Data Sheet

The Cisco® ONS 15454 Multiservice Transport Platform (MSTP) provides a comprehensive, intelligent dense wavelength-division multiplexing (DWDM) solution for expanding metropolitan-area (metro) and regional bandwidth.

Product Overview

The Cisco ONS 15454 MSTP offers a comprehensive selection of fixed optical filters, shown in Figure 1, for delivering the correct amount of bandwidth to each service location in a metro or regional network. The fixed filter cards are part of the Cisco ONS 15454 MSTP intelligent DWDM architecture for reducing DWDM complexity and speeding the deployment of next-generation networking solutions.

Figure 1

Fixed Optical Filter Family
Plug-in modules that deliver flexible access to network bandwidth from a single DWDM channel all the way to 32 channels, Cisco ONS 15454 fixed optical filter cards support the requirements of service provider and enterprise networks. Table 1 outlines the module types available for the Cisco ONS 15454 MSTP with the applications they are designed to support.

Table 1. Optical Filter Cards with Applications

Component

Deployment Application

32-channel multiplexer and demultiplexer

This product provides wavelength access (on or off ramp) for all the channels in a fiber cable. Typical deployment locations are terminal hub sites, including service provider central offices or enterprise telecommunications facilities.

Band-optical add/drop filters (B-OADM)

These filters allow access (add/drop) to a band or bands of frequencies from a fiber cable while passing the remaining frequencies. They are typically deployed at intermediate sites where access to greater bandwidth is required. They can also be inserted where future access to bandwidth may be required.

Channel-optical add/drop filters (C-OADM)

These filters enable access (add/drop) to individual wavelengths from a fiber cable while allowing the remaining frequencies to pass. They are deployed at intermediate sites where access to individual wavelengths is necessary. They can be cascaded to provide from 1- to 32-channel add/drop capabilities.

4-channel multiplexer/demultiplexer (4MD)

This product provides wavelength access (on or off ramp) to four channels from a band-OADM filter. They are deployed at intermediate sites where access to individual wavelengths is necessary.

The Cisco ONS 15454 fixed filter cards are based on the ITU 100-GHz wavelength plan. Each card integrates software-controllable variable optical attenuators (VOAs), providing automatic node- and network-based power level management. The optical cards incorporate LEDs on the faceplate to provide a quick visual check of the card's operational status. An icon on each faceplate is mapped to shelf-slot icons indicating the shelf slot where the card can be installed. The cards are supported by the integrated Cisco Transport Controller craft manager, which provides the user access for operations, administration, maintenance, and provisioning for the system.
All Cisco ONS 15454 fixed optical filter cards can drop and reinsert a wavelength without needing to regenerate the signal (optical bypass). This unique capability is supported at individual channel and band level and allows creation of multiring or mesh traffic matrixes using the available fixed filter cards.
The choice of filters depends on the requirements of the network. The Cisco MetroPlanner optical design tool is available to assist in the engineering, bill-of-material development, and deployment of the DWDM network. Figures 2 through 5 show sample signal-flow diagrams for a selection of Cisco ONS 15454 MSTP node types, outlining the use for each filter type.

Figure 2

MSTP Hub Node

Figure 3

Terminal Node

Figure 4

Active Optical Add/Drop Multiplexer (OADM) Node

Product Specifications

Tables 2 through 7 give specifications of the Cisco ONS 15454 fixed optical filters. Figures 5 through 9 are functional diagrams of the fixed optical filters.

Table 2. Regulatory Compliance1

ANSI System

ETSI System

Countries

Canada, United States, Mexico, Korea, Japan, European Union

European Union, Australia, New Zealand, Singapore, China, Mexico, Hong Kong, Korea

EMC emissions (radiated, conducted)
• ICES-003
• GR-1089-CORE
• 47CFR15
• VCCI V-3/2000.04
• CISPR24
• EN 300 386-TC
• EN50081-1
• EN55022
• AS/NZS3548, Amendment 1 + 2 1995
EMC immunity
• GR-1089-CORE
• CISPR24
• EN50082-2
• EN300-386-TC
• EN55024
Safety
• CAN/CSA-C22.2 No. 60950-00 Third Ed., 12/1/2002
• GR-1089-CORE
• GR-63-CORE
• TS001
• UL 60950 Third Ed., 12/1/2000
• EN60950 (to A4)
• IEC60950/EN60950, Third Ed.
• AS/NZS3260 Supplement 1, 2, 3, 4, 1997
Environmental
• GR-63-CORE
• AT&T Network Equipment Design Specifications (NEDS)
• ETS 300-019 (Class 3.1E) (Note 2)
Structural dynamics
• GR-63-CORE
• AT&T NEDS
• ETS 300-019 (Class 3.1E) (Note 2)
Power and grounding
• SBC (TP76200MP)
• ETS 300-132-1 (DC power)
• ETS 300-253 (grounding)
Optical
• GR-253-CORE
• G.692

