Release Notes for the Cisco 4000 Series for Cisco IOS Release 11.2

April 9, 2001

Note Cisco IOS Release 11.2(26) is the last scheduled maintenance release for Cisco IOS Release 11.2. TAC support will continue to be available. These Release Notes will be the last Release Notes published for Cisco IOS Release 11.2.

Note You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents may contain updates and modifications made after the hardcopy documents were printed.

These release notes for the Cisco 4000 series routers support Cisco IOS Release 11.2, up to and including Cisco IOS Release 11.2(26). These release notes are updated as needed to describe new features, memory recommendations, hardware support, software platform deferrals, and changes to the microcode or modem code and related documents.

For a list of software caveats that apply to Cisco IOS Release 11.2(26), see the "Caveats" section and the "Caveats" section of Release Notes for Cisco IOS Release 11.2. The caveats document is updated for every maintenance release.

Use these release notes with Release Notes for Cisco IOS Release 11.2 located on Cisco.com and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

•System Requirements

•New and Changed Information

•Important Notes

•Caveats

•Related Documentation

•Obtaining Documentation

•Obtaining Technical Assistance

System Requirements

This section describes the system requirements for Release 11.2:

•Memory Recommendations

•Hardware Supported

•Determining the Software Version

•Upgrading to a New Software Release

•Feature Set Tables

Memory Recommendations

Table 1 Memory Recommendations for the Cisco 4000 Series Routers

Feature Set by Platform

Image Name

Recommended Flash Memory

Recommended DRAM Memory

Runs From¹

Cisco 4X00

Cisco 4X00-M

Cisco 4000 and Cisco 4000-M

IP

c4000-i-mz

4 MB

16 MB

8 MB

RAM

IP Plus²

c4000-is-mz

4 MB

16 MB

8 MB

RAM

IP Plus 40

c4000-is40-mz

4 MB

16 MB

8 MB

RAM

IP Plus 56

c4000-is56-mz

4 MB

16 MB

8 MB

RAM

IP/IPX/AT/DEC

c4000-d-mz

4 MB

16 MB

8 MB

RAM

IP/IPX/AT/DEC Plus

c4000-ds-mz

4 MB

16 MB

16 MB

RAM

IP/IPX/AT/DEC Plus 40

c4000-ds40-mz

4 MB

16 MB

16 MB

RAM

IP/IPX/AT/DEC Plus 56

c4000-ds56-mz

4 MB

16 MB

16 MB

RAM

IP/IPX/IBM/APPN

c4000-ainr-mz

4 MB

32 MB

32 MB

RAM

Enterprise

c4000-j-mz

4 MB

16 MB

16 MB

RAM

Enterprise Plus

c4000-js-mz

8 MB

16 MB

16 MB

RAM

Enterprise Plus 40

c4000-js40-mz

8 MB

16 MB

16 MB

RAM

Enterprise Plus 56

c4000-js56-mz

8 MB

16 MB

16 MB

RAM

Enterprise/APPN Plus

c4000-ajs-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 40

c4000-ajs40-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 56

c4000-ajs56-mz

8 MB

32 MB

32 MB

RAM

Cisco 4500
Cisco 4500-M

IP

c4500-i-mz

4 MB

32 MB

16 MB³

RAM

IP Plus⁴

c4500-is-mz

4 MB

32 MB

16 MB

RAM

IP Plus 40

c4500-is40-mz

4 MB

32 MB

16 MB

RAM

IP Plus 56

c4500-is56-mz

4 MB

32 MB

32 MB

RAM

IP/IPX/AT/DEC

c4500-d-mz

4 MB

32 MB

16 MB

RAM

IP/IPX/AT/DEC Plus

c4500-ds-mz

4 MB

32 MB

16 MB

RAM

IP/IPX/AT/DEC Plus 40

c4500-ds40-mz

4 MB

32 MB

16 MB

RAM

IP/IPX/AT/DEC Plus 56

c4500-ds56-mz

4 MB

32 MB

16 MB

RAM

IP/IPX/IBM/APPN

c4500-ainr-mz

8 MB

32 MB

32 MB

RAM

