Release Notes for the Cisco MC3810 for Cisco IOS Release 12.0(5)XK2
July 15, 2002
These release notes for the Cisco MC3810 multiservice access concentrator support Cisco IOS Release 12.0(5)XK2 and describes new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents. Cisco IOS Release 12.0(5)XK2 is based on Cisco IOS Release 12.0(5)T.
For a list of software caveats that apply to Release 12.0(5)XK2, refer to the "Caveats" section.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
As part of an enterprise backbone or as customer premises equipment (CPE) to service provider-managed network services, the Cisco MC3810 multiservice access concentrator reduces operating costs and complexity, and increases network throughput and performance. Cisco IOS software fully supports the Cisco MC3810 for multiprotocol routing, bridging, and Systems Network Architecture (SNA).
To make file management easier, the Cisco MC3810 provides a complete file system for software images, message files, and reports. The standard Flash memory size is 8 MB, and a 16-MB upgrade option can simultaneously hold two code images for fail-safe upgrades.
You can manage the Cisco MC3810 by using standard Cisco management platforms and facilities such as CiscoView and the native remote log-in facilities provided by Telnet and rlogin. Three types of configuration interfaces are provided:
•
Cisco CLI
•
•
The HTTP-based interface allows configuration from any Web browser such as Netscape Navigator or Microsoft Explorer. The SNMP MIB allows management of the Cisco MC3810 from SNMP managers, such as HP OpenView.
System Requirements
•
•
Memory Requirements
Table 1 Memory Requirements for the Cisco MC3810
IP
mc3810-i-mz
4 MB1
16 MB2
RAM
IP Plus
mc3810-is-mz
8 MB
32 MB
RAM
IP Plus/IP Sec 56
mc3810-is56i-mz
8 MB
32 MB
RAM
IP Plus/ATM/IP Sec 56
mc3810-a2is56i-mz
8 MB
32 MB
RAM
IP Plus/ATM/MCM H323
mc3810-a2isx-mz
8 MB
32 MB
RAM
IP Plus/ATM/MCM H323/IP Sec 56
mc3810-a2isx56i-mz
8 MB
32 MB
RAM
IP/ATM Plus
mc3810-a2is-mz
8 MB
32 MB
RAM
Enterprise Plus
mc3810-js-mz
8 MB
32 MB
RAM
Enterprise/ATM Plus
mc3810-a2js-mz
8 MB
32 MB
RAM
Enterprise Plus/ATM/MCM H323
mc3810-a2jsx-mz
8 MB
32 MB
RAM
1 Required flash memory for the IP feature set: The standard configuration includes 8 MB of flash memory.
2 Required DRAM for the IP feature set: The standard configuration includes 32 MB of DRAM.
Hardware Supported
Cisco IOS Release 12.0(5)XK1 supports the Cisco MC3810 multiservice access concentrator.
Determining the Software Version
To determine the version of Cisco IOS software running on your Cisco MC3810, log in to the router and enter the show version user EXEC command:
router>show versionCisco Internetwork Operating System Software IOS (tm) MC3810 Software (mc3810-js-mz), Version 12.0(5)XK1, RELEASE SOFTWAREUpgrading to a New Software Release
For general information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification (#703: 12/97) on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click on Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97).
This product bulletin does not contain information specific to Cisco IOS Release 12.0(5)XK1 but provides general upgrade information that may apply to Cisco IOS Release 12.0(5)XK1.
