Release Notes for the Cisco 4000 Series for Cisco IOS Release 11.2 P

April 16, 2001

Note Cisco IOS Release 11.2(26)P is the last scheduled maintenance release for Cisco IOS 11.2 P. TAC support will continue to be available. These release notes will be the last release notes published for Cisco IOS Release 11.2 P.

Note You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents can contain updates and modifications made after the hardcopy documents were printed.

These release notes for the Cisco 4000 series support Cisco IOS Release 11.2 P, up to and including Cisco IOS Release 11.2(26)P. These release notes are updated as needed to describe new memory recommendations, new features, new hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.

For a list of all the software caveats that apply to Cisco IOS Release 11.2(26)P, see Caveats for Cisco IOS Release 11.2 P that accompanies these release notes. The caveats document is updated for every maintenance release and is also located on Cisco.com and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 11.2 on Cisco.com and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

•System Requirements

•New and Changed Information

•Important Notes

•Caveats

•Related Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

System Requirements

This section describes the system requirements for Cisco IOS Release 11.2 P:

•Memory Recommendations

•Hardware Supported

•Determining the Software Version

•Upgrading to a New Software Release

•Feature Set Tables

Memory Recommendations

Tables 1 and 2 show the memory recommendations for the Cisco 4000 series.

Note Because the Cisco 4000 and Cisco 4000-M routers are not supported in this release, they do not appear in the Memory Recommendations tables.

Table 1 Memory Recommendations for the Cisco 4500 Series

Feature Set

Image Name

Recommended Flash Memory

Recommended DRAM Memory

Cisco 4500 Cisco 4500-M

Runs from¹

IP

c4500-i-mz

4 MB

32 MB

32 MB

RAM

IP Plus²

c4500-is-mz

4 MB

32 MB

32 MB

RAM

IP Plus 40

c4500-is40-mz

4 MB

32 MB

16 MB

RAM

IP Plus 56

c4500-is56-mz

4 MB

32 MB

32 MB

RAM

IP/IPX/AT/DEC

c4500-d-mz

4 MB

32 MB

32 MB

RAM

IP/IPX/AT/DEC Plus

c4500-ds-mz

4 MB

32 MB

32 MB

RAM

Enterprise Plus

c4500-js-mz

8 MB

32 MB

32 MB

RAM

Enterprise Plus 40

c4500-js40-mz

8 MB

32 MB

32 MB

RAM

Enterprise Plus 56

c4500-js56-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus

c4500-ajs-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 40

c4500-ajs40-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 56

c4500-ajs56-mz

8 MB

32 MB

32 MB

RAM

¹When a system is running from Flash memory, you cannot update the system. You must use the Flash memory load helper.

²Plus for the Cisco 4500, 4500-M, 4700, and 4700-M includes NAT, ISL, LANE, and IBM (if IBM is not already included).

Table 2 Memory Recommendations for the Cisco 4700 Series

Feature Set

Image Name

Recommended Flash Memory

Recommended DRAM Memory

Runs from¹

IP

c4700-i-mz

4 MB

32 MB

RAM

IP Plus2

c4700-is-mz

4 MB

32 MB

RAM

IP Plus 40

c4700-is40-mz

4 MB

16 MB

RAM

IP Plus 56

c4700-is56-mz

4 MB

32 MB

RAM

IP//IPX/AT/DEC

c4700-d-mz

4 MB

32 MB

RAM

IP//IPX/AT/DEC Plus

c4700-ds-mz

4 MB

32 MB

RAM

Enterprise Plus

c4700-js-mz

8 MB

32 MB

RAM

Enterprise Plus 40

c4700-js40-mz

8 MB

32 MB

RAM

Enterprise Plus 56

c4700-js56-mz

8 MB

32 MB

RAM

Enterprise/APPN Plus

c4700-ajs-mz

8 MB

32 MB

RAM

Enterprise/APPN Plus 40

c4700-ajs40-mz

8 MB

32 MB

RAM

Enterprise/APPN Plus 56

c4700-ajs56-mz

8 MB

32 MB

RAM

¹When a system is running from Flash memory, you cannot update the system. You must use the Flash memory load helper.

Hardware Supported

Cisco IOS Release 11.2 P supports the Cisco 4000 series:

•Cisco 4500, Cisco 4500-M

•Cisco 4700, Cisco 4700-M

Note Cisco 4000 and Cisco 4000-M routers are not supported in this release.

