Configuring Security for VPNs with IPsec

Contents

Configuring Security for VPNs with IPsec

This module describes how to configure basic IPsec VPNs. IPsec is a framework of open standards developed by the IETF. It provides security for the transmission of sensitive information over unprotected networks such as the Internet. IPsec acts at the network layer, protecting and authenticating IP packets between participating IPsec devices (“peers”), such as Cisco routers.


Note


Security threats, as well as the cryptographic technologies to help protect against them, are constantly changing. For more information about the latest Cisco cryptographic recommendations, see the Next Generation Encryption (NGE) white paper.


Finding Feature Information

Your software release may not support all the features documented in this module. For the latest caveats and feature information, see Bug Search Tool and the release notes for your platform and software release. To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the feature information table at the end of this module.

Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/​go/​cfn. An account on Cisco.com is not required.

Prerequisites for Configuring Security for VPNs with IPsec

IKE Configuration

You must configure Internet Key Exchange (IKE) as described in the module Configuring Internet Key Exchange for IPsec VPNs.


Note


If you decide not to use IKE, you must still disable it as described in the module Configuring Internet Key Exchange for IPsec VPNs.


Ensure Access Lists Are Compatible with IPsec

IKE uses UDP port 500. The IPsec encapsulating security payload (ESP) and authentication header (AH) protocols use protocol numbers 50 and 51, respectively. Ensure that your access lists are configured so that traffic from protocol 50, 51, and UDP port 500 are not blocked at interfaces used by IPsec. In some cases, you might need to add a statement to your access lists to explicitly permit this traffic.

Restrictions for Configuring Security for VPNs with IPsec

NAT Configuration

If you use Network Address Translation (NAT), you should configure static NAT so that IPsec works properly. In general, NAT should occur before the router performs IPsec encapsulation; in other words, IPsec should work with global addresses.

Nested IPsec Tunnels

IPsec supports nested tunnels that terminate on the same router. Double encryption of locally generated IKE packets and IPsec packets is supported only when a static virtual tunnel interface (sVTI) is configured. Double encryption is supported on releases up to and including Cisco IOS Release 12.4(15)T, but not on later releases.

With CSCts46591, the following nested IPsec tunnels are supported:

  • Virtual tunnel interface (VTI) in VTI

  • VTI in Generic Routing Encapsulation (GRE)/IPsec

  • GRE/IPsec in VTI

  • GRE/IPsec in GRE/IPsec

Unicast IP Datagram Application Only

IPsec can be applied to unicast IP datagrams only. Because the IPsec Working Group has not yet addressed the issue of group key distribution, IPsec does not currently work with multicasts or broadcast IP datagrams.

Unsupported Interface Types

Crypto VPNs are not supported on the bridge domain interfaces (BDI).

Cisco IPsec Policy Map MIB

The MIB OID objects are displayed only when an IPsec session is up.

Information About Configuring Security for VPNs with IPsec

Supported Standards

Cisco implements the following standards with this feature:

  • IPsec—IPsec is a framework of open standards that provides data confidentiality, data integrity, and data authentication between participating peers. IPsec provides these security services at the IP layer; IPsec uses IKE to handle negotiation of protocols and algorithms based on the local policy, and generate the encryption and authentication keys to be used by IPsec. IPsec can be used to protect one or more data flows between a pair of hosts, between a pair of security gateways, or between a security gateway and a host.

    Note


    The term IPsec is sometimes used to describe the entire protocol of IPsec data services and IKE security protocols, and is also sometimes used to describe only the data services.


  • IKE—A hybrid protocol that implements Oakley and SKEME key exchanges inside the Internet Security Association and Key Management Protocol (ISAKMP) framework. While IKE is used with other protocols, its initial implementation is with the IPsec protocol. IKE provides authentication of IPsec peers, negotiates IPsec security associations, and establishes IPsec keys.

The component technologies implemented for IPsec include:


Note


Cisco no longer recommends using DES, 3DES, MD5 (including HMAC variant), and Diffie-Hellman (DH) groups 1, 2 and 5; instead, you should use AES, SHA and DH Groups 14 or higher. For more information about the latest Cisco cryptographic recommendations, see the Next Generation Encryption (NGE) white paper.


  • AES—Advanced Encryption Standard. A cryptographic algorithm that protects sensitive, unclassified information. AES is a privacy transform for IPsec and IKE and has been developed to replace DES. AES is designed to be more secure than DES. AES offers a larger key size, while ensuring that the only known approach to decrypt a message is for an intruder to try every possible key. AES has a variable key length—the algorithm can specify a 128-bit key (the default), a 192-bit key, or a 256-bit key.

  • DES—Data Encryption Standard. An algorithm that is used to encrypt packet data. Cisco software implements the mandatory 56-bit DES-CBC with Explicit IV. Cipher Block Chaining (CBC) requires an initialization vector (IV) to start encryption. The IV is explicitly given in the IPsec packet. For backwards compatibility, Cisco IOS IPsec also implements the RFC 1829 version of ESP DES-CBC.

Cisco IOS also implements Triple DES (168-bit) encryption, depending on the software versions available for a specific platform. Cisco no longer recommends Triple DES (3DES).


Note


Cisco IOS images with strong encryption (including, but not limited to 56-bit data encryption feature sets) are subject to United States government export controls, and have a limited distribution. Images to be installed outside the United States require an export license. Customer orders might be denied or subject to delay due to United States government regulations. Contact your sales representative or distributor for more information, or send an e-mail to export@cisco.com.


  • SEAL—Software Encryption Algorithm. An alternative algorithm to software-based DES, 3DES, and AES. SEAL encryption uses a 160-bit encryption key and has a lower impact on the CPU when compared to other software-based algorithms.

  • SHA-2 and SHA-1 family (HMAC variant)—Secure Hash Algorithm (SHA) 1 and 2. Both SHA-1 and SHA-2 are hash algorithms used to authenticate packet data and verify the integrity verification mechanisms for the IKE protocol. HMAC is a variant that provides an additional level of hashing. SHA-2 family adds the SHA-256 bit hash algorithm and SHA-384 bit hash algorithm. This functionality is part of the Suite-B requirements that comprises four user interface suites of cryptographic algorithms for use with IKE and IPSec that are described in RFC 4869. Each suite consists of an encryption algorithm, a digital signature algorithm, a key agreement algorithm, and a hash or message digest algorithm. See the Configuring Security for VPNs with IPsec feature module for more detailed information about Cisco IOS Suite-B support.

  • Diffie-Hellman—A public-key cryptography protocol that allows two parties to establish a shared secret over an unsecure communications channel. Diffie-Hellman is used within IKE to establish session keys. It supports 768-bit (the default), 1024-bit, 1536-bit, 2048-bit, 3072-bit, and 4096-bit DH groups. It also supports a 2048-bit DH group with a 256-bit subgroup, and 256-bit and 384-bit elliptic curve DH (ECDH). Cisco recommends using 2048-bit or larger DH key exchange, or ECDH key exchange.

  • MD5 (Hash-based Message Authentication Code (HMAC) variant)—Message digest algorithm 5 (MD5) is a hash algorithm. HMAC is a keyed hash variant used to authenticate data.

IPsec as implemented in Cisco software supports the following additional standards:

  • AH—Authentication Header. A security protocol, which provides data authentication and optional anti-replay services. AH is embedded in the data to be protected (a full IP datagram).

  • ESP—Encapsulating Security Payload. A security protocol, which provides data privacy services and optional data authentication, and anti-replay services. ESP encapsulates the data to be protected.

Supported Hardware, Switching Paths, and Encapsulation

Supported Hardware

VPN Accelerator Module Support

The VPN Accelerator Module (VAM) is a single-width acceleration module. It provides high-performance, hardware-assisted tunneling and encryption services suitable for VPN remote access, site-to-site intranet, and extranet applications. It also provides platform scalability and security while working with all services necessary for successful VPN deployments—security, quality of service (QoS), firewall and intrusion detection, service-level validation, and management. The VAM off-loads IPsec processing from the main processor, thus freeing resources on the processor engines for other tasks.

The VAM provides hardware-accelerated support for the following multiple encryption functions:

  • 56-bit DES standard mode: CBC

  • 3-Key Triple DES (168-bit)

  • SHA-1 and MD5

  • Rivest, Shamir, Adleman (RSA) public-key algorithm

  • Diffie-Hellman key exchange RC4-40

For more information on VAMs, see the document VPN Acceleration Module (VAM).

AIMs and NM Support

The data encryption Advanced Integration Module (AIM) and Network Module (NM) provide hardware-based encryption.

The data encryption AIMs and NM are hardware Layer 3 (IPsec) encryption modules and provide DES and Triple DES IPsec encryption for multiple T1s or E1s of bandwidth. These products also have hardware support for Diffie-Hellman, RSA, and DSA key generation.

Before using either module, note that RSA manual keying is not supported.

See the table below to determine which VPN encryption module to use.

IPPCP Software for Use with AIMs and NMs in Cisco 2600 and Cisco 3600 Series Routers

The software Internet Protocol Payload Compression Protocol (IPPCP) with AIMs and NMs allows customers to use Lempel-Ziv-Stac (LZS) software compression with IPsec when a VPN module is in Cisco 2600 and Cisco 3600 series routers, allowing users to effectively increase the bandwidth on their interfaces.

Without IPPCP software, compression is not supported with the VPN encryption hardware AIM and NM; that is, a user has to remove the VPN module from the router and run the software encryption with software compression. IPPCP enables all VPN modules to support LZS compression in the software when the VPN module is in the router, thereby allowing users to configure data compression and increase their bandwidth, which is useful for a low data link.

Without IPPCP, compression occurs at Layer 2, and encryption occurs at Layer 3. After a data stream is encrypted, it is passed on for compression services. When the compression engine receives the encrypted data streams, the data expands and does not compress. This feature enables both compression and encryption of the data to occur at Layer 3 by selecting LZS with the IPsec transform set; that is, LZS compression occurs before encryption, and with better compression ratio.

Table 1 AIM/VPN Encryption Module Support by Cisco IOS Release

Platform

Encryption Module Support by Cisco IOS Release—12.2(13)T

Encryption Module Support by Cisco IOS Release—12.3(4)T

Encryption Module Support by Cisco IOS Release—12.3(5)

Encryption Module Support by Cisco IOS Release—12.3(6)

Encryption Module Support by Cisco IOS Release—12.3(7)T

Cisco 831

Software-based AES

Software-based AES

Software-based AES

Software-based AES

Software-based AES

Cisco 1710

Cisco 1711

Cisco 1721

Cisco 1751

Cisco 1760

Software-based AES

Software-based AES

Software-based AES

Software-based AES

Software-based AES

Cisco 2600 XM

AIM-VPN/BPII-Plus Hardware Encryption Module

AIM-VPN/BPII-Plus Hardware Encryption Module

Cisco 2611 XM

Cisco 2621 XM

Cisco 2651 XM

AIM-VPN/BPII Hardware Encryption Module

AIM-VPN/BPII Hardware Encryption Module

AIM-VPN/BPII Hardware Encryption Module

AIM-VPN/BPII-Plus Hardware Encryption Module

Cisco 2691 XM

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII-Plus Hardware Encryption Module

Cisco 3660

Cisco 3745

AIM-VPN/HPII Hardware Encryption Module

AIM-VPN/HPII Hardware Encryption Module

AIM-VPN/HPII-Plus Hardware Encryption Module

AIM-VPN/HPII-Plus Hardware Encryption Module

AIM-VPN/HPII-Plus Hardware Encryption Module

Cisco 3735

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII Hardware Encryption Module

AIM-VPN/EPII-Plus Hardware Encryption Module

AIM-VPN/EPII-Plus Hardware Encryption Module

AIM-VPN/EPII-Plus Hardware Encryption Module

For more information on AIMs and NM, see the Installing Advanced Integration Modules in Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers document.

