Release Notes for Cisco 6400 NSP for Cisco IOS Release 12.0(5)DB
February 18, 2002
These release notes for the Cisco 6400 node switch processor (NSP) support Cisco IOS Release 12.0DB, up to and including Release 12.0(5)DB1. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(5)DB1, see the "Caveats" section and Caveats for Cisco IOS Release 12.0 T. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes in conjunction with the cross-platform Release Notes for Cisco IOS Release 12.0 located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0(5)DB1 and includes the following sections:
•
Determining Your Software Release
•
Memory Requirements
Table 1 describes the memory requirements for the Cisco 6400 platform supported by Cisco IOS Release 12.0 DB.
When used in a redundant configuration, the primary and backup NSPs should have identical hardware configurations, including DRAM size, Flash memory size, and Flash disk size. To learn about redundancy in the Cisco 6400, see "Configuring System Features" in the Cisco 6400 UAC Software Configuration Guide.
Hardware Supported
Cisco IOS Release 12.0(5)DB1 supports the Cisco 6400 NSP. For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Software Compatibility
Cisco recommends that Release 12.0(5)DB1 software is used concurrently with Cisco IOS Release 12.0(5)DC for the Cisco 6400 node route processor (NRP). For information about Release 12.0(5)DC for the NRP, see Release Notes for Cisco 6400 Node Route Processor (NRP) for Cisco IOS Release 12.0(5)DC.
Note
Determining Your Software Release
To determine the version of Cisco IOS software currently running on the Cisco 6400 NSP, log in to the NSP and enter the show version EXEC command. The following is sample output from the show version command performed on the Cisco 6400. The version number is indicated on the second line as shown below:
Cisco Internetwork Operating System SoftwareIOS (tm) C6400 Software (C6400S-WP-M), 12.0(5) DB1 .....The output includes additional information including processor revision numbers, memory amounts, hardware IDs, and partition information. To upgrade to a new software release, see the "Cisco Connection Online" section.
Upgrading to a New Release
For specific information on upgrading a dual-NSP system to a new software release, see "Configuring System Features" in the Cisco 6400 UAC Software Configuration Guide.
For information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 12.0 Upgrade Paths and Packaging Simplification located at:
http://www.cisco.com/kobayashi/library/12.0/120MigrPaths.pdf
If you do not have an account on CCO and want general information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification (#703: 12/97) on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97)
This product bulletin does not contain information specific to Cisco IOS Release 12.0 but provides generic upgrade information that may apply to Cisco IOS Release 12.0.
Feature Set Table
The Cisco IOS software is packaged in feature sets (also called software images) depending on the platform. Each feature set contains a specific set of Cisco IOS features. The Cisco 6400 can only use a single image called c6400s-wp-mz.
CautionThis feature set table contains only a selected list of features. This table is not a cumulative or complete list of all the features in each image.
Table 2 lists the features supported by the c6400s-wp-mz image for the Cisco 6400.
New and Changed Information
The following sections list the new features supported by the Cisco 6400 in Cisco IOS Release 12.0(5)DB.
No New Features in Release 12.0(5)DB1
There are no new hardware or software features in Release 12.0(5)DB1.
New Software Features in Release 12.0(5)DB
ATM Software Enhancements
Release 12.0(5)DB for the Cisco 6400 NSP includes a number of software enhancements, including hierarchical VP tunnels, frame relay network and service interworking, and network clock distribution protocol. For more information about the ATM capabilities of the Cisco 6400 NSP, refer to the following documents:
•
•
•
•
Combined Network Management Ethernet Interface
The combined network management Ethernet (NME) interface allows the entire Cisco 6400 system, including the NSP and all installed NRPs, to be managed through a single Ethernet interface. The NME interface eliminates the need for Ethernet cables and connections on individual NRPs. For more information about using the combined NME interface, see "Configuring the NSP" and "Configuring the NRP" in the Cisco 6400 UAC Software Configuration Guide.
Note
New Hardware Features Supported in Release 12.0(5)DB
OC12 Node Line Card
The OC12 node line card (NLC) supports bandwidth up to 622 Mbps between the Cisco 6400 Universal Access Concentrators and the network backbone. The OC12 NLC is a full-height card that mounts in the chassis on a full-height carrier module. For more information about installing an OC12 NLC, see the Cisco 6400 UAC FRU Installation and Replacement Guide.
