Release Notes for Cisco AS5200 Universal Access Servers for Cisco IOS Release 12.0
January 2, 2001
Note
You can find the most current Cisco IOS documentation on Cisco Connection Online (CCO). These electronic documents may contain updates and modifications made after the hardcopy documents were printed.
These release notes for Cisco AS5200 universal access servers support Cisco IOS Release 12.0(15). These release notes are updated to describe new memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0 that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
•
Introduction
Cisco AS5200 universal access servers are multifaceted data communications platforms that provide the functions of access servers, routers, modems, and terminal adapters (TAs) in a modular chassis. Mid-sized organizations or service providers requiring centralized processing capabilities for mobile users and telecommuters will benefit the most by using Cisco AS5200 universal access servers.
With their optimization for high-speed modem access, Cisco AS5200 universal access servers are ideally suited for all traditional dial-up applications, such as host access, electronic mail, file transfer, and dial-in access to a local area network.
For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.0(15), see the "New and Changed Information" section and the "Related Documentation" section.
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0:
•
•
Memory Recommendations
Table 1 lists the memory recommendations for the Cisco AS5200.
Hardware Supported
Cisco IOS Release 12.0 supports the Cisco AS5200. Table 2 lists the interfaces, network modules, and data rates supported by the Cisco AS5200.
For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco AS5200, log in to the Cisco AS5200 and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 12.0 Software (c5200-d-l), Version 12.0(15), RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see Cisco IOS Upgrade Ordering Instructions located at:
http://www.cisco.com/warp/public/cc/pd/iosw/prodlit/957_pp.htm
Modem Code Software
Cisco IOS Release 11.2 and later releases, including Release 12.0, include bundled modem code for the Cisco AS5200, which is the firmware or portware that runs on the Microcom 12-port and MICA 6-port modem cards. Modem code is bundled with the Cisco IOS software image to eliminate the need to store separate modem code. When the Cisco AS5200 is turned on, the Cisco IOS software unpacks the modem code and loads the proper code on the modem cards. Table 3 lists the current modem code versions.
Note
For information about installing Microcom 12-port modem cards and how Cisco IOS software uses Microcom modem code, see Installing 56K 12-Port Modem Modules in Cisco AS5200 Universal Access Servers and the Cisco AS5200 Universal Access Server Software Configuration Guide. For information about installing MICA 6-port modem cards and how Cisco IOS software uses MICA modem code, see Installing 6-Port MICA Modules and Carrier Cards in Cisco AS5200 Universal Access Servers and the Cisco AS5300 Universal Access Server Software Configuration Guide.The Cisco IOS Software Upgrade Planner on CCO contains information about downloading software. To access this document from CCO, click Login on the CCO home page to access all information. From the CCO home page, go to the Service & Support area menu, click Software Center, then Cisco IOS Software or IOS Upgrade Planner.
The modem code release notes are on CCO and the Documentation CD-ROM.
On CCO at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Firmware and Portware Information
On the Documentation CD-ROM at:
Access Servers and Access Routers: Firmware and Portware Information: Cisco AS5200
Additional information regarding Cisco IOS software compatibility is located in Cisco AS5X00 MICA 6-Port and 12-Port Modem Module Portware/Cisco IOS Software Compatibility Matrixes at:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5200/as52mfw/cm/mca6port.htm
Microcom firmware compatibility issues are discussed in 56K Digital 12-Port Modem Module Compatibility Matrix (56K Modem) for Cisco AS5200/AS5300 at:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/5300/mod_info/cm/56k12prt.htm
Note
Feature Set Table
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Caution
Table 4 lists the features and feature sets supported by the Cisco AS5200 in Cisco IOS Release 12.0 and uses the following conventions:
•
•
Note
New and Changed Information
The following is a list the new hardware and software features categories supported by the Cisco AS5200 for Cisco IOS Release 12.0. These categories are broken down by feature in Table 4.
•
•
•
•
•
•
•
•
MIBs
Current MIBs
If you have an account with CCO, you can find the current list of MIBs supported by Cisco. To reach the Cisco Network Management Toolkit, Login to CCO and click Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.
Deprecated and Replacement MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 5.
Note
Important Notes
The following sections contain important notes about Cisco IOS Release 12.0(15) that can apply to the Cisco AS5200.
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0, which lists severity 1 and 2 caveats and select severity 3 caveats for Cisco IOS Release 12.0 and is located on CCO and the Documentation CD-ROM.
Note
Related Documentation
The following sections describe the documentation available for the Cisco AS5200. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
See Caveats for Cisco IOS Release 12.0, which contain caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.0.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco AS5200 on CCO and the Documentation CD-ROM:
•
•
•
•
•
•
•
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco Product Documentation: Access Servers and Routers: Access Server: Cisco AS5200
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5200
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Cisco IOS Release 12.0 Documentation Set
Table 6 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form if ordered.
Note
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
•
•
•
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
