Release Notes for Cisco AS5800 Universal Access Servers for Cisco IOS Release 12.2 XS

Table Of Contents

Release Notes for Cisco AS5800 Universal Access Servers for Cisco IOS Release 12.2 XS

Contents

Introduction

System Requirements

Memory Requirements

Supported Hardware

Determining the Software Version

Upgrading to a New Software Release

Microcode and Modem Code Software

Feature Set Tables

New and Changed Information

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS2

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS1

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS

MIBs

Current MIBs

Caveats for Cisco IOS Release 12.2(1) XS

Open Caveats—Cisco IOS Release 12.2(1) XS2

Resolved Caveats—Cisco IOS Release 12.2(1) XS2

Open Caveats—Cisco IOS Release 12.2(1) XS1

Resolved Caveats—Cisco IOS Release 12.2(1) XS1

Open Caveats—Cisco IOS Release 12.2(1) XS

Resolved Caveats—Cisco IOS Release 12.2(1) XS

Related Documentation

Release-Specific Documents

Platform-Specific Documents

Feature Modules

Feature Navigator

Cisco IOS Software Documentation Set

Documentation Modules

Cisco IOS Release 12.2 Documentation Set Contents

Obtaining Documentation

World Wide Web

Documentation CD-ROM

Ordering Documentation

Documentation Feedback

Obtaining Technical Assistance

Cisco.com

Technical Assistance Center

Contacting TAC by Using the Cisco TAC Website

Contacting TAC by Telephone


Release Notes for Cisco AS5800 Universal Access Servers for Cisco IOS Release 12.2 XS


February 17, 2002

Cisco IOS Release 12.2(1) XS2

OL-1572-01 Rev. E0

These release notes for the Cisco AS5800 universal access servers describe the enhancements provided in Cisco IOS Release 12.2(1) XS2. These release notes are updated as needed.

For a list of the software caveats that apply to Cisco IOS Release 12.2(1) XS2, see the "Caveats for Cisco IOS Release 12.2(1) XS" section and Caveats for Cisco IOS Release 12.2. The caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.

Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.2 located on Cisco.com and the Documentation CD-ROM.

Contents

These release notes describe the following topics:

Introduction

System Requirements

New and Changed Information

MIBs

Caveats for Cisco IOS Release 12.2(1) XS

Related Documentation

Obtaining Documentation

Obtaining Technical Assistance

Introduction

The Cisco AS5800 access server is a high-density, Integrated Services Digital Network (ISDN), and modem Wide Area Network (WAN) aggregation systems that provide digital and analog call termination. They are intended to be used as a service provider dial point-of-presence (POP) or centralized enterprise dial gateway. The Cisco AS5800 consists of a dial shelf and one or two router shelves:

The Cisco DS5814 (dial shelf) has 14 slots and can support 1 or 2 dial shelf controller cards and up to 12 feature cards to provide full analog modem, and ISDN coverage. Analog calls are terminated by a feature card that is loaded with integrated modems.

ISDN calls are terminated onboard the trunk card on High-Level Data Link Control (HDLC) controllers. The E1 trunk, T1 trunk, and the CT3 trunk cards include channel service units (CSUs) and have either 12 E1 ports, 12 T1 ports, or 28 T1 ports (within the CT3 trunk) that can operate as Primary Rate Interfaces (PRIs), inter-machine trunks (IMTs), or channelized interfaces in any combination. The specific trunk card limitations are described in Table 2, Part 1.


Note T1 and E1 cards are not supported in the same box.


The Cisco RS7206VXR (router shelf) contains a network processing engine, an I/O controller, and the egress interfaces, such as High-Speed Serial Interface (HSSI), Fast Ethernet (FE), Gigabit Ethernet (GE), and Asynchronous Transfer Mode (ATM), and supports either 280W AC-input or 280W DC-input redundant power. The router shelf also may contain one or two dial shelf interconnect port adapters each with a single RJ-45 receptacle, which is used to connect the router shelf to the Cisco 5814 dial shelf. The interconnect port adapter connects directly to the dial shelf controller card on the dial shelf via a Cisco-proprietary cable, customized with jack screws to secure the connection. You must use this specially designed cable that ships with your interconnect port adapter. Each router shelf can only be connected to one dial shelf controller card.If the dial shelf configured in split mode, it must be connected to two separate router shelves.


Note The router shelf is only supported for routing data to and from the dial shelf. The router should not be used with multiple port adapter interfaces to route LAN traffic between multiple networks.


The AC-input power shelf is an optional component of the Cisco AS5800 universal access servers and is used to convert AC-input power into DC-output power for the DC-powered Cisco 5814 dial shelf. The AC-input power shelf contains two AC-input power supplies.

