Combined Release Notes for Cisco NextPort SPE Firmware Version 6.xx


April 26, 2003

These release notes contain Cisco NextPort dial feature card (DFC) firmware version code information.

This document contains the following sections:

NextPort SPE Firmware and Dial Feature Card Overview

NextPort SPE Firmware Feature Table

New With SPE Firmware Version 6.108

New With SPE Firmware Version 6.106

New With SPE Firmware Version 6.93

New With SPE Firmware Version 6.87

New With SPE Firmware Version 6.85

New With SPE Firmware Version 6.81

Downloading NextPort SPE Firmware

Related Links

Obtaining Documentation

Obtaining Technical Assistance

NextPort SPE Firmware and Dial Feature Card Overview

NextPort SPE firmware is software that drives the DSP portion of the Cisco NextPort dial feature cards (DFCs). NextPort firmware includes NextPort SPE firmware and Cisco software code that together drive the NextPort DFC cards.

You cannot load new NextPort firmware without getting a new Cisco IOS release that includes the new code. However, you can load just the NextPort APE firmware.

NextPort SPE firmware runs on the NextPort DFC60, DFC108, and UPC324 DFCs on Cisco AS5350, AS5400, and AS5850 universal gateways, and Cisco AS5800 universal access servers. The ports on these modules can support both modem, voice, fax and digital services and can be aggregated at any of the following levels:

Slot level of the NextPort module

SPE level within the NextPort module

Individual port level

For more information about the NextPort DFC, the Cisco AS5350, AS5400, and AS5850 universal gateways, and Cisco AS5800 universal access servers, and NextPort firmware, refer to the "Related Links" section.

NextPort SPE Firmware Feature Table

Table 1 contains feature content for Version 6.108.

Table 1 Cisco NextPort Features

NextPort SPE Firmware Version
New NextPort SPE Firmware Features

6.108

Adds new features to existing 6.106 features. See the "New With SPE Firmware Version 6.108" section.

New NextPort SPE S Registers

S Registers:

S54 bit mapped register

S59 V.90 Transmit Level Setting

S75 Answer Tone Length

6.106

Adds new features to existing 6.93 features. See the "New With SPE Firmware Version 6.106" section.

New NextPort SPE S Registers

S Registers:

S64 Link Standard

S78 K56Plus

6.93

Adds features to existing Version 6.81 features. See the "New With SPE Firmware Version 6.93" section.

Voice Codecs

G.711, G.723.1 (5.3K and 6.3K), G.729a, G.729ab

DSP Voice Features

G.168 echo cancellation, up to 128 ms tail length

Transparent transcoding between A-law and mu-law encoding

Voice activity detection, silence suppression, comfort noise generation, fixed and adaptive jitter buffering

Call progress tone detection and generation—Dial tone, busy, ring-back, congestion, and re-order tones with local country variants

DTMF and MF

Voice and Fax Signaling Protocols

H.323v2

T.38 real-time fax relay at modulations V.17, V.29 and V.27ter.

DTMF Relay (out-of-band only)

6.87

Adds features to existing Version 6.85 features. See the "New With SPE Firmware Version 6.87" section.

6.85

Adds features to existing Version 6.81 features. See the "New With SPE Firmware Version 6.85" section

6.81

Initial release. See the "New With SPE Firmware Version 6.81" section.

Fax Signaling Protocols

Fax out (transmission) Group 3, standards EIA 2388 Class 2 and EIA 592

Class 2.0 at modulations of V.33, V.17, V.29, V.27ter, and V.21

ISDN Protocols

Sync mode PPP

V.110 at rates up to 38400 bps

Async V.120 at speeds of 64K and 56K for T1 and E1

Modem Modulations

V.90 standard supporting rates of 56,000 to 28,000 in 1333 bps increments

K56Flex at 56,000 to 32,000 in 2000 bps increments

ITU-T V.34 Annex 12 at 33,600 and 31,200 bps

ITU-T V.34 at 28,800, 26,400, 24,000, 21,600, 19,200, 16,800,14,400, 12,000, 9600, 7200, 4800, or 2400 bps

