Release Notes for the Cisco 800 series routers and Cisco 820 Series Routers for Cisco IOS Release 12.2(2)XH


February 17, 2002

These release notes for the Cisco 800 Series and Cisco 820 Series routers describe the enhancements provided in Cisco IOS Release 12.2(2)XH2. These release notes are updated as needed. Use these release notes with Cross-Platform Release Notes for Cisco IOS Release 12.2 located on Cisco.com and the Documentation CD-ROM.

For a list of the software caveats that apply to Cisco IOS Release 12.2(2)XH2, see the "Caveats" section and Caveats for Cisco IOS Release 12.2 T. The caveats document is updated for every maintenance release and is located on Cisco.com and the Documentation CD-ROM.

Contents

These release notes discuss the following topics:

System Requirements

New and Changed Information

Important Notes

Caveats

Related Documentation

Obtaining Documentation

Obtaining Technical Assistance

System Requirements

This section describes the system requirements for Release 12.2(2)XH2 and includes the following sections:

Memory Requirements

Hardware Supported

Determining Your Software Release

Upgrading to a New Software Release

Feature Set Tables

Memory Requirements

This section describes the memory requirements for the Cisco IOS feature sets supported by Cisco IOS Release 12.2(2)XH2 on Cisco 800 and Cisco 820 Series Routers.

Table 1 Memory Requirements for the Cisco 800 Series Routers and Cisco 820 Series Routers

Platforms
Image Name
Required Flash Memory
Required DRAM Memory
Runs From

Cisco 801-804 routers

Cisco 800 Series IOS IP

c800-y6-mw

8 MB

4 MB

RAM

Cisco 800 Series IOS IP Plus

c800-sy6-mw

8 MB

8 MB

RAM

Cisco 800 Series IOS IP/FW

c800-oy6-mw

8 MB

4 MB

RAM

Cisco 800 Series IOS IP/FW Plus IPSec 3DES

c800-k9osy6-mw

8 MB

12 MB

RAM

Cisco 800 Series IOS IP/IPX/FW Plus IPSec 3DES

c800-k9nosy6-mw

8 MB

12 MB

RAM

Cisco 805 routers

Cisco 805 Series IOS IP

c805-y6-mw

4 MB

8 MB

RAM

Cisco 805 Series IOS IP Plus

c805-sy6-mw

4 MB

8 MB

RAM

Cisco 805 Series IOS IP/FW

c805-oy6-mw

4 MB

8 MB

RAM

Cisco 805 Series IOS IP/IPX Plus

c805-nsy6-mw

8 MB

8 MB

RAM

Cisco 805 Series IOS IP/FW Plus IPSec 3DES

c805-k9osy6-mw

8 MB

12 MB

RAM

Cisco 805 Series IOS IP/IPX/FW Plus IPSec 3DES

c805-k9nosy6-mw

8 MB

12 MB

RAM

Cisco 820 series routers

Cisco 820 Series IOS IP

c820-y6-mz

8MB

16MB

RAM

Cisco 820 Series IOS IP/Voice

c820-v6y6-mz

8MB

24MB

RAM

Cisco 820 Series IOS IP Plus

c820-sy6-mz

8MB

20MB

RAM

Cisco 820 Series IOS
IP/Voice Plus

c820-sv6y6-mz

8MB

24MB

RAM

Cisco 820 Series IOS IP/FW

c820-oy6-mz

8MB

20MB

RAM

Cisco 820 Series IOS IP/FW/Voice

c820-ov6y6-mz

8MB

24MB

RAM

Cisco 820 Series IOS IP/FW Plus IPSec 56

c820-k9osy6-mz

8MB

24MB

RAM



Cisco 820 Series IOS IP/FW/Voice Plus 3DES

c820-k9osv6y6-mz

8MB

32MB

RAM


Hardware Supported

Cisco IOS Release 12.2(2)XH2 supports the following Cisco 800 and Cisco 820 series routers:

Cisco 801-804 Routers

Cisco 805 Router

Cisco 826, Cisco 827, and Cisco 827-4V Routers

For detailed descriptions of new hardware features, see the "New and Changed Information" section.

Cisco 801-804 Routers

The Cisco 801-804 routers provide the following key hardware features:

Cisco 802 and Cisco 804 routers have an integrated NT-1, which eliminates the need for an external NT-1 in North America.

Cisco 803 and Cisco 804 routers provide connection to analog telephones or fax machines, which are connected to telephone services through an ISDN line.

Flash memory: Default is 8 MB, expandable to 12 MB. (4MB Flash soldered to the motherboard.)


Note To add additional Flash memory to the Cisco 801-804, remove the existing Flash card and install a new one.


Dynamic RAM: Default is 4 MB, expandable to 12 MB. (4MB Dynamic RAM soldered to the motherboard.)

ISDN B-channel LEDs are a different color from the other LEDs, which make them easy to distinguish.

Color-coded ports and cable reduce the chance of cabling errors.

Routers can be stacked or mounted on a wall.

Cisco 805 Router

The Cisco 805 router connects small professional offices over serial lines to corporate networks and to the Internet. Table 2 summarizes Cisco 805 router ports.

Table 2 Cisco 805 Router Ports

Port Type
Description

Ethernet Port

One 10BaseT (RJ-45)

Serial Port

One WAN interface (RS-232, RS-449, RS-530 and RS-530A, V.35, and X.21)

Console Port

RJ-45


The Cisco 805 router provides the following key features:

One serial WAN interface that delivers up to 512 kbps for synchronous serial connections (Frame Relay, leased lines, and X.25) or up to 115 kbps for asynchronous dial-up.

One Ethernet LAN interface.

Flash memory: 4 MB default, expandable to 12 MB.

Dynamic RAM: 8 MB, expandable to 16 MB.

Color-coded ports and cable reduce the chance of cabling errors.

Routers can be stacked or mounted on a wall.

Cisco 826, Cisco 827, and Cisco 827-4V Routers

The Cisco 826, Cisco 827, and Cisco 827-4V Series Routers provide the following key hardware features:

The routers provide connection to an ADSL network or telephones and fax machines through an ADSL port.

Flash memory: Default is 12 MB and is expandable to 20 MB. If 12 MB is Flash is installed, 8 MB is used for the Cisco IOS images and 4 MB hosts the ROMMON and NVRAM. Additional memory can be added using Flash cards.

