Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 11.3 NA
August 2, 1999
These release notes for Cisco AS5300 universal access servers support Cisco IOS Release 11.3 NA, up to and including Release 11.3(11)NA. These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 11.3(11)NA, see the "Caveats" section and Caveats for Cisco IOS Release 11.3 T. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
The Cisco AS5300 universal access server is a versatile data communications platform that provides the functions of an access server, router, and digital modems in a single modular chassis. The access server is intended for Internet service providers (ISPs), telecommunications carriers, and other service providers that offer managed Internet connections, as well as medium to large sites that provide both digital and analog access to users on an enterprise network. By terminating both analog and digital calls on the same chassis simultaneously, the access server provides a clear, simple, and easy migration path from analog to digital dial access services.
For information on new features and Cisco IOS commands supported by Release 11.3 NA, refer to the "New and Changed Information" section and the "Related Documentation" section.
Early Deployment Releases
These release notes describe only Release 11.3 NA for Cisco AS5300 universal access servers and do not describe features that are available in Release 11.3 or other Release 11. 3 Early Deployment (ED) releases.
For information about features in Release 11.3, see the Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM.
For information about features in other platforms, see the Product Specific Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM.
System Requirements
This section describes the system requirements for Release 11.3 NA:
•
Determining the Version of Your Software Release
•
•
VCWare Requirements
Use the Cisco AS5300 universal access server in Cisco IOS Release 11.3(11)NA with VCWare Version 2.5x. Previous versions will not work.
Memory Requirements
describes the memory requirements for Cisco AS5300 feature sets for Cisco IOS Release 11.3(11)NA.
Hardware Supported
Cisco IOS Release 11.3 NA supports Cisco AS5300 universal access servers:
•
•
•
•
MICA modem cards are supported on the Cisco AS5300 and are subject to the boundaries described in the "Limitations and Restrictions" section.
Determining the Version of Your Software Release
To determine the version of Cisco IOS software running on your Cisco AS5300, log in to the Cisco AS5300 and enter the show version EXEC command.
access_server> show versionCisco Internetwork Operating System SoftwareIOS (tm) 5300 Software (c5300-is-mz), Version 11.3(11)NA, RELEASE SOFTWAREUpgrading to a New Software Release
For information about upgrading to a new software release, see the Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification product bulletin located on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97)
This product bulletin does not contain information specific to Cisco IOS Release 11.3, but provides generic upgrade information that may apply to Cisco IOS Release 11.3.
Microcode and Modem Code Software
Microcode is the firmware or portware that runs on the Microcom 12-port or MICA 6-port modem cards. Microcode software images are bundled with the system software image—with the exception of the Channel Interface Processor (CIP) microcode (all system software images). Bundling eliminates the need to store separate microcode images. When the access server starts, the system software unpacks the microcode software bundle and loads the proper software on all the interface processor boards.
Note
You can reach the release notes on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
You can reach the release notes on the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
The show modemcap command lists all versions of modem code running on the modem modules, residing in system Flash, and bundled with Cisco IOS software. Enter the show modemcap command to help you decide if you need to update your modem code files.
The Cisco IOS Software Upgrade Planner on CCO contains information about downloading software. To access this document from CCO, click Login on the CCO home page to access all information. From the CCO home page, go to the Software Support area, click Software Center, then Cisco IOS Software or IOS Upgrade Planner.
Feature Set Table
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Release 11.3(11)NA supports the same feature sets as Release 11.3 T, but Release 11.3(11)NA can include new features supported by Cisco AS5300 universal access servers.