Feature Set Table
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
lists the features and feature sets supported by the Cisco MC3810 in Cisco IOS Release 12.0(5)XK1 and uses the following conventions:
•
•
Note
Table 3 Feature List by Feature Set for the Cisco MC3810
Frame Relay-ATM Interworking (FRF.5)
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
PPP Over ATM
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
RFC 1483
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
rtVBR, nrtVBR, CBR, UBR
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Structured CES1
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Traffic Shaping
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
UNI 3.1
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
UNI 4.0 (with ILMI)
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
APPN
No
No
No
No
No
No
No
No
No
No
APPN High-Performance Routing
No
No
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
No
No
BAN for SNA Frame Relay Support
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bisync
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bridging-Code Rework
No
No
No
No
No
No
No
No
No
No
Caching and Filtering
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw (RFC 1795)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Enhanced Load Balancing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ Peer Clusters
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw Version 2 (RFC 1266)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DLSw+ RSVP Bandwidth Reservation
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Downstream PU Concentration (DSPU)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay SNA Support
(RFC 1490)No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NCIA
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NetView Native Service Point
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Polled Async
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QLLC
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Integration
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC Transport (STUN)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SDLC-to-LAN Conversion (SDLLC)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNA and NetBIOS WAN Optimization
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRB/RSRB
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SRT
No
No
No
No
Yes
Yes
Yes
No
No
Yes
SRTLB
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TG/COS
No
No
No
No
No
No
No
No
No
No
TN3270
No
No
No
No
No
No
No
Yes
Yes
No
TN3270 LU Nailing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 Server Enhancements
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BGP4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
EGP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced IGRP Optimizations
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ES-IS
No
No
No
No
No
No
No
Yes
Yes
Yes
GRE VPN
No
No
No
No
No
No
No
Yes
Yes
Yes
IGRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IS-IS
No
No
No
No
No
No
No
Yes
Yes
Yes
Named IP Access Control List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Address Translation (NAT)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NHRP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On Demand Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Not-So-Stubby-Areas (NSSA)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF On Demand Circuit (RFC 1793)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Protocol-Independent Multicast (PIM)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Policy-Based Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RIP Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Apollo Domain
No
No
No
No
No
No
No
Yes
Yes
Yes
AppleTalk Phase 2
No
No
No
No
No
No
No
Yes
Yes
Yes
Banyan VINES
No
No
No
No
No
No
No
Yes
Yes
Yes
Concurrent Routing and Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet IV
No
No
No
No
No
No
No
Yes
Yes
Yes
DECnet V
No
No
No
No
No
No
No
Yes
Yes
Yes
GRE
No
No
No
No
No
No
No
Yes
Yes
Yes
Integrated Routing and Bridging (IRB)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LAN Extension Host
No
No
No
No
No
No
No
No
No
No
Multiring
No
No
No
No
No
No
No
No
No
No
Novell IPX
No
No
No
No
No
No
No
Yes
Yes
Yes
OSI
No
No
No
No
No
No
No
Yes
Yes
Yes
Source-Route Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent and Translational Bridging
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VLANs (ISL & IEEE 802.10)
No
No
No
No
No
No
No
No
No
No
XNS
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
AutoInstall
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Automatic Modem Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HTTP Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RMON Events and Alarms
No
No
No
No
No
No
No
No
No
No
RMON Full
No
No
No
No
No
No
No
No
No
No
SNMP version 3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Request
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application Specific Routing
No
No
No
No
No
No
No
No
No
No
Generic Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
H.323 Hot Standby Routing Protocol (HSRP)
No
No
No
No
Yes
No
No
No
No
Yes
Multimedia Conference Manager (H.323)
No
No
No
No
Yes
No
No
No
No
Yes
Process MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Random Early Detection (RED)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Response Time Reporter Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RSVP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AURP
No
No
No
No
No
No
No
Yes
Yes
Yes
IPX RIP
No
No
No
No
No
No
No
Yes
Yes
Yes
NLSP
