Release Notes for Cisco AS5300 Series Universal Access Servers for Cisco IOS Release 12.0 XJ
Ocotber 4, 1999
These release notes for Cisco AS5300 series universal access servers support Cisco IOS Release 12.0(4)XJ. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code or related documents.
For a list of the software caveats that apply to Release 12.0(4)XJ, see the Caveats for Cisco IOS Release 12.0 T document that accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM. For additional information about caveats that apply to Release 12.0(4)XJ, see the "Caveats" section of this document.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
The Cisco AS5300 universal access server is a versatile data communications platform that performs two functions in a single modular chassis depending on the installed feature cards and IOS images:
•
Remote Access Server
•
The access server is intended for Internet service providers (ISPs), telecommunications carriers, and other service providers that offer managed Internet connections, as well as medium to large sites that provide both digital and analog access to users on an enterprise network. By terminating both analog and digital calls on the same chassis simultaneously, the access server provides a clear, simple, and easy migration path from analog dial access services to digital dial access services.
For information on new features and Cisco IOS commands supported by Release 12.0(4)XJ, see the "New and Changed Information" section and the "Related Documentation" section.
Early Deployment Releases
These release notes describe only features unique to Release 12.0(4)XJ for Cisco AS5300 series universal access servers and do not describe features that are available in Release 12.0 or other Release 12.0 Early Deployment (ED) releases. Release 12.0(4)XJ is an Early Deployment (ED) release based on Release 12.0 and announces fixes to software caveats and support for new Cisco hardware or software.
For information about features in Release 12.0, see Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
For information about features in other ED releases, see .
For information about features in other platforms, see Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
System Requirements
This section describes the system requirements for Release 12.0(4)XJ:
•
•
Memory Requirements
Table 2 describes the memory requirements for the Cisco AS5300 platform feature sets supported by Cisco IOS Release 12.0(4)XJ.
Note
Hardware Supported
lists the interfaces and modem cards supported by the Cisco AS5300 series universal access servers using Cisco IOS Release 12.0(4)XJ. For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Table 3 Supported Interfaces for the Cisco AS5300 Universal Access Servers
Ethernet RJ-45
MICA modems
Ethernet/Fast Ethernet (RJ-45)
Microcom 56K modems
ISDN PRI
None
E1-G.703/G.704
None
Channelized T1 (4 ports) without serial support
None
Channelized T1 (4 ports) with 4 serial ports
None
Channelized T1 (8 ports) with 4 serial ports
None
Channelized E1 (4 ports) without serial support
None
Channelized E1 (4 ports) with 4 serial ports
None
Channelized E1 (8 ports) with 4 serial ports
None
Voice over IP (VoIP) feature card (VFC)
None
1 The number in the "In" column indicates the Cisco IOS release in which the interface was first introduced. If a cell in this column is empty, the interface was included in the base release.
Determining the Version of Your Software Release
To determine the version of Cisco IOS software currently running on your Cisco AS5300 universal access server, log in to the Cisco AS5300 and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 5300 Software (c5300-js-n), Version 12.0(4)XJ, RELEASE SOFTWAREUpgrading to a New Software Release
For information on upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 T Upgrade Paths and Packaging Simplification (#819: 1/99) on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 12.0, click Cisco IOS Software Release 12.0 T Upgrade (#819: 1/99).
Modem Code Software
Cisco IOS Release 11.2(2) and later releases, including Release 12.0(4)T, include bundled modem code for the Cisco AS5300, which is the firmware or portware that runs on the Microcom 12-port and MICA 6-port modem cards. Modem code is bundled with the Cisco IOS software image to eliminate the need to store separate modem code. When the Cisco AS5300 access server starts, the Cisco IOS software unpacks the modem code and loads the proper code onto the modem cards.
The show modem mapping command lists all versions of modem code running on the modem modules, residing in system Flash, and bundled with Cisco IOS software. Enter the show modem mapping command to determine if you need to update your modem code files.
