Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 12.0 XR
February 27, 2002
These release notes for Cisco AS5300 universal access servers support Cisco IOS Release 12.0(7) XR4, which is an early deployment release based on Cisco IOS Release 12.0 T. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(7) XR4, see "Caveats" section and Caveats for Cisco IOS Release 12.0 T. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 located on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
MIBs
Introduction
This section contains information about the Cisco AS5300 universal access servers and Early Deployment (ED) releases for the Cisco AS5300.
Note
The Cisco AS5300 is a versatile data communications platform that performs two functions in a single modular chassis depending on the installed feature cards and IOS images:
•
•
The remote access server is intended for Internet service providers (ISPs), telecommunications carriers, and other service providers that offer managed Internet connections, as well as medium to large sites that provide both digital and analog access to users on an enterprise network. By terminating both analog and digital calls on the same chassis simultaneously, the access server provides a clear, simple, and easy migration path from analog dial access services to digital dial access services.
The Cisco AS5300/Voice Gateway is a versatile data communications platform that provides the functions of an access server, router, and digital modem(s) in a single modular chassis. The AS5300 includes three feature card slots: one holds a T1/E1/PRI feature card, and the other two support modem feature cards or voice digital signal processor (DSP) feature cards. When equipped with modem cards, the AS5300 serves as a remote access concentrator for dial-up (modem or ISDN) Internet access. When equipped with voice feature cards and Voice IOS, the AS5300/Voice Gateway serves as a voice (VoIP) gateway. By using one slot for modems and the other for voice DSPs, the AS5300 can serve in both capacities. Modem, voice, or fax calls are routed to the appropriate cards/resources via Dialed Number Identification Service (DNIS).
For information on new features and Cisco IOS commands supported by Release 12.0(7) XR4, see the "New and Changed Information" section and the "Related Documentation" section.
Early Deployment Releases
These release notes describe the Cisco AS5300 universal access servers for Cisco IOS Release 12.0(7) XR4. Release 12.0(7) XR4 is an early deployment (ED) release based on Release 12.0 T that contains fixes to software caveats and support for new Cisco hardware and software features. Other early deployment releases of the Cisco AS5300 are shown in ; unless otherwise indicated, feature support is cumulative from release to release.
System Requirements
This section describes the system requirements for Release 12.0(7) XR4:
•
•
Memory Recommendations
Memory recommendations for the Cisco AS5300 are presented in Table 2.
Hardware Supported
Cisco IOS Release 12.0(7) XR4 supports the Cisco AS5300 universal access servers.
For detailed descriptions of the new hardware features, see New and Changed Information.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco AS5300, log in to the Cisco AS5300 and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) AS5300 Software (c5300-is-mz), Version 12.0(7) XR4, RELEASE SOFTWAREUpgrading to a New Software Release
For information on upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) located at:
http://www.cisco.com/warp/public/cc/pd/iosw/iore/iomjre12/prodlit/index.shtml
Note
If you do not have an account on CCO and want general information about upgrading to a new software release, see the product bulletin Cisco IOS Upgrade Instructions on CCO at:
Software Center: Cisco IOS Software: Product Bulletins: Software
VCWare Requirements
Use the Cisco AS5300 universal access servers in Cisco IOS Release 12.0 XR4 with VCWare Version 5.09. Previous versions will not work. Please refer to the Release Notes for Cisco VCWare Version 5.xx for Cisco AS5300/Voice Gateway.
Note
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Release 12.0 XR4 supports the same feature sets as Release 12.0 T, but Release 12.0 XR4 can include new features supported by the Cisco AS5300 universal access servers.
