Release Notes for Cisco uBR7200 Series for Cisco IOS Release 12.0 XC
January 7, 1999
These release notes describe new features for the Cisco uBR7200 series routers that support Cisco IOS Release 12.0(2)XC. Cisco IOS Release 12.0(2)XC is based on Cisco IOS Release 12.0 T. These release notes are updated with each maintenance release of the Cisco IOS software, which is typically every 6 weeks.
Use these release notes in conjunction with the Release Notes for Cisco IOS Release 12.0 and Release Notes for Cisco uBR904 Cable Modem for Cisco IOS Release 12.0 XC located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
For a list of software caveats that apply to Release 12.0(2)XC and previous releases, refer to the "Caveats" section. Refer also to the Caveats for Cisco IOS Release 12.0 T located on CCO and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
Introduction
This section contains information on the Cisco uBR7200 series routers and Early Deployment Releases (ED) for the Cisco uBR7200 series routers.
For information on new features, see the "New Features in Cisco IOS Release 12.0(2)XC" section.
Cisco Data-over-Cable Products
The Cisco data-over-cable products—the Cisco uBR7223 universal broadband router, the Cisco uBR7246 universal broadband router, and the Cisco uBR904 cable modem—are compliant with Multimedia Cable Network Partners, Ltd. (MCNS) specifications. MCNS is a consortium of cable television companies whose goal is to create standards for interoperable data over cable systems.
Cisco uBR7223 Universal Broadband Router
The Cisco uBR7223 is a cost-effective, scalable interface between subscriber cable modems and the backbone data network, and is designed specifically for small to medium-sized network installations. The Cisco uBR7223 is based on the Cisco uBR7246.
Cisco uBR7246 Universal Broadband Router
The Cisco uBR7246 is the first of data-over-cable products designed to allow two-way transmission of digital data over hybrid fiber-coaxial (HFC) cable. The Cisco uBR7246 supports Internet Protocol (IP) routing with a wide variety of protocols and any combination of Ethernet, Fast Ethernet, High-Speed Serial Interface (HSSI), and Asynchronous Transfer Mode (ATM) media. The Cisco uBR7246 universal broadband router gives cable operators a cost-effective, scalable, and feature-rich interface between subscriber cable modems and the backbone data network.
Cisco uBR904 Cable Modem
The Cisco uBR904 cable modem is the subscriber unit, a key component within a cable data system. This subscriber unit functions as an interface between the subscriber's personal computer and the cable operator's network within the subscriber's small office or home office.
For more information on Cisco uBR904, refer to the "Related Documentation" section.
Early Deployment Releases
This release notes document is based on the Cisco uBR7246 for Cisco IOS Release 12.0(2)XC. Release 12.0 XC is an Early Deployment (ED) release, delivering both fixes to software caveats and support for new Cisco hardware. The following table briefly describes some of the ED releases that will be available for the Cisco uBR7200 series.
System Requirements
This section describes the system requirements for Release 12.0(2)XC and includes the following sections:
•
Determining Your Cisco IOS Software Release
Memory Requirements
Table 2 describes the memory requirements for the Cisco uBR7200 for Release 12.0 XC. Cisco uBR7246 universal broadband routers are shipped with a 16- or 20-MB Flash memory card.
Hardware Supported
Cisco IOS Release 12.0(2)XC supports the Cisco uBR7200 universal broadband routers:
•
•
For detailed descriptions of the new hardware features refer to the "New and Changed Information" section.
Cisco IOS Release 12.0(2)XC also supports the available MC11 and MC16 cable line cards:
•
•
For more information on the MC11 and MC16 cable line card software, refer to the "New and Changed Information" section.Table 3 summarizes the hardware supported on the Cisco uBR7246 universal broadband router.
Table 3 Supported Interfaces on the Cisco uBR7200 Series
1 Refer to the Documentation CD-ROM or http://www.cisco.com, http://www-china.cisco.com, or
http://www-europe.cisco.com for the most current list of supported port adapters.2 CES = circuit emulation services.