Cisco 826 and Cisco 827 routers Dynamic RAM: Default is 16 MB of DRAM and is expandable to 32 MB.

Cisco 827-4V router Dynamic RAM: Default is 24 MB and is expandable to 32 MB. The Cisco 827-4V router also contains an 8-MB DIMM card.

The central processing unit is a 50 MHz MPC 855T RISC processor.

Color-coded ports and cable reduce the chance of cabling errors.

Routers can be stacked or mounted on a wall.

The routers provide locking power connectors and a Kensington-compatible locking slot.

Table 3 Supported Interfaces for the Cisco 826, Cisco 827, and Cisco 827-4V Router

Router
Ethernet Ports
ADSL Ports
Telephone Ports
Console Ports

Cisco 826

One 10BaseT (RJ-45)

RJ-45

-

RJ-45

Cisco 827

One 10BaseT (RJ-45)

RJ-45

-

RJ-45

Cisco 827-4V

One 10BaseT (RJ-45)

RJ-45

Four (RJ-11)

RJ-45


Table 3 lists the supported interfaces for the Cisco 826, Cisco 827, and Cisco 827-4V routers.

Determining Your Software Release

To determine the version of Cisco IOS software currently running on your Cisco 1700 series router, log in to the router and enter the show version EXEC command. The following sample output from the show version command indicates the version number on the second output line:

router> show version
Cisco Internetwork Operating System Software
IOS (tm) c1700 Software (c1700-y-mz), Release 12.2(2)XH2, RELEASE SOFTWARE

Upgrading to a New Software Release

For general information about upgrading to a new software release, see Upgrading the Cisco IOS

Software Release in Cisco Routers and Modems:

http://www.cisco.com/warp/public/620/6.html

Feature Set Tables

The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.2(2)XH2 supports the same feature sets as Releases 12.2 and 12.2 T, but Release 12.2(2)XH2 can include new features supported by the Cisco 800 series and the Cisco 820 series routers. Table 4 lists the feature sets supported by the Cisco 800 series and Cisco 820 series routers.

Table 4 Feature Sets Supported by the Cisco 800 Series and Cisco 820 Series Routers

Image Name
Feature Set Matrix Terms
Software Image
Platform

Cisco 800 Series IOS IP

IP

c800-y6-mw

Cisco 801-804 routers

Cisco 800 Series IOS IP Plus

IP, Plus

c800-sy6-mw

Cisco 800 Series IOS IP/FW

IP, FW

c800-oy6-mw

Cisco 800 Series IOS IP/FW Plus IPSec 3DES

IP, FW, Plus, IPSec, 3DES

c800-k9osy6-mw



Cisco 800 Series IOS IP/IPX/FW Plus IPSec 3DES

IP, IPX, FW, Plus, IPSec, 3DES

c800-k9nosy6-mw



Cisco 805 Series IOS IP

IP

c805-y6-mw

Cisco 805 routers

Cisco 805 Series IOS IP Plus

IP, Plus

c805-sy6-mw

Cisco 805 Series IOS IP/FW

IP, FW

c805-oy6-mw

Cisco 805 Series IOS IP/IPX Plus

IP, IPX, Plus

c805-nsy6-mw



Cisco 805 Series IOS IP/FW Plus IPSec 3DES

IP, FW, Plus, IPSec, 3DES

c805-k9osy6-mw

Cisco 805 routers (continued)

Cisco 805 Series IOS IP/IPX/FW Plus IPSec 3DES

IP, IPX, FW, Plus, IPSec, 3DES

c805-k9nosy6-mw

Cisco 820 Series IOS IP

IP

c820-y6-mz

Cisco 820 Series Routers

Cisco 820 Series IOS IP/Voice

IP/Voice

c820-v6y6-mz



Cisco 820 Series IOS IP Plus

IP Plus

c820-sy6-mz



Cisco 820 Series IOS IP/Voice Plus

IP/Voice Plus

c820-sv6y6-mz



Cisco 820 Series IOS IP/FW

IP/FW

c820-oy6-mz



Cisco 820 Series IOS IP/FW/Voice

IP/FW/Voice

c820-ov6y6-mz



Cisco 820 Series IOS IP Plus IPSec 56

IP Plus IPSec 56

c820-k9osy6-mz



Cisco 820 Series IOS IP/FW/Voice Plus 3DES

IP/FW/Voice Plus 3DES

c820-k9osv6y6-mz



Table 5 through Table 8 list the features and feature sets supported in Cisco IOS Release 12.2(2)XH2:

Table 5 and Table 6—Cisco 801-804 routers

Table 7—Cisco 805 routers

Table 8—Cisco 826, Cisco 827, and Cisco 827 -4V routers

The tables use the following conventions:

Yes—The feature is supported in the software image.

No—The feature is not supported in the software image.


Note These feature set tables only contain a selected list of features. These tables are not cumulative—nor do they list all the features in each image.


Table 5 Feature List by Feature Set for the Cisco 801-804 Routers


Feature Set
Features
IP
IP/Plus
IP/FW
IP/FW/ Plus/ IPSec/ 3DES
IP/IPX/
FW/Plus/
IPSec/ 3DES
Address Conservation


PAT (NAT Overload)

Yes

Yes

Yes

Yes

Yes

NAT

Yes

Yes

Yes

Yes

Yes

NAT with H.323

No

No

No

No

No

Advanced Telephone Features 1


Call Forward (Sweden and Finland only)

Yes

Yes

Yes

Yes

Yes

Call Forward Variable (North America, Denmark, and Finland only)

Yes

Yes

Yes

Yes

Yes

Call Hold Retrieve (North America, Denmark, and Finland only)

Yes

Yes

Yes

Yes

Yes

Call Transfer (North America and Finland only)

Yes

Yes

Yes

Yes

Yes

Call Waiting

Yes

Yes

Yes

Yes

Yes

Caller ID Number delivery to POTS ports (North America, Denmark, Sweden, and Finland only)

Yes

Yes

Yes

No

Yes

Caller ID Name delivery to POTS ports (North America only)

No

No

No

No

No

Caller ID Restriction (Denmark, Finland, and Sweden only)

Yes

Yes

Yes

Yes

Yes

Calling Line Identification Restriction (CLIR) - Temporary Mode (Denmark and Finland only)

Yes

Yes

Yes

Yes

Yes

Data-Over-Voice Bearer (North America only)