Table 4 Feature Sets Supported by the Cisco AS5300 Series
IP Plus
Plus1
c5300-is-mz,
Enterprise Plus
Plus
c5300-js-mz, c5300-js56i-mz
1 This feature set is offered in the Plus feature set.
CautionCisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
lists the features and feature sets supported by the Cisco AS5300 universal access servers in Cisco IOS Release 12.0(7) XR4 and uses the following conventions:
•
•
•
Note
Table 5 Selected Features Supported by the Cisco AS5300 Feature Sets
APPN High-Performance Routing
No
No
No
APPN MIB Enhancements
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
APPN Scalability Enhancements
No
No
No
Bisync Enhancements:
–
–
–
Yes
Yes
Yes
Cisco MultiPath Channel (CMPC)
No
No
No
DLSw+ Enhancements:
–
–
–
–
–
–
–
Yes
Yes
Yes
FRAS Enhancements:
–
–
–
–
–
–
Yes
Yes
Yes
RIF Passthru in DLSw+
Yes
Yes
Yes
TN3270 LU Nailing
No
No
No
TN3270 Server Enhancements
No
No
No
Token Ring LANE
No
No
No
Tunneling of Asynchronous Security Protocols
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
DRP Server Agent Enhancements
Yes
Yes
Yes
Store and Forward Fax
(5)
Yes
Yes
Yes
Easy IP (Phase 1)
Yes
Yes
Yes
Easy IP (Phase 2) DHCP Server
(1)
Yes
Yes
Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
Yes
Yes
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
TCP Enhancements:
–
–
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
Yes
Yes
DECnet Accounting
No
Yes
Yes
IPX Named Access Lists
No
Yes
Yes
IPX SAP-after-RIP
No
Yes
Yes
NLSP Enhancements
No
Yes
Yes
NLSP Multicast Support
No
Yes
Yes
Subnetwork Bandwidth Manager
(5)
Yes
Yes
Yes
Cisco Call History MIB Command-Line Interface
Yes
Yes
Yes
Cisco IOS Internationalization
Yes
Yes
Yes
CNS Client for Cisco IOS Software
(4)
No
Yes
Yes
CNS client for IOS 12.05(t) (aka IPSec Policy Agent II)
(5)
No
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
Process MIB
(3)
Yes
Yes
Yes
ISDN MIB RFC 2127
(1)
Yes
Yes
Yes
OS_IFSS Featurette
(1)
Yes
Yes
Yes
SNMPv2C
Yes
Yes
Yes
SNMPv3
(3)
Yes
Yes
Yes
SNMP Inform Requests
No
Yes
Yes
Time-Based Access Lists
(1)
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
VPDN MIB
Yes
Yes
Yes
VPDN MIB and Syslog Facility
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
PIM Version 2
Yes
Yes
Yes
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
CLI String Search
(1)
Yes
Yes
Yes
Multicast Routing Monitor
(5)
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
BERT/TDM
(3)
Yes
Yes
Yes
TDM Hairpinning
(4)
Yes
Yes
Yes
Automated Double Authentication
Yes
Yes
Yes
Certificate Authority Interoperability
No
No
Yes
Double Authentication
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
Yes
HTTP Security
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
No
Yes
IPSec Network Security
No
No
Yes
IPSec with Triple-DES
(2)
No
No
No
MS-CHAP Support
No
Yes
Yes
Named Method Lists for AAA Authentication and Accounting
Yes
Yes
Yes
Parse Bookmarks
(1)
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
TCP Intercept
No
Yes
Yes
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Vendor-Proprietary RADIUS —Additional Attributes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
Yes
Yes
CLNS and DECnet Fast Switching over PPP
No
Yes
Yes
DECnet/VINES/XNS over ISL:
–
–
–
No
Yes
No
Fast-Switched Policy Routing
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
Yes
Yes
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
Telnet Extensions for Dialout
Yes
Yes
Yes
Virtual Templates for Protocol Translation
No
Yes
Yes
SS7/CCS7 Dial Access Solution (DAS)
(3)
Yes
Yes
Yes
Large Scale Dialout
(3)
Yes
Yes
Yes
Voice over IP
(3)
Yes
Yes
Yes
High-Density Voice over IP for Cisco AS5300/Voice Gateway
(5)
Yes
Yes
Yes
ATM MIB Enhancements
No
No
No
PAD Enhancements
No
Yes
Yes
PAD Subaddressing
Yes
Yes
Yes
Always On/Dynamic ISDN (AO/DI)
No
Yes
Yes
Async over UDP
(5)
Yes
Yes
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
E1 R2 Country Support1
Yes
Yes
Yes
E1 R1 Support for only Taiwan2
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Layer 2 Forwarding—Fast Switching
Yes
Yes
Yes
L2TP Dial-Out
(5)
Yes
Yes
Yes
Leased-Line ISDN at 128 kbps
No
No
No
ISDN LAPB-TA
(4)
Yes
Yes
Yes
Microsoft Point-to-Point Compression (MPPC)
Yes
Yes
Yes
MS Callback
Yes
Yes
Yes
Modem Management Enhancements
Yes
Yes
Yes
Multiple ISDN Switch Types
Yes
Yes
Yes
National ISDN Switch Types for BRI and PRI Interfaces (NI2)
Yes
Yes
Yes