3 CBR = constant bit rate.
Determining Your Cisco IOS Software Release
To determine the version of Cisco IOS software currently running on the Cisco uBR7200 series router, log into the router and use the show version EXEC command. The following is sample output from the show version command. The version number is indicated on the second line as shown below:
Cisco Internetwork Operating System SoftwareIOS (tm) uBR7200 Software (ubr7200-p-mz), Version 12.0(2)XC, RELEASE SOFTWAREAdditional command output lines include more information, such as processor revision numbers, memory amounts, hardware IDs, and partition information.
Upgrading to a New Release
At the time of this printing, no product bulletins are available for upgrading to Cisco IOS Release 12.0 XC. For generic information about upgrading to a new software release, refer to the Cisco IOS Software Release Upgrade Paths and Packaging Simplification product bulletin located on CCO. On CCO, follow this path:
Products & Ordering: More Information: Product Bulletins
Scroll to Software. Under Cisco IOS 11.3, click Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97). The Cisco IOS Software Release Upgrade Paths and Packaging Simplification product bulletin does not contain information specific to Cisco IOS Release 12.0 XC, but provides generic upgrade information that might apply to Cisco IOS Release 12.0 XC.Feature Set Tables
The Cisco IOS software is packaged in feature sets (also called software images) depending on the platform. Each feature set contains a specific set of Cisco IOS features. The following section lists the feature set matrix and the features supported by each feature set.
Table 4 lists the Cisco IOS software feature sets available for the Cisco uBR7200 in Cisco IOS Release 12.0(2)XC. Table 4 lists the feature set name, the software image name, the platform, and whether the feature set is available with additional functionality.
Table 4 Feature Sets Supported by Cisco uBR7200 Series
MCNS Two-way
Basic1
ubr7200-p-mz
MCNS Two-way with VPN/NAT
Basic, VPN/NAT2
ubr7200-ps-mz
MCNS Two-way with Baseline Privacy
Basic, Baseline Privacy3
ubr7200-klp-mz
MCNS Two-way with Baseline Privacy and VPN/NAT
Basic, Baseline Privacy, VPN/NAT
ubr7200-klps-mz
1 This feature is offered in the Basic feature set.
2 This feature is offered with VPN/NAT functionality.
3 This feature is offered in the encryption feature sets which consist of 56bit DES (k1) data encryption feature sets.
CautionCisco IOS images with strong encryption (including, but not limited to, 56-bit data encryption feature sets) are subject to U.S. government export controls, and have a limited distribution. Images to be installed outside the U.S. require an export license. Customer orders might be denied or subject to delay due to U.S. government regulations. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.
Table 5 lists the features and feature sets supported by the Cisco IOS Release 12.0(2)XC for the Cisco uBR7200. This tables uses the following conventions to identify features:
•
•
•
Table 5 Feature List by Feature Set for the Cisco uBR7200 Series
DRP Server Agent
(3)
Yes
Yes
Yes
Yes
Easy IP (Phase 1)
(3)
Yes
Yes
Yes
Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
(3)
Yes
Yes
Yes
Yes
IP Type of Service and Precedence for GRE Tunnels
(4)
Yes
Yes
Yes
Yes
IP Enhanced IGRP Route Authentication
(3)
Yes
Yes
Yes
Yes
TCP Enhancements, including:
•
•
(3)
No
No
No
No
AppleTalk Access List Enhancements
No
No
No
No
DECnet Accounting
No
No
No
No
IPX Named Access Lists
