Release Notes for Cisco 2600 Series for Cisco IOS Release 12.0

January 2, 2001

These release notes for Cisco 2600 series support Cisco IOS Release 12.0, up to and including Release 12.0(15). These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.

For a list of the software caveats that apply to Release 12.0(15), see Caveats for Cisco IOS  Release 12.0 that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release12.0 on CCO and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

•Introduction

•System Requirements

•Limitations and Restrictions

•Important Notes

•Caveats

•Related Documentation

•Service and Support

•Obtaining Documentation

•Obtaining Technical Assistance

Introduction

The Cisco 2600 series modular routers are designed to easily adopt future technologies and scale to accommodate network expansion. The Cisco 2600 series shares modular interfaces with the Cisco 1600, 1700, and 3600 series, providing:

•Secure internet/intranet access

•Multiservice voice/data integration

•Analog and digital dial access services

•Virtual Private Network (VPN) access

•Inter-VLAN routing

The Cisco 2600 series supports advanced Quality of Service (QoS), security, and network integration features.

System Requirements

This section describes the system requirements for Release 12.0(15):

•Memory Recommendations

•Hardware Supported

•Determining the Software Version

•Upgrading to a New Software Release

•Feature Set Tables

Memory Recommendations

Table 1 describes the feature set memory recommendations for the Cisco 2600 series for Cisco IOS Release 12.0(15).

Note All Plus feature sets include voice network support.

Table 1 Memory Recommendations for the Cisco 2600 Series

Feature Set
Images

Flash
Memory

DRAM
Memory
Runs
From

IP

c2600-i-mz

4 MB

20 MB

RAM

IP Plus

c2600-is-mz

8 MB

24 MB

RAM

IP Plus 40

c2600-is40-mz

8 MB

32 MB

RAM

IP Plus 56

c2600-is56-mz

8 MB

32 MB

RAM

IP Plus IPsec 56

c2600-is56i-mz

8 MB

32 MB

RAM

IP/IPX/AT/DEC

c2600-d-mz

8 MB

20 MB

RAM

IP/IPX/AT/DEC Plus

c2600-ds-mz

8 MB

24 MB

RAM

Enterprise Plus

c2600-js-mz

8 MB

24 MB

RAM

Enterprise Plus IPsec 56

c2600-js56i-mz

8 MB

40 MB

RAM

Enterprise/APPN Plus

c2600-ajs-mz

8 MB

32 MB

RAM

Enterprise/APPN Plus IPsec 56

c2600-ajs56i-mz

8 MB

32 MB

RAM

Remote Access Server

c2600-c-mz

4 MB

20 MB

RAM


Hardware Supported

Cisco IOS Release 12.0 supports the following Cisco 2600 series routers:

•Cisco 2610

•Cisco 2611

•Cisco 2612

•Cisco 2613

For detailed descriptions of the new hardware features for Release 12.0, refer to the Cross-Platform Release Notes for Cisco IOS Release12.0 on CCO and the Documentation CD-ROM.

Note The Cisco 2620 and Cisco 2621 are supported by Cisco IOS Release 12.0(2) XC and IOS Release 12.0(3) T and later. Not all modules listed below are supported with this particular IOS version or on all feature sets.

Table 2 lists the supported interfaces for Cisco IOS Release 12.0(15) for the Cisco 2600 Series.

Table 2 Supported Interfaces on the Cisco 2600 Series

Interface, Network Module, or Data Rate1
Platforms Supported
LAN Interfaces

Ethernet (10BaseT), 1- or 2-port

Cisco 2610, Cisco 2611, Cisco 2612

Token Ring (RJ-45), 1-port

Cisco 2612, Cisco 2613

LAN Network Modules

Ethernet, 4-port

All Cisco 2600 series platforms

Ethernet, 1-port

All Cisco 2600 series platforms

Two-WAN interface card network slot module (WAN interface cards offered separately)

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS release 12.0.7XK, 12.1.2T, 12.2.x mainline or later.