The AC-input to DC-output connection supplies -48V DC-output power to the dial shelf power entry modules (PEMs). The PEMs receive the -48V and transmit power to the filter module. Power flows through the filter module to the backplane, where it is distributed to the dial shelf controller card(s) and feature cards.

The AC-input power shelf includes two 2,000 W, AC-input power supplies that plug into a common power backplane in the AC-input power shelf. A single AC-input power supply is capable of powering a fully configured Cisco 5814 dial shelf. The second power supply provides full redundancy.

For information on new features and Cisco IOS commands supported by Cisco IOS Release 12.2(1) XS2, see the "New and Changed Information" section and the "Related Documentation" section.

System Requirements

This section describes the system requirements for Cisco IOS Release 12.2 and includes the following sections:

Memory Requirements

Supported Hardware

Determining the Software Version

Determining the Software Version

Upgrading to a New Software Release

Microcode and Modem Code Software

Feature Set Tables

Memory Requirements

Table 1 Memory Requirements for the Cisco AS5800 Universal Access Servers

System
Components
Feature Set
Image Name
Software Image
Flash
Memory
Required
DRAM
Memory Required
Runs
From
Cisco AS5800

IP Standard

IP Plus

c5800-p4-mz

16 MB

128 MB for NPE-200

256 MB for NPE-300

RAM

Dial Shelf: Cisco 5814

IP Plus

dsc-c5800-mz

8 MB

32 MB1

RAM

Cisco AS5800

Service Provider Standard

Service Provider IPSec 56

c5800-k8p4-mz

16 MB

128 MB for NPE-200

256 MB for NPE-300

RAM

1 Cisco IOS Release 12.2(1) XS2 may be used with the older RS7206 (NPE-based) router shelf as long as the shelf has 128 M of DRAM installed.


Supported Hardware

Cisco IOS Release 12.2 supports the Cisco AS5800 universal access servers:

Cisco DS5814

Cisco RS7206

Cisco RS7206 VXR

For detailed descriptions of the new hardware features, see the "New and Changed Information" section.

Table 2, Part 1 Supported Hardware for the Cisco AS5800 Universal Access Servers

Interfaces, Cards, Options, and Support
Description
Interfaces

12-port T1 or E1 termination card

1- port channelized T3 (CT3) termination card

Modem Cards

72-port modem card (HMM)1

144-port modem card (DMM)2

324-port modem card (UPC)

Dial Shelf

DS5814 Dial Shelf

Dial Shelf Controller (DSC) card

Optional AC-input Power Shelves

Two AC-input power supplies

Router Shelf Support

RS7206VXR (NPE-300 based) Router Shelf

RS7206 (NPE-200 based) Router Shelf

With any Cisco AS5800 software image, the maximum hardware configuration with an RS7206 is one CT3 or two T1/E1 trunk cards and three UPCs, five DMMs, or 10 HMMs for a maximum of 28, 24 T1 / 24 E1 controllers and 720 modems.

If a larger configuration is desired, a second RS7206 router shelf can be configured in split-shelf mode, or a single RS7206 VXR may be used to support up to 1344 modem sessions. Configurations above 1344 modem sessions require two RS7206VXR router shelves in split-shelf mode.

1 72-port modem card requires 32M DRAM.

2 144-port modem card requires 64M DRAM.


Table 2, Part 2 Supported Hardware for the Cisco AS5800 Universal Access Servers

Router Shelf
Port Adapter
Description
RS7206 Router Shelf

PA-100VG

Single-Port 100 VG Port Adapter

PA-12E/2FE

Dual-Wide Ethernet-switch Port Adapter

PA-1C-E

1-Port ESCON Channel Port Adapter

PA-2CE1/PRI-120

2-Port Channelized E1/PRI Port Adapter, 120 ohm

PA-2CE1/PRI-75

2-Port Channelized E1/PRI Port Adapter, 75 ohm

PA-2CT1/PRI

2-Port Channelized T1/PRI Port Adapter

PA-2E3

2-Port E3 Serial Port Adapter with E3 DSU

PA-2FEISL-FX

2-Port Fast Ethernet/ISL 100BaseTx Port Adapter

PA-2FEISL-TX

2-Port Fast Ethernet/ISL 100BaseFx Port Adapter

PA-2H

Port Adapter, 2-Port HSSI

PA-4B-U

4-Port BRI Port Adapter, U Interface

PA-4E

Port Adapter, 4-Port Ethernet,10BT

PA-4R

Port Adapter, 4-Port Token Ring (Older Hermon Based)

PA-4R-DTR

Port Adapter, 4-Port Token Ring (Hawkeye Based)

PA-4R-FDX

Port Adapter, 4 Port Token Ring 4/16Mbps, Full Duplex

RS7206 Router Shelf (Continued)

