Release Notes for
Cisco IOS Release 11.1 AA
July 25, 2003
This document describes the features and caveats for Cisco IOS Release 11.1 AA, up to and including Release 11.1(20) AA5. Release 11.1(20) AA5 is a platform-specific software release that supports features for the Cisco 1600 series routers, Cisco 3600 series routers, and Cisco AS5200 access servers. This document supplements the Cisco IOS Release 11.1 documentation set.
Use these release notes in conjunction with the Release Notes for Cisco IOS Release 11.1. For a list of software caveats that apply to this release, refer to the "Caveats" section and to the Caveats for Release 11.1. All related documentation can be located on Cisco.com and the Documentation CD-ROM. See the "Obtaining Documentation" section for more information.
Contents
These release notes discuss the following topics:
•
Obtaining Technical Assistance
•
System Requirements
This section describes the system requirements for Release 11.1 AA and includes the following subsections:
•
Memory Requirements
This section describes the memory requirements of the Cisco IOS features sets for Release 11.1(20) AA4AA4.
The memory requirements for feature sets available in Cisco IOS Release 11.1(20) AA4 are the same as those listed in the "Memory Requirements" in each of the platforms' hardware documentation.
Note
Table 1 lists the minimum memory requirements for the Cisco 1600 series routers feature sets.
Table 2 lists the minimum memory requirements for the Cisco 3600 series routers feature sets.
Table 3 lists the minimum memory requirements for the Cisco AS5200 access server feature sets.
Table 1 Minimum Memory Requirements for the Cisco 1600 Series
Table 2 Minimum Memory Requirements for the Cisco 3600 Series
Flash MemoryIP
4 MB
16 MB
IP with IBM base
4 MB
16 MB
IP/IPX
4 MB
16 MB
IP/IPX with IBM base
4 MB
16 MB
IP/IPX with IBM base
and APPN4 MB
32 MB
Desktop
4 MB
16 MB
Desktop with IBM base
4 MB
24 MB
Enterprise
4 MB
24 MB
Enterprise with APPN1
8 MB
32 MB
1 Dual-bank Flash memory is not supported with the Enterprise and APPN feature set.
Table 3 Minimum Memory Requirements for the Cisco AS5200
Supported Hardware
Cisco IOS Release 11.1 AA supports the following platforms:
•
•
•
Refer to the Release Notes for Cisco IOS Release 11.1 publication for a summary of the LAN interfaces supported on each platform and the WAN data rates and interfaces supported on each platform.
lists the interfaces supported in Cisco IOS Release11.1(20) AA4.
Table 4 Interfaces Supported
Determining Your Software Release
To determine the version of Cisco IOS software currently running on your device, log in to the router or access server and use the show version EXEC command. The following is sample output from the show version command. The version number is indicated on the second line as shown below:
Cisco Internetwork Operating System SoftwareIOS (tm) 1600 Software (C1600-JS-L), Version 11.1(20) AA4, RELEASE SOFTWAREAdditional command output lines include more information, such as processor revision numbers, memory amounts, hardware IDs, and partition information.
For information on upgrading to a new software release, refer to the Cisco IOS Software Release Upgrade Paths and Packaging Simplification product bulletin #703 located on Cisco.com. For more information, refer to the "Obtaining Documentation" section.
On Cisco.com, follow this path:
Products and Ordering: Product Bulletins: Upgrade Paths and Packaging Simplification
Feature Set Tables
The Cisco IOS software is packaged in feature sets (also called software images) depending on the platform. Each feature set contains a specific set of Cisco IOS features. The following sections list the features set matrix and the features supported by each feature set.
The following feature sets are available in Cisco IOS Release 11.1(20) AA4. Refer to Release Notes for Cisco IOS Release 11.1 for a complete list of the features provided in these sets.
