Release Notes for Cisco 3600 Series for Cisco IOS Release 12.0 XH
December 1, 2000
These release notes for the Cisco 3600 series routers support Cisco IOS Release 12.0 XH, up to and including Release 12.0(4)XH4. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(4)XH4, see the "Caveats" section and Caveats for Release 12.0 T . The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.0 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
The Cisco 3600 series includes the Cisco 3620 and Cisco 3640 routers. As modular solutions, the Cisco 3620 and Cisco 3640 enable corporations to increase dial-up intensity and take advantage of current and emerging WAN technologies and networking capabilities. The Cisco 3600 series routers are fully supported by Cisco IOS software, which includes dial-up connectivity, LAN-to-LAN routing, data and access security, WAN optimization, and multimedia features.
System Requirements
This section describes the system requirements for Release 12.0(4)XH4 and includes the following sections:
•
Determining the Software Version
•
Memory Recommendations
Hardware Supported
Cisco IOS Release 12.0(4)XH4 supports the Cisco 3600 series routers:
•
•
Note
Table 2 Supported Interfaces for the Cisco 3600 Series
16- and 32-port Asynchronous network module
Cisco 3620 and 3640 series
6- to 30-port Integrated Digital Modems network module
Cisco 3620 and 3640 series
8- or 16-port Integrated Analog network module
Cisco 3620 and 3640 series
1- and 4-port Ethernet (AUI and 10BaseT)
Cisco 3620 and 3640 series
1-port Fast Ethernet (100BaseTX and 100BaseFX)
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 1-port Channelized/PRI E1 balanced mode
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 1-port Channelized/PRI E1 unbalanced mode
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 1-port Channelized/PRI T1
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 1-port Channelized/PRI T1 with CSU
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 2-port Channelized/PRI E1 balanced mode
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 2-port Channelized/PRI E1 unbalanced mode
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 2-port Channelized/PRI T1
Cisco 3620 and 3640 series
1-port 10/100BaseTX with 2-port Channelized/PRI T1 with CSU
Cisco 3620 and 3640 series
1 Ethernet and 2 WAN card slots
Cisco 3620 and 3640 series
1 Ethernet, 1 Token Ring, and 2 WAN card slots
Cisco 3620 and 3640 series
2 Ethernet and 2 WAN card slots
Cisco 3620 and 3640 series
1- and 2-port Voice/Fax network module
Cisco 3620 and 3640 series with Voice/Fax network module
2-port E&M Voice interface card
Cisco 3620 and 3640 series
2-port FXO Voice interface card
Cisco 3620 and 3640 series with Voice/Fax network module
2-port FXS Voice interface card
Cisco 3620 and 3640 series with Voice/Fax network module
2-port BRI Voice interface card
Cisco 3620 and 3640 series with Voice/Fax network module
48/56/64 kbps
Cisco 3620 and 3640 series
1.544/2.048 Mbps
Cisco 3620 and 3640 series
Up to 8 Mbps on 4-port Serial network module
Cisco 3620 and 3640 series
52 Mbps max using High-Speed Serial Interface (HSSI) network module
Cisco 3620 and 3640 series
155 Mbps on ATM OC3 network modules
Cisco 3620 and 3640 series
1- and 2-port Channelized T1 and E1 network module
Cisco 3620 and 3640 series
1-port ATM-25 network modules2
Cisco 3620 and 3640 series
1-port BRI with NT or S/T WAN interface card
Cisco 3620 and 3640 series
1-port High Speed Serial Interface (HSSI) network module
Cisco 3620 and 3640 series
4- and 8-port BRI network module with NT1
Cisco 3620 and 3640 series
4- and 8-port BRI network module with S/T interface
Cisco 3620 and 3640 series
4- and 8-port Synchronous/Asynchronous
Cisco 3620 and 3640 series
4-port Serial
Cisco 3620 and 3640 series
56/64 kbps DSU/CSU
Cisco 3620 and 3640 series
T1 WAN interface card
Cisco 3620 and 3640 series
T1 with Integrated DSU/CSU
Cisco 3620 and 3640 series
ATM OC3 network module with multimode fiber and OC3 uplink port
Cisco 3620 and 3640 series
ATM OC3 network module with single-mode intermediate reach fiber and OC3 uplink port (VPD)
