Release Notes for Cisco AS5100 and
Cisco AS5200 Universal Access Servers
for Cisco IOS Release 11.3
July 26, 1999
These release notes for Cisco AS5100 and Cisco AS5200 universal access servers support Cisco IOS Release 11.3, up to and including Release 11.3(11). These release notes are updated as needed to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.
For a list of the software caveats that apply to Release 11.3, see the Caveats for Release 11.3 , which accompanies these release notes. The caveats document is updated for every maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.
Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM.
Contents
These release notes cover the following topics:
Introduction
The Cisco AS5100 and Cisco AS5200 universal access servers are supported in Cisco IOS Release 11.3(11). With their optimization for high-speed modem access, the Cisco AS5100 and Cisco AS5200 universal access servers are ideally suited for all traditional dialup applications, such as host access, electronic mail, file transfer, and dial-in access to a local area network (LAN).
For information on new features and Cisco IOS commands supported by Release 11.3, see the "New and Changed Information" section and "Related Documentation" section.
Cisco AS5100 Universal Access Server
The Cisco AS5100 universal access server is a versatile data communications platform that combines the functions of an access server, a router, and analog and digital modems in one chassis. Organizations requiring centralized processing capabilities for mobile users and telecommuters will benefit the most from using the Cisco AS5100 universal access server.
Cisco AS5200 Universal Access Server
The Cisco AS5200 universal access server is a multifaceted data communications platform that provides the functions of an access server, a router, modems, and terminal adapters (TAs) in a modular chassis. Mid-sized organizations or service providers requiring centralized processing capabilities for mobile users and telecommuters will benefit the most from using the Cisco AS5200 universal access server.
Early Deployment Releases
These release notes describe only Release 11.3(11) for Cisco AS5100 and Cisco AS5200 universal access servers and do not describe features that are available in Release 11.3 or other Release 11. 3 Early Deployment (ED) releases.
For information about features in Release 11.3, see the Cross-Platform Release Notes for Cisco IOS Release 11.3 on Cisco Connection Online (CCO) and the Documentation CD-ROM.
For information about features in other platforms, see the product-specific release notes on CCO and the Documentation CD-ROM.
System Requirements
This section describes the system requirements for Release 11.3(11):
•
Determining the Version of Your Software Release
•
Memory Requirements
Table 1 describes the memory requirements for the Cisco AS5100 and Cisco AS5200 universal access servers' feature sets supported by Cisco IOS Release 11.3.
Beginning with Cisco IOS Release 10.3, some software image sizes exceed 4 MB and, when compressed, exceed 2 MB. Also, some systems now require more than 1 MB of main system memory for data structure tables.
For Cisco access servers to take advantage of the Release 11.3 features, you must upgrade the code or main system memory as listed in . Some platforms have specific chip or architecture requirements that affect what can be upgraded and in what increments.
Hardware Supported
Cisco IOS Release 11.3(11) supports the Cisco AS5100 and Cisco AS5200 universal access servers. For detailed descriptions of the new hardware features, see the "New and Changed Information" section. summarizes the hardware supported on the Cisco AS5100 and Cisco AS5200 universal access servers.
Determining the Version of Your Software Release
To determine the version of Cisco IOS software running on your Cisco AS5100 or Cisco AS5200, log in to the Cisco AS5100 or Cisco AS5200 and enter the show version EXEC command:
router>show versionCisco Internetwork Operating System SoftwareIOS (tm) 5200 Software (c5200-js-l), Version 11.3(11), RELEASE SOFTWAREUpdating to a New Software Release
For information about updating to a new software release, see the Cisco IOS Software Release Upgrade Paths product bulletin #703, located on CCO at:
Service & Support: Technical Documents: Product Bulletins
Under Cisco IOS Release 11.3, click Cisco IOS Software Release 11.3 Upgrade Paths (#703: 12/97).
This product bulletin does not contain information specific to Cisco IOS Release 11.3, but provides generic upgrade information that may apply to Cisco IOS Release 11.3.
Modem Code
Cisco IOS Release 11.2(1) and later includes bundled modem code for the Cisco AS5200, which is the firmware or portware that runs on the Microcom 12-port and MICA 6-port modem cards. Bundling eliminates the need to store separate microcode images. When the access server starts, the Cisco IOS software unpacks the modem code and loads the proper code on the modem cards.