ATM Network Modules

ATM-25, RJ-45 interface, 1-port

All Cisco 2600 series platforms

T1 ATM with IMA network module, 4- or 8-port

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0(7)T, 12.1 mainline, 12.1T or later.

E1 ATM with IMA network module, 4- or 8-port

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0(7)T, 12.1 mainline, 12.1T or later.

DS3 (T3) ATM network module, 1- port

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.1(2)T, 12.2(x) mainline or later.

E3 ATM network module, 1- port

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.1(2)T, 12.2(x) mainline or later.

Serial Network Modules

Asynchronous, 16- or 32-port

All Cisco 2600 series platforms

Asynchronous/synchronous serial low speed
(128 kbps max), 4- or 8-port

All Cisco 2600 series platforms

Dial, ISDN and Channelized Serial Network Modules

Channelized T1/ISDN PRI, 1- or 2-port

All Cisco 2600 series platforms

Channelized T1/ISDN PRI with CSU, 1- or 2-port

All Cisco 2600 series platforms

Channelized E1/ISDN PRI balanced, 1- or 2-port

All Cisco 2600 series platforms

Channelized E1/ISDN PRI unbalanced, 1- or 2-port

All Cisco 2600 series platforms

ISDN BRI S/T interface, 4-or 8-port

All Cisco 2600 series platforms

ISDN BRI U (NT1) interface, 4- or 8-port

All Cisco 2600 series platforms

Analog Modems, 8 or 16

All Cisco 2600 series platforms

Voice/Fax Network Module

Voice/fax, 1 or 2 voice interface card slots

All Cisco 2600 series platforms

24-channel-T1 high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0(7)T, 12.1 mainline or 12.1T or later.

Enhanced 24-channel T1 high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0(7)T, 12.1 mainline or 12.1T or later.

Voice/Fax Network Module (continued)

Forty-eight-channel T1 high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0(7)T, 12.1 mainline or 12.1T or later.

Thirty-channel E1high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0.7XK, 12.1.2T, 12.2.x mainline or better.

Enhanced thirty-channel E1high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0.7XK, 12.1.2T, 12.2.x mainline or better.

Sixty-channel E1high density voice/fax network module

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0.7XK, 12.1.2T, 12.2.x mainline or better.

High-density voice module, spare (no T1 or DSPs)

All Cisco 2600 series platforms not supported in this Cisco IOS release. Requires Cisco IOS Release 12.0.7T, 12.1 mainline, 12.1T or later.

Voice Interface Cards

FXS voice/fax interface card for voice/fax network module, 2-port2

All Cisco 2600 series platforms with Voice/Fax network module

FXO voice/fax interface card for voice/fax network module, 2-port2

All Cisco 2600 series platforms with Voice/Fax network module

E&M voice/fax interface card for voice/fax network module, 2-port2

All Cisco 2600 series platforms with Voice/Fax network module

BRI S/T interface (requires external NTI), I-port

All Cisco 2600 series platforms with voice/fax network module. Requires Cisco IOS Release 12.0(3)T or later.

WAN Interface Cards

ISDN BRI S/T interface (requires external NT1), 1-port

All Cisco 2600 series platforms

ISDN BRI (NT1) U, 1-port

All Cisco 2600 series platforms

56/64-kbps DSU/CSU, 1-port

All Cisco 2600 series platforms

T1/Fractional T1 with DSU/CSU, 1-port

All Cisco 2600 series platforms

High-speed serial (up to 2.048 Mbps), 1-port

All Cisco 2600 series platforms

Dual high-speed serial (up to 2.048 Mbps; asynchronous/synchronous support), 2-port

All Cisco 2600 series platforms

Dual asynchronous/synchronous (up to 128 kbps), 2-port

All Cisco 2600 series platforms

Multiflex Voice/WAN Interface Cards

T1/Fractional T1 Multiflex Trunk with CSU/DSU, 1- and 2-port3

All Cisco 2600 series platforms not supported in this Cisco release. Requires Cisco IOS Release 12.0(7)T, 12.1(x) mainline, 12.1T or later.