No
No
No
No
IPX SAP-after-RIP
No
No
No
No
NLSP Enhancements
No
No
No
No
NLSP Multicast Support
No
No
No
No
Improved and Extended Command Line Interface, including:
•
•
•
•
•
(5)NA
No
Yes
Yes
Yes
Cisco Call History MIB Command Line Interface
(3)
Yes
Yes
Yes
Yes
Cisco IOS Internationalization
(3)
Yes
Yes
Yes
Yes
Entity MIB, Phase 1
(3)
Yes
Yes
Yes
Yes
MIB Enhancements
(5)NA
No
Yes
Yes
Yes
SNMPv2C
(3)
Yes
Yes
Yes
Yes
Spectrum Management Enhancements
Virtual Profiles
(3)
Yes
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
(3)
Yes
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
(3)
Yes
Yes
Yes
Yes
IP Multicast over Token Ring LANs
(3)
Yes
Yes
Yes
Yes
Stub IP Multicast Routing
(3)
Yes
Yes
Yes
Yes
Downstream QoS Handling
(5)NA
No
Yes
Yes
Yes
QoS Configuration
(5)NA
No
Yes
Yes
Yes
Read/Create Implementation of QoS
(5)NA
No
Yes
Yes
Yes
RTP Header Compression
(3)
Yes
Yes
Yes
Yes
Improved Upstream QoS
(5)NA
No
Yes
Yes
Yes
Automated Double Authentication
(3)
Yes
Yes
Yes
Yes
Cable Modem and Multicast Authentication using RADIUS
(5)NA
No
Yes
Yes
Yes
Encrypted Baseline Privacy Key Exchange
(5)NA
No
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
No
HTTP Security
(3)
Yes
Yes
Yes
Yes
Named Method Lists for AAA Authorization & Accounting
(3)
Yes
Yes
Yes
Yes
Per-User Configuration
(3)
Yes
Yes
Yes
Yes
Reflexive Access Lists
(3)
Yes
Yes
Yes
Yes
TCP Intercept
No
No
No
No
Vendor-Proprietary RADIUS Attributes
(3)
Yes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
No
No
CLNS and DECnet Fast Switching over PPP
No
No
No
No
DECnet/Vines/XNS over ISL, including:
•
•
•
No
No
No
No
Fast-Switched Policy Routing
(3)
Yes
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
No
No
No
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
No
Virtual Interface Template Service
No
No
No
No
Virtual Templates for Protocol Translation
No
No
No
No
ATM MIB Enhancements
No
No
No
No
PAD Enhancements
No
No
No
No
PAD Subaddressing
(3)
Yes
Yes
Yes
Yes
Bandwidth Allocation Control Protocol (BACP)
(3)
Yes
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
(3)
Yes
Yes
Yes
Yes
Frame Relay Enhancements
(3)
Yes
Yes
Yes
Yes
Frame Relay MIB Extensions
(3)
Yes
Yes
Yes
Yes
Frame Relay Router ForeSight
(3)
Yes
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
Yes
ISDN Multiple Switch Type
Yes
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Yes
LANE Per-subinterface Debug Messages
No
No
No
No
Layer 2 Forwarding—Fast Switching
No
No
No
No
Leased-Line ISDN at 128 kbps
No
No
No
No
MPPC
Yes
Yes
Yes
Yes
Multilink PPP Interleaving and Fair-Queuing Support
No
No
No
No
National ISDN Switch Types for BRI and PRI
(3)
Yes
Yes
Yes
Yes
PPP over ATM
No
No
No
No
Telnet Extensions for Dialout
No
No
No
No
VPDN MIB and Syslog facility
(3)
Yes
Yes
Yes
Yes
VPDN Tunnel Lookup Based on Dialed Number Information
No
No
No
No
X.25 Enhancements
Yes
Yes
Yes
Yes
X.25 on ISDN
No
No
No
No
X.25 Switching between PVCs and SVCs
(3)
Yes
Yes
Yes
Yes
X.28 Emulation
No
No
No
No
1 This column indicates the maintenance release in which the feature was introduced. For example, (3) means a feature is introduced in 11.3(3)T and a (2) means a feature was introduced in 12.0(2)XC. If this cell is empty in this column, this feature was introduced in the initial base release.
Optional feature set licenses for the Cisco uBR7246 universal broadband router are as follows:
•
•
•
•
•
•
•
•
•
•
•
•
New and Changed Information
The following sections list the new features supported by the Cisco uBR7246 universal broadband router in Cisco IOS Release 12.0 XC.
