Release Notes for the Cisco 1700 Series Routers  for Cisco IOS Release 12.2(4)XM

Table Of Contents

Release Notes for the Cisco 1700 Series Routers  for Cisco IOS Release 12.2(4)XM

Contents

System Requirements

Memory Requirements

Hardware Supported

Cisco 1710 Routers

Cisco 1720 Routers

Cisco 1750, 1750-2V, and 1750-4V Routers

Cisco 1751 and 1751-V Routers

Cisco 1760 and 1760-V Routers

Determining Your Software Release

Upgrading to a New Software Release

Feature Sets

New and Changed Information

New Software Features in Release 12.2(4)XM

Basic Session Initiation Protocol

Call Admission Control for H.323 VoIP Gateways

Call Transfer Capabilities Using the Refer Method

Configurable PSTN Cause Code to SIP Response Mapping

DTMF Relay for SIP calls Using Named Telephone Events

G.728 - CODEC Support on Cisco 1750 and 1751 Routers

Interactive Voice Response Version 2.0 on VoIP Gateways

ISDN Progress Indicator Support for SIP Using 183 Session Progress

Layer 2 Class of Service Matching and Marking

MGCP

MGCP 1.0

MGCP-Based Fax (T.38) and DTMF Relay

MGCP Basic Class and Operator Services

MGCP VoIP Call Admission Control

Modem Passthrough over VoIP

NAT Support for SIP

RFC2782 Compliance (Style of DNS SRV Queries)

SIP Diversion Header Implementation for Redirecting Number

SIP for VoIP Enhancements

SIP Gateway Support for Bind Command

SIP Gateway Support for Third Party Call Control

SIP Gateway Support of RSVP and "tel" URL

SIP Intra-Gateway Hairpinning

SIP INVITE Request with Malformed Via Header

SIP T.38 Fax Relay

SIP User Agent MIB

T.37 Store and Forward Fax

New Software Features in Release 12.2(4)T

Limitations

Commands Not Supported on Cisco 1750 and 1751 Routers

Features Not Supported on Cisco 1700 Series Routers

Features Not Supported on Cisco 1760 Routers

Functionality Not Supported on Cisco 1750 and 1751 Routers

Important Notes

"Faxrate 14000" for T.38

Fan Operation in Cisco 1700 Series Routers

Flash defaults to Flash:1 on Multipartition Flash

H.450 Features Supported on Cisco 1750 and 1751 Routers

Layer 2 COS Matching and Marking Feature Configuration Sequence

Peak Cell Rate and Sustainable Cell Rate Values

Using the boot flash Command

Caveats

Caveats - Releases 12.2(4)XM2, 12.2(4)XM3, and 12.2(4)XM4

Resolved Caveats - Release 12.2(4)XM1

Management

Release 12.2(4)XM - Caveats

Miscellaneous Caveats

SIP-Related Caveats

MGCP-Related Caveats

Related Documentation

Release-Specific Documents

Platform-Specific Documents

Cisco 1710 Routers

Cisco 1720 Routers

Cisco 1750 Routers

Cisco 1751 and 1751-V Routers

Cisco 1760 and 1760-V Routers

Feature Modules

Feature Navigator

Cisco IOS Software Documentation Set

Documentation Modules

Release 12.2 Documentation Set

Obtaining Documentation

World Wide Web

Documentation CD-ROM

Ordering Documentation

Documentation Feedback

Obtaining Technical Assistance

Cisco.com

Technical Assistance Center

Contacting TAC by Using the Cisco TAC Website

Contacting TAC by Telephone


Release Notes for the Cisco 1700 Series Routers  for Cisco IOS Release 12.2(4)XM


August 15, 2002

These release notes describe new features and significant software components for the Cisco 1700 series routers that support Cisco IOS Release 12.2 T, up to and including Release 12.2(4)XM4. These release notes are updated as needed to describe new memory requirements, new features, new hardware support, software platform deferrals, microcode or modem code changes, related document changes, and any other important changes. Use these release notes with the Cross-Platform Release Notes for Cisco IOS  Release 12.2 T located on CCO and the Documentation CD-ROM.

For a list of the software caveats that apply to Release 12.2(4)XM4, refer to the section "Caveats" and to the online Caveats for Cisco IOS Release 12.2 T document. The caveats document is updated for every 12.2 T maintenance release and is located on Cisco Connection Online (CCO) and the Documentation CD-ROM.

Contents

These release notes discuss the following topics:

System Requirements

New and Changed Information

Limitations

Important Notes

Caveats

Related Documentation

Obtaining Documentation

Obtaining Technical Assistance

System Requirements

This section describes the system requirements for Release 12.2(4)XM4 and includes the following sections:

Memory Requirements

Hardware Supported

Determining Your Software Release

Upgrading to a New Software Release

Feature Sets

Memory Requirements

This section describes the memory requirements for the Cisco IOS feature sets supported by Cisco IOS Release 12.2(4)XM4 on the Cisco 1700 series routers.

Table 1 Recommended Memory for the Cisco 1700 Series Routers

Platform
Image Name
Feature Set
Recommended Flash Memory
Recommended DRAM Memory
Runs from

Cisco 1710 router

Cisco 1710 IOS IP Plus IPX/AT/IBM/ FW/IDS IPSec 3DES

IP Plus IPX/AT/ IBM/FW/IDS IPSec 3DES

c1710-bk9no3r2sy-mz

16 MB

48 MB

RAM

Cisco 1710 IOS IP Plus FW/IDS IPSec 3DES

IP Plus FW/IDS IPSec 3DES

c1710-k9o3sy-mz

8 MB

32 MB

RAM

Cisco 1720, 1750, 1751, and 1760 routers

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/FW/ IDS IPSec 56

IP Plus ADSL/ IPX/AT/IBM/ FW/IDS IPSec 56

c1700-bk8no3r2sy7-mz

16 MB

48 MB

RAM

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/FW/ IDS IPSec 3DES

IP Plus ADSL/ IPX/AT/IBM/ FW/IDS IPSec 3DES

c1700-bk9no3r2sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM

IP Plus ADSL/ IPX/AT/IBM

c1700-bnr2sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP/IPX/AT/IBM

IP/IPX/AT/IBM

c1700-bnr2y-mz

8 MB

32 MB

RAM



Cisco 1700 IOS IP Plus ADSL/FW/IDS IPSec 56

IP Plus ADSL/ FW/IDS IPSec 56

c1700-k8o3sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL IPSec 56

IP Plus ADSL IPSec 56

c1700-k8sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/FW/IDS IPSec 3DES

IP Plus ADSL/ FW/IDS IPSec 3DES

c1700-k9o3sy7-mz

16 MB

48 MB

RAM

Cisco 1720, 1750, 1751, and 1760 routers
(continued)

Cisco 1700 IOS IP Plus ADSL IPSec 3DES

IP Plus ADSL IPSec 3DES

c1700-k9sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/IPX/FW/IDS Plus

IP Plus ADSL/ IPX/FW/IDS

c1700-no3sy7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP/IPX

IP/IPX

c1700-ny-mz

8 MB

32 MB

RAM

Cisco 1700 IOS IP/FW/IDS

IP/FW/IDS

c1700-o3y-mz

8 MB

32 MB

RAM

Cisco 1700 IOS IP Plus ADSL

IP Plus ADSL

c1700-sy7-mz

8 MB

48 MB

RAM

Cisco 1700 IOS IP

IP

c1700-y-mz

8 MB

32 MB

RAM

Cisco 1700 IOS IP/ADSL

IP/ADSL

c1700-y7-mz

8 MB

32 MB

RAM

Cisco 1750, Cisco 1751, and Cisco 1760 routers

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/ Voice/FW/IDS IPSec 56

IP Plus ADSL/ IPX/AT/IBM/ Voice/FW/IDS IPSec 56

c1700-bk8no3r2sv3y7-mz

32 MB

64 MB

RAM

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/ Voice/FW/IDS Plus IPSec 3DES

IP Plus ADSL/ IPX/AT/IBM/ Voice/FW/IDS IPSec 3DES

c1700-bk9no3r2sv3y7-mz

32 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/Voice/FW/IDS Plus IPSec 56

IP Plus ADSL/ Voice/FW/IDS IPSec 56

c1700-k8o3sv3y7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/Voice Plus IPSec 56

IP Plus ADSL/ Voice IPSec 56

c1700-k8sv3y7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/Voice/FW/IDS IPSec 3DES

IP Plus ADSL/ Voice/FW/IDS IPSec 3DES

c1700-k9o3sv3y7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/Voice IPSec 3DES

IP Plus ADSL/ Voice IPSec 3DES

c1700-k9sv3y7-mz

16 MB

48 MB

RAM



Cisco 1700 IOS IP Plus ADSL/IPX/Voice/FW/ IDS

IP Plus ADSL/ IPX/Voice/FW/ IDS

c1700-no3sv3y7-mz

16 MB

48 MB

RAM

Cisco 1750, Cisco 1751, and Cisco 1760 routers
(continued)

Cisco 1700 IOS IP Plus ADSL/Voice/FW/IDS

IP Plus ADSL/ Voice/FW/IDS

c1700-o3sv3y7-mz

16 MB

48 MB

RAM

Cisco 1700 IOS IP Plus Voice

IP Plus Voice

c1700-sv3y-mz

16 MB

48 MB

RAM

Cisco 1700 IOS IP Plus ADSL/Voice

IP Plus ADSL/
Voice

c1700-sv3y7-mz

16 MB

48 MB

RAM

Cisco 1700 IOS IP Plus
VOX

IP Plus VOX

c1700-sv8y-mz

16 MB

48 MB

RAM

Cisco 1751 and Cisco 1760 routers

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/ VOX/ FW IDS IPSec 56

IP Plus ADSL/ IPX/AT/IBM/ VOX/ FW/IDS IPSec 56

c1700-bk8no3r2sv8y7-mz

16 MB

64 MB

RAM

Cisco 1700 IOS IP Plus ADSL/IPX/AT/IBM/ VOX/FW/IDS IPSec 3DES

IP Plus ADSL/ IPX/AT/IBM/ VOX/FW/IDS IPSec 3DES

c1700-bk9no3r2sv8y7-mz

32 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX/FW/IDS IPSec 56

IP Plus ADSL/ VOX/FW/IDS IPSec 56

c1700-k8o3sv8y7-mz

32 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX IPSec 56

IP Plus ADSL/ VOX IPSec 56

c1700-k8sv8y7-mz

16 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX/FW/IDS IPSec 3DES

IP Plus ADSL/ VOX/FW/IDS IPSec 3DES

c1700-k9o3sv8y7-mz

16 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX IPSec 3DES

IP Plus ADSL/VOX IPSec 3DES

c1700-k9sv8y7-mz

16 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX/FW/IDS

IP Plus ADSL/ VOX/FW/IDS

c1700-o3sv8y7-mz

16 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/IPX/VOX/FW/IDS

IP Plus ADSL/ IPX/VOX/FW/ IDS

c1700-no3sv8y7-mz

16 MB

64 MB

RAM



Cisco 1700 IOS IP Plus ADSL/VOX

IP Plus ADSL/ VOX

c1700-sv8y7-mz

16 MB

64 MB

RAM


Hardware Supported

Cisco IOS Release 12.2(4)XM4 supports the following Cisco 1700 series routers:

Cisco 1710 Routers

Cisco 1720 Routers

Cisco 1750, 1750-2V, and 1750-4V Routers

Cisco 1751 and 1751-V Routers

Cisco 1760 and 1760-V Routers

The Cisco 1710 and 1720 routers run data images only. The Cisco 1750, 1750-2V, and 1750-4V routers run data and data-and-voice images, providing analog voice support. Cisco 1751, 1751-V, 1760, and 1760-V routers run data and data-and-voice images, providing digital and analog voice support.

