Release Notes for the Cisco 1750 Router for Cisco IOS Release 12.0(5)XQ
December 1, 1999
Cisco IOS Release 12.0(5)XQ
Text Part Number 78-7143-02
These release notes describe new features and significant software components for the Cisco 1750 router that supports Cisco IOS Release 12.0 T, up to and including Release 12.0(5)XQ. These release notes are updated as needed to describe new memory requirements, new features, new hardware support, software platform deferrals, microcode or modem code changes, related document changes, and any other important changes. Use these release notes with the Cross-Platform Release Notes for Cisco IOS Release 12.0 T located on CCO and the Documentation CD-ROM.
For a list of the software caveats that apply to Release 12.0(5)XQ, refer to the Caveats for Cisco IOS Release 12.0 T document that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
System Requirements
This section describes the system requirements for Release 12.0(5)XQ and includes the following sections:
•
Determining Your Software Release
•
Memory Requirements
This section describes the memory requirements for the Cisco IOS feature sets supported by Cisco IOS Release 12.0(5)XQ on the Cisco 1750 router.
Hardware Supported
Cisco IOS Release 12.0(5)XQ supports the Cisco 1750 Routers. For detailed descriptions of the new hardware features, refer to the "New and Changed Information" section.
The voice-and-data capable Cisco 1750 router provides global Internet and company intranet access and includes the following:
•
•
•
•
The Cisco 1750 router has the following hardware components:
•
•
•
•
•
•
(up to T1/E1) and compression processor•
•
•
•
•
The Cisco 1750 router also supports any combination of one or two of the following WAN interface cards, which are shared with the Cisco 1600, 1720, 2600, and 3600 routers:
•
•
•
•
•
•
•
The Cisco 1750 router supports any combination of one or two of the following voice interface cards, which are shared with the Cisco 2600 and 3600 routers:
•
•
•
•
Determining Your Software Release
To determine the version of Cisco IOS software currently running on your Cisco 1750 router, log in to the Cisco 1750 router and enter the show version EXEC command. The following sample output from the show version command indicates the version number on the second output line:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) c1750 Software (c1700-sv3y-mz.120-5.XQ), Version 12.0(5)XQ, RELEASE SOFTWAREAdditional command output lines include more information, such as processor revision numbers, memory amounts, hardware IDs, and partition information.
Upgrading to a New Software Release
For information on upgrading to a new software release, refer to the Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) product bulletin located on CCO.
On CCO, click on this path:
Service & Support: Product Bulletins: Software
Under Cisco IOS 12.0, click Cisco IOS Software Release 12.0 T Upgrade (#819: 1/99).
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.0(5)XQ supports the same feature sets as Releases 12.0 and 12.0 T, but Release 12.0(5)XQ can include new features supported by the Cisco 1750 router. Table 2 lists the feature sets supported by the Cisco 1750 router.
