End-of-Life Notice, No. 3109
Cisco Systems ® announces the end-of-sale and end-of-life dates for the Cisco ® 15216 Baudelaire 100-GHz filter sets. The last day to order the affected product is May 1, 2006. Customers with active service contracts will continue to receive support from the Cisco Technical Assistance Center (TAC) until May 1, 2011. Table 1 describes the end-of-life milestones, definitions, and dates for the affected product. Table 2 lists the product part numbers affected by this announcement.
Customers are encouraged to migrate to the Cisco 15216 FlexLayer filter set, which is a low-cost alternative to the Cisco 15216 Baudelaire filter set. Information about the replacement product can be found at: http://www.cisco.com/en/US/products/hw/optical/ps1996/index.html. Table 3 provides relevant information for migrating to the replacement product.

Table 1. End-of-Life Milestones and Dates for the Cisco 15216 Baudelaire Filter Set

Milestone

Definition

Date

End-of-Life Announcement Date

The date the document that announces the end of sale and end of life of a product is distributed to the general public.

November 1, 2005

End-of-Sale Date

The last date to order the product through Cisco point-of-sale mechanisms. The product is no longer for sale after this date.

May 1, 2006

Last Ship Date

The last-possible ship date that can be requested of Cisco and/or its contract manufacturers. Actual ship date is dependent on lead time.

August 1, 2006

End of SW Maintenance Releases Date

The last date that Cisco Engineering may release any final software maintenance releases or bug fixes. After this date, Cisco Engineering will no longer develop, repair, maintain, or test the product software.

May 1, 2007

End of Routine Failure Analysis Date

The last-possible date a routine failure analysis may be performed to determine the cause of product failure or defect.

May 1, 2007

End of New Service Attachment Date

For equipment and software that is not covered by a service-and-support contract, this is the last date to order a new service-and-support contract or add the equipment and/or software to an existing service-and-support contract.

May 1, 2007

End of Service Contract Renewal Date

The last date to extend or renew a service contract for the product.

November 1, 2010

Last Date of Support

The last date to receive service and support for the product. After this date, all support services for the product are unavailable, and the product becomes obsolete.

May 1, 2011

Table 2. Product Part Numbers Affected by This Announcement

End-of-Sale Product Part Number

Product Description

Replacement Product Part Number

Replacement Product Description

15216-MD16-2-RED=

ITU 100-GHz 16x16 Red multiplexer/demultiplexer

15216-FLA-8-xx.x=

ITU 100-GHz 8-channel FlexLayer Module 15xx.xx to 15xx.xx

15216-MD16-2-BLUE=

ITU 100-GHz 16x16 Blue multiplexer/demultiplexer

15216-FLA-8-xx.x=

ITU 100-GHz 8-channel FlexLayer Module 15xx.xx to 15xx.xx

15216-AD1-2A-30.3=

ITU 100-GHz 1-channel, 2 path optical add/drop multiplexer (OADM), 1530.33 nm with automatic variable optical attenuator (Auto VOA)

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-31.1=

ITU 100-GHz 1-channel, 2 path OADM, 1531.12 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-31.9=

ITU 100-GHz 1-channel, 2 path OADM, 1531.90 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-32.6=

ITU 100-GHz 1-channel, 2 path OADM, 1532.68 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-34.2=

ITU 100-GHz 1-channel, 2 path OADM, 1534.25 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-35.0=

ITU 100-GHz 1-channel, 2 path OADM, 1535.04 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-35.8=

ITU 100-GHz 1-channel, 2 path OADM, 1535.82 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-36.6=

ITU 100-GHz 1-channel, 2 path OADM, 1536.61 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-38.1=

ITU 100-GHz 1-channel, 2 path OADM, 1538.19 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-38.9=

ITU 100-GHz 1-channel, 2 path OADM, 1538.98 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-39.7=

ITU 100-GHz 1-channel, 2 path OADM, 1539.77 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-40.5=

ITU 100-GHz 1-channel, 2 path OADM, 1540.56 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-42.1=

ITU 100-GHz 1-channel, 2 path OADM, 1542.14 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-42.9=

ITU 100-GHz 1-channel, 2 path OADM, 1542.94 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-43.7=

ITU 100-GHz 1-channel, 2 path OADM, 1543.73 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-44.5=

ITU 100-GHz 1-channel, 2 path OADM, 1544.53 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-46.1=

ITU 100-GHz 1-channel, 2 path OADM, 1546.12 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-46.9=