For detailed descriptions of the new hardware features, see the documents listed in the "Platform-Specific Documents" section.

Cisco 1710 Routers

The 1710 router provides Internet and intranet access and includes the following:

Support for virtual private networking.

Modular architecture.

Network device integration.

The Cisco 1710 router has the following hardware components:

One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with manual override available).

One Ethernet (10BASE-T) port, which operates in full- or half-duplex mode.

One auxiliary (AUX) port (up to 115.2 kbps asynchronous serial).

One console port.

Motorola MPC855T PowerQUICC at 48 MHz. The hardware encryption module offloads the processor for encryption and decryption.

One internal expansion slot for support of hardware-assisted services such as encryption (up to T1/E1) and compression.

DRAM memory: 32 MB default, expandable to 64 MB.

Flash memory: 16 MB default, 16 MB maximum.

One security slot that supports Kensington or similar lockdown equipment.

Desktop form factor.

Cisco 1720 Routers

The 1720 router provides Internet and intranet access and includes the following:

Support for virtual private networking.

Modular architecture.

Network device integration.

The Cisco 1720 router has the following hardware components:

One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with manual override available).

Two WAN interface card slots.

One AUX port (up to 115.2 kbps asynchronous serial).

One console port.

RISC Processor for high performance encryption.

One internal expansion slot for support of hardware-assisted services such as encryption (up to T1/E1) and compression.

DRAM memory: 32 MB default, expandable to 48 MB.

Flash memory: 8 MB default, expandable to 16 MB.

Desktop form factor.

The Cisco 1720 router supports any combination of one or two of the following WAN interface cards:

WIC-1T—One port high speed serial (sync/async).

WIC-2T—Two port high speed serial (sync/async).

WIC-2A/S—Two port low speed serial (sync/async) (up to 128 kbps).

WIC-1B-S/T—One port ISDN BRI S/T.

WIC-1B-U—One port ISDN BRI U.

WIC-1DSU-56K4—One port integrated 56/64 kbps 4-wire DSU/CSU.

WIC-1DSU-T1—One port integrated T1 / Fractional T1 DSU/CSU.

WIC-1ENET—One-port 10Base-T Ethernet interface.

WIC-1ADSL—One-port asymmetrical digital subscriber line.

WIC-1SHDSL—One-port G-Standard High bit-rate Digital Subscriber Loop.

Cisco 1750, 1750-2V, and 1750-4V Routers

The voice-and-data capable Cisco 1750, 1750-2V and 1750-4V routers provide global Internet and company intranet access and includes the following:

Voice-over-IP (VoIP) voice-and-data functionality; the router can carry voice traffic (for example, telephone calls and faxes) over an IP network.

Support for virtual private networking.

Modular architecture.

Network device integration.

The Cisco 1750, 1750-2V and 1750-4V routers have the following hardware components:

One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with manual override available).

One voice interface card (VIC) slot—Supports a single voice interface card with two ports per card.

Two WAN interface card (WIC) slots for either WICs or VICs.

Synchronous serial interfaces on serial WICs.

Asynchronous serial interfaces on serial WICs.

ISDN WICs—ISDN dialup and ISDN leased line (IDSL) at 144 kbps; encapsulation over ISDN leased line; Frame Relay and PPP.

One AUX port (up to 115.2 kbps asynchronous serial).

One console port.

One internal expansion slot—Supports hardware-assisted services such as encryption (up to T1/E1 speeds).

RISC Processor—Motorola MPC860T PowerQUICC at 48 MHz.

One security slot that supports Kensington or similar lockdown equipment.

DRAM: 16 MB default, expandable to 48 MB.

Flash memory: 4 MB default, expandable to 16 MB.

Desktop form factor.

The Cisco 1750, 1750-2V and 1750-4V routers support any combination of one or two of the following WICs:

WIC-1T—One port high speed serial (sync/async).

WIC-2T—Two port high speed serial (sync/async).

WIC-2A/S—Two port low speed serial (sync/async) (up to 128 kbps).

WIC-1B-S/T—One port ISDN BRI S/T.

WIC-1B-U—One port ISDN BRI U.

WIC-1DSU-56K4—One port integrated 56/64 kbps 4-wire DSU/CSU.

WIC-1DSU-T1—One port integrated T1 / Fractional T1 DSU/CSU.

WIC-1ENET—One-port 10Base-T Ethernet interface.

WIC-1ADSL—One-port asymmetrical digital subscriber line.

WIC-1SHDSL—One-port G-Standard High bit-rate Digital Subscriber Loop.

The Cisco 1750, 1750-2V and 1750-4V routers support any combination of one or two of the following voice interface cards:

VIC-2FXS—Two-port Foreign Exchange Station (FXS) voice interface card.

VIC-2FXO—Two-port Foreign Exchange Office (FXO) voice interface card.

VIC-2FXO-EU—Two-port FXO voice interface card for Europe.

VIC-2E/M—Two-port Ear and Mouth (E & M) voice interface card.

VIC-2FXO-M1—Two-port FXO for the United States with battery reversal.

VIC-2FXO-M2—Two-port FXO for Europe with battery reversal.

VIC-2FXO-M3—Two-port FXO for Australia.

Cisco 1751 and 1751-V Routers

The voice-and-data capable Cisco 1751 and 1751-V routers provide global Internet and company intranet access and include the following:

VoIP voice-and-data functionality; the router can provide support for digital and analog voice traffic (for example, telephone calls and faxes) over an IP network.

Support for virtual private networking.

Modular architecture.

Network device integration.

The Cisco 1751 and 1751-V routers have the following hardware components:

One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with manual override available).

Institute of Electrical and Electronic Engineers (IEEE) 802.1Q VLAN support.

One VIC slot—Supports a single voice interface card with two ports per card.

Two WIC slots for either WICs or VICs.

Synchronous serial interfaces on serial WICs.

Asynchronous serial interfaces on serial WICs.

ISDN WICs—ISDN dialup and IDSL at 144 kbps; encapsulation over ISDN leased line; Frame Relay and PPP.

One AUX port (up to 115.2 kbps asynchronous serial).

One console port.

One internal expansion slot—Supports hardware-assisted services such as encryption (up to T1/E1 speeds).

RISC Processor—Motorola MPC860P PowerQUICC at 48.384 MHz.

One security slot that supports Kensington or similar lockdown equipment.

DRAM:

Cisco 1751: 32 MB default, expandable to 96 MB.

Cisco 1751-V: 64 MB default, expandable to 128 MB.

Flash memory:

Cisco 1751: 16 MB.

Cisco 1751-V: 32 MB.

Desktop form factor.

The Cisco 1751 and 1751-V routers support any combination of one or two of the following WICs:

WIC-1T—One-port high speed serial (sync/async)(T1/E1).

WIC-2T—Two-port high speed serial (sync/async) (T1/E1).

WIC-2A/S—Two-port low speed serial (sync/async) (up to 128 kbps).

WIC-1B-S/T—One-port ISDN BRI S/T.

WIC-1B-U—One-port ISDN BRI U with integrated NT1.

WIC-1DSU-56K4—One-port integrated 56/64 kbps 4-wire DSU/CSU.

WIC-1DSU-T1—One-port integrated T1 / Fractional T1 DSU/CSU.

WIC-1ADSL—One-port asymmetric digital subscriber line.

WIC-1SHDSL—One-port G-Standard High bit-rate Digital Subscriber Loop.

WIC-1ENET—One-port 10Base-T Ethernet interface.

WIC-1-ADSL—One-port asymmetrical digital subscriber line.

The Cisco 1751 and 1751-V routers support any combination of one, two or three of the following VICs:

VIC-2FXS—Two-port FXS voice interface card.

VIC-2FXO—Two-port FXO voice interface card.

VIC-2FXO-EU—Two-port FXO voice interface card for Europe.

VIC-2E/M—Two-port E & M voice interface card.

VIC-2FXO-M1—Two-port FXO for the United States with battery reversal.

VIC-2FXO-M2—Two-port FXO for Europe with battery reversal.

VIC-2FXO-M3—Two-port FXO for Australia.

VIC-2BRI-NT/TE—Two-port ISDN interface.

VIC-2DID—Two-port direct inward-dialing voice interface card.

Cisco 1760 and 1760-V Routers

The voice-and-data capable Cisco 1760 and 1760-V routers provide global Internet and company intranet access and include the following:

VoIP voice-and-data functionality; the router can provide support for digital and analog voice traffic (for example, telephone calls and faxes) over an IP network.

Cisco 1760-V routers integrate data and voice services with support for multiple voice channels.

VoIP and Voice-over-Frame Relay (VoFR) connections.

Support for virtual private networking.

Modular architecture.

Network device integration.

Support for the following network management tools and applications:

Simple Network Management Protocol (SNMP).

AutoInstall (for downloading configuration files to the router over a WAN connection).

The Cisco 1760 and 1760-V routers have the following hardware components:

One autosensing 10/100 Fast Ethernet port, which operates in full- or half-duplex mode (with software override support).

IEEE 802.1Q VLAN support.

Two VIC slots—Support voice interface cards with two ports per card.

Two WIC slots for either WICs or VICs.

Synchronous serial interfaces on serial WICs.

Asynchronous serial interfaces on serial WICs.

One AUX port (to support a modem connection to the router, which can be configured and managed from a remote location, up to 115.2 kbps asynchronous serial).

One console port (for router configuration and management from a connected terminal or PC, up to 115.2 kbps).

One internal expansion slot—Supports hardware-assisted services such as encryption (up to T1/E1 speeds).

RISC Processor—Motorola MPC860P PowerQUICC at 40 MHz externally and 80MHz internally.

DRAM:

Cisco 1760: 32 MB default, expandable to 96 MB.

Cisco 1760-V: 64 MB default, expandable to 96 MB.

Flash memory:

Cisco 1760: 16 MB default, expandable to 64 MB.

Cisco 1760-V: 32 MB default, expandable to 64 MB.

The Cisco 1760 and 1760-V routers support any combination of one or two of the following WICs:

WIC-1T—One-port high speed serial (sync/async)(T1/E1).

WIC-2T—Two-port high speed serial (sync/async) (T1/E1).

WIC-2A/S—Two-port low speed serial (sync/async) (up to 128 kbps).

WIC-1B-S/T—One-port ISDN BRI S/T.

WIC-1B-U—One-port ISDN BRI U with integrated NT1.

WIC-1DSU-56K4—One-port integrated 56/64 kbps 4-wire DSU/CSU.

WIC-1DSU-T1—One-port integrated T1 / Fractional T1 DSU/CSU.

WIC-1-ADSL—One-port asymmetric digital subscriber line.

WIC-1ENET—One-port 10Base-T Ethernet interface.

WIC-1SHDSL—One-port G-Standard High bit-rate Digital Subscriber Loop.

The Cisco 1760 and 1760-V routers support any combination of one, two, three, or four of the following VICs:

VIC-2FXS—Two-port FXS voice interface card.

VIC-2FXO—Two-port FXO voice interface card.

VIC-2FXO-EU—Two-port FXO voice interface card for Europe.

VIC-2E/M—Two-port E & M voice interface card.

VIC-2FXO-M1—Two-port FXO for the United States with battery reversal.

VIC-2FXO-M2—Two-port FXO for Europe with battery reversal.

VIC-2FXO-M3—Two-port FXO for Australia.