Note
The modem code release notes are on CCO and the Documentation CD-ROM. You can reach the release notes on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
You can reach the release notes on the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
Feature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Release 12.0(4)XJ supports the same feature sets as Release 12.0(4)T, but Release 12.0(4)XJ can include new features supported by the Cisco AS5300 series universal access servers.
CautionCisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
lists the features and feature sets supported by the Cisco AS5300 series universal access servers in Cisco IOS Release 12.0(4)XJ and uses the following conventions:
•
•
•
.
Table 5 Selected Features Supported by the Cisco AS5300 Universal Access Server
3DES1
IPX/
AT/
DEC
IPX/
AT/
DEC
Plus
Plus
prise Plus 40
prise Plus IPSec 56APPN High-Performance Routing
No
No
No
No
No
No
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
Bisync Enhancements:
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Cisco MultiPath Channel (CMPC)
No
No
No
No
No
No
No
No
No
No
No
No
DLSw+ Enhancements:
–
–
–
–
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
FRAS Enhancements:
–
–
–
–
–
–
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
RIF Passthru in DLSw+
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
TN3270 LU Nailing
No
No
No
No
No
No
No
No
No
No
No
No
TN3270 Server Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
Token Ring LANE
No
No
No
No
No
No
No
No
No
No
No
No
Tunneling of Asynchronous Security Protocols
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DRP Server Agent Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Easy IP (Phase 1)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Easy IP (Phase 2) DHCP Server
(1)
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
No
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TCP Enhancements:
–
–
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DECnet Accounting
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX Named Access Lists
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX SAP-after-RIP
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NLSP Enhancements
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
NLSP Multicast Support
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco Call History MIB Command-Line Interface
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS Internationalization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Process MIB
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN MIB RFC 2127
(1)
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
No
SNMPv2C
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMPv3
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP Inform Requests
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Time-Based Access Lists
(1)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VPDN MIB
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
VPDN MIB and Syslog Facility
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
No
No
No
No
No
No
No
No
No
PIM Version 2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI String Search
(1)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BERT/TDM
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Automated Double Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Certificate Authority Interoperability
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
Double Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
No
No
No
No
No
No
No
Yes
Yes
HTTP Security
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Internet Key Exchange Security Protocol
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
IPSec Network Security
No
No
No
Yes
Yes
No
No
No
No
No
Yes
Yes
IPSec with Triple-DES
(2)
No
No
No
No
Yes
No
No
No
No
No
No
Yes
MS-CHAP Support
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Named Method Lists for AAA Authentication and Accounting
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TCP Intercept
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Vendor-Proprietary RADIUS —Additional Attributes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLNS and DECnet Fast Switching over PPP
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
DECnet/VINES/XNS over ISL:
–
–
–
No
No
No
No
No
No
No
Yes
Yes
No
No
No
Fast-Switched Policy Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
No
No
No
No
No
No
No
No
No
Telnet Extensions for Dialout
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Templates for Protocol Translation
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
SS7/CCS7 Dial Access Solution (DAS)
(3)
No
Yes
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Large Scale Dialout
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Voice over IP
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Store and Forward Fax
(4)XJ
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ATM MIB Enhancements
No
No
No
No
No
No
No
No
No
No
No
No
PAD Enhancements
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
PAD Subaddressing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Always On/Dynamic ISDN (AO/DI)
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dialer Watch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dynamic Multiple Encaps for Dial-in over ISDN
(4)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 R2 Country Support3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
E1 R1 Support for only Taiwan4
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Layer 2 Forwarding—Fast Switching
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Leased-Line ISDN at 128 kbps
No
No
No
No
No
No
No
No
No
No
No
No
ISDN LAPB-TA
(4)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Microsoft Point-to-Point Compression (MPPC)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
MS Callback
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Modem Management Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Multiple ISDN Switch Types
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
National ISDN Switch Types for BRI and PRI Interfaces (NI2)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPP over ATM
No
No
No
No
No
No
No
No
No
No
No
No
Stackable Home Gateway
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Switched 56K Digital Connections
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Telnet Extensions for Dialout
No
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Service Provider 1.0 Features
(3)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1 This image is not available in Release 12.0(1)T. It is available in Release 12.0(2)T and later 12.0 T releases.