Note
lists the features and feature sets supported by Cisco AS5300 universal access servers in Cisco IOS Release 11.3 NA and uses the following conventions:
•
•
•
Table 2 Selected Features and Feature Sets for the Cisco AS5300
APPN High-Performance Routing
No
No
No
APPN MIB Enhancements
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
APPN Scalability Enhancements
No
No
No
Bisync Enhancements:
–
–
–
Yes
Yes
Yes
Cisco MultiPath Channel (CMPC)
No
No
No
DLSw+ Enhancements:
–
–
–
–
–
–
–
Yes
Yes
Yes
FRAS Enhancements:
–
–
–
–
–
–
Yes
Yes
Yes
RIF Passthru in DLSw+
(3)
Yes
Yes
Yes
SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers
No
No
No
TN3270 LU Nailing
No
No
No
TN3270 Server Enhancements
No
No
No
Token Ring LANE
No
No
No
Tunneling of Asynchronous Security Protocols
Yes
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
DRP Server Agent Enhancements
(2)
Yes
Yes
Yes
Easy IP (Phase 1)
Yes
Yes
Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
Yes
Yes
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
IP Type of Service and Precedence for GRE Tunnels
(4)
Yes
Yes
Yes
PIM Version 2
Yes
Yes
Yes
TCP Enhancements:
–
–
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
Yes
Yes
DECnet Accounting
No
Yes
Yes
IPX Named Access Lists
No
Yes
Yes
IPX SAP-after-RIP
No
Yes
Yes
NLSP Enhancements
No
No
Yes
NLSP Multicast Support
No
Yes
Yes
Cisco Call History MIB Command Line Interface
Yes
Yes
Yes
Cisco IOS Internationalization
Yes
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
SNMPv2C
Yes
Yes
Yes
SNMP Inform Requests
(1)
No
No
Yes
Virtual Profiles
Yes
Yes
Yes
VPDN MIB
(2)
Yes
Yes
Yes
VPDN MIB and Syslog Facility
(3)
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
PIM Version 2
(2)
Yes
Yes
Yes
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
Automated Double Authentication
(3)
Yes
Yes
Yes
Certificate Authority Interoperability
(3)
No
No
No
Double Authentication
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
HTTP Security
Yes
Yes
Yes
Internet Key Exchange Security Protocol
(3)
No
No
No
IPSec Network Security
(3)
No
No
No
Message Banners for AAA Authentication
(4)
Yes
Yes
Yes
MS-CHAP Support
(3)
No
No
Yes
Named Method Lists for AAA Authentication and Accounting
(3)
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
TCP Intercept
No
No
Yes
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Vendor-Proprietary RADIUS -Additional Attributes
(3)
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
Yes
Yes
CLNS and DECnet Fast Switching over PPP
No
No
Yes
DECnet/VINES/XNS over ISL:
–
–
–
No
No
Yes
Fast-Switched Policy Routing
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
Yes
Yes
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
Telnet Extensions for Dialout
Yes
Yes
Yes
Virtual Templates for Protocol Translation
No
No
Yes
ATM MIB Enhancements
No
No
No
PAD Enhancements
No
No
Yes
PAD Subaddressing
Yes
Yes
Yes
Always On/Dynamic ISDN (AO/DI)
(3)
No
No
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
Yes
Dialer Watch
(2)
Yes
Yes
Yes
E1 R2 Country Support1
(2)
Yes
Yes
Yes
E1 R1 Support for only Taiwan2
(3)
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Layer 2 Forwarding—Fast Switching
Yes
Yes
Yes
Leased-Line ISDN at 128 kbps
No
No
No
Microsoft Point-to-Point Compression (MPPC)
(3)
Yes
Yes
Yes
MS Callback
(2)
Yes
Yes
Yes
Modem Management Enhancements
(2)
Yes
Yes
Yes
Multiple ISDN Switch Types
(3)
Yes
Yes
Yes
National ISDN Switch Types for BRI and PRI Interfaces (NI2)
(3)
Yes
Yes
Yes
PPP over ATM
No
No
No
Stackable Home Gateway
(3)
Yes
Yes
Yes
Switched 56K Digital Connections
(2)
Yes
Yes
Yes
Telnet Extensions for Dialout
(2)
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
Voice over IP
(2)
Yes
Yes
Yes
1 E1 R2 country support requires specific versions of MICA portware. For details, see the MICA portware release notes, which are available on CCO in the Software Center. Note that country support varies with the portware release level, and the release notes provide a list of countries.
2 E1 R1 signaling support for Taiwan requires MICA portware version 2.3.1.0.
New and Changed Information
This section lists new features available for the AS5300 for Release 11.3(11)NA.
No New Features in Release 11.3(8)NA through 11.3(10)NA
No new features were introduced in Release 11.3(8)NA through 11.3(11)NA for the Cisco AS5300 universal access server.
New Features in Release 11.3(7)NA
This section describes the new features for the Cisco AS5300 universal access server in Cisco IOS Release 11.3(7)NA.
E1 R2 Support
R2 signaling support has been added to existing ISDN PRI over a channelized E1 interface. This feature is available in countries supporting R2 signaling.