Supported Switching Paths

The table below lists the supported switching paths that work with IPsec.

Table 2 Supported Switching Paths for IPsec

Switching Paths

Examples

Cisco Express Forwarding

ip cef
interface ethernet0/0
 ip route-cache
! Ensure that you will not hit flow switching.
 no ip route-cache flow

Cisco Express Forwarding-flow switching

! Enable global CEF.
ip cef
interface ethernet0/0
 ip route-cache
 ip route-cache flow
! Enable CEF for the interface
 ip route-cache cef

Fast switching

interface ethernet0/0
 ip route-cache
! Ensure that you will not hit flow switching.
 no ip route-cache flow
! Disable CEF for the interface, which supersedes global CEF.
 no ip route-cache cef

Fast-flow switching

interface ethernet0/0
 ip route-cache
! Enable flow switching
p route-cache flow
! Disable CEF for the interface.
  no ip route-cache cef

Process switching

interface ethernet0/0
 no ip route-cache

Supported Encapsulation

IPsec works with the following serial encapsulations: Frame Relay, High-Level Data-Links Control (HDLC), and PPP.

IPsec also works with Generic Routing Encapsulation (GRE) and IPinIP Layer 3, Layer 2 Forwarding (L2F), Layer 2 Tunneling Protocol (L2TP), Data Link Switching+ (DLSw+), and Source Route Bridging (SRB) tunneling protocols; however, multipoint tunnels are not supported. Other Layer 3 tunneling protocols may not be supported for use with IPsec.

Because the IPsec Working Group has not yet addressed the issue of group key distribution, IPsec currently cannot be used to protect group traffic (such as broadcast or multicast traffic).

IPsec Functionality Overview

IPsec provides the following network security services. (In general, the local security policy dictates the use of one or more of these services.)

  • Data confidentiality—The IPsec sender can encrypt packets before transmitting them across a network.

  • Data integrity—The IPsec receiver can authenticate packets sent by the IPsec sender to ensure that the data has not been altered during transmission.

  • Data origin authentication—The IPsec receiver can authenticate the source of the sent IPsec packets. This service is dependent upon the data integrity service.

  • Anti-replay—The IPsec receiver can detect and reject replayed packets.

IPsec provides secure tunnels between two peers, such as two routers. You define which packets are considered sensitive and should be sent through these secure tunnels, and you define the parameters that should be used to protect these sensitive packets by specifying the characteristics of these tunnels. When the IPsec peer recognizes a sensitive packet, the peer sets up the appropriate secure tunnel and sends the packet through the tunnel to the remote peer. (The use of the term tunnel in this chapter does not refer to using IPsec in tunnel mode.)

More accurately, these tunnels are sets of security associations (SAs) that are established between two IPsec peers. The SAs define the protocols and algorithms to be applied to sensitive packets and specify the keying material to be used by the two peers. SAs are unidirectional and are established per security protocol (AH or ESP).

With IPsec, you can define the traffic that needs to be protected between two IPsec peers by configuring access lists and applying these access lists to interfaces using crypto map sets. Therefore, traffic may be selected on the basis of the source and destination address, and optionally the Layer 4 protocol and port. (The access lists used for IPsec are only used to determine the traffic that needs to be protected by IPsec, not the traffic that should be blocked or permitted through the interface. Separate access lists define blocking and permitting at the interface.)

A crypto map set can contain multiple entries, each with a different access list. The crypto map entries are searched in a sequence—the router attempts to match the packet to the access list specified in that entry.

When a packet matches a permit entry in a particular access list, and the corresponding crypto map entry is tagged as cisco, connections are established, if necessary. If the crypto map entry is tagged as ipsec-isakmp, IPsec is triggered. If there is no SA that the IPsec can use to protect this traffic to the peer, IPsec uses IKE to negotiate with the remote peer to set up the necessary IPsec SAs on behalf of the data flow. The negotiation uses information specified in the crypto map entry as well as the data flow information from the specific access list entry. (The behavior is different for dynamic crypto map entries. See the Creating Dynamic Crypto Maps section later in this module.)

If the crypto map entry is tagged as ipsec-manual, IPsec is triggered. If there is no SA that IPsec can use to protect this traffic to the peer, the traffic is dropped. In this case, the SAs are installed via the configuration, without the intervention of IKE. If SAs do not exist, IPsec does not have all the necessary pieces configured.

Once established, the set of SAs (outbound to the peer) is then applied to the triggering packet and to subsequent applicable packets as those packets exit the router. “Applicable” packets are packets that match the same access list criteria that the original packet matched. For example, all applicable packets could be encrypted before being forwarded to the remote peer. The corresponding inbound SAs are used when processing the incoming traffic from that peer.

Multiple IPsec tunnels can exist between two peers to secure different data streams, with each tunnel using a separate set of SAs. For example, some data streams only need to be authenticated, while other data streams must both be encrypted and authenticated.

Access lists associated with IPsec crypto map entries also represent the traffic that the router needs protected by IPsec. Inbound traffic is processed against crypto map entries—if an unprotected packet matches a permit entry in a particular access list associated with an IPsec crypto map entry, that packet is dropped because it was not sent as an IPsec-protected packet.

Crypto map entries also include transform sets. A transform set is an acceptable combination of security protocols, algorithms, and other settings that can be applied to IPsec-protected traffic. During the IPsec SA negotiation, the peers agree to use a particular transform set when protecting a particular data flow.

IKEv1 Transform Sets

An Internet Key Exchange version 1 (IKEv1) transform set represents a certain combination of security protocols and algorithms. During the IPsec SA negotiation, the peers agree to use a particular transform set for protecting a particular data flow.

You can specify multiple transform sets and then specify one or more of these transform sets in a crypto map entry. The transform set defined in the crypto map entry is used in the IPsec SA negotiation to protect the data flows specified by that crypto map entry’s access list.

During IPsec security association negotiations with IKE, peers search for a transform set that is the same at both peers. When such a transform set is found, it is selected and applied to the protected traffic as part of both peers’ IPsec SAs. (With manually established SAs, there is no negotiation with the peer, so both sides must specify the same transform set.)

If you change a transform set definition, the change is applied only to crypto map entries that reference the transform set. The change is not applied to existing security associations, but is used in subsequent negotiations to establish new SAs. If you want the new settings to take effect sooner, you can clear all or part of the SA database by using the clear crypto sa command.

IKEv2 Transform Sets

An Internet Key Exchange version 2 (IKEv2) proposal is a set of transforms used in the negotiation of IKEv2 SA as part of the IKE_SA_INIT exchange. An IKEv2 proposal is regarded as complete only when it has at least an encryption algorithm, an integrity algorithm, and a Diffie-Hellman (DH) group configured. If no proposal is configured and attached to an IKEv2 policy, then the default proposal is used in the negotiation. The default proposal is a collection of commonly used algorithms which are as follows:

encryption aes-cbc-128 3des
integrity sha md5
group 5 2

The transforms shown above translate to the following combinations in the following order of priority:

aes-cbc-128, sha, 5
aes-cbc-128, sha, 2
aes-cbc-128, md5, 5
aes-cbc-128, md5, 2
3des, sha1, 5
3des, sha1, 2
3des, md5, 5
3des, md5, 2

Although the crypto ikev2 proposal command is similar to the crypto isakmp policy priority command, the IKEv2 proposal differs as follows:

  • An IKEv2 proposal allows configuration of one or more transforms for each transform type.

  • An IKEv2 proposal does not have any associated priority.


Note


To use IKEv2 proposals in negotiation, they must be attached to IKEv2 policies. If a proposal is not configured, then the default IKEv2 proposal is used with the default IKEv2 policy.


When multiple transforms are configured for a transform type, the order of priority is from left to right.

A proposal with multiple transforms for each transform type translates to all possible combinations of transforms. If only a subset of these combinations is required, then they must be configured as individual proposals.

Device(config)# crypto ikev2 proposal proposal-1
Device(config-ikev2-proposal)# encryption aes-cbc-128, aes-cbc-192
Device(config-ikev2-proposal)# integrity sha1, sha256
Device(config-ikev2-proposal)# group 14

For example, the commands shown above translate to the following transform combinations:

aes-cbc-128, sha1, 14
aes-cbc-192, sha1, 14
aes-cbc-128, sha256, 14
aes-cbc-192, sha256, 14

To configure the first and last transform combinations, use the following commands:

Device(config)# crypto ikev2 proposal proposal-1
Device(config-ikev2-proposal)# encryption aes-cbc-128
Device(config-ikev2-proposal)# integrity sha1
Device(config-ikev2-proposal)# group 14
Device(config-ikev2-proposal)# exit
Device(config)# crypto ikev2 proposal proposal-2
Device(config-ikev2-proposal)# encryption aes-cbc-192
Device(config-ikev2-proposal)# integrity sha256
Device(config-ikev2-proposal)# group 14

IPsec Traffic Nested to Multiple Peers

You can nest IPsec traffic to a series of IPsec peers. For example, for traffic to traverse multiple firewalls (these firewalls have a policy of not letting through traffic that they have not authenticated), the router must establish IPsec tunnels with each firewall in turn. The “nearer” firewall becomes the “outer” IPsec peer.

In the example shown in the figure below, Router A encapsulates the traffic destined for Router C in IPsec (Router C is the inner IPsec peer). However, before Router A can send this traffic, it must first reencapsulate this traffic in IPsec to send it to Router B (Router B is the “outer” IPsec peer).

Figure 1. Nesting Example of IPsec Peers

It is possible for the traffic between the “outer” peers to have one kind of protection (such as data authentication) and for traffic between the “inner” peers to have a different protection (such as both data authentication and encryption).

Crypto Access Lists

Crypto Access List Overview

Crypto access lists are used to define which IP traffic is protected by crypto and which traffic is not protected by crypto. (These access lists are not the same as regular access lists, which determine what traffic to forward or block at an interface.) For example, access lists can be created to protect all IP traffic between Subnet A and Subnet Y or Telnet traffic between Host A and Host B.

The access lists themselves are not specific to IPsec. It is the crypto map entry referencing the specific access list that defines whether IPsec processing is applied to the traffic matching a permit in the access list.

Crypto access lists associated with IPsec crypto map entries have four primary functions:

  • Select outbound traffic to be protected by IPsec (permit = protect).

  • Indicate the data flow to be protected by the new SAs (specified by a single permit entry) when initiating negotiations for IPsec security associations.

  • Process inbound traffic to filter out and discard traffic that should have been protected by IPsec.

  • Determine whether or not to accept requests for IPsec security associations on behalf of the requested data flows when processing IKE negotiation from the IPsec peer.