No
No
No
No
No
No
No
Yes
Yes
Yes
RTMP
No
No
No
No
No
No
No
Yes
Yes
Yes
SMRP
No
No
No
No
No
No
No
Yes
Yes
Yes
SRTP
No
No
No
No
No
No
No
Yes
Yes
Yes
LAT
No
No
No
No
No
No
No
Yes
Yes
Yes
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ARAP 1.0/2.0
No
No
No
No
No
No
No
Yes
Yes
Yes
Asynchronous Master Interfaces
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATCP
No
No
No
No
No
No
Yes
Yes
Yes
Yes
CPPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CSLIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DHCP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Pooling
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX and ARAP on Virtual Async Interfaces
No
No
No
No
No
No
Yes
Yes
Yes
Yes
IPXCP
No
No
No
No
No
No
Yes
Yes
Yes
Yes
MacIP
No
No
No
No
No
No
Yes
Yes
Yes
Yes
NASI
No
No
No
No
No
No
Yes
Yes
Yes
Yes
NetBEUI over PPP
No
No
No
No
No
No
Yes
Yes
Yes
Yes
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SLIP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Airline Product Set (ALPS)
No
No
No
No
No
No
No
No
No
No
Cisco IOS File System
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco MC3810 - IGX 8400 Interworking
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Entity MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Expression MIB
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OSPF Point to Multipoint
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Per Port Debugging (Conditionally Triggered Debugging)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Priority Queuing Support Enhancement for Cisco MC3810-IGX Interworking
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Manager
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Security
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Additional Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Authenticating ACLs
No
No
No
No
No
No
No
No
No
No
Automated Double Authentication
No
No
No
No
No
No
No
Yes
Yes
Yes
Certificate Authority Interoperability
No
No
No
No
No
No
No
No
No
No
Context-Based Access Control (CBAC)
No
No
No
No
No
No
No
No
No
No
Extended Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
No
No
No
No
No
No
No
No
No
IPSec Network Security
No
No
Yes
No
No
Yes
Yes
No
No
No
Kerberized Login
No
No
No
No
No
No
No
Yes
Yes
Yes
Kerberos V Client Support
No
No
No
No
No
No
No
Yes
Yes
Yes
Lock and Key
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Mac Security for Hubs
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Md5 Routing Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS-CHAP Support
No
No
No
No
No
No
No
Yes
Yes
Yes
Named Method Lists for AAA Authentication & Accounting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Network Layer Encryption (40-bit or Export Controlled 56-bit DES)
YEs
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
RADIUS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Router Authentication
No
No
No
No
No
No
No
No
No
No
Sublock Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TACACS+
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced ATM VC Configuration and Management
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Multiple ISDN Switch Types
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LAT
No
No
No
No
No
No
No
Yes
Yes
Yes
Rlogin
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TN3270
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Pad
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Xremote
No
No
No
No
No
No
No
Yes
Yes
Yes
Analog Signaling
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Call Detail Records (CDR)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 CAS Signaling2
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Fancy Queuing on Frame Relay or Cisco HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
G.726 (ADPCM)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Gain Control
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN PRI QSIG Voice Signaling3
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Local Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Local Voice Busy Out
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple Ring Tones
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN BRI Voice3
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Facility Data Link on Multiflex Trunk
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multi-length Dial Patterns
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Off-Net Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
On-Net/Off-Net Call Rerouting
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
OPX Ring-Through
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Pass-Through Voice
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Permanent Connection
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PLAR
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Preference-based Hunt Groups
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Remote Dialing
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
T1 CAS Signaling
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Transparent CCS
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice Activity Detection
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over ATM
No
No
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Voice over Frame Relay
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over Frame Relay Using FRF.11 and FRF.12
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over HDLC
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over IP
No
No
No
No
No
No
No
No
No
No