PA-4T+

Port Adapter, 4-Port Serial,5IN1

PA-5EFL

Port Adapter, 5-Port Ethernet,10FL

PA-8B-S/T

8-Port BRI Port Adapter, S/T Interface

PA-8E

Port Adapter, 8-Port Ethernet,10BT

PA-8T-232

Port Adapter, 8-Port Serial,232

PA-8T-V35

Port Adapter, 8-Port Serial,V.35

PA-8T-X21

Port Adapter, 8-Port Serial,X.21

PA-A1-OC3MM

1-Port ATM OC3 Multi-Mode Port Adapter

PA-A1-OC3SM

1-Port ATM OC3 Single Mode Intermediate Reach Port Adapter

PA-A2-4E1XC-E3ATM

CES Port Adapter E3/E1 120 ohms

PA-A2-4E1XC-OC3SM

CES OC3 Port Adapter 4E1 Ports 120 ohms

PA-A2-4T1C-OC3SM

ATM CES Port Adapter, 4T1 CES Ports and 1 OC3 ATM SM Port

PA-A2-4T1C-T3ATM

ATM CES Port Adapter, 4T1 CES Ports and 1 T3 ATM Port

PA-A3-E3

1-Port ATM Enhanced E3 Port Adapter

PA-A3-OC3MM

1-Port ATM Enhanced OC3c/STM1 Multi-Mode

PA-A3-OC3SMI

1-Port ATM Enhanced OC3c/STM1 Single Mode

PA-A3-OC3SML

1-Port ATM Enhanced OC3c/STM1 Single Mode

PA-A3-T3

1-Port ATM Enhanced DS3 Port Adapter

PA-CT3/4T1

Channelized DS3 Port Adapter with 4 T1

PA-E3

1-Port E3 Serial Port Adapter with E3 DSU

PA-F/FD-MM

Port Adapter,1-Port FDDI Full Duplex Multi-Mode

PA-F/FD-SM

Port Adapter,1-Port FDDI Full Duplex Single-Mode

PA-FE-FX

Port Adapter,1-Port FE, 100FX

PA-FE-TX

Port Adapter,1-Port FE,100TX

PA-F-MM

Port Adapter,1-Port FDDI Multi-Mode

PA-F-SM

Port Adapter,1-Port FDDI Single Mode

PA-H

Port Adapter,1-Port HSSI

PA-POS-OC3MM

1-Port Packet/SONET OC3c/STM1 Multi-Mode Port Adapter

PA-POS-OC3SMI

1-Port Packet/SONET OC3c/STM1 Single Mode (IR) Port Adapter

PA-POS-OC3SML

1-Port Packet/SONET OC3c/STM1 Single Mode (LR) Port Adapter

PA-T3

1-Port T3 Serial Port Adapter with T3 DSUs

PA-T3+

1-Port T3 Serial Port Adapter Enhanced

SA-COMP/1

Service Adapter, Compression (64 VCs Stac)

SA-COMP/4

Service Adapter, Compression (256 VCs Stac)

RS7206VXR Router Shelf

PA-100VG

Single Port 100VG Port Adapter

PA-12E/2FE

Dual-Wide Ethernet-Switch Port Adapter

PA-1C-E

1-Port ESCON Channel Port Adapter

PA-2E3

2-Port E3 Serial Port Adapter with E3 DSU

PA-2FEISL-FX

2-Port Fast Ethernet/ISL 100BaseTx Port Adapter

PA-2FEISL-TX

2-Port Fast Ethernet/ISL 100BaseFx Port Adapter

PA-2H

Port Adapter, 2-Port HSSI

PA-4B-U

4-Port BRI Port Adapter, U Interface

PA-4E

Port Adapter, 4-Port Ethernet,10BT

PA-4R-DTR

Port Adapter, 4-Port Token Ring (Hawkeye Based)