2 This image is not available in Release 12.0(1)T. It is available in Release 12.0(2)T and later 12.0 T releases.
3 E1 R2 country support requires specific versions of MICA portware. For details, see the MICA portware release notes, which are available on CCO in the Software Center. Note that country support varies with the portware release level, and the release notes provide a list of countries.
4 E1 R1 signaling support for Taiwan requires MICA portware version 2.3.1.0.
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco AS5300 series universal access servers for Release 12.0(4)XJ.
New Features in Release 12.0(4)XJ
The following new software features are supported by the Cisco AS5300 in Cisco IOS Release 12.0(4)XJ.
Store and Forward Fax
The Store and Forward Fax feature enables Cisco AS5300 access servers to transmit and receive faxes across packet-based networks. This feature is an implementation of the RFC 2305 proposed standard from the Internet Engineering Task Force (IETF), which is the same as the T.37 recommendation from the International Telegraph Union (ITU). With this feature, your access server becomes a multiservice platform, supplying both data and fax communication. With Store and Forward Fax, you can:
•
•
•
Store and Forward Fax functionality is facilitated through Simple Mail Transfer Protocol (SMTP). Additional functionality is provided in this feature to enable confirmed delivery, capabilities negotiation, and session delivery, using existing SMTP mechanisms such as Extended Simple Mail Transfer Protocol (ESMTP).
Store and Forward Fax functionality is limited by the following hardware dependencies:
•
•
•
Important Notes
The following sections contain important notes about Cisco IOS Release 12.0 that can apply to the CiscoAS5300 series universal access servers.
Cisco IOS Syslog Failure
Certain versions of Cisco IOS software may fail or hang when they receive invalid User Datagram Protocol (UDP) packets sent to their syslog ports (port 514). At least one commonly-used Internet scanning tool generates packets, which can cause such problems. This fact has been published on public Internet mailing lists, which are widely read both by security professionals and by security attackers. This information should be considered in the public domain.
Attackers can cause Cisco IOS devices to repeatedly fail and reload, resulting in a completely disabled Cisco IOS device that needs to be reconfigured by its administrator. Some Cisco IOS devices have been observed to hang when attacked instead of failing. These devices do not recover until they are manually restarted by reset or power cycling. An administrator must personally visit an attacked, hung device to restart it, even if the attacker is no longer actively sending any traffic. Some devices have failed without providing stack traces; some devices may indicate that they were "restarted by power-on," even when that is not the case.
Assume that any potential attacker is likely to know the existence of this vulnerability and the ways to exploit it. An attacker can use tools available to the public on the Internet and does not need to write any software to exploit the vulnerability. Minimal skill is required, and no special equipment is required.
Even though Cisco has specifically invited such reports, to date Cisco has received no actual reports of malicious exploitation of this vulnerability.
This vulnerability notice was posted on Cisco's World Wide Web site:
http://www.cisco.com/warp/public/770/iossyslog-pub.shtml
This information was also sent to the following e-mail and USENET news recipients:
•
•
•
•
•
•
•
Affected Devices and Software Versions
describes hardware and software that are affected by this problem. Affected versions include Releases 11.3 AA, 11.3 DB, and all 12.0 versions (including 12.0 mainline, 12.0 S, 12.0 T, and any other regular released version whose number starts with 12.0), up to the repaired releases listed in . Cisco is correcting the problem in certain special releases, will correct it in future maintenance and interim releases, and intends to provide fixes for all affected IOS variants. See , for details.
No particular configuration is needed to make a Cisco IOS device vulnerable. It is possible to filter out attack traffic by using access lists. See the "Workarounds" section for techniques. However, except at Internet firewalls, the appropriate filters are not common in customer configurations. Carefully evaluate your configuration before assuming that any filtering you have protects you against this attack.
The most commonly used or asked-about products are listed below. If you are unsure whether your device is running Cisco IOS software, log in to the device and enter the show version command. Cisco IOS software will identify itself simply as "IOS" or "Internetwork Operating System Software." Other Cisco devices do not have the show version command and identify themselves differently in their output. The most common Cisco devices that run Cisco IOS software include the following:
•
•
•
•
Affected software versions, which are relatively new, are not necessarily available on every device listed above. If you are not running Cisco IOS software, you are not affected by this problem.