The following LAN interfaces are supported on the Cisco 4000 series routers listed above:

•Ethernet (AUI)

•Ethernet (10BaseT)

•4-Mbps Token Ring

•16-Mbps Token Ring

•FDDI DAS

•FDDI SAS

•FDDI multimode (DAS/SAS)

•FDDI single-mode

•ATM

•MultiChannel interface (Channelized E1/T1)

•Packet-over-SONET OC-3 interface

•Synchronous serial

The following WAN data rates are supported on the Cisco 4000 series routers listed above:

•48/56/64 kbps

•1.544/2.048 Mbps

The following WAN interfaces are supported on the Cisco 4000 series routers listed above:

•EIA/TIA-232

•X.21

•V.35

•EIA/TIA-449

•EIA-530

•ISDN BRI

•ISDN PRI

•E1-G.703/G.704

For detailed descriptions of the new hardware and software features for Release 11.2 P, see "New and Changed Information," on page 10.

Determining the Software Version

To determine the version of Cisco IOS software running on your Cisco 4000 series, log in to the Cisco 4000 series and enter the show version EXEC command:
Router> show version
Cisco Internetwork Operating System Software
IOS (tm) 4500 Software (C4500-JS-L), Version 11.2(26)P, RELEASE SOFTWARE
Upgrading to a New Software Release

For general information about upgrading to a new software release, see Cisco IOS Upgrade Ordering Instructions located at:

http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm

Feature Set Tables

Cisco IOS software is packaged into feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Table 3 shows the feature set matrix for the Cisco 4000 series.

Table 3 Feature Set Matrix for the Cisco 4000 Series

Standard Feature Sets

Cisco 4000 Series

IP

Basic, Plus, Encrypt

IP/IPX/AppleTalk/DEC

Basic, Plus, Encrypt

Enterprise

Basic, Plus, Encrypt

Enterprise and APPN

Plus, Encrypt

IP/IPX/IBM and IBM

Basic

Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders can be denied or subject to delay due to Unites States government regulations. When applicable, obtain local import and use authorizations for all encryption strengths. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.

Table 4 Table 4 lists the features and feature sets supported by the Cisco 4000 series in Cisco IOS Release 11.2 P and uses the following conventions:

•No—This feature is not offered in the feature set.

•Basic—This feature is offered in the basic feature set.

•Plus—This feature is offered in the Plus feature set.

•Encrypt—This feature is offered in the encryption feature sets, which consist of 40-bit (Plus 40) or 56-bit (Plus 56) data encryption feature sets.

Note This table might not be cumulative or list all the features in each image. You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents can contain updates and modifications made after the hardcopy documents were printed. If you have a Cisco.com login account, you can find image and release information regarding features prior to Cisco IOS Release 11.2(26)P by using the Feature Navigator tool at: http://www.cisco.com/go/fn.

Table 4 Software Feature Sets Supported by the Cisco 4000 Series

Feature

Feature Set

IP Routing

IP/IPX/IBM/APPN¹

Desktop
(IP/IPX/AppleTalk/DEC)

Enterprise²

LAN Support

Apollo Domain

No

No

No

Basic

AppleTalk 1 and 2³

No

No

Basic

Basic

Banyan VINES

No

No

No

Basic

Concurrent routing and bridging (CRB)

Basic

Basic

Basic

Basic

DECnet IV

No

No

Basic

Basic

DECnet V

No

No

No

Basic

GRE

Basic

Basic

Basic

Basic

Integrated routing and bridging (IRB)⁴

Basic

Basic

Basic

Basic

IP

Basic

Basic

Basic

Basic

LAN extension host

Basic

Basic

Basic

Basic

Multiring

Basic

Basic

Basic

Basic

Novell IPX⁵

No

Basic

Basic

Basic

OSI

No

No

No

Basic

Source-route bridging⁶

No

No

No

No

Transparent and translational bridging

Basic

Basic

Basic

Basic

VLANs (ISL⁷ and IEEE 802.10) (Cisco 4500 only)

Plus

No

Plus

Plus

XNS

No

No

No

Basic

WAN Services

ATM LAN emulation: DECnet routing, XNS routing, and Banyan VINES support (Cisco 4500 and 4700 only)⁸

No

No

Plus

Plus

ATM LAN emulation: Hot Standby Router Protocol (HSRP) and Simple Server Redundancy Protocol (SSRP)
(Cisco 4500 and 4700 only)

Plus

No

Plus

Plus

ATM: Rate queues for SVC per subinterface (Cisco 4000, 4500, and 4700 only)

