Release Notes for the Cisco 4000 Series for Cisco IOS Release 11.3
August 2, 1999
These release notes for the Cisco 4000 series support Cisco IOS Release 11.3, up to and including Release 11.3(11). These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, changes to the microcode or modem code and related document.
For a list of software caveats that apply to Release 11.3(11), see the "Caveats" section. The caveats are updated for every maintenance release.
Use these release notes with the cross platform Release Notes for Cisco IOS Release 11.3 on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Contents
These release notes describe the following topics:
Introduction
The Cisco 4000 series routers offer Flash memory EPROM technology as a standard feature. Flash memory EPROMs enable you to distribute new software releases from a central location. After the software is distributed, the routers can reboot from programs stored in local Flash memory.
All models provide a configurable modular router platform by using network processor modules (NPMs)—individual removable cards used for external network connections. Because the router's modules support many variations of protocols, line speeds, and transmission media, the Cisco 4000 series can accommodate all types of network computing environments. As Cisco introduces new modules, the Cisco 4000 series can be upgraded to keep pace with technological advances.
System Requirements
•
Determining the Version of Your Cisco IOS Software Release
•
Memory Requirements
Table 1 Memory Requirements for the Cisco 4000 Series
IP
c4000-i-mz
4 MB Flash
16 MB DRAM
RAM
IP Plus
c4000-is-mz
4 MB Flash
16 MB DRAM
RAM
IP Plus 40
c4000-is40-mz
4 MB Flash
16 MB DRAM
RAM
IP Plus 56
c4000-is56-mz
4 MB Flash
16 MB DRAM
RAM
IP/IPX/AT/DEC
c4000-d-mz
4 MB Flash
16 MB DRAM
RAM
IP/IPX/AT/DEC Plus
c4000-ds-mz
4 MB Flash
16 MB DRAM
RAM
Enterprise Plus
c4000-js-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise Plus 40
c4000-js40-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise Plus 56
c4000-js56-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise/APPN Plus
c4000-ajs-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 40
c4000-ajs40-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 56
c4000-ajs56-mz
8 MB Flash
32 MB DRAM
RAM
IP
c4000-i-mz
4 MB Flash
8 MB DRAM
RAM
IP Plus
c4000-is-mz
4 MB Flash
8 MB DRAM
RAM
IP Plus 40
c4000-is40-mz
4 MB Flash
16 MB DRAM
RAM
IP Plus 56
c4000-is56-mz
4 MB Flash
16 MB DRAM
RAM
IP/IPX/AT/DEC
c4000-d-mz
4 MB Flash
8 MB DRAM
RAM
IP/IPX/AT/DEC Plus
c4000-ds-mz
4 MB Flash
16 MB DRAM
RAM
Enterprise Plus
c4000-js-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise Plus 40
c4000-js40-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise Plus 56
c4000-js56-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise/APPN Plus
c4000-ajs-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 40
c4000-ajs40-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 56
c4000-ajs56-mz
8 MB Flash
32 MB DRAM
RAM
IP
c4500-i-mz
4 MB Flash
161 MB DRAM
RAM
IP Plus
c4500-is-mz
4 MB Flash
162 MB DRAM
RAM
IP Plus 40
c4500-is40-mz
4 MB Flash
32 MB DRAM
RAM
IP Plus 56
c4500-is56-mz
4 MB Flash
32 MB DRAM
RAM
IP/IPX/AT/DEC
c4500-d-mz
4 MB Flash
16 MB DRAM
RAM
IP/IPX/AT/DEC Plus
c4500-ds-mz
8 MB Flash
16 MB DRAM
RAM
Enterprise Plus
c4500-js-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise Plus 40
c4500-js40-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise Plus 56
c4500-js56-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus
c4500-ajs-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 40
c4500-ajs40-mz
8 MB Flash
32 MB DRAM
RAM
Enterprise/APPN Plus 56
c4500-ajs56-mz
8 MB Flash
32 MB DRAM
RAM
1 The IP feature set for Cisco 4500, Cisco 4500-M, and Cisco 4700 platforms for Release 11.3(4) had a required DRAM memory of 32 MB DRAM.
2 The IP Plus feature set for Cisco 4500, Cisco 4500-M, and Cisco 4700 platforms for Release 11.3(4) had a required DRAM memory of 32 MB DRAM.