Quality
• TR-NWT-000332, Issue 4, Method 1 calculation for 20-year mean time between failure (MTBF)

Table 3. System Requirements

Component

Cisco ONS 15454 ANSI

Cisco ONS 15454 ETSI

Processor

TCC2P/TCC2

TCC2P/TCC2

Cross-connect

All (not required)

All (not required)

Shelf assembly

15454-SA-HD or 15454-SA-HD-DDR shelf assembly with FTA3 version fan-tray assembly

15454-SA-ETSI shelf assembly with SDH 48V fan-tray assembly

System software

Release 4.6.0 ANSI or later

Release 4.6.0 ETSI or later

Table 4. Common Fixed Optical Filter Specifications

Specification

32-Channel Multiplexer

32-Channel Demultiplexer

4-Channel Multiplexer/ Demultiplexer

Channel OADM Cards

Band OADM Cards

Management

Card LEDs

Failure (FAIL)
Active/standby (ACT/STBY)
Signal fail (SF)

Red

Green/yellow

Yellow

Red

Green/yellow

Yellow

Red

Green/yellow

Yellow

Red

Green/yellow

Yellow

Red

Green/yellow

Yellow

Operating environment

Temperature

-5 to 55°C

23 to 131°F

-5 to 55°C

23 to 131°F

-5 to 55°C

23 to 131°F

-5 to 55°C

23 to 131°F

-5 to 55°C

23 to 131°F

Humidity

5 to 95% RH

5 to 95% RH

5 to 95% RH

5 to 95% RH

5 to 95% RH

Storage environment

Temperature

-40 to 85°C

-40 to 185°F

-40 to 85°C

-40 to 185°F

-40 to 85°C

-40 to 185°F

-40 to 85°C

-40 to 185°F

-40 to 85°C

-40 to 185°F

Humidity

5 to 95% RH

5 to 95% RH

5 to 95% RH

5 to 95% RH

5 to 95% RH

Multiplexer and Demultiplexer Filters

Figure 5

Functional Diagrams of 32-Channel Multiplexer and 32-Channel Demultiplexer

Figure 6

Functional Diagram of 4-Channel Multiplexer/Demultiplexer

Table 5. Specifications for 32-Channel Multiplexer, 32-Channel Demultiplexer, and 4-Channel Multiplexer/Demultiplexer

Specification

32-Channel Multiplexer

32-Channel Demultiplexer

4-Channel Multiplexer/Demultiplexer

Optical parameters

Insertion loss (maximum at minimum VOA)

Drop or add
Monitor


8.5 dB

29.5 dB


8.5 dB

-


3.6 (multiplexer), 3.2 (demultiplexer)

-

VOA dynamic range

25 dB

25 dB

30 dB

Maximum input power

25 dBm

25 dBm

25 dBm

Filter type

Array wave guide (AWG)

AWG

Interferential

Minimum transmit filter passband (at 0.5 dB resolution bandwidth)

±0.18 nm

±0.18 nm

±0.18 nm

Adjacent crosstalk
(all operating conditions and attenuation values)

23 dB

23 dB

25 dB

Non-adjacent crosstalk
(all operating conditions and attenuation values)

30 dB

30 dB

38 dB

Total crosstalk

20 dB

20 dB

22 dB

Maximum polarization dependent loss (PDL)
(all operating conditions and attenuation values)

1.6 dB

1.6 dB

0.7 dB

Optical power setting accuracy
(all operating conditions and attenuation values)

±0.5 dB

±0.5 dB

±0.5 dB

Minimum return loss

40 dB

40 dB

40 dB

Connectors

Channel input (multiplexer) and output (demultiplexer) ports

Composite ports

Monitor ports

MPO

LC

LC

MPO

LC

-

LC

LC

-

Power

Card power draw

Typical
Maximum

16W

31W

16W

31W

17W

25W

Physical

Size

2 slots

2 slots

1 slot

Supported shelf slots

1-6, 12-17

1-6, 12-17

1-6, 12-17

Optical Add/Drop Filters

Figure 7

Functional Diagrams for One and Two-Channel OADM

Figure 8

Functional Diagram for Four-Channel OADM Functional Diagrams

Table 6. Channel OADM Filter Specifications

Specification

One-Channel OADM

Two-Channel OADM

Four-Channel OADM

Optical parameters

Insertion loss (maximum)

Drop (maximum)
Add (at minimum VOA)
Express (maximum from express input to composite output)
Express (maximum from composite input to express output)