Yes

Yes

Yes

Yes

Yes

Distinctive Ringing

Yes

Yes

Yes

Yes

Yes

ISDN-Voice Priority

Yes

Yes

Yes

Yes

Yes

Prefix Dialing2

Yes

Yes

Yes

Yes

Yes

Basic Services


GRE Tunneling

No

Yes

No

Yes

Yes

NAT

Yes

Yes

Yes

Yes

Yes

PAP, CHAP, MSCHAP, Local Password

Yes

Yes

Yes

Yes

Yes

Dial


Common Application Programming Interface (CAPI) (available only for NET3 image)

Yes

Yes

Yes

Yes

Yes

Ease of Use and Deployment


Auto SPID / Switch Detection

Yes

Yes

Yes

Yes

Yes

Cisco ConfigMaker

Yes

Yes

Yes

Yes

Yes

Cisco FastStep

Yes

Yes

Yes

Yes

Yes

Easy IP Phase I and II (IPCP Address Negotiation and DHCP Server)

Yes

Yes

Yes

Yes

Yes

TFTP Client and Server

Yes

Yes

Yes

Yes

Yes

IP Routing Protocols


OSPF Flooding Reduction

No

No

No

No

No

LAN


AppleTalk

No

No

No

No

No

IP

Yes

Yes

Yes

Yes

Yes

IPX

No

No

No

No

Yes

NetBIOS Access Lists

Yes

Yes

Yes

Yes

Yes

Transparent Bridging

Yes

Yes

Yes

Yes

Yes

Management


Cisco View

Yes

Yes

Yes

Yes

Yes

Service Assurance Agent

No

Yes

No

Yes

Yes

SNMP, Telnet, Console Port

Yes

Yes

Yes

Yes

Yes

SNTP

Yes

Yes

Yes

Yes

Yes

Syslog

No

Yes

No

Yes

Yes

Routing


BGP

No

No

No

No

No

EGP

No

No

No

No

No

IGRP

No

No

No

No

No

IP Enhanced IGRP (IP-EIGRP)

No

Yes

No

Yes

Yes

IPX Enhanced IGRP (IPX-EIGRP)

No

No

No

No

No

IP Multicast (relay only)

No

Yes

No

Yes

Yes

IP-Policy Routing

No

Yes

No

Yes

Yes

IPXWAN

No

No

No

No

Yes

OSPF

No

No

No

No

No

RIP, RIPv2, Triggered RIP

Yes

Yes

Yes

Yes

Yes

XOT

No

No

No

No

No

Security


AAA Radius

No

No

No

No

No

AAA TACACS+

No

Yes

No

Yes

Yes

Additional Vendor-Proprietary RADIUS Attributes

No

No

No

No

No

Authenticating ACL

No

No

No

No

No

Automated Double Authentication (server functionality)

No

No

No

No

No

Certificate Authority Interoperability

No

No

No

Yes

Yes

Internet Key Exchange Security Protocol

No

No

No

Yes

Yes

IPSec Network Security

No

No

No

Yes

Yes

Cisco IOS Firewall Phase I



Context Based Access Control Lists

No

No

Yes

Yes

Yes

Java Blocking

No

No

Yes

Yes

Yes

Denial of Service Detection and Prevention

No

No

Yes

Yes

Yes

Real-time Alerts and Audit Trails

No

No

Yes

Yes

Yes

IPSec Encryption with 56 bit DES

No

No

No

Yes

Yes

IPSec Encryption with 168 bit DES (3DES)

No

No

No

Yes

Yes

Lock and Key

Yes

Yes

Yes

Yes

Yes

L2TP

No

No

No

Yes

Yes

Named Method Lists for AAA Authentication & Accounting

No

No

No

No

No

Route and Router Authentication

Yes

Yes

Yes

Yes

Yes

Token Card - Double Authentication

Yes

Yes

Yes

Yes

Yes

WAN


Frame Relay Encapsulation (for ISDN LL and ISDN Dial
with PVC)

Yes

Yes

Yes

Yes

Yes

ISDN Digital Subscriber Line (IDSL, up to 144 kbps)
(Cisco 802 & Cisco 804 only)

Yes

Yes

Yes

Yes

Yes

Frame Relay Inverse ARP

Yes

Yes

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

Yes

Yes

ISDN Leased Line (up to 144 kbps)

Yes

Yes

Yes

Yes

Yes

ML-PPP, PPP Compression

Yes

Yes

Yes

Yes

Yes

PPP over Frame Relay (RFC 1973)

No

No

No

No

No

WAN Optimization


Always On/Dynamic ISDN (AO/DI)

No

Yes

No

Yes

Yes

Bandwidth on Demand (BOD)

Yes

Yes

Yes

Yes

Yes

Dial on Demand (DDR)

Yes

Yes

Yes

Yes

Yes

HSRP

Yes

Yes

Yes

Yes

Yes

IPX and SPX Spoofing

No

No

No

No

Yes

ISDN Caller ID Callback

Yes

Yes

Yes

Yes

Yes

Snapshot Routing

Yes

Yes

Yes

Yes

Yes

Stac Compression

Yes

Yes

Yes

Yes

Yes

Time-based Access Lists

Yes

Yes

Yes

Yes

Yes

X.25 ID

No

Yes

No

Yes

Yes

1 Advanced Telephone Features are available on the Cisco 803 and 804 routers only. These features require supplementary services from a telephone company.

2 Prefix Dialing is supported on Cisco 803 and Cisco 804 routers only.


Table 6 Additional Features Supported by Cisco 801-804 Routers

Feature
IP
IP/Plus
IP/FW
IP/FW/Plus/IPSec/ 3DES
IP/IPX/FW/ Plus/IPSec/3DES

Routed Protocol

IP

IP

IP

IP

IP/IPX

Routing Protocol

RIP

Snapshot

RIP/IP-
EIGRP

Snapshot

RIP/IP-
EIGRP

Snapshot

RIP/IP-
EIGRP

Snapshot

RIP/IP-
EIGRP

Snapshot

Tunneling



GRE



GRE

GRE

XXX PAD

No

Yes

No

Yes

Yes

X.25 over B and D

No

Yes

No

Yes

Yes

SNTP (Simple Network Time Protocol)

SNTP

SNTP

SNTP

SNTP

SNTP

Multicast



IP Multicast Forwarding



IP Multicast Forwarding

IP Multicast Forwarding

Management

SNMP

SNMP/
SYSLOG

SNMP

SNMP/
SYSLOG

SNMP/
SYSLOG

Manual ISDN Calls (see reference for commands)

