Release Notes for Cisco MICA Portware Version 2.9.1.0 on Cisco AS5300, Cisco AS5800, Cisco 3600, and Cisco 3700 Series


November 25, 2002

These release notes describe Cisco MICA Portware Version  2.9.1.0 on Cisco AS5300 universal access servers with Cisco IOS Software Release 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher. This is a V.92 initial release.

These release notes describe the following topics:

New Features for Version 2.9.1.0

Compatibility Requirements

Known Problems with Cisco MICA Version 2.9.1.0

Problems Resolved with Cisco MICA Version 2.9.1.0

Downloading Portware Modem Code

Related Links

Obtaining Documentation

Obtaining Technical Assistance

New Features for Version 2.9.1.0

Cisco MICA Portware Version 2.9.1.0 is a feature release that adds the following new features to existing Version 2.7.3.0 functionality:

V.44 Lempel-Ziv-Jeff-Heath (LZJH) data compression algorithm—V.44 LZJH is a new compression standard based on Lempel-Ziv that uses a new string-matching algorithm that increases upload and download speeds to make Internet access and Web browsing faster. V.44 is enabled by default.
Refer to the V.44 LZJH Compression for Cisco AS5300 Universal Access Servers feature module for more information.

V.92 Modem on Hold—V.92 Modem on Hold allows a dial-in customer to suspend a modem session to answer an incoming voice call or to place an outgoing call while engaged in a modem session. V.92 Modem on Hold is disabled by default. Refer to the
V.92 Modem on Hold for Cisco AS5300 Universal Access Servers feature module for more information.

V.92 Quick Connect—V.92 Quick Connect speeds up the client-to-server startup negotiation, reducing the overall Internet service provider (ISP) connect time by avoiding some of the initial signal handshaking. V.92 Quick Connect is enabled by default. Refer to the
V.92 Quick Connect for Cisco AS5300 Universal Access Servers feature module for more information.

Compatibility Requirements

Cisco MICA Portware Version 2.9.1.0 is supported only with Cisco IOS Release 12.2(2)XA, 12.2(2)XB, 12.2(11)T, or higher releases. For Cisco IOS software release compatibility information, refer to the Compatibility Matrixes for Cisco AS5x00, Cisco 3600, and Cisco 3700 Platforms with Cisco MICA 6-Port and 12-Port Modem Module Portware.

The Cisco 3600 and Cisco 3700 series are supported in Cisco MICA Portware Version 2.9.1.0 through Version 2.9.4.0, but only Version 2.9.1.0 contains the bundled firmware for the Cisco 3600 and Cisco 3700 series.

Supported Platforms

Cisco MICA Portware Version 2.9.1.0 is supported on the following platforms:

Cisco 3600 series

Cisco 3700 series

Cisco AS5300

Cisco AS5800


Note Many client modems used in Europe are known to have problems with the Modem on Hold feature. The vendors are aware of the issue and are working to correct it. If you are having trouble with the Modem on Hold feature in Europe, it is suggested that the customer contact the client modem vendor to verify that the modem complies with the telephony signaling for call waiting, caller ID, and 3-way calling in their particular country.



Note For a list of modems tested with Cisco MICA portware, use the following link:
http://www.cisco.com/warp/public/cc/pd/as/as5800/prodlit/modem_rg.htm


Portware Features

Table 1 Feature Content by Modem Version

Portware Version
Feature Content

2.9.1.0

Feature release. New features added to existing 2.7.3.0 features. Supports Cisco IOS Software Releases 12.2(2)XA, 12.2(2)XB, 12.2(11)T, and higher1 .

V.92 Modem on Hold

V.92 Quick Connect

V.44 LZJH Data Compression

2.7.3.0

Maintenance release. New features added to existing 2.7.2.0 features. Cisco IOS Software Release 12.1(5) support.

V.110 blind connect feature for compatibility with nonstandard clients (CSCdr39887), which is enabled by bit 9 in S-register S54.