Table 2 Feature Sets Supported by the Cisco 1750 Router
IP Feature Sets
IP
Basic2
c1700-y-mz
Cisco 17203
Cisco 175012.0(1)XA3
IP Plus
Plus4
c1700-sy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP Plus 40
Plus 405
c1700-sy40-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP Plus 56
Plus 566
c1700-sy56-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP Plus IPSEC 56
Plus, IPSec 567
c1700-sy56i-mz
Cisco 1720
Cisco 175012.0(3)T
IP Plus IPSEC 3DES
Plus, IPSec, 3DES8
c1700-k2sy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/FW
Basic
c1700-oy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX/FW Plus
Plus
c1700-nosy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/FW Plus IPSEC 56
Plus,
IPSec 56c1700-osy56i-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/FW Plus IPSEC 3DES
Plus, IPSec, 3DES
c1700-k2osy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX
Basic
c1700-ny-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX/AT/IBM
Basic
c1700-bnr2y-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX/AT/IBM Plus
Plus
c1700-bnr2sy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX/AT/IBM/FW Plus IPSEC 56
Plus,
IPSec 56c1700-bnor2sy56i-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/IPX/AT/IBM/FW Plus IPSEC 3DES
Plus, IPSec, 3DES
c1700-bk2nor2sy-mz
Cisco 1720
Cisco 175012.0(1)XA3
IP/Voice Plus
Plus, Voice9
c1700-sv3y-mz.120-5.XQ
Cisco 1750
IP/Voice Plus 40
Plus 40, Voice
c1700-sv3y40-mz.120-5.XQ
Cisco 1750
IP Feature Sets (continued)
IP/Voice Plus 56
Plus 56, Voice
c1700-sv3y56-mz.120-5.XQ
Cisco 1750
IP/Voice Plus IPSEC 56
Plus, Voice, IPSec 56
c1700-sv3y56i-mz.120-5.XQ
Cisco 1750
IP/Voice Plus IPSEC 3DES
Plus, Voice, IPSec, 3DES
c1700-k2sv3y-mz.120-5.XQ
Cisco 1750
IP/FW/Voice Plus
Plus, FW, Voice
c1700-osv3y-mz.120-5.XQ
Cisco 1750
IP/FW/Voice Plus IPSEC 56
Plus, FW, Voice, IPSEC 56
c1700-osv3y56i-mz.120-5.XQ
Cisco 1750
IP/FW/Voice Plus 3DES
Plus, FW, Voice, 3DES
c1700-k2osv3y-mz.120-5.XQ
Cisco 1750
IP/IPX/FW/Voice Plus
Plus, IPX, FW, Voice
c1700-nosv3y-mz.120-5.XQ
Cisco 1750
IP/IPX/AT/IBM/FW/Voice Plus IPSEC 56
Plus, IPX, AT, IBM, FW, Voice,
IPSEC 56c1700-bnor2sv3y56i-mz.120-5.XQ
Cisco 1750
IP/IPX/AT/IBM/FW/Voice Plus 3DES
Plus, IPX, AT, IBM, FW, Voice, 3DES
c1700-bk2nor2sv3y-mz.120-5.XQ
Cisco 1750
1 The number in the "In" column indicates the Cisco IOS release in which the feature was introduced. For example, (3T) means a feature was introduced in Release 12.0(3)T. If a cell in this column is empty, the feature was included in the initial base release.
2 This set of features is provided in the basic feature set.
3 Cisco 1720 routers are mentioned here only to indicate that all images that run on Cisco 1720 routers also run on Cisco 1750 routers, but not vice-versa—voice images do not run on the Cisco 1720 routers.
4 This set of features is provided in the Plus feature set.
5 This set of features is provided in the 40-bit (Plus 40) data encryption feature sets.
6 This set of features is provided in the 56-bit (Plus 56) data encryption feature sets.
7 This set of features is provided in the IPSec 56-bit (Plus IPSec 56) data encryption feature sets.
8 This set of features is provided in the Triple DES (3DES) Encryption data encryption feature sets.
9 This set of features is provided in the Voice feature set.
Caution
Table 3 (parts 1 through 4) lists the features and feature sets supported by the Cisco 1750 router in Cisco IOS Release 12.0(5)XQ. Both tables use the following conventions:
•
•
Note
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 1750 router in Release 12.0 T.
New Hardware Features in Release 12.0(5)XQ
The following new hardware enhancements are supported by the Cisco 1750 in Release 12.0(5)XQ and later releases. For more information about new hardware and configuring the new software features, see the "Platform-Specific Documents" section.
Support for Cisco 1750 Router
Cisco IOS Release 12.0(5)XQ includes support for the Cisco 1750 router. The Cisco 1750 router is a voice-and-data capable router that provides VoIP functionality and can carry voice traffic (for example, telephone calls and faxes) over an IP network. Cisco voice support is implemented using voice packet technology.
New Software Features in Release 12.0(5)XQ1
The following software enhancements are supported by the Cisco 1750 in Release 12.0(5)XQ1 and later releases. For an introduction to the new software features, see the "Release-Specific Documents" section and the "Feature Modules and the Quality of Service Solutions Configuration Guide" section.
