFAS functionality means that all your T1 and E1 channels are used for voice and data while the associated signaling is carried separately over the SS7 network. In addition, you can cost-effectively scale your network from a few hundred to thousands of ports because you do not need to add a D channel for every additional port.
The Cisco SS7/CCS7 DAS allows carrier customers to connect their Cisco AS5300 access servers to the PSTN directly, using SS7 signaling protocols. The SS7 signaling links terminate on a separate UNIX system called the Signaling Controller (SC2200). The SC2200 maps incoming calls, which are signaled via SS7, to bearers on the access servers. The access servers and SC2200 interact to set up and tear down calls using an extended Q.931 protocol over Q.921 and User Datagram Protocol (UDP). In this manner, the Cisco AS5300 access servers and the SC2200 form a system that emulates a terminating or originating end-office telephone switch in the PSTN.
This feature adds two capabilites to Cisco IOS software:
•
•
Large Scale Dialout
In previous dial-on-demand routing (DDR) networking strategies, only incoming calls could take advantage of features such as dialer and virtual profiles, Multichassis Multilink PPP (MMP) support, and the ability to use an authentication, authorization, and accounting (AAA) server to store attributes. MMP allows network access servers (NASes) to be stacked together and appear as a single NAS chassis so that if one NAS fails, another NAS in the stack can accept calls. MMP also provides stacked NASes access to a local Internet point of presence (POP) using a single telephone number. This allows for easy expansion and scalability as well as assured fault tolerance and redundancy. With large scale dialout, these features are now available for both outgoing and incoming calls.
Large scale dialout eliminates the need to configure dialer maps on every NAS for every destination. Instead, you create remote site profiles containing outgoing call attributes (telephone number, service type, and so on) on the AAA server. The profile is downloaded by the NAS when packet traffic requires a call to be placed to a remote site.
Additionally, large scale dialout addresses congestion management by seeking an uncongested, alternative NAS within the same POP when the designated primary NAS experiences port congestion.
As an added benefit, large scale dialout enables scalable dialout service to many remote sites across one or more Cisco NASes or Cisco routers. This is especially beneficial to both Internet service providers (ISPs) and large scale enterprise customers because it can simplify network configuration and management. Large scale dialout streamlines activities such as service maintenance and scheduled activities like application upgrades from a centralized location. Large enterprise networks such as those used by retail stores, supermarket chains, and franchise restaurants can use large scale dialout to easily update daily prices and inventory information from a central server to all branch locations in one process, using the same NASes they currently use for dial-in functions.
CDP Additions for Cisco IOS Software
The Cisco Discovery Protocol (CDP) is a media-independent device discovery protocol that runs on all Cisco-manufactured equipment, including routers, bridges, access servers, and switches. Each device sends periodic messages to a multicast address. Each device listens to the periodic messages sent by others in order to learn about neighboring devices and determine when their interfaces to the media go up or down. With CDP, network management applications can learn the device type and the SNMP agent address of neighboring devices. This process enables applications to send SNMP queries to neighboring devices.
CDP runs on all media that support Subnetwork Access Protocol (SNAP), including local-area network (LAN), Frame Relay, and Asynchronous Transfer Mode (ATM) media. CDP runs over the data link layer only. Therefore, two systems that support different network-layer protocols can learn about each other.
Each device configured for CDP sends periodic messages to a multicast address. Each device advertises at least one address at which it can receive SNMP messages. The advertisements also contain time-to-live, or holdtime, information that indicates the time a receiving device should hold CDP information before discarding it.
Additions for Cisco Discovery Protocol (CDP) include the following:
•
•
Cisco IOS SNMP v3
Cisco IOS Simple Network Management Protocol version 3 (SNMPv3) addresses issues related to the large scale deployment of SNMP for configuration, accounting, and fault management. SNMP is currently used predominantly for monitoring and performance management. SNMPv3 also facilitates remote configuration of the SNMP entities, which makes remote administration of SNMP entities a much simpler task. SNMPv3 builds on top of SNMPv1 and SNMPv2 to provide a secure environment for the management of systems and networks.
SNMPv3 provides an identification strategy for SNMP devices to facilitate communication only between known SNMP peers. Each SNMP device has an identifier called the SNMP EngineID. SNMP communication is possible only if an SNMP entity knows the identity of its peer SNMP device.
SNMPv3 also contains a security model or security strategy that exists between an SNMP user and the SNMP group to which the user belongs. A security model may define the security policy within an administrative domain or intranet. The SNMPv3 protocol consists of the specification for the User-Based Security Model (USM).