Interactive Voice Response
The following two new Interactive Voice Response (IVR) scripts have been added to this release:
•
This script is similar to clid_authen_col_npw, but it allows two retries (3 tries total) for entering the account and password. For each of the two retries, it plays a special retry message.
•
This is similar to clid_col_npw_3, but it does not collect a personal identification number (PIN). Instead, it uses the collected account number with a NULL password for authentication.
New Features in Release 11.3(6)NA2
This section describes the new features for the Cisco AS5300 universal access server in Cisco IOS Release 11.3(6)NA2, which introduced features supported by IP Telephony. For detailed information about these features, refer to Configuring the Cisco AS5300 for Voice Service Provider Features, which is an addendum to the Cisco AS5300 Software Configuration Guide.
The IP Telephony features include enhancements made to the functionality and configuration of both the gateway and the VoIP gatekeeper. The architecture of these features provides the quality of service (QoS), stability, and functionality necessary for carrier class real-time IP communications services. The Cisco gateway functionality and gatekeeper functionality work in concert to provide the ITU-T H.323 infrastructure.
To provide understanding of which features affect which portions of the internetworking environment, the various IP Telephony features are described in the following two categories:
•
•
Gatekeeper
The gatekeeper can manage a zone and provide bandwidth management and address resolution services to gateways when present in the network.
Gateway RAS Implementation
This refers to the Cisco AS5300 universal access server with voice cards and the Voice over IP (VoIP) image. Gateways are also referred to as VoIP gateways.
The gateway can terminate a call from the public switched telephone network (PSTN), provide user admission control using interactive voice response (IVR), direct the call to the destination, terminate the call from another gateway and send the call to the PSTN, and finally provide accounting records for the calls.
Registration, Admission, and Status (RAS) is a signaling function that performs registration, admissions, status, and disengage procedures between the VoIP gateway and the gatekeeper.
The gateway relies on Cisco IOS command-line interface commands outside the gateway configuration mode to configure the AAA servers. The two following RAS command fields have been added to the dial-peer entry to enable the RAS implementation:
•
•
AAA Enhancements
AAA represents authentication, authorization, and accounting features that are required in the VoIP gateway. The standard Cisco AAA functionality is enhanced to allow calls to:
•
•
The AAA authentication feature permits RADIUS to authenticate users on the gateway. It is normally used with IVR to check the legitimacy of a prospective gateway user based on an account number (collected by IVR) or based on answer number identification (ANI).
Interactive Voice Response
This application provides basic IVR capabilities necessary to collect caller PINs, passwords, and destination phone numbers. IVR consists of simple voice prompting and digit collection to collect information from the caller for the purpose of authenticating the caller and identifying the destination.
"Simple" IVR allows the use of one of several interactive voice response scripts embedded in Cisco IOS software. The ability to modify the embedded scripts is not yet provided. However, you can modify the audio files (for the prompts).
The IVR application:
•
•
•
An IP/PSTN gateway can have several different IVR applications to accommodate many different gateway services.
ISDN Redirect Number Support
This feature supports the redirecting call feature of the VoIP gateway. The redirecting number is an optional field of the Q.931 setup message.
When a local exchange carrier (LEC) switch detects an incoming call that is destined for a busy or nonanswering party, the switch formulates a Q.931 setup message with the redirecting number field set to the originally called number, and sends it to the gateway. The called party number of the setup message will be set to one of the DNIS access numbers belonging to the gateway.
If a redirect number is present in an incoming call, then it is used in place of the called number (DNIS).
Rotary Call Pattern
This feature provides the ability, under certain circumstances, to route an incoming call arriving by one telephony interface back out by another telephony interface. This is primarily used to provide reliable service during network failures. Call establishment via Rotary Call Pattern will be supported via rotary group support of dial peers where multiple dial peers may match a given destination telephone number and will be selected in sequence.
In prior releases of VoIP, if you wanted the system to search through a number of destinations when a given number was dialed, you needed to configure those dial peers with the same destination pattern. Now with the Rotary Call Pattern feature, if you want the destinations to be tried in a certain order, you can assign preference (using the preference command) to the dial peers to reflect the desired order.
T1 CAS
Channel Associated Signaling (CAS) is the transmission of signaling information within the voice channel. In addition to receiving and placing calls, T1 CAS:
•
•
•
•
The development of this feature enhances and integrates T1 CAS capabilities on the DSP Module (DSPM) in order to support central office (CO) and PBX configurations for voice calls.