Enterprise

c4500-j-mz

8 MB

32 MB

16 MB

RAM

Enterprise Plus

c4500-js-mz

8 MB

32 MB

16 MB

RAM

Enterprise Plus 40

c4500-js40-mz

8 MB

32 MB

16 MB

RAM

Enterprise Plus 56

c4500-js56-mz

8 MB

32 MB

16 MB

RAM

Enterprise/APPN Plus

c4500-ajs-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 40

c4500-ajs40-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 56

c4500-ajs56-mz

8 MB

32 MB

32 MB

RAM

Cisco 4700
Cisco 4700-M

IP

c4500-i-mz

4 MB

16 MB

16 MB

RAM

IP Plus4

c4500-is-mz

4 MB

16 MB

16 MB

RAM

IP Plus 40

c4500-is40-mz

4 MB

16 MB

16 MB

RAM

IP Plus 56

c4500-is56-mz

4 MB

32 MB

32 MB

RAM

IP//IPX/AT/DEC

c4500-d-mz

4 MB

16 MB

16 MB

RAM

IP//IPX/AT/DEC Plus

c4500-ds-mz

4 MB

16 MB

16 MB

RAM

IP//IPX/AT/DEC Plus 40

c4500-ds40-mz

4 MB

16 MB

16 MB

RAM

IP//IPX/AT/DEC Plus 56

c4500-ds56-mz

4 MB

16 MB

16 MB

RAM

IP/IPX/IBM/APPN

c4500-ainr-mz

8 MB

32 MB

32 MB

RAM

Enterprise

c4500-j-mz

8 MB

16 MB

16 MB

RAM

Enterprise Plus

c4500-js-mz

8 MB

16 MB

16 MB

RAM

Enterprise Plus 40

c4500-js40-mz

8 MB

16 MB

16 MB

RAM

Enterprise Plus 56

c4500-js56-mz

8 MB

16 MB

16 MB

RAM

Enterprise/APPN Plus

c4500-ajs-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 40

c4500-ajs40-mz

8 MB

32 MB

32 MB

RAM

Enterprise/APPN Plus 56

c4500-ajs56-mz

8 MB

32 MB

32 MB

RAM

¹When a system is running from Flash memory, you cannot update the system while it is running. You must use the Flash memory load helper.

²Plus for the Cisco 4000 and Cisco 4000-M includes NAT and IBM (if IBM is not already included).

³The Cisco 4500 requires 16 MB DRAM when two NP-CT1 or two NP-CE1 Network Processor Modules are installed in the chassis.

⁴Plus for the Cisco 4500, Cisco 4500-M, Cisco 4700, and Cisco 4700-M includes NAT, ISL, LANE, and IBM (if IBM is not already included).

Hardware Supported

Cisco IOS Release 11.2(26) supports the Cisco 4000 series:

•Cisco 4000, Cisco 4000-M

•Cisco 4500, Cisco 4500-M

•Cisco 4700, Cisco 4700-M

The following LAN interfaces are supported on Cisco 4000 series routers:

•Ethernet (AUI)

•Ethernet (10BaseT)

•4-Mbps Token Ring

•16-Mbps Token Ring

•FDDI DAS

•FDDI SAS

•FDDI multimode (DAS/SAS)

•FDDI single-mode

•ATM

•Multichannel interface (channelized E1/T1)

•Packet-over-SONET OC-3 Interface2

•Synchronous serial

The following WAN data rates are supported on Cisco 4000 series routers:

•48/56/64 kbps

•1.544/2.048 Mbps

The following WAN interfaces are supported on Cisco 4000 series routers:

•EIA/TIA-232

•X.21

•V.35

•EIA/TIA-449

•EIA-530

•ISDN BRI

•ISDN PRI

•E1-G.703/G.704

Determining the Software Version

To determine the version of Cisco IOS software running on your Cisco 4000 series router, log in to the router and enter the show version EXEC command:
router> show version
Cisco Internetwork Operating System Software
router>

Upgrading to a New Software Release

For general information about upgrading to a new software release, see Cisco IOS Upgrade Ordering Instructions located at:

http://www.cisco.com/warp/public/cc/cisco/mkt/ios/prodlit/957_pp.htm

Feature Set Tables

Cisco IOS software is packaged into feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features, as shown in Table 2.