New Features in Cisco IOS Release 12.0(2)XC
The following hardware enhancements were introduced in Cisco IOS Release 12.0(2)XC and are available for the Cisco uBR7200 series router.For more information refer to the Release Notes for Cisco IOS Release 12.0.Cisco uBR7246 Universal Broadband Router
Cisco uBR7246 universal broadband features enable the Cisco uBR7200 universal broadband router to communicate with a hybrid fiber-coaxial (HFC) cable network via a Cisco MC11 cable modem card. Cisco MC11 cable modem cards allow you to connect cable modems on the HFC network to a Cisco uBR7246 in a Community Antenna Television (CATV) headend facility. The modem card provides the interface between the Cisco uBR7246 protocol control information (PCI) bus and the radio frequency (RF) signal on the HFC network.Cisco uBR7223 Universal Broadband Router
The Cisco uBR7223 is part of a new class of Cisco data-over-cable products designed to allow two-way transmission of digital data over hybrid fiber-coaxial (HFC) cable. The Cisco uBR7223 supports IP routing with a wide variety of protocols and any combination of Ethernet, Fast Ethernet, High-Speed Serial Interface (HSSI), serial, Packet-Over-SONET (POS), and Asynchronous Transfer Mode (ATM) media.
Cable Router Line Card (MC16)
The Cable Router Line Card (MC16) is available for the Cisco uBR7200. The software for the MC16 card is a driver running on the Cisco uBR7246. Using a PCI interface, the universal broadband router line card software interacts with the MC16 card. Data is passed back and forth, as direct memory access (DMA) transfers, from the Cisco uBR7246 memory to the MC16 card.
Additionally, the MC16 card supports universal broadband router line card management and control with the MC16 MIB, MAC control software and logical link management software based on MCNS standards, and minimized security.
For more information refer to the Update to the Cisco uBR7200 Series Cable Modem Card Installation and Configuration for the MC16A EFT Card publication.
Important Notes
This section contains important information about use of your Cisco IOS Release 12.0 XC software.
Deprecated MIBs
Older Cisco Management Information Bases (MIBs) will be replaced in a future release. OLD-CISCO-* MIBS are currently being migrated into more scalable MIBs, without affecting existing Cisco IOS products or NMS applications. Application developers should update from deprecated MIBs to the replacement MIBs as shown in the table below.
Caveats
This section contains a detailed list of the open and resolved caveats affecting Cisco IOS Release 12.0(2) XC only. For information on other caveats that also apply to this release, refer to the Caveats for Cisco IOS Release 12.0 T document and the Cross-Platform Release Notes for Cisco IOS Release 12.0 document located on CCO and the Documentation CD-ROM.
Note
Open Caveats—Release 12.0(2)XC
This section describes possibly unexpected behavior by Release 12.0(2)XC. This section describes only severity 1 and 2 caveats.
Miscellaneous
•
Description: If a User Datagram Protocol (UDP) packet with an invalid length is sent to port 514 (the "syslog" port) on an IOS device, the device is likely to reload. In this situation, a stack trace might not be saved. Such packets are sent by the popular nmap port scanning program.
Workaround: You can work around this vulnerability by preventing any affected Cisco IOS device from receiving or processing UDP datagrams addressed to its port 514. This can be done either using packet filtering on surrounding devices, or by using input access list filtering on the affected IOS device itself.
If you use an input access list, that list should be applied to all interfaces to which attackers may be able to send datagrams. This includes not only physical LAN and WAN interfaces, but virtual subinterfaces of those physical interfaces, as well as virtual interfaces and/or interface templates corresponding to GRE, L2TP, L2F, and other tunnelling protocols.
The input access list must block traffic destined for any of the CiscoIOS device's own IP addresses, as well as for any broadcast or multicast addresses on which the Cisco IOS device may be listening. It's important to remember to block old-style "all-zeroes" broadcasts as well as new-style "all-ones" broadcasts.