The goals of message authentication service include the following protection strategies:
•
•
•
•
•
•
•
CISCO-PROCESS-MIB
The CISCO-PROCESS-MIB contains MIB objects that define information displayed about active processes when using the show processes command. The addition of this MIB, along with changes to the CISCO-MEMORY-POOL-MIB, allows the retrieval and reporting of additional CPU and memory statistics by SNMP. The CISCO-PROCESS-MIB provides CPU statistics at 5-second, 1-minute, and 5-minute intervals. In addition, this MIB provides CPU utilization and memory allocation/deallocation statistics for each process on each CPU listed in the MIB.
The information defined includes the following objects:
•
•
•
•
•
•
•
The CISCO-PROCESS-MIB is enabled when the first SNMP command is configured. The background statistics collection for VIP cards and the master CPU occurs even if the SNMP subsystem is not initialized.
New Features in Release 12.0(2)T
The following new features are available for the Cisco AS5300 in Cisco IOS Release 12.0(2)T. To locate the online documentation about these features, refer to the "Platform-Specific Documents" section.
Triple-DES Encryption
The IPSec feature in the Cisco IOS now implements Triple-DES, the IPSec standard for high-security encryption, as described in the IETF draft specification The ESP Triple DES Transform, by N. Doraswamy, P. Metzger, and W.A. Simpson. This transform uses three independent DES keys to achieve security far greater than that of DES.
For more information, refer to the Triple DES Encryption for IPSec document. This document is available on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Cisco DialOut Utility
This feature is now supported on the Cisco AS5300 when using MICA modem portware version 2.5.1.0. The Cisco DialOut Utility is a COM port redirector that utilizes a protocol defined in RFC 2217 for communications between the client PC and a dial network access server (NAS).
New Features in Release 12.0(1)T
The following new features are available for the Cisco AS5300 in Cisco IOS Release 12.0(1)T. To locate the online documentation about these features, refer to the "Platform-Specific Documents" section.
CLI String Search
The Command-Line Interface (CLI) String Search feature allows you to search or filter the output of any show or more command. This is useful when you need to sort through large amounts of output or if you want to exclude output that you do not need to see. CLI String Search also allows for searching and filtering at --More-- paging prompts.
With the search function, you can begin unfiltered output at the first line that contains a regular expression you specify. You can specify a maximum of one filter per command to either include or exclude output lines that contain the specified regular expression. A regular expression is any word, phrase, number, or other type of information that appears in show or more command output.
Easy IP Phase 2-DHCP Server
With the introduction of Easy IP Phase 2, Cisco IOS software also supports Intelligent DHCP Relay functionality. A DHCP Relay Agent is any host that forwards DHCP packets between clients and servers. A DHCP Relay Agent enables the client and server to reside on separate subnets. If the Cisco IOS DHCP server cannot satisfy a DHCP request from its own database, it can forward the DHCP request to one or more secondary DHCP servers defined by the network administrator using standard Cisco IOS IP helper-address functionality.
ISDN MIB RFC 2127
The new ISDN MIB RFC 2127 has been designed to provide useful information in accordance with the IETF's new standard for the management of ISDN interfaces. It controls all aspects of ISDN interfaces. RFC 2127 provides information on the physical Basic Rate Interfaces (BRIs), control and statistical information for B (bearer) and D (signaling) channels, terminal endpoints, and directory numbers.
The ISDN MIB RFC 2127 controls all aspects of ISDN interfaces. It consists of five groups:
•
•
•
•
•
The ISDN MIB RFC 2127 enables you to use any commercial SNMP network management application to support ISDN call processing in Cisco IOS software. You can integrate management of dial access products using ISDN with your existing network management systems.
Time-Based Access Lists
It is now possible to implement access lists based on the time of day. To do so, create a time range that defines specific times of the day and week. The time range is identified by a name, and then referenced by a function, so that those time restrictions are imposed on the function itself.
Currently, IP and IPX extended access lists are the only functions that can use time ranges. The time range allows the network administrator to define when the permit or deny statements in the access list are in effect. Prior to this feature, access list statements were continuously in effect after they had been applied. Both named or numbered access lists can reference a time range.
Limitations and Restrictions
MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in :
Important Notes
This section contains important information about Cisco IOS Release 12.0 T software that can apply to the Cisco AS5300 universal access server.
Deferral of AS5300 Boot Image
The c5300-boot-mz image has been deferred in Cisco IOS Release 12.0(7)T because of a severe defect. This defect has been assigned Cisco Caveat ID CSCdu10569. The software solution for this defect is the c5300-boot-mz image in Cisco IOS Release 12.0(4)T1.