Plus

No

Plus

Plus

ATM: UNI 3.1 signaling for ATM
(Cisco 4500 and 4700 only)

Plus

No

Plus

Plus

Combined Packet Protocol (CPP)

Basic

Basic

Basic

Basic

Dialer profiles

Basic

Basic

Basic

Basic

Frame Relay

Basic

Basic

Basic

Basic

Frame Relay SVC Support (DTE)

No

No

No

Basic

Frame Relay traffic shaping

Basic

Basic

Basic

Basic

Half bridge/half router for CPP and PPP

Basic

Basic

Basic

Basic

HDLC

Basic

Basic

Basic

Basic

IPXWAN 2.0

No

Basic

Basic

Basic

ISDN⁹

Basic

Basic

Basic

Basic

Multichassis Multilink PPP (MMP)

No

No

No

Basic

NetBEUI over PPP

No

No

No

Basic

PPP¹⁰

Basic

Basic

Basic

Basic

SMDS

Basic

Basic

Basic

Basic

Switched 56

Basic

Basic

Basic

Basic

Virtual Private Dial-Up Network (VPDN)

Plus

No

Plus

Basic

X.25¹¹

Basic

Basic

Basic

Basic

WAN Optimization

Bandwidth-on-demand

Basic

Basic

Basic

Basic

Custom and priority queuing

Basic

Basic

Basic

Basic

Dial backup

Basic

Basic

Basic

Basic

Dial-on-demand

Basic

Basic

Basic

Basic

Header¹², link and payload compression

Basic

Basic

Basic

Basic

Snapshot routing

Basic

Basic

Basic

Basic

Weighted fair queuing

Basic

Basic

Basic

Basic

IP Routing

BGP

Basic

Basic

Basic

Basic

BGP4¹³

Basic

Basic

Basic

Basic

EGP

Basic

Basic

Basic

Basic

Enhanced IGRP

Basic

Basic

Basic

Basic

Enhanced IGRP Optimizations

Basic

Basic

Basic

Basic

ES-IS

No

No

No

Basic

IGRP

Basic

Basic

Basic

Basic

IS-IS

No

No

No

Basic

Named IP Access Control List

Basic

Basic

Basic

Basic

Network Address Translation (NAT)

Plus

No

Plus

Plus

NHRP

Basic

Basic

Basic

Basic

On Demand Routing (ODR)

Basic

Basic

Basic

Basic

OSPF

Basic

Basic

Basic

Basic

OSPF Not-So-Stubby-Areas (NSSA)

Basic

Basic

Basic

Basic

OSPF On Demand Circuit (RFC 1793)

Basic

Basic

Basic

Basic

PIM

Basic

Basic

Basic

Basic

Policy-based routing

Basic

Basic

Basic

Basic

RIP

Basic

Basic

Basic

Basic

RIP Version 2

Basic

Basic

Basic

Basic

Other Routing

AURP

No

No

Basic

Basic

IPX RIP

No

Basic

Basic

Basic

NLSP

No

Basic

Basic

Basic

RTMP

No

No

Basic

Basic

SMRP

No

No

Basic

Basic

SRTP

No

No

No

Basic

Multimedia and Quality of Service

Generic traffic shaping

Basic

Basic

Basic

Basic

Random Early Detection (RED)¹⁴

Basic

Basic

Basic

Basic

Resource Reservation Protocol (RSVP)14

Basic

Basic

Basic

Basic

Management

AutoInstall

Basic

Basic

Basic

Basic

Automatic modem configuration

Basic

Basic

Basic

Basic

HTTP Server

Basic

Basic

Basic

Basic

RMON events and alarms¹⁵

Basic

Basic

Basic

Basic

RMON full (Cisco 2500 series only)

Plus

Plus

Plus

Plus

SNMP

Basic

Basic

Basic

Basic

Telnet

Basic

Basic

Basic

Basic

Security

Access lists

Basic

Basic

Basic

Basic

Access security

Basic

Basic

Basic

Basic

Extended access lists

Basic

Basic

Basic

Basic

Kerberized login

No

No

No

Basic

Kerberos V client support

No

No

No

Basic

Lock and key

Basic

Basic

Basic

Basic

MAC security for hubs¹⁶

Basic

Basic

Basic

Basic

MD5 routing authentication

Basic

Basic

Basic

Basic

Router authentication and network layer encryption (40-bit or export controlled 56-bit DES)¹⁷

Encrypt

No

Encrypt

Encrypt

RADIUS

Basic

Basic

Basic

Basic

TACACS+¹⁸

Basic

Basic

Basic

Basic

IBM Support (optional)

