Release Notes for Cisco 7200 Series for Cisco IOS Release 12.0 XK
February 12, 2002
Note
You can find the most current Cisco IOS documentation on Cisco Connection Online (CCO). These electronic documents may contain updates and modifications made after the hardcopy documents were printed.
These release notes for the Cisco 7000 family of routers support Cisco IOS Release 12.0(7)XK3. These release notes describe new features, memory requirements, hardware support, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(7)XK3, see the "Caveats" section, the Caveats for Cisco IOS Release 12.0 T document, and the Caveats for Cisco IOS Release 12.0 document that accompany these release notes. All caveats in Release 12.0 and Release 12.0 T are also in Release 12.0 XK. The caveats documents are updated for every maintenance release and are located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with the Cross-Platform Release Notes for Cisco IOS Release 12.0 and the Release Notes for Cisco 7000 Family for Cisco IOS Release 12.0 T located on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
•
•
Early Deployment Releases
These release notes describe the Cisco 7200 series routers for Cisco IOS Release 12.0(7)XK3, which is an early deployment (ED) release based on Cisco IOS Release 12.0 T. Early deployment releases contain fixes for software caveats and support for new Cisco hardware and software features. Table 1 shows recent early deployment releases of the Cisco 7200 series routers.
Table 1 Early Deployment Releases for the Cisco 7200 Series Routers
Release 12.0 XK3
(7)XK3
Cisco IOS Release 12.0(7)XK3 contains no additional software or hardware features.
Cisco IOS Release 12.0(7)XK3 includes caveat fixes only. For more information, see the "Caveats" section.
02/08/2002
Release 12.0 XK
(7)
QSIG for Cisco 7200 Series Routers
Cisco IOS Release 12.0(7)XK contains no additional hardware features.
01/24/2000
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0(7)XK3:
•
•
•
Image Support and Memory Requirements
Table 2 describes the memory recommendations and the images supported by Cisco IOS Release 12.1 E for the Cisco 7000 family of routers.
Hardware Supported
Cisco IOS Release 12.0(7)XK3 supports the Cisco 7200 series routers:
•
•
A hardware-software compatibility matrix is available on CCO for users with CCO login accounts. Using this matrix, you can search for supported hardware components by entering a Cisco platform and an IOS release number. The hardware-software compatibility matrix tool is available at the following URL:
http://www.cisco.com/cgi-bin/front.x/Support/HWSWmatrix/hwswmatrix.cgi
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco 7200 series router, log in to the Cisco 7200 series router and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) 7200 series Software c7200-js-mz, Version 12.0(7)XK3, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see UCisco IOS Upgrade Ordering Instructions located at:
http://www.cisco.com/warp/public/cc/pd/iosw/prodlit/957_pp.htm
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Caution
Table 4 lists the features and feature sets supported by the Cisco 7200 series routers in Cisco IOS Release 12.0(7)XK3 and uses the following conventions:
•
•
•
Note
Table 4 Feature List by Feature Set for the Cisco 7200 Series
QSIG for Cisco 7200 series routers
Yes
Yes
New and Changed Information
The following section list the new hardware and software features supported by the Cisco 7200 series routers for Release 12.0(7)XK3:
New Features in Cisco IOS Release 12.0(7)XK3
There are no new features supported in Cisco IOS Release 12.0(7)XK3.
New Features in Cisco IOS Release 12.0(7)XK2
There are no new features supported in Cisco IOS Release 12.0(7)XK2.
New Features in Cisco IOS Release 12.0(7)XK1
There are no new features supported in Cisco IOS Release 12.0(7)XK1.
New Hardware Features in Cisco IOS Release 12.0(7)XK
There are no new hardware features supported in Cisco IOS Release 12.0(7)XK.
New Software Features in Cisco IOS Release 12.0(7)XK
The following new software feature is supported by the Cisco 7200 for Release 12.0(7)XK:
QSIG for Cisco 7200 Series Routers
QSIG protocol support allows Cisco voice switching services to connect private branch exchanges (PBXs), key systems (KTs), and central office switches that communicate by using the QSIG protocol, which is becoming the standard for PBX interoperability in Europe and North America. With QSIG, Cisco networks emulate the functionality of the PSTN, and QSIG signaling messages allow the dynamic establishment of voice and data connections across a Cisco wide-area network (WAN) to a peer router, which can then transport the signaling and voice packets to a second PINX.