VIC-2BRI-NT/TE—Two-port ISDN interface.

VIC-2DID—Two-port direct inward-dialing voice interface card.

Determining Your Software Release

To determine the version of Cisco IOS software currently running on your Cisco 1700 series router, log in to the router and enter the show version EXEC command. The following sample output from the show version command indicates the version number on the second output line:

router> show version
Cisco Internetwork Operating System Software
IOS (tm) c1700 Software (c1700-y-mz), Version 12.2(4)XM4, RELEASE SOFTWARE

Upgrading to a New Software Release

For general information about upgrading to a new software release, see
Technical Support for 1700 Series Access Routers.

Feature Sets

The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.2(4)XM4 supports the same feature sets as Releases 12.2 and 12.2 T, but Release 12.2(4)XM4 include new features supported by the Cisco 1700 series routers.


Caution Cisco IOS images with strong encryption (including, but not limited to 168-bit (3DES) data encryption feature sets) are subject to United States government export controls and have limited distribution. Strong encryption images to be installed outside the United States are likely to require an export license. Customer orders can be denied or subject to delay due to United States government regulations. When applicable, the purchaser/user must obtain local import and use authorizations for all encryption strengths. Please contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.

Table 2 through Table 5 list the features and feature sets supported in Cisco IOS Release 12.2(4)XM4:

Table 2—Cisco 1710 routers

Table 3—Cisco 1720, 1750, 1751, and 1760 routers

Table 4—Cisco 1750, 1751, and 1760 routers

Table 5—Cisco 1751 and 1760 routers

The tables use the following conventions:

Yes—The feature is supported in the software image.

No—The feature is not supported in the software image.

In—The number in the "In" column indicates the Cisco IOS release in which the feature was introduced. For example, "12.2(4)XM" means the feature was introduced in Release 12.2(4)XM. If a cell in this column is empty, the feature was included in a previous release or the initial base release.


Note These feature set tables only contain a selected list of features, which are cumulative for Release 12.2(4)nn early deployment releases only (nn identifies each early deployment release). The tables do not list all features in each image—additional features are listed in the Cross-Platform Release Notes for Cisco IOS  Release 12.2 T  and Release 12.2 T Cisco IOS documentation.


Table 2 Feature List by Feature Set for Cisco 1710 Routers

Feature
In
Feature Set

IP Plus IPX/AT/ IBM/FW/IDS IPSec 3DES
IP Plus FW/IDS IPSec 3DES
Multimedia & Quality of Service


CAC for VoIP call



No

No

DiffServ for voice signaling traffic



No

No

Layer 2 COS matching and marking



Yes

Yes

Multiservice Applications


G.728 codec support



No

No

TCL scripting for IVR



No

No

RTSP enhanced IVR



No

No

T.37 fax relay



No

No

T.38 fax relay



No

No

SIP features 1



No

No

MGCP features 2



No

No

Modem pass through over VoIP



No

No

1 SIP features include:

1 . Call transfer capabilities using the refer method

1 . Configurable public switched telephone network (PSTN) cause code to SIP response

1 . Gateway support for bind command

1 . ISDN progress indicator support for SIP using 183 session progress

1 . NAT support for SIP

1 . RFC2782 compliance for DNS SRV

1 . Session initiation protocol (SIP)

1 . Session initiation protocol for VoIP enhancements

1 . SIP diversion header implementation for redirecting number

1 . SIP DTMF relay using NTE

1 . SIP gateway support for third party call control

1 . SIP gateway support of RSVP and "tel" URL

1 . SIP intra-gateway hair-pinning

1 . SIP INVITE request with malformed via header

1 . SIP T.38 fax relay

1 . SIP user agent MIB

2 MGCP features include:

2 . MGCP 1.0

2 . MGCP based fax (T.38) and DTMF relay

2 . MGCP basic CLASS and operator services

2 . MGCP VoIP call admission control


Table 3 Feature List by Feature Set for Cisco 1720, 1750, 1751, and 1760 Routers, Part 1 of 2

Feature
In
Feature Set

IP Plus ADSL/ IPX/AT/IBM/FW/ IDS IPSec 56
IP Plus ADSL/ IPX/AT/IBM/FW/IDS IPSec 3DES
IP Plus ADSL/ IPX/AT/ IBM
IP/IPX/ AT/IBM
IP Plus ADSL/FW/ IDS IPSec 56
IP Plus ADSL IPSec 56
Multimedia & Quality of Service


CAC for VoIP call



No

No

No

No

No

No

DiffServ for voice signaling traffic



No

No

No

No

No

No

Layer 2 COS matching and marking 1

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Yes

Multiservice Applications


G.728 codec Support



No

No

No

No

No

No

TCL scripting for IVR



No

No

No

No

No

No

RTSP enhanced IVR



No

No

No

No

No

No

T.37 fax relay



No

No

No

No

No

No

T.38 fax relay



No

No

No

No

No

No

SIP features 2



No

No

No

No

No

No

MGCP features 3



No

No

No

No

No

No

Modem pass through over VoIP



No

No

No

No

No

No

1 The Layer 2 COS matching and marking feature is supported on the Cisco 1710, 1751, and 1760 routers only.

2 For a list of the SIP features, see Table 2, Footnote 1

3 For a list of the MGCP features, see Table 2, Footnote 2


Table 3 Feature List by Feature Set for Cisco 1720, 1750, 1751, and 1760 Routers, Part 2 of 2 (continued)

Feature
In
Feature Set

IP Plus FW/ ADSL/IDS IPSec 3DES
IP Plus ADSL IPSec 3DES
IP Plus ADSL/IPX/ FW/IDS
IP/IPX
IP/FW/ IDS
IP Plus ADSL
IP
IP/ ADSL
Multimedia & Quality of Service


CAC for VoIP call



No

No

No

No

No

No

No

No

DiffServ for voice signaling traffic



No

No

No

No

No

No

No

No

Layer 2 COS matching and marking 1

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Multiservice Applications


G.728 codec support



No

No

No

No

No

No

No

No

TCL scripting for IVR



No

No

No

No

No

No

No

No

RTSP enhanced IVR



No

No

No

No

No

No

No

No

T.37 fax relay



No

No

No

No

No

No

No

No

T.38 fax relay



No

No

No

No

No

No

No

No

SIP features 2



No

No

No

No

No

No

No

No

MGCP features 3



No

No

No

No

No

No

No

No

Modem pass through over VoIP



No

No

No

No

No

No

No

No

1 The Layer 2 COS matching and marking feature is supported on the Cisco 1710, 1751, and 1760 routers only.

2 For a list of the SIP features, see Table 2, Footnote 1

3 For a list of the MGCP features, see Table 2, Footnote 2


Table 4 Feature List by Feature Set for Cisco 1750, 1751, and 1760 Routers, Part 1 of 2 (continued)

Feature
In
Feature Set

IP Plus ADSL/ IPX/AT/IBM/ Voice/FW/IDS IPSec 56
IP Plus ADSL/ IPX/AT/IBM/ Voice/FW/IDS IPSec 3DES
IP Plus ADSL/FW/ Voice/IDS IPSec 56
IP Plus ADSL/ Voice IPSec 56
IP Plus ADSL/FW/ Voice/IDS IPSec 3DES
IP Plus ADSL/ Voice IPSec 3DES
Multimedia & Quality of Service


CAC for VoIP call



No

No

No

No

No

No

DiffServ for voice signaling traffic

12.2(4)XM

No

No

Yes

Yes

No

Yes

Layer 2 COS matching and marking 1

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Yes

Multiservice Applications


G.728 codec support

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Yes

TCL scripting for IVR



No

No

No

No

No

No

RTSP enhanced IVR



No

No

No

No

No

No

T.37 fax relay



No

No

No

No

No

No

T.38 fax relay



No

No

No

No

No

No

SIP features 2



No

No

No

No

No

No

MGCP features 3



No

No

No

No

No

No

Modem pass through over VoIP



No

No

No

No

No

No

1 The Layer 2 COS matching and marking feature is supported on the Cisco 1710, 1751, and 1760 routers only.

2 For a list of the SIP features, see Table 2, Footnote 1

3 For a list of the MGCP features, see Table 2, Footnote 2


Table 4 Feature List by Feature Set for Cisco 1750, 1751, and 1760 Routers, Part 2 of 2

Feature
In
Feature Set

IP Plus ADSL/ IPX/Voice/ FW/IDS
IP Plus ADSL/IDS/ Voice/FW
IP Plus Voice
IP Plus ADSL/ Voice
IP Plus VOX
Multimedia & Quality of Service


CAC for VoIP call

12.2(4)XM

No

No

No

No

Yes

DiffServ for voice signaling traffic

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Layer 2 COS matching and marking 1

12.2(4)XM

Yes

Yes

Yes

Yes

No

Multiservice Applications


G.728 codec support

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

TCL scripting for IVR

12.2(4)XM

No

No

No

No

Yes

RTSP enhanced IVR

12.2(4)XM

No

No

No

No

Yes

T.37 fax relay

12.2(4)XM

No

No

No

No

Yes

T.38 fax relay



No

No

No

No

Yes

SIP features 2

12.2(4)XM

No

No

No

No

Yes

MGCP features 3

12.2(4)XM

No

No

No

No

Yes

Modem pass through over VoIP

12.2(4)XM

No

No

No

No

Yes

1 The Layer 2 COS matching and marking feature is supported on the Cisco 1710, 1751, and 1760 routers only.

2 For a list of the SIP features, see Table 2, Footnote 1

3 For a list of the MGCP features, see Table 2, Footnote 2



Note SIP and Media Gateway Control Protocol (MGCP) features are not supported on Cisco 1760 routers.


Table 5 Feature List by Feature Set for Cisco 1751 and 1760 Routers, Part 1 of 2

Feature
In
Feature Set

IP Plus ADSL/ IPX/AT/ IBM/ VOX/ FW/IDS IPSec 56
IP Plus ADSL/ IPX/AT/IBM/ VOX/FW/IDS IPSec 3DES
IP Plus ADSL/VOX/ FW/ IDS IPSec 56
IP Plus ADSL/ VOX IPSec 56
Multimedia & QoS


CAC for VoIP call

12.2(4)XM

Yes

Yes

Yes

Yes

DiffServ for voice signaling traffic

12.2(4)XM

Yes

Yes

Yes

Yes

Layer 2 COS matching and marking

12.2(4)XM

Yes

Yes

Yes

Yes

Multiservice Applications


G.728 codec support

12.2(4)XM

Yes

Yes

Yes

Yes

TCL scripting for IVR

12.2(4)XM

Yes

Yes

Yes

Yes

RTSP enhanced IVR

12.2(4)XM

Yes

Yes

Yes

Yes

T.37 fax relay

12.2(4)XM

Yes

Yes

Yes

Yes

T.38 fax relay



Yes

Yes

Yes

Yes

SIP features 1

12.2(4)XM

Yes

Yes

Yes

Yes

MGCP features 2

12.2(4)XM

Yes

Yes

Yes

Yes

Modem pass through over VoIP

12.2(4)XM

Yes

Yes

Yes

Yes

1 For a list of the SIP features, see Table 2, Footnote 1

2 For a list of the MGCP features, see Table 2, Footnote 2


Table 5 Feature List by Feature Set for Cisco 1751 and 1760 Routers, Part 2 of 2

Feature
In
Feature Set

IP Plus ADSL/VOX/FW/IDS IPSec 3DES
IP Plus ADSL/VOX IPSec 3DES
IP Plus ADSL/ IPX/VOX/FW/IDS
IP Plus ADSL/ VOX/ FW/IDS
IP Plus ADSL/ VOX
Multimedia & QoS


CAC for VoIP call

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

DiffServ for voice signaling traffic

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Layer 2 COS matching and marking

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Multiservice Applications


G.728 codec support

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

TCL scripting for IVR

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

RTSP enhanced IVR

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

T.37 fax relay

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

T.38 fax relay 1



Yes

Yes

Yes

Yes

Yes

SIP features 1  2

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

MGCP features 1  3

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

Modem pass through over VoIP 1

12.2(4)XM

Yes

Yes

Yes

Yes

Yes

1 Release 12.2(4)XM and above do not support this feature on Cisco 1760 routers.

2 For a list of the SIP features, see Table 2, Footnote 1

3 For a list of the MGCP features, see Table 2, Footnote 2


New and Changed Information

The following sections list the new hardware and software features supported by the Cisco 1700 series routers for Release 12.2(4)XM4.