PPP over ATM
No
No
No
SS7
(4)
Yes
Yes
Yes
Stackable Home Gateway
Yes
Yes
Yes
Switched 56K Digital Connections
Yes
Yes
Yes
Telnet Extensions for Dialout
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
H.323 Version 2 Support
(5)
Yes
Yes
Yes
Resource Pool Manager
(5)
Yes
Yes
Yes
Service Provider 1.0 Features
(3)
Yes
Yes
Yes
Cisco H.323 Multizone Enhancements
(7)
Yes
Yes
Yes
Configuring RADIUS for Multiple User Datagram Protocol Ports
(7)
Yes
Yes
Yes
Debit Card Accounting and New RADIUS Attributes for IP Telephony
(7)
Yes
Yes
Yes
Dynamic Multiple Encaps for Dial-in over ISDN
(7)
Yes
Yes
Yes
Interactive Voice Response for Cisco Access
(7)
Yes
Yes
Yes
Open Settlements Protocol (OSP) for IP Telephony
(7)
No
No
Yes
Resource Pool Management Server
(7)
Yes
Yes
Yes
Resource Pool Management with Direct Remote Services
(7)
Yes
Yes
Yes
Selecting AAA Server Groups Based on DNIS
(7)
Yes
Yes
Yes
Voice over IP Q.SIG Network Transparency for Cisco AS5300
(7)
Yes
Yes
Yes
Cisco H.323 VoIP with SS7
(7)XR1
Yes
Yes
Yes
MGCP
(7)XR1
Yes
Yes
No
1 E1 R2 country support requires specific versions of Mica portware. For details, see the Mica portware release notes, which are available on CCO in the Software Center. Note that country support varies with the portware release level, and the release notes provide a list of countries.
2 E1 R1 signaling support for Taiwan requires MICA portware version 2.3.1.0.
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco AS5300 universal access servers for Release 12.0(7) XR4.
No New Hardware and Software Features in Release 12.0(7)XR4
There are no new hardware and software features supported by the Cisco AS5300 for Release 12.0(7)XR4.
No New Hardware and Software Features in Release 12.0(7)XR3
There are no new hardware and software features supported by the Cisco AS5300 for Release 12.0(7)XR3.
No New Hardware and Software Features in Release 12.0(7)XR2
There are no new hardware and software features supported by the Cisco AS5300 for Release 12.0(7)XR2.
No New Hardware Features in Release 12.0(7)XR1
There are no new hardware features supported by the Cisco AS5300 for Release 12.0(7)XR1.
New Software Features in Release 12.0(7)XR1
The following new software features are supported by the Cisco AS5300 for Release 12.0(7)XR1:
Cisco H.323 Voice over IP (VoIP) with SS7 for the Cisco AS5300 Access Gateway
The Cisco H.323 VoIP with SS7 feature provides SS7 connectivity for voice gateways by using the signaling controller as a protocol translator to control the gateway using the ISDN Q.931 protocol. This feature interacts over the IP network with other Cisco H.323 VoIP with SS7 solutions functioning as an end-to-end SS7 voice network. In addition, it can communicate with other H.323 endpoints, including gateways using non-SS7 signaling such as ISDN PRI and channelized T1.
The access gateway terminates the PSTN trunks, also referred to as bearer channels, that carry the call traffic. The PSTN trunks are T1 or E1 PRI interfaces. In addition, the access gateway performs call control (including originating and terminating call processing/signaling). The gateway referred to is the Cisco AS5300.
The following enhancements to dial peer configuration limit complexity of dial planning and reduces the amount of effort in creating dial peer entries:
•
These new dial string symbols are added: period, brackets, percent, parenthesis, plus, and question mark.
**Add table of dial string symbols**
•
When configuring your dial peers, you are provided with an option called the translation rule. This rule applies a translation rule to a calling party number [Automatic Number Identification (ANI)] or a called party number [Dial Number Information Service (DNIS)] for both incoming and outgoing calls within Cisco H.323 voice-enabled gateways. Also, the rule allows translation of the type of number. Refer to the Q.931 ITU specification for details.
•
To match on a number type for a dial peer call leg, the numbering-type command is used in dial-peer configuration mode.
•
Number-type matching is used in dial-peer configuration mode to match on a number type for a dial peer call leg.
•
When a called number is received and matched to a POTS dial peer, the matched digits are stripped and the remaining digits are forwarded to the voice interface. A new command called digit strip makes this default behavior an option.