Hardware Supported
Cisco IOS Release 11.3 supports the Cisco 4000 series routers:
•
•
•
Determining the Version of Your Cisco IOS Software Release
To determine the version of Cisco IOS software running on your Cisco 4000 series router, log in to the router and use the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) 4000 Software (C4000-JS-MZ), Version 11.3(11), RELEASE SOFTWAREUpgrading to a New Software Release
For information on upgrading to a new software release, see Cisco IOS Software Release 11.3 Upgrade Paths and Packaging Simplification product bulletin located on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97)
Feature Set Tables
Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
Table 3 Feature Sets Supported by the Cisco 4000 Series
IP
Basic1
c4000-i-mz
Cisco 4000, Cisco 4000-M
c4500-i-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
IP Plus
Plus2
c4000-is-mz
Cisco 4000, Cisco 4000-M
c4500-is-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
IP Plus 40
Plus, Plus 403
c4000-is40-mz
Cisco 4000, Cisco 4000-M
c4500-is40-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
IP Plus IPSec 56
Plus, Plus IPSec 564
c4000-is56i-mz
Cisco 4000, Cisco 4000-M
c4500-is56i-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Desktop IBM (IP/IPX/AppleTalk/DEC)
Basic
c4000-d-mz
Cisco 4000, Cisco 4000-M
c4500-d-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Desktop IBM Plus (IP/IPX/AppleTalk/DEC Plus)
Plus
c4000-ds-mz
Cisco 4000, Cisco 4000-M
c4500-ds-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise Plus
Plus
c4000-js-mz
Cisco 4000, Cisco 4000-M
c4500-js-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise Plus 40
Plus, Plus 40
c4000-js40-mz
Cisco 4000, Cisco 4000-M
c4500-js40-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise Plus 56
Plus, Plus 56
c4000-js56-mz
Cisco 4000, Cisco 4000-M
c4500-js56-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise/APPN Plus
Plus
c4000-ajs-mz
Cisco 4000, Cisco 4000-M
c4500-ajs-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise/APPN Plus 40
Plus, Plus 40
c4000-ajs40-mz
Cisco 4000, Cisco 4000-M
c4500-ajs40-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
Enterprise/APPN Plus 56
Plus, Plus 56
c4000-ajs56-mz
Cisco 4000, Cisco 4000-M
c4500-ajs56-mz
Cisco 4500, Cisco 4500-M, Cisco 4700
1 This feature set matrix term is offered in the Basic feature set.
2 This feature set matrix term is offered in the Plus feature set.
3 This feature set matrix term is offered in the encryption feature sets which consist of 40-bit (Plus 40) data encryption feature sets.
4 This feature set matrix term is offered in the encryption feature sets which consist of 56-bit (Plus 56) data encryption feature sets.
CautionCisco IOS images with strong encryption (including, but not limited to, 168-bit (3DES) encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, you must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.
and list the features and feature sets supported in Cisco IOS Release 11.3(11) by the Cisco 4000/4000-M and Cisco 4500/4500-M/4700/4700-M routers, respectively. Both tables use the following conventions to identify features:
•
•
Note
New and Changed Information
Cisco IOS Release 11.3(1) and all later releases support features in the following categories:
•
•
•
•
•
•
•
•
•
•
•
For more information about new features, see the "Related Documentation" section.
Important Notes
The following sections contain important notes about Cisco IOS Release 11.3 and can apply to the Cisco 4000 series.
Cisco IOS Release 11.3, 11.3 NA, and 11.3 T End of Sales and End of Engineering
End of Engineering (EOE) means there are no more regularly scheduled maintenance releases. The following maintenance releases scheduled on the EOE date are only available through CCO and Field Service Operations—not through manufacturing:
•
•
EOS and EOE releases are subject to change. For the most up-to-date information on the status of EOS or EOE, see End of Sales and End of Engineering for Cisco IOS Software Releases product bulletin on CCO.
Ongoing support for functionality in Releases 11.3, 11.3 NA, and 11.3 T is available in Cisco IOS Release 12.0(3)T and later maintenance releases of Cisco IOS Release 12.0 on CCO at:
Service & Support: Product Bulletins: Software
Under Cisco IOS 11.3, click End of Sales and End of Engineering for Cisco IOS Software Releases 11.3 and 11.3 T (#847: 12/98) or Cisco IOS Software 11.3 NA EOS and EOE (#849:12/98)
Booting Cisco 4000 Series Routers
You must use the Cisco IOS Release 9.14 rxboot image for Cisco 4000 series routers because the Release 11.0 rxboot image is too large to fit in the ROMs. (Note that rxboot image size is not a problem for Cisco 4500 series routers.) However, because the Release 9.14 rxboot image does not recognize new network processor modules, such as the Multiport Basic Rate Interface (MBRI), its use causes two problems:
•
•
Bad interface specificationNo interface specified - IP addressBad interface specificationNo interface specified - IP addressEnabling IPX Routing
The Token Ring interface is reset whenever IPX routing is enabled on that interface.
Forwarding of Locally Sourced AppleTalk Packets
Cisco's implementation of AppleTalk does not forward packets with local-source and destination network addresses. This behavior does not conform to the definition of AppleTalk in Apple Computer's Inside AppleTalk publication. However, this behavior is designed to prevent any possible corruption of the AppleTalk Address Resolution Protocol (AARP) table in any AppleTalk node that is performing MAC-address gleaning.
