Release Notes for Cisco 6400 NSP for Cisco IOS Release 12.0(7)DB
February 18, 2002
Note
You can find the most current Cisco IOS documentation on Cisco.com. The electronic documents might contain updates and modifications made after the hardcopy documents were printed.
These release notes for the node switch processor (NSP) of the Cisco 6400 Universal Access Concentrator (UAC) support Cisco IOS Release 12.0 DB, up to and including Cisco IOS Release 12.0(7)DB2. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 12.0(7)DB2, see the "Software Caveats" section and Caveats for Cisco IOS Release 12.0 T. The caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.
Use these release notes in conjunction with the cross-platform Release Notes for Cisco IOS Release 12.0 located on Cisco.com and the Documentation CD-ROM.
Contents
These release notes discuss the following topics:
•
•
System Requirements
This section describes the system requirements for Cisco IOS Release 12.0(7)DB2 and includes the following sections:
•
•
Memory Requirements
Table 1 describes the memory requirements for the Cisco 6400 platform supported by Cisco IOS Release 12.0 DB.
When used in a redundant configuration, the primary and backup NSPs should have identical hardware configurations, including DRAM size, Flash memory size, and Flash disk size. To learn about redundancy in the Cisco 6400, see "Configuring System Features" in the Cisco 6400 UAC Software Configuration Guide.
Hardware Supported
Cisco IOS Release 12.0(7)DB2 supports the Cisco 6400 NSP as well as the NSP with Stratum 3/BITS (C6400-NSP-S3B). The NSP-S3B is required to use the BITS Network Clocking software feature. For detailed descriptions of the new hardware features, see the "New and Changed Information" section.
Note
Software Compatibility
Cisco recommends that Release 12.0(7)DB2 software is used concurrently with Cisco IOS Release 12.0(7)DC for the Cisco 6400 node route processor (NRP). For information about Release 12.0(7)DC for the NRP, see Release Notes for Cisco 6400 Node Route Processor (NRP) for Cisco IOS Release 12.0(7)DC.
Note
Determining Your Software Release
To determine the version of Cisco IOS software currently running on the Cisco 6400 NSP, log in to the NSP and enter the show version EXEC command. The following is sample output from the show version command performed on the Cisco 6400. The version number is indicated on the second line as shown below:
Cisco Internetwork Operating System SoftwareIOS (tm) C6400 Software (C6400S-WP-M), 12.0(7) DBThe output includes additional information including processor revision numbers, memory amounts, hardware IDs, and partition information. To upgrade to a new software release, see the section below.
Upgrading to a New Software Release
For specific information on upgrading a dual-NSP system to a new software release, see "Configuring System Features" in the Cisco 6400 UAC Software Configuration Guide.
For information about upgrading to a new software release, see the product bulletin Cisco IOS Upgrade Ordering Instructions located at:
http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htmIf you do not have an account on Cisco.com and want general information about upgrading to a new software release, see the product bulletin Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification (#703: 12/97) on Cisco.com at:
Technical Documents: Product Bulletins: Software: Cisco IOS 11.3:
Cisco IOS Software Release 11.3 Upgrade Paths No. 703This product bulletin does not contain information specific to Cisco IOS Release 12.0 but provides generic upgrade information that may apply to Cisco IOS Release 12.0.
Feature Table
The Cisco IOS software is packaged in software images that each contain a specific set of Cisco IOS features. Table 2 lists the features supported by the Cisco 6400 NSP image called c6400s-wp-mz.