Media Gateway Control Protocol for the Cisco AS5300 Voice/Gateway
The Media Gateway Control Protocol (MGCP) provides simple call control functionality in a Voice over IP (VoIP) environment. In this VoIP environment, distributed call agent applications manage calls on trunking gateways.
This feature enables inter-exchange carriers (IXCs) that do not have time division multiplexing (TDM) equipment to provide both long distance services to corporate customers and provide connectivity to local exchange carriers (LECs) and other IXCs that use TDM equipment. This feature also offers IXCs IP networks as an alternative to congested TDM networks.
This feature provides standard MGCP implementing. MGCP will support SNMP through the XGCP-MIB which provides network management for external media gateway control protocols.
This feature also supports TDM hairpinning. Hairpinning allows trunking gateways to route a call back to the public switched telephone network or private or PBX if the IP network is too busy to handle the call. Hairpinning also can be used to connect the public switched telephone network (PSTN) to the network access server (NAS).
Note
MIBs
Current MIBs
If you have an account with CCO, you can find the current list of MIBs supported by Cisco. To reach the Cisco Network Management Toolkit, Login to CCO and click Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.
Deprecated and Replacement MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in:
Important Information
The following section contains important notes about Cisco IOS Release 12.0(7) XR4 that can apply to the Cisco AS5300.
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml .
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 and Release 12.0 T are also in Release 12.0(7) XR4.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0.
For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T, which lists severity 1 and 2 caveats and is located on CCO and the Documentation CD-ROM.
Note
Open Caveats—Cisco IOS Release 12.0(7) XR4
There are no open caveats specific to Cisco IOS Release 12.0(7) XR4 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 12.0(7) XR4
All the caveats listed in this section are resolved in Cisco IOS Release 12.0(7) XR4. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Resolved Caveats for Release 12.0(7) XR3
All the caveats listed in this section are resolved in Cisco IOS Release 12.0(7) XR3.
Basic System Services
•
When utilizing Network Time Protocol (NTP) private mode and control type messages for remote query, a router might reload or you might see traceback messages. There is no workaround.
When utilizing NTP private mode and control type messages for remote query it is possible to see a router crash or traceback messages.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
If you enter the show interface accounting command on a Cisco router that is running Cisco IOS Release 12.0(3)T, the accounting records are updated only when the first system interface is sampled, and all interfaces share the accounting record of the first interface.
This is resolved in Cisco IOS Release 12.0(7) XR3.
Interfaces and Bridging
•
A Cisco router that is running Cisco IOS Release 12.0(04a) might receive the following alignment error messages on dot1q over Internetwork Packet Exchange service access point (IPX SAP):
%ALIGN-3-CORRECT: Alignment correction made at 0x605B8E70 reading 0x63E5A6F1 %ALIGN-3-TRACE: -Traceback= 605B8E70 60095714 60095700 00000000 00000000 00000000 00000000 00000000
IPX SAP is affected only when dot1q encapsulation is involved (such as when IPX SAP is configured on a dot1q interface).
These alignment error messages do not affect connectivity or cause packet loss. There is no workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
IP Routing Protocols
•
Same global inside address used for three different inside hosts - using dynamic address translation / 11.2.9 IOS.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
The following entries might be added to the running configuration of a Cisco router even though Network Address Translation (NAT) is not configured:
•
•
•
•
•
•
•
There is no workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
Miscellaneous
•
A Multiport Basic Rate Interface (MBRI) might pause indefinitely in "awaiting establishment" and "tei assigned" modes. Entering the clear interface bri <interface number> command establishes multiple frames on the port and allows another ISDN call to be made. There is no workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
For Cisco IOS Release 11.2 P or Cisco IOS Release 11.3, packets could be switched in the clear if Fast Ethernet subinterfaces are configured for encryption over encapsulation Inter-Switch Link (ISL), the crypto map is only applied to the main interface, and the IP address is configured in the subinterface. The packets might be dropped when using a Cisco IOS Release 12.0 image while enabling Cisco Express Forwarding (CEF). There is no workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
When tunneling IPX over an IP tunnel, and when using an extended inbound access list for IP on the tunnel interface, the IPX traffic gets blocked by the access list. As a workaround a permit gre statement could be added in the extended access-list.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
If Token Ring is the endpoint of an encrypted tunnel, extra packets are generated.