Quality of Service
Cisco IOS Release 12.0(5)XQ1 supports the following features:
•
•
•
•
•
•
To configure these features on Cisco 1750 series routers, see the online document Quality of Service Solutions Configuration Guide. From CCO, click on the path (under the heading Service & Support):
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Configuration Guides and Command References: Quality of Service Solutions Configuration Guide
Important Notes
The following sections contain important notes about Cisco IOS Release 12.0 that can apply to the Cisco 1750 router.
Flash defaults to Flash:1 on Multipartition Flash
When using a multipartition flash card, the various flash partitions are referred to as "flash:1:", "flash:2:", etc. If you specify only "flash" in a multipartition flash, the parser assumes "flash:1:." For example, if you type "show flash all" the parser defaults to "show flash:1: all" and only the flash information for the first partition displays. To see information for all flash partitions, type "show flash ?" This will list all of the valid partitions. Then enter "show flash:xx: all" on each valid partition.
Cisco IOS Syslog Failure
Certain versions of Cisco IOS software may fail or hang when they receive invalid User Datagram Protocol (UDP) packets sent to their syslog ports (port 514). At least one commonly used Internet scanning tool generates packets that cause such problems. This fact has been published on public Internet mailing lists, which are widely read both by security professionals and by security crackers. This information should be considered in the public domain.
Attackers can cause Cisco IOS devices to repeatedly fail and reload, resulting in a completely disabled Cisco IOS device that needs to be reconfigured by its administrator. Some Cisco IOS devices have been observed to hang instead of failing when attacked. These devices do not recover until they are manually restarted by reset or power cycling. An administrator must personally visit an attacked, hung device to restart it, even if the attacker is no longer actively sending any traffic. Some devices have failed without providing stack traces; some devices may indicate that they were "restarted by power-on," even when that is not the case.
Assume that any potential attacker is likely to know that existence of this problem and the ways to exploit it. An attacker can use tools available to the public on the Internet and does not need to write any software to exploit the vulnerability. Minimal skill is required and no special equipment is required. Despite Cisco specifically inviting such reports, Cisco has received no actual reports of malicious exploitation of this problem.
This vulnerability notice was posted on Cisco's World Wide Web site:
http://www.cisco.com/warp/public/770/iossyslog-pub.shtml
This information was also sent to the following e-mail and USENET news recipients:
•
•
•
•
•
•
•
Affected Devices and Software Versions
Vulnerable devices and software versions are specified in Table 7, Affected and Repaired Software Versions. Affected versions include Releases 11.3 AA, 11.3 DB, and all 12.0 versions (including 12.0 mainline, 12.0 S, 12.0 T, and any other regular released version whose number starts with 12.0), up to the repaired releases listed in Table 7. Cisco is correcting the problem in certain special releases and will correct it in future maintenance and interim releases. See Table 7, Affected and Repaired Software Versions for details. Cisco intends to provide fixes for all affected Cisco IOS variants.
No particular configuration is needed to make a Cisco IOS device vulnerable. It is possible to filter out attack traffic by using access lists. See the "Workarounds" section for techniques. However, except at Internet firewalls, the appropriate filters are not common in customer configurations. Carefully evaluate your configuration before assuming that any filtering you have protects you against this attack.
The most commonly used or asked-about products are listed below. If you are unsure whether your device is running Cisco IOS software, log in to the device and issue the show version command. Cisco IOS software will identify itself simply as "IOS" or "Internetwork Operating System Software". Other Cisco devices will not have the show version command, or they will identify themselves differently in their output. The most common Cisco devices that run Cisco IOS software include the following:
•
•
•
•
Affected software versions, which are relatively new, are not necessarily available on every device listed above. If you are not running Cisco IOS software, you are not affected by this problem.
The following Cisco devices are not affected:
•
•
•
•
•
•
•
•
This vulnerability has been assigned Cisco bug ID CSCdk77426.