The following Cisco devices are not affected:
•
•
•
•
•
•
•
•
This vulnerability has been assigned Cisco bug ID CSCdk77426.
Solution
Cisco offers free software updates to correct this vulnerability for all affected customers—regardless of their contract status. However, because this vulnerability information has been disseminated by third parties, Cisco has released this notice before updates are available for all software versions. gives Cisco's projected fix dates.
Make sure that your hardware has adequate RAM to support the new software before installing it. The amount of RAM is seldom a problem when you upgrade within a major release, for example, from 11.2[11]P to 11.2[17]P, but it is often a factor when you upgrade between major releases, for example, from 11.2 P to 11.3 T.
Because fixes will be available for all affected releases, this vulnerability will rarely, if ever, require you to upgrade to a new major release. Cisco recommends that you carefully plan for any upgrade between major releases. Make certain no known bugs will prevent the new software from working properly in your environment.
Further upgrade planning assistance is available on Cisco's World Wide Web site at:
http://www.cisco.com
If you have service contracts, you can obtain new software through your regular update channels (generally through Cisco's World Wide Web site). You can upgrade to any software release, but you must remain within the boundaries of the feature sets you have purchased.
If you do not have service contracts, you can upgrade to only obtain the bug fixes; free upgrades are restricted to the minimum upgrade required to resolve the defects. You can only upgrade to the software described in one row of —except when no upgrade within the same row is available in a timely manner.
Obtain updates by contacting one of the following Cisco Technical Assistance Centers (TACs):
•
•
•
Give the URL of this notice (http://www.cisco.com/warp/public/770/iossyslog-pub.shtml) as evidence for a free update. Customers with no contracts must request for free updates through the TAC. For software updates, please do not contact either "psirt@cisco.com" or "security-alert@cisco.com.
Workarounds
You can work around this vulnerability by preventing any affected Cisco IOS device from receiving or processing UDP datagrams addressed to port 514. You can do this by either using packet filtering on surrounding devices, or by using input access list filtering on the affected IOS device itself.
If you use an input access list, apply it to all interfaces to which attackers can send datagrams. Interfaces include not only physical LAN and WAN interfaces but also virtual subinterfaces of those physical interfaces—as well as virtual interfaces and interface templates corresponding to GRE, L2TP, L2F, and other tunneling protocols.
The input access list must block traffic destined for UDP port 514 at any of the Cisco IOS device's own IP addresses—as well as at any broadcast or multicast addresses on which the Cisco IOS device may be listening. Be sure to block both old-style "all-zeros" broadcasts and new-style "all-ones" broadcasts. It is not necessary to block traffic being forwarded to other hosts—only traffic actually addressed to the Cisco IOS device.
No single input access list works in all configurations. Be sure you know the effect of your access list in your specific configuration before activating it.
The following example shows a possible access list for a three-interface router, along with the configuration commands needed to apply the list. The example assumes input filtering is not needed—other than as a workaround for this problem:
! Deny all multicasts, and all unspecified-net broadcasts, to port 514access-list 101 deny udp any 224.0.0.0 31.255.255.255 eq 514! Deny old-style unspecified-net broadcastsaccess-list 101 deny udp any host 0.0.0.0 eq 514! Deny network-specific broadcasts. This example assumes that all of! the local interfaces are on the class B network 172.16.0.0, subnetted! everywhere with mask 255.255.255.0. This will differ from network! to network. Note that we block both new-style and old-style broadcasts.access-list 101 deny udp any 172.16.0.255 0.0.255.0 eq 514access-list 101 deny udp any 172.16.0.0 0.0.255.0 eq 514! Deny packets sent to the addresses of our own network interfaces.access-list 101 deny udp any host 172.16.1.1 eq 514access-list 101 deny udp any host 172.16.2.1 eq 514access-list 101 deny udp any host 172.16.3.3 eq 514! Permit all other traffic (default would be to deny)access-list 101 permit ip any any! Apply the access list to the input side of each interfaceinterface ethernet 0ip address 172.16.1.1 255.255.255.0ip access-group 101 ininterface ethernet 2ip address 172.16.2.1 255.255.255.0ip access-group 101 ininterface ethernet 3ip address 172.16.3.3 255.255.255.0ip access-group 101 inListing all possible addresses—especially all possible broadcast addresses—to which attack packets can be sent is complicated. If you do not need to forward any legitimate syslog traffic received on an interface, you can block all syslog traffic arriving on that interface. Remember that blocking will affect traffic routed through the Cisco IOS device—as well as traffic destined to the device. If the IOS device is expected to forward syslog packets, you will have to filter in detail. Because input access lists impact system performance, install them with caution—especially on systems running very near their capacity.