APPN (optional)2

No

Basic

No

Basic

BAN for SNA Frame Relay support

Plus

Basic

Plus

Basic

Bisync

Plus

Basic

Plus

Basic

Caching and filtering

Plus

Basic

Plus

Basic

DLSw+ ¹⁹

Plus

Basic

Plus

Basic

Downstream PU concentration (DSPU)

Plus

Basic

Plus

Basic

Frame Relay SNA support (RFC 1490)

Plus

Basic

Plus

Basic

Native Client Interface Architecture (NCIA) Server

Plus

Basic

Plus

Basic

NetView Native Service Point

Plus

Basic

Plus

Basic

QLLC

Plus

Basic

Plus

Basic

Response Time Reporter (RTR)

Plus

Basic

Plus

Basic

SDLC integration

Plus

Basic

Plus

Basic

SDLC transport (STUN)

Plus

Basic

Plus

Basic

SDLC-to-LAN conversion (SDLLC)

Plus

Basic

Plus

Basic

SNA and NetBIOS WAN optimization
via local acknowledgment

Plus

Basic

Plus

Basic

SRB/RSRB²⁰

Plus

Basic

Plus

Basic

SRT

Plus

Basic

Plus

Basic

TG/COS

No

No

No

Basic

TN3270

No

No

No

Basic

Protocol Translation

LAT

No

No

No

Basic

Rlogin

No

No

No

Basic

Remote Node²¹

ARAP 1.0/2.0²²

No

No

Basic

Basic

Asynchronous master interfaces

Basic

Basic

Basic

Basic

ATCP

No

No

Basic

Basic

CPPP

Basic

Basic

Basic

Basic

CSLIP

Basic

Basic

Basic

Basic

DHCP

Basic

Basic

Basic

Basic

IP pooling

Basic

Basic

Basic

Basic

IPX and ARAP on virtual async interfaces

No

No

No

Basic

IPXCP12

No

Basic

Basic

Basic

MacIP

No

No

Basic

Basic

NASI

No

Basic

Basic

Basic

PPP

Basic

Basic

Basic

Basic

SLIP

Basic

Basic

Basic

Basic

Terminal Services21

LAT²³

No

No

No

Basic

Rlogin

Basic

Basic

Basic

Basic

Telnet

Basic

Basic

Basic

Basic

TN3270

No

No

No

Basic

X.25 PAD

Basic

Basic

Basic

Basic

Xremote

No

No

No

Basic

¹This feature set has no additional options. It offers a low-end APPN solution for this set of hardware platforms. This feature set is not available for AccessPro PC cards.

²Enterprise is available with APPN in a separate feature set. APPN includes APPN Central Registration (CRR) and APPN over DLSw+. APPN is not available on the AccessPro PC Card.

³This feature includes AppleTalk load balancing.

⁴IRB supports IP, IPX, and AppleTalk; it is supported for transparent bridging, but not for SRB; it is supported on all media-type interfaces except X.25 and ISDN bridged interfaces; and IRB and concurrent routing and bridging (CRB) cannot operate at the same time.

⁵The Novell IPX feature includes display SAP by name, IPX Access Control List violation logging, and plain-English IPX access lists.

⁶Translational bridging is fast switched by default but can be disabled.

⁷Note that the only IPX encapsulation supported in ISL is 802.3.

⁸ATM LAN emulation for Banyan VINES is only supported in Enterprise. The Desktop feature set supports DECnet only.

⁹ISDN support includes calling line identification (ANI), X.25 over the B channel, ISDN subaddressing, and applicable WAN optimization features.

¹⁰PPP includes support for LAN protocols supported by the feature set, address negotiation, PAP and CHAP authentication, Multilink PPP, and PPP compression.

¹¹X.25 includes X.25 switching.

¹²IPX header compression (RFC 1553) is available in the feature sets that support IPX.

¹³BGP4 includes soft configuration, multipath support, and prefix filtering with inbound route maps.

¹⁴RED and RSVP are supported in IP/IPX/IBM/APPN for the Cisco 4000, 4500, and 4700 only.

¹⁵The RMON events and alarms groups are supported on all interfaces. Full RMON support is available with the Plus feature sets.

¹⁶MAC security for hubs is applicable to the following Cisco 2500 series Ethernet hub models: Cisco 2505, 2507, 2516, and 2518.