Note
Table 2 Feature List for the Cisco 6400 Node Switch Processor
Access lists on Interim Local Management Interface (ILMI) registration
Asynchronous Transfer Mode (ATM) access lists
ATM accounting
ATM accounting enhancements
ATM Address Resolution Protocol (ARP) client on NSP
ATM ARP server on NSP
ATM remote monitoring (RMON)
ATM soft restart
BITS External Network Clock Source
Closed user groups (CUGs)
Dynamic Host Configuration Protocol (DHCP) client support
Dual leaky bucket policing
E.164 address translation and autoconversion
Hardware redundancy
Interim-Interswitch Signaling Protocol (IISP)
ILMI version 4.0
Internet Protocol (IP)
LANE1 client (LEC) and LANE Services (LES2 /BUS3 /LECS4 ) on NSP
Left-justified E.164 AFI support
Logical multicast support (up to 254 leaves per output port, per point-to-multipoint virtual circuits [VCs])
Multiprotocol Label Switching (MPLS) Label Switch Router (LSR)
Multiple, weighted, dynamic thresholds for selective packet marking and discard
Multipoint-to-point User-Network Interface (UNI) signaling
Network clocking enhancements for smooth switchover
Network Time Protocol (NTP)
Operation, administration, and maintenance (OAM) F4 and F5
Per-VC or per-virtual path (VP) nondisruptive snooping
Private Network Node Interface (PNNI) hierarchy
Point-to-point and point-to-multipoint permanent virtual channel connections (VCCs) and virtual path connections (VPCs)
Point-to-point and point-to-multipoint switched VCCs and VPCs (UNI 3.0)
Point-to-point and point-to-multipoint switched VCCs and VPCs (UNI 3.1)
Point-to-point and point-to-multipoint switched VCCs and VPCs (UNI 4.0)
Port snooping
Scheduler/Service Class/permanent virtual circuit (PVC) configuration
Shaped VP tunnels for constant bit rate (CBR) traffic
Signaling diagnostics and Management Information Base (MIB)
Simple Network Management Protocol (SNMP)
Soft VCCs and VPCs
Stratum 3 Internal Clock Accuracy
Substitution of other service categories in shaped VP tunnels
Support for nonzero minimum cell rate (MCR) on available bit rate (ABR) connections
Synchronous Optical Network (SONET) automatic protection switching (APS) support
Terminal Access Controller Access Control System Plus (TACACS+)
Telco alarm support
Telnet
Token Ring LANE services
VP tunneling
Virtual path identifier/virtual channel identifier (VPI/VCI) range support in ILMI 4.0
Web-based configuration
1 LANE = LAN emulation
2 LES = LAN Emulation Server
3 BUS = broadcast and unknown server
4 LECS = LAN Emulation Configuration Server
New and Changed Information
The following sections list the new features supported by the Cisco 6400 in Cisco IOS Release 12.0 DB.
No New Hardware Feature Supported in Release 12.0(7)DB2
There are no new hardware features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(7)DB2.
No New Software Features in Release 12.0(7)DB2
There are no new software features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(7)DB2.
No New Hardware Feature Supported in Release 12.0(7)DB1
There are no new hardware features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(7)DB1.
New Software Features in Release 12.0(7)DB1
Web Console VP Provisioning Enhancement
The Cisco 6400 NSP web console now supports a graphical user interface (GUI) to provision virtual paths (VPs). This enhancement only affects the http server operation on the Cisco 6400 and does not affect any other operation on the Cisco 6400. The GUI works with Netscape Navigator version 4.51, 4.7, and 6.0 and with Microsoft Internet Explorer version 5.0 and 5.5.
Clicking on the "VP subscriber" graphic button on the graphical navigator menu bar initiates the VP provisioning process. The help files now include a "VP Subscriber" help page.
For information on how to launch the NSP web console application, see the section NSP Web Console Application in the chapter Managing the Cisco 6400 SCM Element Manager Windows in the Cisco 6400 Service Connection Manager User Guide.
New Hardware Feature Supported in Release 12.0(7)DB
Node Switch Processor with Stratum 3/BITS
The Node Switch Processor with Stratum 3/BITS (NSP-S3B) enables the use of the BITS Network Clocking software feature. The NSP-S3B enables the Cisco 6400 to serve as a stratum 3 network clock source for other network devices. When no external clock source is available, the NSP-S3B provides stratum level 3 internal timing on the Cisco 6400. Otherwise the NSP-S3B is identical to the default NSP. For more information about installing the NSP-S3B, see the Cisco 6400 UAC Hardware Installation and Maintenance Guide.