Dual-port T1/Fractional T1 Multiflex Trunk with CSU/DSU and Drop & Insert3

All Cisco 2600 series platforms not supported in this Cisco release. Requires Cisco IOS Release 12.0(7)T, 12.1(x) mainline, 12.1T or later.

E1/Fractional E1 Multiflex Trunk with DSU, 1- and 2-port3

All Cisco 2600 series platforms not supported in this Cisco release. Requires Cisco IOS Release 12.0(7)T, 12.1(x) mainline, 12.1T or later.

Dual-port E1/Fractional E1 Multiflex Trunk with CSU/DSU and Drop & Insert3

All Cisco 2600 series platforms not supported in this Cisco release. Requires Cisco IOS Release 12.0(7)T, 12.1(x) mainline, 12.1T or later.

G.703 Multiflex Trunk, 1- and 2-port3

All Cisco 2600 series platforms not supported in this Cisco release. Requires Cisco IOS Release 12.1(2)T, 12.2(x) mainline, or later.

Advanced Integration Modules

Data compression AIM (up to 8.192Mbps)

All Cisco 2600 series platforms

1 The voice/fax and ATM-25 network modules require Cisco IOS Plus feature sets.

2 This interface card requires the NM-1V or NM-2V network module.

3 Packet telephony applications require the NM-HDV in most cases.


Note For additional information on the Cisco 2600 series hardware, go to: http://www-tac.cisco.com/Support_Library/Hardware/2600/2600-new.html.

Determining the Software Version

To determine the version of Cisco IOS software running on your Cisco 2600 series, log in to the Cisco 2600 series and enter the show version EXEC command:

router>show version

Cisco Internetwork Operating System Software

IOS (tm) 2600 series Software (c2600-i-mz), Version 12.0(15), RELEASE SOFTWARE

Upgrading to a New Software Release

For general information about upgrading to a new software release, see the product bulletin Cisco IOS Upgrade Ordering Instructions located at:

http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm

On CCO at:

Software Center: Cisco IOS Software: Product Bulletins: Software: General System Software Bulletins

Feature Set Tables

The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific software image, as shown in Table 3.

Table 3 Feature Sets Supported by the Cisco 2600 Series

Feature Sets
Feature Set Matrix Term
Software Image
Platforms
IP Standard

IP

Basic1

c2600-i-mz

All Cisco 2600 series

IP Plus

Basic, Plus2

c2600-is-mz

All Cisco 2600 series

IP Plus 40

Plus, Plus 403

c2600-is40-mz

All Cisco 2600 series

IP Plus 56

Plus, Plus 56

c2600-is56-mz

All Cisco 2600 series

IP Plus IPsec 56

Plus, Plus IPsec 564

c2600-is56i-mz

All Cisco 2600 series

IP/IPX/AppleTalk/
DEC Standard

IP/IPX/AppleTalk/DEC

Basic

c2600-d-mz

All Cisco 2600 series

IP/IPX/AppleTalk/DEC Plus

Basic, Plus

c2600-ds-mz

All Cisco 2600 series

Enterprise Standard

Enterprise Plus

Plus

c2600-js-mz

All Cisco 2600 series

Enterprise Plus IPsec 56

Plus, Plus IPsec 56

c2600-js56i-mz

All Cisco 2600 series

Enterprise/APPN Standard

Enterprise/APPN Plus

Plus

c2600-ajs-mz

All Cisco 2600 series

Enterprise/APPN Plus IPsec 56

Plus, Plus IPSec 56

c2600-ajs56i-mz

All Cisco 2600 series

Telco

Remote Access Server

Telco Feature Set

c2600-c-mz

All Cisco 2600 series

1 This feature is offered in the Basic feature set.

2 This feature is offered in the Plus feature set.

3 This feature is offered in the encryption feature sets which consist of 40-bit (Plus 40) data encryption feature sets.

4 This feature is offered in the encryption feature sets which consist of IPsec 56-bit (Plus IPsec 56) data encryption feature sets.