PA-4T+

Port Adapter, 4-Port Serial,5in1

PA-5EFL

Port Adapter, 5-Port Ethernet,10FL

PA-8B-S/T

8-Port BRI Port Adapter, S/T Interface

PA-8E

Port Adapter, 8-Port Ethernet,10BT

PA-8T-232

Port Adapter, 8-Port Serial,232

PA-8T-V35

Port Adapter, 8-Port Serial,V.35

PA-8T-X21

Port Adapter, 8-Port Serial,X.21

PA-A1-OC3MM

1-Port ATM OC3 Multi-Mode Port Adapter

PA-A1-OC3SM

1-Port ATM OC3 Single Mode Intermediate Reach Port Adapter

PA-A2-4E1XC-E3ATM

CES Port Adapter E3/E1 120 ohms

PA-A2-4E1XC-OC3SM

CES OC3 Port Adapter 4E1 Ports 120 ohms

PA-A2-4T1C-OC3SM

ATM CES Port Adapter, 4T1 CES Ports and 1 OC3 ATM SM Port

PA-A2-4T1C-T3ATM

ATM CES Port Adapter, 4T1 CES Ports and 1 T3 ATM Port

PA-A3-E3

1-Port ATM Enhanced E3 Port Adapter

PA-A3-OC3MM

1-Port ATM Enhanced OC3c/STM1 Multi-Mode

PA-A3-OC3SMI

1-Port ATM Enhanced OC3c/STM1 Single Mode

PA-A3-OC3SML

1-Port ATM Enhanced OC3c/STM1 Single Mode

PA-A3-T3

1-Port ATM Enhanced DS3 Port Adapter

PA-E3

1-Port E3 Serial Port Adapter with E3 DSU

PA-FE-FX

Port Adapter, 1-Port FE, 100FX

PA-FE-TX

Port Adapter, 1-Port FE,100TX

PA-GE

One-Port Gigabit Ethernet PA for 7200VXR

PA-H

Port Adapter, 1-Port HSSI

PA-MC-8E1/120

8-Port Multichannel E1 Port Adapter

PA-POS-OC3MM

1-Port Packet/SONET OC3c/STM1 Multi-Mode Port Adapter

PA-POS-OC3SMI

1-Port Packet/SONET OC3c/STM1 Single Mode (IR) Port Adapter

PA-POS-OC3SML

1-Port Packet/SONET OC3c/STM1 Single Mode (LR) Port Adapter

RS7206VXR Router Shelf (Continued)

PA-T3

1-Port T3 Serial Port Adapter with T3 DSUs

PA-T3+

1-Port T3 Serial Port Adapter Enhanced


Determining the Software Version

For general information about upgrading to a new software release, refer to Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:

http://www.cisco.com/warp/public/130/upgrade_index.shtml

For specific information about upgrading AS5800 IOS software, modem and firmware upgrades, and split dial shelf, refer to the "Provisioning" chapter in the Cisco AS5800 Operations, Administration, Maintenance, and Provisioning Guide (OAM&P) at:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5800/sw_conf/58_oamp/prov.htm

Upgrading to a New Software Release

For general information about upgrading to a new software release, refer to Upgrading the Cisco IOS Software Release in Cisco Routers and Modems located at:

http://www.cisco.com/warp/public/130/upgrade_index.shtml

Microcode and Modem Code Software

Microcode software images are bundled with the system software image—with the exception of the Channel Interface Processor (CIP) microcode (all system software images). Bundling eliminates the need to store separate microcode images. When the router starts, the system software unpacks the microcode software bundle and loads the proper software on all the interface processor boards.

You could have received a later version of modem code than the one bundled with the Cisco IOS software. The modem code in Flash memory is mapped to the modems. Unless you fully understand how Cisco IOS software uses modem code, it is important to keep the factory configuration.

The modem code release notes are on Cisco.com and the Documentation CD-ROM.

On Cisco.com at:

Technical Documents: Access Servers and Access Routers: Access Servers: Cisco AS5800: Configuration Documents for Cisco AS5800: Port Firmware

On the Documentation CD-ROM at:

Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5800: Configuration Documents for Cisco AS5800: Port Firmware

To obtain the latest Cisco IOS software release compatible with Cisco MICA portware, refer to the Cisco AS5x00 MICA 6-Port and 12-Port Modem Module Portware/Cisco IOS Software Compatibility Matrixes at http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/5300/sw_conf/sw_ports/compmat/mca12prt.htm.

Feature Set Tables

The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features.

Cisco IOS Release 12.2(1) XS2 supports the same feature sets as Cisco IOS Release 12.2(1), but Cisco IOS Release 12.2(1) XS2 can include new features supported by the Cisco AS5800 universal access servers.


Caution Cisco IOS images with strong encryption (including, but not limited to, 168-bit Triple Data Encryption Standard [3DES] data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders may be denied or subject to delay because of United States government regulations. When applicable, purchaser and user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.

Table 3 lists the features and feature sets supported by the Cisco AS5800 universal access servers in Cisco IOS Release 12.2(1) XS2 and uses the following conventions:

Yes—The feature is supported in the software image.

No—The feature is not supported in the software image.


Note This table might not be cumulative or list all the features in each image. If you have a Cisco.com login account, you can find image and release information regarding features prior to Cisco IOS Release 12.2(1) by using the Feature Navigator tool at http://www.cisco.com/go/fn.