AC Power Entry Module
The AC power entry module (PEM) provides power conversion directly from the facility VAC input power to the -48VDC used internally in the Cisco 6400 chassis. AC power comes into the AC PEM through a power cord attached to the front faceplate. An additional AC PEM can be used for redundancy. For more information about installing an AC PEM, see the Cisco 6400 UAC Hardware Installation Guide.
No New Features in Release 12.0(4)DB
There are no new features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(4)DB.
New Hardware Features Supported in Release 12.0(3)DB
DS3 Node Line Card
A new DS3 node line card (NLC) has been developed for the Cisco 6400 chassis. The DS3 NLC is a half-height card that mounts in the chassis on a full-height carrier module. Coaxial interface cables are connected to the DS3 using BNC connectors on the back of the Cisco 6400 chassis. For more information about installing a DS3 NLC, see the Cisco 6400 UAC FRU Installation and Replacement guide.
No New Features in Release 12.0(2)DB
There are no new features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(2)DB.
New Software Features in Cisco IOS Release 12.0(1)DB
Redundancy
Resiliency for both the NSP and NRP is based on extended high system availability (EHSA). If the NRP fails, no virtual circuits (VCs) from the NSP must be reconfigured. The NRP blades also support online insertion and removal (OIR). When operating in non-redundant mode, the NRPs appear as separate network management entities, and can be accessed via individual console ports.
Synchronous Optical Network (SONET) Automatic Protection Switching (APS)
SONET APS provides a mechanism to support redundant transmission circuits, such as single-mode fibers, between SONET devices. Automatic switchover from the primary or working circuit to the backup or protection circuit happens when the working circuit fails or degrades.
The Cisco 6400 supports 1+1, linear, unidirectional, non-reverting APS operation on its redundant OC-3/STM-1 ports.
Telco Alarms
A telco uses system alarms to help monitor equipment and identify the cause of physical system problems within the central office. There are three levels of alarms: minor, major, and critical, and there are many sources of alarm conditions. Temperature thresholds are one source, but alarms can be triggered by card failure, SONET APS failures, NRP failures, and generic alarms.
The Cisco 6400 includes environmental monitoring hardware and a digital thermometer that measures the temperature of the intake air flow and the temperature at the hottest part of the chassis. Temperature thresholds for each alarm type and location are automatically set, based on empirically determined values that vary depending on the number and type of boards inserted in the chassis. In addition to the automatically set thresholds, you can set your own thresholds for minor and major temperature alarms.
The Cisco 6400 supports BellCore standard alarms, and additional commands have been added that allow you to manage the alarms and reset chassis components as needed.
Dynamic Host Configuration Protocol (DHCP) Client
The Cisco 6400 acts as a DHCP client and automatically acquires an IP address, subnet mask, and default route from a DHCP server on the network. This feature allows you to install the Cisco 6400 in the central office using non-technical personnel. The plug-n-play option allows you to configure the Cisco 6400 from a Network Operations Center (NOC), without being physically close to the system.
Web Console
Web Console is a graphical user interface (GUI) lets you set or change the system configuration and monitor system activity. The Web Console application is accessible from any Web browser on the Telco management network. You can configure basic system parameters, Simple Network Management Protocol (SNMP) management parameters, set up subscribers, and monitor the current status of your chassis LEDs from anywhere on the network with Web Console.
Important Notes
This section contains important information about use of your Cisco 6400 UAC NSP.
Web Console Issues
The Web Console application is designed to use JavaScript, which is available with both Netscape Navigator and Microsoft Internet Explorer. However, a number of issues are present when using either application. To date, using Netscape Navigator 4.x has resulted in fewer issues than Microsoft Internet Explorer 4.x.
Before using the Web Console application, verify that your browser is set to use at least 4 MB (4096 KB) of cache memory.
The following sections tell how to deal with some of the browser issues affecting each application.
Microsoft Internet Explorer 4.x
Web Console might not reflect the most current redundancy status and auto synchronization setting because the check box and option buttons are not displayed properly. Therefore, you must verify your configuration by viewing the configuration file.
An empty dialog box might display after you apply new settings in any of the Web Console pages. If an empty dialog box is displayed, click the Internet Explorer Refresh button to view your new settings.
The show interface command on the Status page fails with Internet Explorer. There is no workaround, so this function is not available.
Netscape Navigator 4.x
If a blank window is displayed after you resize your Navigator window, click the Reload button to redisplay the page.
Frequent and rapid clicking on the Web Console Status page can cause syntax and LED errors. This problem is eliminated if the browser cache is set to 4096 KB.