Bandwidth-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Custom and Priority Queuing4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial Backup
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dial-on-Demand
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Header, Link and Payload Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Snapshot Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Weighted Fair Queuing4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Always On/Direct ISDN
No
No
No
No
No
No
No
No
No
No
ATM LAN Emulation: Decnet Routing and Banyan Vines Support
No
No
No
Yes
Yes
No
Yes
No
Yes
Yes
ATM LAN Emulation: (HSRP and SSRP)
No
No
No
Yes
Yes
No
Yes
No
Yes
Yes
ATM: Rate Queues for SVC per Subinterface
No
No
No
Yes
Yes
No
Yes
No
Yes
Yes
ATM: UNI 3.1 Signaling for ATM
No
No
No
Yes
Yes
No
Yes
No
Yes
ATM: UNI 4.0
No
No
No
Yes
Yes
No
Yes
ATM SVCs for Voice, Video and Data
No
No
No
Yes
Yes
No
Yes
No
Yes
Yes
Combinet Packet Protocol (CPP)
No
No
No
No
Yes
No
Yes
No
No
Yes
Dialer Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Facility Data Link Capabilities on Multiflex Trunk
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Compression (FRF.9)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay/ATM Internetworking Services (FRF.8)
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Frame Relay SVCs Support (DTE)
No
No
No
No
No
No
No
No
No
No
Frame Relay Traffic Shaping
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Switching
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay UNI
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay-ATM Interworking (FRF.5)
No
No
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Half Bridge/Half Router For CPP And PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HDLC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Integrated BRI Backup3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPXwan 2.0
No
No
No
No
No
No
No
Yes
Yes
Yes
ISDN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Advise of Charge
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Leased Line ISDN at 128 kbps
No
No
No
No
No
No
No
No
No
No
MPPC-MS PPP Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS Callback
No
No
No
No
No
No
No
No
No
No
Multichassis Multilink PPP (MMP)
No
No
No
No
No
No
No
Yes
Yes
Yes
National ISDN Switch Type
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SMDS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stackable Home Gateway
No
No
No
No
No
No
No
No
No
No
Switched 56
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Private Dialup Network (VPDN)
No
No
No
No
No
No
No
Yes
Yes
No
Voice over Frame Relay Using FRF.11 and FRF.12
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 over Frame Relay (Annex G)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs
and SVCsYes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1 Voice signaling on CES is not available.
2 Includes T1 CAS protocols, UK Standard CAS (Mercury protocol), and CEPT standard E&M.
3 When the older motherboard (SCB 6.06) is used with this feature, serial port 1 cannot be used. When the new motherboard (SCB 6.07 and later versions) is used, serial port 1 can be used in DCE mode only.
4 Applicable to data-only interfaces.
Cisco IOS File System
To make file management easy, the Cisco MC3810 provides a complete file system for software images, message files and reports. The standard Flash memory size is 8 MB, and a 16-MB upgrade option can simultaneously hold two code images for fail-safe upgrades.
New and Changed Information
The following sections list new information about the Cisco MC3810 in Cisco IOS Release 12.0(5)XK1.
New Features in Release 12.0(5)XK1
The following hardware and software enhancements are available for the Cisco MC3810 in Cisco IOS Release 12.0(5)XK1.
Video over ATM SVCs and PVCs
Video over ATM switched virtual circuits (SVCs) expands the capabilities of the Cisco MC3810 multiservice access concentrator to provide cost-effective, dynamic, and flexible video conferencing system support. By using a plug-in video dialing module (VDM) to provide an RS-366 dialing interface to an H.320 video codec, the Cisco MC3810 automatically accepts dial-out requests from the video system. The codec connects to either of the Cisco MC3810 serial ports and also to the Cisco MC3810 RS-366 dial-up port.
The current feature also improves permanent virtual circuit (PVC) support by permitting PVC connections with automatic connection through a serial port. Each codec must place a call to the other video conferencing system before the expiration of the video codec time-out period (set on the codec, usually one minute). By using a video dial map, each system reconciles the dialed number with a PVC that has already been configured, allowing fast connectivity.
FRF.5 Enhancement for the Cisco MC3810
The Frame Relay-ATM Network Interworking (FRF.5) feature that was first introduced in 11.3(1)MA has been enhanced to allow setting the mode of the Discard Eligibility and Cell Loss Priority fields as defined in the FRF.5 implementation agreement.
Network Interworking (FRF.5) allows the transparent tunneling of Frame Relay user traffic and PVCs over ATM. This function is often used to link Frame Relay networks over an ATM backbone. The most distant nodes must be configured to interoperate with one another—in contrast to Service Interworking—because intact Frame Relay frames are sent over the ATM network. The ATM backbone is used as an alternative to a leased line and provides cost savings over leased lines. There can be a one-to-one relationship between Frame Relay and ATM PVCs, or multiple Frame Relay PVCs can be multiplexed into a single ATM PVC.