New Software Features in Release 12.2(4)XM

The following sections describe the new software features supported by the Cisco 1700 series routers for Release 12.2(4)XM.

Basic Session Initiation Protocol

Session Initiation Protocol (SIP) is a signaling protocol that has equivalent or greater functionality than H.323, but is significantly less complex. SIP provides enhanced functionality in protocol extensibility, system scalability, personal mobility services, and inter-vendor interoperability. The following basic SIP features are supported by Release 12.2(4)XM on all digital and analog interfaces:

User agent (UA) functionality in accordance with RFC2543, with limited compliance.

Real Time Transport Protocol (RTP) and Real Time Streaming Protocol (RTSP) for media transport.

Support for g711, g729a, g726r32 and g723r63 data conversion (codecs).

Signaling using both Transmission Control Protocol (TCP) and User Datagram Protocol (UDP).

Support for UDP multicast IP addresses to use the SIP REGISTER method.

Network security through authentication, authorization, and accounting (AAA).

Call Admission Control for H.323 VoIP Gateways

Release 12.2(4)XM supports the call admission control (CAC) for H.323 VoIP gateways feature with the following characteristics:

CAC based on local resources

Advanced voice busy out (AVBO)

Public switched telephone network (PSTN) fallback

You can configure the congestion threshold and the call treatment (that is, how a call should be treated when local resources are not available to handle the call). Two call-treatment action types are available: system denial using AVBO (which "busyouts" incoming calls) or per-call denial. Per-call denial treatment choices are as follows:

Time division multiplexing (TDM) hairpin—Redirects the calls through the Plain Old Telephone Service (POTS) dial peer.

Reject—Disconnects the call.

Play message or tone—Plays a configured message or tone.

If an interface-based resource is not available to admit the call, the call is dropped from the session protocol (such as H.323). If an IP network is congested and a POTS dialpeer is configured, a call can be routed through the PSTN network or to an alternate IP destination.


Note The PSTN fallback does not ensure that a VoIP call that proceeds over the IP network is protected from the effects of congestion. This functionality is handled by other QoS mechanisms such as IP RTP priority and low latency queuing (LLQ).


For additional information about busyout, the call-denial aspects of this feature, and the PSTN fallback, see the following publications, respectively. Point your web browser to CCO and click the following paths:

Advanced Voicebusyout

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2:
New Feature Documentation: New Features in 12.2-Based Limited Lifetime Releases: New  Features in 12.2 X Releases: New Features in Release 12.2(2)XA: Advanced Voice Busyout

Call Admission Control Based on CPU Utilization

Cisco Product Documentation: Access Servers and Access Routers: Access Servers:
Cisco AS5400: Configuration documents for Cisco AS5400: Configuring selected Cisco IOS  12.1-based software features: Call Admission Control based on CPU Utilization

PSTN Fallback

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
New Feature Documentation: New Features in Release 12.1 T: New Features in  Release 12.1(3)T: PSTN Fallback


Note The call admission control for H.323 VoIP gateways feature was released previous to Release 12.2(4)XM on some other Cisco routers and access servers. Release 12.2(4)XM introduces the feature on Cisco 1700 series routers.


Call Transfer Capabilities Using the Refer Method

The Call Transfer Capabilities Using the Refer Method feature provide call transfer capabilities that supplement the Bye and Also methods implemented on SIP gateways. Call transfer allows a wide variety of decentralized multiparty call operations. These operations form the basis for third-party call control and are important features for VoIP and SIP. Call transfer also enables conference calls to transition smoothly between multiple point-to-point links and IP level multicasting.

For additional information about the following components of transfer functionality, see the online-only document Call Transfer Capabilities Using the Refer Method:

Refer Method

Refer-To Header

Referred-By Header

Notify Method

Using the Refer Method to Achieve Call Transfer

Blind Transfer

Attended Transfer

To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2:
New Feature Documentation: New Features in 12.2-Based Limited Lifetime Releases: New  Features in 12.2 X Releases: New Features in Release 12.2 XB: New Features in Release 12.2(2)XBCall Transfer Capabilities Using the Refer Method


Note The Call Transfer Capabilities Using the Refer Method feature was released previous to Release 12.2(4)XM on some other Cisco routers and access servers. Release 12.2(4)XM introduces the feature on Cisco 1700 series routers.


Configurable PSTN Cause Code to SIP Response Mapping

For calls to be established between a SIP network and a PSTN network, the two networks must interoperate. The PSTN cause codes indicate the reasons for a PSTN call failure or completion. One aspect of SIP-network and PSTN-network interoperation is the mapping of these PSTN cause codes to SIP status codes or events and the mapping of SIP status codes or events to PSTN cause codes.

The SIP and PSTN networks have standard or default interoperation mappings. Using the Configurable PSTN Cause Code to SIP Response Mapping feature, you can customize the SIP-user-agent software to override the default mappings and configure specific map settings.

Any SIP status code can be mapped to any PSTN cause code, or vice versa. When customized, the settings can be stored in the NVRAM and are restored automatically on bootup.

SIP maps all possible Integrated Services Digital Network (ISDN) cause codes to SIP Error response codes. There is a one-to-one mapping between SIP Response codes and PSTN cause codes. Event mapping tables showing the standard or default mappings between SIP and PSTN are provided in the publication Configurable PSTN Cause Code to SIP Response Mapping.

To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2:
New Feature Documentation: New Features in 12.2-Based Limited Lifetime Releases: New  Features in 12.2 X Releases: New Features in Release 12.2 XB: New Features in Release 12.2(2)XB Configurable PSTN Cause Code to SIP Response Mapping


Note The Configurable PSTN Cause Code to SIP Response Mapping feature was released previous to Release 12.2(4)XM on some other Cisco routers and access servers. Release 12.2(4)XM introduces the feature on Cisco 1700 series routers.


DTMF Relay for SIP calls Using Named Telephone Events

The dual tone multifrequency (DTMF) Relay using named telephone event (NTE) feature adds support for relaying DTMF tones and hookflash events in SIP on Cisco VoIP gateways.


Note The DTMF Relay using NTE feature is implemented for SIP only.


Using NTE to relay DTMF tones provides a standardized means of transporting DTMF tones in RTP packets according to section 3 of RFC 2833, RTP Payload for DTMF Digits, Telephony Tones and Telephony Signals, developed by the Internet Engineering Task Force (IETF) Audio/Video Transport (AVT) working group. RFC 2833 defines formats of NTE RTP packets used to transport DTMF digits, hookflash, and other telephony events between two peer endpoints.

The DTMF tones are generated when a button is pressed on a touch-tone phone. When the tone is generated, it is compressed, transported to the other party, and decompressed. If a low-bandwidth codec, such as a G.729 or G.723, is used without a DTMF relay method, the tone might be distorted during compression and decompression.

The DTMF-Relay-using-NTE feature allows SIP phones calling voice mail or other Interactive Voice Response (IVR) systems to relay DTMF tones instead of relaying the tones using Cisco Proprietary RTP or transparently in band. Additionally, this feature prevents the distortion of DTMF tones if the RTP session uses a low bit-rate codec, because tones are passed in NTE packets and are not compressed using the default codec.

When using the DTMF-Relay-using-NTE feature, endpoints can perform per-call negotiation of the DTMF relay method. During call setup, the calling and called parties negotiate to choose the DTMF relay mode. They also negotiate to determine the payload type value for the NTE RTP packets.

In a SIP call, the gateway forms a session description protocol (SDP) message that indicates:

Whether or not NTP is to be used

Which events are to be sent using NTE

The NTE payload type value

The DTMF-Relay-using-NTE feature provides support for hookflash, using in-band and out-of-band modes. When using in-band mode, the gateway relays the hookflash without notifying the application and the default session application and any IVR scripts do not receive the hookflash. When using out-of-band mode, the gateway reports the hookflash to the application and the application can relay the hookflash to the next call leg.


Note The DTMF-Relay-using-NTE feature does not support hookflash generation for advanced features such as call waiting and conferencing.


G.728 - CODEC Support on Cisco 1750 and 1751 Routers

Support for the G.728-codec feature on Cisco 1750 and 1750 routers enables the coding of speech at 16 kbps. Codec negotiation involves two phases: a H.245 capability exchange phase and a call establishment phase. Codec negotiation allows a router to offer several codecs during the H.245 capability exchange phase and to ultimately settle on a single common codec during the call establishment phase. Offering several codecs increases the probability of establishing a connection because there is a greater chance of overlapping voice capabilities between endpoints.

Codec negotiation allows a means to specify a prioritized list of codecs associated with a dial peer. During the call establishment phase, the router uses the highest priority codec from the list the router has in common with the remote endpoint. The router also adjusts to the codec selected by the remote endpoint, so a common codec is established for both the receive and the send voice directions.

Codecs have the following characteristics:

Number of voice data bytes per frame: 10 to 240

Default number of data bytes per frame: 10

Bit Rate: 16 kbps

Interactive Voice Response Version 2.0 on VoIP Gateways

The IVR feature consists of simple voice prompting and digit collection to gather caller information for authenticating the user and identifying the destination. You can assign IVR applications to specific ports or invoke them on the basis of the called number; that is, the dialed number identification service (DNIS). An IP public switched telephone network gateway can have several IVR applications to accommodate many different gateway services, and you can customize the IVR applications to present different interfaces to the various callers.

The IVR systems provide information in the form of recorded messages over telephone lines in response to user input in the form of spoken words, or more commonly DTMF signalling. For example, when you make a call with a debit card, an IVR application prompts you to enter a specific type of information, such as an account number. After playing the voice prompt, the IVR application collects the predetermined number of touch tones and then places the call to the destination phone or system.

The IVR uses Tool Command Language (TCL) scripts to gather information and to process accounting and billing. For example, a TCL IVR script plays when a caller receives a voice-prompt instruction to enter a specific type of information, such as a personal identification number (PIN). After playing the voice prompt, the TCL IVR application collects the predetermined number of touch tones and sends the collected information to an external server for user authentication and authorization.

The TCL IVR Version 2.0 on the Cisco 1750 and Cisco 1751 routers consists of the following elements:

RTSP client implementation

TCL IVR prompt playout and digit collection on IP call legs

New TCL verbs to utilize RTSP scripting features

IVR application MIB

This feature provides the following capabilities:

Adds scalability and enables TCL IVR scripting functionality on VoIP call legs.

Reduces the CPU load and saves router memory because no packetization is involved.

Supports RTSP to enable VoIP gateways to play messages from RTSP-compliant announcement servers and voice mail servers.

Allows larger prompts to be played.

Provides support for the use of an external audio server.

Supports a robust IVR script checking mechanism when a new script is loaded.