Cisco 3620 and 3640 series
ATM OC3 network module with single-mode long reach fiber and OC3 uplink port
Cisco 3620 and 3640 series
Compression network module
Cisco 3620 and 3640 series
1 The Voice/Fax network modules require Cisco IOS Plus feature sets.
2 The ATM-25 network modules require Cisco IOS Plus feature sets.
Determining the Software Version
To determine the version of Cisco IOS software currently running on your device, log in to the router and enter the show version EXEC command:
Router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 3620 Software (C3620-JS-MZ), Version 12.0(4)XH4, RELEASE SOFTWAREUpgrading to a New Software Release
For information about upgrading to a new software release, see the Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification (#703: 12/97) product bulletin located on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click on Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97).
Feature Set Tables
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
CautionCisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
list the features and feature sets supported by the Cisco 3600 series in Cisco IOS Release 12.0(4)XH4 and uses the following conventions:
•
•
•
Note
Table 4 Feature Lists by Feature Sets for the Cisco 3600 Series
Layer 2 Tunnel Protocol (L2TP)
No
Yes
Yes
RIP Enhancements
Yes
Yes
Yes
SNMP version 3
Yes
Yes
Yes
DLSw+ RSVP
No
Yes
Yes
DLSw+ Enhanced Load Balancing
No
Yes
Yes
DLSw+ Peer Clusters
No
Yes
Yes
Token Ring Interswitch Link
Yes
Yes
Yes
Easy IP Phase 2- DHCP Server
(1)
Yes
Yes
Yes
Flow Random Early Detection
(3)
Yes
Yes
Yes
OSPF Packet Pacing
(1)
Yes
Yes
Yes
OS_IFSS
Yes
Yes
Yes
Response Time Reporter Enhancements
(3)
Yes
Yes
Yes
Service Provider 1
(3)
No
No
No
NetFlow Policy Infrastructure
(3)
Yes
Yes
Yes
Web Cache Communications Protocol V2 (WCCPv2)
(3)
Yes
Yes
Yes
1FE2P Network Module
(1)
Yes
Yes
Yes
ISDN MIB RFC 2127
(1)
Yes
Yes
Yes
Process MIB
(3)
Yes
Yes
Yes
CLI String Search
(1)
Yes
Yes
Yes
Cisco IOS Firewall Feature Set Platform Support
(1)
No
No
Yes
IPSec Triple DES
(2)
No
No
No
Cisco IOS STP Enhancements
(1)
No
Yes
Yes
BRI Voice over IP: VIC-2BRI-S/T-TE
(3)
No
Yes
Yes
Voice Over Frame Relay, FRF.11 and FRF.12
(4)
No
Yes
Yes
Settlement for Packet Voice
(4)XH
No
Yes
Yes
Debit Card for Packet Telephony on Cisco Access Platforms
(4)XH
No
Yes
Yes
TCLWare
(4)XH
No
Yes
Yes
Interactive Voice Response for Cisco Access
(4)XH
No
Yes
Yes
H.323 Version 2 Support
(4)XH
No
Yes
Yes
Annex-G (X.25 over Frame Relay)
(3)
Yes
Yes
Yes
ATM OC3 NM
(3)
No
Yes
Yes
IOS IEEE 802.1Q Support
(1)
No
Yes
Yes
ISDN Dynamic Multiple Encaps for Dial-in
(4)
Yes
Yes
Yes
ISDN LAPB-TA
(4)
Yes
Yes
Yes
Mobile IP
(1)
No
Yes
Yes
Modem over ISDN BRI1
(3)
Yes
Yes
Yes
PPP Over Frame Relay
(1)
Yes
Yes
Yes
R2 Signaling
(1)
Yes
Yes
Yes
Time-based Access Lists
(1)
Yes
Yes
Yes
X.25 over ISDN D Channel
(1)
Yes
Yes
Yes
X.25 Load Balancing
(3)
No
No
No
1 Cisco 3640 routers only
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 3600 series for Release 12.0(4)XH4.