Caution Cisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, the purchaser or user must obtain local import and use authorizations for all encryption strengths. Contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.

Table 4, Part 1 and Table 4, Part 2, list the features and feature sets supported by Cisco IOS Release 12.0(15) for the Cisco 2600 Series. Both tables use the following conventions to identify features:

•Yes—The feature is supported in the feature set.

•No—The feature is not supported in the feature set.

Note This feature set table contains only a selected list of features. This table is not a cumulative or complete list of all the features in each image.

Table 4, Part 1 Feature List by Feature Set for the Cisco 2600 Series

Features
Feature Sets
IP
IP Plus
IP Plus 40
IP Plus 56
IP Plus IPsec 56
IP/IPX/
AT/DEC
IP/IPX/
AT/DEC Plus
IBM Support

Bridging Code Rework

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIF Passthru in DLSw+

No

Yes

Yes

Yes

Yes

No

Yes

IP Routing

IP Precedence for GRE Tunnels (GRE VPN)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Protocol- Independent Multicast (PIM) Version 2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Management

SNMP Inform Request

No

No

No

No

No

No

No

VPDN MIB and Syslog Facility

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Scalability

Airline Product Set (ALPS)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Cisco IOS File System

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Entity MIB

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Expression MIB

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF Point to Multipoint

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Per Port Debugging (Conditionally Triggered Debugging)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SNMP Manager

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Security

Additional Vendor-Proprietary RADIUS Attributes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Authenticating ACLs

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Automated Double Authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Certificate Authority Interoperability

No

No

No

No

Yes

No

No

Internet Key Exchange Security Protocol

Yes

Yes

Yes

Yes

Yes

No

No

IPSec Network Security

No

No

No

No

Yes

No

No

MS-CHAP Support

No

Yes

Yes

Yes

Yes

No

Yes

Named Method Lists for AAA Authentication and Accounting

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Subblock Phase 1

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Switching

Enhanced ATM VC Configuration and Management

No

Yes

Yes

Yes

Yes

No

Yes

Multiple ISDN Switch Types

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Voice/Multimedia

VoIP

No

Yes

Yes

Yes

Yes

No

Yes

WAN Optimization

ATM PVC Management

No

Yes

Yes

Yes

Yes

No

Yes

DRP Server Agent

Yes

Yes

Yes

Yes

Yes

Yes

Yes

WAN Services

Always On/Dynamic ISDN (AO/DI)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Dialer Watch

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Interface Name Modularity

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Microsoft Point-to-Point Compression (MPPC)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

MS Callback

Yes

Yes

Yes

Yes

Yes

Yes

Yes

National ISDN Switch Types

Yes

Yes

Yes

Yes

Yes

Yes

Yes

New and Changed Show Commands for the Cisco 2600 Series Routers

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Stackable Home Gateway

No

Yes

Yes

Yes

Yes

No

Yes


Table 4, Part 2 Feature List by Feature Set for the Cisco 2600 Series

Features
Feature Sets
Enterprise
Plus
Enterprise
Plus
IPsec 56
Enterprise/
APPN
Plus
Enterprise/
APPN
Plus
IPsec 56
IBM Support

Bridging Code Rework

Yes

Yes

Yes

Yes

RIF Passthru in DLSw+

Yes

Yes

Yes

Yes

IP Routing

IP Type of Service Precedence for GRE Tunnels (GRE VPN)

Yes

Yes

Yes

Yes

Protocol- Independent Multicast (PIM) Version 2

Yes

Yes

Yes

Yes

Management

SNMP Inform Request

Yes

Yes

Yes

Yes

VPDN MIB and Syslog Facility

Yes

Yes

Yes

Yes

Scalability

Airline Product Set (ALPS)