Provides backward-compatible support for TCL IVR 1.0 scripts.

ISDN Progress Indicator Support for SIP Using 183 Session Progress

This feature provides support for handling inband treatments, such as call progress tones and announcements, when SIP is the session protocol for establishing call connections. The feature ensures the correct establishment of the media stream through the SIP network to allow the successful transport of inband treatments, which might ingress from a PSTN node on a SIP gateway or egress to a PSTN node. The feature also allows VoIP calls using SIP to provide inband call treatment such as ringback tones, announcements when interworking with ISDN and channel associated signaling (CAS) PSTN networks.

Release 12.2(4)XM supports SIP 183 Session Progress messages, which facilitate better call treatment for SIP VoIP calls when interworking with PSTN networks. The introduction of the 183 Session Progress message allows a called user agent to suppress local alerting from the calling user agent, and to play a tone or announcement during a preliminary call session, before the full SIP session is set up. This functionality enables the calling party to be notified of the status of the call without being charged for the preliminary portion of the call. A new Session header in the 183 Session Progress message controls whether or not the called user agent plays a tone or announcement for the calling party. The 183 Session Progress message is supported by default and does not require any special configuration.

Layer 2 Class of Service Matching and Marking

The matching and marking of layer 2 class of service (COS) bits to the Differentiated Services Codepoint (DSCP) bits in the IP header and vice versa is supported by Release 12.2(4)XM on Cisco 1700 series routers. Through IEEE 802.1q trunking support, WAN routers can trunk the separate VLANs from Ethernet switch. Ethernet switches use separate VLANs for voice and data. User priority bits in the 802.1p portion of the 802.1q standard header provide prioritization in Ethernet switches. Cisco 1750 and 1751 routers support both 802.1p and 802.1q VLAN trunking.

Prerequisites

The following configuration tasks must be completed before a Cisco 1700 series router can support the layer 2 COS matching and marking feature:


Step 1 Install the required IOS software version on the router.

Step 2 Enable IP routing.

Step 3 Configure the router for VLAN.


Configuring the IEEE 802.1p Feature

To configure Cisco 1700 series routers to support the Cisco IOS Layer 2 COS matching and marking feature, use the following commands, beginning in global configuration mode:

Step
Command
Task

1.

router(config)# class-map [match-all|match-any]
class-map-name

Configure the QoS class map. To verify the class-map configuration, enter the command show class-map class-map-name.

2.

router(config-cmap)# match [ip dscp|cos]
[differentiated_services_codepoint_values|
class-of-service_values]

Configure the classification criteria.

Up to 8 differentiated services codepoint values or 4 class-of-service values can be entered.

3.

router(config-cmap)# description description_of_the_
class-map

Provide the class-map description.

4.

router(config-cmap)# rename new class-map name

Rename the class-map.

5.

router(config)# policy-map policy-map name

Configure the QoS Policy Map. To verify the policy-map configuration, enter the command show policy-map policy-map-name/interface.

6.

router(config-pmap)# class class-map_name

Configure the policy criteria. The class_map_name should be one of the names used in Step 1 or Step 4.

7.

router(config-pmap)# description description_of_the_
policy-map

Enter the Policy-Map description.

8.

router(config-pmap)# rename new_policy-map_name

Rename the policy-map.

9.

router(config-pmap-c)# set [cos|ip dscp]
[cos_value|services_codepoint_value]

Set the QoS values.

10.

router(config)# interface [FastEthernet|Ethernet]
port number.sub-interface number

Configure the Ethernet interface to perform the Layer 2 COS matching and marking.

11.

router(config-subif)# encapsulation [dot1Q]
[IEEE_802.1Q_VLAN_ID ]

Set the encapsulation type for the interface configured in Step 10.

12.

router(config-subif)# ip address 1.9.85.153
255.255.0.0

Configure the IP address and its network mark.

13.

router(config-subif)# service-policy
[input|output|history] policy-map_name

Configure the QoS service policy. The policy_map_name should be one of the names used in Step 5 or Step 8.

Configuration Example

The following example shows the configuration of the 802.1p feature on a Cisco 1751 router. This configuration attempts to match DSCP 8 to COS 2. Note the configuration of the class-map, policy-map, and QoS service policy.

Router_1751#sh run
Building configuration...

Current configuration : 1078 bytes
!
version 12.2
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname Router_1751
!
!
memory-size iomem 25
mmi polling-interval 60
no mmi auto-configure
no mmi pvc
mmi snmp-timeout 180
ip subnet-zero
!
!
ip dhcp pool vespa
   network 192.168.1.0 255.255.255.0
   default-router 192.168.1.1
   option 150 ip 192.168.1.1
!
ip cef
vpdn enable
!
class-map match-all qos-test
  match ip dscp 8
!
!
policy-map 8021p-set
  class qos-test
   set cos 2
!
!
interface FastEthernet0/0
 no ip address
 speed auto
!
interface FastEthernet0/0.1
encapsulation dot1Q 256
 ip address 1.9.85.153 255.255.0.0
 service-policy output 8021p-set
!
interface Serial1/0
 ip address 3.0.0.3 255.0.0.0
 no keepalive
!
interface Serial1/1
 no ip address
 shutdown
!
ip default-gateway 1.8.0.1
ip classless
ip route 1.9.0.0 255.255.0.0 FastEthernet0
ip route 223.255.254.254 255.255.255.255 1.8.0.1
no ip http server
ip pim bidir-enable
!
!
tftp-server flash:SEPDEFAULT.cnf
!
trunk group 650
 hunt-scheme round-robin
!
line con 0
line aux 0
line vty 0 4
 login
line vty 5 15
 login
!
end

MGCP

The Media Gateway Control Protocol (MGCP) is a device control protocol developed within the IETF which provides call control elements (Softswitches or Call Agents) for controlling Media Gateways (MGs) in a packet telephony system. In this master-and-slave protocol model, the Call Agents are external to the MGs and the gateways execute commands sent by the Call Agents. The MGCP does not define a mechanism for synchronizing Call Agents; the protocol assumes that the commands the Call Agents send to the gateways under their control are synchronized and coherent. The MGCP is not a standard and is currently in version 1.0 as an RFC.

For a description of the MGCP model and a definition of MGCP 1.0, see the publication MGCP 1.0  Including NCS 1.0 and TGCP 1.0 Profiles.  To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2:
New Feature Documentation: New Features in Release 12.2T: New Features in Release 12.2(4)T MGCP 1.0 Including NCS 1.0 and TGCP 1.0 Profiles


Note The MGCP model and MGCP 1.0 were released previous to Release 12.2(4)XM on some other Cisco routers and access servers. Release 12.2(4)XM introduces these features on Cisco 1700 series routers.


MGCP 1.0

The MGCP 1.0 Profile feature implements the MGCP 1.0 (RFC 2705) protocol on supported Cisco media gateways. The feature is backward-compatible with MGCP 0.1, Simple Gateway Control Protocol (SGCP) 1.1, and SGCP 1.5.

MGCP-Based Fax (T.38) and DTMF Relay

The MGCP-Based Fax (T.38) and DTMF Relay feature provides capabilities on Cisco IOS voice gateways to reliably transmit fax and DTMF in an MGCP network. The feature enhances the existing proprietary DTMF and fax pass-through implementations by supporting RFC2833 and International Telegraph Union-T (ITU-T) T.38 standards, respectively. The T.38 standard is a real-time, Group 3, Fax-over-IP standard, which enhances the reliability of fax transmissions and reduces bandwidth requirements.

Support for RFC 2833 provides a standardized method of DTMF transmission, based on telephony events. The RFC 2833 facilitates interoperability with third-party platforms including, but not limited to: voice mail, unified messaging, voice gateways, and media servers.

MGCP Basic Class and Operator Services

The MGCP basic class and operator services (BCOS) are a set of calling features, sometimes called "custom calling" features, that use MGCP to transmit voice, video, and data over the IP network. These features are usually found in circuit-based networks. MGCP BCOS brings them to the Cisco IOS gateways on packet-based networks.

The following MGCP BCOS features are available on RGWs:

Distinctive power ring

Various tones and rings

Visual Message Waiting Indicator

Caller ID (Caller ID Type 1)

Caller ID with Call Waiting (Caller ID Type 2)

Distinctive Call Waiting Tone

Message Waiting Tone

Off-Hook Warning Tone

Three-Way Calling

xGCP support for the following codecs: G.711, G.723, G.726, G.729,G.729a and G.728


Caution Cisco 1751 routers do not support Network-based Call Signaling (NCS) 1.0, the PacketCable profile of MGCP 1.0 for residential gateways (RGWs) or Trunking Gateway Control Protocol (TGCP) 1.0, the PacketCable profile of MGCP 1.0 for trunking gateways (TGWs).

MGCP VoIP Call Admission Control

The MGCP VoIP CAC feature enables gateways managed by Call Agents to identify and gracefully refuse calls that are susceptible to poor voice quality. Poor voice quality on an MGCP voice network can result from the following sources:

Transmission artifacts such as echo

The use of low quality codecs

Network congestion and delay

Overloaded gateways

The first two causes of poor voice quality are overcome by the use of echo cancellation and better codec selection. The last two causes are addressed by the MGCP VoIP CAC feature, which ensures gateway and network resource availability. The MGCP VoIP CAC feature disallows calls when resources are above configured thresholds and reserves guaranteed bandwidth throughout the network for each completed call.

MGCP VoIP CAC has three components for improving voice quality and reliability:

System Resource Check (SRC) CAC—Evaluates memory and call resources local to the gateway. It is supported on MGCP 1.0 and MGCP 0.1.

Resource Reservation Protocol (RSVP) CAC—Surveys bandwidth availability on the network, reports the results of the reservation request to the call agent, and reserves bandwidth across IP networks using RSVP. Trigger thresholds are configurable on the gateway. RSVP CAC is supported on MGCP 1.0 and MGCP 0.1.

Cisco Service Assurance Agent (SA Agent) CAC—Uses Response Time Reporter (RTR) to appraise network congestion conditions. It is supported on MGCP 1.0 only.


Note SA Agent was called RTR in earlier Cisco IOS software releases.


If all three CAC types are configured on a gateway, the gateway checks resources in the following order:

1. SRC CAC

2. RSVP CAC

3. SA Agent CAC

If any resource check fails, the call fails and no further checks are performed. When the call fails, the gateway refuses to accept it.


Note The MGCP VoIP CAC feature is not supported on the NCS 1.0 and TGCP 1.0 profiles of MGCP 1.0.


Modem Passthrough over VoIP

The modem passthrough over VoIP feature provides the transport of modem signals through a packet network by using pulse code modulation (PCM) encoded packets. The Modem Passthrough over VoIP feature performs the following functions:

Represses processing functions like compression, echo cancellation, high-pass filter, and voice activity detection (VAD).

Issues redundant packets to protect against random packet drops.

Provides static jitter buffers of 200 milliseconds to protect against clock skew.

Discriminates modem signals from voice and fax signals, indicating the detection of the modem signal across the connection, and placing the connection in a state that transports the signal across the network with the least amount of distortion.

Reliably maintains a modem connection across the packet network for a long duration under normal network conditions.

For additional information, see the Modem Passthrough over Voice over IP publication. To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
New Feature Documentation: New Features in Release 12.1 T: New Features in Release 12.1(3)T Modem Passthrough over Voice over IP


Note The Modem Passthrough over VoIP feature was released previous to Release 12.2(4)XM on some other Cisco routers and access servers. Release 12.2(4)XM introduces the feature on Cisco 1700 series routers.