There is no single input access list that will work in all configurations. It is very important that you understand the effect of your access list in your specific configuration before you activate the list.
The following example shows a possible access list for a three-interface router, along with the configuration commands needed to apply that access list. The example assumes no need for input filtering other than as a workaround for this vulnerability.
! Deny all multicasts, and all unspecified-net broadcasts, to port 514access-list 101 deny udp any 224.0.0.0 31.255.255.255 eq 514! Deny old-style unspecified-net broadcastsaccess-list 101 deny udp any host 0.0.0.0 eq 514! Deny network-specific broadcasts. This example assumes that all of! the local interfaces are on the class B network 172.16.0.0, subnetted! everywhere with mask 255.255.255.0. This will differ from network! to network. Note that we block both new-style and old-style broadcasts.access-list 101 deny udp any 172.16.0.255 0.0.255.0 eq 514access-list 101 deny udp any 172.16.0.0 0.0.255.0 eq 514! Deny packets sent to the addresses of our own network interfaces.access-list 101 deny udp any host 172.16.1.1 eq 514access-list 101 deny udp any host 172.16.2.1 eq 514access-list 101 deny udp any host 172.16.3.3 eq 514! Permit all other traffic (default would be to deny)access-list 101 permit ip any any! Apply the access list to the input side of each interfaceinterface ethernet 0ip address 172.16.1.1 255.255.255.0ip access-group 101 ininterface ethernet 2ip address 172.16.2.1 255.255.255.0ip access-group 101 ininterface ethernet 3ip address 172.16.3.3 255.255.255.0ip access-group 101 inIt can be complicated to list all possible addresses, and especially all possible broadcast addresses, to which attack packets might be sent. If you do not expect to receive any legitimate syslog traffic on an interface, you may wish to simply block all syslog traffic arriving on that interface. Remember that this will affect traffic routed through the Cisco IOS device as well as traffic destined to the device.
Input access lists have an impact on system performance, and should be installed with a degree of caution, especially on systems that are running very near their capacity limits.
•
Description: When you configure Bisync (encapsulation bstun) with the ASCII character set (bsc char-set ascii) on the first port of a serial WIC (1T, 2T, or 2A/S) in WIC slot 0 of a Cisco 2600 series router, only the first character of each frame is received, and the BSTUN tunnel is not established. This only affects Bisync mode when it is configured with the ASCII character set. Other encapsulations are not affected, and using the EBCDIC character set with Bisync works correctly.
Details: For the first serial port in WIC slot 0, the parity detection is not configured correctly for Bisync in ASCII mode. The first character of each frame generates a parity error that causes the receiver to discard the frame after the first character received.
Workaround: Use a different serial port: either the second serial port (port 1) on a 2T or 2A/S WIC in WIC slot 0 or any serial port in WIC slot 1. If you have only one serial WIC, moving it from WIC slot 0 to WIC slot 1 fixes this problem.
Resolved Caveats—Release 12.0(2)XC
Because Cisco IOS Release 12.0(2)XC is a limited-time release, only the initial caveats are documented in these release notes.
Related Documentation
The following sections describe the documentation available for the Cisco uBR7200 series routers. Typically, these documents consist of hardware installation guides, software installation guides, Cisco IOS configuration and command references, system error messages, and feature modules, which are updates to the Cisco IOS documentation. Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online only.
The most up-to-date documentation can be found on the Web via Cisco Connection Online (CCO) and the Documentation CD-ROM. These electronic documents might contain updates and modifications made after the hard copy documents were printed.
These release notes should be used in conjunction with the documents listed in this section.
•
Release-Specific Documentation
The following documents are specific to Release 12.0. They are located on CCO and the Documentation CD-ROM:
•
To reach the cross-platform Release Notes for Cisco IOS Release 12.0 on CCO, follow this path:
Software & Support: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes for Cisco IOS Release 12.0To reach the cross-platform Release Notes for Cisco IOS Release 12.0 on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes for Cisco IOS Release 12.0•
To reach these documents, refer to the Software Center at this path on CCO:
Software & Support: Software Center: Cisco IOS Software•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see the Caveats for Cisco IOS Release 12.0 T document, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T.