Table 2 Feature Set Matrix for the Cisco 4000 Series

Standard Feature Sets

Cisco 4000 Series

IP

Basic, Plus, Encrypt

IP/IPX/AppleTalk/DEC

Basic, Plus, Encrypt

Enterprise

Basic, Plus, Encrypt

Enterprise and APPN

Plus, Encrypt

IP/IPX/IBM and IBM

Basic

Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders can be denied or subject to delay due to Unites States government regulations. When applicable, obtain local import and use authorizations for all encryption strengths. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.

Table 3Table 3 lists the features and feature sets supported by the Cisco 4000 series in Cisco IOS Release 11.2(26) and uses the following conventions:

•Yes—This feature is offered in the feature set.

•No—This feature is not offered in the feature set.

•Basic—This feature is offered in the basic feature set.

•Plus—This feature is offered in the Plus feature set.

•Encrypt—This feature is offered in the encryption feature sets, which consist of 40-bit (Plus 40) or 56-bit (Plus 56) data encryption feature sets.

Note This table might not be cumulative or list all the features in each image. You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents can contain updates and modifications made after the hardcopy documents were printed. If you have a Cisco.com login account, you can find image and release information regarding features prior to Cisco IOS Release 11.2(26) by using the Feature Navigator tool at: http://www.cisco.com/go/fn.

Table 3 Feature List by Feature Set for the Cisco 4000 Series Routers

Feature

Feature Set

IP Routing

IP/IPX/
IBM/APPN¹

IP/IPX/
AppleTalk/
DEC

Enterprise²

LAN Support

Apollo Domain

No

No

No

Yes

AppleTalk 1 and 2³

No

No

Yes

Yes

Banyan VINES

No

No

No

Yes

Concurrent routing and bridging (CRB)

Yes

Yes

Yes

Yes

DECnet IV

No

No

Yes

Yes

DECnet V

No

No

No

Yes

GRE

Yes

Yes

Yes

Yes

Integrated routing and bridging (IRB)⁴

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Novell IPX⁵

No

Yes

Yes

Yes

OSI

No

No

No

Yes

Source-route bridging⁶

No

No

No

No

Transparent and translational bridging

Yes

Yes

Yes

Yes

VLANs (ISL⁷ and IEEE 802.10) (Cisco 4500 only)

Plus

No

Plus

Plus

XNS

No

No

No

Yes

WAN Services

ATM LAN emulation: DECnet routing, XNS routing, and Banyan VINES support (Cisco 4500 and Cisco 4700 only)⁸

No

No

Plus

Plus

ATM LAN emulation: Hot Standby Router Protocol (HSRP) and Simple Server Redundancy Protocol (SSRP)
(Cisco 4500 and Cisco 4700 only)

Plus

No

Plus

Plus

ATM: Rate queues for SVC per subinterface (Cisco 4000, Cisco 4500, and Cisco 4700 only)

Plus

No

Plus

Plus

ATM: UNI 3.1 signaling for ATM
(Cisco 4500 and Cisco 4700 only)

Plus

No

Plus

Plus

Combinet Packet Protocol (CPP)

Yes

Yes

Yes

Yes

Dialer profiles

Yes

Yes

Yes

Yes

Frame Relay

Yes

Yes

Yes

Yes

Frame Relay SVC Support (DTE)

No

No

No

Yes

Frame Relay traffic shaping

Yes

Yes

Yes

Yes

Half bridge/half router for CPP and PPP

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

IPXWAN 2.0

No

Yes

Yes

Yes

ISDN⁹

Yes

Yes

Yes

Yes

Multichassis Multilink PPP (MMP)

No

No

No

Yes

NetBEUI over PPP

No

No

No

Yes

PPP¹⁰

Yes

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Switched 56

Yes

Yes

Yes

Yes

Virtual Private Dial-Up Network (VPDN)