New S-registers:

S71 and S72 (Decouple maximum symbol rates for V.90 and V.34)

S64, finer granularity in modulation selection (CSCdm94337)

2.7.2.0

Maintenance release. New features added to existing 2.7.1.0 features. Cisco IOS Software Release 12.1(5) support.

W, X, and (,) dial modifiers

Call Tracker

Support for IPDC protocol for call control signaling

Additional V.110 speeds (CSCdm43898): 38,400, 28,800, 24,000, 12,000 bps

Additional dial modifiers (CSCdk10292)

Decoupled V.90 power levels for S-registers S39 and S59 (CSCdm52396)

New values for S54 general capabilities register

Signal quality threshold changes

Parity for error controlled connections (CSCdj92333)

Added client modems for V.90 Digital Impariment Learning (DIL) sequence detection

2.7.1.0

Feature release. New features added to existing Version 2.6.2.0 features.

V.110 ISDN rate specification

spe download command

Cisco AS5800 supported on Cisco IOS Release 12.0(5)T only

Modulation

ITU-T Recommendation Q.931 V.110 Bearer Rates:
1200 bps, 2400 bps, 4800 bps, 7200 bps, 9600 bps, 14,400 bps, 19,200 bps, 38,400 bps.

ITU-T Recommendation Q.931 Intermediate Rates:
8k, 16k, 32k, and 64k bps.

2.6.2.0

Maintenance release. New features added to existing Version 2.6.1.0 features.

Signaling

Resource Pool Management (RPM):

Ring-back tone generation.

Port Management

Improved port management interfacing for acquiring modem/port data for AAA records.

2.6.1.0

SS7 support added to Version 2.5.1.0 features.

Signaling

Continuity Testing (COT) of DSO channels in SS7 networks.

2.5.1.0

V.90 and RFC-2217 dialout support for fax/data.

Note The Cisco DialOut Utility (CDU) is no longer supported. Refer to the
Cisco DialOut Utility End of Sale/Shipping bulletin and the
Sample NAS Configurations for Cisco DialOut Utility document for information.

Modulation

V.90 standard supporting rates of 56,000 to 28,000 in 1333.3-bps increments.

Fax out (transmission) Group 3, standards EIA 2388 Class 2 and EIA 592 Class 2.0, at modulations V.33, V.29, V.27ter, V.21, and V.17.

2.3.1.0

R1 support plus K56flex maintenance.

Signaling

R1 noncompelled and semicompelled.

2.2.3.0

K56flex support.

Modulation

Rockwell K56flex at 56,000 to 32,000 in 2000 bps increments.

2.0.1.7

Initial V.34+ release.

Modulation

ITU-T V.34 Annex 12 at 33600 and 31200 bps.

ITU-T V.34 at 26,400, 24,000, 21,600, 19,200, 16,800, 14,400, 12,000, 9600, 7200, 4800, or 2400 bps.

V.32bis = 14400, 12000, 9600, 7200, 4800; V.32 = 9600, 4800; V.22bis = 2400, 1200; V.21 = 300; Bell212A = 1200, Bell103 = 300; V.22 = 1200; V.23 = 1200/75.

Signaling

MF

DTMF

R2 compelled, noncompelled, and semicompelled.

Protocols

ITU-T V.42 (including MNP 2-4 and LAPM) Error Correction.

ITU-T V.42bis (1K nodes) and MNP 5 Data Compression.

Modem Standard

ITU-T V. 25—Automatic calling or answering equipment on dialup lines. This standard includes the procedures for disabling echo control devices for calls that are established manually and automatically.

1 Support for V.92 and V.44 on the Cisco 36x0 and Cisco 37x0 has been added with Cisco IOS Release 12.2(11)YT. Cisco MICA Version 2.9.1.0 is the bundled portware with the Cisco IOS software.