Note
The modem code release notes are on CCO and the Documentation CD-ROM.
You can reach the release notes on CCO at:
Service & Support: Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
You can reach the release notes on Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Firmware and Portware Information
Note
Service and Support: Software Center: Access Products: AS5200 SeriesFeature Set Tables
The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.
lists the Cisco IOS software feature sets available for the Cisco AS5100 and Cisco AS5200 universal access servers in Cisco IOS Release 11.3(10).
Table 3 Feature Sets Supported by the Cisco AS5100 and Cisco AS5200
IP
Basic1
c2500-i-l
Cisco AS5100
c5200-i-l
Cisco AS5200
IP Plus
Basic, Plus2
c5200-is-l
Cisco AS5200
IP/IPX/AT/DEC
Basic
c2500-d-l
Cisco AS5100
c5200-d-l
Cisco AS5200
IP/IPX/AT/DEC Plus
Basic, Plus
c5200-ds-l
Cisco AS5200
Enterprise
Basic
c5200-j-l
Cisco AS5200
Enterprise Plus
Basic, Plus
c5200-js-l
Cisco AS5200
Remote Access Server
Basic
c2500-c-l
Cisco AS5100
1 This feature is offered in the basic feature set.
2 This feature is in the Plus feature set.
j
CautionCisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay due to United States government regulations. When applicable, purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.
and list the features and feature sets supported by the Cisco IOS Release 11.3(11) for the Cisco AS5100 and Cisco AS5200, respectively, and use the following conventions:
•
•
Table 4 Cisco IOS Software Feature Sets for the Cisco AS5100 Universal Access Server
APPN High-Performance Routing
No
No
No
APPN MIB Enhancements
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
APPN Scalability Enhancements
No
No
No
Bisync Enhancements
No
No
No
Cisco MultiPath Channel (CMPC)
No
No
No
DLSw+ Enhancements
No
No
No
FRAS Enhancements
No
No
No
SRB over FDDI on Cisco 4000, 4500, and 4700 Series Routers
No
No
No
TN3270 LU Nailing
No
No
No
TN3270 Server Enhancements
No
No
No
Token Ring LANE
No
No
No
Tunneling of Asynchronous Security Protocols
No
No
No
DRP Server Agent
Yes
Yes
No
Easy IP (Phase 1)