The Cisco 1600 series routers feature sets are as follows:
•
•
•
•
The Cisco 3600 series routers feature sets are as follows:
•
•
•
•
•
The Cisco AS5200 access server feature sets are as follows:
•
•
•
New and Changed Information
The following sections list the new features that are available in each maintenance release of Cisco IOS Release 11.1 AA. Features are detailed in the documentation listed in the "Related Documentation" section.
New Features in Cisco IOS Releases 11.1(20) AA4 Through 11.1(15) AA
There were no new features introduced in these releases.
New Features in Cisco IOS Release 11.1(14) AA
This software release supports the Cisco AS5200 access server microcom modem module, which can connect up to 33.6 Kbps.
New Features in Cisco IOS Releases 11.1(13) AA Through 11.1(9) AA
There were no new features introduced in these releases.
New Features in Cisco IOS Release 11.1(8) AA
This software release supports the NM-1E1R2W network module for Cisco 3600 routers.
New Features in Cisco IOS Release 11.1(7) AA
The following new features were added in Cisco IOS Release 11.1(7) AA:
•
•
The Cisco 3640 is equipped with four network module slots. The Cisco 3620 has two slots. Each network module slot accepts a variety of network module interface cards, including LAN and WAN mixed media cards supporting Ethernet, Token Ring, and a variety of WAN technologies. These cards provide the foundation of LAN and WAN connectivity on a single network module. Additional applications are supported with a series of network module cards offering asynchronous and synchronous serial, ISDN PRI, and ISDN BRI interfaces.
•
This software release supports the dual E1 PRI interface card for Cisco AS5200 access servers.
New or Changed Commands in Cisco IOS Release 11.1(7) AA for Cisco 1600 Series Routers
The following is a list of ROM monitor and Cisco IOS commands that are new or modified, or have special syntax or usage for Cisco 1600 series routers. All other commands used with these routers are documented in the Cisco IOS Release 11.2 command references.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
For documentation describing the new software features specific to the Cisco 1600 series routers, refer to the online feature module New Features for Cisco 1600 Series Routers.
New or Changed Commands in Cisco IOS Release 11.1(7) AA for Cisco 3600 Series Routers
The following is a list of ROM monitor and Cisco IOS commands that are new or modified, or have special syntax or usage for Cisco 3600 series routers. All other commands used with these routers are documented in the Cisco IOS Release 11.2 command references.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
For documentation describing the new software features specific to the Cisco 3600 series routers, refer to the online feature module New Features for Cisco 3600 Series Routers.
New or Changed Commands in Cisco IOS Release 11.1(7)AA for Cisco AS5200 Access Server
The Cisco IOS command listed below is new or modified, or has a special syntax or usage for Cisco A5200 access server. All other commands used with this server are documented in the Cisco IOS Release 11.2 command references.
•
For documentation describing this new software feature specific to the Cisco AS5200 access server, refer to the online feature module Channelized E1 Signaling for the Cisco AS5200.
New Features in Cisco IOS Release 11.1(6) AA
The following new features were added to Cisco IOS Release 11.1(6) AA:
•
With this feature, you must configure E1 clocking using the clock source line primary command and the clock source line secondary command.
•
•
Caveats
There are no caveats specific to Cisco IOS Release 11.1(20) AA.
For complete descriptions of open and resolved caveats for previous maintenance releases, see the Caveats for Release 11.1 document on Cisco.com and on the Documentation CD-ROM.
•
Products and Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.1: Cisco IOS Release 11.1 Software Caveats.
•
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.1: Cisco IOS Release 11.1 Software Caveats.
See the "Obtaining Documentation" section for more information.
Open Caveats—Cisco IOS Release 11.1(20)AA5
There are no open caveats specific to Cisco IOS Release 11.1(20)AA5 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 11.1(20)AA5
All the caveats listed in this section are resolved in Cisco IOS Release 11.1(20)AA5. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
Cisco routers and switches running Cisco IOS software and configured to process Internet Protocol version 4 (IPv4) packets are vulnerable to a Denial of Service (DoS) attack. A rare sequence of crafted IPv4 packets sent directly to the device may cause the input interface to stop processing traffic once the input queue is full. No authentication is required to process the inbound packet. Processing of IPv4 packets is enabled by default. Devices running only IP version 6 (IPv6) are not affected. A workaround is available.