Software Versions and Fixes
Many Cisco software images have been or will be specially reissued to correct this vulnerability. For example, regular released Cisco IOS version 12.0(2) is vulnerable, as are interim versions 12.0(2.1) to 12.0(2.3). The first fixed interim version of Release12.0 mainline software is Release12.0(2.4). However, a special release, 12.0(2a), contains only the fix for this vulnerability and does not include any other bug fixes from later 12.0 interim releases.
If you are running Release 12.0(2) and want to fix this problem without risking possible instability presented by installing the 12.0(2.4) interim release, you can upgrade to Release 12.0(2a). Release 12.0(2a) is a "code branch" from the Release 12.0(2) base, which will merge back into the Release 12.0 mainline at Release 12.0(2.4).
Special releases, like 12.0(2a), are one-time spot fixes, and they will not be maintained. Thus, the upgrade path from Release 12.0(2a) is to Release 12.0(3).
Note
Table 6 Affected and Repaired Software Versions
11.2 and earlier releases—all variants
Unaffected early releases (no syslog server)
Unaffected
Unaffected
Unaffected
11.3, 11.3 T, 11.3 DA, 11.3 MA, 11.3 NA, 11.3 WA, 11.3(2)XA
11.3 releases without syslog servers
Unaffected
Unaffected
Unaffected
11.3 AA
11.3 early deployment for AS58xx
11.3(7)AA2, 15-FEB-19994
11.3(7.2)AA
11.3(8)AA, 15-FEB-1999
11.3 DB
11.3 for Cisco NRP routing blade in Cisco 6400 xDSL DSLAM
11.3(7)DB2, 15-FEB-1999
12.0
12.0 Mainline
12.0(2a), 15-FEB-1999
12.0(2.4)
12.0(4), 12-APR-1999
12.0 T
12.0 new technology early deployment
12.0(2a)T1, 15-FEB-1999
12.0(2.4)T
12.0(3)T1, 15-MAR-1999
12.0(1)XA3
Short-life release; merged to 12/0T at 12.0(2)T
Obsolete
Merged
Upgrade to 12.0(3)T1
12.0(1)XB
Short-life release for Cisco 800 series; merged to 12.0 T and 12.0 (3)T
12.0(1)XB1
Merged
Upgrade to 12.0(3)T1
12.0(2)XC
Short-life release for new features in Cisco 2600, Cisco 3600, uBR7200, uBR900 series; merged to 12.0 T at 12.0(3)T
12.0(2)XC1, 15-FEB-1999
Merged
Upgrade to 12.0(3)T1
12.0(2)XD
Short-life release for ISDN voice features; merged to 12.0 T at 12.0(3)T
12.0(2)XD1, 15-FEB-1999
Merged
Upgrade to 12.0(3)T1
12.0(1)XE
Short-life release
12.0(2)XE, 15-FEB-1999
Merged
Upgrade to 12.0(3)T1
1 A special fix is a one-time release that provides the most stable immediate upgrade path.
2 Interim releases are tested less rigorously than regular maintenance releases; interim releases can contain serious bugs.
3 Fixed maintenance releases are on a long-term upgrade path. Other long-term upgrade paths also exist.
4 All dates in this table are estimates and are subject to change.
Deprecated MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. OLD-CISCO-* MIBs are currently migrated into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in:
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 and Release 12.0 T are also in Release 12.0(4)XJ.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0.