Missing Source-Route Bridging Commands
Due to a production problem, many source-route bridging commands were omitted from the printed version of the Cisco IOS Software Command Summary (78-4746-01). For complete documentation of all source-route bridging commands refer to the Bridging and IBM Networking Command Reference (78-4743-01). You may also obtain the most current documentation on Cisco Connection Online (CCO) or on the Documentation CD-ROM.
New TACACS+ Attribute-Value Pair
A new authorization feature was added in Cisco IOS Release 11.3(1) that allows for separate configuration and authorization of Multilink PPP. This can cause MLP authorization to fail in TACACS+ servers that do not include the relevant authorization permissions in the configuration.
For TACACS+, the following attribute-value (AV) pair should be added for all users who are allowed to negotiate Multilink PPP:
service = ppp protocol = multilink {
Using LAN Emulation
Note the following information regarding the LAN Emulation (LANE) feature in Cisco IOS Release 11.3:
•
•
•
•
•
•
Using Source-Route Transparent Bridging and Source-Route Bridging on Cisco 2500 and Cisco 4000 Series Routers
Certain products containing the Texas Instruments TMS380C26 Token Ring controller do not support source-route transparent bridging (SRT). SRT is the concurrent operation of Source Router Bridging (SRB) and transparent bridging on the same interface. The affected products, shipped between March 30, 1994 and January 16, 1995, are the Cisco 4000 NP-1R, Cisco 4000 NP-2R, Cisco 2502, Cisco 2504, Cisco 2510, Cisco 2512, Cisco 2513, and Cisco 2515.
Units shipped before March 30, 1994 or after January 16, 1995, are not affected. They use the Texas Instruments TMS380C16 Token Ring controller, which supports SRT.
SRT support is necessary in two situations:
•
•
Beginning with Cisco IOS Release 10.3(1), SRB in the following Cisco IOS feature sets is no longer supported:
•
•
To use SRB, you need one of the following feature sets:
•
•
•
•
•
•
In most non-IBM Token Ring environments, the multiring feature in IP, IP/IPX, and Desktop eliminates the need for IP/IBM base, IP/IPX/IBM base, IP/IPX/IBM/APPN, Desktop/IBM base, Enterprise, or Enterprise/APPN.
Caveats
Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
For information on caveats in Cisco IOS Release 11.3, see "Important Notes and Caveats for Release 11.3" section in Cross-Platform Release Notes for Cisco IOS Release 11.3 document located on CCO and the Documentation CD-ROM. These release notes contain caveats affecting all maintenance releases and list severity 1 and 2 caveats for Cisco IOS Release 11.3.
Note
Caveats for Release 11.3(1) through 11.3(11).
This section describes possibly unexpected behavior by Release 11.3(11). Unless otherwise noted, these caveats apply to all 11.3 releases up to and including 11.3(11).
Access Server
•
Cable length options are missing for T1 lines on Cisco AS5200 access servers. The options exist for Cisco AS5300 access servers in Cisco IOS Releases 11.2 and 11.3.
Cisco should remove conditional compile and provide similar functionality.
Basic System Services
•
When hardware compression is enabled, packets are normally fast switched. If the user turns fast switching off and then back on, fast switching remains disabled.
Workaround is to reconfigure compression by using the no compress and then the compress stac commands.
•
When configured for SDLC, serial ports on a Cisco MC3810 may report input abort errors when the clock rate is greater than 38,400 bps. These errors do not affect performance; they are not typically input aborts. This problem does not result in retransmitted frames, and there is no performance impact.
•
All router interfaces are reset with their states changing from up to down and then back to up again. The cause for the restart is:
System restarted by error - an arithmetic exception, PC 0x6016B6E0•
When doing FRF.9 compression with the CSA, it may be impossible to compress packets with certain repetitive patterns. The CSA can decompress these same packets.
•
A router running Cisco IOS Release 11.3(8) may experience a software forced crash caused by memory corruption.
•
After a succesful completion of the SNMP poll to the CISCO-MEMORY-POOL-MIB on a Cisco AS5800 access server, the poll may fail for several minutes before it becomes available again.
IBM Connectivity
•
A Cisco 3600 series router running Cisco IOS Release 11.3 T may restart with either the following bus error or a software forced crash when running BSTUN. There is no workaround.
System restarted by error - a Software forced crash, PC 0x601C4398System image file is "flash:c3640-is-mz.113-4", booted via flash•
Some Cisco 4500 and 4700 series routers with a 2-Port Token Ring Network Processor Module (NP-2R) hang once a week displaying a "%SYS-2-INPUTQ: INPUTQ set, but no IDB" message. All revision levels of the motherboard are affected.
•
An APPN Network Node (NN) router has consumed 40 MB for the APPN process.
•
A BSTUN router running Cisco IOS Release 11.3(10) hangs and crashes. No workaround is available.
•
When configuring for FRAS BAN with DDR backup, the backup is only driven if the primary interface goes to the down/down state. If the DLCI is lost, the interface goes to the up/down state and the backup is not driven.