Yes
Yes
Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
No
No
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
Protocol Independent Multicast (PIM) Version 2
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
Yes
No
DECnet Accounting
No
Yes
No
IPX Named Access Lists
No
Yes
Yes
IPX SAP-after-RIP
No
Yes
Yes
NLSP Enhancements
No
No
No
NLSP Multicast Support
No
Yes
No
Cisco Call History MIB Command Line Interface
Yes
Yes
No
Cisco IOS Internationalization
Yes
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
SNMPv2C
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
Double Authentication
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
HTTP Security
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
TCP Intercept
No
No
No
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
No
No
CLNS and DECnet Fast Switching over PPP
No
No
No
DECnet/VINES/XNS over ISL
No
No
No
Fast Switched Policy Routing
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
No
No
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
Virtual Templates for Protocol Translation
No
No
Yes
ATM MIB Enhancements
No
No
No
PAD Enhancements
No
No
Yes
PAD Subaddressing
Yes
Yes
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
No
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
No
ISDN Caller ID Callback
Yes
Yes
No
ISDN NFAS
No
No
No
Layer 2 Forwarding—Fast Switching
No
No
Yes
Leased-Line ISDN at 128 kbps
No
No
No
PPP over ATM
No
No
No
Telnet Extensions for Dialout1
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
No
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
1 All platforms with integrated MICA modems will support Cisco DialOut in future releases.
Table 5 Cisco IOS Software Feature Sets for the Cisco AS5200 Universal Access Server
Plus
DEC
DEC
Plus
PlusAPPN High-Performance Routing
No
No
No
No
No
No
APPN MIB Enhancements
No
No
No
No
No
No
APPN over Ethernet LAN Emulation
No
No
No
No
No
No
APPN Scalability Enhancements
No
No
No
No
No
No
Bisync Enhancements, include:
•
•
•
No
No
No
No
Yes
Yes
Cisco MultiPath Channel (CMPC)
No
No
No
No
No
No
DLSw+ Enhancements, include:
•
•
•
•
•
•
•
No
No
No
No
Yes
Yes
FRAS Enhancements, include:
•
•
•
•
•
•
No
No
No
No
Yes
Yes
SRB over FDDI on Cisco 4000, 4500, and 4700 Series Routers
No
No
No
No
No
No
TN3270 LU Nailing
No
No
No
No
No
No
TN3270 Server Enhancements
No
No
No
No
No
No
Token Ring LANE
No
No
No
No
No
No
Tunneling of Asynchronous Security Protocols
No
No
No
No
Yes
Yes
DRP Server Agent
Yes
Yes
Yes
Yes
Yes
Yes
Easy IP (Phase 1)
Yes
Yes
Yes
Yes
Yes
Yes
Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations
No
No
No
No
No
No
IP Enhanced IGRP Route Authentication
Yes
Yes
Yes
Yes
Yes
Yes
TCP Enhancements, include:
•
•
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Access List Enhancements
No
No
Yes
Yes
Yes
Yes
DECnet Accounting
No
No
Yes
Yes
Yes
Yes
IPX Named Access Lists
No
No
Yes
Yes
Yes
Yes
IPX SAP-after-RIP
No
No
Yes
Yes
Yes
Yes
NLSP Enhancements
No
No
No
No
Yes
Yes
NLSP Multicast Support
No
No
Yes
Yes
Yes
Yes
Cisco Call History MIB Command Line Interface
Yes
Yes
Yes
Yes
Yes
Yes
Cisco IOS Internationalization
Yes
Yes
Yes
Yes
Yes
Yes
Entity MIB, Phase 1
Yes
Yes
Yes
Yes
Yes
Yes
SNMPv2C
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Profiles
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast Load Splitting across Equal-Cost Paths
Yes
Yes
Yes
Yes
Yes
Yes
IP Multicast over ATM Point-to-Multipoint Virtual Circuits
No
No
No
No
No
No
IP Multicast over Token Ring LANs
Yes
Yes
Yes
Yes
Yes
Yes
Stub IP Multicast Routing
Yes
Yes
Yes
Yes
Yes
Yes
RTP Header Compression
Yes
Yes
Yes
Yes
Yes
Yes
Double Authentication
Yes
Yes
Yes
Yes
Yes
Yes
Encrypted Kerberized Telnet
No
No
No
No
No
No
HTTP Security
Yes
Yes
Yes
Yes
Yes
Yes
Per-User Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Reflexive Access Lists
Yes
Yes
Yes
Yes
Yes
Yes
TCP Intercept
No
No
No
No
Yes
Yes
Vendor-Proprietary RADIUS Attributes
Yes
Yes
Yes
Yes
Yes
Yes
AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs
No
No
No
No
No
No
CLNS and DECnet Fast Switching over PPP
No
No
No
No
Yes
Yes
DECnet/VINES/XNS over ISL, includes:
•
•
•
No
No
No
No
Yes
Yes
Fast Switched Policy Routing
Yes
Yes
Yes
Yes
Yes
Yes
IPX Routing over ISL Virtual LANs
No
No
No
No
No
No
VIP Distributed Switching Support for IP Encapsulated in ISL
No
No
No
No
No
No
Telnet Extensions to Dialout
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Templates for Protocol Translation
No
Yes
No
Yes
Yes
Yes
ATM MIB Enhancements
No
No
No
No
No
No
PAD Enhancements
No
Yes
No
Yes
Yes
Yes
PAD Subaddressing
Yes
Yes
Yes
Yes
Yes
Yes
Bandwidth Allocation Control Protocol
Yes
Yes
Yes
Yes
Yes
Yes
Enhanced Local Management Interface (ELMI)