Symptoms are a high CPU load (mainly taken by the Crypto Engine) and bogus addresses when enabling the debug tunnel command.
The workaround is to use the interface command tunnel sequence-datagrams on both endpoints of the tunnel.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
When changing traffic shaping parameters in presence of traffic going through, NRP may have a software crash. There is already a fix, but not in 11.3(9)DB2. One may choose to shutdown the interface during configuration update as a workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
In Cisco IOS Release 12.0 T, Cisco Express Forwarding (CEF) will not work with bundle virtual circuits (VCs) if you use subinterfaces that are part of the same physical interface.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
Received packets which had been padded by the previous hop so as to not be Ethernet runts are corrupted by the MPLS DCEF label imposition code and will result in IP checksum errors at their final destination, or at an intermediate hop, depending on the network configuration. A workaround is to disable DCEF globally or on a per-vip-interface basis.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
A Cisco AS5300 was idle because the VSC was in a hung state and RLM along with NFAS was down on the gateway. The gateway flushed on bad ISDN frames and restarted.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
When using RLM to connect a Cisco AS5300 access server to a SC2200 running Elan 7, you must configure NFAS on T1 controllers consecutively starting at T1 controller 0. If NFAS is configured on any other combination of T1 controllers, the SS7 CICs on the SC2200 may be blocked upon the restart of TransPath. This can be verified by issuing a rtrv-tc:all command at the mml prompt on the SC2200. All blocked CICs will be identified as BLK=LOCMAN. If you do not use the workaround described above, you must issue a reset-cic command from the mml prompt on the SC2200 for all blocked CICs.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
An MGCP call agent can request the Cisco AS5300 to detect the new milli-watt (1004Hz) tone. This is done via the MGCP RQNT command with the requested event being "nm". The problem is that the detection of this milli-watt tone works most of the time, but not 100%.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
The disconnect or release message cause value should pass end to end across different networks. If the cause value is equal to UUNSPECIFIED_CAUSE (0x1F), the value will be change to NORMAL_CLEARING (0x10) in the CSM module. To fix this bug, the disconnect cause value will pass end to end instead of change to a different value.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
If devices that can share the same IP address at different times are connected behind an MPC, some Multiprotocol over ATM (MPOA) shortcuts might not be valid after they switch over the IP address. There is no workaround.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
When the destination pattern explicitly has N number of ".", we expect a match up to the last "." and only forward N digits. Currently, if the called number is longer than the destination pattern, then the whole number is sent. For example:
dial-peer voice 100 potsdestination-pattern 408.....port 0:DIf a call comes in via an IP-call leg and the called number is "4085277878", it would match the above dial-peer. However, instead of forwarding 52778, which is what is configured, the entire called number sent is 527878.
Previous to the addition of the new wildcards (%,+,$), this is the behavior and was accepted. However, with the new wildcards, we now have a way to configure for variable length numbers so the explicit matching should now be enforced.
Note
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
The Kerberos Client functionality on Cisco products, when configured to provide access control, will fail in a "deny" state when the expiration of the credentials is in January or February of leap years, thus denying any Kerberos-authenticated access. A workaround for the problem is to choose an alternate form of authentication such as TACACS+ or RADIUS.
This is resolved in Cisco IOS Release 12.0(7) XR3.
Wide-Area Networking
•
The problem seems to happen only when transferring large amounts of information (i.e., ftp).
During that time we see Badsync or Badversion.
This is resolved in Cisco IOS Release 12.0(7) XR3.
•
If there are calls that are up, and the signalling controller (SC) does a switchover, some existing active calls are dropped on the network access server.
Workaround: Upgrade to Cisco IOS Release 12.0(6.5)T7 or higher.
This is resolved in Cisco IOS Release 12.0(7) XR3.
Related Documentation
The following sections describe the documentation available for the Cisco AS5300 universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Technical Documents: Product Bulletins
•
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 XR4.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco AS5300 universal access servers on CCO and the Documentation CD-ROM:
•
•
•
•
Cisco AS5300 Universal Access Server Install and Configure•
•
•
•
•
On CCO at:
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Access Servers: Cisco AS5300
On the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
Feature Modules
Feature modules describe new features supported by Release 12.0(7) XR4 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents that are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet that shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the
Cisco Technical Assistance Center Home PageIf you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/technotes/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
Translated documentation can be accessed on the WWW at:
http://www.cisco.com/public/countries_languages.shtml
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-6990-03 Rev. A0