Known Problems with Cisco MICA Version 2.9.1.0

This section describes known problems with portware Version 2.9.1.0. If a workaround is not provided, a solution is being developed.

Bugs

CSCdt39317—Specific PCMCIA client modem falls back to V.34 from V.90.

CSCds50294—Modem occasionally goes into sudden connect failure mode.

CSCdt45194—FTP transfer stops passing data when transferring 2x10 test file to a specific client modem.

CSCdu04829—Specific client disconnects in trainup.

CSCdu25569—V.110 flow control may corrupt user data.

CSCdu24349—Dial-out to a specific vendor modem on E1 line type yields poor CSR.

CSCdt68962—On rare occasions a Hex is marked bad without TIMER_ASSERT failure.

CSCdt68782—On rare occasions a Hex is marked bad with TIMER_ASSERT failure.

Problems Resolved with Cisco MICA Version 2.9.1.0

None.

If you have an account on Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in to Cisco.com and click Service & Support: Software Center: Cisco IOS Software: BUG TOOLKIT. Another option is to go to

http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.

Downloading Portware Modem Code

Cisco supports portware configuration using service processing element (SPE) configuration commands and modem-pool commands. The spe command allows portware to be downloaded to the SPE.

SPE Download Tasks

To download modem portware/firmware using the spe command, enter the spe command, one configuration command per line.


Step 1 Enter the spe command and subcommands, one configuration command per line:

Router# configure terminal
Router(config)# spe <slot>/<spe_begin> <slot>/<spe_end>
Router(config-spe)# firmware location system:/ucode/mica_port_firmware
Router(config-spe)# ^Z

For example, the following display shows a Cisco AS5300 SPE download to all modems in Slot 1 (that is, all modems on a feature card containing ten 6-port modem modules). The modem code resides in the Flash memory, and the modem code filename is mica-modem-portware.2.9.1.0.bin.

Router(config)# spe 1/0 1/9
Router(config-spe)# firmware location flash:mica-modem-portware.2.9.1.0.bin

Step 2 Copy the configuration from NVRAM into running RAM:

Router# copy running-config startup-config

Download occurs when the modems become available and shows the SPE firmware upgrade option defined (default: busyout). The spe command generates NVRAM modem download and configuration file entries.


Note If the configuration is not saved as described above, download of the portware specified with the spe command will not occur after the next reboot.


For detailed information on the spe command, go to the following link:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios120/120newft/120t/120t7/spe1206t.htm


Modem-Pool Download Tasks

If you have an account on Cisco.com, you can download modem portware/firmware using FTP if you are using Cisco IOS Software Release 12.0(5)T or earlier at the following link:

http://www.cisco.com/kobayashi/sw-center/sw-access.shtml

Related Links

For further information about Cisco MICA portware and Cisco IOS software, see the following related sources:

Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 12.2 XA

Release Notes for Cisco AS5300 Universal Access Servers for Cisco IOS Release 12.2 XB

Cisco AS5x00 Cisco MICA 6-Port and 12-Port Modem Module Portware/Cisco IOS Software Compatibility Matrixes

Cisco MICA Modem Dial Modifiers for Cisco AS5300, Cisco AS5400, and AS5800 Universal Access Servers

Cisco IOS Release 12.2 Configuration Guides and Command References

Cisco IOS Release 12.2 Master Indexes

Cisco IOS Dial Services Command Reference for Cisco IOS Software Release 12.2

AT Command Set and Register Summary for Cisco MICA 6-Port Modules

Modem Management Operations

SPE and Firmware Download Enhancements

Cisco AS5300 access servers, Appendix A, "Managing Modems," and Appendix B, "Rom Monitor," in the Cisco AS5300 Universal Access Server Software Configuration Guide

Modem Management Commands


Note The Cisco DialOut Utility (CDU) is no longer supported. Refer to the Cisco DialOut Utility End of Sale/Shipping bulletin and the Sample NAS Configurations for Cisco DialOut Utility document for information.