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay MIB Extensions
Yes
Yes
Yes
Yes
Yes
Yes
Frame Relay Router ForeSight
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Advice of Charge
Yes
Yes
Yes
Yes
Yes
Yes
ISDN Caller ID Callback
Yes
Yes
Yes
Yes
Yes
Yes
ISDN NFAS
Yes
Yes
Yes
Yes
Yes
Yes
Layer 2 Forwarding—Fast Switching
No
Yes
No
Yes
Yes
Yes
Leased-Line ISDN at 128 kbps
No
No
No
No
No
No
PPP over ATM
No
No
No
No
No
No
Telnet Extensions for Dialout1
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Enhancements
Yes
Yes
Yes
Yes
Yes
Yes
X.25 on ISDN
Yes
Yes
Yes
Yes
Yes
Yes
X.25 Switching between PVCs and SVCs
Yes
Yes
Yes
Yes
Yes
Yes
X.28 Emulation
Yes
Yes
Yes
Yes
Yes
Yes
1 All platforms with integrated MICA modems will support Cisco DialOut in future releases.
New and Changed Information
The following section lists the new features supported by the Cisco AS5100 and Cisco AS5200 universal access servers in Cisco IOS Release 11.3.
No New Features in Release 11.3(11)
There are no new features supported by the Cisco AS5100 and Cisco AS5200 universal access servers in Cisco IOS Release 11.3(11).
Important Notes
The following sections contain important notes about Cisco IOS Release 11.3 that might apply to the Cisco AS5100 and Cisco AS5200 universal access servers.
ATM Multipoint Signaling
Prior to Cisco IOS Release 11.1(13) and 11.2(8), the atm multipoint-signaling command was used on the main interface and affected all subinterfaces. For Release 11.1(13), 11.2(8), and later releases (including Release 11.3), explicit configuration on each subinterface is required to obtain the same functionality. Refer to caveat CSCdj20944, which is described as follows:
The atm multipoint-signaling interface command is currently only available on the main ATM interface. The effect is that signaling behavior (point-to-point or point-to-multipoint) for all clients on all subinterfaces is determined by the command on the main interface.
Clients on different subinterfaces can behave differently. Specifically, 1577 requires point-to-point, and PIM allows point-to-multipoint. Use the command on a per subinterface basis.
Enable the atm multipoint-signaling command on all subinterfaces that require it. Previously, you only needed to enable the command on the main interface.
Cisco IOS Release 11.3, 11.3 NA, and 11.3 T End of Sales and End of Engineering
End of Engineering (EOE) means that there are no more regularly scheduled maintenance releases. The last maintenance release scheduled on the EOE date is only available through CCO and Field Service Operations—not through manufacturing.
•
•
EOS and EOE releases are subject to change. For the most up-to-date information on the status of EOS or EOE, see the End of Sales and End of Engineering for Cisco IOS Software Releases product bulletins located on CCO.
Ongoing support for functionality in Releases 11.3, 11.3 NA, and 11.3 T is available in Cisco IOS Release 12.0(3)T and later maintenance releases of Cisco IOS Release 12.0 on CCO at:
Service & Support: Technical Documents: Product Bulletins: Software
Under Cisco IOS 11.3, click End of Sales and End of Engineering for Cisco IOS Software Releases 11.3 and 11.3 T (#847: 12/98) or Cisco IOS Software 11.3 NA EoS and EoE (#849:12/98)
Forwarding of Locally Sourced AppleTalk Packets
Cisco's implementation of AppleTalk does not forward packets with local source and destination network addresses. This behavior does not conform to the definition of AppleTalk in Inside AppleTalk. However, this behavior is designed to prevent any possible corruption of the AppleTalk Address Resolution Protocol (AARP) table in any AppleTalk node that collects MAC-addresses.
Missing Source-Route Bridging Commands
Due to a production problem, many source-route bridging commands were omitted from the printed version of the Cisco IOS Software Command Summary (78-4746-XX). For documentation of all source-route bridging commands, refer to the Bridging and IBM Networking Command Reference (78-4743-XX). You can also obtain the most current documentation on CCO or on the Documentation CD-ROM.
New TACACS+ Attribute-Value Pair
A new authorization feature that allows you to separately configure and authorize Multilink PPP was added in Cisco IOS Release 11.3(1). This feature can cause MLP authorization to fail in Terminal Access Controller Access Control System (TACACS+) servers that do not include authorization permissions in the configuration.