V.32bis at 14,400, 12,000, 9600, 7200, 4800; V.32 at 9600 and 4800; V.22bis and 2400 or 1200; V.21at 300; Bell at 103 and 300; V.22 at 1200; V.23 at 1200/75

Modem Protocols

ITU-T V.42 (including MNP 2-4 and LAPM) error correction

ITU-T V.42bis (1000 nodes) and Microcom Networking Protocol (MNP) 5 data compression

Async-mode PPP

Wireless Protocols

V.110


New With SPE Firmware Version 6.108

The following three new S registers were added to SPE firmware 6.108:

S54 bit mapped S register—By setting S54 equal to 4, the V.25 answer tones (2100 Hz) are disabled for V.22bis modulations and lower.

S75 [11] Answer Tone Length—allows you to configure the number of phase reversals of the answer tone (In units of 450ms). For V.90, K56Flex, and V.34 default duration is 4950ms. All other modulations the default duration is 3600ms.

0-255 = Number of phase reversals of the answer tone

S59 [6] V.90 Transmit Level Setting

0:-6dBm

1:-7dBm

2:-8dBm

3:-9dBm

4:-10dBm

5:-11dBm

6:-12dBm

7:-13dBm

8:-14dBm

9:-15dBm

10:-16dBm

Caveats for Release 6.108

This section describes known problems with NextPort Firmware and NextPort SPE firmware. If a workaround is not provided, a solution is being developed.

NextPort Firmware Caveats

Resolved Caveats

CSCdu02016—Some ports are unable to transmit data after reaching steady state

CSCdv73152— Characters Tx is always 0

CSCdv51292—Upload big file failed after passing traffic for some time

CSCdv75228—Unable to make outbound modem calls or use modemcap after voice call

New With SPE Firmware Version 6.106

The following new S register was added to SPE firmware 6.106:

S64 Link Standard

S78 K56Plus

Caveats for Release 6.106

This section describes known problems with NextPort Firmware and NextPort SPE firmware. If a workaround is not provided, a solution is being developed.

NextPort Firmware Caveats

Resolved Caveats

CSCdt70273—NextPort gateway services do not initiate global data on restart

NextPort SPE Firmware Caveats

Resolved Caveats

CSCds71659—Degraded CSR 97-98% for g729abr8 VAD t1/PRI with 2.1.3.92

CSCdt51654—AT%R does not show digital data service options

CSCdt57352—T38 call fails on Cisco AS5400 from australia to australia

CSCdt82268—7002 session abort on startup test

CSCdt83157—7005 session abort during 2.3.0.103 call-drop regression testing

CSCdt87502—Calltracker record does not identify a particular client

CSCdt90663—7001 session abort due csmv6 software crash (FA fail code)

Unresolved Caveats

CSCdt85338—Need the ability to set Tx power level for V.90

CSCdu12284—High number of bad frames/PPR for V.17 12K fax-relay

CSCdu30217—dtmf-relay h245-alpha/g711 with ABC digits cause switch to FAX

CSCdu40292—Dispose ip.formaterr errors with NextPort modems

CSCdu52981—V.32bis handshake failure with Cisco AS5350

New With SPE Firmware Version 6.93

The following new features were added for Version 6.93:

Voice Codecs—G.711, G.723.1 (5.3K and 6.3K), G.729a, G.729ab

DSP Voice Features

G.168 echo cancellation, up to 128 ms tail length

Transparent transcoding between A-law and mu-law encoding

Voice activity detection, silence suppression, comfort noise generation, fixed and adaptive jitter buffering

Call progress tone detection and generation—Dial tone, busy, ring-back, congestion, and re-order tones with local country variants

DTMF and MF

Voice and Fax Signaling Protocols

H.323v2

T.38 real-time fax relay at modulations V.17, V.29 and V.27ter.