Plus

No

Plus

Yes

X.25¹¹

Yes

Yes

Yes

Yes

WAN Optimization

Bandwidth-on-demand

Yes

Yes

Yes

Yes

Custom and priority queuing

Yes

Yes

Yes

Yes

Dial backup

Yes

Yes

Yes

Yes

Dial-on-demand

Yes

Yes

Yes

Yes

Header¹², link and payload compression

Yes

Yes

Yes

Yes

Snapshot routing

Yes

Yes

Yes

Yes

Weighted fair queuing

Yes

Yes

Yes

Yes

IP Routing

BGP

Yes

Yes

Yes

Yes

BGP4¹³

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Enhanced IGRP Optimizations

Yes

Yes

Yes

Yes

ES-IS

No

No

No

Yes

IGRP

Yes

Yes

Yes

Yes

IS-IS

No

No

No

Yes

Named IP Access Control List

Yes

Yes

Yes

Yes

Network Address Translation (NAT)

Plus

No

Plus

Plus

NHRP

Yes

Yes

Yes

Yes

On Demand Routing (ODR)

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

OSPF Not-So-Stubby-Areas (NSSA)

Yes

Yes

Yes

Yes

OSPF On Demand Circuit (RFC 1793)

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

Policy-based routing

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

RIP Version 2

Yes

Yes

Yes

Yes

Other Routing

AURP

No

No

Yes

Yes

IPX RIP

No

Yes

Yes

Yes

NLSP

No

Yes

Yes

Yes

RTMP

No

No

Yes

Yes

SMRP

No

No

Yes

Yes

SRTP

No

No

No

Yes

Multimedia and Quality of Service

Generic traffic shaping

Yes

Yes

Yes

Yes

Random Early Detection (RED)¹⁴

Yes

Yes

Yes

Yes

Resource Reservation Protocol (RSVP)14

Yes

Yes

Yes

Yes

Management

AutoInstall

Yes

Yes

Yes

Yes

Automatic modem configuration

Yes

Yes

Yes

Yes

HTTP Server

Yes

Yes

Yes

Yes

RMON events and alarms¹⁵

Yes

Yes

Yes

Yes

SNMP

Yes

Yes

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

Security

Access lists

Yes

Yes

Yes

Yes

Access security

Yes

Yes

Yes

Yes

Extended access lists

Yes

Yes

Yes

Yes

Kerberized login

No

No

No

Yes

Kerberos V client support

No

No

No

Yes

Lock and key

Yes

Yes

Yes

Yes

MAC security for hubs

Yes

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Router authentication and network layer encryption (40-bit or export controlled 56-bit DES)¹⁶

Encrypt

No

Encrypt

Encrypt

RADIUS

Yes

Yes

Yes

Yes

TACACS+¹⁷

Yes

Yes

Yes

Yes

IBM Support (Optional)

APPN (optional)2

No

Yes

No

Yes

BAN for SNA Frame Relay support

Plus

Yes

Plus

Yes

Bisync

Plus

Yes

Plus

Yes

Caching and filtering

Plus

Yes

Plus

Yes

DLSw+ ¹⁸

Plus

Yes

Plus

Yes

Downstream PU concentration (DSPU)

Plus

Yes

Plus

Yes

Frame Relay SNA support (RFC 1490)

Plus

Yes

Plus

Yes

Native Client Interface Architecture (NCIA) Server

Plus

Yes

Plus

Yes

NetView Native Service Point

Plus

Yes

Plus

Yes

QLLC

Plus

Yes

Plus

Yes

Response Time Reporter (RTR)

Plus

Yes

Plus

Yes

SDLC integration

Plus

Yes

Plus

Yes

SDLC transport (STUN)

Plus

Yes

Plus

Yes

SDLC-to-LAN conversion (SDLLC)