FRF.8 for the Cisco MC3810
FRF.8 Frame Relay to Asynchronous Transfer Mode (ATM) Service Interworking allows connection of Frame Relay traffic across high-speed ATM trunks using ATM standard Network and Service Interworking. Cisco IOS Release 12.0(5)XK introduces Frame Relay-to-ATM Service Interworking for data transfer, outlined in Frame Relay Forum implementation agreement FRF.8 and designed for the Cisco MC3810 multiservice access concentrator.
Service Interworking connects a Frame Relay network to an ATM network while the networks function independently, allows bidirectional PVC protocol conversion functions, and provides a standards-based solution for service providers, enterprises, and end users.
This feature supports two modes of operation of the interworking function (IWF) for upper-layer user protocol encapsulation—transparent mode and translation mode:
•
•
Multimedia Conference Manager (MCM H323)
Use the Multimedia Conference Manager to enable your current internetwork to route bit-intensive data, such as audio telephony, video and audio telephony, and data conferencing by using existing telephone and ISDN links—without degrading the network's current level of service. The Multimedia Conference Manager feature provides H.323 application options previously unavailable. By using Multimedia Conference Manager, you can implement H.323-compliant applications on existing networks in an incremental fashion without upgrades. This feature also provides a rich list of networking capability, including:
•
•
The Multimedia Conference Manager feature provides network administration mechanisms to support H.323 applications without impacting the mission critical applications running on today's networks. Multimedia Conference Manager is implemented on Cisco IOS software. Multimedia Conference Manager provides the network administrator with these abilities:
•
•
•
•
•
Multimedia Conference Manager has two principal functions: gatekeeper and proxy. These functions are unique to Multimedia Conference Manager. Similar robust features are currently not available in other vendor solutions.
Gatekeeper subsystems provide:
•
•
•
•
•
Starting with Cisco IOS Releases 11.3(6)Q and 11.3(7)NA and later releases, you can configure Cisco gatekeepers to use the Cisco Hot Standby Routing Protocol (HSRP), so that when one gatekeeper fails, the standby gatekeeper assumes its role.
Proxy subsystems provide:
•
•
•
•
Voice and Data over ATM Switched Virtual Circuits
VoATM SVCs allow the Cisco MC3810 to transfer voice and data dynamically and as needed—without tying up the resources required for static, manually provisioned permanent virtual circuits (PVCs). An SVC connection is initiated for each call, and each request includes bandwidth and quality-of-service (QoS) information required for the connection. SVCs are ideal for networks that are highly interconnected, where scalability is essential, and in situations where traffic is sporadic. In addition, service providers often proffer more advantageous, use-based pricing options for SVCs.
VoATM (voice over ATM) using SVCs on the Cisco MC3810 includes all of the voice features that the Cisco MC3810 supports for PVCs and for Frame Relay transport. Like other Cisco voice implementations, VoATM is based on dial peers and uses ATM Adaptation Layer 5 (AAL5). ATM SVC service operates much like X.25 SVC service, although ATM allows much higher throughput. It requires a signaling protocol between a router or multiservice access concentrator and ATM switch. The ATM signaling software provides a method of dynamically establishing, maintaining, and clearing ATM connections at the User-Network Interface (UNI). In UNI, the router serves as the user and the ATM switch is considered the network. The router does not perform call-level routing. Instead, the ATM switch does the ATM call routing, and the router directs packets through the resulting circuit.
Important Notes
This section contains important information about the use of your Cisco IOS Release 12.0(5)XK1 software.
Cisco IOS release 12.0(5)XK1 is supported on all Cisco 2600, 3600, and MC3810 platforms and incorporates a number of bug fixes and enhancements. These include improvements to the echo canceller located within the DSP firmware. These improvements result in better performance during off-net calls and within noisy environments.
Refer to the Caveats section for details on individual bug fixes found within this release.