The Cisco voice packet network appears to the traditional QSIG PBXs as a distributed transit PBX that can establish calls to any PBX, non-QSIG PBX, or other telephony endpoint served by a Cisco gateway, including non-QSIG endpoints. When originating and terminating on QSIG endpoints, the QSIG messages are passed transparently across the network; the PBXs are responsible for processing and provisioning the supplementary services. When linking QSIG and non-QSIG endpoints served by a Cisco packet voice gateway, only basic calls are supported. In addition, all switched voice connections must be established and torn down in response to QSIG control messages.
QSIG support includes the following capabilities:
•
•
•
•
MIBs
Current MIBs
If you have an account with CCO, you can find the current list of MIBs supported by Cisco. To reach the Cisco Network Management Toolkit, log in to CCO and click Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIBs.
Deprecated and Replacement MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. Currently, OLD-CISCO-* MIBs are being converted into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in Table 5.
Important Notes
The following sections contain important notes about Cisco IOS Release 12.0(7)XK3 that can apply to the Cisco 7200 series routers.
Image Obsolescence
All Cisco 7200 series images in Cisco IOS Release 12.0(7)XK1 have been obsoleted from manufacturing.
These images are now available in Cisco IOS Release 12.0(7)XK2 and Cisco IOS Release 12.0(7)XK3.
Note
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to Cisco IOS Release 12.1(3a)E4 or later releases of Cisco IOS Release 12.1 E.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml .
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release. only.
All caveats in Cisco IOS Release 12.0 and Release 12.0 T are also in Release 12.0 XK3.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0 document on CCO and the Documentation CD-ROM.
For information on caveats in Cisco IOS Release 12.0 T, see the Caveats for Cisco IOS Release 12.0 T, which lists serverity 1 and 2 caveats and select severity 3 caveats and is located on CCO and the Documentation CD-ROM.
Note
Open for Caveats for Release12.0(7)XK3
There are no open caveats specific to Cisco IOS Release 12.0(7) XK3 that require documentation in the release notes.
Resolved Caveats for Release12.0(7)XK3
All the caveats listed in this section are resolved in Cisco IOS Release 12.0(7) XK3. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
SNMP
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Related Documentation
The following sections describe the documentation available for the Cisco 7200 series routers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Technical Documents
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T, which contain caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.0 and Cisco IOS Release 12.0 T.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco 7200 series on CCO and the Documentation CD-ROM:
•
•
•
•
•
On CCO at:
Technical Documents: Documentation Home Page: Core/High-End Routers
On the Documentation CD-ROM at:
Cisco Product Documentation: Core/High-End Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.0 XK and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
Table 6 describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
On CCO at:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Obtaining Documentation
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml .
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly. Therefore, it is probably more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Registered CCO users can order the Documentation CD-ROM and other Cisco Product documentation through our online Subscription Services at http://www.cisco.com/cgi-bin/subcat/kaojump.cgi.
Nonregistered CCO users can order documentation through a local account representative by calling Cisco's corporate headquarters (California, USA) at 408 526-4000 or, in North America, call 800 553-NETS (6387).
Obtaining Technical Assistance
Cisco provides Cisco Connection Online (CCO) as a starting point for all technical assistance. Warranty or maintenance contract customers can use the Technical Assistance Center. All customers can submit technical feedback on Cisco documentation using the Web, e-mail, a self-addressed stamped response card included in many printed documents, or by sending mail to Cisco.
Cisco Connection Online
Cisco continues to revolutionize how business is done on the Internet. Cisco Connection Online is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
CCO's broad range of features and services helps customers and partners to streamline business processes and improve productivity. Through CCO, you will find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online support services, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on CCO to obtain additional personalized information and services. Registered users may order products, check on the status of an order and view benefits specific to their relationships with Cisco.
You can access CCO in the following ways:
•
•
•
–
–
You can e-mail questions about using CCO to cco-team@cisco.com.
Technical Assistance Center
The Cisco Technical Assistance Center (TAC) is available to warranty or maintenance contract customers who need technical assistance with a Cisco product that is under warranty or covered by a maintenance contract.
To display the TAC web site that includes links to technical support information and software upgrades and for requesting TAC support, use www.cisco.com/techsupport.
To contact by e-mail, use one of the following:
In North America, TAC can be reached at 800 553-2447 or 408 526-7209. For other telephone numbers and TAC e-mail addresses worldwide, consult the following web site: http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml.
Software Configuration Tips on the Cisco TAC Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/technotes/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Service & Support: Technical Assistance Center: Technical Tips. You must have a CCO account to access this link.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