  • Perform negotiation only for ipsec-isakmp crypto map entries.

If you want certain traffic to receive one combination of IPsec protection (for example, authentication only) and other traffic to receive a different combination of IPsec protection (for example, both authentication and encryption), you need to create two different crypto access lists to define the two different types of traffic. These different access lists are then used in different crypto map entries, which specify different IPsec policies.


Note


The IPsec traffic cannot be sent when the crypto map access list is modified under a crypto map. The IPsec traffic can be forwarded again after the tunnels are re-keyed. Use the clear crypto session command to continue IPsec traffic forwarding.

When to Use the permit and deny Keywords in Crypto Access Lists

Crypto protection can be permitted or denied for certain IP traffic in a crypto access list as follows:

  • To protect IP traffic that matches the specified policy conditions in its corresponding crypto map entry, use the permit keyword in an access list.

  • To refuse protection for IP traffic that matches the specified policy conditions in its corresponding crypto map entry, use the deny keyword in an access list.


Note


IP traffic is not protected by crypto if it is refused protection in all of the crypto map entries for an interface.


After the corresponding crypto map entry is defined and the crypto map set is applied to the interface, the defined crypto access list is applied to the interface. Different access lists must be used in different entries of the same crypto map set. However, both inbound and outbound traffic is evaluated against the same “outbound” IPsec access list. Therefore, the access list criteria is applied in the forward direction to traffic exiting your router and in the reverse direction to traffic entering your router.

In the figure below, IPsec protection is applied to traffic between Host 10.0.0.1 and Host 192.168.0.2 as the data exits Router A’s S0 interface en route to Host 192.168.0.2. For traffic from Host 10.0.0.1 to Host 192.168.0.2, the access list entry on Router A is evaluated as follows:

source = host 10.0.0.1
dest = host 192.168.0.2

For traffic from Host 192.168.0.2 to Host 10.0.0.1, the access list entry on Router A is evaluated as follows:

source = host 192.168.0.2
dest = host 10.0.0.1
Figure 2. How Crypto Access Lists Are Applied for Processing IPsec

If you configure multiple statements for a given crypto access list that is used for IPsec, in general the first permit statement that is matched is the statement used to determine the scope of the IPsec SA. That is, the IPsec SA is set up to protect traffic that meets the criteria of the matched statement only. Later, if traffic matches a different permit statement of the crypto access list, a new, separate IPsec SA is negotiated to protect traffic matching the newly matched access list statement.

Any unprotected inbound traffic that matches a permit entry in the crypto access list for a crypto map entry flagged as IPsec is dropped because this traffic was expected to be protected by IPsec.


Note


If you view your router’s access lists by using a command such as show ip access-lists, all extended IP access lists are shown in the command output. This display output includes extended IP access lists that are used for traffic filtering purposes and those that are used for crypto. The show command output does not differentiate between the different uses of the extended access lists.


The following example shows that if overlapping networks are used, then the most specific networks are defined in crypto sequence numbers before less specific networks are defined. In this example, the more specific network is covered by the crypto map sequence number 10, followed by the less specific network in the crypto map, which is sequence number 20.

crypto map mymap 10 ipsec-isakmp
 set peer 192.168.1.1
 set transform-set test
 match address 101
crypto map mymap 20 ipsec-isakmp
 set peer 192.168.1.2
 set transform-set test
 match address 102
access-list 101 permit ip 10.1.1.0 0.0.0.255 172.16.1.0 0.0.0.255
access-list 102 permit ip 10.0.0.0 0.255.255.255 172.16.0.0 0.15.255.255

The following example shows how having a deny keyword in one crypto map sequence number and having a permit keyword for the same subnet and IP range in another crypto map sequence number are not supported.

crypto map mymap 10 ipsec-isakmp
 set peer 192.168.1.1
 set transform-set test
 match address 101
crypto map mymap 20 ipsec-isakmp
 set peer 192.168.1.2
 set transform-set test
 match address 102
access-list 101 deny   ip 10.1.1.0 0.0.0.255 172.16.1.0 0.0.0.255
access-list 101 permit ip 10.0.0.0 0.255.255.255 172.16.0.0 0.15.255.255
access-list 102 permit ip 10.1.1.0 0.0.0.255 172.16.1.0 0.0.0.255

Mirror Image Crypto Access Lists at Each IPsec Peer

Cisco recommends that for every crypto access list specified for a static crypto map entry that you define at the local peer, you define a “mirror image” crypto access list at the remote peer. This ensures that traffic that has IPsec protection applied locally can be processed correctly at the remote peer. (The crypto map entries themselves must also support common transforms and must refer to the other system as a peer.)

The figure below shows some sample scenarios of mirror image and nonmirror image access lists.

Figure 3. Mirror Image vs. Nonmirror Image Crypto Access Lists (for IPsec)

As the above figure indicates, IPsec SAs can be established as expected whenever the two peers’ crypto access lists are mirror images of each other. However, an IPsec SA can be established only some of the time when access lists are not mirror images of each other. This can happen in the case where an entry in one peer’s access list is a subset of an entry in the other peer’s access list, such as shown in Cases 3 and 4 in the above figure. IPsec SA establishment is critical to IPsec—without SAs, IPsec does not work, thus causing packets matching the crypto access list criteria to be silently dropped instead of being forwarded with IPsec.

In the figure above, an SA cannot be established in Case 4. This is because SAs are always requested according to the crypto access lists at the initiating packet’s end. In Case 4, Router N requests that all traffic between Subnet X and Subnet Y be protected, but this is a superset of the specific flows permitted by the crypto access list at Router M, so the request is not permitted. Case 3 works because Router M’s request is a subset of the specific flows permitted by the crypto access list at Router N.

Because of the complexities introduced when crypto access lists are not configured as mirror images at peer IPsec devices, Cisco strongly encourages you to use mirror image crypto access lists.

When to Use the any Keyword in Crypto Access Lists

When you create crypto access lists, using the any keyword could cause problems. Cisco discourages the use of the any keyword to specify the source or destination addresses. By default, VTI solutions use the any keyword as a proxy identity. Use of VTI is encouraged when proxy identities of any are required.

The any keyword in a permit statement is not recommended when you have multicast traffic flowing through the IPsec interface; the any keyword can cause multicast traffic to fail.


Note


In Cisco IOS Release 12.4(9)T and later releases, multicast traffic from the router will be encapsulated into IPsec if proxy identities allow encapsulation.


The permit any any statement is strongly discouraged because this causes all outbound traffic to be protected (and all protected traffic is sent to the peer specified in the corresponding crypto map entry) and requires protection for all inbound traffic. Then, all inbound packets that lack IPsec protection are silently dropped, including packets for routing protocols, the Network Time Protocol (NTP), echo, echo response, and so on.

You need to be sure that you define which packets to protect. If you must use the any keyword in a permit statement, you must preface that statement with a series of deny statements to filter out any traffic (that would otherwise fall within that permit statement) that you do not want to be protected.

The use of the any keyword in access control lists (ACLs) with reverse route injection (RRI) is not supported. (For more information on RRI, see the section “Creating Crypto Map Sets.”)

Transform Sets: A Combination of Security Protocols and Algorithms

About Transform Sets


Note


Cisco no longer recommends using ah-md5-hmac, esp-md5-hmac, esp-des or esp-3des. Instead, you should use ah-sha-hmac, esp-sha-hmac or esp-aes. For more information about the latest Cisco cryptographic recommendations, see the Next Generation Encryption (NGE) white paper.


A transform set represents a certain combination of security protocols and algorithms. During the IPsec SA negotiation, the peers agree to use a particular transform set for protecting a particular data flow.

You can specify multiple transform sets, and then specify one or more of these transform sets in a crypto map entry. The transform set defined in the crypto map entry is used in the IPsec SA negotiation to protect the data flows specified by that crypto map entry’s access list.

During IPsec security association negotiations with IKE, peers search for an identical transform set for both peers. When such a transform set is found, it is selected and applied to the protected traffic as part of both peers’ IPsec SAs. (With manually established SAs, there is no negotiation with the peer, so both sides must specify the same transform set.)

If you change a transform set definition, the change is only applied to crypto map entries that reference the transform set. The change is not applied to existing security associations, but is used in subsequent negotiations to establish new SAs. If you want the new settings to take effect sooner, you can clear all or part of the SA database by using the clear crypto sa command.

The table below shows allowed transform combinations.

Table 3 Allowed Transform Combinations

Transform Type

Transform

Description

AH Transform (Pick only one.)

ah-md5-hmac

AH with the MD5 (Message Digest 5) (an HMAC variant) authentication algorithm. (No longer recommened).

ah-sha-hmac

AH with the SHA (Secure Hash Algorithm) (an HMAC variant) authentication algorithm.

ESP Encryption Transform (Pick only one.)

esp-aes

ESP with the 128-bit Advanced Encryption Standard (AES) encryption algorithm.

esp-gcm

esp-gmac

The esp-gcm and esp-gmac transforms are ESPs with either a 128-bit or a 256-bit encryption algorithm. The default for either of these transforms is 128 bits.

Both esp-gcm and esp-gmac transforms cannot be configured together with any other ESP transform within the same crypto IPsec transform set using the crypto ipsec transform-set command.

esp-aes 192

ESP with the 192-bit AES encryption algorithm.

esp-aes 256

ESP with the 256-bit AES encryption algorithm.

esp-des

ESP with the 56-bit Data Encryption Standard (DES) encryption algorithm. (No longer recommended).

esp-3des

ESP with the 168-bit DES encryption algorithm (3DES or Triple DES). (No longer recommended).

esp-null

Null encryption algorithm.

esp-seal

ESP with the 160-bit SEAL encryption algorithm.

ESP Authentication Transform (Pick only one.)

esp-md5-hmac

ESP with the MD5 (HMAC variant) authentication algorithm. (No longer recommended).

esp-sha-hmac

ESP with the SHA (HMAC variant) authentication algorithm.

IP Compression Transform

comp-lzs

IP compression with the Lempel-Ziv-Stac (LZS) algorithm

Cisco IOS Suite-B Support for IKE and IPsec Cryptographic Algorithms

Suite-B adds support for four user interface suites of cryptographic algorithms for use with IKE and IPSec that are described in RFC 4869. Each suite consists of an encryption algorithm, a digital signature algorithm, a key agreement algorithm, and a hash or message digest algorithm.

Suite-B has the following cryptographic algorithms:

  • Suite-B-GCM-128-Provides ESP integrity protection, confidentiality, and IPsec encryption algorithms that use the 128-bit AES using Galois and Counter Mode (AES-GCM) described in RFC 4106. This suite should be used when ESP integrity protection and encryption are both needed.

  • Suite-B-GCM-256-Provides ESP integrity protection and confidentiality using 256-bit AES-GCM described in RFC 4106. This suite should be used when ESP integrity protection and encryption are both needed.

  • Suite-B-GMAC-128-Provides ESP integrity protection using 128-bit AES- Galois Message Authentication Code (GMAC) described in RFC 4543, but does not provide confidentiality. This suite should be used only when there is no need for ESP encryption.

  • Suite-B-GMAC-256-Provides ESP integrity protection using 256-bit AES-GMAC described in RFC 4543, but does not provide confidentiality. This suite should be used only when there is no need for ESP encryption.