Yes

Yes

Yes

Yes

Yes


Table 7 Feature List by Feature Set for the Cisco 805 Router


Feature Set
Features
IP
IP Plus
IP/FW
IP/FW Plus IPSec 3DES
IP/IPX/ FW Plus IPSec 3DES
Address Conservation


PAT (NAT Overload)

Yes

Yes

Yes

Yes

Yes

NAT

Yes

Yes

Yes

Yes

Yes

NAT with H.323

No

No

No

Yes

Yes

Basic Services


GRE Tunneling

No

Yes

No

Yes

Yes

NAT

Yes

Yes

Yes

Yes

Yes

PAP, CHAP, MSCHAP, Local Password

Yes

Yes

Yes

Yes

Yes

Ease of Use and Deployment


Cisco ConfigMaker

Yes

Yes

Yes

Yes

Yes

Cisco FastStep

Yes

Yes

Yes

Yes

Yes

Easy IP Phase I and II (IPCP Address Negotiation and DHCP Server)

Yes

Yes

Yes

Yes

Yes

TFTP Client and Server

Yes

Yes

Yes

Yes

Yes

LAN


IP

Yes

Yes

Yes

Yes

Yes

IPX

No

No

No

No

Yes

NetBIOS Access Lists

Yes

Yes

Yes

Yes

Yes

Transparent Bridging

Yes

Yes

Yes

Yes

Yes

Management


Cisco View

Yes

Yes

Yes

Yes

Yes

Service Assurance Agent

No

Yes

No

Yes

Yes

SNMP, Telnet, Console Port

Yes

Yes

Yes

Yes

Yes

SNTP

Yes

Yes

Yes

Yes

Yes

Syslog

No

Yes

No

Yes

Yes

Routing


BGP

No

No

No

No

No

EGP

No

No

No

No

No

IGRP

No

No

No

No

No

IP Enhanced IGRP (IP-EIGRP)

No

Yes

No

Yes

Yes

IPX Enhanced IGRP (IPX-EIGRP)

No

No

No

No

No

IP-Policy Routing

No

Yes

No

Yes

Yes

IPXWAN

No

No

No

No

Yes

OSPF

No

No

No

No

No

PIM for IP

No

Yes

No

Yes

Yes

RIP, RIPv2, Triggered RIP

Yes

Yes

Yes

Yes

Yes

XOT

No

Yes

No

Yes

Yes

Security


AAA Radius

No

No

No

No

No

AAA TACACS+

No

Yes

No

Yes

Yes

Additional Vendor-Proprietary RADIUS Attributes

No

No

No

No

No

Authenticating ACL

No

No

No

No

No

Automated Double Authentication (server functionality)

No

No

No

No

No

Certificate Authority Interoperability

No

No

No

Yes

Yes

Internet Key Exchange Security Protocol

No

No

No

Yes

Yes

IPSec Network Security

No

No

No

Yes

Yes

Cisco IOS Firewall Phase I



Context Based Access Control Lists

No

No

Yes

Yes

Yes

Java Blocking

No

No

Yes

Yes

Yes

Denial of Service Detection and Prevention

No

No

Yes

Yes

Yes

Real-time Alerts and Audit Trails

No

No

Yes

Yes

Yes

IPSec Encryption with 56 bit DES

No

No

No

Yes

Yes

IPSec Encryption with 168 bit DES (3DES)

No

No

No

Yes

Yes

Lock and Key

Yes

Yes

Yes

Yes

Yes

L2TP

No

No

No

Yes

Yes

Named Method Lists for AAA Authentication & Accounting

No

No

No

No

No

Route and Router Authentication

Yes

Yes

Yes

Yes

Yes

Token Card - Double Authentication

Yes

Yes

Yes

Yes

Yes

WAN


Frame Relay Encapsulation

Yes

Yes

Yes

Yes

Yes

Frame Relay Inverse ARP

Yes

Yes

Yes

Yes

Yes

ML-PPP, PPP Compression

Yes

Yes

Yes

Yes

Yes

PPP over Frame Relay (RFC 1973)

No

No

No

No

No

WAN Optimization


Bandwidth on Demand (BOD)

No

No

No

No

No

Dial on Demand (DDR)

No

No

No

No

No

HSRP

Yes

Yes

Yes

Yes

Yes

IPX and SPX Spoofing

No

No

No

No

Yes

Snapshot Routing

No

No

No

No

No

Stac Compression

Yes

Yes

Yes

Yes

Yes

Time-based Access Lists

Yes

Yes

Yes

Yes

Yes

X.25 ID

Yes

Yes

Yes

Yes

Yes


Table 8 Feature List by Feature Set for the Cisco 820 Series Routers


Feature Sets
Features
IP
IP/ Voice
IP Plus
IP/Voice Plus
IP/FW
IP/FW/Voice
IP /FW Plus IPSec 56
IP/FW/ Voice Plus 3DES

Address Conservation


DHCP Client Address Negotiation

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPCP Address Negotiation

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NAT Many to One (PAT)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NAT Many to Many (Multi-NAT)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Bandwidth Optimization


NetBIOS Name Caching

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

STAC Compression

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Business-Class Quality of Service


ATM TX Ring Programming

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

CBR, VBRrt, VBRnrt, UBR Traffic Classes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Class-Based Weighted Fair Queuing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP Policy Routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

LFI/LLQ

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Per-Virtual Circuit Queuing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Per-Virtual Circuit Shaping

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Weighted Random Early Detection

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Business-Class Security


GRE Tunneling

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP (and IPX when applicable) Basic and Extended Access Lists

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NetBIOS Access Lists

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAP, CHAP, Local Password

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Route and Router Authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Ease of Use and Deployment


Cisco Fast Step Software

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Easy IP Phase I and II

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PPPoE MTU Adjustment

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced Security


Cisco IOS Firewall

No

No

Yes

Yes

No

Yes

Yes

Yes

Context-Based Access Control Lists

No

No

Yes

Yes

No

Yes

Yes

Yes

Denial-of-Service Detection

No

No

Yes

Yes

No

Yes

Yes

Yes

IPSec Encryption with 3DES and L2TP

No

No

No

No

No

Yes

Yes

Yes

Java Blocking

No

No

Yes

Yes

No

Yes

Yes

Yes

Real-Time Alerts

No

No

Yes

Yes

No

Yes

Yes

Yes

LAN


IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX

No

No

No

No

Yes

No

Yes

No

Transparent Bridging

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Management


CiscoView

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SNTP

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SNMP, Telnet, Console Port

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Syslog

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

TACACS+ (also a security feature)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