New Software Features in Release 12.0(7)DB
BITS Network Clocking
The BITS Network Clocking feature enables the Cisco 6400 to derive network timing from the central office (CO) BITS. This feature requires the NSP with Stratum 3/BITS (NSP-S3B). For more information about this feature, see the BITS Network Clocking feature module.
Multiprotocol Label Switching
The NSP can participate in a Multiprotocol Label Switching (MPLS) network as an ATM label switch router (LSR). For more information about MPLS on the Cisco 6400, see the Configuring Multiprotocol Label Switching on the Cisco 6400 UAC configuration note.
New Hardware Features Supported in Release 12.0(5)DB
OC12 Node Line Card
The OC12 node line card (NLC) supports bandwidth up to 622 Mbps between the Cisco 6400 Universal Access Concentrators and the network backbone. The OC12 NLC is a full-height card that mounts in the chassis on a full-height carrier module. For more information about installing an OC12 NLC, see the Cisco 6400 UAC FRU Installation and Replacement Guide.
AC Power Entry Module
The AC power entry module (PEM) provides power conversion directly from the facility VAC input power to the -48VDC used internally in the Cisco 6400 chassis. AC power comes into the AC PEM through a power cord attached to the front faceplate. An additional AC PEM can be used for redundancy. For more information about installing an AC PEM, see the Cisco 6400 UAC Hardware Installation Guide.
New Software Features in Release 12.0(5)DB
ATM Software Enhancements
Release 12.0(5)DB for the Cisco 6400 NSP includes a number of software enhancements, including hierarchical VP tunnels, frame relay network and service interworking, and network clock distribution protocol. For more information about the ATM capabilities of the Cisco 6400 NSP, refer to the following documents:
•
•
•
•
Combined Network Management Ethernet Interface
The combined network management Ethernet (NME) interface allows the entire Cisco 6400 system, including the NSP and all installed NRPs, to be managed through a single Ethernet interface. The NME interface eliminates the need for Ethernet cables and connections on individual NRPs. For more information about using the combined NME interface, see "Configuring the NSP" and "Configuring the NRP" in the Cisco 6400 UAC Software Configuration Guide.
Note
No New Features in Release 12.0(4)DB
There are no new features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(4)DB.
New Hardware Features Supported in Release 12.0(3)DB
DS3 Node Line Card
A new DS3 node line card (NLC) has been developed for the Cisco 6400 chassis. The DS3 NLC is a half-height card that mounts in the chassis on a full-height carrier module. Coaxial interface cables are connected to the DS3 using BNC connectors on the back of the Cisco 6400 chassis. For more information about installing a DS3 NLC, see the Cisco 6400 UAC FRU Installation and Replacement Guide.
No New Features in Release 12.0(2)DB
There are no new features supported by the Cisco 6400 NSP in Cisco IOS Release 12.0(2)DB.
New Software Features in Cisco IOS Release 12.0(1)DB
Redundancy
Resiliency for both the NSP and NRP is based on extended high system availability (EHSA). If the NRP fails, no virtual circuits (VCs) from the NSP must be reconfigured. The NRP blades also support online insertion and removal (OIR). When operating in non-redundant mode, the NRPs appear as separate network management entities, and can be accessed via individual console ports.
Synchronous Optical Network (SONET) Automatic Protection Switching (APS)
SONET APS provides a mechanism to support redundant transmission circuits, such as single-mode fibers, between SONET devices. Automatic switchover from the primary or working circuit to the backup or protection circuit happens when the working circuit fails or degrades.
The Cisco 6400 supports 1+1, linear, unidirectional, non-reverting APS operation on its redundant OC-3/STM-1 ports.
Telco Alarms
A telco uses system alarms to help monitor equipment and identify the cause of physical system problems within the central office. There are three levels of alarms: minor, major, and critical, and there are many sources of alarm conditions. Temperature thresholds are one source, but alarms can be triggered by card failure, SONET APS failures, NRP failures, and generic alarms.