Solution
Cisco offers free software updates to correct this vulnerability for all affected customers—regardless of their contract status. However, because this vulnerability information has been disseminated by third parties, Cisco has released this notice before updates are available for all software versions. Table 7 gives Cisco's projected fix dates.
Make sure your hardware has adequate RAM to support the new software before installing it. The amount of RAM is seldom a problem when you upgrade within a major release (say, from 11.2[11]P to 11.2[17]P), but it is often a factor when you upgrade between major releases (say, from 11.2 P to 11.3 T).
Because fixes will be available for all affected releases, this vulnerability will rarely, if ever, require an upgrade to a new major release. Cisco recommends very careful planning for any upgrade between major releases. Make certain no known bugs will prevent the new software from working properly in your environment.
Further upgrade planning assistance is available on Cisco's World Wide Web site at:
http://www.cisco.com
If you have service contracts you can obtain new software through your regular update channels (generally through Cisco's World Wide Web site). You can upgrade to any software release, but you must remain within the boundaries of the feature sets you have purchased.
If you do not have service contracts, you can upgrade to obtain only the bug fixes; free upgrades are restricted to the minimum upgrade required to resolve the defects. In general, you will be restricted to upgrading within a single row of Table 7, except when no upgrade within the same row is available in a timely manner. Obtain updates by contacting one of the following Cisco Technical Assistance Centers (TACs):
•
•
•
Give the URL of this notice (http://www.cisco.com/warp/public/770/iossyslog-pub.shtml) as evidence for a free update. Non-contract customers must request free updates through the TAC. Please do not contact either "psirt@cisco.com" or "security-alert@cisco.com" for software updates.
Workarounds
You can work around this vulnerability by preventing any affected Cisco IOS device from receiving or processing UDP datagrams addressed to its port 514. This can be done either by using packet filtering on surrounding devices, or by using input access list filtering on the affected Cisco IOS device itself.
If you use an input access list, apply that list to all interfaces to which attackers may be able to send datagrams. Interfaces include not only physical LAN and WAN interfaces but also virtual subinterfaces of those physical interfaces, as well as virtual interfaces and interface templates corresponding to GRE, L2TP, L2F, and other tunneling protocols.
The input access list must block traffic destined for UDP port 514 at any of the Cisco IOS device's own IP addresses, as well as at any broadcast or multicast addresses on which the Cisco IOS device may be listening. Be sure to block both old-style "all-zeros" broadcasts and new-style "all-ones" broadcasts. It is not necessary to block traffic being forwarded to other hosts—only traffic actually addressed to the Cisco IOS device is of interest.
No single input access list works in all configurations. Know the effect of your access list in your specific configuration before activating it.
The following example shows a possible access list for a three-interface router, along with the configuration commands needed to apply the list. The example assumes input filtering is not needed, other than as a workaround for this problem:
! Deny all multicasts, and all unspecified-net broadcasts, to port 514access-list 101 deny udp any 224.0.0.0 31.255.255.255 eq 514! Deny old-style unspecified-net broadcastsaccess-list 101 deny udp any host 0.0.0.0 eq 514! Deny network-specific broadcasts. This example assumes that all of! the local interfaces are on the class B network 172.16.0.0, subnetted! everywhere with mask 255.255.255.0. This will differ from network! to network. Note that we block both new-style and old-style broadcasts.access-list 101 deny udp any 172.16.0.255 0.0.255.0 eq 514access-list 101 deny udp any 172.16.0.0 0.0.255.0 eq 514! Deny packets sent to the addresses of our own network interfaces.access-list 101 deny udp any host 172.16.1.1 eq 514access-list 101 deny udp any host 172.16.2.1 eq 514access-list 101 deny udp any host 172.16.3.3 eq 514! Permit all other traffic (default would be to deny)access-list 101 permit ip any any! Apply the access list to the input side of each interfaceinterface ethernet 0ip address 172.16.1.1 255.255.255.0ip access-group 101 ininterface ethernet 2ip address 172.16.2.1 255.255.255.0ip access-group 101 ininterface ethernet 3ip address 172.16.3.3 255.255.255.0ip access-group 101 inListing all possible addresses—especially all possible broadcast addresses—to which attack packets may be sent is complicated. If you do not need to forward any legitimate syslog traffic received on an interface, you can block all syslog traffic arriving on that interface. Remember that blocking will affect traffic routed through the Cisco IOS device as well as traffic destined to the device; if the Cisco IOS device is expected to forward syslog packets, you will have to do the detailed filtering. Because input access lists impact system performance, install them with caution—especially on systems running very near their capacity.