In order to increase network availability, Cisco recommends that you upgrade affected Cisco IOS images with the suggested replacement software images. Cisco will discontinue manufacturing shipment of affected Cisco IOS images. Any pending order will be substituted by the replacement software images.
Caution
The terms and conditions that governed your rights and obligations and those of Cisco, with respect to the deferred images will apply to the replacement images.
Last Maintenance Release of Cisco IOS Release 12.0 T
Cisco IOS Release 12.0(6)T has been renamed 12.0(7)T to align this release with the 12.0(7) mainline release. The closed caveats for Release 12.0(7)T are identical to the caveats closed in the 12.0(7) mainline release. There was no change in the feature content of the renamed release--the features in 12.0(6)T are the same as 12.0(7)T. Release 12.0(7)T is the last maintenance release of the 12.0 T release train.
Customers needing closure of caveats for the 12.0 T features should migrate to the 12.1mainline release, which has the complete feature content of Release 12.0 T and will eventually reach General Deployment (GD). Release 12.0 T is a super set of the 12.0 mainline release, so all caveats closed in the 12.0 mainline are also closed in 12.0 T.
Cisco IOS Syslog Failure
Certain versions of Cisco IOS software can fail when they receive invalid User Datagram Protocol (UDP) packets sent to their syslog ports (port 514). At least one commonly used Internet scanning tool generates packets that cause such problems. This fact has been published on public Internet mailing lists, which are widely read both by security professionals and by security crackers. This information should be considered in the public domain.
Attackers can cause Cisco IOS devices to repeatedly fail and reload, resulting in a completely disabled Cisco IOS device that needs to be reconfigured by its administrator. Some Cisco IOS devices can hang instead of failing when attacked. These devices do not recover until they are manually restarted by reset or power cycling. An administrator must visit the device to restart it, even if the attacker is no longer actively sending any traffic. Some devices have failed without providing stack traces; some devices indicate that they were "restarted by power-on," even when that was not the case.
Assume that any potential attacker knows the existence of this problem and the ways to exploit it. An attacker can use tools available to the public on the Internet and does not need to write any software to exploit the vulnerability. Minimal skill is required and no special equipment is required.
Despite Cisco specifically inviting such reports, Cisco has received no actual reports of malicious exploitation of this problem.
This vulnerability notice was posted on Cisco's World Wide Web site:
http://www.cisco.com/warp/public/770/iossyslog-pub.shtml
This information was also sent to the following e-mail and USENET news recipients:
•
•
•
•
•
•
•
Affected Devices and Software Versions
describes hardware and software that are affected by this problem. Affected versions include Releases 11.3 AA, 11.3 DB, and all 12.0 versions (including 12.0 mainline, 12.0 S, 12.0 T, and any other regular released version whose number starts with 12.0), up to the repaired releases listed in . Cisco is correcting the problem in certain special releases, will correct it in future maintenance and interim releases, and intends to provide fixes for all affected IOS variants. See , for details.
No particular configuration is needed to make a Cisco IOS device vulnerable. It is possible to filter out attack traffic by using access lists. See the "Workarounds" section for techniques. However, except at Internet firewalls, the appropriate filters are not common in customer configurations. Carefully evaluate your configuration before assuming that any filtering you have protects you against this attack.
The most commonly used or asked-about products are listed below. If you are unsure whether your device is running Cisco IOS software, log in to the device and enter the show version command. Cisco IOS software will identify itself simply as "IOS" or "Internetwork Operating System Software." Other Cisco devices do not have the show version command and identify themselves differently in their output. The most common Cisco devices that run Cisco IOS software include the following:
•
•
•
•
Affected software versions, which are relatively new, are not necessarily available on every device listed above. If you are not running Cisco IOS software, you are not affected by this problem.
The following Cisco devices are not affected:
•
•
•
•
•
•
•
•
This vulnerability has been assigned Cisco bug ID CSCdk77426.
Solution
Cisco offers free software updates to correct this vulnerability for all affected customers—regardless of their contract status. However, because this vulnerability information has been disseminated by third parties, Cisco has released this notice before updates are available for all software versions. gives Cisco's projected fix dates.
Make sure that your hardware has adequate RAM to support the new software before installing it. The amount of RAM is seldom a problem when you upgrade within a major release, for example, from 11.2[11]P to 11.2[17]P, but it is often a factor when you upgrade between major releases, for example, from 11.2 P to 11.3 T.
Because fixes will be available for all affected releases, this vulnerability will rarely, if ever, require you to upgrade to a new major release. Cisco recommends that you carefully plan for any upgrade between major releases. Make certain no known bugs will prevent the new software from working properly in your environment.