TFTP Client and Server

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Routing


IP Enhanced IGRP

No

No

Yes

Yes

No

Yes

Yes

No

IP Multicast (relay only)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP-Policy Routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX RIP/SAP IPX WAN

No

No

No

No

Yes

No

Yes

No

RIP, RIPv2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Voice Features (Cisco 827-4V only)


G.711, G.729a, G.723.1 Codecs with
High-Performance DSP Support

No

Yes

No

Yes

Yes

No

No

Yes

Loop-Start Key-System or Direct Phone
Support

No

Yes

No

Yes

Yes

No

No

Yes

RAS Gatekeeper Communications Protocol

No

Yes

No

Yes

Yes

No

No

Yes

VoIP H.323

No

Yes

No

Yes

Yes

No

No

Yes


New and Changed Information

The following sections list the new software features supported by the Cisco 800 series and Cisco 820 series routers for Release 12.2(2)XH2 and above.

New Software Features in Release 12.2(2)XH1

The following sections list the new software features supported by the Cisco 800 series and Cisco 820 series routers for Release 12.2(2)XH1.

IP Named Access Lists

Cisco 805 routers now support the IP Named Access Lists feature. Using this feature, you can identify IP access lists with an alphanumeric string (a name) rather than a number. Named access lists enable you to configure more IP access lists in a router than numbered access lists. This feature is required to support the Virtual Private Network (VPN) Solution Center, which does not operate with numbered access lists.


Note Release 12.2(2)XH supports the IP Named Access Lists feature on Cisco 801-804 routers only. Release 12.2(2)XH1 is required to use the IP Named Access Lists feature on Cisco 805 routers.


New Software Features in Release 12.2(2)XH

The following sections list the new software features supported by the Cisco 800 series and Cisco 820 series routers for Release 12.2(2)XH. Information is included for any changed or new command line interface (CLI) commands associated with the new features.

Committed Access Rate

Cisco 826, Cisco 827, and Cisco 827-4V routers now support Committed Access Rate (CAR). CAR can be used to rate-limit traffic based on certain matching criteria such as incoming interface, IP precedence, QoS group, or IP access list criteria. CAR provides configurable actions, such as transmit, drop, set precedence, or set QoS group, when traffic conforms to or exceeds the rate limit.

The CAR feature performs the following functions:

Limits the input or output transmission rate on an interface or subinterface based on a flexible set of criteria.

Classifies packets by setting the IP precedence or Quality of Service (QoS) group, which is a class identifier that is internal to the router.

IP Named Access Lists

Cisco 801-804 routers now support the IP Named Access Lists feature. Using this feature, you can identify IP access lists with an alphanumeric string (a name) rather than a number. Named access lists enable you to configure more IP access lists in a router than numbered access lists. This feature is required to support the Virtual Private Network (VPN) Solution Center, which does not operate with numbered access lists.

New Software Features in Release 12.2 T

For information regarding the features supported in Cisco IOS Release 12.2 T, refer to the Cross-Platform Release Notes and New Feature Documentation links at the following location on Cisco.com:

http://www.cisco.com/univercd/cc/td/doc/product/software/ios122/122relnt/xprn122t/index.htm

This URL is subject to change without notice. If it changes, point your web browser to Cisco.com, and click on the following path:

Service & Support: Technical Documents: Release 12.2  (from the Cisco IOS Software drop-down list)

Important Notes

The following sections contain important notes about Cisco IOS Release 12.2(2)XH2 and above that can apply to the Cisco 800 series and Cisco 820 series routers. (Also, see the "Caveats" section.)

PPPoE MTU Adjustment Command Syntax Change

The syntax of the ip adjust-mss command has changed to the following command syntax:

ip tcp adjust-mss mss

where mss must be 1452 or less to fix the PPPoE Maximum Transmission Unit (MTU) problem.

Cisco 820 Series Memory Management When Using WFQ

When weighted fair queuing (WFQ) is used on the Dialer interface, or when WFQ is used in the default class of a service policy, the following parameters need to be set to the values shown because of the limited amount of memory on the router:

Congestive Discard Threshold: 64 or less

Number Dynamic Conversation Queues: 64 or less

Total maximum output packets: 64 or less

For example, if you apply WFQ to the Dialer interface, configure it as follows:

interface Dialer 1
 fair-queue 64 64 0
 hold-queue 64 out

In this example, the command fair-queue 64 64 0 limits the number of conversations to 64, and sets the discard threshold to 64. The command hold-queue 64 out limits the maximum number of output packets to 64.

In another example, if you configure a service policy, and WFQ is used on the default class, configure the policy as follows:

policy-map mypolicy
 class voice
  priority 100
 class class-default
  fair-queue 64
  queue-limit 64

 int dialer 1
 service-policy out mypolicy
 hold-queue 64 out

Here, the command fair-queue 64 limits the number of conversations to 64, and the command queue-limit 64 sets the discard threshold to 64. The command hold-queue 64 out limits the maximum number of output packets to 64. Failure to configure the above parameters may cause the router to display out-of-memory messages when a large amount of mixed traffic is transmitted from Ethernet to ATM.

Cisco 820 Series Router Clock—CSCdp09409

To run IPSec successfully, the Cisco 820 series router clock needs to be set accurately. Cisco 820 series router clocks are set and maintained using Simple Network Time Protocol (SNTP). For best results, set up a Network Time Protocol (NTP) server to periodically send time information messages to Cisco 820 series routers. See the SNTP configuration and command reference documentation for configuration instructions. If you do not have an NTP server, you must reset the Cisco 820 series router clock using the command clock set each time you restart the router.

The SNTP configuration documentation is available in the chapter "Monitoring the Router and Network" volume of the Configuration Fundamentals Configuration Guide in the Cisco IOS documentation set. The SNTP command reference documentation is available in the chapter "Router and Network Monitoring Commands" in the ""System Management Commands" volume of the Configuration Fundamentals Command Reference manual of the Cisco IOS documentation set.