Table 3 Feature List by Feature Set for the Cisco AS5800

Features
Software Images by Feature Set
IP Plus
IPSec 56

Dial

AAA Session MIB

Yes

Yes

Deutsche Telekom Phase I

Yes

Yes

Dial Modifiers

Yes

Yes

Dialer DNIS-Group Range

Yes

Yes

L2TP Tunnel Management Enhancements

Yes

Yes

Monitoring Resource Availability on
Cisco AS5300 Universal Access Servers

Yes

Yes

Monitoring Resource Availability on
Cisco AS5x00 Universal Access Servers

Yes

Yes

Network Side ISDN PRI Signaling, Trunking, and Switching

Yes

Yes

Preauthentication with ISDN PRI and Channel-Associated Signaling

Yes

Yes

TCP Clear Performance Optimization

Yes

Yes



File or System Management

AutoInstall Using DHCP for LAN Interfaces

Yes

Yes

Circuit Interface Identification MIB

Yes

Yes

Event MIB

Yes

Yes

Individual SNMP Trap Support

Yes

Yes

Interface Index Persistence

Yes

Yes

Parser Cache

Yes

Yes

IP

NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)

Yes

Yes

Security

AAA Server Group Deadtimer

Yes

Yes

AAA Server Group Enhancements

Yes

Yes

Cisco AAA Server MIB and Additional Enhancements for the Cisco AS5300 and Cisco AS5800

Yes

Yes

Preauthentication with ISDN PRI

Yes

Yes

Radius Tunnel Attribute Extensions

Yes

Yes

Sticky IP

Yes

Yes


New and Changed Information

The following sections list the new hardware and software features supported by the Cisco AS5800 universal access servers for Cisco IOS Release 12.2(1) XS2.

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS2

There are no new hardware and software features supported by the Cisco AS5800 universal access servers for Cisco IOS Release 12.2(1) XS2.

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS1

There are no new hardware and software features supported by the Cisco AS5800 universal access servers for Cisco IOS Release 12.2(1) XS1.

New Hardware and Software Features in Cisco IOS Release 12.2(1) XS

There are no new hardware and software features supported by the Cisco AS5800 universal access servers for Cisco IOS Release 12.2(1) XS.

MIBs

Current MIBs

To download MIB modules, go to the Cisco MIB website on Cisco.com at http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml.

The Cisco AS5800 universal access servers support the following MIBs:

AAA-SESSION-MIB

AAA-SERVER-MIB

ATM-MIB

CALL-TRACKER-MIB

CISCO-ATM2-MIB

CISCO-ATM-IF-PHYS-MIB

CISCO-ATM-SIG-DIAG-MIB

CISCO-BULK-FILE-MIB

CISCO-C8500-REDUNDANCY-MIB

CISCO-CALL-HISTORY-MIB.my

CISCO-CIRCUIT-INTERFACE-MIB

CISCO-DIAL-CONTROL-MIB

CISCO-DSP-MGMT-MIB

CISCO-ENTITY-MIB

CISCO-ENTITY-FRU-CONTROL-MIB

CISCO-ENVMON-MIB.my

CISCO-FRAME-RELAY-MIB

CISCO-ISDN-MIB

CISCO-MEMORY-POOL-MIB.my

CISCO-MODEM-MGMT-MIB

CISCO-PING-MIB

CISCO-POP-MGMT-MIB

CISCO-QUEUE-MIB.my

CISCO-SMI.my

CISCO-TC

CISCO TOKEN RING MIB

CISCO-SYSLOG-MIB

CISCO-VPDN-MGMT-MIB

DIAL-CONTROL-MIB

ENTITY-MIB

EXPRESSION-MIB

FDDI-SMT73-MIB

FSIP-MIB

IF-MIB.mib

OLD-CISCO-CPU-MIB

OLD-CISCO-CHASSIS-MIB

OLD-CISCO-IP-MIB

OLD-CISCO-MEMORY-MIB

PROCESS-MIB

RFC-1212.mib

RFC-1215.mib

RFC1155-SMI.mib

RFC1213-MIB.mib

RFC1354-MIB.mib

RFC1406-MIB

RFC1407-MIB

RFC1398-MIB

RTT Mon MIB

SONET-MIB

Caveats for Cisco IOS Release 12.2(1) XS

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats; severity 2 caveats are less serious. Severity 3 caveats are moderate caveats, and only select severity 3 caveats are included in the caveats document.

This section contains only open and resolved caveats for the current Cisco IOS maintenance release.

All caveats in Cisco IOS Release 12.2 and Cisco IOS Release 12.2(1) are also in Cisco IOS Release 12.2(1) XS2.

For information on caveats in Cisco IOS Release 12.2, see Caveats for Cisco IOS Release12.2,  which lists severity 1 and 2 caveats and select severity 3 caveats and is located on Cisco.com and the Documentation CD-ROM.

Caveat numbers and brief descriptions for Cisco IOS Release12.2(1) XS2 are listed in Table 4. Release note enclosure that are not visible from Bug ToolKit at this time are included in the tables. For details about a particular caveat, go to Bug Toolkit at:

http://www.cisco.com/kobayashi/bugs/bugs.html

To access this location, you must have an account on Cisco.com. For information about how to obtain an account, go to the "Feature Navigator" section.


Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, log in to Cisco.com and click Service and Support: Technical Assistance Center: Select & Download Software: Jump to a software resource: Software Bug Toolkit/Bug Watcher. Another option is to go to http://www.cisco.com/support/bugtools/.


Open Caveats—Cisco IOS Release 12.2(1) XS2

There are no open caveats specific to Cisco IOS Release 12.2(1) XS2 that require documentation in the release notes.

Resolved Caveats—Cisco IOS Release 12.2(1) XS2

All the caveats listed in Table 4 are resolved in Cisco IOS Release 12.2(1) XS2. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 4 Resolved Caveats for Cisco IOS Release 12.2(1) XS2

Caveat ID Number
Description

CSCdw65903

An error can occur with management protocol processing. Please use the following URL for further information:

http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903


Open Caveats—Cisco IOS Release 12.2(1) XS1

All the caveats listed in Table 5 are open in Cisco IOS Release 12.2(1) XS1. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 5 Open Caveats for Cisco IOS Release 12.2(1) XS1

Caveat ID Number
Description

CSCdu69405

After bootup SS7 signalling is up but B channels are not ready

CSCdu69747

SS7 link fluctuates and calls are dropped unnder stress on 5800

CSCdv48950

Very poor (unuseably) upload performance from dialup client modems

Symptom: Attempting to upload (port to Egress direction) information larger than a few kilobytes fails or runs extremely slowly.

Conditions: This problem occurs on Cisco AS5850 Access Servers running Cisco IOS Release 12.2(02)XB. The upload will start ok with a "normal" packet rate, but the packet rate will very quickly drop to near zero in both directions of the TCPsession. The packet rate can be observed by issuing

show interfaces async x/y

where x is the slot number and y is the port (modem) number of the modem the problem is occuring on.

Workaround: There is no known workaround.

Note: This issue is not seen on the AS5400 and AS5350 platforms.

CSCdv51292

Symptom: Attempting to upload (port to Egress direction) information larger than a few kilobytes fails or runs extremely slowly. Examples of applications affected are ftp and Microsoft Netbios File sharing.

Conditions: This problem occurs on Cisco AS5800 or AS5850 Access Servers running:

Cisco IOS Release 12.2(01)XS (which has SPE portware version 0.6.108 bundled)

Cisco IOS Release 12.2(02)XB (which has SPE portware 0.7.5.0 bundled)

The upload will start ok with a "normal" packet rate, but the packet rate will very quickly drop to near zero in both directions of the TCP session. The packet rate can be observed by issuing the following command for the Cisco AS5800:

show interfaces async <shelf>/<slot>/<port>

For the Cisco AS5850:

show interfaces async <slot>/<port>

The SPE portware version can be found by issuing the following command:

show spe version

Workaround: There is no known workaround for Cisco IOS Release 12.2(02)XB.

For Cisco IOS Release 12.2(01)XS, a workaround is to use SPE portware version 0.6.93.0. This can be loaded into the SPE's with the following configuration command:

(config)#spe <shelf>/<slot>/<spe> <shelf>/<slot>/<spe>

(config-spe)#firmware location flash:<filename>

(config-spe)#end

where the 0.6.93.0 version of the SPE portware has been copied into flash with the name <filename>.


Resolved Caveats—Cisco IOS Release 12.2(1) XS1

All the caveats listed in Table 6 are resolved in Cisco IOS Release 12.2(1) XS1. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 6 Resolved Caveats for Cisco IOS Release 12.2(1)XS1

Caveat ID Number
Description

CSCdp66118

Traceback and crash with v.120,X.75,modem,bacp calls

CSCds52880

Spurious memory access made at csm_event_from_isdn reading 0x4

CSCds72317

Alignment errors in ip_hc_context_status

CSCdt82323

Bus error at entry_in_pw_dld_queue

CSCdu01392

Image crashes at datagram_done called from lapb_reset

CSCdu09342

ISDN network-side continuously sends RESTART after user-side reloads

CSCdu10012

TWU7: VPDN tunnels do not came up for Analog calls

CSCdu16158

Idle-timeout on Virtual Profiles breaks some configs

CSCdu33245

During stress test router crash

CSCdu48944

ISDN ERROR aleart on as5800 while traffic going

CSCdu64551

SF Crash - Check_heaps found invalid block in IO mem

CSCdu88651

Memory corruption crash

CSCdv06104

Spurious access and crash in mlp_fastsend_les

CSCdv12625

LAPB-TA frames larger than 1526 bytes are being dropped

CSCdv20100

Buffers memory leak

CSCdv25288

Alignment Error at isdn_call_disconnect

CSCdv35725

Output packets corrupted with CEF, Virtual-Profiles and ISDN

CSCdv42884

CSCdu64551 fix does not work for Marvel platform


Open Caveats—Cisco IOS Release 12.2(1) XS

All the caveats listed in Table 7 are open in Cisco IOS Release 12.2(1) XS. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 7 Open Caveats for Cisco IOS Release 12.2(1) XS

Caveat ID Number
Description

CSCdv12625

LAPB-TA frames larger than 1526 bytes are being dropped


Resolved Caveats—Cisco IOS Release 12.2(1) XS

All the caveats listed in Table 6 are resolved in Cisco IOS Release 12.2(1) XS. This table lists only severity 1 and 2 caveats and select severity 3 caveats.