DTMF Relay (out-of-band only)

Caveats for Release 6.93

This section describes known problems and resolved caveats with Cisco NextPort Firmware and Cisco NextPort SPE firmware.

NextPort Firmware Caveats

Resolved Caveats

CSCds18037 3—Power level stats are reported as positive values

Unresolved Caveats

CSCds892393—CNG tone detection is too sensitive, prone to false triggers

CSCds898544—Minimum Playout Delay value of 0 not supported for Voice/Fax

NextPort SPE Firmware Caveats

Resolved Caveats

CSCds385223—Digital Pad Compensation is Always 1.

CSCds385453—V.90 DIL (Index 51) is incorrect

CSCdr329293—S32 Signal Quality Threshold does not seem to work.

CSCdr485002—7003 EST-6-RUNTIME_ERROR caused by AT%VATZ

Unresolved Caveats

CSCdr506474—Payload Type Protocol Violation

CSCds716593—degraded CSR 97-98% for g729abr8 VAD t1/PRI with 2.1.3.92

CSCdt002073—Calls of 1 second call duration not pegged on originating gateway

CSCdt106963—SPE crashed during fax stress test

CSCdt261614—Problem with at%r missing 2 s reg. s52 + s53

CSCdt116112—70020BAD session abort seen on Tetryl

CSCdt147972—ATO from command state drops the connection, failed on all SPE versions

CSCdt186893—Cisco NextPort needs complete parity support

CSCdt197446—Need the capability of setting a configurable answer tone (S220)

CSCdt198235—AT%R is missing value 8 (v.110) for S29

CSCdt233263—Cisco NextPort AT interface hangs on call setup failure - no result code seen

CSCdt105163—Fax relay high speed modulation statistic missing

CSCdt2977 3—show spe voice summary shows multiple errors

CSCdt396564—T38INFO shows invalid FAXSTATE

CSCdt516544—AT%R does not show digital data service options

CSCdt529022—7002/7001 during 270 fax E1 R2 stress test

New With SPE Firmware Version 6.87

No new features were added in this release.

Caveats for Release 6.87

This section describes known problems with NextPort Firmware and NextPort SPE firmware. If a workaround is not provided, a solution is being developed.

NextPort Firmware Caveats

Unresolved Caveats

CSCdr89674—Generation of R2 digits are out of spec. shows -9.5 or colder

NextPort SPE Firmware Caveats

Unresolved Caveats

CSCdr41432—Outgoing FXS calls using NextPort fail because dial tone is not detected

CSCdr89657—R2 Digits Fails on-time duration variances of 50 ms and below

CSCdr89665—R2 digits not detected when twist is applied at =<50ms of on-time

CSCdr89670—R2 digits not detected below -14 with on-time duration of 50ms

New With SPE Firmware Version 6.85

There are no new features added with this release.

Caveats for Release 6.85

This section describes known problems with NextPort Firmware and NextPort SPE firmware. If a workaround is not provided, a solution is being developed.

NextPort Firmware Caveats

Unresolved Caveats

CSCdr33913—Clients do not grant fall-forward requests to CSM modem

CSCdr41432—Outgoing FXS calls using NextPort fail because dial tone is not detected

CSCdr89674—Generation of R2 digits are out of spec. shows -9.5 or colder

CSCdr91992—Poor modem performance seen with Lucent vendor

NextPort SPE Firmware Caveats

Unresolved Caveats

CSCdr72167—Channel down message immediately after a download fail

CSCdr89657—R2 Digits Fails on-time duration variances of 50 ms and below

CSCdr89665—R2 digits not detected when twist is applied at =<50ms of on-time

CSCdr89670—R2 digits not detected below -14 with on-time duration of 50ms

New With SPE Firmware Version 6.81

The following features were added in this release:

Fax Signaling Protocols

Fax out (transmission) Group 3, standards EIA 2388 Class 2 and EIA 592

Class 2.0 at modulations of V.33, V.17, V.29, V.27ter, and V.21

ISDN Protocols

Sync mode PPP

V.110 at rates up to 38400 bps

Async V.120 at speeds of 64K and 56K for T1 and E1

Modem Modulations

V.90 standard supporting rates of 56,000 to 28,000 in 1333 bps increments

K56Flex at 56,000 to 32,000 in 2000 bps increments

ITU-T V.34 Annex 12 at 33,600 and 31,200 bps

ITU-T V.34 at 28,800, 26,400, 24,000, 21,600, 19,200, 16,800,14,400, 12,000, 9600, 7200, 4800, or 2400 bps

V.32bis at 14,400, 12,000, 9600, 7200, 4800; V.32 at 9600 and 4800; V.22bis and 2400 or 1200; V.21at 300; Bell at 103 and 300; V.22 at 1200; V.23 at 1200/75

Modem Protocols

ITU-T V.42 (including MNP 2-4 and LAPM) error correction

ITU-T V.42bis (1000 nodes) and Microcom Networking Protocol (MNP) 5 data compression

Async-mode PPP

Wireless Protocols

V.110

Caveats for Release 6.81

This section describes known problems with NextPort Firmware and NextPort SPE firmware. If a workaround is not provided, a solution is being developed.

NextPort Firmware Caveats

Unresolved Caveats

CSCdr41432—Outgoing FXS calls using NextPort fail because dial tone is not detected

CSCdr45091—MF-R1 generated digits are too high at -2.5

NextPort SPE Firmware Caveats

Unresolved Caveats

CSCdr21930—R2 digits are not detected below -33

CSCdr22868—MF-R1 Taiwan fails absolute power detection at -4 and higher

CSCdr33913—Clients do not grant fall-forward requests to CSM modem

CSCdr34724—S23/S24 (LAP-M & MNP Enable/Disable) not working

CSCdr42083—Extra AT command characters, and entering ato disconnects the call

CSCdr42572—Session aborts at beta site 0x70020BAD

CSCdr46673—Vendor TA gets garbled characters with show commands

Finding Software Bugs

If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any Cisco software release. You can reach Bug Navigator II on CCO at
Service & Support: Online Technical Support: Software Bug Toolkit
Or at
http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl

Downloading NextPort SPE Firmware

NextPort SPE firmware is downloaded using the spe command. The spe command allows firmware to be downloaded to the service processing element, or SPE.

SPE Download Tasks

To download modem firmware, follow these steps, beginning by entering the spe command:


Step 1 Enter the spe command and subcommands, one configuration command per line:

Router# configure terminal
Router(config)# spe slot/spe_begin slot/spe_end
Router(config-spe)# firmware location system:/ucode/np_spe_firmware1
Router(config-spe)# ^Z

For example, the following display shows a Cisco AS5400 SPE download to all modems in Slot 1 (that is, all modems on a feature card containing 18 6-port modem modules). The modem code resides in the Flash memory, and the modem code filename is dfc108-firmware.6.81.

Router(config)# spe 1/0 1/17
Router(config-spe)# firmware location flash:dfc108-firmware.6.81

Step 2 Copy the configuration from running RAM into NVRAM:

Router# copy running-config startup-config

Download occurs when the modems become available and shows the SPE firmware upgrade option defined (default: busyout). The spe command generates NVRAM modem download and configuration file entries.


Note If the configuration is not saved as described above, download of the firmware specified with the spe command will not occur after the next reboot.


For detailed information on the spe command, refer to the Cisco document,
SPE and Firmware Download Enhancements.


Related Links

For further information about Cisco NextPort Firmware and Cisco IOS Software, refer to the following related sources:

AT Command Set and Register Summary for NextPort Universal Digital Signal Processor Platforms

Caveats, Cisco IOS Release 12.2.