IPSec encryption algorithms use AES-GCM when encryption is required and AES-GMAC for message integrity without encryption.

IKE negotiation uses AES Cipher Block Chaining (CBC) mode to provide encryption and Secure Hash Algorithm (SHA)-2 family containing the SHA-256 and SHA-384 hash algorithms, as defined in RFC 4634, to provide the hash functionality. Diffie-Hellman using Elliptic Curves (ECP), as defined in RFC 4753, is used for key exchange and the Elliptic Curve Digital Signature Algorithm (ECDSA), as defined in RFC 4754, to provide authentication.

Suite-B Requirements

Suite-B imposes the following software crypto engine requirements for IKE and IPsec:

  • HMAC-SHA256 and HMAC-SHA384 are used as pseudorandom functions; the integrity check within the IKE protocol is used. Optionally, HMAC-SHA512 can be used.

  • Elliptic curve groups 19 (256-bit ECP curve) and 20 (384-bit ECP curve) are used as the Diffie-Hellman group in IKE. Optionally, group 21 (521-bit ECP curve) can be used.

  • The Elliptic Curve Digital Signature Algorithm (ECDSA) algorithm (256-bit and 384-bit curves) is used for the signature operation within X.509 certificates.

  • GCM (16 byte ICV) and GMAC is used for ESP (128-bit and 256-bit keys). Optionally, 192-bit keys can be used.

  • Public Key Infrastructure (PKI) support for validation of X.509 certificates using ECDSA signatures must be used.

  • PKI support for generating certificate requests using ECDSA signatures and for importing the issued certificates into IOS must be used.

  • IKEV2 support for allowing the ECDSA signature (ECDSA-sig) as authentication method must be used.

Where to Find Suite-B Configuration Information

Suite-B configuration support is described in the following documents:

  • For more information on the esp-gcm and esp-gmac transforms, see the “Configuring Transform Sets for IKEv1” section.

  • For more information on SHA-2 family (HMAC variant) and Elliptic Curve (EC) key pair configuration, see the Configuring Internet Key Exchange for IPsec VPNs feature module.

  • For more information on configuring a transform for an integrity algorithm type, see the “Configuring the IKEv2 Proposal” section in the Configuring Internet Key Exchange Version 2 (IKEv2) and FlexVPN Site-to-Site feature module.

  • For more information on configuring the ECDSA-sig to be the authentication method for IKEv2, see the “Configuring IKEv2 Profile (Basic)” section in the Configuring Internet Key Exchange Version 2 (IKEv2) and FlexVPN Site-to-Site feature module.

  • For more information on configuring elliptic curve Diffie-Hellman (ECDH) support for IPsec SA negotiation, see the Configuring Internet Key Exchange for IPsec VPNs and Configuring Internet Key Exchange Version 2 and FlexVPN feature modules.

For more information on the Suite-B support for certificate enrollment for a PKI, see the Configuring Certificate Enrollment for a PKI feature module.

Crypto Map Sets

Before you create crypto map entries, you should determine the type of crypto map—static, dynamic, or manual—best addresses the needs of your network.

About Crypto Maps

Crypto map entries created for IPsec pull together the various parts used to set up IPsec SAs, including:

  • Which traffic should be protected by IPsec (per a crypto access list)

  • The granularity of the flow to be protected by a set of SAs

  • Where IPsec-protected traffic should be sent (who the remote IPsec peer is)

  • The local address to be used for the IPsec traffic (See the “Applying Crypto Map Sets to Interfaces” section for more details)

  • What IPsec SA should be applied to this traffic (selecting from a list of one or more transform sets)

  • Whether SAs are manually established or are established via IKE

  • Other parameters that might be necessary to define an IPsec SA

How Crypto Maps Work

Crypto map entries with the same crypto map name (but different map sequence numbers) are grouped into a crypto map set. Later, you apply these crypto map sets to interfaces; all IP traffic passing through the interface is evaluated against the applied crypto map set. If a crypto map entry sees outbound IP traffic that should be protected and the crypto map specifies the use of IKE, an SA is negotiated with the remote peer according to the parameters included in the crypto map entry; otherwise, if the crypto map entry specifies the use of manual SAs, an SA should have already been established via configuration. (If a dynamic crypto map entry sees outbound traffic that should be protected and no security association exists, the packet is dropped.)

The policy described in the crypto map entries is used during the negotiation of SAs. If the local router initiates the negotiation, it uses the policy specified in the static crypto map entries to create the offer to be sent to the specified IPsec peer. If the IPsec peer initiates the negotiation, the local router checks the policy from the static crypto map entries, as well as any referenced dynamic crypto map entries, to decide whether to accept or reject the peer’s request (offer).

For IPsec to succeed between two IPsec peers, both peers’ crypto map entries must contain compatible configuration statements.

Compatible Crypto Maps: Establishing an SA

When two peers try to establish an SA, they must each have at least one crypto map entry that is compatible with one of the other peer’s crypto map entries. For two crypto map entries to be compatible, they must meet the following criteria:

  • The crypto map entries must contain compatible crypto access lists (for example, mirror image access lists). In cases, where the responding peer is using dynamic crypto maps, the entries in the local crypto access list must be “permitted” by the peer’s crypto access list.

  • The crypto map entries must each identify the other peer (unless the responding peer is using dynamic crypto maps).

  • The crypto map entries must have at least one transform set in common.

Load Sharing Among Crypto Maps

You can define multiple remote peers using crypto maps to allow load sharing. Load sharing is useful because if one peer fails, there is still a protected path. The peer to which packets are actually sent is determined by the last peer that the router heard from (that is, received either traffic or a negotiation request) for a given data flow. If the attempt fails with the first peer, IKE tries the next peer on the crypto map list.

If you are not sure how to configure each crypto map parameter to guarantee compatibility with other peers, you might consider configuring dynamic crypto maps as described in the section “Creating Dynamic Crypto Maps”. Dynamic crypto maps are useful when the establishment of the IPsec tunnels is initiated by the remote peer (such as in the case of an IPsec router fronting a server). They are not useful if the establishment of the IPsec tunnels is locally initiated because the dynamic crypto maps are policy templates, not complete statements of policy.

Crypto Map Guidelines

You can apply only one crypto map set to a single interface. The crypto map set can include a combination of IPsec/IKE and IPsec/manual entries. Multiple interfaces can share the same crypto map set if you want to apply the same policy to multiple interfaces.

If you create more than one crypto map entry for a given interface, use the seq-num argument of each map entry to rank the map entries; the lower the seq-num argument the higher the priority. At the interface that has the crypto map set, traffic is first evaluated against the higher priority map entries.

You must create multiple crypto map entries for a given interface if any of the following conditions exist:

  • If different data flows are to be handled by separate IPsec peers.

  • If you want to apply different IPsec security to different types of traffic (for the same or separate IPsec peers); for example, if you want traffic between one set of subnets to be authenticated, and traffic between another set of subnets to be both authenticated and encrypted. In such cases, the different types of traffic should be defined in two separate access lists, and you must create a separate crypto map entry for each crypto access list.

  • If you are not using IKE to establish a particular set of security associations, and you want to specify multiple access list entries, you must create separate access lists (one per permit entry) and specify a separate crypto map entry for each access list.

Static Crypto Maps

When IKE is used to establish SAs, IPsec peers can negotiate the settings they use for the new security associations. This means that you can specify lists (such as lists of acceptable transforms) within the crypto map entry.

Perform this task to create crypto map entries that use IKE to establish the SAs. To create IPv6 crypto map entries, you must use the ipv6 keyword with the crypto map command. For IPv4 crypto maps, use the crypto map command without the ipv6 keyword.


Note


Static IPv6 crypto maps with IKE is not supported.


Dynamic Crypto Maps

Dynamic crypto maps can simplify IPsec configuration and are recommended for use with networks where the peers are not always predetermined. To create dynamic crypto maps, you should understand the following concepts:

Dynamic Crypto Maps Overview

Dynamic crypto maps are only available for use by IKE.

A dynamic crypto map entry is essentially a static crypto map entry without all the parameters configured. It acts as a policy template where the missing parameters are later dynamically configured (as the result of an IPsec negotiation) to match a remote peer’s requirements. This allows remote peers to exchange IPsec traffic with the router even if the router does not have a crypto map entry specifically configured to meet all of the remote peer’s requirements.

Dynamic crypto maps are not used by the router to initiate new IPsec security associations with remote peers. Dynamic crypto maps are used when a remote peer tries to initiate an IPsec security association with the router. Dynamic crypto maps are also used in evaluating traffic.

A dynamic crypto map set is included by reference as part of a crypto map set. Any crypto map entries that reference dynamic crypto map sets should be the lowest priority crypto map entries in the crypto map set (that is, have the highest sequence numbers) so that the other crypto map entries are evaluated first; that way, the dynamic crypto map set is examined only when the other (static) map entries are not successfully matched.

If the router accepts the peer’s request, it installs the new IPsec security associations, it also installs a temporary crypto map entry. This entry contains the results of the negotiation. At this point, the router performs normal processing using this temporary crypto map entry as a normal entry, even requesting new security associations if the current ones are expiring (based upon the policy specified in the temporary crypto map entry). Once the flow expires (that is, all corresponding security associations expire), the temporary crypto map entry is removed.

For both static and dynamic crypto maps, if unprotected inbound traffic matches a permit statement in an access list, and the corresponding crypto map entry is tagged as “IPsec,” the traffic is dropped because it is not IPsec-protected. (This is because the security policy as specified by the crypto map entry states that this traffic must be IPsec-protected.)

For static crypto map entries, if outbound traffic matches a permit statement in an access list and the corresponding SA is not yet established, the router initiates new SAs with the remote peer. In the case of dynamic crypto map entries, if no SA exists, the traffic would simply be dropped (because dynamic crypto maps are not used for initiating new SAs).


Note


Use care when using the any keyword in permit entries in dynamic crypto maps. If the traffic covered by such a permit entry can include multicast or broadcast traffic, the access list should include deny entries for the appropriate address range. Access lists should also include deny entries for network and subnet broadcast traffic, and for any other traffic that should not be IPsec protected.


Tunnel Endpoint Discovery

Defining a dynamic crypto map allows only the receiving router to dynamically determine an IPsec peer. Tunnel Endpoint Discovery (TED) allows the initiating router to dynamically determine an IPsec peer for secure IPsec communications.

Dynamic TED helps to simplify the IPsec configuration on individual routers within a large network. Each node has a simple configuration that defines the local network that the router is protecting and the required IPsec transforms.

To have a large, fully-meshed network without TED, each peer needs to have static crypto maps to every other peer in the network. For example, if there are 100 peers in a large, fully-meshed network, each router needs 99 static crypto maps for each of its peers. With TED, only a single dynamic TED-enabled crypto map is needed because the peer is discovered dynamically. Thus, static crypto maps do not need to be configured for each peer.


Note


TED only helps in discovering peers and does not function any differently than normal IPsec. TED does not improve the scalability of IPsec (in terms of performance or the number of peers or tunnels).


The figure below and the corresponding steps explain a sample TED network topology.