Cisco has made software available, free of charge, to correct the problem.
This advisory is available at
http://www.cisco.com/warp/public/707/cisco-sa-20030717-blocked.shtml
Open Caveats—Cisco IOS Release 11.1(20)AA4
There are no open caveats specific to Cisco IOS Release 11.1(20)AA4 that require documentation in the release notes.
Resolved Caveats—Cisco IOS Release 11.1(20)AA4
All the caveats listed in this section are resolved in Cisco IOS Release 11.1(20)AA4. This section describes only severity 1 and 2 caveats and select severity 3 caveats.
•
An error can occur with management protocol processing. Please use the following URL for further information:
http://www.cisco.com/pcgi-bin/bugtool/onebug.pl?bugid=CSCdw65903
Closed and Resolved Caveats—Release 11.1(20)AA3
This section describes caveats that have been closed and resolved in Cisco IOS Release 11.1(20)AA3.
•
A Border Gateway Protocol (BGP) UPDATE contains Network Layer Reachability Information (NLRI) and attributes that describe the path to the destination. Each path attribute is a type, length, value (TLV) object.
The type is a two-octet field that includes the attribute flags and the type code. The fourth high-order bit (bit 3) of the attribute flags is the Extended Length bit. It defines whether the attribute length is one octet (if set to 0) or two octets (if set to 1). The extended length bit is used only if the length of the attribute value is greater than 255 octets.
The AS_PATH (type code 2) is represented by a series of TLVs (or path segments). The path segment type indicates whether the content is an AS_SET or AS_SEQUENCE. The path segment length indicates the number of autonomous systems (ASes) in the segment. The path segment value contains the list of ASes (each AS is represented by two octets).
The total length of the attribute depends on the number of path segments and the number of ASes in them. For example, if the AS_PATH contains only an AS_SEQUENCE, then the maximum number of ASes (without having to use the extended length bit) is 126 [= (255-2)/2]. If the UPDATE is propagated across an AS boundary, then the local Abstract Syntax Notation (ASN) must be appended and the extended length bit used.
The caveat was caused by the mishandling of the operation during which the length of the attribute was truncated to only one octet. Because of the internal operation of the code, the receiving border router would not be affected, but its iBGP peers would detect the mismatch and issue a NOTIFICATION message (update malformed) to reset their session.
The average maximum AS_PATH length in the Internet is between 15 and 20 ASes, so there is no need to use the extended length. The failure was discovered because of a malfunction in the BGP implementation of another vendor. There is no workaround.
This caveat is resolved in Cisco IOS Release 11.1(20)AA3.
•
Cisco IOS software contains a flaw that permits the successful prediction of TCP Initial Sequence Numbers.
This vulnerability is present in all released versions of Cisco IOS software running on Cisco routers and switches. It only affects the security of TCP connections that originate or terminate on the affected Cisco device itself; it does not apply to TCP traffic forwarded through the affected device in transit between two other hosts.
To remove the vulnerability, Cisco is offering free software upgrades for all affected platforms. The defect is described in DDTS record CSCds04747.
Workarounds are available that limit or deny successful exploitation of the vulnerability by filtering traffic containing forged IP source addresses at the perimeter of a network or directly on individual devices.
This notice will be posted at http://www.cisco.com/warp/public/707/ios-tcp-isn-random-pub.shtml.
This caveat is resolved in Cisco IOS Release 11.1(20)AA3.
Related Documentation
The following sections describe the documentation available for the Cisco 1600 series, the Cisco 3600 series, and the Cisco AS5200 access server. Typically, these documents consist of hardware installation guides, software installation guide guides, Cisco IOS configuration and command references, system error messages, and feature modules, which are updates to the Cisco IOS documentation. Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online only.