NAT Support for SIP

Release 12.2(4)XM2 supports the ability to deploy Network Address Translation (NAT) between VoIP solutions that are based on the SIP. The SIP is an application-layer signaling protocol for creating and controlling multimedia sessions with two or more participants and a client-server protocol transported over TCP or UDP. An Application Layer Gateway (ALG) with NAT enables the SIP. The messages in the protocol might have IP addresses embedded in the packet payload. If a message passes through a router configured with NAT, the embedded information must be translated and encoded back to the packet.


Note Note: NAT only translates embedded IP version 4 addresses.


In Release 12.2(4)XM2 the new option sip is available for the command debug ip nat. When the sip debug option is on, the router displays messages related to the NAT processing of SIP messages:

debug ip nat [ ACL | detailed | h323 | sip | pptp ]

By default, NAT expects SIP messages only on port 5060 (TCP and UDP). To configure more ports, use the following command:

ip nat register port port_number protocol sip [ tcp | udp ]

RFC2782 Compliance (Style of DNS SRV Queries)

SIP on Cisco VoIP gateways uses a Domain Name System Server (DNS SRV) query to determine the IP address of the user endpoint. The query string has a prefix in the form of "protocol.transport." and is attached to the fully qualified domain names (FQDNs) of the next hop SIP server. This prefix style, from RFC 2052, has always been available; however, with this release, a second style is also available.

The second style is in compliance with RFC 2782, and prepends the protocol label with an underscore "_"; as in "_protocol._transport.". The addition of the underscore reduces the risk of the same name being used for unrelated purposes. The form compliant with RFC 2782 is the default style. Use the command srv version to configure the DNS SRV feature.

SIP Diversion Header Implementation for Redirecting Number

The SIP Diversion Header Implementation for Redirecting Number feature provides support for a new SIP header field; Call Control (CC)-Diversion. The CC-Diversion header field enables the SIP gateway to pass call control redirecting information during the call setup. Call control redirection is the redirection of a call based on a subscriber service such as call forwarding or call deflection. Call redirection information is information that is typically used for Unified Messaging and voice mail services to identify the recipient of a message. Call control rediversion information can also be used to support applications such as automatic call distribution and enhanced telephony features such as Do Not Disturb and Caller ID.

If the CC-Diversion header field is generated by the SIP gateway during the call process, the header field is based on the contents of the Redirecting Number Information Element (IE) in the ISDN Setup message. In addition, information such as the reason the call was redirected is included in the CC-Diversion header field.

See the online-only document SIP Diversion Header Implementation for Redirecting Number  for call flow samples of the following types of gateway-to-gateway calls:

Redirection with CC-diversion

SIP 3xx redirection response after receipt of a SIP 18x information response

To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
Related Documentation: Session Initiation Protocol Gateway Call Flows: SIP Gateway Support  for  Third Party Call Control


Note The SIP Diversion Header Implementation for Redirecting Number feature was released previous to Release 12.2(4)XM2 on some other Cisco routers and access servers. Release 12.2(4)XM2 introduces the feature on Cisco 1700 series routers.


SIP for VoIP Enhancements

VoIP currently implements the ITU's H.323 specification within Internet Telephony Gateways (ITGs) to signal voice call setup. SIP is a new protocol developed by the IETF for multimedia conferencing over IP. SIP features are compliant with IETF RFC 2543, SIP: Session Initiation Protocol, published in March 1999. The Cisco SIP functionality in Release 12.2(4)XM2 enables Cisco 1700 series routers to signal the setup of voice and multimedia calls over IP networks.

Release 12.2(4)XM2 supports SIP feature enhancements on Cisco 1700 series routers, which enable SIP gateways with the following functionality:

Enables Cisco voice-enabled platforms to provide RFC2543 compliant user-agent client gateways.

Supports proxy-routed calls.

Redirects an unanswered call to another SIP gateway or SIP-enabled IP phone.

Allows end users to place calls on hold.

Hides the identity of the calling party, based on the setting of the ISDN presentation indicator.

Additionally, the following SIP for VoIP feature enhancements are supported by Release 12.2(4)XM:

SIP mid-call changes of SDP sessions using an INVITE with changed SDP.

Enhanced SIP stack to support new routing headers (including the headers: Also, Contact, Expires, Max-Forwards, Record-Route, Requested-By, Route, Timestamp, and Unsupported).

Call Hold and Call Transfer.

Session Progress Messages 180, 183, and 184, with inband alerts.

Enhanced PSTN-to-SIP Event and Cause-Code Mapping.

UDP socket layer enhancements to support connected sockets; enabling Internet Control Message Protocol (ICMP) network notifications to be used to identify destinations rather than relying only on SIP timers.

Interoperation with the Amteva UCS Messaging platform.

IPSec in SIP security.

SIP Gateway Support for Bind Command

In previous releases of Cisco IOS software, the source address of a packet going out of the gateway was never deterministic. That is, the session protocols and VoIP layers always depended on the IP layer to give the best local address. The best local address was then used as the source address (the address showing where the SIP request came from) for signaling and media packets. Using this nondeterministic address occasionally caused confusion for firewall applications, as a firewall could not be configured with an exact address and would take action on several different source address packets.

However, the bind interface command allows you to configure the source IP address of signaling and media packets to a specific interface's IP address. Thus, the address that goes out on the packet is bound to the IP address of the interface specified with the bind command. Packets that are not destined to the bound address are discarded. When you do not want to specify a bind address, or if the interface is down, the IP layer still provides the best local address.

The bind command performs different functions based on the state of the interface:

Interface State
Result Using Bind Command

Shutdown

With or without active calls

The TCP and UDP socket listeners are initially closed. (Socket listeners receive datagrams addressed to the socket.) The sockets are then opened to listen to any IP address. If the outgoing gateway has the bind command enabled and has an active call, the call becomes a one-way call with media flowing from the outgoing gateway to the terminating gateway.

No Shutdown

No Active Calls

The TCP and UDP socket listeners are initially closed. The sockets are then opened and bound to the IP address that are set by the bind command. The sockets accept packets destined for the bound address only.

No Shutdown

Active Calls

The TCP and UDP socket listeners are initially closed. The sockets are then opened to listen to any IP address.

Bound interface IP address is removed

The TCP and UDP socket listeners are initially closed. The sockets are then opened to listen to any address, because the IP address has been removed. A message is printed stating that the IP address has been deleted from a SIP-bound interface. If the command bind is enabled on an outgoing gateway and the gateway has an active call, the call becomes a one-way call, with media flowing from the outgoing gateway to the terminating gateway.

The physical cable is pulled on the bound port, or

the Interface Layer goes down

The TCP and UDP socket listeners are initially closed. The sockets are then opened and bound to listen to any address. When the pulled cable is replaced, the result is as documented for no shutdown interfaces.

A bind interface is shutdown, or

its IP address is changed, or

the physical cable is pulled while SIP calls are active

The call becomes a one-way call with media flowing in only one direction. Media flows from the gateway where the change or shutdown took place, to the gateway where no change occurred. Thus, the gateway with the status change no longer receives media. The call is then disconnected, but the disconnected message is not understood by the gateway with the status change, and the call is still assumed to be active.



Note If there are active calls and the command bind is issued for the first time or issued while another bind command is in effect, the bind command does not take effect. A message is printed to remind you that there are active calls and the bind command changes cannot take effect.


SIP Gateway Support for Third Party Call Control

Release 12.2(4)XM2 supports the SIP Gateway Support for Third-Party Call Control feature, which enables one endpoint (for example, a call controller) to create, modify, or terminate calls between other endpoints via delayed media negotiation. In delayed media negotiation, the SDP information is not completely advertised in the initial call setup. Third-party call control is often used for conferencing and operator services (creating a call connecting two parties together).

Release 12.2(4)XM2 also supports the following functionality:

Negotiation enhancements for codec

Enhancements in the SDP parser and builder on SIP gateways

Endpoints specified as FQDNs in the SDP

Gateways can route on an FQDN in addition to routing on an IP address. When the SIP gateway receives a SIP message containing a FQDN in the c= SDP field, it parses the c= field of the SDP body, determines that it is a FQDN and resolves the next hop via a DNS query.

SIP Gateway-to-SIP Gateway Call—Call Setup with Delayed Media via Third-Party Call Controller

SIP IP Phone-to-SIP Gateway—Call Setup and Call Hold with Delayed Media

SIP Gateway-to-One Call—Call Setup with Voice Mail

SIP Gateway-to-SIP Gateway—Call Setup using a FQDN and Delayed Media

To access this document, point your web browser to CCO, and click the following path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.1:
Related Documentation: Session Initiation Protocol Gateway Call Flows: SIP Gateway Support  for  Third Party Call Control


Note The SIP Gateway Support for Third-Party Call Control feature was released previous to Release 12.2(4)XM2 on some other Cisco routers and access servers. Release 12.2(4)XM2 introduces the feature on Cisco 1700 series routers.


SIP Gateway Support of RSVP and "tel" URL

The SIP Gateway Support of RSVP and Telephone Uniform Resource Locators (TEL URL) feature provides the following new headers:

Content-Disposition

Supported

Unsupported

RSeq

RSck

The feature also supports the following SIP enhancements:

RSVP—The coordination of SIP call signaling and RSVP resource management. A QoS module is provided that acts as a broker between the VoIP Service Provider Interfaces (SPIs) and the Cisco IOS RSVP subsystem. The QoS module enables the VoIP SPIs to initiate resource reservation, modify parameters of an existing reservation, and clean up the reserved resources. The QoS module then communicates the results of the operation to the RSVP subsystem.

Telephone URL Format in SIP Messages—Support for TEL URL. The TEL URL formats describe voice call connections, including the originator, recipient, and destination. The TEL URLs enable a gateway to accept TEL calls sent through the Internet and to generate TEL URLs in the request line of outgoing INVITEs requests.

Interaction with Forking Proxies—Call forking enables the terminating gateway to handle multiple requests and enables the originating gateway to handle multiple provisional responses for the same call. Interaction with forking proxies applies to gateways acting as a user agent client (UAC), and takes place when a user is registered to several different locations.

Reliability of SIP Provisional Responses—SIP reliable provisional responses ensure that media information is exchanged and resource reservation can take place prior to connecting the call. Provisional acknowledgement (PRACK) and conditions met (COMET) are two methods that have been implemented. PRACK allows reliable exchanges of SIP provisional responses between SIP endpoints. COMET indicates if the pre-conditions for a given call or session have been met.

RFC2782 Compliance (Style of DNS SRV Queries)—SIP on Cisco VoIP gateways uses DNS SRV query to determine the IP address of the user endpoint. The query string has a prefix in the form of "protocol.transport.", which is attached to the FQDN of the next hop SIP server. This prefix style, from RFC 2052, has always been available; however, with this release, a second style is also available. The second style is in compliance with RFC 2782, and prepends the protocol label with an underscore "_"; as in "_protocol._transport.". The addition of the underscore reduces the risk for the same name to be used for unrelated purposes. The form compliant with RFC 2782 is the default style. Use the command srv version to configure the DNS SRV feature.

SIP Intra-Gateway Hairpinning

SIP Intra-Gateway Hairpinning—SIP hairpinning is a call routing capability in which an incoming call on a specific gateway is signaled through the IP network and back out the same gateway. This can be a PSTN call routed into the IP network and back out to the PSTN over the same gateway. Similarly, SIP hairpinning can be a call signaled from a line (for example, a telephone line) to the IP network and back out to a line on the same access gateway. With SIP hairpinning, unique gateways for ingress and egress are no longer necessary.