Further upgrade planning assistance is available on Cisco's World Wide Web site at:
http://www.cisco.com
If you have service contracts, you can obtain new software through your regular update channels (generally through Cisco's World Wide Web site). You can upgrade to any software release, but you must remain within the boundaries of the feature sets you have purchased.
If you do not have service contracts, you can upgrade to only obtain the bug fixes; free upgrades are restricted to the minimum upgrade required to resolve the defects. You can only upgrade to the software described in one row of —except when no upgrade within the same row is available in a timely manner.
Obtain updates by contacting one of the following Cisco Technical Assistance Centers (TACs):
•
•
•
Give the URL of this notice (http://www.cisco.com/warp/public/770/iossyslog-pub.shtml) as evidence for a free update. Customers with no contracts must request for free updates through the TAC. For software updates, please do not contact either "psirt@cisco.com" or "security-alert@cisco.com.
Workarounds
You can work around this vulnerability by preventing any affected Cisco IOS device from receiving or processing UDP datagrams addressed to port 514. You can do this by either using packet filtering on surrounding devices, or by using input access list filtering on the affected IOS device itself.
If you use an input access list, apply it to all interfaces to which attackers can send datagrams. Interfaces include not only physical LAN and WAN interfaces but also virtual subinterfaces of those physical interfaces—as well as virtual interfaces and interface templates corresponding to GRE, L2TP, L2F, and other tunneling protocols.
The input access list must block traffic destined for UDP port 514 at any of the Cisco IOS device's own IP addresses—as well as at any broadcast or multicast addresses on which the Cisco IOS device may be listening. Be sure to block both old-style "all-zeros" broadcasts and new-style "all-ones" broadcasts. It is not necessary to block traffic being forwarded to other hosts—only traffic actually addressed to the Cisco IOS device.
No single input access list works in all configurations. Be sure you know the effect of your access list in your specific configuration before activating it.
The following example shows a possible access list for a three-interface router, along with the configuration commands needed to apply the list. The example assumes input filtering is not needed—other than as a workaround for this problem:
! Deny all multicasts, and all unspecified-net broadcasts, to port 514access-list 101 deny udp any 224.0.0.0 31.255.255.255 eq 514! Deny old-style unspecified-net broadcastsaccess-list 101 deny udp any host 0.0.0.0 eq 514! Deny network-specific broadcasts. This example assumes that all of! the local interfaces are on the class B network 172.16.0.0, subnetted! everywhere with mask 255.255.255.0. This will differ from network! to network. Note that we block both new-style and old-style broadcasts.access-list 101 deny udp any 172.16.0.255 0.0.255.0 eq 514access-list 101 deny udp any 172.16.0.0 0.0.255.0 eq 514! Deny packets sent to the addresses of our own network interfaces.access-list 101 deny udp any host 172.16.1.1 eq 514access-list 101 deny udp any host 172.16.2.1 eq 514access-list 101 deny udp any host 172.16.3.3 eq 514! Permit all other traffic (default would be to deny)access-list 101 permit ip any any! Apply the access list to the input side of each interfaceinterface ethernet 0ip address 172.16.1.1 255.255.255.0ip access-group 101 ininterface ethernet 2ip address 172.16.2.1 255.255.255.0ip access-group 101 ininterface ethernet 3ip address 172.16.3.3 255.255.255.0ip access-group 101 inListing all possible addresses—especially all possible broadcast addresses—to which attack packets can be sent is complicated. If you do not need to forward any legitimate syslog traffic received on an interface, you can block all syslog traffic arriving on that interface. Remember that blocking will affect traffic routed through the Cisco IOS device—as well as traffic destined to the device. If the IOS device is expected to forward syslog packets, you will have to filter in detail. Because input access lists impact system performance, install them with caution—especially on systems running very near their capacity.
Software Versions and Fixes
Many Cisco software images have been or will be specially reissued to correct this vulnerability. For example, regular released Cisco IOS version 12.0(2) is vulnerable, as are interim versions 12.0(2.1) to 12.0(2.3). The first fixed interim version of Release12.0 mainline software is Release12.0(2.4). However, a special release, 12.0(2a), contains only the fix for this vulnerability and does not include any other bug fixes from later 12.0 interim releases.
If you are running Release 12.0(2) and want to fix this problem without risking possible instability presented by installing the 12.0(2.4) interim release, you can upgrade to Release 12.0(2a). Release 12.0(2a) is a "code branch" from the Release 12.0(2) base, which will merge back into the Release 12.0 mainline at Release 12.0(2.4).
Special releases, like 12.0(2a), are one-time spot fixes, and they will not be maintained. Thus, the upgrade path from Release 12.0(2a) is to Release 12.0(3).