Plus

Yes

Plus

Yes

SNA and NetBIOS WAN optimization
via local acknowledgment

Plus

Yes

Plus

Yes

SRB/RSRB¹⁹

Plus

Yes

Plus

Yes

SRT

Plus

Yes

Plus

Yes

TG/COS

No

No

No

Yes

TN3270

No

No

No

Yes

Protocol Translation

LAT

No

No

No

Yes

Rlogin

No

No

No

Yes

Remote Node²⁰

ARAP 1.0/2.0²¹

No

No

Yes

Yes

Asynchronous master interfaces

Yes

Yes

Yes

Yes

ATCP

No

No

Yes

Yes

CPPP

Yes

Yes

Yes

Yes

CSLIP

Yes

Yes

Yes

Yes

DHCP

Yes

Yes

Yes

Yes

IP pooling

Yes

Yes

Yes

Yes

IPX and ARAP on virtual async interfaces

No

No

No

Yes

IPXCP12

No

Yes

Yes

Yes

MacIP

No

No

Yes

Yes

NASI

No

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

SLIP

Yes

Yes

Yes

Yes

Terminal Services20

LAT²²

No

No

No

Yes

Rlogin

Yes

Yes

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

TN3270

No

No

No

Yes

X.25 PAD

Yes

Yes

Yes

Yes

Xremote

No

No

No

Yes

¹This feature set has no additional options. It offers a low-end APPN solution for this set of hardware platforms. This feature set is not available for AccessPro PC cards.

²Enterprise is available with APPN in a separate feature set. APPN includes APPN Central Registration (CRR) and APPN over DLSw+. APPN is not available on the AccessPro PC Card.

³This feature includes AppleTalk load balancing.

⁴IRB supports IP, IPX, and AppleTalk; it is supported for transparent bridging, but not for SRB; it is supported on all media-type interfaces except X.25 and ISDN bridged interfaces; and IRB and concurrent routing and bridging (CRB) cannot operate at the same time.

⁵The Novell IPX feature includes displaying SAP by name, IPX Access Control List violation logging, and plain-English IPX access lists.

⁶Translational bridging is fast switched by default but can be disabled.

⁷Note that the only IPX encapsulation supported in ISL is IEEE 802.3.

⁸ATM LAN emulation for Banyan VINES is only supported in Enterprise. The Desktop feature set supports DECnet only.

⁹ISDN support includes calling line identification (ANI), X.25 over the B channel, ISDN subaddressing, and applicable WAN optimization features.

¹⁰PPP includes support for LAN protocols supported by the feature set, address negotiation, PAP and CHAP authentication, Multilink PPP, and PPP compression.

¹¹X.25 includes X.25 switching.

¹²IPX header compression (RFC 1553) is available in the feature sets that support IPX.

¹³BGP4 includes soft configuration, multipath support, and prefix filtering with inbound route maps.

¹⁴RED and RSVP are supported in IP/IPX/IBM/APPN for the Cisco 4000, Cisco 4500, and Cisco 4700 only.

¹⁵The RMON events and alarms groups are supported on all interfaces. Full RMON support is available with the Plus feature sets.

¹⁶For more details, see the description of the new data encryption options in the section "Cisco IOS Packaging" in the Release Notes for Cisco IOS Release 11.2. (See the "Related Documentation" section for information on accessing the related release notes.)

¹⁷TACACS+ Single Connection and TACACS+ SENDAUTH enhancements are supported.

¹⁸Cisco IOS Release 11.2 introduces several DLSw+ enhancements available in the Plus, Plus 40, and Plus 56 feature sets.

¹⁹SRB/RSRB is fast switched. This enhancement is on by default, but it can be disabled.

²⁰These features are supported on access servers (with limited support on router auxiliary ports).

²¹The Cisco 4000, Cisco 4500, and Cisco 4700 products do not support ARAP 1.0/2.0.

²²Use of LAT requires terminal license (FR-L8-10.X= for an 8-user license or FR-L16-10.X= for a 16-user license).

New and Changed Information

The following section lists the new hardware and software features supported by the Cisco 4000 series for Cisco IOS Release 11.2.

New Features in Cisco IOS Release 11.2(26)

There are no new features in Cisco IOS Release 11.2(26). Previous releases support features in the following categories:

•IBM Support

•Internet

•LAN Support

•Management

•Multimedia

•Quality of Service

•Security

•Switching

•Terminal Services

•WAN Optimization

•WAN Services

Detailed descriptions of the features can be found on Cisco.com or on the Documentation CD-ROM. See the "Obtaining Documentation" section for more details.

Important Notes

The following sections contain important notes about Cisco IOS Release 11.2 and apply to the Cisco 4000 series.