Software Versions and Fixes
Many Cisco software images have been or will be specially reissued to correct this vulnerability. For example, regular released Cisco IOS version 12.0(2) is vulnerable, as are interim versions 12.0(2.1) through 12.0(2.3). The first fixed interim version of Release12.0 mainline software is Release12.0(2.4). However, a special release, 12.0(2a), contains only the fix for this vulnerability and does not include any other bug fixes from later 12.0 interim releases.
If you are running Release 12.0(2) and want to fix this problem without risking possible instability presented by installing the 12.0(2.4) interim release, you can upgrade to Release 12.0(2a). Release 12.0(2a) is a "code branch" from the Release 12.0(2) base, which will merge back into the Release 12.0 mainline at Release 12.0(2.4).
Special releases, like 12.0(2a), are one-time, spot fixes, and they will not be maintained. Thus, the upgrade path from Release 12.0(2a) is to Release 12.0(3).
Table 7 specifies information about affected and repaired software versions.
Note
Table 7 Affected and Repaired Software Versions
11.2 and earlier releases—all variants
Unaffected early releases (no syslog server)
Unaffected
Unaffected
Unaffected
11.3, 11.3 T, 11.3 DA, 11.3 MA, 11.3 NA, 11.3 WA, 11.3(2)XA
11.3 releases without syslog servers
Unaffected
Unaffected
Unaffected
11.3 AA
11.3 early deployment for AS58xx
11.3(7)AA2, 8-JAN-19994
11.3(7.2)AA
11.3(8)AA, 15-FEB-1999
11.3 DB
11.3 for Cisco NRP routing blade in Cisco 6400 xDSL DSLAM
11.3(7)DB2, 18-JAN-1999
12.0
12.0 Mainline
12.0(2a), 8-JAN-1999
12.0(2.4)
12.0(3), 1-FEB-1999
12.0 T
12.0 new technology early deployment
12.0(2a)T1, 11-JAN-1999
12.0(2.4)T
12.0(3)T, 15-FEB-1999
12.0 S
ISP support; 7200, RSP, GSR
12.0(2.3)S, 27-DEC-1998
12.0(2)S5 , 18-JAN-1999
12.0 DB
12.0 for Cisco 6400 universal access concentrator node switch processor (lab use)
12.0(2)DB, 18-JAN-1999
12.0(1)W
12.0 for Catalyst 8500 and LS1010
12.0(1)W5(5a) and 12.0(1a)W5(5b) (LS1010 platform only)
12.0(1)W5(5.15)
12.0(1)W5(6) (platform support for Catalyst 8540M will be in 12.0(1)W5(7))
12.0(0.6)W5
One-time early deployment for CH-OC-12 module in Catalyst 8500 series switches
Unaffected; one-time release
Unaffected
Unaffected; To upgrade use 12.0(1)W5 releases.
12.0(1)XA3
Short-life release; merged to 12/0T at 12.0(2)T
Obsolete
Merged
Upgrade to 12.0(2a)T1 or to 12.0(3)T.
12.0(1)XB
Short-life release for Cisco 800 series; merged to 12.0 T and 12.0 (3)T
12.0(1)XB1
Merged
Upgrade to 12.0(3)T.