Cisco AS5350 documentation index

Cisco AS5400 documentation index

Cisco AS5800 documentation index

Cisco AS5850 documentation index

Configuration Guides and Command References, Cisco IOS Release 12.2

Managing Port Services on the Cisco AS5400 Universal Access Server

NextPort SPE Firmware Release Notes index


Note You must have an account with Cisco.com to access the following link.


Software Download

SPE and Firmware Download Enhancements

Obtaining Documentation

The following sections explain how to obtain documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at the following URL:

http://www.cisco.com

Translated documentation is available at the following URL:

http://www.cisco.com/public/countries_languages.shtml

Documentation CD-ROM

Cisco documentation and additional literature are available in a Cisco Documentation CD-ROM package, which is shipped with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or through an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

Registered Cisco Direct Customers can order Cisco product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, elsewhere in North America, by calling 800 553-NETS (6387).

Documentation Feedback

If you are reading Cisco product documentation on Cisco.com, you can submit technical comments electronically. Click Leave Feedback at the bottom of the Cisco Documentation home page. After you complete the form, print it out and fax it to Cisco at 408 527-0730.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:

Cisco Systems
Attn: Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools by using the Cisco Technical Assistance Center (TAC) Web Site. Cisco.com registered users have complete access to the technical support resources on the Cisco TAC Web Site.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information, networking solutions, services, programs, and resources at any time, from anywhere in the world.

Cisco.com is a highly integrated Internet application and a powerful, easy-to-use tool that provides a broad range of features and services to help you to

Streamline business processes and improve productivity

Resolve technical issues with online support

Download and test software packages

Order Cisco learning materials and merchandise

Register for online skill assessment, training, and certification programs

You can self-register on Cisco.com to obtain customized information and service. To access Cisco.com, go to the following URL:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC is available to all customers who need technical assistance with a Cisco product, technology, or solution. Two types of support are available through the Cisco TAC: the Cisco TAC Web Site and the Cisco TAC Escalation Center.

Inquiries to Cisco TAC are categorized according to the urgency of the issue:

Priority level 4 (P4)—You need information or assistance concerning Cisco product capabilities, product installation, or basic product configuration.

Priority level 3 (P3)—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

Priority level 2 (P2)—Your production network is severely degraded, affecting significant aspects of business operations. No workaround is available.

Priority level 1 (P1)—Your production network is down, and a critical impact to business operations will occur if service is not restored quickly. No workaround is available.

Which Cisco TAC resource you choose is based on the priority of the problem and the conditions of service contracts, when applicable.

Cisco TAC Web Site

The Cisco TAC Web Site allows you to resolve P3 and P4 issues yourself, saving both cost and time. The site provides around-the-clock access to online tools, knowledge bases, and software. To access the Cisco TAC Web Site, go to the following URL:

http://www.cisco.com/tac

All customers, partners, and resellers who have a valid Cisco services contract have complete access to the technical support resources on the Cisco TAC Web Site. The Cisco TAC Web Site requires a Cisco.com login ID and password. If you have a valid service contract but do not have a login ID or password, go to the following URL to register:

http://www.cisco.com/register/

If you cannot resolve your technical issues by using the Cisco TAC Web Site, and you are a Cisco.com registered user, you can open a case online by using the TAC Case Open tool at the following URL:

http://www.cisco.com/tac/caseopen

If you have Internet access, it is recommended that you open P3 and P4 cases through the Cisco TAC Web Site.

Cisco TAC Escalation Center

The Cisco TAC Escalation Center addresses issues that are classified as priority level 1 or priority level 2; these classifications are assigned when severe network degradation significantly impacts business operations. When you contact the TAC Escalation Center with a P1 or P2 problem, a Cisco TAC engineer will automatically open a case.

To obtain a directory of toll-free Cisco TAC telephone numbers for your country, go to the following URL:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

Before calling, please check with your network operations center to determine the level of Cisco support services to which your company is entitled; for example, SMARTnet, SMARTnet Onsite, or Network Supported Accounts (NSA). In addition, please have available your service agreement number and your product serial number.