CiscoView Application Support

The CiscoView application supports the Cisco 820 series routers. The CiscoView application provides dynamic status, statistics, and comprehensive configuration information for Cisco switches, routers, concentrators, and adapters. It displays a graphical view of Cisco devices. This network management tool also provides configuring and monitoring functions and offers basic troubleshooting tips.

Downloading Images

Before attempting to download new images, you must first delete files in the router Flash memory. Be sure to use the delete command, not command erase, to free up space. Entering erase removes all files, including the configuration.

Multilink PPP and Interleaving

Multilink PPP fragments large data packets so that small voice packets can be interleaved within them. However, apart from first-in-first-out (FIFO) queuing, no other kind of output queuing mechanisms are currently supported with PPP over ATM. Consequently, when multilink PPP is configured on the Cisco 827 routers, the big packets are fragmented, but interleaving of small voice packets within them does not occur.

NAT Support for H.323 Signaling

Currently, NAT does not support alerting H.225 messages. Therefore, NAT communication cannot be established between the router end points. NAT support for H.323 signaling is limited to the Netmeeting application.

Phone Mate Answering Machine Model 9200

A Phone Mate answering machine model 9200 fails to recognize the ringing signal sent by AMD R79 ringing SLIC. This was confirmed by testing against Phone Mate model 3750 and newer model 9300.

ROM Monitor set stop-bits Parameter

This release supports the setting of 1 only, for the ROM monitor set stop-bits parameter.

Caveats

Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious of these three severity levels.

Caveats in Cisco IOS Releases 12.2 and 12.2 T are also in Cisco IOS Release 12.2(2)XH2. For information on caveats in Cisco IOS Release 12.2, see Caveats for Cisco IOS Release 12.2. For information on caveats in Cisco IOS Release 12.2 T, see Caveats for Cisco IOS Release 12.2 T  These two documents list severity 1 and 2 caveats and are located on Cisco.com and the Documentation CD-ROM.


Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in toCisco.com and click Service & Support: Technical Assistance Center: Tool Index: Bug Toolkit. Another option is to go to http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.


Resolved Caveats - Release 12.2(2)XH2

This section describes unexpected behavior that is fixed in Release 12.2(2)XH2.

Management

CSCdw65903

An error can occur with management protocol processing. Please use the following URL for further information:

http://www.cisco.com/cgi-bin/bugtool/onebug.pl?bugid=CSCdw65903

Caveats for Release 12.2(2)XH

This section describes possibly unexpected behavior by software Release 12.2(2)XH.

CSCdu29516

Normally, the no ip route-cache command is applied to the dialer interface for the Ethernet interface to rate-limit incoming traffic. However, in this case, the dialer interface does not rate-limit incoming or outgoing traffic when ATM encapsulation AAL5 Point-to-Point Protocol (PPP) is used.

The workaround is to issue the ip route-cache command on the Ethernet interface if you are running ATM encapsulation PPP over Ethernet. All interfaces will then be able to rate-limit incoming and outgoing traffic.

CSCdu44295

On an intermittent basis, traceback occurs on the Cisco 801-804 routers that are running the 12.2(2)XH release. However, the traceback does not affect any other functionality.

Related Documentation

The following sections describe the documentation available for the Cisco 820 Series Routers. Typically, these documents consist of hardware and software installation guides, Cisco IOS configuration and command references, system error messages, feature modules, and other documents.

Documentation is available as printed manuals or electronic documents, except for feature modules, which are available online on Cisco.com and the Documentation CD-ROM.

Use these release notes with the documents listed in the following sections:

Release-Specific Documents

Platform-Specific Documents

Feature Modules

Cisco IOS Software Documentation Set

Release-Specific Documents

The following documents are specific to Release 12.2 and apply to Release 12.2(2)XH2. They are located on Cisco.com and the Documentation CD-ROM:

Release Notes for Cisco IOS Release 12.2(2)XH

To reach the Release Notes for the Cisco IOS Release 12.2(2)XH from Cisco.com, click this path (under the heading Service & Support):

Technical Documents: Cisco IOS Software: Release 12.2: Release Notes: <platform>  Routers: <platform> Series - Release Notes for Release 12.2(2)XH

To reach the Release Notes for the Cisco 800 Series Routers for Cisco IOS Release 12.2(2)XH on the Documentation CD-ROM, click this path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Release Notes: Cisco 800 Series Routers: Cisco 800 Series - Release Notes for Release 12.2(2)XH

Release Notes for Cisco IOS Release 12.2

To reach the Cross-Platform Release Notes for Cisco IOS Release 12.2 from Cisco.com, click this path (under the heading Service & Support):

Technical Documents: Cisco IOS Software: Release 12.2: Release Notes: Cross-Platform  Release Notes (Cisco IOS Release 12.2)

To reach the Cross-Platform Release Notes for Cisco IOS Release 12.2 on the Documentation CD-ROM, click this path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Release Notes: Cross-Platform Release Notes

Product bulletins, field notices, and other release-specific documents

To reach these documents from Cisco.com, click this path (under the heading Service & Support):

Technical Documents: Product Bulletins

Caveats for Cisco IOS Release 12.2 and 12.2 T

The Caveats for Cisco IOS Release 12.2 and Caveats for Cisco IOS Release 12.2 T  documents contain caveats applicable to all platforms for all maintenance releases of Release 12.2.

To reach the caveats document from Cisco.com, click this path (under the heading Service & Support):

Technical Documents: Cisco IOS Software: Release 12.2: Caveats

To reach the caveats document on the Documentation CD-ROM, click this path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Caveats


Note If you have an account with Cisco.com, you can also use the Bug Toolkit to find select caveats of any severity. To reach the Bug Toolkit, log in toCisco.com and click Service & Support: Technical Assistance Center: Tool Index: Bug Toolkit. Another option is to go to http://www.cisco.com/cgi-bin/Support/Bugtool/launch_bugtool.pl.


Platform-Specific Documents

The following documents are available for the Cisco 820 Series Routers on Cisco.com and the Documentation CD-ROM:

Cisco 801-804 Routers

These documents are available for the Cisco 800 series on Cisco.com and the Documentation CD-ROM:

Cisco 800 Series Router Quick Start Guide

Cisco 800 Series Routers Hardware Installation Guide

Cisco 800 Series Routers Software Configuration Guide

Release Notes for Cisco 800 Series Routers

Configuring Cisco IOS Software Features

Cisco 800 Fast Step Quick Start Guide

Cisco Fast Step documentation for the 800 series routes

Regulatory Compliance and Safety Information

Upgrading Memory in the Cisco 800 Series Routers

From Cisco.com or on the Documentation CD, click this path:

Technical Documents (under the heading Service & Support): Fixed Configuration Access  Routers (under Access Servers & Routers): Cisco 801-804 Routers

Cisco 805 Routers

These documents are available for the Cisco 805 router on Cisco.com and the Documentation CD-ROM.