For information on caveats in Cisco IOS Release 12.0 T, see Caveats for Cisco IOS Release 12.0 T, which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM.
Note
Open Caveats—Release 12.0(4)XJ
This section describes possibly unexpected behavior by Release 12.0(4)XJ. Unless otherwise noted, these caveats apply to all 12.0 releases up to and including 12.0(4)XJ.
Basic System Services
•
SegV Exception in peer_list_sum, NTP related
When utilising ntp pivate mode and control type messages for remote query it is possible to see a router crash or traceback messages .
IBM Connectivity
•
Removing the client ip ... configuration command may cause the router to unexpectedly restart due to a software forced crash.
Interfaces and Bridging
•
When configuring a new E1 interface on a Port Adapter in a VIP2 based system ALL active E1's will go down.
The E1's don't have to be on the same VIP2
This event has been observed when configuring the following: 1) timeslots on the controller, 2) encapsulation type on the interface.
Currently there is no workaround.
Configuration changes on an E1 controller have to be executed in a maintenance window until this behaviour has been corrected.
•
Alignment error messages on dot1q over IPX SAP.
*Jul 8 11:50:37: %ALIGN-3-CORRECT: Alignment correction made at 0x605B8E70 reading 0x63E5A6F1 *Jul 8 11:50:37: %ALIGN-3-TRACE: -Traceback= 605B8E70 60095714 60095700 00000000 00000000 00000000 00000000 00000000
However this alignment errors do not effect the connectivity or cause packet loss.
•
Under certain conditions when IRB is enabled, and appletalk routing only is enabled at the interface level, appletalk routing will not work properly. The main problem is that appletalk broadcasts will not be seen on an interface, so the router will not see neighboring appletalk routers, will not receive routing updates, and will not be able to process appletalk arp packets. Some appletalk packets may actually be bridged to other appletalk routed interfaces in which the bridge-group corresponding with the BVI is defined. In a working scenerio, we should see the following mac address programmed in the output of a "show smf" command: 0900.07ff.ffff 75 RCV Appletalk broadcast In this scenerio, this mac address will be missing. The workaround is to define an additional appletalk cable-range (or address) and apple zone on the bvi.
IP Routing Protocols
•
After reloading BGP-3-BADROUTEMAP: Bad parameters in the route-map <name> applied for Dampening is logged every minute on 12.0(5)T (not on 12.0(4)T)
A sho ip bgp dampened-paths shows % dampening reconfiguration in progress
Doing a no bgp dampening route-map <name> bgp makes both issues go away.
•
BGP will not send the default route to its neighbor when "default-origintate" is configured.
•
In some circumstances, EIGRP will not automatically install and advertise PPP host routes created through dial-in.
Workaround: Perform redistribute connected under EIGRP on the router receiving the dial connections.
Miscellaneous
•
Customer has to issue the command clear interface bri X, where X is the interface number of the 4000 8 port MBRI module that has a layer 2 state of "AWAITING_ESTABLISHMENT" for one Spid and "TEI_ASSIGNED" for the other Spid. The interface that gets stuck in this state is not always the same and it occurs at random times. It is not periodic.
After issuing the clear interface command, the layer 2 of the affected port changes to state "MULTIPLE_FRAME_ESTABLISHED" for both Spids. At this time, another ISDN call is able to be placed.
•
In Release 11.2P and 11.3 when Fast Ethernet subinterfaces are configured for encryption, if the crypto map is only applied to the main interface and the IP address is configured in the subinterface, the packets could be switched in the clear. In Release 12.0, enabling CEF could cause the packets to get dropped.
•
When tunneling IPX over an ip tunnel, and when using an extended inbound access list for IP on the tunnel interface, the IPX traffic gets blocked by the access list. As a workaround a permit gre statement could be added in the extended access-list.
•
If Token Ring is the endpoint of an encrypted tunnel, extra packets are generated.
Symptoms are a high CPU load (mainly taken by the Crypto Engine) and bogus addresses when enabling the debug tunnel command.