Using the Cisco MC3810 with QSIG or BRI
Serial port 1 is restricted to DCE operation when the following occurs:
•
•
•
Using the Cisco MC3810 with the PSTN
This section describes important notes regarding use of the Cisco MC3810 with the Public Switched Telephone Network (PSTN).
Connections to a PSTN
Be careful when connecting switched voice ports on the Cisco MC3810 directly to the PSTN because improper configurations can expose the corporate network to telephone fraud.
Switched Access from the PSTN
The Cisco MC3810 has the capability to connect a user from the PSTN directly to the corporate wide-area telephone network. Using the Cisco MC3810 as a phone switch, you can configure the access concentrator to switch the user to any location in that network, even to remote locations that are connected again to another PSTN. However, the Cisco MC3810 does not provide any mechanism to restrict users from calling after they are connected. Without proper network design, this condition could result in the unauthorized use of the corporate network for making calls at the corporation's expense. To prevent this from occurring, you should not connect a switched voice interface on the Cisco MC3810 directly to the PSTN. Instead, connect the interface to a PBX that implements a security scheme that prevents unauthorized use.
Non-Switched Calls
The same opportunity for illicit use does not exist for non-switched call types, such as pass-through connections (although the possibility for fraud does exist at the direct contact point). Pass-through calls create a path to a single location specified by the network administrator. For example, you might use a pass-through connection to pass a trunk from a PBX to the PSTN. In this case, the trunk on the PBX always passes straight through the Cisco MC3810 to the PSTN. As a result, the necessary security is provided by the PBX.
Caveats
Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 and Release 12.0 T are also in Release 12.0(5)XK1.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0 that describes caveats affecting all maintenance releases.
For information on other caveats that also apply to this release, see Caveats for Cisco IOS Release 12.0 T which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM
Note
Caveats for Release 12.0(5)XK2
This section describes possibly unexpected behavior by Cisco IOS Release 12.0(5)XK2.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Caveats for Release12.0(5)XK1
This section describes possibly unexpected behavior by Release 12.0(5)XK1. Unless otherwise noted, these caveats apply to all 12.0 releases up to and including 12.0(5)XK1.
Basic System Services
•
Brings IOS up to RFC 2217 spec. Adds in extra flow control for faxing through IOS. Corrects [now ignores] software flow control issue.
•
Error messages are generated by RSP routers with VIP cards in some cases. The error messages are generally benign, indicating temporarily out of memory situations, which are then recovered from.
•
SegV Exception in peer_list_sum, NTP related
When utilizing ntp private mode and control type messages for remote query, it is possible to see a router crash or traceback messages.
•
If sh run or wr t are issued at exactly the same time from two different VTY, one session may finish before the other and trash a variable that still need to be used by the 1st session which causes a router crash.
Workaround: Don't do sh run at the same time from 2 VTY's.
•
If you have a Vip2-50 with a ESA module for hardware encryption, you might be seeing this problem. Execute show version and look for 12.0.5, if rsp-dsv56i-mz.120-5 show interface stat and look for...
Router # sh int stat FastEthernet4/0/0 Switching path Pkts In Chars In Pkts Out Chars Out Processor 169 17028 5866912 2018892867 Route cache 5866778 2019797528 0 0 ^^^notice no route cache^^ Distributed cache 0 0 0 0 Total 5866948 2019815576 5866912 2018892867Serial5/0/0 Switching path Pkts In Chars In Pkts Out Chars Out Processor 5964672 1993916338 530 37168 Route cache 0 0 5958298 1967889708 ^^^notice no route cache^^ Distributed cache 0 0 0 0 Total 5964672 1993916338 5958828 1967926876•
The use of the command backup interface bri 0 breaks the tdm-group command under the T1/E1 controllers in Cisco IOS 12.0(5)XK. Removing the command, saving the config to nvram, and reloading doesn't resolve the problem. The user must either:
write erase and reload
-or-
boot the router ignoring vnram
Reconfigure the router without the faulty command. The work-around is to disable ISDN backup.