Cisco 805 Router Hardware Installation Guide

Quick Start Guide — Setting up the Cisco 805 Router

Cisco 805 Router Software Configuration Guide

Regulatory Compliance and Safety Info For the Cisco 805 Router

Release Notes for the Cisco 805 Router

From Cisco.com or on the Documentation CD, click this path:

Technical Documents (under the heading Service & Support): Fixed Configuration Access  Routers (under Access Servers & Routers): Cisco 805 Router

Cisco 826 Router

These documents are available for the Cisco 826 router on Cisco.com and the Documentation CD-ROM:

Quick Start Guide - Setting up the Cisco 826 Router

Cisco 826 Router Hardware Installation Guide

Software Enhancements for the Cisco 826 and 827 Routers

Regulatory Compliance and Safety Information for the Cisco 826 Router

From Cisco.com or on the Documentation CD, click this path:

Technical Documents (under the heading Service & Support): Fixed Configuration Access  Routers (under Access Servers & Routers): Cisco 826 Routers

Cisco 827 and Cisco 827 4-V Routers

These documents are available for the Cisco 827 and Cisco 827 4-V routers on Cisco.com and the Documentation CD-ROM:

Quick Start Guide - Setting Up the Cisco 827 Routers

Cisco 827 Routers Hardware Installation Guide

Cisco 827 Routers Software Configuration Guide

Release Notes for Cisco 827 Routers

Upgrading Memory in Cisco 800 Series Routers

From Cisco.com or on the Documentation CD, click this path:

Technical Documents (under the heading Service & Support): Fixed Configuration Access  Routers (under Access Servers & Routers): Cisco 827 Routers

Feature Modules

Feature modules describe new features supported by Release 12.2 and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference. As updates, the feature modules are available online only. Feature module information is incorporated in the next printing of the Cisco IOS documentation set.

To reach the Release 12.2 feature modules:

From Cisco.com, click this path (under the heading Service & Support):

Technical Documents: Cisco IOS Software: Release 12.2: New Feature Documentation:
New Features in 12.2-Based Limited Lifetime Releases: New Features in 12.2X Releases

From the Documentation CD-ROM, click this path:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: New Feature Documentation: New Features in 12.2-Based Limited Lifetime Releases: New Features in 12.2X Releases

Feature Navigator

Feature Navigator is a web-based tool that enables you to quickly determine which Cisco IOS software images support a particular set of features and which features are supported in a particular Cisco IOS image. Feature Navigator is available 24 hours a day, 7 days a week.

To access Feature Navigator, you must have an account on Cisco.com. If you have forgotten or lost your account information, e-mail the Contact Database Administration group at cdbadmin@cisco.com. If you do not have an account on Cisco.com, go to http://www.cisco.com/register and follow the directions to set up an account.

To use Feature Navigator, you must have a JavaScript-enabled web browser such as Netscape 3.0 or later, or Internet Explorer 4.0 or later. Internet Explorer 4.0 always has JavaScript enabled. To enable JavaScript for Netscape 3.x or Netscape 4.x, follow the instructions provided with the web browser. For JavaScript support and enabling instructions for other browsers, check with the browser vendor.

Feature Navigator is updated when major Cisco IOS software releases and technology releases occur. You can access Feature Navigator at the following URL:

http://www.cisco.com/go/fn

Cisco IOS Software Documentation Set

The Cisco IOS software documentation set consists of the Cisco IOS configuration guides, Cisco IOS command references, and several other supporting documents. The Cisco IOS software documentation set is shipped with your order in electronic form on the Documentation CD-ROM—unless you specifically ordered the printed versions.

Documentation Modules

Each module in the Cisco IOS documentation set consists of one or more configuration guides and one or more corresponding command references. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality, and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Use each configuration guide with its corresponding command reference. The Cisco IOS software documentation set is available on Cisco.com and on the Documentation CD-ROM.

On Cisco.com (under the heading Service & Support) at:

Technical Documents: Cisco IOS Software: Release 12.2: Configuration Guides and  Command References

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2: Configuration Guides and Command References

Release 12.2 Documentation Set

Table 9 lists the contents of the Cisco IOS Release 12.2 software documentation set, which is available in both electronic and printed form.


Note You can find the most current Cisco IOS documentation on Cisco.com and the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed.


On Cisco.com (under the heading Service & Support) at:

Technical Documents: Cisco IOS Software: Release 12.2

On the Documentation CD-ROM at:

Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.2

Table 9 Cisco IOS Release 12.2 Documentation Set

Books
Major Topics

Cisco IOS Configuration Fundamentals Configuration Guide

Cisco IOS Configuration Fundamentals Command Reference

Cisco IOS User Interfaces
File Management
System Management

Cisco IOS Bridging and IBM Networking Configuration Guide

Cisco IOS Bridging and IBM Networking Command Reference, Volume 1 of 2

Cisco IOS Bridging and IBM Networking Command Reference, Volume 2 of 2

Transparent Bridging
SRB
Token Ring Inter-Switch Link
Token Ring Route Switch Module
RSRB
DLSw+
Serial Tunnel and Block Serial Tunnel
LLC2 and SDLC
IBM Network Media Translation
SNA Frame Relay Access
NCIA Client/Server
Airline Product Set
DSPU and SNA Service Point
SNA Switching Services
Cisco Transaction Connection
Cisco Mainframe Channel Connection
CLAW and TCP/IP Offload
CSNA, CMPC, and CMPC+
TN3270 Server

Cisco IOS Dial Technologies Configuration Guide

Cisco IOS Dial Technologies Command Reference

Preparing for Dial Access
Modem and Dial Shelf Configuration and Management
ISDN Configuration
Signaling Configuration
Dial-on-Demand Routing Configuration
Dial Backup Configuration
Dial Related Addressing Service
Virtual Templates, Profiles, and Networks
PPP Configuration
Callback and Bandwidth Allocation Configuration
Dial Access Specialized Features
Dial Access Scenarios