Figure 4. Tunnel Endpoint Discovery Sample Network Topology

SUMMARY STEPS

    1.    Host A sends a packet that is destined for Host B.

    2.    Router 1 intercepts and reads the packet. According to the IKE policy, Router 1 contains the following information: the packet must be encrypted, there are no SAs for the packet, and TED is enabled. Thus, Router 1 drops the packet and sends a TED probe into the network. (The TED probe contains the IP address of Host A (as the source IP address) and the IP address of Host B (as the destination IP address) embedded in the payload.

    3.    Router 2 intercepts the TED probe and checks the probe against the ACLs that it protects; after the probe matches an ACL, it is recognized as a TED probe for proxies that the router protects. The probe then sends a TED reply with the IP address of Host B (as the source IP address) and the IP address of Host A (as the destination IP address) embedded in the payload.

    4.    Router 1 intercepts the TED reply and checks the payloads for the IP address and half proxy of Router 2. It then combines the source side of its proxy with the proxy found in the second payload and initiates an IKE session with Router 2; thereafter, Router 1 initiates an IPsec session with Router 2.


DETAILED STEPS
    Step 1   Host A sends a packet that is destined for Host B.
    Step 2   Router 1 intercepts and reads the packet. According to the IKE policy, Router 1 contains the following information: the packet must be encrypted, there are no SAs for the packet, and TED is enabled. Thus, Router 1 drops the packet and sends a TED probe into the network. (The TED probe contains the IP address of Host A (as the source IP address) and the IP address of Host B (as the destination IP address) embedded in the payload.
    Step 3   Router 2 intercepts the TED probe and checks the probe against the ACLs that it protects; after the probe matches an ACL, it is recognized as a TED probe for proxies that the router protects. The probe then sends a TED reply with the IP address of Host B (as the source IP address) and the IP address of Host A (as the destination IP address) embedded in the payload.
    Step 4   Router 1 intercepts the TED reply and checks the payloads for the IP address and half proxy of Router 2. It then combines the source side of its proxy with the proxy found in the second payload and initiates an IKE session with Router 2; thereafter, Router 1 initiates an IPsec session with Router 2.
    Note

    IKE cannot occur until the peer is identified.


    What to Do Next

    TED Versions

    The following table lists the available TED versions:

    Version

    First Available Release

    Description

    TEDv1

    12.0(5)T

    Performs basic TED functionality on nonredundant networks.

    TEDv2

    12.1M

    Enhanced to work with redundant networks with paths through multiple security gateways between the source and the destination.

    TEDv3

    12.2M

    Enhanced to allow non-IP-related entries to be used in the access list.

    TED Restrictions

    TED has the following restrictions:

    • It is Cisco proprietary.

    • It is available only on dynamic crypto maps. (The dynamic crypto map template is based on the dynamic crypto map performing peer discovery. Although there are no access-list restrictions on the dynamic crypto map template, the dynamic crypto map template should cover data sourced from the protected traffic and the receiving router using the any keyword. When using the any keyword, include explicit deny statements to exempt routing protocol traffic prior to entering the permit any command.

    • TED works only in tunnel mode; that is, it does not work in transport mode.

    • It is limited by the performance and scalability of the limitation of IPsec on each individual platform.

      Note


      Enabling TED slightly decreases the general scalability of IPsec because of the set-up overhead of peer discovery, which involves an additional “round-trip” of IKE messages (TED probe and reply). Although minimal, the additional memory used to store data structures during the peer discovery stage adversely affects the general scalability of IPsec.


    • IP addresses must be routed within the network.

    • The access list used in the crypto map for TED can only contain IP-related entries—TCP, UDP, or other protocols cannot be used in the access list.

      Note


      This restriction is no longer applicable in TEDv3.


    Redundant Interfaces Sharing the Same Crypto Map

    For redundancy, you could apply the same crypto map set to more than one interface. The default behavior is as follows:

    • Each interface has its own piece of the security association database.

    • The IP address of the local interface is used as the local address for IPsec traffic originating from or destined to that interface.

    If you apply the same crypto map set to multiple interfaces for redundancy purposes, you must specify an identifying interface. One suggestion is to use a loopback interface as the identifying interface. This has the following effects:

    • The per-interface portion of the IPsec security association database is established one time and shared for traffic through all the interfaces that share the same crypto map.

    • The IP address of the identifying interface is used as the local address for IPsec traffic originating from or destined to those interfaces sharing the same crypto map set.

    Establish Manual SAs

    The use of manual security associations is a result of a prior arrangement between the users of the local router and the IPsec peer. The two parties may begin with manual SAs and then move to using SAs established via IKE, or the remote party’s system may not support IKE. If IKE is not used for establishing SAs, there is no negotiation of SAs, so the configuration information in both systems must be the same in order for traffic to be processed successfully by IPsec.

    The local router can simultaneously support manual and IKE-established SAs, even within a single crypto map set.

    There is very little reason to disable IKE on the local router (unless the router only supports manual SAs, which is unlikely).


    Note


    Access lists for crypto map entries tagged as ipsec-manual are restricted to a single permit entry and subsequent entries are ignored. In other words, the SAs established by that particular crypto map entry are only for a single data flow. To support multiple manually established SAs for different kinds of traffic, define multiple crypto access lists, and apply each one to a separate ipsec-manual crypto map entry. Each access list should include one permit statement defining what traffic to protect.


    How to Configure IPsec VPNs

    Creating Crypto Access Lists

    SUMMARY STEPS

      1.    enable

      2.    configure terminal

      3.    Do one of the following:

      • access-list access-list-number {deny | permit} protocol source source-wildcard destination destination-wildcard [log]
      • ip access-list extended name

      4.    Repeat Step 3 for each crypto access list you want to create.


    DETAILED STEPS
       Command or ActionPurpose
      Step 1 enable


      Example:
      Device> enable


      Enables privileged EXEC mode.

      • Enter your password if prompted.


      Step 2 configure terminal


      Example:
      Device# configure terminal


      Enters global configuration mode.


      Step 3Do one of the following:
      • access-list access-list-number {deny | permit} protocol source source-wildcard destination destination-wildcard [log]
      • ip access-list extended name


      Example:
      Device(config)# access-list 100 permit ip 10.0.68.0 0.0.0.255 10.1.1.0 0.0.0.255


      Example:
      Device(config)# ip access-list extended vpn-tunnel


      Specifies conditions to determine which IP packets are protected.

      • You specify conditions using an IP access list designated by either a number or a name. The access-list command designates a numbered extended access list; the ip access-list extended command designates a named access list.

      • Enable or disable crypto for traffic that matches these conditions.

      Tip

      Cisco recommends that you configure “mirror image” crypto access lists for use by IPsec and that you avoid using the any keyword.


      Step 4 Repeat Step 3 for each crypto access list you want to create.



      What to Do Next

      After at least one crypto access list is created, a transform set needs to be defined as described in the “Configuring Transform Sets for IKEv1 and IKEv2 Proposals” section.

      Next the crypto access lists need to be associated to particular interfaces when you configure and apply crypto map sets to the interfaces. (Follow the instructions in the “Creating Crypto Map Sets” and “Applying Crypto Map Sets to Interfaces” sections).

      Configuring Transform Sets for IKEv1 and IKEv2 Proposals

      Perform this task to define a transform set that is to be used by the IPsec peers during IPsec security association negotiations with IKEv1 and IKEv2 proposals.

      Restrictions

      If you are specifying SEAL encryption, note the following restrictions:

      • Your router and the other peer must not have a hardware IPsec encryption.

      • Your router and the other peer must support IPsec.

      • Your router and the other peer must support the k9 subsystem.

      • SEAL encryption is available only on Cisco equipment. Therefore, interoperability is not possible.

      • Unlike IKEv1, the authentication method and SA lifetime are not negotiable in IKEv2, and because of this, these parameters cannot be configured under the IKEv2 proposal.

      Configuring Transform Sets for IKEv1

      SUMMARY STEPS

        1.    enable

        2.    configure terminal

        3.    crypto ipsec transform-set transform-set-name transform1 [transform2 [transform3]]

        4.    mode [tunnel | transport]

        5.    end

        6.    clear crypto sa [peer {ip-address | peer-name} | sa map map-name | sa entry destination-address protocol spi]

        7.    show crypto ipsec transform-set [tag transform-set-name]


      DETAILED STEPS
         Command or ActionPurpose
        Step 1 enable


        Example:
        Device> enable


        Enables privileged EXEC mode.

        • Enter your password if prompted.


        Step 2 configure terminal


        Example:
        Device# configure terminal


        Enters global configuration mode.


        Step 3 crypto ipsec transform-set transform-set-name transform1 [transform2 [transform3]]


        Example:
        Device(config)# crypto ipsec transform-set aesset esp-aes 256 esp-sha-hmac


        Defines a transform set and enters crypto transform configuration mode.

        • There are complex rules defining the entries that you can use for transform arguments. These rules are explained in the command description for the crypto ipsec transform-set command, and the table in “About Transform Sets” section provides a list of allowed transform combinations.


        Step 4 mode [tunnel | transport]


        Example:
        Device(cfg-crypto-tran)# mode transport


        (Optional) Changes the mode associated with the transform set.

        • The mode setting is applicable only to traffic whose source and destination addresses are the IPsec peer addresses; it is ignored for all other traffic. (All other traffic is in tunnel mode only.)


        Step 5 end


        Example:
        Device(cfg-crypto-tran)# end


        Exits crypto transform configuration mode and enters privileged EXEC mode.


        Step 6 clear crypto sa [peer {ip-address | peer-name} | sa map map-name | sa entry destination-address protocol spi]


        Example:
        Device# clear crypto sa


        (Optional) Clears existing IPsec security associations so that any changes to a transform set takes effect on subsequently established security associations.

        Manually established SAs are reestablished immediately.

        • Using the clear crypto sa command without parameters clears out the full SA database, which clears out active security sessions.

        • You may also specify the peer, map, or entry keywords to clear out only a subset of the SA database.


        Step 7 show crypto ipsec transform-set [tag transform-set-name]


        Example:
        Device# show crypto ipsec transform-set


        (Optional) Displays the configured transform sets.


        What to Do Next

        After you have defined a transform set, you should create a crypto map as specified in the “Creating Crypto Map Sets” section.

        Configuring Transform Sets for IKEv2

        SUMMARY STEPS

          1.    enable

          2.    configure terminal

          3.    crypto ikev2 proposal proposal-name

          4.    encryption transform1 [transform2] ...

          5.    integrity transform1 [transform2] ...

          6.    group transform1 [transform2] ...

          7.    end

          8.    show crypto ikev2 proposal


        DETAILED STEPS
           Command or ActionPurpose
          Step 1 enable


          Example:
          Device> enable


          Enables privileged EXEC mode.

          • Enter your password if prompted.


          Step 2 configure terminal


          Example:
          Device# configure terminal


          Enters global configuration mode.


          Step 3 crypto ikev2 proposal proposal-name


          Example:
          Device(config)# crypto ikev2 proposal proposal-1


          Specifies the name of the proposal and enters crypto IKEv2 proposal configuration mode.

          • The proposals are referred in IKEv2 policies through the proposal name.


          Step 4 encryption transform1 [transform2] ...