Using Verbose Debug Options
On a dual-NSP system, switchovers can occur if verbose debugging commands, such as debug all or debug oir commands, are used. To avoid this situation when using verbose debug commands, execute the redundancy keepalive disable command at the EXEC prompt prior to turning on the debug command. After debugging is disabled, enter the redundancy keepalive enable command to restore normal system operation.
ATM Generic Flow Control Field
When an ATM cell is received on the NSP, the generic flow control (GFC) field of the ATM cell is passed without modification to the outbound virtual circuit. This is not compliant with the ATM Forum UNI specification, version 3.1, which requires all bits of the GCF field to be reset to zero.
Caveats
This section contains open and resolved caveats for the current Cisco 6400 NSP IOS release only.
Caveats in Cisco IOS Release 12.0(5)T also apply to Release 12.0(5)DB1. For information on caveats in the Cisco IOS Release 12.0(5)T, refer to the "Caveats" sections in the Cross-Platform Release Notes for Cisco IOS Release 12.0 located on CCO and the Documentation CD-ROM. This section contains caveats affecting all maintenance releases.
Note
Open Caveats-Release 12.0(5)DB1
There are no open caveats in Release 12.0(5) DB1.
Resolved Caveats-Release 12.0(5)DB1
All the caveats listed in this section are resolved in Cisco IOS Release 12.0(5) DB1. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Open Caveats-Release 12.0(5)DB
This section describes possibly unexpected behavior by Release 12.0(5)DB.This section describes severity 1, 2, and selected severity 3 caveats.
•
The dir disk0: command shows the disk is still present even after it has been removed. A message is sent to the console log when a PCMCIA disk is removed. Do not attempt any disk operations after the removal notice is displayed because they will not work.
Resolved Caveats-Release 12.0(5)DB
There are no additional caveats resolved in Release 12.0(5) DB.
Related Documentation
The following sections describe the documentation available for the Cisco 6400 Universal Access Concentrator. The most up-to-date documentation can be found on the web via Cisco Connection Online (CCO) and on the Documentation CD-ROM. These electronic documents might contain updates and modifications made after the hard copy documents were printed.
These release notes should be used in conjunction with the documents listed in the following sections:
•
Release-Specific Documents
The following documents are specific to Release 12.0 T. They are located on CCO and the Documentation CD-ROM:
•
To access the cross-platform Release Notes for Cisco IOS Release 12.0 T on CCO, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
To access the cross-platform Release Notes for Cisco IOS Release 12.0 on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
To access these documents, refer to the Software Center at this path on CCO:
Service and Support: Technical Documentation
•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see the Caveats for Cisco IOS Release 12.0 T document, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T.
To access the caveat document on CCO, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
To access the caveat document on the Documentation CD-ROM, follow this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Platform-Specific Documents
The documents listed in are available for the Cisco 6400 UAC. These documents are also available online at Cisco Connection Online (CCO) and on the Documentation CD-ROM.
To access Cisco 6400 documentation on CCO, follow this path:
Service and Support: Technical Documents: Documentation Home Page: DSL Products: Cisco 6400
To access Cisco 6400 documentation on the Documentation CD-ROM, follow this path:
DSL Products: Cisco 6400
Feature Modules
Feature modules describe new features supported by Release 12.0 DB. Feature modules are available online only. In the next printing of the Cisco IOS documentation set, feature modules will be included as updates to the Cisco IOS Documentation set. Each feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference.
•
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases
•
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases
Cisco IOS Software Document Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. These documents are shipped with your order in electronic form on the Documentation CD-ROM, unless you specifically ordered the printed versions.
Documentation Modules and Indexes
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked indexes provide indexing information for the Cisco IOS software documentation set: an index for the configuration guides and an index for the command references. In addition, individual books contain a book-specific index.
To access these indexes on CCO, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Cisco IOS Release 12.0 Configuration Guides and Command References: Configuration Guide Master Index or Command Reference Master Index
To access these indexes on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Cisco IOS Release 12.0 Configuration Guides and Command References: Configuration Guide Master Index or Command Reference Master Index
To access documentation related to an index entry, click on the page number following the entry.
Release 12.0 Documentation Set
details the contents of the Cisco IOS Release 12.0 software documentation set. The document set is available in electronic form, and also in printed form upon request.
Note
To access the Cisco IOS documentation set on CCO, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
To access the Cisco IOS documentation set on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-5788-06 Rev A0
