Release Notes for Cisco 3600 Series for Cisco IOS Release 12.0
January 2, 2001
These release notes for Cisco 3600 series support Cisco IOS Release 12.0, up to and including Release 12.0(15). These release notes are updated as needed to describe new features, memory recommendations, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(15), see Caveats for Cisco IOS Release 12.0 that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
Obtaining Technical Assistance
Introduction
The Cisco 3600 series includes the Cisco 3620 and Cisco 3640 routers. As modular solutions, the Cisco 3620 and Cisco 3640 enable corporations to increase dial-up intensity and take advantage of current and emerging WAN technologies and networking capabilities. The Cisco 3600 series routers are fully supported by Cisco IOS software, which includes dial-up connectivity, LAN-to-LAN routing, data and access security, WAN optimization, and multimedia features.
System Requirements
This section describes the system requirements for Release 12.0(15) and includes the following sections:
•
•
Memory Recommendations
Table 1 describes the feature set memory recommendations for the Cisco 3600 series for Cisco IOS Release 12.0(15).
Hardware Supported
Cisco IOS Release 12.0(15) supports the Cisco 3600 series routers:
•
•
For detailed descriptions of the new hardware features for Release 12.0(15), refer to the Cross-Platform Release Notes for Cisco IOS Release 12.0.
Table 2 lists the supported interfaces for Cisco IOS Release 12.0(15) for the Cisco 3600 Series.
Table 2 Supported Interfaces for Cisco IOS Release 12.0 for the Cisco 3600 Series
16- and 32-port asynchronous network module
All Cisco 3600 series
6- to 30-port integrated digital modems network module
All Cisco 3600 series
8- or 16-port integrated analog network module
All Cisco 3600 series
1- and 4-port Ethernet (AUI and 10BaseT)
All Cisco 3600 series
4/16 Mbps Token Ring
All Cisco 3600 series
Fast Ethernet (100BaseTX and 100BaseFX)
All Cisco 3600 series
1- and 2-port voice/fax network module
All Cisco 3600 series with voice/fax network module
2-port E&M voice interface card
All Cisco 3600 series
2-port FXO voice interface card
All Cisco 3600 series with voice/fax network module
2-port FXS voice interface card
All Cisco 3600 series with voice/fax network module
48/56/64 kbps
All Cisco 3600 series
1.544/2.048 Mbps
All Cisco 3600 series
Up to 8 Mbps on 4-port serial network module
All Cisco 3600 series
52 Mbps max using High-Speed Serial Interface (HSSI) network module
All Cisco 3600 series
1- and 2-port channelized T1 and E1 network module
All Cisco 3600 series
1-port ATM-25 network modules for the Cisco 3600 series
All Cisco 3600 series
1-port BRI with NT or S/T WAN interface card
All Cisco 3600 series
1-port HSSI network module
All Cisco 3600 series
4- and 8-port BRI network module with NT1
All Cisco 3600 series
4- and 8-port BRI network module with S/T interface
All Cisco 3600 series
4- and 8-port synchronous/asynchronous
All Cisco 3600 series
4-port serial
All Cisco 3600 series
56/64 kbps DSU/CSU
All Cisco 3600 series
T1 WAN interface card for Cisco 3600, Cisco 2600, and Cisco 1600 series
All Cisco 3600 series
T1 with integrated DSU/CSU for the Cisco 3600, Cisco 2600, and Cisco 1600 series
All Cisco 3600 series
1 The Voice/Fax network modules require Cisco IOS Plus feature sets.
2 The ATM-25 network modules require Cisco IOS Plus feature sets.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco 3600 series, log in to the Cisco 3600 series and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) 3600 series Software (c3620-i-mz), Version 12.0(15), RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see the product bulletin Cisco IOS Upgrade Ordering Instructions located at:
http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm
On CCO at:
Software Center: Cisco IOS Software: Product Bulletins: Software
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Table 3 lists the Cisco IOS software feature sets available for Cisco IOS Release 12.0(15).
Table 3 Feature Sets Supported by the Cisco 3600 Series
IP
Basic1
c3620-i-mz c3640-i-mz
Cisco 3620 Cisco 3640
IP Plus
Plus2
c3620-is-mz c3640-is-mz
Cisco 3620 Cisco 3640
IP Plus 40
Plus, Plus 403
c3620-is40-mz c3640-is40-mz
Cisco 3620 Cisco 3640
IP Plus IPSec 56
Plus, IPSec 564
c3620-is56i-mz c3640-is56i-mz
Cisco 3620 Cisco 3640
/DEC StandardIP/IPX/AppleTalk/DEC
Basic
c3620-d-mz
c3640-d-mzCisco 3620 Cisco 3640
IP/IPX/AppleTalk/DEC Plus
Basic, Plus
c3620-ds-mz
c3640-ds-mzCisco 3620 Cisco 3640
Enterprise Plus
Plus
c3620-js-mz c3640-js-mz
Cisco 3620 Cisco 3640
Enterprise Plus IPSec 56
Plus, IPSec 56
c3620-js56i-mz c3640-js56i-mz
Cisco 3620 Cisco 3640
StandardEnterprise/APPN Plus
Plus
c3620-ajs-mz c3640-ajs-mz
Cisco 3620 Cisco 3640
Enterprise/APPN Plus IPSec 56
Plus, IPSec 56
c3620-ajs56i-mz c3640-ajs56i-mz
Cisco 3620 Cisco 3640
Service Provider
Basic
c3620-p-mz c3640-p-mz
Cisco 3620 Cisco 3640
1 This feature set is offered in the basic feature set.
2 This feature set is offered in the Plus feature set.
3 This feature set is offered in the encryption feature sets which consist of 40-bit (Plus 40) data encryption feature sets.
4 This feature set is offered in the encryption feature sets which consist of IPSec 56-bit (Plus IPSec 56) data encryption feature sets.
Caution
Table 4, Table 5, Part 1, and Table 5, Part 2 list the features and feature sets supported by the Cisco 3600 series in Cisco IOS Release 12.0(15). All tables use the following conventions to identify features:
•
•
To determine the features that are available with each feature set for the entire Cisco 3600 series, see Table 4. To determine the additional features that are available with each feature set for the Cisco 3640 only, see Table 5, Part 1, and Table 5, Part 2.
Note
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 3600 series for Release 12.0(15).
New Hardware Features in Release 12.0(15)
There are no new hardware features supported by the Cisco 3600 series in Cisco IOS Release 12.0(15).
New Software Features in Release 12.0(15)
There are no new software features supported by the Cisco 3600 series in Cisco IOS Release 12.0(15).
Limitations and Restrictions
MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 6.
Important Notes
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at
http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml.
Product Number Change
Beginning with Cisco IOS Release 12.0(7)XK, Cisco changed the product numbers used to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0 which lists severity 1 and 2 caveats and select severity 3 caveats for Release 12.0 and is located on CCO and the Documentation CD-ROM.
Related Documentation
The following sections describe the documentation available for the Cisco 3600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0:
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Technical Documents
•
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco 3600 series on CCO and the Documentation CD-ROM:
•
•
•
•
•
•
•
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
Table 7 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet that shipped with your product.
If you purchased your product from a reseller, you can access CCO as a guest. CCO is Cisco Systems' primary real-time support channel. Your reseller offers programs that include direct access to CCO services.
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco TAC Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at the following sites:
•
•
•
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/cgi-bin/order/order_root.pl
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
.