Table 8 Resolved Caveats for Cisco IOS Release 12.2(1) XS

Caveat ID Number
Description

CSCdu64551

SF Crash - Check_heaps found invalid block in IO

CSCdt25737

Unable to start session on L2TP tunnel that is coming down

CSCdt20687

CSM rejects call to free timeslot

CSCdu73738

Data will not flow with V.120 with flow control set

CSCdu40675

Buffer header leak on as5800

CSCdu69988

Some modems stuck in vdev status(0x00002000)

CSCdu48362

RS Rebooted by watchdog hard reset

CSCdt64496

First LCP packet is dropped by NAS during PPP neg

CSCdt59455

vty-async virtual-template doesnt work with no peer default ip addr

CSCdu48362

RS Rebooted by watchdog hard reset

CSCdu22255

Crash at acct_periodic_update_data()

CSCdu19484

Invalid memory free action by OSPF causes router crash

CSCdt09214

Spurious memory access at vp_ipfib_fixup+0x20

CSCdt46139

%ALIGN-1-FATAL: Corrupted program counter with virtual-profiles

CSCdt68534

bus error at PC 0x0, address 0x0 - serial_process_receive_packet

CSCds55069

V120 vty sessions are hanging

CSCdt40568

SAPI = 16, without X25 configured

CSCdu69988

Some modems stuck in vdev status(0x00002000)

CSCdu44831

Line card restarts during portware download

CSCds79849

CPUHOG while clearing counters w/large number of PPP sessions


Related Documentation

The following sections describe the documentation available for the Cisco AS5800 universal access servers. These documents consist of hardware and software installation guides, Cisco IOS configuration guides and command references, system error messages, feature modules, and other documents.

Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.

Use these release notes with these documents:

Release-Specific Documents

Platform-Specific Documents

Feature Modules

Feature Navigator

Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Cisco IOS Release 12.2 and are located on Cisco.com and the Documentation CD-ROM:

Cross-Platform Release Notes for Cisco IOS Release 12.2

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.2: Release Notes: Cross-Platform Release Notes

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Release Notes: Cross-Platform Release Notes

Product bulletins, field notices, and other release-specific documents on Cisco.com at:

Technical Documents

The "Caveats for Cisco IOS Release 12.2(1) XS" section

As a supplement to the caveats listed in Caveats for Cisco IOS Release 12.2(1) XS in these release notes, see Caveats for Cisco IOS Release 12.2, which contain caveats applicable to all platforms for all maintenance releases of Cisco IOS Release 12.2.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.2: Release Notes: Caveats

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Caveats


Note If you have an account with Cisco.com, you can use Bug Navigator II to find caveats of any severity for any release. To reach Bug Navigator II, log in to Cisco.com and click Service & Support: Technical Assistance Center: Select & Download Software: Jump to a software resource: Software Bug Toolkit/Bug Watcher. Another option is to go to http://www.cisco.com/support/bugtools/bugtool.shtml.


Platform-Specific Documents

These documents are available for the Cisco AS5800 universal access servers on Cisco.com and the Documentation CD-ROM:

Read Me First—Cisco AS5800 Universal Access Server

Hardware Installation Documents for Cisco AS5800

Configuration Documents for Cisco AS5800

Cisco AS5800 Universal Access Server Regulatory Compliance and Safety Information

On Cisco.com at:

Technical Documents: Access Servers and Access Routers: Access Servers: Cisco AS5800

On the Documentation CD-ROM at:

Cisco Product Documentation: Access Servers and Access Routers: Access Servers: Cisco AS5800

Feature Modules

Feature modules describe new features supported by Cisco IOS Release 12.2(1) XS2 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.2: New Feature Documentation

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: New Feature Documentation

Feature Navigator

Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image.

Feature Navigator is available 24 hours a day, 7 days a week. To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to establish an account.

To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.

Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:

http://www.cisco.com/go/fn

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference.

On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.2: Configuration Guides and Command References

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Configuration Guides and Command References

Cisco IOS Release 12.2 Documentation Set Contents

Table 9 lists the contents of the Cisco IOS Release 12.2 software documentation set, which is available in electronic form and in printed form if ordered.


Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.


On Cisco.com at:

Technical Documents: Cisco IOS Software: Cisco IOS Release 12.2

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2

Table 9 Cisco IOS Release 12.2 Documentation Set

Books
Major Topics

Cisco IOS Configuration Fundamentals Configuration Guide

Cisco IOS Configuration Fundamentals Command Reference

Cisco IOS User Interfaces
File Management
System Management

Cisco IOS Bridging and IBM Networking Configuration Guide

Cisco IOS Bridging and IBM Networking Command Reference, Volume 1 of 2

Cisco IOS Bridging and IBM Networking Command Reference, Volume 2 of 2

Transparent Bridging
SRB
Token Ring Inter-Switch Link
Token Ring Route Switch Module
RSRB
DLSW+
Serial Tunnel and Block Serial Tunnel
LLC2 and SDLC
IBM Network Media Translation
SNA Frame Relay Access
NCIA Client/Server
Airline Product Set
DSPU and SNA Service Point
SNA Switching Services
Cisco Transaction Connection
Cisco Mainframe Channel Connection
CLAW and TCP/IP Offload
CSNA, CMPC, and CMPC+
TN3270 Server

Cisco IOS Dial Technologies Configuration Guide: Dial Access

Cisco IOS Dial Technologies Configuration Guide: Large-Scale Dial Applications

Cisco IOS Dial Technologies Command Reference,
Volume 1 of 2

Cisco IOS Dial Technologies Command Reference,
Volume 2 of 2

Dial Access
Modem and Dial Shelf Configuration and Management
ISDN Configuration
Signaling Configuration
Point-to-Point Protocols
Dial-on-Demand Routing
Dial Backup
Dial Related Addressing Service
Network Access Solutions
Large-Scale Dial Solutions
Cost-Control Solutions
Internetworking Dial Access Scenarios

Cisco IOS Interface Configuration Guide

Cisco IOS Interface Command Reference

LAN Interfaces
Serial Interfaces
Logical Interfaces

Cisco IOS IP Configuration Guide

Cisco IOS IP Command Reference, Volume 1 of 3: Addressing and Services

Cisco IOS IP Command Reference, Volume 2 of 3: Routing Protocols

Cisco IOS IP Command Reference, Volume 3 of 3: Multicast

IP Addressing
IP Services
IP Routing Protocols
IP Multicast

Cisco IOS AppleTalk and Novell IPX Configuration Guide

Cisco IOS AppleTalk and Novell IPX Command Reference

AppleTalk
Novell IPX

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference

Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

Cisco IOS Voice, Video, and Fax Configuration Guide

Cisco IOS Voice, Video, and Fax Command Reference

Voice over IP
Call Control Signaling
Voice over Frame Relay
Voice over ATM
Telephony Applications
Trunk Management
Fax, Video, and Modem Support

Cisco IOS Quality of Service Solutions Configuration Guide

Cisco IOS Quality of Service Solutions Command Reference

Packet Classification
Congestion Management
Congestion Avoidance
Policing and Shaping
Signaling
Link Efficiency Mechanisms

Cisco IOS Security Configuration Guide

Cisco IOS Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options
Supported AV Pairs

Cisco IOS Switching Services Configuration Guide

Cisco IOS Switching Services Command Reference

Cisco IOS Switching Paths
NetFlow Switching
Multiprotocol Label Switching
Multilayer Switching
Multicast Distributed Switching
Virtual LANs
LAN Emulation

Cisco IOS Wide-Area Networking Configuration Guide

Cisco IOS Wide-Area Networking Command Reference

ATM
Frame Relay
SMDS
X.25 and LAPB

Cisco IOS Mobile Wireless Configuration Guide

Cisco IOS Mobile Wireless Command Reference

General Packet Radio Service

Cisco IOS Terminal Services Configuration Guide

Cisco IOS Terminal Services Command Reference

ARA
LAT
NASI
Telnet
TN3270
XRemote
X.28 PAD
Protocol Translation

Cisco IOS Configuration Guide Master Index

Cisco IOS Command Reference Master Index

Cisco IOS Debug Command Reference

Cisco IOS Software System Error Messages

New Features in 12.2-Based Limited Lifetime Releases

New Features in Release 12.2 T

Release Notes (Release note and caveat documentation for 12.2-based releases and various platforms)




Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

You can access the most current Cisco documentation on the World Wide Web at the following sites:

http://www.cisco.com

http://www-china.cisco.com

http://www-europe.cisco.com

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

Registered Cisco Direct Customers can order Cisco Product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco product documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address:

Attn Document Resource Connection
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools. For Cisco.com registered users, additional troubleshooting tools are available from the TAC website.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

If you cannot resolve your technical issue by using the TAC online resources, Cisco.com registered users can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1 (P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