Cisco IOS Interface Configuration Guide

Cisco IOS Interface Command Reference

LAN Interfaces
Serial Interfaces
Logical Interfaces

Cisco IOS IP Configuration Guide

Cisco IOS IP Command Reference, Volume 1 of 3: Addressing and Services

Cisco IOS IP Command Reference, Volume 2 of 3: Routing Protocols

Cisco IOS IP Command Reference, Volume 3 of 3: Multicast

IP Addressing and Services
IP Routing Protocols
IP Multicast

Cisco IOS AppleTalk and Novell IPX Configuration Guide

Cisco IOS AppleTalk and Novell IPX Command Reference

AppleTalk
Novell IPX

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Configuration Guide

Cisco IOS Apollo Domain, Banyan VINES, DECnet, ISO CLNS, and XNS Command Reference

Apollo Domain
Banyan VINES
DECnet
ISO CLNS
XNS

Cisco IOS Voice, Video, and Fax Configuration Guide

Cisco IOS Voice, Video, and Fax Command Reference

Voice over IP
Call Control Signaling
Voice over Frame Relay
Voice over ATM
Telephony Applications
Trunk Management
Fax, Video, and Modem Support

Cisco IOS Quality of Service Solutions Configuration Guide

Cisco IOS Quality of Service Solutions Command Reference

Packet Classification
Congestion Management
Congestion Avoidance
Policing and Shaping
Signaling
Link Efficiency Mechanisms

Cisco IOS Security Configuration Guide

Cisco IOS Security Command Reference

AAA Security Services
Security Server Protocols
Traffic Filtering and Firewalls
IP Security and Encryption
Passwords and Privileges
Neighbor Router Authentication
IP Security Options
Supported AV Pairs

Cisco IOS Switching Services Configuration Guide

Cisco IOS Switching Services Command Reference

Cisco IOS Switching Paths
NetFlow Switching
Multiprotocol Label Switching
Multilayer Switching
Multicast Distributed Switching
Virtual LANs
LAN Emulation

Cisco IOS Wide-Area Networking Configuration Guide

Cisco IOS Wide-Area Networking Command Reference

ATM
Broadband Access
Frame Relay
SMDS
X.25 and LAPB

Cisco IOS Mobile Wireless Configuration Guide

Cisco IOS Mobile Wireless Command Reference

General Packet Radio Service

Cisco IOS Terminal Services Configuration Guide

Cisco IOS Terminal Services Command Reference

ARA
LAT
NASI
Telnet
TN3270
XRemote
X.28 PAD
Protocol Translation

Cisco IOS Configuration Guide Master Index

Cisco IOS Command Reference Master Index

Cisco IOS Debug Command Reference

Cisco IOS Software System Error Messages

New Features in 12.2-Based Limited Lifetime Releases

New Features in Release 12.2 T

Release Notes (Release note and caveat documentation for 12.2-based releases and various platforms)




Obtaining Documentation

The following sections provide sources for obtaining documentation from Cisco Systems.

World Wide Web

The most current Cisco documentation is available on the World Wide Web at http://www.cisco.com.  Translated documentation can be accessed at http://www.cisco.com/public/countries_languages.shtml.

Documentation CD-ROM

Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM is updated monthly and may be more current than printed documentation. The CD-ROM package is available as a single unit or as an annual subscription.

Ordering Documentation

Cisco documentation is available in the following ways:

Registered Cisco Direct Customers can order Cisco product documentation from the Networking Products MarketPlace:

http://www.cisco.com/cgi-bin/order/order_root.pl

Registered Cisco.com users can order the Documentation CD-ROM through the online Subscription Store:

http://www.cisco.com/go/subscription

Nonregistered Cisco.com users can order documentation through a local account representative by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, in North America, by calling 800 553-NETS(6387).

Documentation Feedback

If you are reading Cisco products documentation on the World Wide Web, you can submit technical comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco.

You can e-mail your comments to bug-doc@cisco.com.

For your convenience, many documents contain a response card behind the front cover for submitting your comments by mail. Otherwise, you can mail your comments to the following address:

Cisco Systems, Inc.
Document Resource Connection
170 West Tasman Drive
San Jose, CA 95134-9883

We appreciate your comments.

Obtaining Technical Assistance

The following sections provide sources for obtaining technical assistance from Cisco Systems.

Cisco.com

Cisco.com is the foundation of a suite of interactive, networked services that provides immediate, open access to Cisco information and resources at anytime, from anywhere in the world. This highly integrated Internet application is a powerful, easy-to-use tool for doing business with Cisco.

Cisco.com provides a broad range of features and services to help customers and partners streamline business processes and improve productivity. Through Cisco.com, you can find information about Cisco and our networking solutions, services, and programs. In addition, you can resolve technical issues with online technical support, download and test software packages, and order Cisco learning materials and merchandise. Valuable online skill assessment, training, and certification programs are also available.

Customers and partners can self-register on Cisco.com to obtain additional personalized information and services. Registered users can order products, check on the status of an order, access technical support, and view benefits specific to their relationships with Cisco.

To access Cisco.com, go to the following website:

http://www.cisco.com

Technical Assistance Center

The Cisco TAC website is available to all customers who need technical assistance with a Cisco product or technology that is under warranty or covered by a maintenance contract.

Contacting TAC by Using the Cisco TAC Website

If you have a priority level 3 (P3) or priority level 4 (P4) problem, contact TAC by going to the TAC website:

http://www.cisco.com/tac

P3 and P4 level problems are defined as follows:

P3—Your network performance is degraded. Network functionality is noticeably impaired, but most business operations continue.

P4—You need information or assistance on Cisco product capabilities, product installation, or basic product configuration.

In each of the above cases, use the Cisco TAC website to quickly find answers to your questions.

To register for Cisco.com, go to the following website:

http://www.cisco.com/register/

Cisco.com registered users who cannot resolve a technical issue by using the TAC online resource can open a case online by using the TAC Case Open tool at the following website:

http://www.cisco.com/tac/caseopen

Contacting TAC by Telephone

If you have a priority level 1(P1) or priority level 2 (P2) problem, contact TAC by telephone and immediately open a case. To obtain a directory of toll-free numbers for your country, go to the following website:

http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml

P1 and P2 level problems are defined as follows:

P1—Your production network is down, causing a critical impact to business operations if service is not restored quickly. No workaround is available.

P2—Your production network is severely degraded, affecting significant aspects of your business operations. No workaround is available.