•
This problem concerns a Cisco 4700 series router defined as APPN NN with an APPN link across Frame Relay RFC 1490 to an IBM NN950 configured as a NN. Occasionally, when the DLCI fails, the APPN link does not restart, even though the router is configured to retry infinitely.
•
No SNA traffic passes between a server and a Cisco Network Node router because the Network Node was using DLSw flow control to disallow the sending of further SNA traffic by the server.
Interfaces and Bridging
•
A Cisco 7500 series router running Cisco IOS Release 11.3(7) does not crash, but the Fast Ethernet interface goes down with the following message.
%SYS-2-QCOUNT: Bad dequeue 611E3EBC count -1 -Process= "<interruptlevel>", ipl= 66d18h: %ALIGN-3-SPURIOUS:Spurious memory access made at 0x601A35D8 reading 0x1C 6d18hInterface FastEthernet12/1, changed state to downLine protocol on Interface FastEthernet12/0,changed state to upThe only way to bring the router up is to reload it.
Possible workaround: Disable weighted fair-queue.
•
A Cisco router running BSC/BSTUN on a PowerQUICC serial interface at half-duplex causes bad queue error messages.
Workarounds:
•
•
•
When a router is configured for FRF.9 compression, input packets are counted twice: once in compressed format and again in uncompressed format.
For every received packet the "input pkts" and the "in bytes" fields (in output from the show frame pvc command) are invalid.
Workaround: Disable FRF.9 compression by using the no frame-relay ip ip-address command.
IP Routing Protocols
•
The new ip spd mode aggressive configuration command is available. When configured, all IP packets that fail sanity check (such as "bad checksum not version 4" and "bad TTL") are dropped aggressively to guard against bad IP packets spoofing. The show ip spd command displays whether aggressive mode is enabled or not. SPD random drop in RSP is supported.
When enabled, Selective Packet Discard (SPD) now works as follows:
•
•
•
•
To avoid an input interface that takes too many router resources, new packets (SPD or non-SPD) received from that interface are dropped when the interface has more than the input hold queue limit of input packets in the router.
•
EIGRP does not trigger the selection of a new route when one of the less favorable or equal paths is removed from the routing table. The route disappears but no new route is selected from the topology table.
•
IP access lists always permit IP fragments.
There is no workaround for this problem.
•
Using the show ip igmp group command may cause a bus error reload if an IGMP entry is deleted during the execution of the show ip igmp group command.
There is no workaround.
Miscellaneous
•
A BRI leased line interface on a Cisco 3600 series router that has been configured for XNS may not transfer data.
Workaround: Clear the interface or reload the router following the configuration change.
•
When you have two simultaneous accesses to NVRAM (for example, one access from the console and another access from a Telnet session), one session might attempt to issue the show configuration command and might pause at the More prompt while the other session issues the write memory command. This problem is unlikely during normal router usage. There is no workaround.
•
While waiting for a crypto key exchange session with a Telnet session into the router, the user cannot abort the crypto key exchange session.
Workaround: Enter the show tcp bri and clear tcp tcb commands in the following manner:
router(config)#crypto key-ex passive Enter escape character to abort if connection does not complete. Wait for connection from peer[confirm] Waiting ....telnet> quit Connection closed. janedoe@janedoe-ultra:/users/janedoe> telnet router Trying 171.21.114.109... Connected to router.cisco.com. Escape character is '^]'.User Access VerificationPassword: router>enable Password:router#configure terminal Enter configuration commands, one per line. End with CNTL/Z. router(config)#crypto key-ex passive TCP bind failed: Address already in userouter(config)#exit router#show tcp bri TCB Local Address Foreign Address (state) 60C3DF74 router.cisco.com.23 janedoe-ultra.ci.42272 ESTAB 60A23A24 router.cisco.com.23 janedoe-ultra.ci.42271 CLOSEWAIT router#clear tcp tcb60A23A24 [confirm] [OK] router#configure terminalEnter configuration commands, one per line. End with CNTL/Z.router(config)#crypto key-ex passive Enter escape character to abort if connection does not complete. Wait for connection from peer[confirm]n router(config)#•
When tunneling IPX over an IP tunnel and using an extended inbound access list for IP on the tunnel interface, the IPX traffic is blocked by the access list.
Workaround is to add the permit gre command to the extended access list.
•
The Ascend-Idle-Limit attribute is defined as a value in seconds. However, when it is applied to a client using PPP interactive mode, the attribute is interpreted as a value in minutes.
This attribute works properly in PPP dedicated mode.
•
When printing is performed over asynchronous lines by using software flow control, large numbers of overruns occur.
•
When you perform an encrypted Kerberized Telnet to a Cisco 7500 series router, the initial setup works properly, but nonsense output results when the decryption of packets from the router occurs on the client side. There is no workaround.
•
Cisco encryption crashes the router when it is used over an ISDN backup line.