For TACACS+, add the following attribute-value (AV) pair for all users who are allowed to negotiate Multilink PPP:
service = ppp protocol = multilink {40-bit Encryption Images are Unavailable in Release 11.3(1)
Cisco is conducting an internal review of the build and distribution processes associated with its 40-bit Cisco IOS cryptographic products. To provide seamless access to Cisco IOS 40-bit encryption capability, Cisco will provide access to the most current 40-bit encryption images, beginning with Cisco IOS Release 11.2 (12), 11.2(12)P, and 11.3(2).
The following 40-bit encryption images are unavailable indefinitely:
•
•
•
•
This review is not related to any new or previously unreported caveats. The information gathered in the review will be used to implement new automated development and order-processing applications.
Caveats
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious.
This section only contains open and resolved caveats for the current Cisco IOS maintenance release.
For information on caveats in Cisco IOS Release 11.3, see "Important Notes and Caveats for Release 11.3" in Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO and the Documentation CD-ROM. These release notes contain caveats affecting all maintenance releases and list severity 1 and 2 caveats for Cisco IOS 11.3(11).
Note
Related Documentation
The following sections describe the documentation available for the Cisco AS5100 and Cisco AS5200 universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.
Documentation is available as printed manuals or electronic documents.
Use these release notes with these documents:
•
Release-Specific Documents
The following documents are specific to Release 11.3 and are located on CCO and the Documentation CD-ROM:
•
You can reach Cross-Platform Release Notes for Cisco IOS Release 11.3 on CCO at:
Service & Support: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
You can reach Cross-Platform Release Notes for Cisco IOS Release 11.3 on the Documentation CD-ROM at:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Release Notes for Cisco IOS Release 11.3
•
You can reach these documents on CCO at:
Service & Support: Technical Documents
•
See the "Caveats" section of these release notes for caveats applicable to this release.
Note
Platform-Specific Documents
These documents are available for the Cisco AS5100 and Cisco AS5200 universal access servers on CCO and the Documentation CD-ROM.
Cisco AS5100 Documents
The documents listed below are available for the Cisco AS5100 access servers and are available on Cisco Connection Online (CCO) and on the Documentation CD-ROM.
•
•
•
•
You can reach the Cisco AS5100 documentation on CCO at:
Service & Support: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5100
You can reach the Cisco AS5100 documentation on the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5100
Cisco AS5200 Documents
The documents listed below are available for the Cisco AS5200 access servers and are available on Cisco Connection Online (CCO) and on the Documentation CD-ROM.
•
•
•
•
•
•
•
You can reach the Cisco AS5200 documentation on CCO at:
Service & Support: Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5200
You can reach the Cisco AS5200 documentation on the Documentation CD-ROM at:
Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5200
Cisco IOS Software Documentation Set
The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM —unless you specifically ordered the printed versions.
Documentation Modules and Indexes
Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.
On CCO and the Documentation CD-ROM, two master hot-linked documents provide information for the Cisco IOS software documentation set.
You can reach these documents on CCO at:
Service & Support: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
You can reach these indexes on the Documentation CD-ROM at:
Cisco IOS Software Configuration: Cisco IOS Release 11.3: Cisco IOS 11.3 Configuration Guides, Command References: Configuration Guide Master Index or Command Reference Master Index
To reach documentation related to an index entry, click the page number following the entry.
Release 11.3 Documentation Set
describes the contents of the Cisco IOS Release 11.3 software documentation set, which is available in electronic form and also in printed form upon request.
Note
You can reach these documents on CCO at:
Service & Support: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.3
You can reach these indexes on the Documentation CD-ROM at:
Cisco IOS Software Configuration: Cisco IOS Release 11.3
Note
Service and Support
For service and support for a product purchased from a reseller, contact the reseller, who offers a wide variety of Cisco service and support programs described in "Service and Support" of Cisco Information Packet shipped with your product.
Note
For service and support for a product purchased directly from Cisco, use CCO.
Software Configuration Tips from the Cisco Technical Assistance Center
If you have a CCO login account, you can access the following URL, which contains links and tips on configuring your Cisco products:
http://www.cisco.com/kobayashi/serv_tips.shtml
This URL is subject to change without notice. If it changes, point your Web browser to CCO and click on this path: Products & Technologies: Products: Technical Tips.
The following sections are provided from the Technical Tips page:
•
•
•
•
•
•
•
•
•
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can reach CCO in the following ways:
•
•
•
•
•
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Note
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which package that ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.
78-5050-11