Settlements for Packet Voice
Internet voice telephony is often used for toll bypass by using an existing data network or the Internet instead of PSTN trunking. Calls of this nature require an originating and terminating gateway to be completed. When the originating and terminating voice gateways are owned by two different carriers, settlement between these carriers is required. The Settlements for Packet Voice project implements a standardized settlement protocol, which can be implemented between different vendors, gateways, and voice settlement servers.
Debit Card for Packet Telephony on Cisco Access Platforms
The Debit Card feature provides the ability to offer calling service with the use of debit accounting to service providers. The Debit Card for Packet Telephony on Cisco Access Platforms is one application supported by the Cisco Interactive Voice Response (IVR) feature. The IVR voice scripts have been modified to use Tool Command Language (TCL) scripts.
TCLWare
The Debit Card for Packet Telephony on Cisco Access Platforms feature requires the use of both Audio Files and TCL Scripts. Unzip and download the files to your TFTP server.
In addition, download the audio files and TCL scripts from the Access Products Service and Support site on CCO at the following "TCLWare" location:
http://www.cisco.com/kobayashi/sw-center/sw-access.shtml
Interactive Voice Response for Cisco Access
Cisco is building voice gateways to connect more traditional telephone networks to voice over IP (VoIP) networks. Customers who are installing VoIP networks often need a mechanism at the gateway to present a customized interface to the caller. The Interactive Voice Response (IVR) feature was first made available to customers with Cisco IOS Release 11.(3)NA2 with the Service Provider VoIP feature set. IVR, with the addition of scripts using Tool Command Language (TCL), is being introduced with Cisco IOS Release 12.0(4)XH. These TCL IVR scripts are the default scripts that must be used with the IVR application in Cisco IOS Release 12.0(4)XH and future releases.
IVR consists of simple voice prompting and digit collection to gather caller information for authenticating the user and identifying the destination. IVR provides the ability to:
•
•
•
•
H.323 Version 2 Support
H.323 Version 2 Support upgrades Cisco IOS software to comply with the mandatory requirements in the Version 2 specification. This upgrade enhances the existing Voice Over IP GateWay, the Multimedia Conference Manager (GateKeeper and Proxy), and the DTMF digital relay by using H.245.
DTMF is the tone generated on a touch-tone phone when you press keypad digits. The tones are compressed into a single stream at one end of a call and decompressed at the other end by using H.245 messages. However, doing this can lead to distortion, depending upon the CODEC used. Thus, the DTMF-relay is used to configure a method to transport DTMF tones generated after the call is established out-of-band. The three methods are:
•
•
•
H.323 Version 2 defines a lightweight registration procedure that requires full registration for initial registration, but uses an abbreviated renewal procedure to update the gatekeeper and minimize overhead. Lightweight registration requires each endpoint to specify a TimeToLive (TTL) value in its Registration Request (RRQ) message.
The H.323 Version 2 gateway supports the registration of fully-qualified E.164 numbers with the gatekeeper for phones connected directly to the gateway. Tunneling through H.225 User-to-User Information Element (UUIE) facilitates transparent handling of supplementary services between two endpoints through a VoIP network. This eliminates the need to interpret various supplementary signaling messages in the VoIP gateways.
The H.323 Version 2 gatekeeper selects a destination gateway by choosing a gateway from among all gateways registered in a zone by allowing you to assign selection priorities to these gateways based on the dialed prefix. Gateway resource reporting allows the gateway to notify the gatekeeper when H.323 resources are getting low. The gatekeeper uses this information to determine which gateway it will use to complete a call and maintains a separate gateway list ordered by priority for each of its zone-prefixes.
Important Notes
This section contains important information about using your Cisco IOS Release 12.0(4)XH4 software.
Note
Caveat CSCdr91706 and IOS HTTP Vulnerability
A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
The vulnerability, identified as Cisco bug ID CSCdr91706, affects virtually all mainstream Cisco routers and switches running Cisco IOS software releases 12.0 through 12.1, inclusive. This is not the same defect as CSCdr36952.