•
Using the clear vpdn tunnel command for a tunnel using L2F protocol sends individual close packets for all L2F sessions (Mids), rather than a single close packet for the tunnel itself. This results in congestion on the WAN interfaces on the requesting peer. Simultaneously, the receiving peer is not able to keep up with the flood of multiple L2F close packets—resulting in dropped packets, interface throttle, and the remaining Mids taking a long time to idle out and eventually close.
•
A Cisco 2600 series router with an E1 balanced network module may inadvertently reload. There is no workaround.
•
Under heavy uses of L2F VPDN configurations on Cisco access servers, some virtual-access interfaces do not have a corresponding MID (L2F session) entry.
Turning on the debug vpdn l2x-error command shows messages similar to the these:
*Dec 9 20:37:59.421: Vi291 L2X: Discarding packet because of no mid/session *Dec 9 20:37:59.421: Vi419 L2X: Discarding packet because of no mid/session *Dec 9 20:37:59.421: Vi169 L2X: Discarding packet because of no mid/session *Dec 9 20:37:59.421: Vi36 L2X: Discarding packet because of no mid/sessionOther problems also may cause these messages.
•
When a hub-and-spoke frame relay configuration is run and the hub router is set as a multipoint interface, DHCP requests fail.
Workaround: Configure both the hub and the spoke to use point-to-point subinterfaces.
•
A Cisco 3640 router with BRI interfaces locks up every two weeks. Approximately six hours prior to lockup, ISDN dial-in users notice a significant slowdown in transfer rates. When the router locks up, it continuously displays the message below.
%SYS-2-BADSHARE: Bad refcount in retparticle, ptr=0, count=0 -Traceback= 601AA500 600B55C8 600B9F64At this point, the router does not respond to console or Telnet input. Even though the indicator LEDs show steady traffic, the router also does not route any packets. The router must be reloaded to recover.
There is no workaround.
•
Spurious accesses and router hangs can occur when using fair queuing.
•
SNA packets are dropped and not forwarded over a 64 KB leased line with HDLC encapsulation. There is no workaround.
•
A Cisco 3640 router is unable to use E&M ports and displays the following message "error C542-1 to big rxx port 1/1/1 pkt (size 41318) to big."
•
A Bus error occurs during the scheduler process.
Protocol Translation
•
TCP to X.25 PVC translation does not work.
Wide-Area Networking
•
Two Cisco 4500 series routers connected using back-to-back E1 controllers are running PPP. When an FAS alarm is generated, PPP reliable does not reconnect. When an AIS alarm is generated, PPP reliable reconnects.
This problem only affects the PPP reliable protocol. No other protocols, such as HDLC, are affected.
•
No packets can be forwarded over synchronous DDR lines with X.25/X.25-IETF encapsulation. There is no workaround.
•
A router with over 180 DLCIs cannot boot properly because of excessive console log messages related to the startup of Frame Relay PVCs.
•
Some protocol translation configurations produce "%ALIGN-3-SPURIOUS: ..." messages, usually when a PPP over LAT session is terminated ungracefully.
•
The input queue of an ATM interface on a Cisco 7200 series router slowly fills with Novell packets. These packets are visible in the output of the show buffer old packet command. It can take days for the input queue to completely fill up and prevent input of any packets on that interface.
Workaround: Monitor the router and reload it before the input queue gets wedged (as indicated by 76/75 in the output of the show interface command). Increasing the size of the input queue can delay the wedge.
•
When using X.25 encapsulation, the serial interface input queue shows a negative value.
•
When an X.25 host sends a "set parameters" packet assembler/disassembler (PAD) message followed by several octets for X.3 parameters (1 through 18) to a Cisco router acting as a PAD, the parameter setting "6=1" is improperly rejected by the router.
Parameter 6 is control of PAD service signals. Value 1 is PAD service signals are transmitted in the standard format.
Workaround: Locally preset parameter 6 to value 1 before making the call to the X.25 host. Then the Cisco router acting as a PAD will accept the X.3 parameters coming from the X.25 host.
•
A Cisco 2500 series router's async line may hang when a PAD call is not cleared correctly. Clearing the line does not solve the problem. This has been observed in Cisco IOS Release 11.3(6). Restarting the router is the only workaround.
•
A Cisco 3600 series router with a WIC-1T serial interface experiences instability when Adtran TSU 100 or TSU 600 devices are attached. Customers have seen slowness and retransmissions of packets or flapping of the leased line.
•
When configuring PPP multilink on a router running Cisco IOS Release 11.3(7)T, the different B channels on an E1 hang. When running Release 11.3(8)T, the problem seems to be limited to one B channel. When PPP multilink is not used, the problem does not appear.
•
A Cisco 7200 series router crashed due to memory corruption caused by large numbers of protocol translations.
•
Adding the dialer isdn short-hold command to the map-class dialer to optimize ISDN costs based on AOC-D messages breaks the dialer idle-timeout. This means that:
1) The idle timer resets to 4294966 seconds when expiring and does not disconnect the ISDN call.