Note
Table 7 Affected and Repaired Software Versions
11.2 and earlier releases—all variants
Unaffected early releases (no syslog server)
Unaffected
Unaffected
Unaffected
11.3, 11.3 T, 11.3 DA, 11.3 MA, 11.3 NA, 11.3 WA, 11.3(2)XA
11.3 releases without syslog servers
Unaffected
Unaffected
Unaffected
11.3 AA
11.3 early deployment for AS58xx
11.3(7)AA2, 8-JAN-19994
11.3(7.2)AA
11.3(8)AA, 15-FEB-1999
11.3 DB
11.3 for Cisco NRP routing blade in Cisco 6400 xDSL DSLAM
11.3(7)DB2, 18-JAN-1999
12.0
12.0 Mainline
12.0(2a), 8-JAN-1999
12.0(2.4)
12.0(3), 1-FEB-1999
12.0 T
12.0 new technology early deployment
12.0(2a)T1, 11-JAN-1999
12.0(2.4)T
12.0(3)T, 15-FEB-1999
12.0 S
ISP support; 7200, RSP, GSR
12.0(2.3)S, 27-DEC-1998
12.0(2)S5 , 18-JAN-1999
12.0 DB
12.0 for Cisco 6400 universal access concentrator node switch processor (lab use)
12.0(2)DB, 18-JAN-1999
12.0(1)W
12.0 for Catalyst 8500 and LS1010
12.0(1)W5(5a) and 12.0(1a)W5(5b) (LS1010 platform only)
12.0(1)W5(5.15)
12.0(1)W5(6) (platform support for Catalyst 8540M will be in 12.0(1)W5(7))
12.0(0.6)W5
One-time early deployment for CH-OC-12 module in Catalyst 8500 series switches
Unaffected; one-time release
Unaffected
Unaffected; To upgrade use 12.0(1)W5 releases.
12.0(1)XA3
Short-life release; merged to 12/0T at 12.0(2)T
Obsolete
Merged
Upgrade to 12.0(2a)T1 or to 12.0(3)T.
12.0(1)XB
Short-life release for Cisco 800 series; merged to 12.0 T and 12.0 (3)T
12.0(1)XB1
Merged
Upgrade to 12.0(3)T.
12.0(2)XC
Short-life release for new features in Cisco 2600, Cisco 3600, uBR7200, uBR900 series; merged to 12.0 T at 12.0(3)T
12.0(2)XC1, 7-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(2)XD
Short-life release for ISDN voice features; merged to 12.0 T at 12.0(3)T
12.0(2)XD1, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(1)XE
Short-life release
12.0(2)XE, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
1 A special fix is a one-time release that provides the most stable immediate upgrade path.
2 Interim releases are tested less rigorously than regular maintenance releases; interim releases can contain serious bugs.
3 Fixed maintenance releases are on a long-term upgrade path. Other long-term upgrade paths also exist.
4 All dates in this table are estimates and are subject to change.
5 This entry is not a misprint. The 12.0(2.3)S interim release is available before the 12.0(2)S regular release.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T.
All caveats in Release 12.0 are also in Release 12.0 T.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0, which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM.
Note
Related Documentation
The following sections describe the documentation available for the Cisco AS5300 universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 12.0 T and are located on CCO and the Documentation CD-ROM:
•
You can reach Cross-Platform Release Notes for Cisco IOS Release 12.0 T from the CCO home page by clicking on:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross Platform Release Notes
You can reach Cross-Platform Release Notes for Cisco IOS Release 12.0 T on the Documentation CD-ROM by clicking on:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross Platform Release Notes
•
You can reach these documents from the CCO home page at:
Technical Documents: Product Bulletins
•
See the Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T documents, which contain caveats applicable to all platforms for all maintenance releases of Release 12.0 and Release 12.0 T.
You can reach the caveat documents from the CCO home page by clicking on:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
You can reach the caveat documents on the Documentation CD-ROM by clicking on:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
The documents listed below for the Cisco AS5300 are available on CCO and on the Documentation CD-ROM:
•
•
•
•
Cisco AS5300 Universal Access Server Install and Configure•
•
•
•
•
You can reach the Cisco AS5300 documentation on CCO at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Access Servers: Cisco AS5300
You can reach the Cisco AS5300 documentation on the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
Feature Modules
Feature modules describe new features supported by Cisco IOS 12.0 T releases and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, feature modules are only available online. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
You can access the feature modules on CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
You can reach the feature modules on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
You can reach these documents on CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
You can reach these documents on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
You can reach the Cisco IOS documentation set on CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
You can reach the Cisco IOS documentation set on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-6121-06 Rev. -C0