ITU 100-GHz 1-channel, 2 path OADM, 1546.92 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-47.7=

ITU 100-GHz 1-channel, 2 path OADM, 1547.72 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-48.5=

ITU 100-GHz 1-channel, 2 path OADM, 1548.51 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-50.1=

ITU 100-GHz 1-channel, 2 path OADM, 1550.12 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-50.9=

ITU 100-GHz 1-channel, 2 path OADM, 1550.92 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-51.7=

ITU 100-GHz 1-channel, 2 path OADM, 1551.72 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-52.5=

ITU 100-GHz 1-channel, 2 path OADM, 1552.52 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-54.1=

ITU 100-GHz 1-channel, 2 path OADM, 1554.13 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-54.9=

ITU 100-GHz 1-channel, 2 path OADM, 1554.94 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-55.7=

ITU 100-GHz 1-channel, 2 path OADM, 1555.75 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-56.5=

ITU 100-GHz 1-channel, 2 path OADM, 1556.55 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-58.1=

ITU 100-GHz 1-channel, 2 path OADM, 1558.17 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-58.9=

ITU 100-GHz 1-channel, 2 path OADM, 1558.98 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-59.7=

ITU 100-GHz 1-channel, 2 path OADM, 1559.79 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD1-2A-60.6=

ITU 100-GHz 1-channel, 2 path OADM, 1560.61 nm with Auto VOA

Single-channel filter not available; use 2-channel filter instead



15216-AD2-2A-31.1=

ITU 100-GHz 2-channel, 2 path OADM, 1531.12, 1530.33 nm with Auto VOA

15216-FLB-2-31.1=

ITU 100-GHz 2-channel FlexLayer Module 1531.12, 1530.33 nm

15216-AD2-2A-32.6=

ITU 100-GHz 2-channel, 2 path OADM, 1532.68, 1531.90 nm with Auto VOA

15216-FLB-2-32.6=

ITU 100-GHz 2-channel FlexLayer Module 1532.68, 1531.90 nm

15216-AD2-2A-35.0=

ITU 100-GHz 2-channel, 2 path OADM, 1535.04, 1534.25 nm with Auto VOA

15216-FLB-2-35.0=

ITU 100-GHz 2-channel FlexLayer Module 1535.04, 1534.25 nm

15216-AD2-2A-36.6=

ITU 100-GHz 2-channel, 2 path OADM, 1536.61, 1535.82 nm with Auto VOA

15216-FLB-2-36.6=

ITU 100-GHz 2-channel FlexLayer Module 1536.61, 1535.82 nm

15216-AD2-2A-38.9=

ITU 100-GHz 2-channel, 2 path OADM, 1538.98, 1538.19 nm with Auto VOA

15216-FLB-2-38.9=

ITU 100-GHz 2-channel FlexLayer Module 1538.98, 1538.19 nm

15216-AD2-2A-40.5=

ITU 100-GHz 2-channel, 2 path OADM, 1540.56, 1539.77 nm with Auto VOA

15216-FLB-2-40.5=

ITU 100-GHz 2-channel FlexLayer Module 1540.56, 1539.77 nm

15216-AD2-2A-42.9=

ITU 100-GHz 2-channel, 2 path OADM, 1542.94, 1542.14 nm with Auto VOA

15216-FLB-2-42.9=

ITU 100-GHz 2-channel FlexLayer Module 1542.94, 1542.14 nm

15216-AD2-2A-44.5=

ITU 100-GHz 2-channel, 2 path OADM, 1544.53, 1543.73 nm with Auto VOA

15216-FLB-2-44.5=

ITU 100-GHz 2-channel FlexLayer Module 1544.53, 1543.73 nm

15216-AD2-2A-46.9=

ITU 100-GHz 2-channel, 2 path OADM, 1546.92, 1546.12 nm with Auto VOA

15216-FLB-2-46.9=

ITU 100-GHz 2-channel FlexLayer Module 1546.92, 1546.12 nm

15216-AD2-2A-48.5=

ITU 100-GHz 2-channel, 2 path OADM, 1548.51, 1547.72 nm with Auto VOA

15216-FLB-2-48.5=

ITU 100-GHz 2-channel FlexLayer Module 1548.51, 1547.72 nm

15216-AD2-2A-50.9=

ITU 100-GHz 2-channel, 2 path OADM, 1550.92, 1550.12 nm with Auto VOA

15216-FLB-2-50.9=

ITU 100-GHz 2-channel FlexLayer Module 1550.92, 1550.12 nm

15216-AD2-2A-52.5=

ITU 100-GHz 2-channel, 2 path OADM, 1552.52, 1530.33 nm with Auto VOA

15216-FLB-2-52.5=