No New Features in Release 11.3(4)NA through 11.3(6)NA
No new features were introduced in these releases for the Cisco AS5300 universal access server.
No Release 11.3(3)NA
Cisco IOS Release 11.3(3)NA was not released.
New Features in Release 11.3(2)NA
This section describes the new features for the Cisco AS5300 universal access server in Cisco IOS Release 11.3(2)NA.
Voice over IP
The Voice over IP (VoIP) software enhancement was added to the Cisco AS5300 platform for Cisco IOS Release 11.3(2)NA. VoIP enables a Cisco AS5300 to carry live voice traffic (for example, telephone calls and faxes) over an IP network.
When used as a PTSN gateway, VoIP leverages the standardized use of H.323-based Internet telephone client applications.
VoIP on the Cisco AS5300 supports two primary applications:
•
•
Major customer applications for VoIP include:
•
•
•
•
To use VoIP, which is primarily a software feature on the Cisco AS5300, you must install the VoIP feature card (VFC) that contains multiple digital signal processor (DSP) modules. The VFC uses the Cisco AS5300 quad T1/E1 PSTN interface and LAN or WAN routing capabilities to provide up to a 48- or 60-channel gateway for VoIP packetized voice traffic to and from T1/E1 time-division multiplexing (TDM) traffic.
Features in the Parent Release 11.3 T
Features for the Cisco AS5300 in Release 11.3 T are also supported in the current Cisco IOS Release 11.3 NA. For information about these features, see the current Release Notes for Cisco AS5300 for Cisco IOS Release 11.3 T.
Features added to the Cisco AS5300 for Cisco IOS Release 11.3 T between Cisco IOS Releases 11.3(2)T and Cisco IOS Release 11.3.(8)T, are not supported in Cisco IOS Release 11.3(10)NA unless they have also been added separately to Cisco IOS Release 11.3 NA and support is explicitly stated to coincide in the release notes for Cisco IOS Release 11.3(10)NA. Currently, no such features have been added. Check the feature set in the Release Notes for Cisco AS5300 for Cisco IOS Release 11.3 T to determine at which maintenance release a given feature was added.
Limitations and Restrictions
Release 11.3 NA is an Early Deployment (ED) release of software to support the Cisco AS5300 universal access servers. Release 11.3 NA is the same as Release 11.3 T, except that the following caveats have been resolved in Release 11.3 NA:
AAA Accounting
If you are using CiscoSecure ACS for Windows NT and H.323 accounting (AAA accounting), use version 2.1.8.4 or higher of CiscoSecure.
MICA and Microcom Modems
You can use a voice card in the Cisco AS5300 with MICA modems installed in the other feature card slot, but the equivalent configuration with Microcom modems is not supported.
Note
Important Notes
The following section contains important notes about Cisco IOS Release 11.3 that may apply.
Voice Telephony over the Internet
In certain countries, use of these products or provision of voice telephony over the Internet may be prohibited and subject to laws, regulations or licenses, including requirements applicable to the use of the products under telecommunications and other laws and regulations; customers must comply with all such applicable laws in the countries where they intend to use the products.
Cisco IOS Release 11.3 NA End of Sales and End of Engineering
End of Engineering (EOE) means that there are no more regularly scheduled maintenance releases. The last maintenance release scheduled on the EOE date is only available through CCO and Field Service Operations—not through manufacturing.
•
•
EOS and EOE releases are subject to change. For the most up-to-date information on the status of EOS or EOE, see the End of Sales and End of Engineering for Cisco IOS Software Releases product bulletins located on CCO.
Ongoing support for functionality in Releases 11.3, 11.3 NA, and 11.3 T is available in Cisco IOS Release 12.0(3)T and later maintenance releases of Cisco IOS Release 12.0 on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click End of Sales and End of Engineering for Cisco IOS Software Releases 11.3 and 11.3 T (#847: 12/98) or Cisco IOS Software 11.3 NA EoS and EoE (#849:12/98)
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section contains open and resolved caveats only for the current Cisco IOS maintenance release.
All caveats in Release 11.3 and Release 11.3 T are also in Release 11.3(11)NA.
For information on caveats in Cisco IOS Release 11.3, see "Important Notes and Caveats for Release 11.3"in Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM. These release notes list severity 1 and 2 caveats affecting all maintenance releases.