2 dB

2.6 dB

1.2 dB

2.4 dB

2.4 dB

3.1 dB

1.6 dB

2.7 dB

5.5 dB

4.9 dB

1.2 dB

2.7 dB

VOA dynamic range

30 dB

30 dB

30 dB

Maximum input power

25 dBm

25 dBm

25 dBm

Filter type

Interferential

Interferential

Interferential

Minimum transmit filter passband (at 0.5 dB resolution bandwidth)

+0.18 nm

+0.18 nm

+0.18 nm

Adjacent crosstalk
(all operating conditions and attenuation values)

25 dB

25 dB

25 dB

Non-adjacent crosstalk
(all operating conditions and attenuation values)

38 dB

38 dB

38 dB

Total crosstalk

22 dB

22 dB

22 dB

Maximum polarization dependent loss (PDL)
(all operating conditions and attenuation values)

0.7 dB

0.7 dB

0.7 dB

Optical power setting accuracy
(all operating conditions and attenuation values)

+0.5 dB

+0.5 dB

+0.5 dB

Minimum return loss

40 dB

40 dB

40 dB

Connectors

Input/output ports

Monitor ports

LC

LC

LC

LC

LC

LC

Power

Card power draw

Typical
Maximum

17W

25W

17W

25W

17W

25W

Physical

Size

1 slot

1 slot

1 slot

Supported shelf slots

1-6, 12-17

1-6, 12-17

1-6, 12-17

Figure 9

One- and Four-Band OADM Functional Diagrams

Table 7. Band OADM Filter Specifications

Specification

One-Band OADM

Four-Band OADM

Optical parameters

Insertion loss (maximum)

Drop path (at minimum VOA)
Add path
Express - From express input to composite output
Express - From composite input to express output (at minmum VOA)

3 dB

2.2 dB

1.6 dB

2.9 dB

4.5 dB

3.5 dB

3 dB

4.9 dB

VOA dynamic range

30 dB

30 dB

Maximum input power

25 dBm

25 dBm

Filter type

Interferential

Interferential

Minimum filter passband (at -1 dB)

3.49 nm

3.49 nm

Adjacent crosstalk
(all operating conditions and attenuation values)

25 dB

25 dB

Non-adjacent crosstalk
(all operating conditions and attenuation values)

35 dB

35 dB

Maximum polarization dependent loss (PDL)
(all operating conditions and attenuation values)

0.7 dB

0.7 dB

Optical power setting accuracy
(all operating conditions and attenuation values)

+0.5 dB

+0.5 dB

Connectors

Input/output ports

Monitor ports

LC

LC

LC

LC

Power

Card power draw

Typical
Maximum

17W

25W

17W

25W

Physical

Size

1 slot

1 slot

Supported shelf slots

1-6, 12-17

1-6, 12-17

Ordering Information

Tables 8 and 9 give ordering information for the Cisco ONS 15454 MTSP optical fixed filter cards.

Table 8. System Ordering Information2

Part Number

Description

15454-32MUX-O=

32-channel multiplexer card, C-band, 100-GHz, MPO connectors for add path, LC connector for interconnection

15454-32DMX-O=

32-channel demultiplexer card, C-band, 100-GHz, MPO connectors for drop path, LC connectors for interconnection, includes one 2-m LC/LC fiber-optic cables

15454-4MD-xx.x=

4-channel multiplexer and demultiplexer card, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

15454-AD-1C-xx.x=

1-channel OADM, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

15454-AD-2C-xx.x=

2-channel OADM, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

15454-AD-4C-xx.x=

4-channel OADM, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

15454-AD-1B-xx=

1-band OADM, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

15454-AD-4B-xx=

4-band OADM, C-band, 100-GHz, LC connectors, includes two 2-m LC/LC fiber-optic cables

Table 9. Wavelength Ordering Information (value to use for part number in Table 8)

Wavelength (nm)