Cisco IOS Release 11.2(15a) and 11.2(15a)P

After the release of Cisco IOS Release 11.2(15) and 11.2(15)P, a serious defect (caveat CSCdk33475) was identified that impacts Enhanced IGRP for Cisco IOS Releases 11.2(14.1) through 11.2(15.2) and Releases 11.2(14.1)P through 11.2(15.2)P. It was determined that this defect was significant enough to merit a software rebuild. The rebuild includes the caveat fix and is renumbered to 11.2(15a) and 11.2(15a) P.

Caveat CSCdk33475 causes a router to fail after the command show ip eigrp events is entered. While this show command is not required for normal operation, its use might present difficulties for customers who are running images with this defect.

Release 11.2(15a) and Release 11.2(15a)P and all subsequent releases of Cisco IOS software, including Release 11.2(16) and Release 11.2(16)P, include the fix for this caveat.

Cisco IOS Release 11.2 Switches to Long-Cycle Maintenance Releases

Beginning with Cisco IOS Release 11.2(15) and Release 11.2(15)P, all subsequent 11.2 and 11.2 P releases switch to Long-Cycle Maintenance Releases. A new 11.2 and 11.2 P maintenance release is scheduled to be available every thirteen weeks during the Long-Cycle Maintenance Release period. Interim builds will be available approximately every two weeks.

Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

For information on caveats in Cisco IOS Release 11.2, see Cross-Platform Release Notes for Cisco IOS Release 11.2 located on Cisco.com and the Documentation CD-ROM, that describes caveats affecting all maintenance releases.

Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. You can reach Bug Navigator II on Cisco.com at Software Center: Cisco IOS Software: Cisco Bug Toolkit: Cisco Bugtool Navigator II, or at http://www.cisco.com/support/bugtools.

Related Documentation

The following sections describe the documentation available for the Cisco 4000 series. These documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, and other documents.

Documentation is available as printed manuals or electronic documents.

Use these release notes with these documents:

•Release-Specific Documents

•Platform-Specific Documents

•Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Release 11.2 and are located on Cisco.com and the Documentation CD-ROM:

•Cross-Platform Release Notes for Cisco IOS Release 11.2

On Cisco.com:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Product Specific Release Notes for Cisco IOS Release 11.2: Cross-Platform Release Notes for Cisco IOS Release 11.2

On the Documentation CD-ROM:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Product Specific Release Notes for Cisco IOS Release 11.2: Cross-Platform Release Notes for Cisco IOS Release 11.2

•Product bulletins, field notices, and other release-specific documents on Cisco.com at:

Technical Documents

Platform-Specific Documents

The following documents are specific to the Cisco 4000 series:

•Cisco 4000 Hardware Installation and Maintenance (Cisco 4000, Cisco 4000-M, Cisco 4500)

•Cisco 4000 Series Installation Guide (Cisco 4000-M, Cisco 4500-M, Cisco 4700-M)

•Cisco 4000 Series Configuration Notes (Cisco 4000, Cisco 4000-M, Cisco 4500, Cisco 4500-M, Cisco 4700, Cisco 4700-M)

•Cisco 4000 Series Regulatory Compliance and Safety Information (Cisco 4000, Cisco 4000-M, Cisco 4500, Cisco 4500-M, Cisco 4700, Cisco 4700-M)

•FDDI Frames-Per-Token Limit for the Cisco 4000 Series (Cisco 4000, Cisco 4000-M, Cisco 4500, Cisco 4500-M, Cisco 4700, Cisco 4700-M)

•Redundant Power Systems (Cisco 4000, Cisco 4000-M, Cisco 4500, Cisco 4500-M, Cisco 4700, Cisco 4700-M)

•Network Processor Two-Port Ethernet Full-Duplex (NP-2E-FDX) (Cisco 4500, Cisco 4500-M, Cisco 4700, Cisco 4700-M)

•Release Notes—Cisco 4000 Series Routers

On Cisco.com at:

Technical Documents: Documentation Home Page: Access Servers and Access Routers: Modular Access Routers: Cisco 4000 series

On the Documentation CD-ROM at:

Cisco Product Documentation: Access Servers and Access Routers: Modular Access Routers: Cisco 4000 series

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents, which are shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used with its corresponding command reference.