The workaround is to use the interface command tunnel sequence-datagrams on both endpoints of the tunnel.
•
The RPM is a NPE-150 based router card capable to sustain traffic up-to 150,000pps. The RPM limits it to 62,000pps because of it's single switch interface design. Under heavy load (data or controlled traffic) the CPU utilization increases which breaks the IPC communication channel between the PXM and RPM card, due to which PXM declares RPM as Failed. Under such condition the provisioning commands will time-out as the PXM assumes that the RPM card is not available, whereas the RPM will continue to pass traffic.
It is recommended for OSPF configurations to limits the number of networks to 20 or less and the MPLS configuration to limit the interface to 100 or less. Doing so will guarantee a sustainable traffic with a low CPU utilization and hence the CPU will be able to service IPC channel traffic.
•
When the DHCP client makes the DHCP request, the DHCP server returns the request, however, when the return packet is going through the router, the router is putting 0.0.0.0 as the giaddr address when it should put the router's ethernet address.
•
For the CCBS feature (Call Completion to Busy Subscribers), when PBX sends a PROGRESS message, the voice cut-through does'nt happen. Hence, though CCBS does work, the message played to inform the caller that he/she will get a ringback when the callee is on-hook is not heard by the caller.
•
If the AS5300 is used according to specification: (maximum of 2 calls/sec/interface), this problem will not occur. If the AS5300 is overloaded for several days (greater than 2 calls/sec/interface), it will run out of memory and a reload will be required.
•
SNA Switch DLUR may fail LU-LU sessions with 0x08A00002 when uninterpreted PLU names are requested by the dependent LU.
•
When a virtual access interface is reused via recycling mechanism, it causes memory leaks if it's configured with CEF switching.
The workaround is to turn off CEF switching, no ip cef.
Wide-Area Networking
•
All platforms running MLP may potentially encounter a transient error condition where no links are assigned to a multi-link bundle.
•
Occassionaly a VIP card may not respond to a RSP boards request for a DBUS transaction. When this occurs the RSP will reset the VIP interface and perform a cbus complex restart (to re-allocate MEMD).
We do have a workaround for this problem now. Please refer to the workaround enclosure.
•
Callback configured on the dialer interface does not work and a work around is to use the ISDN caller command which has the same functionality...
•
A NAS which is unable to allocate a resource (such as a modem) for an incoming voice call will send an ALERTING to the switch. This can cause the switch to stop from hunting to the next available trunk. There is no workaround.
•
While making multiple digital calls to an isdn PRI router, excessive CPU utilization will be given to the Dialer software component. These CPU HOGS will cause an rsp4 with 10 busy PRI's to become unusable.
•
In 12.0(5)T release of IOS software, LANE clients may use an incorrect value as a SDU size in their setup message to the LES. This can prevent the client from coming up. This would happen only if the mtu on the sub-interface is non-default(greater than 1500). The workaround is to use an MTU of 1500 on those sub-interfaces until this problem is resolved in the next release of IOS software.
Resolved Caveats—Release 12.0(4)XJ
There are no caveats as 12.0(4)XJ is the base release.
Related Documentation
The following sections describe the documentation available for the Cisco AS5300 series universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are only available online on CCO and on the Documentation CD-ROM.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 12.0 and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Service & Support: Technical Documents
•
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 12.0 and Caveats for Cisco IOS Release 12.0 T, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0(4)XJ.
On CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats
Note
Platform-Specific Documents
These documents are available for the Cisco AS5300 series universal access servers on CCO and the Documentation CD-ROM:
•
•
•
•
Cisco AS5300 Universal Access Server Install and Configure•
•
•
•
•
You can reach Cisco AS5300 documentation from the CCO home page by clicking on:
Service & Support: Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
You can reach Cisco AS5300 documentation on the Documentation CD-ROM by clicking on:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
Feature Modules
Feature modules describe new features supported by Release 12.0(4)XJ and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
You can reach these documents on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
You can reach these documents on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
You can reach the Cisco IOS documentation set on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
You can reach the Cisco IOS documentation set on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-6918-03