Cisco 32-Channel Plan

AD-1C

AD-2C

AD-4C

AD-1B

AD-4B

1530.33

X

30.3

30.3

30.3

30.3

30.3

1531.12

X

31.1

1531.90

X

31.9

31.9

1532.68

X

32.6

1534.25

X

34.2

34.2

34.2

34.2

1535.04

X

35.0

1535.82

X

35.8

35.8

1536.61

X

36.6

1538.19

X

38.1

38.1

38.1

38.1

1538.98

X

38.9

1539.77

X

39.7

39.7

1540.56

X

40.5

1542.14

X

42.1

42.1

42.1

42.1

1542.94

X

42.9

1543.73

X

43.7

43.7

1544.53

X

44.5

1546.12

X

46.1

46.1

46.1

46.1

46.1

1546.92

X

46.9

1547.72

X

47.7

47.7

1548.51

X

48.5

1550.12

X

50.1

50.1

50.1

50.1

1550.92

X

50.9

1551.72

X

51.7

51.7

1552.52

X

52.5

1554.13

X

54.1

54.1

54.1

54.1

1554.94

X

54.9

1555.75

X

55.7

55.7

1556.55

X

56.5

1558.17

X

58.1

58.1

58.1

58.1

1558.98

X

58.9

1559.79

X

59.7

59.7

1560.61

X

60.6

Text Box:  Corporate HeadquartersCisco Systems, Inc.170 West Tasman DriveSan Jose, CA 95134-1706USAwww.cisco.comTel: 	408 526-4000	800 553-NETS (6387)Fax:	408 526-4100	European HeadquartersCisco Systems International BVHaarlerbergparkHaarlerbergweg 13-191101 CH AmsterdamThe Netherlandswww-europe.cisco.comTel:	31 0 20 357 1000Fax:	31 0 20 357 1100	Americas HeadquartersCisco Systems, Inc.170 West Tasman DriveSan Jose, CA 95134-1706USAwww.cisco.comTel:	408 526-7660Fax:	408 527-0883	Asia Pacific HeadquartersCisco Systems, Inc.168 Robinson Road#28-01 Capital Tower Singapore 068912www.cisco.comTel: 	+65 6317 7777Fax: 	+65 6317 7799Cisco Systems has more than 200 offices in the following countries and regions. Addresses, phone numbers, and fax numbers are listed on theCisco Website at www.cisco.com/go/offices.Argentina · Australia · Austria · Belgium · Brazil · Bulgaria · Canada · Chile · China PRC · Colombia · Costa RicaCroatia · Cyprus · Czech Republic · Denmark · Dubai, UAE · Finland · France · Germany · Greece · Hong Kong SARHungary · India · Indonesia · Ireland · Israel · Italy · Japan · Korea · Luxembourg · Malaysia · MexicoThe Netherlands · New Zealand · Norway · Peru · Philippines · Poland · Portugal · Puerto Rico · Romania · RussiaSaudi Arabia · Scotland · Singapore · Slovakia · Slovenia · South Africa · Spain · Sweden · Switzerland · TaiwanThailand · Turkey · Ukraine · United Kingdom · United States · Venezuela · Vietnam · ZimbabweAll contents are Copyright © 1992-2006 Cisco Systems, Inc. All rights reserved. Cisco, Cisco Systems, and the Cisco Systems logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0502R)	 Pa/LW9883 01/06Printed in USA Text Box:  Corporate HeadquartersCisco Systems, Inc.170 West Tasman DriveSan Jose, CA 95134-1706USAwww.cisco.comTel: 	408 526-4000	800 553-NETS (6387)Fax:	408 526-4100	European HeadquartersCisco Systems International BVHaarlerbergparkHaarlerbergweg 13-191101 CH AmsterdamThe Netherlandswww-europe.cisco.comTel:	31 0 20 357 1000Fax:	31 0 20 357 1100	Americas HeadquartersCisco Systems, Inc.170 West Tasman DriveSan Jose, CA 95134-1706USAwww.cisco.comTel:	408 526-7660Fax:	408 527-0883	Asia Pacific HeadquartersCisco Systems, Inc.168 Robinson Road#28-01 Capital Tower Singapore 068912www.cisco.comTel: 	+65 6317 7777Fax: 	+65 6317 7799Cisco Systems has more than 200 offices in the following countries and regions. Addresses, phone numbers, and fax numbers are listed on theCisco Website at www.cisco.com/go/offices.Argentina · Australia · Austria · Belgium · Brazil · Bulgaria · Canada · Chile · China PRC · Colombia · Costa RicaCroatia · Cyprus · Czech Republic · Denmark · Dubai, UAE · Finland · France · Germany · Greece · Hong Kong SARHungary · India · Indonesia · Ireland · Israel · Italy · Japan · Korea · Luxembourg · Malaysia · MexicoThe Netherlands · New Zealand · Norway · Peru · Philippines · Poland · Portugal · Puerto Rico · Romania · RussiaSaudi Arabia · Scotland · Singapore · Slovakia · Slovenia · South Africa · Spain · Sweden · Switzerland · TaiwanThailand · Turkey · Ukraine · United Kingdom · United States · Venezuela · Vietnam · ZimbabweAll contents are Copyright © 1992-2006 Cisco Systems, Inc. All rights reserved. Cisco, Cisco Systems, and the Cisco Systems logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0502R)	 Pa/LW9883 01/06Printed in USA
1All compliance testing and documentation may not be completed at release of the product. Check with your sales representative for countries outside of Canada, the United States, and the European Union.
2xx.x in the part number indicates the ordering wavelength of the card (example: 1530.33 = 30.3). Refer to Table 9 for wavelength plan.