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Cisco IOS Release 11.2 Configuration Guides/Command References

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2: Cisco IOS Release 11.2 Configuration Guides/Command References

Release 11.2 Documentation Set

Table 4 describes the contents of the Cisco IOS Release 11.2 software documentation set, which is available in electronic form and in printed form on request.

Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the paper documents were printed.

On Cisco.com at:

Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 11.2

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.2

Table 4 Cisco IOS Software Documentation Set

Books

Chapter Topics

•Configuration Fundamentals Configuration Guide

•Configuration Fundamentals Command Reference

Configuration Fundamentals Overview
Cisco IOS User Interfaces
File Management
Interface Configuration
System Management

•Network Protocols Configuration Guide, Part 1

•Network Protocols Command Reference, Part 1

IP Addressing
IP Services
IP Routing Protocols

•Network Protocols Configuration Guide, Part 2

•Network Protocols Command Reference, Part 2

AppleTalk
Novell IPX

•Network Protocols Configuration Guide, Part 3

•Network Protocols Command Reference, Part 3

Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

•Wide-Area Networking Configuration Guide

•Wide-Area Networking Command Reference

ATM
Frame Relay
SMDS
X.25 and LAPB

•Security Configuration Guide

•Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering
Network Data Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options

•Dial Solutions Configuration Guide

•Dial Solutions Command Reference

Dial Business Solutions and Examples
Dial-In Port Setup
DDR and Dial Backup
Remote Node and Terminal Service
Cost-Control and Large-Scale Dial Solutions
VPDN

•Cisco IOS Switching Services Configuration Guide

•Cisco IOS Switching Services Command Reference

Switching Paths for IP Networks
Fast Switching
Autonomous Switching
NetFlow Switching
Optimum Switching
Virtual LAN (VLAN) Switching and Routing
Inter-Switch Link Protocol Encapsulation
IEEE 802.10 Encapsulation
LAN Emulation

•Bridging and IBM Networking Configuration Guide

•Bridging and IBM Networking Command Reference

Transparent Bridging
Source-Route Bridging
Remote Source-Route Bridging
DLSw+
STUN and BSTUN
LLC2 and SDLC
IBM Network Media Translation
DSPU and SNA Service Point
SNA Frame Relay Access Support
APPN
NCIA Client/Server Topologies
IBM Channel Attach

•Cisco IOS Software Command Summary

•Dial Solutions Quick Configuration Guide

•System Error Messages

•Debug Command Reference

Note Cisco Management Information Base (MIB) User Quick Reference is no longer published. For the latest list of MIBs supported by Cisco, see Cisco Network Management Toolkit on Cisco.com. From Cisco.com, click on the following path: Software Center: Network Mgmt Products: Cisco Network Management Toolkit: Cisco MIB.

Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

•Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

•Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

•Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:

Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC Web site.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following Web site:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC Web site is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Web site

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC Web site:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

•P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

•P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC Web site to quickly find answers to your questions.

To register for Cisco.com, go to the following Web site:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following Web site:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following Web site:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

•P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

•P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.

Cisco IOS Software Releases 11.2

Release Notes for Cisco 4000 Series for Cisco IOS Release 11.2

Hierarchical Navigation

Downloads

Table Of Contents

Release Notes for the Cisco 4000 Series for Cisco IOS Release 11.2

Contents

System Requirements

Memory Recommendations

Hardware Supported

Determining the Software Version

Upgrading to a New Software Release

Feature Set Tables

New and Changed Information

New Features in Cisco IOS Release 11.2(26)

Important Notes

Cisco IOS Release 11.2(15a) and 11.2(15a)P

Cisco IOS Release 11.2 Switches to Long-Cycle Maintenance Releases

Caveats

Related Documentation

Release-Specific Documents

Platform-Specific Documents

Cisco IOS Software Documentation Set

Documentation Modules

Release 11.2 Documentation Set

Obtaining Documentation

World Wide Web

Documentation CD-ROM

Ordering Documentation

Documentation Feedback

Obtaining Technical Assistance

Cisco.com

Technical Assistance Center

Contacting TAC by Using the Cisco TAC Web site

Contacting TAC by Telephone

Technology Trends