SIP INVITE Request with Malformed Via Header

A SIP INVITE requests a user or service to participate in a session. Each INVITE contains a Via header that indicates the previous transport path of the request and where to send a response.

When an INVITE contains a malformed Via header, the SIP INVITE Request with Malformed Via Header feature provides a response to the malformed request. When a response to a malformed Via field is sent to the source IP address at UDP port 5060 (the IP address where the SIP request originated), a counter, Client Error: Bad Request, also increments. Bad Request is a class 400 response and includes the explanation Malformed Via Field.


Note This feature applies to messages arriving on UDP because the Via header is not used to respond to messages arriving on TCP.


SIP T.38 Fax Relay

The SIP T.38 fax relay feature adds standards-based fax support to SIP and conforms to ITU-T T.38, Procedures for real-time Group 3 facsimile communication over IP networks. The ITU-T standard specifies real-time transmission of faxes between two regular fax terminals over an IP network. Much like a voice call, SIP T.38 fax relay requires call establishment, data transmission, and release signaling.

The following functionality is also included in SIP T.38 fax relay:

Support for Facsimile User Datagram Protocol transport layer (UDPTL)

UDPTL, as defined in ITU-T T.38, is a transport layer that is used on top of UDP. The UDPTL makes the delivery of packets more reliable by providing data redundancy.

Support for QoS

SIP T.38 fax relay supports QoS when establishing T.38 sessions. If the dial peer is already configured for QoS, then the T.38 stream maintains the QoS support. QoS ensures certain bandwidth reservations for calls.

SIP User Agent MIB

The SIP User Agent MIB adds the ability to manage a SIP network via an SNMP-based network management platform.

T.37 Store and Forward Fax

The Store and Forward Fax feature enables Cisco 1700 series routers to transmit and receive faxes across packet-based networks using the H.323 protocol. This feature is an implementation of the RFC 2305 proposed standard from the IETF, which is the same as the T.37 recommendation from the ITU.

Store and Forward Fax supports the following functionality:

Single number access for voicemail and fax access

Sending and receiving faxes to and from Group 3 fax devices

Receiving faxes that are delivered as e-mail attachments

Creating and sending standard e-mail messages to be delivered as faxes to standard Group 3 fax devices

Real-time fax fallback


Caution Before configuring the store and forward fax feature, ensure that VoIP software is installed and functional on the Cisco 1700 series routers.

When configured for fax detection, Cisco 1700 series routers automatically listen to incoming calls to discriminate between voice and fax. The routers then direct the calls to the appropriate application or server.

Fax detection is implemented by configuring a fax detection application and dial peers for fax detection. The fax detection application (a Cisco IVR application) determines whether a call is voice or fax so that the call is routed appropriately. A voice call can be broken into discrete call segments, or call legs, that connect the various intermediate points and end points of a call. Voice technologies use configuration constructs called dial peers to define call legs and to associate various attributes with them. The attributes are used to make routing decisions that provide more flexibility than simply routing by a dialed number.

New Software Features in Release 12.2(4)T

For information regarding the features supported in Cisco IOS Release 12.2 T, refer to the Cross-Platform Release Notes and New Feature Documentation links at the following location on CCO:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios122/122relnt/xprn122t/index.htm

This URL is subject to change without notice. If it changes, point your web browser to CCO, and click the following path:

Service & Support: Technical Documents: Cisco IOS Software: Release 12.2: Release Notes:  Cross-Platform Release Notes (Cisco IOS Release 12.2T)

Limitations

The following sections describe limitations about Cisco IOS Release 12.2(4)XM4 that can apply to the Cisco 1700 series routers. (Also, see the "Caveats" section.)

Commands Not Supported on Cisco 1750 and 1751 Routers

The following command line interface (CLI) commands and functionality are not supported on Cisco 1750 or 1751 routers:

The AVBO commands (Cisco 1750 and 1751 routers do not support T1/E1 CAS and T1/E1 primary rate interface [PRI]):

ds0 busyout

isdn service b_channel

isdn service dsl


CAC commands (Cisco 1750 and 1751 routers do not support T1 CAS):

ds0-group

Fax interface-type modem commands (Cisco 1750 and 1751 routers do not support modem cards). The following associated debug commands are also disabled:

debug text-to-fax

debug tiff reader

debug tiff writer

Features Not Supported on Cisco 1700 Series Routers

Release 12.2(4)XM4 does not support the following features on the Cisco 1700 series routers mentioned below:

Global system for mobile communication over frame relay (GSM-FR) on Cisco 1700 series routers.

NCS 1.0, the PacketCable profile of MGCP 1.0 for RGWs on Cisco 1751 routers.

TGCP 1.0, the PacketCable profile of MGCP 1.0 for TGWs on Cisco 1751 routers.

Features Not Supported on Cisco 1760 Routers

The following features are not supported by Release 12.2(4)XM4 on Cisco 1760 routers:

CAC for VoIP call

DiffServ for voice signaling traffic

G.728 codec support

Modem pass through over VoIP

MGCP features

MGCP 1.0

MGCP based fax (T.38) and DTMF relay

MGCP basic CLASS and operator services

MGCP VoIP call admission control

RTSP enhanced IVR

SIP features

Call transfer capabilities using the refer method

Configurable PSTN cause code to SIP response

Gateway support for bind command

ISDN progress indicator support for SIP using 183 session progress

NAT support for SIP

RFC2782 compliance for DNS SRV

SIP

SIP diversion header implementation for redirecting number

SIP DTMF relay using NTE

SIP for VoIP enhancements

SIP gateway support for third party call control

SIP gateway support of RSVP and "tel" URL

SIP intra-gateway hairpinning

SIP INVITE request with malformed via header

SIP T.38 fax relay

SIP user agent MIB

T.37 fax relay

TCL scripting for IVR


Note SIP and MGCP features are not supported on Cisco 1760 routers.


Functionality Not Supported on Cisco 1750 and 1751 Routers

The following functionality is not supported by Release 12.2(4)XM4 on Cisco 1750 or 1751 routers:

Remote alarm indication (RAI) is not supported because Cisco 1750 series routers do not support T1 CAS.

Soft Busyout is not supported because this functionality is supported only for DS0 and ISDN.

Cisco 1751 routers do not support the following PacketCable profiles of MGCP 1.0:

NCS 1.0 for RGWs

TGCP 1.0 for TGWs

Cisco 1751 routers do not support ISDN PRI/CAS; therefore, the following SIP call sequence is also not supported:

ISDN PRI/CAS - SIP Orig. Gateway - SIP Term. Gateway - ISDN PRI/CAS

Important Notes

The following sections contain important notes about Cisco IOS Release 12.2(4)XM4 that can apply to the Cisco 1700 series routers. (Also, see the "Caveats" section.)

"Faxrate 14000" for T.38

T.37 works in conjunction with T.38, which was released for Cisco 1750 and 1751 routers in a release prior to Release 12.2(4)XM. The "faxrate 14000" is now added to T.38.

Fan Operation in Cisco 1700 Series Routers

The fans in some Cisco 1700 series routers stay off until thermally activated. The fans in Cisco 1760 and 1760-V routers are always on.

Flash defaults to Flash:1 on Multipartition Flash

When using a multipartition flash card, the various flash partitions are referred to as "flash:1:", "flash:2:", etc. If you specify only "flash" in a multipartition flash, the parser assumes "flash:1:." For example, if you enter show flash all the parser defaults to "show flash:1: all" and only the flash information for the first partition displays. To see information for all flash partitions, enter show flash ?. This will list all of the valid partitions. Then enter show flash:xx: all on each valid partition.

H.450 Features Supported on Cisco 1750 and 1751 Routers

Previous to Release 12.2(4)XM, H.450 features were not supported on Cisco 1750 and 1751 routers because IVR was not supported. The H.450 features are now supported, as Release 12.2(4)XM supports IVR on Cisco 1750 and 1751 routers.

Layer 2 COS Matching and Marking Feature Configuration Sequence

The class-map, policy-map, and service-policy for the Layer 2 COS matching and marking feature must be configured in the proper sequence. For example, if you change the class-map configuration, you must also update the policy-map and the service-policy. To change the policy-map configuration, you must first update the class-map, then change the policy-map, and finally update the service-policy.

Peak Cell Rate and Sustainable Cell Rate Values

On Cisco 1700 routers, specify the Peak Cell Rate (PCR) and Sustainable Cell Rate (SCR) as multiples of 32 Kbps. Other rates are treated as the next lower value of a multiple of 32. For example, an entered PCR value of 150 is considered 128.

Using the boot flash Command

Booting a Cisco 1700 series router with the commands boot flash or boot system flash results in unpredictable behavior. To work around this problem, be sure to enter a colon (:) following both commands (for example, boot flash: or boot system flash:.)

Caveats

Caveats describe unexpected behavior or defects in Cisco IOS software releases. Severity 1 caveats are the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious of these three severity levels.

All caveats in Release 12.2 T are also in Release 12.2(4)XM4. For information on caveats in Cisco IOS Release 12.2 T, refer to the Caveats for Cisco IOS Release 12.2 T document. For information on caveats in Cisco IOS Release 12.2, refer to the Caveats for Cisco IOS Release 12.2 document. These documents list severity 1 and 2 caveats, and are located on CCO and the Documentation CD-ROM.


Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in toCisco.com and click Service & Support: Technical Assistance Center: Tool Index: Bug Toolkit. Another option is to go to http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.


Caveats - Releases 12.2(4)XM2, 12.2(4)XM3, and 12.2(4)XM4

There are no new or resolved caveats in software Releases 12.2(4)XM2, 12.2(4)XM3, or 12.2(4)XM4.

Resolved Caveats - Release 12.2(4)XM1

This section describes unexpected behavior in software Release 12.2(4)XM that is fixed in Release 12.2(4)XM1.

Management

CSCdv65207

The command-line interface (CLI) does not prompt for the erase keyword when the copy [ /erase] source-url destination-url EXEC command is entered. This behavior does not allow a file system to be erased using the copy [ /erase] source-url destination-url EXEC command. To work around this problem, enter the erase filesystem: command before entering the copy EXEC command.

CSCdu86498

When AAA Authentication is enabled and default group RADIUS is configured, you are prompted for a user-name and password. Previous Cisco IOS releases only prompted you for "enable password." To work around this problem, enter any character(s) at the user-name prompt and then enter the enable password.

Release 12.2(4)XM - Caveats

This section describes possibly unexpected behavior by Release 12.2(4)XM. Only severity 1 through 3 caveats are included.

Miscellaneous Caveats

CSCdu53872

When a fax machine sends high-density pages through Cisco 1700 series routers, the required transmission time can be too long, causing a time out and breaking the connection. To work around this problem, decrease the fax-page density.

CSCdu63909

Offramp does not work with FXO cards. When mail is sent from a mail server to an Offramp gateway, a connection is established but is then disconnected without receiving a fax.

CSCdv42255

In global level configuration mode, the "mgcp" keyword initiates MGCP processes. However, if the voice port associated with "mgcpapp" is in an active (off-hook) state and a system administrator issues the global command no mgcp during an unconfigure stage, Cisco 1700 series routers do not stop MGCP processes. To shut down MGCP processes, force the voice-port to the inactive (on-hook) state.

CSCdv91375

When SIP messages must be mapped to ISDN SETUP or CONNECT messages, the corresponding PI value is missing from the messages. To work around this issue, explicitly set the command progress_ind in the corresponding dial-peer, as follows:

progress_ind setup enable 1
progress_ind connect enable 2

CSCdw05578

When the call threshold is set to a maximum of one call, many H.323 calls can be made but MGCP calls fail and the error message "403 endpoint does not have resources" is displayed. To work around this issue, set the call thresholds individually for H.323 calls and MGCP calls.