          Example:
          Device(config-ikev2-proposal)# encryption aes-cbc-128


          (Optional) Specifies one or more transforms of the following encryption type:

          • AES-CBC 128—128-bit AES-CBC

          • AES-CBC 192—192-bit AES-CBC

          • AES-CBC 256—256-bit AES-CBC

          • 3DES—168-bit DES (No longer recommended. AES is the recommended encryption algorithm).


          Step 5 integrity transform1 [transform2] ...


          Example:
          Device(config-ikev2-proposal)# integrity sha1


          (Optional) Specifies one or more transforms of the following integrity type:

          • The sha256 keyword specifies SHA-2 family 256-bit (HMAC variant) as the hash algorithm.

          • The sha384 keyword specifies SHA-2 family 384-bit (HMAC variant) as the hash algorithm.

          • The sha512 keyword specifies SHA-2 family 512-bit (HMAC variant) as the hash algorithm

          • the sha1 keyword specifies the SHA-1 (HMAC variant) as the hash algorithm.

          • The md5 keyword specifies MD5 (HMAC variant) as the hash algorithm. (No longer recommended. SHA-1 is the recommended replacement.)


          Step 6 group transform1 [transform2] ...


          Example:
          Device(config-ikev2-proposal)# group 14


          (Optional) Specifies one or more transforms of the possible DH group type:

          • 1—768-bit DH (No longer recommended.)

          • 2—1024-bit DH (No longer recommended)

          • 5—1536-bit DH (No longer recommended)

          • 14—Specifies the 2048-bit DH group.

          • 15—Specifies the 3072-bit DH group.

          • 16—Specifies the 4096-bit DH group.

          • 19—Specifies the 256-bit elliptic curve DH (ECDH) group.

          • 20—Specifies the 384-bit ECDH group.

          • 24—Specifies the 2048-bit DH/DSA group.


          Step 7 end


          Example:
          Device(config-ikev2-proposal)# end


          Exits crypto IKEv2 proposal configuration mode and returns to privileged EXEC mode.


          Step 8 show crypto ikev2 proposal


          Example:
          Device# show crypto ikev2 proposal


          (Optional) Displays the parameters for each IKEv2 proposal.


          Transform Sets for IKEv2 Examples

          The following examples show how to configure a proposal:

          IKEv2 Proposal with One Transform for Each Transform Type
          Device(config)# crypto ikev2 proposal proposal-1
          Device(config-ikev2-proposal)# encryption aes-cbc-128
          Device(config-ikev2-proposal)# integrity sha1
          Device(config-ikev2-proposal)# group 14

          IKEv2 Proposal with Multiple Transforms for Each Transform Type
          Device(config)# crypto ikev2 proposal proposal-2
          Device(config-ikev2-proposal)# encryption aes-cbc-128 aes-cbc-192
          Device(config-ikev2-proposal)# integrity sha2 sha256
          Device(config-ikev2-proposal)# group 14 15


          The IKEv2 proposal proposal-2 translates to the following prioritized list of transform combinations:

          • aes-cbc-128, sha1, 14

          • aes-cbc-128, sha1, 15

          • aes-cbc-128, sha256, 14

          • aes-cbc-128, sha256, 15

          • aes-cbc-192, sha1, 14

          • aes-cbc-192, sha1, 15

          • aes-cbc-192, sha256, 14

          • aes-cbc-192, sha256, 15

          IKEv2 Proposals on the Initiator and Responder

          The proposal of the initiator is as follows:

          Device(config)# crypto ikev2 proposal proposal-1
          Device(config-ikev2-proposal)# encryption aes-cbc-128 aes-cbc-196
          Device(config-ikev2-proposal)# integrity sha1 sha256
          Device(config-ikev2-proposal)# group 14 16


          The proposal of the responder is as follows:

          Device(config)# crypto ikev2 proposal proposal-2
          Device(config-ikev2-proposal)# encryption aes-cbc-196 aes-cbc-128
          Device(config-ikev2-proposal)# integrity sha256 sha1
          Device(config-ikev2-proposal)# group 16 14


          In the scenario, the initiator’s choice of algorithms is preferred and the selected algorithms are as follows:

          encryption aes-cbc-128
          integrity sha1
          group 14
          What to Do Next

          After you have defined a transform set, you should create a crypto map as specified in the “Creating Crypto Map Sets” section.

          Creating Crypto Map Sets

          Creating Static Crypto Maps

          When IKE is used to establish SAs, the IPsec peers can negotiate the settings they use for the new security associations. This means that you can specify lists (such as lists of acceptable transforms) within the crypto map entry.

          Perform this task to create crypto map entries that use IKE to establish SAs. To create IPv6 crypto map entries, you must use the ipv6 keyword with the crypto map command. For IPv4 crypto maps, use the crypto map command without the ipv6 keyword.


          Note


          Security threats, as well as the cryptographic technologies to help protect against them, are constantly changing. For more information about the latest Cisco cryptographic recommendations, see the Next Generation Encryption (NGE) white paper.


          SUMMARY STEPS

            1.    enable

            2.    configure terminal

            3.    crypto map [ipv6] map-name seq-num [ipsec-isakmp]

            4.    match address access-list-id

            5.    set peer {hostname | ip-address}

            6.    crypto ipsec security-association dummy {pps rate | seconds seconds}

            7.    set transform-set transform-set-name1 [transform-set-name2...transform-set-name6]

            8.    set security-association lifetime {seconds seconds | kilobytes kilobytes | kilobytes disable}

            9.    set security-association level per-host

            10.    set pfs [group1 | group14 | group15 | group16 | group19 | group2 | group20 | group24 | group5]

            11.    end

            12.    show crypto map [interface interface | tag map-name]


          DETAILED STEPS
             Command or ActionPurpose
            Step 1 enable


            Example:
            Device> enable


            Enables privileged EXEC mode.

            • Enter your password if prompted.


            Step 2 configure terminal


            Example:
            Device# configure terminal


            Enters global configuration mode.


            Step 3 crypto map [ipv6] map-name seq-num [ipsec-isakmp]


            Example:
            Device(config)# crypto map static-map 1 ipsec-isakmp


            Creates or modifies a crypto map entry, and enters crypto map configuration mode.

            • For IPv4 crypto maps, use the command without the ipv6 keyword.


            Step 4 match address access-list-id


            Example:
            Device(config-crypto-m)# match address vpn-tunnel


            Names an extended access list.

            • This access list determines the traffic that should be protected by IPsec and the traffic that should not be protected by IPsec security in the context of this crypto map entry.


            Step 5 set peer {hostname | ip-address}


            Example:
            Device(config-crypto-m)# set-peer 192.168.101.1


            Specifies a remote IPsec peer—the peer to which IPsec protected traffic can be forwarded.

            • Repeat for multiple remote peers.


            Step 6crypto ipsec security-association dummy {pps rate | seconds seconds}


            Example:
            Device(config-crypto-m)# set security-association dummy seconds 5


            Enables generating dummy packets. These dummy packets are generated for all flows created in the crypto map.


            Step 7 set transform-set transform-set-name1 [transform-set-name2...transform-set-name6]


            Example:
            Device(config-crypto-m)# set transform-set aesset


            Specifies the transform sets that are allowed for this crypto map entry.

            • List multiple transform sets in the order of priority (highest priority first).


            Step 8 set security-association lifetime {seconds seconds | kilobytes kilobytes | kilobytes disable}


            Example:
            Device (config-crypto-m)# set security-association lifetime seconds 2700


            (Optional) Specifies a SA lifetime for the crypto map entry.

            • By default, the SAs of the crypto map are negotiated according to the global lifetimes, which can be disabled.


            Step 9 set security-association level per-host


            Example:
            Device(config-crypto-m)# set security-association level per-host


            (Optional) Specifies that separate SAs should be established for each source and destination host pair.

            • By default, a single IPsec “tunnel” can carry traffic for multiple source hosts and multiple destination hosts.

            Caution

            Use this command with care because multiple streams between given subnets can rapidly consume resources.


            Step 10 set pfs [group1 | group14 | group15 | group16 | group19 | group2 | group20 | group24 | group5]


            Example:
            Device(config-crypto-m)# set pfs group14


            (Optional) Specifies that IPsec either should ask for password forward secrecy (PFS) when requesting new SAs for this crypto map entry or should demand PFS in requests received from the IPsec peer.

            • Group 1 specifies the 768-bit Diffie-Hellman (DH) identifier (default). (No longer recommended).

            • Group 2 specifies the 1024-bit DH identifier. (No longer recommended).

            • Group 5 specifies the 1536-bit DH identifier. (No longer recommended)

            • Group 14 specifies the 2048-bit DH identifier.

            • Group 15 specifies the 3072-bit DH identifier.

            • Group 16 specifies the 4096-bit DH identifier.

            • Group 19 specifies the 256-bit elliptic curve DH (ECDH) identifier.

            • Group 20 specifies the 384-bit ECDH identifier.

            • Group 24 specifies the 2048-bit DH/DSA identifier

            • By default, PFS is not requested. If no group is specified with this command, group 1 is used as the default.


            Step 11 end


            Example:
            Device(config-crypto-m)# end


            Exits crypto map configuration mode and returns to privileged EXEC mode.


            Step 12 show crypto map [interface interface | tag map-name]


            Example:
            Device# show crypto map


            Displays your crypto map configuration.


            Troubleshooting Tips

            Certain configuration changes take effect only when negotiating subsequent SAs. If you want the new settings to take immediate effect, you must clear the existing SAs so that they are reestablished with the changed configuration. If the router is actively processing IPsec traffic, clear only the portion of the SA database that would be affected by the configuration changes (that is, clear only the SAs established by a given crypto map set). Clearing the full SA database should be reserved for large-scale changes, or when the router is processing very little other IPsec traffic.

            To clear IPsec SAs, use the clear crypto sa command with appropriate parameters. (Omitting all parameters clears out the full SA database, which clears active security sessions.)

            What to Do Next

            After you have successfully created a static crypto map, you must apply the crypto map set to each interface through which IPsec traffic flows. To complete this task, see the “Applying Crypto Map Sets to Interfaces” section.

            Creating Dynamic Crypto Maps

            Dynamic crypto map entries specify crypto access lists that limit traffic for which IPsec SAs can be established. A dynamic crypto map entry that does not specify an access list is ignored during traffic filtering. A dynamic crypto map entry with an empty access list causes traffic to be dropped. If there is only one dynamic crypto map entry in the crypto map set, it must specify the acceptable transform sets.

            Perform this task to create dynamic crypto map entries that use IKE to establish the SAs.


            Note


            IPv6 addresses are not supported on dynamic crypto maps.



            Note


            Security threats, as well as the cryptographic technologies to help protect against them, are constantly changing. For more information about the latest Cisco cryptographic recommendations, see the Next Generation Encryption (NGE) white paper.


            SUMMARY STEPS

              1.    enable

              2.    configure terminal

              3.    crypto dynamic-map dynamic-map-name dynamic-seq-num

              4.    set transform-set transform-set-name1 [transform-set-name2...transform-set-name6]

              5.    match address access-list-id

              6.    set peer {hostname | ip-address}

              7.    set security-association lifetime {seconds seconds | kilobytes kilobytes | kilobytes disable}

              8.    set pfs [group1 | group14 | group15 | group16 | group19 | group2 | group20 | group24 | group5]

              9.    exit

              10.    exit

              11.    show crypto dynamic-map [tag map-name]

              12.    configure terminal

              13.    crypto map map-name seq-num ipsec-isakmp dynamic dynamic-map-name [discover]

              14.    exit


            DETAILED STEPS
               Command or ActionPurpose
              Step 1 enable


              Example:
              Device> enable


              Enables privileged EXEC mode.