The Cisco 6400 includes environmental monitoring hardware and a digital thermometer that measures the temperature of the intake air flow and the temperature at the hottest part of the chassis. Temperature thresholds for each alarm type and location are automatically set, based on empirically determined values that vary depending on the number and type of boards inserted in the chassis. In addition to the automatically set thresholds, you can set your own thresholds for minor and major temperature alarms.
The Cisco 6400 supports BellCore standard alarms, and additional commands have been added that allow you to manage the alarms and reset chassis components as needed.
Dynamic Host Configuration Protocol (DHCP) Client
The Cisco 6400 acts as a DHCP client and automatically acquires an IP address, subnet mask, and default route from a DHCP server on the network. This feature allows you to install the Cisco 6400 in the central office using non-technical personnel. The plug-n-play option allows you to configure the Cisco 6400 from a Network Operations Center (NOC), without being physically close to the system.
Web Console
Web Console is a graphical user interface (GUI) lets you set or change the system configuration and monitor system activity. The Web Console application is accessible from any Web browser on the Telco management network. You can configure basic system parameters, Simple Network Management Protocol (SNMP) management parameters, set up subscribers, and monitor the current status of your chassis LEDs from anywhere on the network with Web Console.
Important Notes
This section contains important information about use of your Cisco 6400 UAC NSP.
Web Console Issues
The Web Console application is designed to use JavaScript, which is available with both Netscape Navigator and Microsoft Internet Explorer. However, a number of issues are present when using either application. To date, using Netscape Navigator 4.x has resulted in fewer issues than Microsoft Internet Explorer 4.x.
Before using the Web Console application, verify that your browser is set to use at least 4 MB (4096 KB) of cache memory.
The following sections tell how to deal with some of the browser issues affecting each application.
Microsoft Internet Explorer 4.x
Web Console might not reflect the most current redundancy status and auto synchronization setting because the check box and option buttons are not displayed properly. Therefore, you must verify your configuration by viewing the configuration file.
An empty dialog box might display after you apply new settings in any of the Web Console pages. If an empty dialog box is displayed, click the Internet Explorer Refresh button to view your new settings.
The show interface command on the Status page fails with Internet Explorer. There is no workaround, so this function is not available.
Netscape Navigator 4.x
If a blank window is displayed after you resize your Navigator window, click the Reload button to redisplay the page.
Frequent and rapid clicking on the Web Console Status page can cause syntax and LED errors. This problem is eliminated if the browser cache is set to 4096 KB.
Using Verbose Debug Options
On a dual-NSP system, switchovers can occur if verbose debugging commands, such as debug all or debug oir commands, are used. To avoid this situation when using verbose debug commands, execute the redundancy keepalive disable command at the EXEC prompt prior to turning on the debug command. After debugging is disabled, enter the redundancy keepalive enable command to restore normal system operation.
ATM Generic Flow Control Field
When an ATM cell is received on the NSP, the generic flow control (GFC) field of the ATM cell is passed without modification to the outbound virtual circuit. This is not compliant with the ATM Forum UNI specification, version 3.1, which requires all bits of the GCF field to be reset to zero.
Pre-Existing NSP Hardware Caveats
This section describes possible unexpected behavior by earlier hardware versions of the NSP. To determine your NSP part number (P/N) and hardware version, see the "Determining Your NSP Part Number and Hardware Version" section.
•
Affected Part Number: 800-03785-03
Symptom:
While the NSP is in Slot 0A of a single NSP system, the NRPs reset during NSP reloads or resets.
Workaround:
In a non-redundant system using an NSP of P/N 800-03785-03, place the NSP in Slot 0B.
•
Affected Part Number: 800-03785-03
Symptom:
The system remains at the ROMMON prompt after a crash instead of rebooting automatically.
Workaround:
To prevent this problem, set the config register boot field to 0x2.
If the workaround does not work, replace the NSP with P/N 800-03785-04 or higher.