ITU 100-GHz 2-channel FlexLayer Module 1552.52, 1551.72 nm

15216-AD2-2A-54.9=

ITU 100-GHz 2-channel, 2 path OADM, 1554.94, 1554.13 nm with Auto VOA

15216-FLB-2-54.9=

ITU 100-GHz 2-channel FlexLayer Module 1554.94, 1554.13 nm

15216-AD2-2A-56.5=

ITU 100-GHz 2-channel, 2 path OADM, 1556.55, 1555.75 nm with Auto VOA

15216-FLB-2-56.5=

ITU 100-GHz 2-channel FlexLayer Module 1556.55, 1555.75 nm

15216-AD2-2A-58.9=

ITU 100-GHz 2-channel, 2 path OADM, 1558.98, 1557.36 nm with Auto VOA

15216-FLB-2-58.9=

ITU 100-GHz 2-channel FlexLayer Module 1558.98, 1558.17 nm

15216-AD2-2A-60.6=

ITU 100-GHz 2-channel, 2 path OADM, 1560.61, 1559.79 nm with Auto VOA

15216-FLB-2-60.6=

ITU 100-GHz 2-channel FlexLayer Module 1560.61, 1559.79 nm

15216-AD4-2A-32.6=

ITU 100-GHz 4-channel, 2 path OADM, 1532.68,31.90,31.12,30.33 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-36.6=

ITU 100-GHz 4-channel, 2 path OADM, 1536.61,35.82,35.04,34.25 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-40.5=

ITU 100-GHz 4-channel, 2 path OADM, 1540.56,39.77,38.98,38.19 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-44.1=

ITU 100-GHz 4-channel, 2 path OADM, 1544.15,43.73,42.94,42.14 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-48.5=

ITU 100-GHz 4-channel, 2 path OADM, 1548.51,47.72,46.92,46.12 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-52.5=

ITU 100-GHz 4-channel, 2 path OADM, 1552.52,51.72,50.92,50.12 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-56.5=

ITU 100-GHz 4-channel, 2 path OADM, 1556.55,55.75,54.94,54.13 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



15216-AD4-2A-60.6=

ITU 100 -GHz 4-channel, 2 path OADM, 1560.61,59.79,58.98,58.17 with Auto VOA

4-channel filter not available; use 2- or 8-channel filter



Product Migration Options

The recommended replacement for the Cisco Baudelaire 100-GHz filter set is the Cisco FlexLayer 100-GHz filter set (Table 3). The Cisco FlexLayer 100-GHz filter set is a low-cost alternative to the Baudelaire filter set. The 2- and 8-channel filters enable a granular growth from 2 to 32 channels with low loss.

Table 3. Product Comparisons

Feature

Cisco Baudelaire 100 GHz filter set

Cisco FlexLayer 100 GHz filter set

Allows flexible and granular channel growth in service

No

Yes

Low cost

No

Yes

Built-in attenuators for channel balancing

Yes

No

Passive module (no power requirement)

No

Yes

Customers can use the Cisco Technology Migration Plan (TMP) to trade in products and receive credit toward the purchase of new Cisco equipment. For more information about Cisco TMP, go to: http://www.cisco.com/go/tradein/. The Cisco TMP application requires all users to have a Cisco.com user ID.
Customers may be able to continue to purchase the end-of-sale product through the Cisco Authorized Refurbished Equipment program. Refurbished units of the end-of-sale product are available in limited supply for sale in certain countries on a first-come, first-served basis. For information about the refurbished equipment program, go to: http://www.cisco.com/en/US/ordering/or6/or17/order_refurbished_equipment_program_description.html.

For More Information

For more information about the Cisco Baudelaire 100 GHz filter set, visit http://www.cisco.com/en/US/products/hw/optical/ps1996/index.html or contact your local account representative or pscriven@cisco.com.
For more information about the Cisco End-of-Life Policy, go to: http://www.cisco.com/en/US/products/prod_end_of_life.html.
To subscribe to receive end-of-life/end-of-sale information, go to: http://www.cisco.com/cgi-bin/Support/FieldNoticeTool/field-notice.