12.0(2)XC
Short-life release for new features in Cisco 2600, Cisco 3600, uBR7200, uBR900 series; merged to 12.0 T at 12.0(3)T
12.0(2)XC1, 7-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(2)XD
Short-life release for ISDN voice features; merged to 12.0 T at 12.0(3)T
12.0(2)XD1, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
12.0(1)XE
Short-life release
12.0(2)XE, 18-JAN-1999
Merged
Upgrade to 12.0(3)T
1 A special fix is a one-time release that provides the most stable immediate upgrade path.
2 Interim releases are tested less rigorously than regular maintenance releases; interim releases can contain serious bugs.
3 Fixed maintenance releases are on a long-term upgrade path. Other long-term upgrade paths also exist.
4 All dates in this table are estimates and are subject to change.
5 This entry is not a misprint. The 12.0(2.3)S interim release is available before the 12.0(2)S regular release.
Caveats
Caveats describe unexpected behavior or defects in Cisco IOS software releases. For information on caveats in Cisco IOS Release 12.0 T, refer to the Caveats for Cisco IOS Release 12.0 T document. All caveats in Release 12.0 are also in Release 12.0 T.
For information on caveats in Cisco IOS Release 12.0, refer to the Caveats for Cisco IOS Release 12.0 document, which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
Note
Caveats for Release 12.0(5)XQ
This section describes possibly unexpected behavior by Release 12.0(5)XQ. Only severity 1 and 2 caveats are included.
Miscellaneous
•
Booting a Cisco 1700 series router with the commands boot flash or boot system flash results in unpredictable behavior. For example, SNMP queries fail when a Cisco 1750 router is booted in 0x0 mode, although the router appears to boot up properly. To work around this problem, do not use the commands boot flash or boot system flash to boot up a Cisco 1700 series router.
•
The command session target loopback:rtp (which loops all voice data back to the originating source using Real-Time Transport Protocol [RTP] for VoIP dial peers) causes an unexpected router reload on a Cisco 1750 router. As a workaround for this problem, the command session target loopback:rtp is disabled in this release.
•
If you use the command no frame-relay payload-compress packet-by-packet to disable Stacker payload compression on an interface while the interface is up, the router might unexpectedly reload. To work around this problem, shut down the interface before disabling the feature.
Related Documentation
The following sections describe the documentation available for the Cisco 1750 router. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with the documents listed in the following sections:
•
•
Release-Specific Documents
The following documents are specific to Release 12.0. They are located on CCO and the Documentation CD-ROM:
•
–
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
–
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
To reach these documents from CCO, click on this path (under the heading Service & Support):
Technical Documents: Product Bulletins
•
As a supplement to the caveats listed in the "Caveats" section section in these release notes, see the Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T documents, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0.
–
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
–
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco 1750 router on CCO and the Documentation CD-ROM.
•
•
•
•
•
To reach Cisco 1750 documentation from CCO, click on this path (under the heading Service & Support):
Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 1750 Router
On the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 1750 Router
Feature Modules and the Quality of Service Solutions Configuration Guide
Feature modules describe new features supported by Release 12.0(5)XQ and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
To reach the Release 12.0(5)XQ feature modules:
•
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases: New Features in Release 12.0 XQ
•
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases: New Features in Release 12.0 XQ
The Quality of Service Solutions Configuration Guide is part of the Cisco IOS software document set described in the next section. This specific document is emphasized here because it relates specifically to the Cisco IOS release 12.0(5)XQ software features.
To reach the Quality of Service Solutions Configuration Guide:
•
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Configuration Guides and Command References: Quality of Service Solutions Configuration Guide
•
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Configuration Guides and Command References: Quality of Service Solutions Configuration Guide
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. These documents are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks and Cisco IOS software functionality, and they contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set: configuration guides and command references.
To reach these documents from CCO, click on this path (under the heading Service & Support):
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
To reach these documents on the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
Table 8 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
To reach the Cisco IOS documentation set from CCO, click on this path (under the heading Service & Support):
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
To reach the Cisco IOS documentation set on the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller. Resellers offer a wide variety of Cisco service and support programs that are described in the "Service and Support" section of the information packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and helpful tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•
•
•
•
•
For a copy of CCO Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
Guest