Yes

Yes

Yes

Yes

Cisco IOS File System

Yes

Yes

Yes

Yes

Entity MIB

Yes

Yes

Yes

Yes

Expression MIB

Yes

Yes

Yes

Yes

OSPF Point to Multipoint

Yes

Yes

Yes

Yes

Per Port Debugging (Cond Triggered Debugging)

Yes

Yes

Yes

Yes

SNMP Manager

Yes

Yes

Yes

Yes

Security

Additional Vendor-
Proprietary RADIUS Attributes

Yes

Yes

Yes

Yes

Authenticating ACLs

Yes

Yes

Yes

Yes

Automated Double Authentication

Yes

Yes

Yes

Yes

Certificate Authority Interoperability

No

Yes

No

Yes

Internet Key Exchange Security Protocol

No

Yes

Yes

No

IPSec Network Security

No

Yes

No

Yes

MS-CHAP Support

Yes

Yes

Yes

Yes

Named Method Lists for AAA Authentication & Accounting

Yes

Yes

Yes

Yes

Subblock Phase 1

Yes

Yes

Yes

Yes

Switching

Multiple ISDN Switch Types

Yes

Yes

Yes

Yes

National ISDN Switch Types

Yes

Yes

Yes

Yes

Voice/Multimedia

Voice over IP

Yes

Yes

Yes

Yes

WAN Optimization

ATM PVC Management

Yes

Yes

Yes

Yes

DRP Server Agent

Yes

Yes

Yes

Yes

WAN Services

Always On/Dynamic ISDN (AO/DI)

Yes

Yes

Yes

Yes

Dialer Watch

Yes

Yes

Yes

Yes

Interface Name Modularity

Yes

Yes

Yes

Yes

Microsoft Point-to-Point Compression (MPPC)

Yes

Yes

Yes

Yes

MS Callback

Yes

Yes

Yes

Yes

New and Changed Show Commands for the Cisco 2600 Series Routers

No

No

Yes

Yes

Stackable Home Gateway

Yes

Yes

Yes

Yes


New and Changed Information

The following sections list the new hardware and software features supported by the Cisco 2600 series for Release 12.0(15).

New Hardware Features in Release 12.0(15)

There are no new hardware features supported by the Cisco 2600 series in Cisco IOS Release 12.0(15).

New Software Features in Release 12.0(15)

There are no new software features supported by the Cisco 2600 series in Cisco IOS Release 12.0(15).

Limitations and Restrictions

MIBs

Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 5.

Table 5 Deprecated and Replacement MIBs

Deprecated MIB
Replacement

OLD-CISCO-APPLETALK-MIB

RFC1243-MIB

OLD-CISCO-CHASSIS-MIB

ENTITY-MIB

OLD-CISCO-CPUK-MIB

In development

OLD-CISCO-DECNET-MIB

In development

OLD-CISCO-ENV-MIB

CISCO-ENVMON-MIB

OLD-CISCO-FLASH-MIB

CISCO-FLASH-MIB

OLD-CISCO-INTERFACES-MIB

IF-MIB CISCO-QUEUE-MIB

OLD-CISCO-IP-MIB

In development

OLD-CISCO-MEMORY-MIB

CISCO-MEMORY-POOL-MIB

OLD-CISCO-NOVELL-MIB

NOVELL-IPX-MIB

OLD-CISCO-SYS-MIB

(Compilation of other OLD* MIBs)

OLD-CISCO-SYSTEM-MIB

CISCO-CONFIG-COPY-MIB

OLD-CISCO-TCP-MIB

CISCO-TCP-MIB

OLD-CISCO-TS-MIB

In development

OLD-CISCO-VINES-MIB

CISCO-VINES-MIB

OLD-CISCO-XNS-MIB

In development


Important Notes

Caveat CSCdr91706 and IOS HTTP Vulnerability

A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.

The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.

The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.

This vulnerability can only be exploited if the enable password is known or not set.

You are strongly encouraged to read the complete advisory, which is available at

http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml.

Product Number Change

Beginning with Cisco IOS Release 12.0(7)XK, Cisco changed the product numbers you use to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.