To reach the caveat document on CCO, follow this path:
Products & Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
To reach the caveat document on the Documentation CD-ROM, follow this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Feature Modules
Feature modules describe new features supported by Release 12.0, and are an update to the Cisco IOS documentation set. As updates, the features modules are available online only. The feature module information is included in the next printing of the Cisco IOS documentation set. Each feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference.
To reach the feature modules on CCO, follow this path:
Products & Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime ReleasesTo reach the feature modules on the Documentation CD-ROM, follow this path:Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime ReleasesPlatform-Specific Documents
The documents listed in this section are available for the Cisco uBR7200 series. These documents are also available on CCO and the Documentation CD-ROM.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
To reach Cisco uBR7200 and Cisco uBR900 series documentation on CCO, follow this path:
Software & Support: Documentation: Cisco Documentation: Cisco Product Documentation: Broadband/Cable Solutions: Cisco uBR7200 Series Universal Broadband Routers or Cisco uBR904 Cable Modem
To reach Cisco uBR7200 and Cisco uBR900 series documentation on the Documentation CD-ROM, follow this path:
Broadband/Cable Solutions: Cisco uBR7200 Series Universal Broadband Routers or Cisco uBR904 Cable ModemCisco IOS Software Documents
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. These documents are shipped with your order in electronic form on the Documentation CD-ROM, unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set: configuration guides and command references.
To reach these documents on CCO, follow this path:
Products & Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Cisco IOS Interface Configuration Guide or Cisco IOS Interface Command Reference
To reach these documents on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References: Cisco IOS Interface Configuration Guide or Cisco IOS Interface Command Reference
Release 12.0 Documentation Set
details the contents of the Cisco IOS Release 12.0 software documentation set. The document set is available in electronic form, and also in printed form upon request.
Note
To reach the Cisco IOS documentation set on CCO, follow this path:
Products & Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
To reach the Cisco IOS documentation set on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Configuration Guides and Command References
.
Table 7 Cisco IOS Software Documentation Set for Release 12.0
Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
System ManagementTransparent Bridging
Source-Route Bridging
Token Ring Inter-Switch Link
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point
SNA Frame Relay Access Support
APPN
Cisco Database Connection
NCIA Client/Server Topologies
Cisco Mainframe Channel Connection
Airline Product SetDial-In Port Setup
Dial-In Terminal Services
Dial-on-Demand Routing (DDR)
Dial Backup
Dial-Out Modem Pooling
Large-Scale Dial Solutions
Cost-Control Solutions
ISDN
X.25 over ISDN
VPDN
Dial Business Solutions and ExamplesInterface Configuration Overview
IP Addressing
IP Services
IP Routing ProtocolsAppleTalk
Novell IPXApollo Domain
Banyan VINES
DECnet
ISO CLNS
XNSAAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security OptionsSwitching Paths for IP Networks
Virtual LAN (VLAN) Switching and RoutingATM
Frame Relay
SMDS
X.25 and LAPB•
Voice over IP
Voice over Frame Relay
Voice over ATM
Voice over HDLC
Video Support
Universal Broadband FeaturesClassification
Scheduling
Packet Drop
Traffic Shaping
ATM QoS
SNA QoS
Line Protocols
1 This book will not be available until January 1999.
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller. Resellers offer a wide variety of Cisco service and support programs, which are described in the section "Service and Support" in the information packet that shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco TAC Home Page
For helpful tips on configuring Cisco products, follow this path on CCO:
Software & Support: Technical Tips (button on left margin)
"Hot Tips" are popular tips and hints gathered from Cisco's Technical Assistance Center (TAC). Most of these documents are also available from the TAC's Fax-on-Demand service. To reach Fax-on-Demand and receive documents at your fax machine, call 888-50-CISCO (888-502-4726).
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-6264-01