•
A small percentage of NSPs might experience dropped cells. To determine if your NSP is affected, use the show controllers atm 0/0/0 EXEC command and check the values in the TPE column. This field counts the number of transmit parity errors and should display all zeros for a good system. If a non-zero value is displayed in the TPE column, replace the NSP with P/N 800-03785-05 or higher.
•
Affected Part Numbers:
•
•
•
Symptoms:
•
•
Since these symptoms might be caused by other problems, use the following table to determine the likelihood of this particular problem:
Workaround:
If you experience this problem, replace your NSP with P/N 800-03785-06 or higher, or with P/N 800-03785-03 with deviation sticker D99-3628 applied.
•
Affected Part Numbers:
800-03785-01, 800-03785-02, 800-03785-03, 800-03785-04, 800-03785-05, 800-03785-06, 800-03785-07Symptom:
NSP reports unknown cardtype when the chassis is populated primarily with NRPs.•
•
•
•
Determining Your NSP Part Number and Hardware Version
To determine the part number and hardware version of the NSP, use one of the following methods along with Table 3:
•
•
•
The following example displays the show hardware command output for an NSP:
Switch# show hardware6400 named Switch, Date:17:51:21 UTC Thu Mar 9 2000Feature Card's FPGA Download Version:0Slot Ctrlr-Type Part No. Rev Ser No Mfg Date RMA No. Hw Vrs Tst EEP----- ------------ ---------- -- -------- --------- -------- ------- --- ---1/0 NRP 73-3082-08 F0 17827878 Feb 02 00 00-00-00 4.255 0 22/0 NRP 73-3082-08 F0 17828272 Feb 02 00 00-00-00 4.255 0 23/0 NRP 73-3082-08 F0 17800617 Feb 16 00 00-00-00 4.255 0 24/0 NRP 73-3082-08 F0 17801802 Feb 22 00 00-00-00 4.255 0 25/0 NRP 73-3082-08 F0 17828075 Feb 06 00 00-00-00 4.255 0 27/0 NRP 73-3082-08 F0 17800637 Feb 16 00 00-00-00 4.255 0 28/0 622SM NLC 73-3868-02 A0 14327690 Oct 15 99 00-00-00 1.0 0 20B/FC NSP-PC 73-2996-06 A0 15794042 Mar 05 00 00-00-00 1.1 0 2
0B/PC FC-PFQ 73-2281-04 B0 17803407 Mar 05 00 00-00-00 4.1 0 2
Note
Table 3 NSP Part Numbers and Hardware Versions
Note
Software Caveats
This section contains open and resolved caveats for the current Cisco 6400 NSP Cisco IOS release only. Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats.
Caveats in Cisco IOS Release 12.0(7)T also apply to Release 12.0(7)DB2. For information on caveats in the Cisco IOS Release 12.0(7)T, refer to the "Caveats" sections in the Cross-Platform Release Notes for Cisco IOS Release 12.0. This document lists severity 1 and 2 caveats and only selected severity 3 caveats, and is located on Cisco.com and the Documentation CD-ROM.
Note
Open Caveats-Release 12.0(7)DB2
There are no open caveats specific to Cisco IOS Release 12.0(7)DB2 that require documentation in the release notes.
Resolved Caveats-Release 12.0(7)DB2
All the caveats listed in this section are resolved in Release 12.0(7)DB2. This section describes severity 1, 2, and selected severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/pcgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Open Caveats-Release 12.0(7)DB1
This section describes possibly unexpected behavior by Release 12.0(7)DB. This section describes severity 1, 2, and selected severity 3 caveats.
•
The dir disk0: command shows the disk is still present even after it has been removed. A message is sent to the console log when a PCMCIA disk is removed. Do not attempt any disk operations after the removal notice is displayed because they will not work. There is no workaround.
•
Using WebConsole, when one clicks the "configure" button for an NRP, one might receive an error message in the browser indicating that the browser "cannot locate the server". There is no workaround.
Resolved Caveats-Release 12.0(7)DB1
All the caveats listed in this section are resolved in Release 12.0(7)DB. This section describes severity 1, 2, and selected severity 3 caveats.