              • Enter your password if prompted.


              Step 2 configure terminal


              Example:
              Device# configure terminal


              Enters global configuration mode.


              Step 3 crypto dynamic-map dynamic-map-name dynamic-seq-num


              Example:
              Device(config)# crypto dynamic-map test-map 1


              Creates a dynamic crypto map entry and enters crypto map configuration mode.


              Step 4 set transform-set transform-set-name1 [transform-set-name2...transform-set-name6]


              Example:
              Device(config-crypto-m)# set transform-set aesset


              Specifies the transform sets allowed for the crypto map entry.

              • List multiple transform sets in the order of priority (highest priority first). This is the only configuration statement required in dynamic crypto map entries.


              Step 5 match address access-list-id


              Example:
              Device(config-crypto-m)# match address 101


              (Optional) Specifies the list number or name of an extended access list.

              • This access list determines which traffic should be protected by IPsec and which traffic should not be protected by IPsec security in the context of this crypto map entry.

              Note

              Although access lists are optional for dynamic crypto maps, they are highly recommended.

              • If an access list is configured, the data flow identity proposed by the IPsec peer must fall within a permit statement for this crypto access list.

              • If an access list is not configured, the device accepts any data flow identity proposed by the IPsec peer. However, if an access list is configured but the specified access list does not exist or is empty, the device drops all packets. This is similar to static crypto maps, which require access lists to be specified.

              • Care must be taken if the any keyword is used in the access list, because the access list is used for packet filtering as well as for negotiation.

              • You must configure a match address; otherwise, the behavior is not secure, and you cannot enable TED because packets are sent in the clear (unencrypted.)


              Step 6 set peer {hostname | ip-address}


              Example:
              Device(config-crypto-m)# set peer 192.168.101.1


              (Optional) Specifies a remote IPsec peer. Repeat this step for multiple remote peers.

              Note

              This is rarely configured in dynamic crypto map entries. Dynamic crypto map entries are often used for unknown remote peers.


              Step 7 set security-association lifetime {seconds seconds | kilobytes kilobytes | kilobytes disable}


              Example:
              Device(config-crypto-m)# set security-association lifetime seconds 7200


              (Optional) Overrides (for a particular crypto map entry) the global lifetime value, which is used when negotiating IP Security SAs.

              Note

              To minimize the possibility of packet loss when rekeying in high bandwidth environments, you can disable the rekey request triggered by a volume lifetime expiry.


              Step 8 set pfs [group1 | group14 | group15 | group16 | group19 | group2 | group20 | group24 | group5]


              Example:
              Device(config-crypto-m)# set pfs group14


              (Optional) Specifies that IPsec should ask for PFS when requesting new security associations for this crypto map entry or should demand PFS in requests received from the IPsec peer.

              • Group 1 specifies the 768-bit Diffie-Hellman (DH) identifier (default). (No longer recommended).

              • Group 2 specifies the 1024-bit DH identifier. (No longer recommended).

              • Group 5 specifies the 1536-bit DH identifier. (No longer recommended)

              • Group 14 specifies the 2048-bit DH identifier.

              • Group 15 specifies the 3072-bit DH identifier.

              • Group 16 specifies the 4096-bit DH identifier.

              • Group 19 specifies the 256-bit elliptic curve DH (ECDH) identifier.

              • Group 20 specifies the 384-bit ECDH identifier.

              • Group 24 specifies the 2048-bit DH/DSA identifier

              • By default, PFS is not requested. If no group is specified with this command, group1 is used as the default.


              Step 9 exit


              Example:
              Device(config-crypto-m)# exit


              Exits crypto map configuration mode and returns to global configuration mode.


              Step 10 exit


              Example:
              Device(config)# exit


              Exits global configuration mode.


              Step 11 show crypto dynamic-map [tag map-name]


              Example:
              Device# show crypto dynamic-map


              (Optional) Displays information about dynamic crypto maps.


              Step 12 configure terminal


              Example:
              Device# configure terminal


              Enters global configuration mode.


              Step 13 crypto map map-name seq-num ipsec-isakmp dynamic dynamic-map-name [discover]


              Example:
              Device(config)# crypto map static-map 1 ipsec-isakmp dynamic test-map discover


              (Optional) Adds a dynamic crypto map to a crypto map set.

              • You should set the crypto map entries referencing dynamic maps to the lowest priority entries in a crypto map set.

              Note

              You must enter the discover keyword to enable TED.


              Step 14 exit


              Example:
              Device(config)# exit


              Exits global configuration mode.


              Troubleshooting Tips

              Certain configuration changes take effect only when negotiating subsequent SAs. If you want the new settings to take immediate effect, you must clear the existing SAs so that they are reestablished with the changed configuration. If the router is actively processing IPsec traffic, clear only the portion of the SA database that would be affected by the configuration changes (that is, clear only the SAs established by a given crypto map set). Clearing the entire SA database must be reserved for large-scale changes, or when the router is processing minimal IPsec traffic.

              To clear IPsec SAs, use the clear crypto sa command with appropriate parameters. (Omitting all parameters clears the full SA database, which clears active security sessions.)

              What to Do Next

              After you have successfully created a crypto map set, you must apply the crypto map set to each interface through which IPsec traffic flows. To complete this task, see the “Applying Crypto Map Sets to Interfaces” section.

              Creating Crypto Map Entries to Establish Manual SAs

              Perform this task to create crypto map entries to establish manual SAs (that is, when IKE is not used to establish the SAs). To create IPv6 crypto maps entries, you must use the ipv6 keyword with the crypto map command. For IPv4 crypto maps, use the crypto map command without the ipv6 keyword.

              SUMMARY STEPS

                1.    enable

                2.    configure terminal

                3.    crypto map [ipv6] map-name seq-num [ipsec-manual]

                4.    match address access-list-id

                5.    set peer {hostname | ip-address}

                6.    set transform-set transform-set-name

                7.    Do one of the following:

                • set session-key inbound ah spi hex-key-string
                • set session-key outbound ah spi hex-key-string

                8.    Do one of the following:

                • set session-key inbound esp spi cipher hex-key-string [authenticator hex-key-string]
                • set session-key outbound esp spi cipher hex-key-string [authenticator hex-key-string]

                9.    exit

                10.    exit

                11.    show crypto map [interface interface | tag map-name]


              DETAILED STEPS
                 Command or ActionPurpose
                Step 1 enable


                Example:
                Device> enable


                Enables privileged EXEC mode.

                • Enter your password if prompted.


                Step 2 configure terminal


                Example:
                Device# configure terminal


                Enters global configuration mode.


                Step 3 crypto map [ipv6] map-name seq-num [ipsec-manual]


                Example:
                Device(config)# crypto map mymap 10 ipsec-manual


                Specifies the crypto map entry to be created or modified and enters crypto map configuration mode.

                • For IPv4 crypto maps, use the crypto map command without the ipv6 keyword.


                Step 4 match address access-list-id


                Example:
                Device(config-crypto-m)# match address 102


                Names an IPsec access list that determines which traffic should be protected by IPsec and which traffic should not be protected by IPsec in the context of this crypto map entry.

                • The access list can specify only one permit entry when IKE is not used.


                Step 5 set peer {hostname | ip-address}


                Example:
                Device(config-crypto-m)# set peer 10.0.0.5


                Specifies the remote IPsec peer. This is the peer to which IPsec protected traffic should be forwarded.

                • Only one peer can be specified when IKE is not used.


                Step 6 set transform-set transform-set-name


                Example:
                Device(config-crypto-m)# set transform-set someset


                Specifies which transform set should be used.

                • This must be the same transform set that is specified in the remote peer’s corresponding crypto map entry.

                Note

                Only one transform set can be specified when IKE is not used.


                Step 7Do one of the following:
                • set session-key inbound ah spi hex-key-string
                • set session-key outbound ah spi hex-key-string


                Example:
                Device(config-crypto-m)# set session-key inbound ah 256 98765432109876549876543210987654


                Example:
                Device(config-crypto-m)# set session-key outbound ah 256 fedcbafedcbafedcfedcbafedcbafedc


                Sets the AH security parameter indexes (SPIs) and keys to apply to inbound and outbound protected traffic if the specified transform set includes the AH protocol.

                • This manually specifies the AH security association to be used with protected traffic.


                Step 8Do one of the following:
                • set session-key inbound esp spi cipher hex-key-string [authenticator hex-key-string]
                • set session-key outbound esp spi cipher hex-key-string [authenticator hex-key-string]


                Example:
                Device(config-crypto-m)# set session-key inbound esp 256 cipher 0123456789012345


                Example:
                Device(config-crypto-m)# set session-key outbound esp 256 cipher abcdefabcdefabcd


                Sets the Encapsulating Security Payload (ESP) Security Parameter Indexes (SPI) and keys to apply to inbound and outbound protected traffic if the specified transform set includes the ESP protocol.

                Or

                Specifies the cipher keys if the transform set includes an ESP cipher algorithm. Specifies the authenticator keys if the transform set includes an ESP authenticator algorithm.

                • This manually specifies the ESP security association to be used with protected traffic.


                Step 9 exit


                Example:
                Device(config-crypto-m)# exit


                Exits crypto map configuration mode and returns to global configuration mode.


                Step 10 exit


                Example:
                Device(config)# exit


                Exits global configuration mode.


                Step 11 show crypto map [interface interface | tag map-name]


                Example:
                Device# show crypto map


                Displays your crypto map configuration.


                Troubleshooting Tips

                For manually established SAs, you must clear and reinitialize the SAs for the changes to take effect. To clear IPsec SAs, use the clear crypto sa command with appropriate parameters. (Omitting all parameters clears the entire SA database, which clears active security sessions.)

                What to Do Next

                After you have successfully created a crypto map set, you must apply the crypto map set to each interface through which IPsec traffic flows. To complete this task, see the “Applying Crypto Map Sets to Interfaces” section.

                Applying Crypto Map Sets to Interfaces

                You must apply a crypto map set to each interface through which IPsec traffic flows. Applying the crypto map set to an interface instructs the device to evaluate the interface’s traffic against the crypto map set and to use the specified policy during connection or security association negotiation on behalf of traffic to be protected by the crypto map.

                Perform this task to apply a crypto map to an interface.

                SUMMARY STEPS

                  1.    enable

                  2.    configure terminal

                  3.    interface type/number

                  4.    crypto map map-name

                  5.    exit

                  6.    crypto map map-name local-address interface-id

                  7.    exit

                  8.    show crypto map [interface interface]


                DETAILED STEPS
                   Command or ActionPurpose
                  Step 1 enable


                  Example:
                  Device> enable


                  Enables privileged EXEC mode.

                  • Enter your password if prompted.


                  Step 2 configure terminal


                  Example:
                  Device# configure terminal


                  Enters global configuration mode.


                  Step 3 interface type/number


                  Example:
                  Device(config)# interface FastEthernet 0/0


                  Configures an interface and enters interface configuration mode.