2) The short-hold timer gets incremented on receipt of an AOC-D message and never disconnects an ISDN call either.Workaround: Remove the dialer isdn short-hold command from the map-class dialer configuration.
•
On a BRI that is used for backup of a serial interface, when standby time arrives, a disconnect on q931 is never sent. The ISDN switch needs to declare that remote TE is out of order.
•
A router intermittently displays the "%TCP-2-INVALIDTCPENCAPS" message.
•
Although BRI is used as a backup and the dialer interface is in stanby, the router will make an ISDN call.
This call should never occur because the leased lines are up and no backup is needed.
Both rotary groups and dialer profiles result in the same problem.
•
After reloading a router, the ATM interfaces assumes the default UNI value (3.0) instead of the actual configuration.
Workaround: Reset the interface by using the shutdown and no shutdown commands.
•
When doing TCP to X.25 translation, the router does not negotiate X.3 parameters with the PAD, and the whole session drops after a couple of seconds.
•
ATCP (appletalk) negotiation over asynchronous PPP fails. There is no workaround. Cisco IOS Releases 11.2(19)P and 11.1(24) exibit the same problem.
Caveats for Release 11.3(1) through 11.3(10).
This section describes possibly unexpected behavior by Release 11.3(10). Unless otherwise noted, these caveats apply to all 11.3 releases up to and including 11.3(10). For additional caveats applicable to Release 11.3(10), see the caveats sections for newer 11.3 releases. The caveats for newer releases precede this section.
All the caveats listed in this section are resolved in release 11.3(11).
Basic System Services
•
Certain Internetwork Status Monitor (ISM) NetView users can issue non-enable mode commands without router authentication. Users accessing the router through NetView must be authenticated through NetView's security methods, which may include RACF and SAF. Mainframe users can be restricted from issuing any router commands through the restriction of the RUNCMD within NetView. Users issuing enable mode commands must be authorized to issue this level of command through ISM, and must here possess the ENABLE mode password. If the router is controlled by TACACS+, the ISM user must have a TACACS+ user ID and password to issue enable level commands.
The show user command has been modified, so that the user field is filled up by the host name.
The no-enable and high-security keywords have been added to the sna host and dspu host commands. These keywords must be configured with focalpoint and are defined as follows:
no-enable: Does not allow enable commands from the host.
high-security: Allows the following commands in user EXEC mode. (Privileged EXEC mode is not affected by this option.)
Note
For example, sh ver is not allowed as an abbreviation for the show version command.
•
•
•
•
•
A Cisco 7200 series router with an encryption card (ESA) reloads periodically. No workaround is available.
•
On a Cisco 7200 series routers running Cisco IOS Release 11.3(7)T, the EnvMonTemperature trap value sent for the temperature sensor at chassis outlet 3 is incorrect.
•
A Cisco 7500 series router can erroneously detect output stuck conditions, which causes interfaces to reset or perform cBus restarts and all IPs on the router to reset.
DECnet
•
When DECnet accounting is implemented, the router may crash, depending on the number of connections.
•
During configuration of DEC net on a router, it is possible to specify an address translation gateway (ATG) network number in the range 0 to 3. If the atg-network-number argument is specified incorrectly while configuring an interface, the router will reload.
Workaround: Ensure that the atg-network-number argument specified when enabling an interface matches that specified when DECnet routing is enabled globally, for example:
decnet 1 routing 2.3 interface ethernet 0/0 decnet 1 cost 5
EXEC and Configuration Parser
•
A router crashes when using the username command under the following conditions:
If you enter a long username, type a shortened form of the password keyword, and press the Tab key to complete the password keyword, the router crashes.
IBM Connectivity
•
A Cisco 7206 router running Cisco IOS Release 11.3(9)T configured for DLSw priority peers may crash with a bus error. There is no workaround.
•
Console message flooding may occur when an XID3 loop occurs with APPN in the router. The following messages are repeated for each iteration of the loop:
%APPN-3-logcsCS_XXXXIP11_LOGMSG_01: CS - Sending Alert to MS, sense_code = 83E0001, proc_name = XXXXIP32, port_name = HMAC04, ls_name = @LS00289%APPN-3-logcsCS_XXXXIP11_LOGMSG_03: CS - Associated outbound XID data in alert (length >= 29):%APPN-3-Error: 327307700000000000F7C1000000008000010B510005000000000007000E11F4C4C5C2E5D4E4F0F04BD5D5C 3C9D7F0F110380037110C0804F1F2F0F0F0F00908F0F0F0F0F0F0F01406C3C9E2C3D640C1D7D7D540D5D561 C4D3E4D90F0FC3C9E2C3D640C1D7D7D540D5D52207000000083E0001 %APPN-3-logcsCS_XXXXIP11_LOGMSG_05: CS - Associated inbound XID data in alert (length >= 29):%APPN-3-Error: 326705D56F010000B00810000000000000010B410005B800000000070010370023110C0804F0F3F0F0F0F00 F06D4E240E2D5C140E2C5D9E5C5D90908F0F0F0F0F0F0F0131103100010F0F0F0F0F0F0F0F0F0F0F0F0F00E 0FF4C4C5C2E5D4E4F0F04BC3E3F5F6C6Workaround: Disable console logging.