•
An active redundant NRP in an even slot will not pass some VC RADIUS information correctly. Instead of the ingress VPI/VCI, a RADIUS packet with a zero field is sent. Correct information is passed to the RADIUS server when the active redundant NRP is in an odd slot number.
•
In the NSP Cisco IOS Release 12.0(5)DB, we can't establish a non-UBR soft-vc from the ATM port going to the NRP. Various workarounds do exist:
1) Use 12.0(4)DB
2) Use UBR soft-vc•
An NSP running Cisco IOS Release 12.0(5)DB will not accept ATM PVC CTTR parameters with certain rx-cttr and tx-cttr values.
Related Documentation
The following sections describe the documentation available for the Cisco 6400 Universal Access Concentrator. The most up-to-date documentation can be found on the web via Cisco.com and on the Documentation CD-ROM. These electronic documents might contain updates and modifications made after the hard copy documents were printed.
These release notes should be used in conjunction with the documents listed in the following sections:
•
Release-Specific Documents
The following documents are specific to Release 12.0 T. They are located on Cisco.com and the Documentation CD-ROM:
•
To access the cross-platform Release Notes for Cisco IOS Release 12.0 T on Cisco.com, follow this path:
Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
To access the cross-platform Release Notes for Cisco IOS Release 12.0 on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Release Notes: Cross-Platform Release Notes
•
To access these documents, refer to the Software Center at this path on Cisco.com:
Service and Support: Technical Documentation
•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see the Caveats for Cisco IOS Release 12.0 T document, which contains caveats applicable to all platforms for all maintenance releases of Release 12.0 T.
To access the caveat document on Cisco.com, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
To access the caveat document on the Documentation CD-ROM, follow this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS 12.0: Caveats: Caveats for Cisco IOS Release 12.0 T
Note
Platform-Specific Documents
The documents listed in are available for the Cisco 6400 UAC. These documents are also available online at Cisco.com and on the Documentation CD-ROM.
To access Cisco 6400 documentation on Cisco.com, follow this path:
Service and Support: Technical Documents: Documentation Home Page: DSL Products: Cisco 6400
To access Cisco 6400 documentation on the Documentation CD-ROM, follow this path:
DSL Products: Cisco 6400
Feature Modules
Feature modules describe new features supported by Release 12.0 DB. Feature modules are available online only. In the next printing of the Cisco IOS documentation set, feature modules will be included as updates to the Cisco IOS Documentation set. Each feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference.
To reach the feature modules on the Cisco.com home page, click on this path:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases
To reach the feature modules on the Documentation CD-ROM, click on this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.0: New Feature Documentation: New Features in 12.0-Based Limited Lifetime Releases
Cisco IOS Software Document Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. These documents are shipped with your order in electronic form on the Documentation CD-ROM, unless you specifically ordered the printed versions.
Documentation Modules and Indexes
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
On Cisco.com and the Documentation CD-ROM, two master hot-linked indexes provide indexing information for the Cisco IOS software documentation set: an index for the configuration guides and an index for the command references. In addition, individual books contain a book-specific index.
To access these indexes on Cisco.com, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0: Cisco IOS Release 12.0 Configuration Guides and Command References: Configuration Guide Master Index or Command Reference Master Index
To access these indexes on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0: Cisco IOS Release 12.0 Configuration Guides and Command References: Configuration Guide Master Index or Command Reference Master Index
To access documentation related to an index entry, click on the page number following the entry.
Release 12.0 Documentation Set
details the contents of the Cisco IOS Release 12.0 software documentation set. The document set is available in electronic form, and also in printed form upon request.
Note
To access the Cisco IOS documentation set on Cisco.com, follow this path:
Service and Support: Technical Documentation: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.0
To access the Cisco IOS documentation set on the Documentation CD-ROM, follow this path:
Cisco IOS Software Configuration: Cisco IOS Release 12.0
Note
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml .
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/public/ordsum.html
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883We appreciate your comments.
Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
78-5788-07 Rev. C0