CSCdw09722

The 802.1p matching and marking of layer 2 COS occurs when the command ip cef is enabled on Cisco 1700 series routers. After configuring service policies for an interface and disabling the command ip cef, the feature works properly and packets are marked with the configured COS value.

CSCdw11276

The 802.1p matching and marking of layer 2 COS CLI and MIB have differing sizes for the policy name and the policy description.

SIP-Related Caveats

CSCdw04200

When an INVITE is sent to a router without SDP, the router responds with a 183 message, and a subsequent re-INVITE is sent to the router, codec negotiation happens but the command show voice dsp is not updated with the new codec. To work around this problem, if the initial INVITE is sent without SDP, send the SDP using the ACK.

MGCP-Related Caveats

CSCdv79984

The redirection of event notification messages to a new Call Agent by way of "N:new-ca-ip-address:port" in a Call Agent command fails. The failure occurs only for events configured as "persistent events" with the command mgcp persistent <event-name> on Cisco 1700 series routers. The event notifications are instead only sent to the original Call Agent.

CSCdw13666

When the "S: vmwi(-)" parameter is sent in a MGCP message to an endpoint that is off hook, the message LED on the phone stays on after the phone is placed on-hook. To work around this problem, rely on the mail waiting indicator tones instead of the voice mail waiting indicator LED.

CSCdw13706

When the "S: vmwi(+)" parameter is sent to an endpoint that is off-hook and the phone is placed on-hook without making a call, the phone LED does not go on. To work around this problem, rely on the mail waiting indicator tones instead of the voice mail waiting indicator LED.

Related Documentation

The following sections describe the documentation available for the Cisco 1700 series routers. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents. Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.

Use these release notes with the documents listed in the following sections:

Release-Specific Documents

Platform-Specific Documents

Feature Modules

Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Release 12.2 and apply to Release 12.2(4)XM4. They are located on Cisco.com and the Documentation CD-ROM (under the heading Service & Support):

To reach the Release Notes for the Cisco 1700 Series Routers for Cisco IOS  Release 12.2(4)XM,  click this path:

Technical Documents: Cisco IOS Software: Release 12.2: Release Notes: Cisco 1700 Series  Routers: Cisco 1700 Series - Release Notes for Release 12.2(4)XM

To reach the Cross-Platform Release Notes for Cisco IOS Release 12.2 T, click this path:

Technical Documents: Cisco IOS Software: Release 12.2: Release Notes: Cisco IOS  Release 12.2 T

To reach product bulletins, field notices, and other release-specific documents, click this path:

Technical Documents: Product Bulletins

To reach the Caveats for Cisco IOS Release 12.2 and Caveats for Cisco IOS Release 12.2 T  documents, which contain caveats applicable to all platforms for all maintenance releases of Release 12.2, click this path:

Technical Documents: Cisco IOS Software: Release 12.2: Caveats


Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in toCisco.com and click Service & Support: Technical Assistance Center: Tool Index: Bug Toolkit. Another option is to go to http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.


Platform-Specific Documents

Cisco 1710 Routers

These documents are available for the Cisco 1720 router on CCO and the Documentation CD-ROM at Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 1710  Series Routers:

Quick Start Guide for Installing Your Cisco 1710 Security Router

Cisco 1710 Security Router Hardware Installation Guide

Cisco 1710 Security Router Software Configuration Guide

Regulatory Compliance and Safety Information for Cisco 1700 Routers

Cisco 1720 Routers

These documents are available for the Cisco 1720 router on CCO and the Documentation CD-ROM at Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 1720  Series Routers:

Installing Your Cisco 1700 Router Quick Start Guide

Cisco 1720 Series Router Hardware Installation Guide

Cisco 1700 Series Router Software Configuration Guide

Cisco 1720 Series Router Release Notes

Installing and Upgrading the Boot ROM in Cisco 1720 Routers

Cisco 1700 Series (Cisco IOS) Router Release Notes

Configuration Notes for Cisco 1700 Series Routers

WAN Interface Cards Hardware Installation Guide

Cisco 1750 Routers

These documents are available for the Cisco 1750 router on CCO and the Documentation CD-ROM at Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 1750  Series Routers:

Installing Your Cisco 1700 Router Quick Start Guide

Cisco 1750 Series Router Hardware Installation Guide

Cisco 1700 Series Router Software Configuration Guide

Cisco 1750 Series Router Release Notes

Cisco 1750 Router Voice-over-IP quick start guide

Cisco 1750 Voice-over-IP Software Configuration Guide

Cisco 1700 Series (Cisco IOS) Router Release Notes

Configuration Notes for Cisco 1700 Series Routers

WAN Interface Cards Hardware Installation Guide

Cisco 1751 and 1751-V Routers

These documents are available for the Cisco 1751 and 1751-V routers on CCO and the Documentation CD-ROM at Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 1751  Series Routers:

Installing Your Cisco 1700 Router Quick Start Guide

Cisco 1751 Router Hardware Installation Guide

Cisco 1751 Router Software Configuration Guide

Cisco 1700 Series Router Software Configuration Guide

Cisco 1751 Router Hardware Release Notes

Configuring the Voice Interface Card for the Cisco 1751 Router

Installing and Removing Packet Voice/fax DSP Modules

Cisco 1700 Series (Cisco IOS) Router Release Notes

Configuration Notes for Cisco 1700 Series Routers

WAN Interface Cards Hardware Installation Guide

Cisco 1760 and 1760-V Routers

These documents are available for the Cisco 1760 and 1760-V routers on CCO and the Documentation CD-ROM at Technical Documents: Access Servers and Access Routers: Modular Access Routers: Cisco 1760  Series Routers:

Quick Start Guide for Installing Your Cisco 1760 Modular Access Router

Cisco 1760 Modular Access Router Hardware Installation Guide

Cisco 1751 Router Software Configuration Guide

Cisco 1700 Series Router Software Configuration Guide

Configuration Notes for Cisco 1700 Series Routers

Configuring the Voice Interface Card for the Cisco 1751 Router

Installing and Removing Packet Voice/fax DSP Modules

WAN Interface Cards Hardware Installation Guide

Feature Modules

Feature modules describe new features supported by Release 12.2 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference.

As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set. To reach the Release 12.2 feature modules, click this path (under the heading Service & Support): Technical Documents: Cisco IOS Software:  Release 12.2: New Feature Documentation: New Features in 12.2-Based Limited Lifetime  Releases:  New Features in 12.2X Releases

Feature Navigator

Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image. Feature Navigator is available 24 hours a day, 7 days a week.

To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to set up an account.

To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.

Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:

http://www.cisco.com/go/fn

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference. The Cisco IOS software documentation set is available on Cisco.com and on the Documentation CD-ROM (under the heading Service & Support) at:

Technical Documents: Cisco IOS Software: Release 12.2: Configuration Guides and  Command References

Release 12.2 Documentation Set

Table 6 lists the contents of the Cisco IOS Release 12.2 software documentation set, which is available in both electronic and printed form (under the heading Service & Support) on Cisco.com and on the Documentation CD-ROM:

Technical Documents: Cisco IOS Software: Release 12.2


Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.


Table 6 Cisco IOS Release 12.2 Documentation Set

Books
Major Topics

Cisco IOS Configuration Fundamentals Configuration Guide

Cisco IOS Configuration Fundamentals Command Reference

Cisco IOS User Interfaces
File Management
System Management

Cisco IOS Bridging and IBM Networking Configuration Guide

Cisco IOS Bridging and IBM Networking Command Reference, Volume 1 of 2

Cisco IOS Bridging and IBM Networking Command Reference, Volume 2 of 2

Transparent Bridging
SRB
Token Ring Inter-Switch Link
Token Ring Route Switch Module
RSRB
DLSw+
Serial Tunnel and Block Serial Tunnel
LLC2 and SDLC
IBM Network Media Translation
SNA Frame Relay Access
NCIA Client/Server
Airline Product Set
DSPU and SNA Service Point
SNA Switching Services
Cisco Transaction Connection
Cisco Mainframe Channel Connection
CLAW and TCP/IP Offload
CSNA, CMPC, and CMPC+
TN3270 Server

Cisco IOS Dial Technologies Configuration Guide

Cisco IOS Dial Technologies Command Reference

Preparing for Dial Access
Modem and Dial Shelf Configuration and Management
ISDN Configuration
Signaling Configuration
Dial-on-Demand Routing Configuration
Dial Backup Configuration
Dial Related Addressing Service
Virtual Templates, Profiles, and Networks
PPP Configuration
Callback and Bandwidth Allocation Configuration
Dial Access Specialized Features
Dial Access Scenarios

Cisco IOS Interface Configuration Guide

Cisco IOS Interface Command Reference

LAN Interfaces
Serial Interfaces
Logical Interfaces

Cisco IOS IP Configuration Guide

Cisco IOS IP Command Reference, Volume 1 of 3: Addressing and Services

Cisco IOS IP Command Reference, Volume 2 of 3: Routing Protocols

Cisco IOS IP Command Reference, Volume 3 of 3: Multicast

IP Addressing and Services
IP Routing Protocols
IP Multicast

Cisco IOS AppleTalk and Novell IPX Configuration Guide

Cisco IOS AppleTalk and Novell IPX Command Reference

AppleTalk
Novell IPX

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference

Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

Cisco IOS Voice, Video, and Fax Configuration Guide

Cisco IOS Voice, Video, and Fax Command Reference

Voice over IP
Call Control Signaling
Voice over Frame Relay
Voice over ATM
Telephony Applications
Trunk Management
Fax, Video, and Modem Support

Cisco IOS Quality of Service Solutions Configuration Guide

Cisco IOS Quality of Service Solutions Command Reference

Packet Classification
Congestion Management
Congestion Avoidance
Policing and Shaping
Signaling
Link Efficiency Mechanisms

Cisco IOS Security Configuration Guide

Cisco IOS Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options
Supported AV Pairs

Cisco IOS Switching Services Configuration Guide

Cisco IOS Switching Services Command Reference

Cisco IOS Switching Paths
NetFlow Switching
Multiprotocol Label Switching
Multilayer Switching
Multicast Distributed Switching
Virtual LANs
LAN Emulation

Cisco IOS Wide-Area Networking Configuration Guide

Cisco IOS Wide-Area Networking Command Reference

ATM
Broadband Access
Frame Relay
SMDS
X.25 and LAPB

Cisco IOS Mobile Wireless Configuration Guide

Cisco IOS Mobile Wireless Command Reference

General Packet Radio Service

Cisco IOS Terminal Services Configuration Guide

Cisco IOS Terminal Services Command Reference

ARA
LAT
NASI
Telnet
TN3270
XRemote
X.28 PAD
Protocol Translation

Cisco IOS Configuration Guide Master Index

Cisco IOS Command Reference Master Index

Cisco IOS Debug Command Reference

Cisco IOS Software System Error Messages

New Features in 12.2-Based Limited Lifetime Releases

New Features in Release 12.2 T

Release Notes (Release note and caveat documentation for 12.2-based releases and various platforms)




Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

The most current Cisco documentation is available on the World Wide Web at http://www.cisco.com.  Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

Registered Cisco Direct Customers can order Cisco product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco products documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

For your convenience, many documents contain a response card behind the front cover for submitting your comments by mail. Otherwise, you can mail your comments to the following address:

Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

The following sections provide sources for obtaining technical assistance from Cisco Systems.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

Cisco.com registered users who cannot resolve a technical issue by using the TAC online resource can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