The vulnerability has been corrected and Cisco is making fixed releases available for free to replace all affected IOS releases. Customers are urged to upgrade to releases that are not vulnerable to this defect as shown in detail below.
This vulnerability can only be exploited if the enable password is known or not set.
You are strongly encouraged to read the complete advisory, which is available at http://www.cisco.com/warp/public/707/ioshttpserverquery-pub.shtml.
Deprecated MIBs
Old Cisco Management Information Bases (MIBs) will be replaced in a future release. OLD-CISCO-* MIBS are currently being migrated into more scalable MIBs—without affecting existing Cisco IOS products or NMS applications. You can update from deprecated MIBs to the replacement MIBs as shown in the following table.
Limitations and Restrictions
The Settlement for Packet Voice feature is offered only in crypto images, so that Cisco can provide export controls.
Before you can download 56-bit or 56i encryption images, the image must first go through the entitlement process. This process makes sure that the image is from a registered DNS address and that the images are not coming from an encryption-restricted country (Iraq, Libya, etc.). You can entitle yourself by filling out the forms located at the following URL:
http://www.cisco.com/kobayashi/library/12.0
Once you are entitled, you can see crypto images in the upgrade planner. You do not have to entitle yourself again, unless you come from a different host. You do not have to entitle yourself for every release. Entitlement is good for all releases.
If there are any problems with your entitlement, you will either be directed to help on DNS registration (if that is your problem), or your case will be escalated to David Moore in ECRA who will review it himself.
Also, all users MUST be entitled before they can receive 56 or 56i images. Never give a 56 or 56i image to a customer if you are uncertain about their entitlement status.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
All caveats in Release 12.0 and Release 12.0T are also in Release 12.0(4)XH4.
For information on caveats in Cisco IOS Release 12.0, see Caveats for Cisco IOS Release 12.0, which lists severity 1 and 2 caveats, and is located on CCO and the Documentation CD-ROM.
For information on caveats in Cisco IOS Release 12.0T, see Caveats for Cisco IOS Release 12.0T on CCO and the Documentation CD-ROM.
Note
Open Caveats—Release 12.0(4)XH4
This section describes possibly unexpected behavior by Release 12.0(4)XH4 and describes only severity 1 and 2 caveats:
Miscellaneous
•
The router configured as the standby gatekeeper fails to complete the call after the primary gatekeeper is shutdown. The h225 channel is terminated with error number 134.
•
H323 traffic is taking a data path to the destination when an ASR path is configured.
Resolved Caveats—Release 12.0(4)XH4
The following caveat has been resolved in Cisco IOS Release 12.0(4)XH4.
•
Callgen remains in SETUP state while making a call through an E&M interface.
Related Documentation
The following sections describe the documentation available for the Cisco 3600 series. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.
Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on CCO and the Documentation CD-ROM.
Use these release notes with the documents listed in the following sections:
•
Release-Specific Documents
The following documents are specific to Cisco IOS Release 12.0T, and are located on CCO and the Documentation CD-ROM:
•
On CCO at:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
Service & Support: Technical Documents
•
On CCO at:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Platform-Specific Documents
The documents listed below are available for the Cisco 3600 series routers. These documents are also available online at Cisco Connection Online (CCO) and on the Documentation CD-ROM:
•
•
•
•
•
•
•
•
•
•
•
•
•
On CCO at:
Service & Support: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers
On the Documentation CD-ROM at:
Access Servers and Access Routers: Modular Access Routers: Cisco 3600 Series Routers
Feature Modules
Feature modules describe new features supported by Cisco IOS Release 12.0T and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
On CCO at:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
On the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
You can reach these documents on CCO at:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
You can reach these documents on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
Release 12.0 Documentation Set
describes the contents of the Cisco IOS Release 12.0 software documentation set, which is available in electronic form and in printed form upon request.
Note
To reach the Cisco IOS documentation set from CCO, click on this path:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
To reach the Cisco IOS documentation set on the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0
Service and Support
For service and support for a product purchased from a reseller, contact the reseller. Resellers offer a wide variety of Cisco service and support programs, which are described in the section "Service and Support" in the information packet that shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and helpful tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-10057-03 Rev B0
Guest