¹⁷For more details, see the description of the new data encryption options in the section "Cisco IOS Packaging" in the Release Notes for Cisco IOS
Release 11.2. (See the "Related Documentation" section for information on accessing the related release notes.)

¹⁸TACACS+ Single Connection and TACACS+ SENDAUTH enhancements are supported.

¹⁹Cisco IOS Release 11.2 introduces several DLSw+ enhancements available in the Plus, Plus 40, and Plus 56 feature sets.

²⁰SRB/RSRB is fast switched. This enhancement is on by default, but can be disabled.

²¹This feature is supported on access servers (with limited support on router auxiliary ports).

²²The Cisco 4000, 4500, and 4700 products do not support ARAP 1.0/2.0.

²³Use of LAT requires terminal license (FR-L8-10.X= for an 8-user license or FR-L16-10.X= for a 16-user license).

New and Changed Information

The following sections list the new hardware and software features supported by the Cisco 4000 series for Cisco IOS Release 11.2P.

New Features in Cisco IOS Release 11.2(25)P

No new features are supported by the Cisco 4000 series for Cisco IOS Release 11.2(26)P.

New Hardware Features in Previous Releases

The following hardware features were introduced in previous Cisco IOS 11.2 P releases:

•Fast Ethernet—Release 11.2(2)P

•2T16S Network Processor Module—Release 11.2(3)P

•High-Speed Serial Interface Network Processor Module—Release 11.2(5)P

•Network Processor Two-Port Ethernet Full-Duplex (NP-2E-FDX)—Release 11.2(14)P

New Software Features in Previous Releases

The following software features were introduced in previous Cisco IOS 11.2 P releases:

•Web Cache Control Protocol—Release 11.2(10)P

•Cisco IOS WCCP Support—Release 11.2(10)P

•FDDI Frames-Per-Token Limit—Release 11.2(11)P

Important Notes

Product Number Change

Beginning with Cisco IOS Release 12.0(7)XK, Cisco changed the product numbers you use to order a specific Cisco IOS software image. In short, Cisco will remove the periods separating the release train, maintenance release, and build number. The following table provides some examples.

Old Product Number

New Product Number

Release

Image Description

S364AR1K2-12.0.7XK=

S364AR1K2-12007XK=

Cisco IOS Release 12.0(7) XK

Cisco 3640 series IOS Enterprise/SNA SW PLUS IPSEC 3DES

S26CP-12.0.7XK=

S26CP-12007XK=

Cisco IOS Release 12.0(7) XK

Cisco 2600 series IOS IP Plus

Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

For information on caveats in Cisco IOS Release 11.2 P, refer to the Caveats for Cisco IOS Release 11.2 P located on Cisco.com and the Documentation CD-ROM.

All caveats in Cisco IOS Release 11.2 are also in Cisco IOS Release 11.2 P.

For information on caveats in Cisco IOS Release 11.2, refer to the "Caveats" section in the Cross-Platform Release Notes for Cisco IOS Release 11.2 on Cisco.com and the Documentation CD-ROM. These release notes list severity 1 and 2 caveats affecting all maintenance releases.

Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on Cisco.com at Software & Support: Online Technical Support: Software Bug Toolkit or at http://www.cisco.com/support/bugtools.

Related Documentation

The following sections describe the documentation available for the Cisco 4000 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.

Documentation is available as printed manuals or electronic documents, except for feature modules, which are only available online on Cisco.com and the Documentation CD-ROM.

Use these release notes with these documents:

•Release-Specific Documents

•Platform-Specific Documents

•Feature Modules

•Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Release 11.2 and are located on Cisco.com and the Documentation CD-ROM:

•Release Notes for Cisco IOS Release 11.2

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Release Notes for Cisco IOS Release 11.2

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Release Notes for Cisco IOS Release 11.2

•Product bulletins, field notices, and other release-specific documents on Cisco.com at:

Technical Documents

•Caveats for Cisco IOS Release 11.2 P

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Product Specific Release Notes for Cisco IOS Release 11.2: Caveats for Release 11.2 P

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Product Specific Release Notes for Cisco IOS Release 11.2: Caveats for Release 11.2 P

Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on Cisco.com at Software & Support: Online Technical Support: Software Bug Toolkit or at http://www.cisco.com/support/bugtools.