Old Product Number
New Product Number
Release
Image Description

S364AR1K2-12.0.7XK=

S364AR1K2-12007XK=

Cisco IOS Release 12.0(7)XK

Cisco 3640 Series IOS Enterprise/SNA SW PLUS IPSEC 3DES

S26CP-12.0.14=

S26CP-12014=

Cisco IOS Release 12.0(14)

Cisco 2600 Series IOS IP Plus


Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

For information on caveats in Cisco IOS Release 12.0(15), see Caveats for Cisco IOS Release 12.0 that lists severity 1 and 2 caveats and select severity 3 caveats for Release 12.0 and is located on CCO and the Documentation CD-ROM.

Related Documentation

The following sections describe the documentation available for the Cisco 2600 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.

Documentation is available as printed manuals or electronic documents.

Use these release notes with these documents:

•Release-Specific Documents

•Platform-Specific Documents

•Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:

•Cross-Platform Release Notes for Cisco IOS Release 12.0

On CCO at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes

•Product bulletins, field notices, and other release-specific documents on CCO at:

Technical Documents

•Caveats for Cisco IOS Release 12.0

As a supplement to the caveats listed in "Important Notes" in these release notes, see Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T that contains caveats applicable to all platforms for all maintenance releases of Release 12.0.

On CCO at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats

Note If you have an account with CCO, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on CCO at Software Center: Cisco IOS Software: Cisco Bug Toolkit: Cisco Bugtool Navigator II, or at http://www.cisco.com/support/bugtools.

Platform-Specific Documents

These documents are available for the Cisco 2600 series on CCO and the Documentation CD-ROM:

•Quick Start Guide Cisco 2600 Series Cabling and Setup

•Cisco 2600 Series Hardware Installation Guide

•Cisco Network Module Hardware Installation Guide

•Cisco Update to Network Module Hardware and Software Guides

•Cisco WAN Interface Cards Hardware Installation Guide

•Cisco Update to WAN Interface Cards Hardware Installation Guide

•Cisco Software Configuration Guide

•New and Changed Show Commands for the Cisco 2600 Series Routers

•Cisco 2600 Series Cabling Specifications

•Redundant Power Systems

•Cisco Modular Access Router Cable Specifications

•Compression Advanced Integration Module (AIM)

On CCO at:

Technical Documents: Documentation Home Page: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco 2600 series

On the Documentation CD-ROM at:

Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 2600 Series Routers

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.

On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.

On CCO at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References

Release 12.0 Documentation Set

Table 6 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.

Note You can find the most current Cisco IOS documentation on CCO and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.

On CCO at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0

Table 6 Cisco IOS Software Release 12.0 Documentation Set

Books
Chapter Topics

•Configuration Fundamentals Configuration Guide

•Configuration Fundamentals Command Reference

Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
System Management

•Bridging and IBM Networking Configuration Guide

•Bridging and IBM Networking Command Reference

Transparent Bridging
Source-Route Bridging
Token Ring Inter-Switch Link
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point
SNA Frame Relay Access Support
APPN
Cisco Database Connection
NCIA Client/Server Topologies
Cisco Mainframe Channel Connection
Airline Product Set

•Dial Solutions Configuration Guide

•Dial Solutions Command Reference

X.25 over ISDN
Appletalk Remote Access
Asynchronous Callback, DDR, PPP, SLIP
Bandwidth Allocation Control Protocol
ISDN Basic Rate Service
ISDN Caller ID Callback
PPP Callback for DDR
Channelized E1 and T1
Dial Backup for Dialer Profiles
Dial Backup Using Dialer Watch
Dial Backup for Serial Lines
Peer-to-Peer DDR with Dialer Profiles
DialOut
Dial-In Terminal Services
Dial-on-Demand Routing (DDR)
Dial Backup
Dial-Out Modem Pooling
Large-Scale Dial Solutions
Cost-Control Solutions
Virtual Private Dialup Networks
Dial Business Solutions and Examples