For information on caveats in Cisco IOS Release 11.3 T, see Caveats for Cisco IOS Release 11.3 T on CCO and the Documentation CD-ROM.
Note
Open Caveats—Release 11.3(11)NA
This section describes possibly unexpected behavior by Release 11.3(11)NA and describes only severity 1 and 2 caveats.
Miscellaneous
•
BPI MIB will now be available in released code.
•
When running 11.3.10NA image, ingress gw may display wrong cause code.
•
This fixes CM status display in CMTS when the modem goes offline with BPI turned on and key expiration.
Resolved Caveats—Release 11.3(11)NA
All the caveats listed in this section are resolved in Release 11.3(11)NA. This section only describes severity 1 and 2 caveats.
Basic System Services
•
Certain Internetwork Status Monitor (ISM) NetView users can issue non-enable mode commands without router authentication. Users accessing the router through NetView must be authenticated through NetView's security methods, which may include RACF and SAF. Mainframe users can be restricted from issuing any router commands through the restriction of the RUNCMD within NetView. Users issuing enable mode commands must be authorized to issue this level of command through ISM, and must possess the ENABLE mode password. If the router is controlled by TACACS+, the ISM user must have a TACACS+ User ID and Password to issue enable level commands.
show user : command has been modified : the user field is filled up by the host name.
Two options have been added to the following commands : sna host dspu host
Options are : no-enable and high-security. These options have to be configured with focalpoint.
•
•
enable or en quit
exit
show ?
show appn
show version
show controller
show extended
show dspu
show sna
show tech
show memory
show process
show interface
show environment
show protocol
IBM Connectivity
•
There is a problem whereby DLSw Lite peers leak CLS connect request buffers. If possible, the customer can try using a different peer type. This patch will free an outstanding connect request if additional requests are received while the first is still pending.
Interfaces and Bridging
•
Symptom: Crash in frf9_preComp()
Condition: Mostly frequently will occur during times when router traffic is heavy which causes memory usage to increase and a possible low memory condition to occur.
Workaround: Disable compression or use a different type.
Miscellaneous: Since this problem is aggravated by a low memory condition tuning the memory tuning can help prevent it from occurring but will not guarantee it can not happen.
•
This is caused by an over-write issue in BSS area with FDDI modules equipped which has potential to cause serious problem such as crash in 12.0T.
•
A PA-4R-DTR port may reset under the following circumstances:
•
•
•
When this problem occurs, the PA-4R-DTR port will reset, and the ring will experience a beacon.
Workaround: Make sure the DTR port is not the active monitor on the ring. This can be done by ensuring that the MAC-address of the DTR card is not the highest MAC-address on the physical ring.
IP Routing Protocols
•
IP access lists fail to block pings on interfaces configured for policy routing with IP route-cache policy.
•
Some IP fragments may be incorrectly filtered out by access lists.
•
DNS replies passing from "inside" to "outside" via NAT are not NAT translated correctly in many cases. There is no work around.
Miscellaneous
•
AS5300 will get bus error when under heavy load caused by outgoing Modem calls. Have tested with IOS 11.3(9)T and 11.3(8.5)T with same results.
Problem is reproducible within minutes.
•
Problem description: When "cable ip-broadcast-echo" is enabled, under certain timing conditions may cause a buffer leak.
Workaround: Do not enable "cable ip-broadcast-echo" and "cable ip-multicast-echo".
•
Symptom : The NM-1FE-TX fails to autonegotiate properly when connected through an SMF connector.
Analysis : Setting the speed to 100 manually solves the problem. An interface speed command with the following syntax is being added to overcome this. The default behaviour would be to autonegotiate.
[no] speed {10 | 100 | auto}
•
When port info is passed from LAC and 'vpdn aaa attribute nas-port vpdn-nas' is configured, it should be mapped to correct NAS-Port-Type value.
•
Configuring PPP encaplusation on an interface and the making that interface a member of a bridge group gives tracebacks and fair-queue not properly initialized messages. Remove brdging from the interface or turning off fair queue the massages dissappear.
00:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:39: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:39: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:40: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:40: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:40: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:40: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020 00:06:40: Fair Queue:packet not initialized properly: 0, 0 , 38 00:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020
•
Under conditions of stress (if the ESA is bringing up a large number of crypto sessions simultaneously), it may either enter a race condition or get the crypto initiation messages wedged in the input-q of the interface doing encryption.