•
The router crashes with a bus error when executing the show dlsw circuit command, and there is a circuit with a local RIF of 18 bytes.
This is a regression introduced by CSCdk83294.
•
DLSw Lite (LLC2 encapsulation) peers leak CLS connect request buffers.
Workaround: Use a different peer type. This will free an outstanding connect request if additional requests are received while the first is still pending.
•
An APPN router may run out of memory because of unnecessary LFSID table expansion for some DLUR links to downstream PU2.0s. This problem can occur after DLUR takeover, or if the DLUR-PU had previously received a "dactpu not final use" message from the DLUS.
•
In a rare situation, a Cisco router may crash in the TCPD routines or managed timer. There is no workaround.
Interfaces and Bridging
•
When router traffic and memory usage is heavy, a router may crash in frf9_preComp().
Workaround: Disable compression, use a different type of compression, or tune the memory tuning.
•
In Cisco IOS Releases 11.3(8.5) to 11.3(10.4), and 11.3(8.5)T through 11.3(10.4)T, all RSM and RSP platforms that use a VIP2/PA-4R IBM2692 adapter will potentially ignore non-RIF Token Ring packets because the VIP Token Ring driver incorrectly classifies these packets as runts and drops them.
This is a regression introduced by CSCdk64195.
•
An overwrite issue in the BSS area with FDDI modules equipped can cause a router to crash.
IP Routing Protocols
•
IP access lists fail to block pings on interfaces configured for policy routing with IP route-cache policy enabled.
•
ARP to a Cisco 2500 series router running Cisco IOS Release 11.2(17) or 12.0(3.7) fails on the serial interface when bridging is enabled, and the router is reloaded. This problem was seen on the following topology:
----Ethernet----Cisco 2500 series router---serial interface---Cisco 2500 series router---Ethernet---
The workaround is to remove and reenter the IP address on the serial interface.
•
Some IP fragments may be incorrectly filtered out by access lists.
•
If you are redistributing OSPF routes into any other routing protocol, the redistributed routes do not include NSSA external routes. There is no workaround.
•
DNS replies passing from inside to outside by way of NAT are not NAT-translated correctly in many cases. There is no workaround.
ISO CLNS
•
Under certain circumstances, Cisco routers running Cisco IOS Release 11.3(9)T may stop receiving packets on interfaces. This happens when CLNS packets with an N-selector of 0x20 (the DECnet NSP protocol selecter) are received by the router and the decnet conversion command has not been enabled or configured correctly.
If this happens, the show interface command displays a full input queue and a number of dropped packets (for example: input queue 76/75, 122 drops).
When the input queue is full and the interface stops receiving packets, the only workaround is to reload the router.
Miscellaneous
•
The NM-1FE-TX fails to autonegotiate properly when connected through an SMF connector.
Workaround: Manually set the speed to 100 by using the following new speed command. By default, the command is configured as speed auto.
[no] speed {10 | 100 | auto}
•
A race condition can occur between the processes that tried to get connection status and dropped packet information from the VIP.
Workaround: Put in a semaphore to prevent multiple processes from accessing the globals used at the same time.
•
Configuring PPP encapsulation on an interface and then making that interface a member of a bridge group causes tracebacks and "fair-queue not initialized properly" messages.
Workaround: Remove bridging from the interface, or turn off fair queueing.
00:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:39: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:39: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:39: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:40: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:40: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:40: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:40: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D02000:06:40: Fair Queue:packet not initialized properly: 0, 0 , 3800:06:40: -Traceback= 601C9C58 602015E0 60556558 60553958 6021D034 6021D020•
After a router is reloaded, ESA can not re-establish active crypto connections.
Workaround: Remove the crypto map, reload the router again, and then re-apply the crypto map.
•
A Cisco 3600 series router with a 4T card configured for DTR goes down because the DTR downtime is too short.
•
A Cisco 7500 series router running virtual profiles continually resets the ciscoBus (cBus).
The first message is "%RSP-3-RESTART: interface Serial4/0:1, output stuck." shortly before the cBus resets. To see more detailed information, enter the debug cbus command.
This BUS resetting also causes all attached controllers to loose connectivity. Then, the only way to access the device is through the console port.
•
On a router running Cisco IOS Release 11.3(9.2), you cannot change the MTU size of a tunnel interface. CSCdk15279 permitted this ability to exceed the MTU size of the physical interface, which is 24.
Workarounds:
•
•
Once this workaround is issued, there should be no problems in the event of a router reboot because the ip mtu command is parsed before the tunnel destination.
•
If a router running CET encryption has many connection setup attempts happening at once, some routers may time out prematurely. Also, some connection setup attempts may not set up properly.