•Cisco IOS Interface Configuration Guide

•Cisco IOS Interface Command Reference

Interface Configuration Overview
LAN Interfaces
Logical Interfaces
Serial Interfaces

•Network Protocols Configuration Guide, Part 1

•Network Protocols Command Reference, Part 1

IP Overview
IP Addressing and Services
IP Routing Protocols

•Network Protocols Configuration Guide, Part 2

•Network Protocols Command Reference, Part 2

AppleTalk
Novell IPX

•Network Protocols Configuration Guide, Part 3

•Network Protocols Command Reference, Part 3

Network Protocols Overview
Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

•Security Configuration Guide

•Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options

•Cisco IOS Switching Services Configuration Guide

•Cisco IOS Switching Services Command Reference

Switching Services
Switching Paths for IP Networks
Virtual LAN (VLAN) Switching and Routing

•Wide-Area Networking Configuration Guide

•Wide-Area Networking Command Reference

Wide-Area Network Overview
ATM
Frame Relay
SMDS
X.25 and LAPB

•Voice, Video, and Home Applications Configuration Guide

•Voice, Video, and Home Applications Command Reference

Voice over IP
Voice over Frame Relay
Voice over ATM
Voice over HDLC
Frame Relay-ATM Internetworking
Synchronized Clocks
Video Support
Universal Broadband Features

•Quality of Service Solutions Configuration Guide

•Quality of Service Solutions Command Reference

Policy-Based Routing
QoS Policy Propagation via BGP
Committed Access Rate
Weighted Fair Queueing
Custom Queueing
Priority Queueing
Weighted Random
Early Detection
Scheduling
Signaling
RSVP
Packet Drop
Frame Relay Traffic Shaping
Link Fragmentation
RTP Header Compression

•Cisco IOS Release 12.0 Command Reference Master Index

•Cisco IOS Release 12.0 Configuration Guide Master Index

•Cisco IOS Software Command Summary

•Dial Solutions Quick Configuration Guide

•System Error Messages

•Debug Command Reference




Note Cisco Management Information Base (MIB) User Quick Reference is no longer published. For the latest list of MIBs supported by Cisco, see Cisco Network Management Toolkit on Cisco Connection Online. From CCO, click on the following path: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.

Service and Support

For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet that shipped with your product.

If you purchased your product from a reseller, you can access CCO as a guest. CCO is Cisco Systems' primary real-time support channel. Your reseller offers programs that include direct access to CCO services.

For service and support for a product purchased directly from Cisco, use CCO.

Software Configuration Tips on the Cisco TAC Home Page

If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:

http://www.cisco.com/kobayashi/serv_tips.shtml

This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.

The following sections are provided from the Technical Tips page:

•Access Dial Cookbook—Contains common configurations or recipes for configuring various access routes and dial technologies.

•Field Notices—Notifies you of any critical issues regarding Cisco products and includes problem descriptions, safety or security issues, and hardware defects.

•Frequently Asked Questions—Describes the most frequently asked technical questions about Cisco hardware and software.

•Hardware—Provides technical tips related to specific hardware platforms.

•Hot Tips—Describes popular tips and hints gathered from the Cisco Technical Assistance Center (TAC). Most of these documents are available from the TAC Fax-on-demand service. To reach Fax-on-demand and receive documents at your fax machine from the United States, call 888-50-CISCO (888-502-4726). From other areas, call 650-596-4408.

•Internetworking Features—Lists tips on using Cisco IOS software features and services.

•Sample Configurations—Provides actual configuration examples that are complete with topology and annotations.

•Software Products—Contains Cisco IOS Software Bulletins, Cisco TCP/IP Suite 100, General Cisco IOS, Internet/Intranet Applications and Software, Network Management, Network Protection Software Tips, and WAN Switching Products and Software.

•Special Collections—Lists other helpful documents, including Case Studies, References & Request for Comments (RFCs), and Security Advisories.

Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at the following sites:

•http://www.cisco.com

•http://www-china.cisco.com

•http://www-europe.cisco.com

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

•Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:

Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

•P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.

.