                  Step 4 crypto map map-name


                  Example:
                  Device(config-if)# crypto map mymap


                  Applies a crypto map set to an interface.


                  Step 5 exit


                  Example:
                  Device(config-if)# exit


                  Exits interface configuration mode and returns to global configuration mode.


                  Step 6 crypto map map-name local-address interface-id


                  Example:
                  Device(config)# crypto map mymap local-address loopback0


                  (Optional) Permits redundant interfaces to share the same crypto map using the same local identity.


                  Step 7 exit


                  Example:
                  Device(config)# exit


                  (Optional) Exits global configuration mode.


                  Step 8 show crypto map [interface interface]


                  Example:
                  Device# show crypto map


                  (Optional) Displays your crypto map configuration



                  Configuration Examples for IPsec VPN

                  Example: Configuring AES-Based Static Crypto Map

                  This example shows how a static crypto map is configured and how an AES is defined as the encryption method:

                  crypto isakmp policy 10
                   encryption aes 256
                   authentication pre-share
                   group 14
                   lifetime 180
                  crypto isakmp key cisco123 address 10.0.110.1
                  !
                  !
                  crypto ipsec transform-set aesset esp-aes 256 esp-sha-hmac
                   mode transport
                  !
                  crypto map aesmap 10 ipsec-isakmp
                   set peer 10.0.110.1
                   set transform-set aesset
                   match address 120
                  !
                  !
                  !
                  voice call carrier capacity active
                  !
                  !
                  mta receive maximum-recipients 0
                  !
                  !
                  interface FastEthernet0/0
                   ip address 10.0.110.2 255.255.255.0
                   ip nat outside
                   no ip route-cache
                   no ip mroute-cache
                   duplex auto
                   speed auto
                   crypto map aesmap
                  !
                  interface Serial0/0
                   no ip address
                   shutdown
                  !
                  interface FastEthernet0/1
                   ip address 10.0.110.1 255.255.255.0
                   ip nat inside
                   no ip route-cache
                   no ip mroute-cache
                   duplex auto
                   speed auto
                  !
                  ip nat inside source list 110 interface FastEthernet0/0 overload
                  ip classless
                  ip route 0.0.0.0 0.0.0.0 10.5.1.1
                  ip route 10.0.110.0 255.255.255.0 FastEthernet0/0
                  ip route 172.18.124.0 255.255.255.0 10.5.1.1
                  ip route 172.18.125.3 255.255.255.255 10.5.1.1
                  ip http server
                  !
                  !
                  access-list 110 deny   ip 10.0.110.0 0.0.0.255 10.0.110.0 0.0.0.255
                  access-list 110 permit ip 10.0.110.0 0.0.0.255 any
                  access-list 120 permit ip 10.0.110.0 0.0.0.255 10.0.110.0 0.0.0.255
                  !

                  Additional References for Configuring Security for VPNs with IPsec

                  Related Documents

                  Related Topic

                  Document Title

                  Cisco IOS commands

                  Cisco IOS Master Commands List, All Releases

                  IKE, IPsec, and PKI configuration commands: complete command syntax, command mode, defaults, usage guidelines, and examples

                  IKE configuration

                  Configuring Internet Key Exchange for IPsec VPNs

                  Suite-B SHA-2 family (HMAC variant) and Elliptic Curve (EC) key pair configuration

                  Configuring Internet Key Exchange for IPsec VPNs

                  Suite-B Integrity algorithm type transform configuration

                  Configuring Internet Key Exchange Version 2 (IKEv2)

                  Suite-B Elliptic Curve Digital Signature Algorithm (ECDSA) signature (ECDSA-sig) authentication method configuration for IKEv2

                  Configuring Internet Key Exchange Version 2 (IKEv2)

                  Suite-B Elliptic curve Diffie-Hellman (ECDH) support for IPsec SA negotiation

                  • Configuring Internet Key Exchange for IPsec VPNs

                  • Configuring Internet Key Exchange Version 2 (IKEv2) and FlexVPN Site-to-Site

                  Suite-B support for certificate enrollment for a PKI

                  Configuring Certificate Enrollment for a PKI

                  Recommended cryptographic algorithms

                  Next Generation Encryption

                  Standards

                  Standards

                  Title

                  None

                  MIBs

                  MIBs

                  MIBs Link

                  • CISCO-IPSEC-FLOW-MONITOR- MIB

                  • CISCO-IPSEC-MIB

                  • CISCO-IPSEC-POLICY-MAP-MIB

                  To locate and download MIBs for selected platforms, Cisco IOS software releases, and feature sets, use Cisco MIB Locator found at the following URL:

                  http://www.cisco.com/go/mibs

                  RFCs

                  RFCs

                  Title

                  RFC 2401

                  Security Architecture for the Internet Protocol

                  RFC 2402

                  IP Authentication Header

                  RFC 2403

                  The Use of HMAC-MD5-96 within ESP and AH

                  RFC 2404

                  The Use of HMAC-SHA-1-96 within ESP and AH

                  RFC 2405

                  The ESP DES-CBC Cipher Algorithm With Explicit IV

                  RFC 2406

                  IP Encapsulating Security Payload (ESP)

                  RFC 2407

                  The Internet IP Security Domain of Interpretation for ISAKMP

                  RFC 2408

                  Internet Security Association and Key Management Protocol (ISAKMP)

                  Technical Assistance

                  Description

                  Link

                  The Cisco Support and Documentation website provides online resources to download documentation, software, and tools. Use these resources to install and configure the software and to troubleshoot and resolve technical issues with Cisco products and technologies. Access to most tools on the Cisco Support and Documentation website requires a Cisco.com user ID and password.

                  http:/​/​www.cisco.com/​cisco/​web/​support/​index.html

                  Feature Information for Configuring Security for VPNs with IPsec

                  The following table provides release information about the feature or features described in this module. This table lists only the software release that introduced support for a given feature in a given software release train. Unless noted otherwise, subsequent releases of that software release train also support that feature.

                  Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/​go/​cfn. An account on Cisco.com is not required.

                  Table 4 Feature Information for Configuring Security for IPsec VPNs

                  Feature Name

                  Software Releases

                  Feature Information

                  Advanced Encryption Standard

                  12.2(8)T

                  This feature adds support for the new encryption standard AES, which is a privacy transform for IPsec and IKE and has been developed to replace DES.

                  The following commands were modified by this feature: crypto ipsec transform-set, encryption (IKE policy), show crypto ipsec transform-set, show crypto isakmp policy.

                  DES/3DES/AES VPN Encryption Module (AIM-VPN/EPII, AIM-VPN/HPII, AIM-VPN/BPII Family)

                  12.3(7)T

                  This feature describes in which VPN encryption hardware AIM and NM are supported, in certain Cisco IOS software releases.

                  IKEv2 Proposal Support

                  15.1(1)T

                  An IKEv2 proposal is a set of transforms used in the negotiation of IKEv2 SA as part of the IKE_SA_INIT exchange. An IKEv2 proposal is regarded as complete only when it has at least an encryption algorithm, an integrity algorithm, and a Diffie-Hellman (DH) group configured. If no proposal is configured and attached to an IKEv2 policy, then the default proposal is used in negotiation.

                  The following commands were modified by this feature: crypto ikev2 proposal, encryption (ikev2 proposal), group (ikev2 proposal), integrity (ikev2 proposal), show crypto ikev2 proposal.

                  IPv6 Support for IPsec and IKEv2

                  15.1(4)M

                  15.1(1)SY

                  This feature allows IPv6 addresses to be added to IPsec and IKEv2 protocols.

                  The following commands were introduced or modified: crypto map (global IPsec), crypto map (isakmp), crypto map (Xauth), ipv6 crypto map.

                  Option to Disable Volume-based IPsec Lifetime Rekey

                  15.0(1)M

                  This feature allows customers to disable the IPsec security association rekey when processing large amounts of data.

                  The following commands were modified by this feature: crypto ipsec security association lifetime, set security-association lifetime.

                  SEAL Encryption

                  12.3(7)T

                  This feature adds support for SEAL encryption in IPsec.

                  The following command was modified by this feature: crypto ipsec transform-set.

                  Software IPPCP (LZS) with Hardware Encryption

                  12.2(13)T

                  This feature allows customers to use LZS software compression with IPsec when a VPN module is in Cisco 2600 and Cisco 3600 series routers.

                  Suite-B Support in IOS SW Crypto

                  15.1(2)T

                  Suite-B adds support for four user interface suites of cryptographic algorithms for use with IKE and IPSec that are described in RFC 4869. Each suite consists of an encryption algorithm, a digital signature algorithm, a key agreement algorithm, and a hash or message digest algorithm.

                  The following command was modified by this feature: crypto ipsec transform-set.

                  Glossary

                  anti-replay—Security service where the receiver can reject old or duplicate packets to protect itself against replay attacks. IPsec provides this optional service by use of a sequence number combined with the use of data authentication. Cisco IOS XE IPsec provides this service whenever it provides the data authentication service, except for manually established SAs (that is, SAs established by configuration and not by IKE).

                  data authentication—Verification of the integrity and origin of the data. Data authentication can refer either to integrity alone or to both of these concepts (although data origin authentication is dependent upon data integrity).

                  data confidentiality—Security service in which the protected data cannot be observed.

                  data flow—Grouping of traffic, identified by a combination of source address or mask, destination address or mask, IP next protocol field, and source and destination ports, where the protocol and port fields can have the values of any. IPsec protection is applied to data flows.

                  IKE—Internet Key Exchange. IKE establishes a shared security policy and authenticates keys for services (such as IPSec) that require keys. Before any IPSec traffic can be passed, each router/firewall/host must verify the identity of its peer. This can be done by manually entering preshared keys into both hosts or by a CA service.

                  IPsec—IP Security. A framework of open standards that provides data confidentiality, data integrity, and data authentication between participating peers. IPSec provides these security services at the IP layer. IPSec uses IKE to handle the negotiation of protocols and algorithms based on local policy and to generate the encryption and authentication keys to be used by IPSec. IPSec can protect one or more data flows between a pair of hosts, between a pair of security gateways, or between a security gateway and a host.

                  peer—In the context of this module, a “peer” is a router or other device that participates in IPsec.

                  PFS—perfect forward secrecy. Cryptographic characteristic associated with a derived shared secret value. With PFS, if one key is compromised, previous and subsequent keys are not compromised, because subsequent keys are not derived from previous keys.

                  SA—security association. Description of how two or more entities use security services in the context of a particular security protocol (AH or ESP) to communicate securely on behalf of a particular data flow. The transform and the shared secret keys are used for protecting the traffic.

                  SPI—security parameter index. A number which, together with a destination IP address and security protocol, uniquely identifies a particular security association. Without IKE, the SPI is manually specified for each security association.

                  transform—List of operations performed on a dataflow to provide data authentication, data confidentiality, and data compression. For example, one transform is the ESP protocol with the HMAC-MD5 authentication algorithm; another transform is the AH protocol with the 56-bit DES encryption algorithm and the ESP protocol with the HMAC-SHA authentication algorithm.

                  tunnel—In the context of this module, “tunnel” is a secure communication path between two peers, such as two routers. It does not refer to using IPsec in tunnel mode.