IBM Connectivity
•
A Cisco router using Advanced Peer-to-Peer Networking (APPN) may consume excessive CPU while issuing messages during a Locate storm. In particular, message: XXXTPD02_LOGMSG_01 can be issued repetitively.
•
APPN Network Node router fails to allocate the conwinner session of its dual CP-CP session with an adjacent End Node. The conloser session will be setup correctly, but the conwinner sessions fails with sense 80140003 as indicated in the debug appn ss. The problem results after changing an adjacent Network Node to an End Node. The workaround is to cycle the link for this End Node.
•
Router may crash when creating a circuit history for a DLSw lite circuit.
Workaround is to disable circuit history logging by configuring no dlsw history-log.
Interfaces and Bridging
•
If an interface on a HSSI 1 port (PA-H or H1T+) card goes down/down and you see the following error message, you may be experiencing this problem:
%MUSELIX-1-STOPFAIL: XXXX: Stop Failed at disable port (XXXX = the interface affected) %MUSELIX-1-STARTFAIL: XXXX: Start Failed at enable port MUESLIX-1-FAILURE_CAUSE: SerialX/X:This problem is caused by several factors.
Once it falls into this state, execute the following (undocumented) test commands -- (<CR> is a carriage return):
term len 0<CR> sh cont h 1/0<CR> test tpu b<CR> 1/0<CR> g<CR> x<CR> y<CR> r<CR> s<CR> 3<CR> q<CR> test tpu b<CR> 1/1<CR> g<CR> x<CR> y<CR> r<CR> s<CR> 3<CR> q<CR> test len 24<CR>
An example of this process can be obtained by using Bug Navigator II.
Note
Resolved Caveats for Release12.0(5)XK1
All caveats listed in this section are resolved in Release 12.0(5)XK1. This section only describes severity 1 and severity 2 caveats.
•
Crashed happened on routing_svc, switching_svc, and bridging_svc HAWK testing after the configuration is done. It is in version 12.0(5.1)PI6.
The same problem is also seen on 12.0(19990715:065145) [BLD-v120_5_xk_throttle.990714 109] where is stack trace is the same.
•
Regression of BVM (qsig) failed to pass the SETUP to the PBX (i.e., making an outgoing call). Apparently, some code changes for other boxes introduced the problem. A new field called bchan_reassigned is added to the isdn_bri structure. This structure is used to make calls to routines such as process_bri_call. For the MC3810, we have an api (ccsapi.c) to translate ccs api messages to isdn host messages, the person(s) who add this field forgot to initialize the field for this api, and thus contains garbage.
This is causing the "UKNOWN BCHANNEL" problem shown by the regression.
•
Clocking configuration information may be over written if the hw work-around software is running while a clocking config change is made.
•
Cannot configure more than one channel-group on E1.
•
In FRF8, the IWF is setting the DE bit of the FR frame only if the last cell of a AAL5 pack has the CLP bit set. According to the FRF.8 spec, the DE bit should be set if any of the cells of a fragmented AAL5 packet has the CLP bit set.
•
FRF.8 ATM PVCs cannot be removed if the corresponding FR VCs are not configured on the IWF.
Related Documentation
The following sections describe the documentation available for the Cisco MC3810. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Releases 12.0 T and 12.0, on which Release 12.0(5)XK is based and are located on CCO and the Documentation CD-ROM:
•
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Service & Support: Technical Documents
•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see Caveats for Cisco IOS Release 12.0 T which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T. Caveats for Release 12.0(5)T apply to Release 12.0(5)XK.
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Platform-Specific Documents
These documents are available for the Cisco MC3810 on CCO and on the Documentation CD-ROM.
•
•
•
•
•
•
On CCO:
Service & Support: Documentation Home Page: Access Servers and Access Routers: Multiservice Access Concentrators
On the Documentation CD-ROM:
Cisco Product Documentation: Access Servers and Access Routers: Multiservice Access Concentrators
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.0 T, 12.0(5)XK, and other ED releases and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Document Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Cisco IOS Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set which is available in electronic form and in printed form upon request.
Note
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" in Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you read Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-7028-02 Rev. B1
Guest