The most up-to-date documentation can be found on the web via Cisco.com and on the latest Documentation CD-ROM. These electronic documents might contain updates and modifications made after the paper documents were printed. See the "Obtaining Documentation" section for more information.
This section contains the following subsections:
•
•
•
•
Cisco 1600 Series-Specific Documentation
The following Cisco 1600 documents are available:
•
•
•
•
•
•
•
Cisco 3600 Series-Specific Documentation
The following Cisco 3600 documents are available:
•
•
•
•
•
•
•
Cisco AS5200-Specific Documentation
The following Cisco AS5200 documents are available:
•
•
•
•
•
•
Feature Module Documentation
Feature modules describe new features supported by Release 11.1 AA and are an update to the Cisco IOS documentation set. As updates, the features modules are available online only. The feature module information is included in the next printing of the Cisco IOS documentation set. Feature modules consist of a brief overview of the feature, benefits, configuration tasks, and a command reference.
To access the feature modules on Cisco.com, follow this path:
Products and Ordering: Cisco Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.1: Feature Pack Information.
To access the feature modules on the documentation CD-ROM, follow this path:
Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 11.1: Feature Pack Information.
Feature Navigator
Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.
Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.
To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For Java Script support and enabling instructions for other browsers, check with the browser vendor.
Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:
http://www.cisco.com/go/fn
Cisco IOS Software Documentation
Table 5 lists the Cisco IOS software documentation set. Software documentation consists of the Cisco IOS configuration guides and command references and also includes several supporting documents. These documents are shipped with the routers and access servers in electronic form on the Documentation CD-ROM, unless you specifically ordered the printed version of the documents.
The Cisco IOS configuration guides, command references, and major topics are as follows:
Obtaining Documentation
The following sections provide sources for obtaining documentation from Cisco Systems.
World Wide Web
The most current Cisco documentation is available on the World Wide Web at http://www.cisco.com. Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.
Documentation CD-ROM
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.
Ordering Documentation
Cisco documentation is available in the following ways:
•
http://www.cisco.com/public/ordsum.html
•
http://www.cisco.com/go/subscription
•
Documentation Feedback
If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.
You can e-mail your comments to bug-doc@cisco.com.
To submit your comments by mail, for your convenience many documents contain a response card behind the front cover. Otherwise, you can mail your comments to the following address:
Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883
We appreciate your comments.Obtaining Technical Assistance
Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.
Cisco.com
Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.
Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.
Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.
To access Cisco.com, go to the following website:
http://www.cisco.com
Technical Assistance Center
The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.
Contacting TAC by Using the Cisco TAC Website
If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:
http://www.cisco.com/tac
P3 and P4 level problems are defined as follows:
•
•
In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.
To register for Cisco.com, go to the following website:
http://www.cisco.com/register/
If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:
http://www.cisco.com/tac/caseopen
Contacting TAC by Telephone
If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml
P1 and P2 level problems are defined as follows:
•
•
Open Source License Acknowledgements
The following notices pertain to this software license.
OpenSSL/Open SSL Project
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).
This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).
This product includes software written by Tim Hudson (tjh@cryptsoft.com).
License Issues
The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org.
OpenSSL License:
Copyright © 1998-2007 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1.
2.
3.
4.
5.
6.
"This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)".
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT "AS IS"' AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com).
Original SSLeay License:
Copyright © 1995-1998 Eric Young (eay@cryptsoft.com). All rights reserved.
This package is an SSL implementation written by Eric Young (eay@cryptsoft.com).
The implementation was written so as to conform with Netscapes SSL.
This library is free for commercial and non-commercial use as long as the following conditions are adhered to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
Copyright remains Eric Young's, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1.
2.
3.
"This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)".
The word `cryptographic' can be left out if the routines from the library being used are not cryptography-related.
4.
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The license and distribution terms for any publicly available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution license [including the GNU Public License].
78-3725-15 Rev. D0