Novell IPX, XNS, and Apollo Domain
•
Routers running IPX and EIGRP on Cisco IOS Release 11.2 or greater can experience crashes when there is a high frequency of interface up/down transitions, especially with dial-up interfaces.
Workaround: Disable IPX EIGRP.
VINES
•
Cisco 2500 series and Cisco 4000 series routers (68000-based routers) might reload a few minutes after VINES Sequenced Routing Update Protocol (SRTP) is configured.
Workaround: Do not use VINES SRTP. If it is enabled, disable it by issuing the no vines srtp-enabled command.
Wide-Area Networking
•
DDR with the dialer dtr command does not reset DTR to a down state after an unsuccessful call attempt. (Unsuccessful in this case means that DDR is triggered, DTR is raised, but the modem/TA attached to the serial port never connects so that DCD does not come up.)
This can be verified by using the show dialer command to ensure that the dialer state is idle, and enter using the show interface serial interface command to check the state of DTR.
This problem does not occur in Cisco IOS Release 11.1.
•
When a router is functioning as an X.28 PAD, it should send an X-on to the DTE as soon as it enters the data transfer mode if parameter 5 is set to 1. The pad does not.
•
All platforms running MLP may potentially encounter a transient error condition where no links are assigned to a multilink bundle.
•
ISDN looses packets and headers when:
1) Switch type is PRI_4ESS or PRI_5ESS.
2) A connect request is sent by the router.
3) The switch does not respond to a connect within T313.This causes the connect to be retransmitted, and that packet and header memory to not be released.
•
STAC compression LZS DCP becomes stuck in an R-Req loop.
This problem is seen with Cisco IOS Release 11.1 or 11.2 hardware compression/RSP on one end and Cisco IOS Release 11.3 or 12.0 software compression on the other.
Workaround: If you are using a Cisco 7500 series router, disable compression. If you are using a non-RSP router, you could also use software compression (instead of hardware compression) on both sides.
There still may be some problems with 11.1/11.2 hardware compression or RSP interfacing to 11.3/12.0 hardware compression or RSP (see CSCdm31447).
•
When the router is operating as an X.25 switch and forwards an X.25 call containing certain facilities not interpreted by the router, the facility values may be corrupted. This problem is most likely to occur when the call cannot be forwarded immediately (for example, when using X.25-over-TCP) with heavy traffic; the affected facilities include any local facilities and the Charging Information facility.
•
A router performing X.25 switching may reload when clearing many calls simultaneously during heavy traffic.
•
A customer is deterministically getting a crash (segV) when dialer rotor best is configured and the deb dialer command is used once to traffic trigger a call.
•
A Cisco 5200 series router's PRI never sends a UAF response to a telco's switch.
•
Reliable PPP can cause an intermittent crash when used with WFQ.
Workaround: Disable reliable PPP or WFQ.
•
A Cisco 4000 series router running Cisco IOS Release 11.3(9)WA4(11.1) crashes when configuring LECS, LES/BUS, and LEC. There is no workaround.
•
In a Multi-chassis MLP stack group, when two stack group members cross project MLP link interfaces, one of the stack group members may crash. There is no workaround.
Related Documentation
The following sections describe the documentation available for the Cisco 4000 series routers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 11.3 and are located on CCO and the Documentation CD-ROM:
•
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
•
Service & Support: Technical Documents
•
As a supplement to the caveats listed in the "Caveats" section in these release notes, see the "Important Notes and Caveats for Release 11.3" section in the Cross-Platform Release Notes for Cisco IOS Release 11.3, which contains caveats applicable to all platforms for all maintenance releases of Release 11.3.
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Product Specific Release Notes for Cisco IOS Release 11.3: Cross-Platform Release Notes for Cisco IOS Release 11.3: Important Notes and Caveats for Release 11.3
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Product Specific Release Notes for Cisco IOS Release 11.3: Cross-Platform Release Notes for Cisco IOS Release 11.3: Important Notes and Caveats for Release 11.3
Note
Platform-Specific Documents
The documents listed below are available for the Cisco 4000 series routers. These documents are also available online on CCO and on the Documentation CD-ROM.
•
•
•
•
•
•
•
•
On CCO:
Service & Support: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 4000 Series Routers
On the Documentation CD-ROM:
Access Servers and Access Routers: Modular Access Routers: Cisco 4000 Series Routers
Cisco IOS Software Documentation
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.
Documentation Modules and Indexes
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked indexes provide indexing information for the Cisco IOS software documentation set.
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
On the Documentation CD-ROM:
Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
To reach documentation related to an index entry, click on the page number following the entry.
Release 11.3 Documentation Set
details the contents of the Cisco IOS Release 11.3 software documentation set. The document set is available in electronic form, and also in printed form upon request.
Note
On CCO:
Service & Support: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.3
On the Documentation CD-ROM:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" in Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips on the Cisco Technical Assistance Center Home Page
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it may be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also reach Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar, select Documentation, and click Enter the feedback form. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-5044-12