Wide-Area Networking
•
DDR with dialer dtr does not reset DTR to a down state after an unsuccessful call attempt. Unsuccessful in this case means that DDR is triggered, DTR is raised, but the modem/TA attached to the serial port never connects so that DCD does not come up.
This can be verified by viewing show dialer to ensure that the dialer state is idle, and then show interface serial x to check the state of DTR.
•
Customer is deterministically getting a crash (segV) when dialer rotor best is configured and 'deb dialer' is started once traffic trigger a call.
•
Reliable PPP can cause an intermittent crash when used with WFQ. Workaround is to disable Reliable PPP or WFQ.
Troubleshooting
The following section provides troubleshooting information for the Cisco AS5300 universal access server in Cisco IOS Release 11.3 NA.
Error Messages in Cisco IOS Release 11.3(2)NA: Error Messages for Telephony Voice Calls on the PSTN Interface
The following CSM-generated error messages can appear in this release.
Error MessageInvalid voice interface controller:groupExplanation The voice interface defined by controller:group is not yet defined within the voice software, but attempts were made to use this interface.
Recommended Action
Error MessageUndefined dsx0 interface for controllerExplanation The dsx0 interface for the specified controller is not defined, but the voice software used it.
Recommended Action Internal software fault. Contact your field service representative if this message coincides with dropped calls.
Error MessageNo signaling data block is available to build the voice interfaceExplanation The voice software might be out of memory.
Error MessageThe Voice Telephony Service Provider has rejected our request to add this voice interfaceExplanation The voice software was unable to report a new signaling interface to the voice telephony service provider.
Error MessageNo memory is available to build the voice interfaceExplanation The voice software was unable to allocate memory to build a voice interface data structure. The system might be out of memory.
Error MessageNo memory is available to build any internal data structure for the voice software.Explanation The voice software was unable to allocate memory to build any internal data structures. The system might be out of memory.
Error MessageCSM failed to get a free dsp channel from the DSP Resource Manager (DSPRM) to handle an incoming callExplanation The voice software was unable to obtain a free DSP channel from the DSP Resource Manager. All the DSPs have been used to process calls or have been taken out of service.
Error MessageCSM failed to get a free dsp tdm channel from the DSP Resource Manager (DSPRM) to handle an incoming callExplanation The voice software was unable to obtain the TDM channel for a free DSP from the DSP Resource Manager. All the DSPs have been used to process calls or have been taken out of service.
Error MessageCannot find the voice data block which matches an asynchronous response for a callExplanation Internal software fault. Contact your field service representative if this message coincides with dropped calls.
Related Documentation
The following sections describe the documentation available for Cisco AS5300 universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 11.3 and are located on CCO and the Documentation CD-ROM.
•
You can reach Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
You can reach Cross-Platform Release Notes for Cisco IOS Release 11.3 on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
•
You can reach these documents on CCO at:
Service & Support: Technical Documents
•
As a supplement to the caveats listed in "Caveats" in these release notes, see Caveats for Cisco IOS Release 11.3 T, which contains caveats applicable to all platforms for all maintenance releases of Release 11.3 T.
You can reach the caveats document on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Caveats for Cisco IOS Release 11.3 T
You can reach the caveats document on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Caveats for Cisco IOS Release 11.3 T
Note
Platform-Specific Documents
The following Cisco AS5300 universal access servers documents are available:
•
•
•
•
Cisco AS5300 Universal Access Server Install and Configure•
•
•
•
•
The above documentation can be found on CCO and on the Documentation CD-ROM:
•
Service & Support: Technical Documents: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5300
•
Access Servers and Access Routers: Access Servers: Cisco AS5300
Feature Modules
Feature modules describe new features supported by Release 11.3 NA and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.
You can reach the feature modules on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3: New Features in Release 11.3
You can reach the feature modules on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3: New Features in Release 11.3
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
You can reach these documents on CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS Release 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
You can reach these documents on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS Release 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
Release 11.3 Documentation Set
describes the contents of the Cisco IOS Release 11.3 software documentation set, which is available in electronic form and also in printed form upon request.
Note
You can reach the Cisco IOS documentation set from CCO at:
Service & Support: Technical Documents: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3
You can reach the Cisco IOS documentation set on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-5280-10
Guest