Platform-Specific Documents

The following documents are specific to the Cisco 4000 series:

•Cisco 4000 Series Hardware Installation and Maintenance

•Cisco 4000 Series Installation Guide

•Redundant Power Systems

•Regulatory Compliance and Safety Information

•Cisco 4000 Series Configuration Notes

On Cisco.com at:

Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 4000 Series (4000/4500/4700/4000-M/4500-M/4700-M)

On the Documentation CD-ROM at:

Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 4000 Series (4000/4500/4700/4000-M/4500-M/4700-M)

Feature Modules

Feature modules describe new features supported by Release 11.2 P and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, feature modules are available online only. The feature module information is included in the next printing of the Cisco IOS documentation set.

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Feature Guide for Cisco IOS Release 11.2 P

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Feature Guide for Cisco IOS Release 11.2 P

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used with its corresponding command reference.

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Cisco IOS Release 11.2 Configuration Guides/Command References or Command Reference Master Index

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Cisco IOS Release 11.2 Configuration Guides/Command References or Command Reference Master Index

Cisco IOS Release 11.2 Documentation Set

Table 5 describes the contents of the Cisco IOS Release 11.2 P software documentation set, which is available in electronic form and in printed form upon request.

Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the paper documents were printed.

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2

Table 5 Cisco IOS Release 11.2 P Software Documentation Set

Books

Chapter Topics

•Configuration Fundamentals Configuration Guide

•Configuration Fundamentals Command Reference

Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
Interface Configuration
System Management

•Network Protocols Configuration Guide, Part 1

•Network Protocols Command Reference, Part 1

IP Addressing
IP Services
IP Routing Protocols

•Network Protocols Configuration Guide, Part 2

•Network Protocols Command Reference, Part 2

AppleTalk
Novell IPX

•Network Protocols Configuration Guide, Part 3

•Network Protocols Command Reference, Part 3

Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

•Wide-Area Networking Configuration Guide

•Wide-Area Networking Command Reference

Wide-Area Networking Overview
ATM
Frame Relay
SMDS
X.25 and LAPB

•Security Configuration Guide

•Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering
Network Data Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options

•Dial Solutions Configuration Guide

•Dial Solutions Command Reference

Business Applications and Scenarios
Dial-In Port Setup
Dial-In Terminal Services and Remote Note Configuration
Dial Authentication
Dial-on-Demand Routing (DDR)
Dial Backup
Dial-Out Modem Pooling
Large-Scale Dial Solutions
Dial-Related Addressing Services (NAT/Easy IP)
Cost-Control Solutions
Network Traffic over ISDN Channels
X.25 over ISDN
Virtual Private Dialup Networks

•Cisco IOS Switching Services Configuration Guide

•Cisco IOS Switching Services Command Reference

Switching Paths for IP Networks
NetFlow Switching
Virtual LAN (VLAN) Routing
LAN Emulation

•Configuration Fundamentals Configuration Guide

•Configuration Fundamentals Command Reference

Transparent Bridging
Source-Route Bridging
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point Support
SNA Frame Relay Access Support
APPN
NCIA Client/Server Topologies
IBM Channel Attach

•Network Protocols Configuration Guide, Part 1

•Network Protocols Command Reference, Part 1

Note Cisco Management Information Base (MIB) User Quick Reference is no longer published. For the latest list of MIBs supported by Cisco, see Cisco Network Management Toolkit on Cisco.com at: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.

Obtaining Documentation

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtm.

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly. Therefore, it is probably more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

•Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products Marketplace:

http://www.cisco.com/cgi-bin/order/order-root.pl

•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at (408) 526-7208 or, in North America, by calling (800) 553-NETS (6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:

Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.comto obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC web site is available to all customers who need technical assistance with a Cisco product of technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.

Hierarchical Navigation

Cisco IOS Software Releases 11.2

Release Notes for Cisco 4000 Series for Cisco IOS Release 11.2 P

Downloads

Table Of Contents

Release Notes for the Cisco 4000 Series for Cisco IOS Release 11.2 P

Contents

System Requirements

Memory Recommendations

Hardware Supported

Determining the Software Version

Upgrading to a New Software Release

Feature Set Tables

New and Changed Information

New Features in Cisco IOS Release 11.2(25)P

New Hardware Features in Previous Releases

New Software Features in Previous Releases

Important Notes

Product Number Change

Caveats

Related Documentation

Release-Specific Documents

Platform-Specific Documents

Feature Modules

Cisco IOS Software Documentation Set

Documentation Modules

Cisco IOS Release 11.2 Documentation Set

Obtaining Documentation

World Wide Web

Documentation CD-ROM

Ordering Documentation

Documentation Feedback

Obtaining Technical Assistance

Cisco.com

Technical Assistance Center

Contacting TAC by Using the Cisco TAC Website

Contacting TAC by Telephone
